AUS Pop-Up Powering Outlet
Installation Instructions
How to Install the Outlet
Step 1 - Select a location for the pop-up
outlet that meets the following requirements:
• The edge of the cut out should be at least
40mm from the nearest wall.
• A power outlet should be within 1.5 meters
of the installation cut out for the power cord
to reach.
Step 2 - Cut a hole in surface of the
countertop using the above requirements of
your corresponding model.
of space needed
under countertop
of space needed
under countertop
of space needed
under countertop
countertop
thickness
countertop
thickness
Cut out size
Cut out size
Cut out size
400mm
400mm
405mm
10-45mm
10-45mm
0290-00902-AUS
0290-00902QI-AUS
0290-00904-AUS
0290-00904QI-AUS
0290-00903PQI-AUS
COVER
OVERLOAD SWITCH
MODULE
RELEASE BUTTON
POWER CORD
BODY
FIXED RING
BOTTOM CAP
0290-00902-AUS
0290-00902QI-AUS
0290-00902-AUS
0290-00902QI-AUS
0290-00903PQI-AUS
• For indoor use only.
• Avoid liquid owing into the socket.
• Be sure to ground connection.
• Do not disassemble without permission.
• If something goes wrong, please have
repaired by a professional.
CAUTION – READ CAREFULLY
Visit our Support Library at
support.dockingdrawer.com to nd additional
mounting diagrams and cut out templates.
95-100mm
95-100mm
105mm
countertop
thickness
10-50mm
To Open - Use palm to press the center of
the cover. Release your palm and the product
will pop up. Lift the outlet body until the product
locks into place.
Electric Control - The red on/o switch
controls the power. Product will be in a state of
power when the switch is OFF. Product will be
powered when switch is ON.
To Close - Press the “Push to Release”
button. Push the body back into the table, then
press the center of the cover with your palm to
lock.
Have questions? Need help? Call us!
+1 (530) 205-3625
12893 Alcosta Blvd, Suite M,
San Ramon, CA 94583
www.dockingdrawer.com
Docking
Drawer
Duo™
CHARGING
Style
Drawer
Trio™
POWERING
Complete Outlet Lineup
Perfect for charging
cell phones, tablets,
and tness trackers.
Perfect for powering
hair dryers, curling
irons, and small
kitchen appliances.
AG111819
How to Use the Outlet
Step 3 - Rotate the xed ring in a
counterclockwise direction to remove, and then
place the bottom of the outlet body into the cut
out hole of the countertop.
Step 4 - Adjust the front of the product to
face in the desired direction. Under the counter,
reattach the xed ring and rotate in a clockwise
direction to tighten. Note that when the xed
ring is askew, it will get stuck. If this occurs, re-
tighten after alignment.
Step 5 - Connect power cord to the nearest
power outlet, product can be used normally.
