Joy-it ROBOT05 User manual

ROBOT05
Robot car kit for Raspberry Pi & Arduino
1. INTRODUCTION & OVERVIEW
Dear customer,
thank you for choosing our product. In the following, we will show what
you should note at the commissioning and during the usage.
Should you encounter any unexpected problems during use, please do not
hesitate to contact us.
The Robot Car Kit 05 is a construction set which can function as the basic
structure for a car / robot. You must add yourself further components like an
energy source (batteries) and a control like for example an Arduino with a
motor controller. We recommend using Joy-IT appurtenances.
motor voltage 4.5 - 9V DC
current (idle) 190 - 200mA

Included materials:
1x base plate
1x mounting plate
1x mounting plate kit
4x screws (M3x30)
2x screws (M3x10)
1x front axle
2x motors
2x wheels
4x nuts (M3)
2x perforated discs

4x spacers
1x battery compartment
1x switch
4x motor brackets
2. SAFETY INSTRUCTIONS
The device must not be unsupervised. Separate the power supply or rather
the voltage source (e.g. batteries) if you are not using the device. This device
is not a toy. It contains swallowable small parts and it is not appropriate for
children. Acrylic plates can break at an overload.
The motors must not be blocked or overloaded. This can cause a great heat
development. The motor can generate heat during operation, so let the
motors cool down before you touch them. The kit is built for the use in dry
rooms, it must not be wet or moist. Strong solar radiation should be
prevented. Note also the safety instructions of the additionally purchased
components. Especially, during soldering is a high risk of burn injuries.

3. ASSEMBLY
Attention! We recommend installing supply lines for the motors before the
assembly of the vehicle.
First, apply the motor brackets and the switch onto the base plate. But befo-
rehand, remove the yellow protective lm.
The axle hole of the perforated discs have a broad and a slim side. The broad
side should point to the motor. Mount the perforated discs at the motors and
mount them onto the brackets.

Now screw the motor tight.
Mount the battery compartment.

Put in the spacers and mount the front axle.
Now mount the mounting plate with the help of the enclosed mounting pla-
te kit. The according mounting holes for Robot05 are marked on the moun-
ting plate as R1.
The assembly is now nished. You can mount a microcontroller of your
choice on the mounting plate and use the Robot05.

4. INFORMATION AND REDEMPTION OBLIGATIONS
Symbol on electrial and electronic products
This crossed-out bin means that electrical and electronic products do not
belong into the household waste. You must hand over your old appliance
to a registration oice. Before you can hand over the old appliance, you
must remove used batteries and accumulators which are not enclosed by
the device.
Return options :
As the end user, you can hand over with the purchase of a new device
your old appliance (which has essentially the same functions as the new
one) free of charge for disposal. Small devices which do not have outer
dimensions greater than 25 cm can be submitted independently of the
purchase of a new product in normal household quantities.
Possibility of restitution at our company location during our opening
hours :
Simac GmbH, Pascalstr. 8, D-47506 Neukirchen-Vluyn
possibility of restitution nearby :
We send you a parcel stamp with which you can send us your old appliance
free of charge. For this possibility, you must contact us via e-mail at
servic[email protected] or via telephone.
information about packaging:
Please package your old appliance safe during transport. Should you not
have a suitable packaging material or you do not want to use your own
material, you can contact us and we will send you an appropriate package.

5. SUPPORT
If any questions remain open or problems arise aer your purchase, we are
available by e-mail, telephone and with a ticket support system to answer
these.
E-Mail: servic[email protected]
Ticket-System: http://support.joy-it.net
Telephone: [phone] – 66 (10 - 17 o‘clock)
For further information visit our website:
www.joy-it.net
