JRC NSVS1234 User manual

NSVS1234 Oct. 2008
Application
174MHz (BW=22MHz) for GPS-IF
Electrical Specification: (Table 1)
The device characteristics are measured in the circuit shown in Fig.1.
Maximum Rating: (Table 2)
Mechanical Specification: (Fig.2)
Package is designed as small as 5.2x4.5x1.5[mm3] for SMD (Surface Mount Device) type.
Notice:
This part is electrostatic discharge sensitive and may be damaged by improper handling.
Communications Equipment Division
Communications Equipment Marketing Department
10-1, Nishi-Shinjuku 6-chome, Shinjuku-ku,
Tokyo, 160-8328 Japan
Tel. [phone]
Fax. [phone]
http://www.jrc.co.jp/jp/product/device/saw/index.html (Japanese)
http://www.jrc.co.jp/eng/product/saw/index.html(English)
Table 1. Electrical Specifications
Parameter Spec. Typ.
Input and Output Impedance - 50Ω
Nominal Center Frequency (f0) - 174MHz
Insertion Loss 12.0dB max. 10.8dB
Passband Ripple 1.5dB max. 0.9dB
Group Delay Variation 163~185MHz 100ns max. 40ns
124~154MHz 30dB min. 38dBOut of Band Rejection
(Relative to minimum Insertion Loss) 194~224MHz 18dB min. 28dB
(Operating Temperature Range: -40~+85ºC)
Table 2. Maximum Ratings
Parameter Rating
Maximum Input Power +10dBm
Maximum DC Voltage 7.5V
Operating Temperature Range -40~+85ºC
Storage Temperature -40~+85ºC
JRC SAW FILTER
NSVS1234

NSVS1234 Oct. 2008
1.27
1.27
1.0
5.3
1.6
1.0
6.0
Via-Hole(
Φ
0.3)
[6x]
[6x]
[3x]
Marking
(1) Manufacture’s Mark
(2) Lot Number
(a) Year
(b) Month
*Oct.--- X
Nov.--- Y
Dec.--- Z
(C) Date
1-9 --- 0
10-19--- 1
20-31--- 2
(3) Part number Mark
Pin no. Connection
1 GND
2 IN
3 GND
4 GND
5 GND
6 OUT
7 GND
8 GND
Fig.1 Measuring Circuit
Fig.2 Package dimensions (in mm)
Fig.3 Desirable land area (in mm)
IN
50Ω∗OUT
50Ω∗
1
2
3
7
6
5
4
8
SAW
*murata LQW18A series
*
82
nH
*
56
nH
5.2±0.2
4.5±0.2
1.5±0.2
(0.7)
(4-R0.2)
4
3
2
1
5
6
7
8(12-R0.3)
(1.2)(1.55)
(1.27)(1.27)
(0.75)
(0.8)
J8X1
083
(1) (a) (b)
(2)
(3)
[8x]
(1.27)(1.27)
[2x]
[5x]
(C)

NSVS1234 Oct. 2008
Notice
1. Use this component within operating temperature range. It might not be
satisfied with electrical specification without operating temperature range.
When it is used less than -40ºC or more than +85ºC, it might be a cause of
degradation or destruction of the component. Even if it endures during a short
time, it causes degradation of qualification.
2. When soldering iron is used, solder with the temperature at the tip of soldering
iron: 350ºC max., the time of soldering: 10 seconds max., the power of
soldering iron: 30W max..
3. Notice that the allowed time of soldering with soldering iron is accumulated
time, when soldering is repeated.
4. As rapid temperature change for cleaning after reflow soldering might be a
cause of destruction clean this component after confirming that temperature of
this component goes down to room temperature.
5. Confirm that there are not any influence for qualification to this component in
mounting on PCB when this component is cleaned.
6. As it might be a cause of degradation of destruction to apply static electricity to
this component, do not apply static electricity or excessive voltage while
assembling and measuring. And do not transport this component with bare
hand.
7. As it might be a cause of degradation or destruction to apply D.C. voltage
between each terminal, apply D.C. voltage 7.5V max. in actual circuit.
Note
1. This specification specifies the quality of this component as a single unit. Make
sure that this component is evaluated and confirmed against this specification
when it is mounted to your products.
2. The information contained herein may be changed without prior notice. It is
therefore advisable to contact Japan Radio Company before proceeding with the
design of equipment incorporating this product.
3.The products are designed to be used with ordinary electronic equipment (data
and communications equipment, office equipment, audio-video equipment,
measuring instruments, etc). Japan Radio Company does not assume any
liability for the case using the products with the application required high
reliability or safety extremely (such as space equipment, sea-bottom equipment,
medical equipment etc). When intending to use any our product please
contact our sales representatives in advance.

NSVS1234 Oct. 2008
FREQUENCY CHARACTERISTICS
S22
S11
134 154 174 194 214
60
50
40
30
20
10
0
Frequency [MHz]
Insertion Loss [dB]
16
14
12
10
8
6
4
154 164 174 184 194
200
300
400
500
600
700
Frequency [MHz]
Group Delay [ns]
