Julian Bowen Limited Rialto User manual

Julian Bowen Limited
Rialto 135cm Bed
Assembly Instructions
VERSION: 161216 01

03
Hardware
Parts
A
Allen Key M8 X 1pc
B
Bolts M8 X 20mm X 8pcs
C
Allen Key M6 X 1pc
D
Bolts M6 X 70mm X 4pcs
E
Bolts M6 X 50mm X 5pcs
F
Bolts M6 X 40mm X 4pcs
G
Spring Washers X 2pcs
H
Flat Washers X 2pcs
I
Dowel M8 X 30mm X 4pcs
J
Foot Pads X 7pcs
1
2
3
3
3
3
4
4
56
7
7
7
8
8
9
10
10

04
Safety Advise
Please take the time to carefully read through the whole of these
instructions before you commence.
Keep these instructions for future reference.
Unpack, inspect andcheck off all of the contents.
Please dispose of all packaging safety.
Small component part could choke a child if swallowed.
We strongly recommend that you keep children well away from
the work area.
It would be sensible to lay a sheet or blanket on the floor where
you intend to work to avoid scratching this product and to protect
your floor.
This product is heavy. Take extreme care when lifting to avoid
personal injury or damage to the product.
Assemble the product as close to its intended final position in the
room as possible.
We strongly urge that you do not use Power Tools, Such as drills
or electric screwdrivers during this assembly as this could cause
irreparable damage to your product and will invalidate the
warranty.
HANDY HINT: If you keep the hardware in a bowl during
assembly you will be less likely to lose them.

05
STEP 1
STEP 2
2
1
C
D
I
3
3
J
Please note that the straight cut
side of the leg is always facing outside
4
4
2
1
AB
X 8

06
STEP 3
STEP 4
E
C
F
C
5
7
7
7
X 3
X 4
J
This bed may fail if it is used on a wooden floor WITHOUT the use of non slip pads on
all support legs and bed posts.

07
STEP 5
STEP 6
C
E
G
H
6
88
9
10
10
X 24
X 13
X 2
Urgent Warning
When correctly adjusted the centre support legs on this product should be raised by 5mm from the
floor with the added weight of the mattress and bedding. This bed may fail if it is used on a wooden
floor WITHOUT the use of non slip pads on all support legs and bed posts If the bed is to be moved,
carefully lift the product rather than dragging to ensure that the centre legs do not become twisted
and buckle.

08
Your Rialto Bed is ready for use
