JUMO mTRON T User guide

JUMO mTRON T
Measuring, Control, and Automation System
B 705000.8
System Description
2014-05-06/00575652
- Web browser
- Setup program
- PC Evaluation Software PCA3000
- PCA Communication Software PCC
- Plant Visualization Software SVS3000
- Programming system CODESYS
LAN
Com2
RS422/485 or RS232,
Modbus master/slave
or
PROFIBUS-DP slave
System bus
Com1
RS422/485 or RS232,
Modbus master/slave
Com1
Com2
USB
RS422/485 or RS232,
Modbus master/slave,
connection for bar code scanner
RS422/485 or RS232,
Modbus master/slave,
connection for bar code scanner
Host and device
max. 100 m
max. 100 m

3
Contents
1Introduction......................... . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
1.1 Structure of this system description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.2 The JUMO mTRON T measuring, control, and automation system . . . . . . . . . . . . . . . . . . . . . . . 8
1.2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2.2 Brief description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2.3 Base units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.2.4 Input/output modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.2.5 Special modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.2.6 Operating, visualization, recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.2.7 Power supply units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.2.8 PC programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.3 Content of the technical documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1.3.1 Device documentation in printed form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1.3.2 Device documentation in the form of PDF files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
1.3.3 Documentation for optional software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
1.3.4 Device documentation on the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
1.3.5 Training documents on the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
1.4 Available technical documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
1.4.1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
1.4.2 Base units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
1.4.3 Input/output modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
1.4.4 Special modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
1.4.5 Operating, visualization, recording . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
1.4.6 Power supply units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2Safetyinformation..................... . . . . . . . . . . . . . . . . . . . . . . . . . . .23
2.1 Warning symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.2 Note signs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.3 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.4 Qualification of personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3 Acceptance of goods, storage, and transport . . . . . . . . . . . . . . . . . . . . . . . . .25
3.1 Checking the delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.2 Notes on storage and transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.3 Returning goods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.3.1 Accompanying letter for repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.3.2 Protection against electrostatic discharge (ESD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.4 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4Identifyingthedeviceversion............. . . . . . . . . . . . . . . . . . . . . . . . . .27
4.1 Nameplates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.2 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.3 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Contents
4
4.3.1 General accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.3.2 Central processing unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.3.3 Controller module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5Installation......................... . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
5.1 General information on installation/dismounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5.2 Module sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.2.1 System with centralized module assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.2.2 System with decentralized module assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.3 Installation/dismounting on DIN rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.3.1 Base units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.3.2 Input/output modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5.3.3 Special modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.4 Mounting in a panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.4.1 Multifunction panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.5 Replacing module inserts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.5.1 Input/output modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.5.2 Special modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
6Electricalconnection.................. . . . . . . . . . . . . . . . . . . . . . . . . . . .51
6.1 Installation notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
6.2 Electrical isolation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
6.3 Voltage supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6.4 Current load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
6.5 System bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
7Startupandconfiguration............... . . . . . . . . . . . . . . . . . . . . . . . . . .63
7.1 Setup program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7.2 Multifunction panel 840 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
8Appendix.......................... . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
8.1 General technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.1.1 Directives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.1.2 Electrical safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.1.3 Protection type according to DIN EN 60529 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.1.4 Protection rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.1.5 EMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.1.6 Voltage supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.1.7 Ambient requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
8.1.8 Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
8.1.9 Climatic tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
8.1.10 Mechanical tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

5
Contents
8.2 System expansion (system version 02) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
8.3 Training courses/seminars . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Contents
6

7
1 Introduction
1.1 Structure of this system description
This system description, which is also a component of the system manual (accessories), de-
scribes features that relate to the overall measuring, control, and automation system or are
equally applicable for all modules.
The complete scope of information for each module is contained in the downloadable operating
manuals.
Content of the individual sections
NOTE!
The user should follow the individual sections of this system description step for step to gain
an overview of the measuring, control, and automation system and the available technical
documentation.
Section Explanation
1 Introduction • Initial information on the measuring, control, and automation sys-
tem
•Findouthowthetechnicaldocumentationisstructured
2 Safety information • Symbols and types of figures used and their meanings
3 Receipt of goods, storage,
and transport
•Checkingthedeliveryfordamageandcompleteness
•Notesonstorageandtransport
•Handlingthepackagingmaterial
•Notesondisposal
4 Identifying the
device version
• Detecting which device version is indicated by the specifications
on the nameplate
5 Installation • Correctly fitting or installing the devices, taking into consideration
the prevailing climatic conditions at the installation location
6 Electrical connection • Safely connecting the devices, taking into consideration the "in-
stallation notes"
7 Startup and
configuration
•Startingupandconfiguringthesystemusingthesetupprogram
(overview).
•Configuringandoperatingthesystemusingthemultifunctionpan-
el (overview).
NOTE!
All additional information is module-specific and is contained in the respective index divider
of the system manual and in the downloadable operating manuals.

1 Introduction
8
1.2 The JUMO mTRON T measuring, control, and automation
system
1.2.1 Overview
1.2.2 Brief description
The modular measuring, control, and automation system is suitable for the precise detection,
regulation, control, and recording. Special features of the system are the easy operation and
the corresponding software components, the high measuring accuracy and regulation quality
as well as the sturdy and service-friendly mechanical system.
An application consists of a base unit (central processing unit), a maximum of 30 input/output
modules (multichannel controller module, analog input module 4-channel, analog input module
8-channel, digital input/output module 12-channel), and if necessary the multifunction panel, up
to four operating panels, and router modules for distributed module arrangement. For user-
friendly all-in-one solutions, various PC programs are available.
Automation solutions for small and medium size machine lines are possible due to the integra-
tion of an optional PLC including programming system according to IEC 61131-3.
The base unit is equipped with a sturdy metal case; the router module and the input and output
modules are equipped with a plastic case. All these devices can be fitted on a 35 mm DIN rail.
The multifunction panel with TFT touch screen has a metal case with decor foil and is intended
for mounting into a panel cut-out.
The system operates at a voltage of DC 24 V. The supply of operating voltage is only required
at the base unit (central processing unit), at the router module, and at the multifunction panel.
- Web browser
- Setup program
- PC Evaluation Software PCA3000
- PCA Communication Software PCC
- Plant Visualization Software SVS3000
- Programming system CODESYS
LAN
Com2
RS422/485 or RS232,
Modbus master/slave
or
PROFIBUS-DP slave
System bus
Com1
RS422/485 or RS232,
Modbus master/slave
Com1
Com2
USB
RS422/485 or RS232,
Modbus master/slave,
connection for bar code scanner
RS422/485 or RS232,
Modbus master/slave,
connection for bar code scanner
Host and device
max. 100 m
max. 100 m

9
1 Introduction
1.2.3 Base units
•Thebaseunit,upto30input/outputmodules,andupto30routermodulescanbeusedto
build a compact and economic central or decentral measuring, control, and automation sys-
tem (visualization and operation either with the multifunction panel or the plant visualization
software JUMO SVS3000).
• The base units contain the process image of the application. Furthermore, all configuration
and parameter data of the system are stored in these modules (except for the multifunction
panel). As a result, individual input/output modules can be replaced with Plug and Play.
•AllbaseunitsoperateatavoltagesupplyofDC24V.
• The setup program or the multifunction panel can be used to comfortably configure and pa-
rameterize the base units.
• LEDs are used to indicate the voltage supply as well as the operating status of a module
and of the interfaces.
Central processing unit
Additional base units in preparation.
•Thecentralprocessingunitisthebasisforthemaximumex-
tension of the system
•Nineprogramgenerators(option)
• 64 limit values are monitored
•AnintegratedPLCacc.toIEC61131-3(option)
• Math and logic function (option) for all connected multichannel
controller modules
• Two interfaces for field bus applications; optional:
- RS232, Modbus RTU as master or slave
- RS422/485 Modbus RTU as master or slave
- PROFIBUS-DP as slave (as of system version 02)
• One USB device interface (setup)
•Systembusconnectionatthefront(BusOut)
• A LAN interface (Ethernet) for HTTP and Modbus/TCP as
master and slave
• Integrated web server
•E-mailtransmission
•Thecentralprocessingunitoperatesatavoltagesupplyof
DC 24 V and supplies the connected input/output modules
•Dimensions(WxHxD):135mmx101mmx67.1mm
(without connection elements)
For further information: Refer to data sheet 705001

1 Introduction
10
1.2.4 Input/output modules
• The modules are equipped with removable terminal strips with Push-In technology for the
electrical connection.
•Allinput/outputmodulesoperateatavoltagesupplyofDC24V.
• The setup program, the multifunction panel or the optional PLC can be used to comfortably
configure and parameterize the modules.
• LEDs are used to indicate the voltage supply as well as the operating status of a module
and the input/output statuses.
• For service work (replacement) or adding optional boards, the module insert can be easily
pulled out of the case at the front.
Multichannel controller module
• 2-channel PID controller with relay output or logic output
to control solid-state relays
• Up to 4 PID controller channels can be activated (cascadable)
•Twouniversalanaloginputs,twodigitalinputs
(DC 0/24 V) and two digital outputs (relay or logic DC 0/15 V)
• Supported measuring probes: Thermocouples, RTD tempera-
ture probes, resistance transmitters, resistance/potentiome-
ters, or standard signals (current or voltage)
•Theanaloginputsareelectricallyisolatedfromeachother
• Three option slots for the extension of up to four
universal analog inputs, eight digital inputs,
three analog outputs, or eight digital outputs
• Supported controller types: Two-state controller, three-state
controller, modulating controller, continuous controller, or con-
tinuous controller with integrated actuator controller
• Customer-specific linearization possible by using a formula
• Limit value monitoring
• Four formulae for math and logic functions (option)
• One counting input up to 10 kHz
• The module operates independently (configurable) which
means the control task is carried out even if the base unit or
the higher-ranking system malfunctions
•Ifthecontrollerisreplacedduringserviceworkthenewcon-
troller (identical type) is automatically configured
•Dimensions(WxHxD):45mmx103.6mmx101.5mm
(without connection elements)
For further information: Refer to data sheet 705010

11
1 Introduction
Relay module 4-channel
Analog input module 4-channel
Analog input module 8-channel
• Four relay outputs controlled via the system bus by digital sig-
nals
•Eachrelayisequippedwithachangeovercontact
AC 230 V / 3 A
•Separateterminalstripperrelayoutput
• Automatic configuration after the module insert has been ex-
changed during service work
•Dimensions(WxHxD):22.5mmx103.6mmx101.5mm
(without connection elements)
For further information: Refer to data sheet 705015
• Four universal analog inputs
• Supported measuring probes: Thermocouples, RTD tempera-
ture probes, resistance transmitters, resistance/potentiome-
ters or standard signals (current or voltage)
•Theanaloginputsareelectricallyisolatedfromeachother
•Customer-specificlinearizationpossible by using a formula or
up to 45 pairs of values
• Limit value monitoring
• Automatic configuration after the module insert has been ex-
changed during service work
•Adigitalinput(DC0/24V)isalsoprovided
•Dimensions(WxHxD):22.5mmx103.6mmx101.5mm
(without connection elements)
For further information: Refer to data sheet 705020
•EightanaloginputsforRTDtemperatureprobesPt100,Pt500
or Pt1000 in 2-wire circuit
• The analog inputs are not electrically isolated from each other
• Limit value monitoring
• Automatic configuration after the module insert has been ex-
changed during service work
•Adigitalinput(DC0/24V)isalsoprovided
•Dimensions(WxHxD):22.5mmx103.6mmx101.5mm
(without connection elements)
For further information: Refer to data sheet 705021

1 Introduction
12
Digital input/output module 12-channel
1.2.5 Special modules
Router module
•12channelswhichcanberespectively configured as digital in-
puts (DC 0/24 V) or as digital outputs (DC 0/24 V, 500 mA)
• Supply of external voltage through terminal at the front
• Automatic configuration after the module insert has been ex-
changed during service work
•Dimensions(WxHxD):22.5mmx103.6mmx101.5mm
(without connection elements)
For further information: Refer to data sheet 705030
• The router module distributes the input/output modules to
several DIN rails/control cabinets (decentralized arrangement)
•Itusesthesystembustolinkmodules to the base unit or the
multifunction panel
• Up to 100 m distance between two router modules or between
a router module and the base unit or the multifunction panel
• Up to 30 router modules are possible
•TheroutermoduleoperatesatavoltagesupplyofDC24Vand
supplies the connected input/output modules
• No configuration of the router module required
•ForapplicationssuchasHotConnect,forexample,thead-
dress of the router module can be set by rotary coding switch-
es
• Three RJ45 system bus connections at the front
(1 ×Bus In, 2 ×Bus Out), electrically isolated
•Dimensions(WxHxD):22.5mmx103.6mmx101.5mm
(without connection elements)
For further information: Refer to data sheet 705040

13
1 Introduction
1.2.6 Operating, visualization, recording
Multifunction panel 840
• Touchscreen with front made of aluminum incl. design foil
(IP67)
• TFT color monitor 21.3 cm (8.4”),
resolution 640 x 480 pixels, 256 colors, with LED backlight
• As an interface between man and machine it allows an optimal
and clearly-arranged view of the process statuses and param-
eters of the system
•Display(inrealtime)andoperationofcontrollerscreen,pro-
cess screen, program editor, and recording function (option)
• Configuration of all connected modules
• Setpoint values and batch texts are directly entered on the
screen
• Data archiving and evaluation with PC
• The multifunction panel operates at a voltage supply of
DC 24 V
•Asetupprogramcanbeusedtocomfortablyconfigurethe
multifunction panel
• Two interfaces for field bus applications; optional:
- RS232, Modbus RTU as master or slave
- RS422/485, Modbus RTU as master or slave
• One USB device interface (setup)
• Two USB host interfaces (memory stick)
•Twosystembusconnections(BusInandBusOut)
• A LAN interface (Ethernet) for HTTP and Modbus/TCP as
master and slave
• Integrated web server
•E-mailtransmission
• Connection possibility for barcode scanner
•Dimensions(WxHxD):235mmx195mmx58mm
For further information: Refer to data sheet 705060

1 Introduction
14
Operating panels 350, 570, 1040
•TFTcolordisplay(64kcolors) with resistiv-touch technology
• Display sizes 8.9 cm (3.5''), 14.5 cm (5.7''), and 26.4 cm
(10.4'')
• Display resolutions 320 ×240pixelsand640×480 pixels
•Differentcasematerials(plastics,metal)
•ProtectiontypeIP65(atthefront)
•VoltagesupplyDC24V
•Ethernetinterface(RJ45)forconnectiontothesystem
•Uptofouroperatingpanelspercentral processing unit (PLC
option required)
• Specific process screens for operating the system
•DirectaccesstoPLCvariables
System structure:
For further information: Refer to data sheet 705065

15
1 Introduction
1.2.7 Power supply units
Power supply units 705090/...
•VoltagesupplyAC100V...240V
• 150 % peak load capability (for typical 4 s)
• Minimum current inrush
• Floating DC-OK relay contact
•Efficiencyupto93.5%
•Activepowerfactorcorrection(PFC)
•Activefilteragainstmainstransients
• Quick connection due to spring-cage terminals
•Dimensions(WxHxD):
705090/05-33: 40 mm x 130.5 mm x 121.5 mm
705090/10-33: 60 mm x 130.5 mm x 121.5 mm
For further information: Refer to data sheet 705090

1 Introduction
16
1.2.8 PC programs
Setup program
PC Evaluation Software PCA3000
PCA Communication Software PCC
Setup program for project planning and configuration of the entire
measuring, control, and automation system
A complete PLC can be activated as an option.
The setup program is distinguished by:
•User-friendlyconfiguration,parameterization,andstartupof
the base units, the input/output modules, and the multifunction
panel
•AutomaticimportofthehardwareconfigurationintothePLC
programming software CODESYS
•Programeditor
• Process screen editor
The project file contains all data that is relevant for the configura-
tion, parameterization, and visualization. The file also contains the
controller programs and, if applicable, the customer-specific PLC
code.
For further information: Refer to operating manual 705000.6
Professional evaluation software to manage, archive, visualize and
evaluate process data (measuring data, batch data, messages, ...)
The process data can be imported via USB memory stick or pro-
vided by the software PCC.
•Datamemory:Clearlyarrangedandeasybackupandar-
chiving of all process data in a data file
•Databackup:ArchivedatacandirectlybeimportedfromCD/
DVD and then displayed
• Data export: Data export to HTML level or ASCII text file
(for evaluation in Excel) or customer-specific forms
• Communication: The communication software PCC optimally
adapted to PCA3000 can be used to comfortably import data
via an interface or a modem
For further information: Refer to operating manual 709701.0
The communication software PCC optimally adapted to PCA3000
can be used to comfortably import data via an interface or modem.
• Data memory: Clearly-arranged, easy backup and archiving of
all process data in a data file
• Teleservice function (display of the process data)
For further information: Refer to operating manual 709702.0

17
1 Introduction
Plant Visualization Software JUMO SVS3000
Plant Visualization Software for online visualization, batch report-
ing and operation of the measuring, control and automation system
with a networked PC
This software ensures quick familiarity and easy creation of appli-
cations. The user is able to quickly configure an individual applica-
tion according to his/her requirements due to the prepared masks
(process, group, trend screens).
•Easyandquickapplication creation
• Extensive library with predefined graphical elements
• System operation via group masks
• Extensive documentation function with continuous and batch
related evaluation
•Searchfunctionfordate/time,plant,andbatchcriteriatobe
defined
•Automaticprintanddataexport
•Recipefunction
• Quick and easy commissioning/startup due to installation
menu
• Alarm and event list
• Password protected
•Historyandrealtimetrend
• Network compatible
•Connectionofbarcodescanner
•Remotealerting(optional)
For further information: Refer to data sheet 700755

1 Introduction
18
1.3 Content of the technical documentation
The documentation for the measuring, control, and automation system is intended for plant
manufacturers and users with specialist training. It has a modular structure and comprises dif-
ferent sections.
1.3.1 Device documentation in printed form
B 7050XX.4
Installation instructions
A hard copy of the installation instructions is included in the scope of delivery of every module.
The installation instructions describe the installation of the device and the connection of the
supply and signal cables. They also contain the order details and a list of technical data.
The scope of delivery for a power supply unit includes a hard copy of the operating instructions.
These include information on installation and electrical connection.
B 705000.0
System manual
A hard copy of the system manual can be provided as an accessory subject to charge.
The system manual describes the scope of services of the measuring, control, and automation
system and provides all information for project design and startup.
Index divider 1 "System description" summarizes the information applicable to all modules.
Module-specific descriptions in the following sections complement the specifications stated
here.
Index divider 2 "Setup program" describes the project design of the overall system.
1.3.2 Device documentation in the form of PDF files
The device documentation files specified below are saved as PDF files on the DVD contained
in the scope of delivery of a base unit.
T 705000
Data sheet
The data sheet provides general information on the measuring, control, and automation system
and forms the basis for plant planning and purchase decisions.
T 7050XX
Data sheet
The data sheets of the individual modules provide specific information, order details, and tech-
nical data.
B 7050XX.0
Operating manual
The operating manuals of the individual modules contain all information on installation, electri-
cal connection, startup, operation, and – if required – parameterization and configuration.

19
1 Introduction
B 7050XX.2.0
Interface description (Modbus interface)
It provides information on communication with other devices or superordinate systems using
the Modbus protocol (Modbus RTU, Modbus TCP).
B 7050XX.4
Installation instructions
The installation instructions describe the installation of the device and the connection of the
supply and signal cables. The instructions also contain a list of the technical data.
B 7050XX.5.X
Operating manual (application)
The operating manual describes the use of a certain application (e. g. PLC application).
1.3.3 Documentation for optional software
The manuals specified below are available on the Internet as PDF files. They also form part of
the scope of delivery of the respective software.
B 705000.6
Setup program
The manual describes the function of the setup program.
B 709701.0
PC evaluation software PCA3000
The operating manual describes the operation and the features of the PC evaluation software.
The PC evaluation software helps to visualize and evaluate the recorded process data (mea-
surement data, batch data, messages, etc.).
B 709702.0
PCA communication software PCC
The operating manual describes the operation and the features of the PCA communication
software. The PCA communication software is responsible for the data transfer from a device
or system to a PC or to a network.
B 700755.0
Plant visualization software SVS3000
The operating manual describes the operation and features of the plant visualization software.
The plant visualization software is responsible for networking interface-ready process devices
with a PC.

1 Introduction
20
1.3.4 Device documentation on the Internet
All documents are available for download on the Internet at www.jumo.net.
Download procedure:
1.3.5 Training documents on the Internet
Training documents (eLearning courses) on various topics are available at www.jumo.net.
Procedure:
Step Action
1OntheJUMOwebsite,enterthenumberoftherelevantproductgroupinthesearchfieldat
the top right (e.g. 705001 for the central processing unit) and start the search.
The search results are listed.
2 Select product (click the link).
3Inthe"Documentation"dropdownlist,selectthedesireddocumentationintherequired
national language (click the link).
4 +++++Open the PDF document or save it as a file.
Step Action
1OntheJUMOwebsite,navigateto the "Support/Services" area.
2Inthe"Information&Training"menuontheleft-hand side, select "eLearning courses".
3 Click the link "Review of our eLearning courses".
4 Select the desired eLearning course from the overview (click the link).
The presentation starts.
