HBX SensorLinx WPS-0014 User manual

HBX Control Systems Inc.
Installation Manual
SensorLinx™ Pressure Sensor Installation Guide
Version 2.0.3
WPS-0014
WPS-0030
WPS-0070
WPS-0130
WPS-0400

© 2021 HBX Controls2
INTRODUCTION
This manual will help with the installation, parameter setting, trouble shooting and general
maintenance requirements for the Controller. To guarantee the safe and reliable operation
of this Control, you must rst read this manual in detail and take particular note to any and all
warnings or caution directives prior to connecting to AC power.
Only suitably qualied individuals with formal training in electrical and HVAC controls should
attempt the installation of this equipment. Incorrect wiring and installation will affect the
warranty provided with this unit. Wiring must be completed in accordance with the codes and
practices applicable to the jurisdiction for the actual installation.
The HBX Sensorlinx™ Metering System is a microprocessor based controller and as such is not
to be regarded as a safety (limit) control. Please consult and install the heating or cooling
appliance in accordance with the manufacturer’s recommendations.
SAFETY SYMBOLS AND WARNINGS
ExtrEmE Hazard
This action poses a serious threat that could result in personal injury or death, as well as
permanent damage to the equipment. Proceed with caution.
modEratE Hazard
This action may cause personal injury or have adverse effects on the installation
process if handled incorrectly.
disconnEct PowEr sourcE
The presence of low voltage (24VAC) or high voltage (120VAC) could result in personal
injury or permanent damage to components or equipment. Point of Interest - This point
claries pertinent information, or brings your attention to an action that may have
adverse effects on the installation process.
TABLE OF CONTENTS
Introduction Index
Safety symbols and Warnings Index
Receipt and Inspection 1
Storage 1
Nameplate Information 1
Technical Data and Information 2 - 5
Description and Main Parts 2
Technical Data and Dimensions 3
Flow Sensor Technical Specications 4
Pressure Sensor Technical Specications 5
Installation Guide 6-8
Device Wiring 6-8
Installation 9-10
ThermoLinx App Setup 11-13
Connecting to a Network (Android) 11
Connecting to a Network (iOS) 12-13
Adding Sensors to the ThermoLinx App 14
Navigating the ThermoLinx App 15
Local Connection 16
Limited Warranty 17
Index
WARNING: This product can expose you to chemicals including lead, which is known to
the State of California to cause cancer and birth defects or other reproductive harm. For
more information go to www.P65Warnings.ca.gov.
!

1
RECEIPT & INSPECTION
After receiving, inspect the unit for any possible physical damage that may have
occurred during transportation. After unpacking the unit make sure the box contains:
• 1 x WPS-0100 (Temperature & Pressure Sensor)
• 2 x EPDM Flat Washers
• 1 x Dual unions, tailpieces - NPT, sweat, press
• 1 x Flow pipe and tube with connection ttings
• Instruction Manual
Make sure the part number on the unit corresponds to the part number on
the original box
STORAGE
The Sensorlinx™ Heat Meter should be kept in its original shipping carton prior to
installation. In order to retain the warranty coverage it should be stored properly:
• Store within an ambient temperature range of +10ºC to +40ºC
• If possible, store in an air-conditioned environment where the relative humidity is
less than 95%
• Do not store in places where the unit may come into contact with corrosive
gases or liquids
• Do not store in an area or upon an unstable surface where it may become
damaged due to falling
NAME AND PIN INFORMATION
The label displays the serial number which will match the serial number on your
actual HBX Sensorlinx™ Sensor, the lot number, the bar code and the products PIN.
Sync Code: APRE1234
PIN: 1A2B3
WiFi Pressure Sensor
WFS-0100
3068143
Conforms to EN 1434
Conforms to UL Standard 873
Certified to CSA C22.2 No 24
READY
SERVER
WI-FI

© 2021 HBX Controls2
WPS-0100
Sync Code: AFLO1234
PIN: 1A2B3
12
34567
8
DESCRIPTION AND MAIN PARTS
dEscriPtion
The SensorLinx™ Sensor System is designed to measure and record the thermal energy
used in a residential or commercial heating or cooling system including HVAC, Solar
thermal heating and Geothermal. The sensors can be used individually to track many
system parameter congurations in real time using the HBX ThermoLinx™ App. When
the Sensorlinx™ sensors are used in conjunction within your liquid system, the system
allows for accurate Heat measurement.
SENSOR REPLACEMENT: If one of the sensors fails or must be replaced when
being used in Heat Meter conguration, both the WFS and WPS sensors must
be replaced, as they come pre-paired.
comPonEnts
1. Power Supply Cable: 24V.
2. Wi-Fi Set Button: Press set button to connect to local Wi-Fi network or create local
Wi-Fi connection.
3. NPT Tail Piece: Tailpiece to connect to return/supply piping.
4. Flow Tube: Composite or Stainless steel option.
5. Sensor Clip: Secure the sensor inside the ow pipe. Clip must be ush with the ow
pipe.
6. EPDM Flat Washer: Washer must be placed inside before installation.
7. Flow Tube Union: Brass Union
8. Name Plate: Contains sensor Sync-Code

3
Input Voltage: 24VAC, ±10%, 60Hz, 0.1A
1 x Thermistor Output: Tank
1 x Modulating Output: 0.5VDC - 3.5VDC
Microprocessor: 8Bit, 64MHz
Languages: English
Temperature Measuring Range: 10-90 °C
(50-194 °F)
Max. Pressure Range: 0-10 bar (0-145 psig)
WiFi: 2.4GHz Network Only
FCC ID: 2AHMRESP125
Liquid Types:
Aqueous media compatible with wetted
materials. Kinematic viscosity less than or
equal to 2 mm2/s (cSt). Potable Water, or
a water mixture with Glycol, Methanol, or
Ethanol.
ETL Listings:
Meets CSA C22.2
No. 24 Meets UL Standard 873
ETL Control No. 3068143
Storage: +10ºC to +40ºC
TECHNICAL DATA AND DIMENSIONS
WPS-0014 WPS-0030 WPS-0070 WPS-0130 WPS-0400
mm 82 88 129 137.5 180
in 3.23 3.46 5.08 5.41 7.09
L/MIN 1.4 -14 3-30 7-70 13-130 20-400
GPM 0.36-3.69 0.70-7.92 1.84-18.49 3.43-34.34 5.28-105.67
Flow Tube House Flow Tube
Size
Union Pipe
Cong. Torque Pressure Range
Part
Number
N/A N/A 1/2"
(NPT Threaded nipple)
5 ft-lb /
6.78 N m
< 10 BAR
(145 PSI) WPS-0010
Composite,
Stainless 1/2" 3/4"
(G Thread)
5 ft-lb /
6.78 N m
< 10 BAR
(145 PSI) WPS-0014
Composite,
Stainless 1/2" 3/4"
(G Thread)
5 ft-lb /
6.78 N m
< 10 BAR
(145 PSI) WPS-0030
Composite,
Stainless 3/4" 1"
(G Thread) < 10 BAR (145 PSI) WPS-0070
Composite,
Stainless 1" 1 1/4"
(G Thread) < 10 BAR (145 PSI) WPS-0130
Composite 1 1/4" 1 1/2"
(G Thread) < 10 BAR (145 PSI) WPS-0400
No pipe tape/dope
should be used on
threads.

© 2021 HBX Controls4
PRESSURE SENSOR TECHNICAL SPECIFICATIONS
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0 0120
[V]
Temperature output signal
Tmax = Peak temperature
[V]
P max
Pressure output signal
Selection of flow sensor to minimise pressure drop at 1 cSt
Head loss:
0.002
0.001
0.003
0.004
0.005
0.006
0.008
0.01
0.02
0.03
0.04
0.05
0.06
0.08
0.1
0.2
0.3
0.4
0.5
0.6
Δp [bar]
0.029
0.015
0.044
0.058
0.073
0.087
0.116
0.15
0.29
0.44
0.58
0.73
0.87
1.16
1.5
2.9
4.4
5.8
7.3
8.7
[psi]
0.3 0.4 0.6 0.8 11.2 1.5 2 3 4 5 6 8 10 12 15 20 30 40 50 60 80 100 150 200300Q [m3/h ]
0.0003
0.0004
0.0005
0.0006
0.0008
0.0044
0.0058
0.0073
0.0087
0.0116
Q[gpm (US)]
4.626.2 264.2 8.253.5 528.3 60111 1057 7.9 79.3 792.5 1316 21 159
DN18 SBB
DN25 SBB
DN32 SBB
DN40 SBB
DN50 SBB
DN65 SBB
DN80 SBB
DN100 SBB
[psig]

5
DEVICE WIRING
1/2: Input Power: This input is to power the sensor. 1 Amps at 24VAC is required to
power this device.
3. Ground Power: This input is for the ground wire. WPS Sensor must be grounded to
the pipe. Refer to Device Wiring (Page 7-8).
4. Thermistor Input: Pins 4, 3 Optional temperature sensor. (Ex. Tank temp)
Under no circumstance should power be applied to these terminals!
Permanent damage to the controller’s circuitry may result.
5. Triac Output: Pins 5, 2 This input is to send a triac output to energize a relay. 24VAC
is required to power the triac. Optional
6: Modulating Output: This output carries the modulating signal (0.5 – 3.5 VDC) to
modulate the device. Optional
124 VAC R (Red)
24 VAC C (White)
Ground (Blue)
Thermistor Input (Yellow)
24 VAC Triac Output, 0.5A Max (Green)
Modulating Output (Black)
2
3
4
5
6

© 2021 HBX Controls6
R
C
L
N
120 VAC
24 V AC
DEVICE WIRING
Standard Pressure and Temperature Sensor Installation
Ensure the R and W wires from each
unit are hooked up to the same
corresponding wire. Do not cross wire!

7
dEscriPtion
Install the temperature and pressure sensor in a location that will be easy to perform
periodic maintenance. Install shut-off valves upstream and downstream of the
sensors to aid installation and maintenance. Install a strainer or other ltering device
upstream of the ow and pressure sensors.
The rst length of straight of pipe connected to the ow sensor must be a
minimum of 3” long prior to a bend for the sensor to register a proper reading.
using Fluids otHEr tHan watEr; glycol, mEtHanol, EtHanol
Recommended Fluid Concentration
Heating: 0-50%
Cooling: 0-30%
Fluids other than water must factor that the Kinematic viscosity less than or
equal to 2 mm2/s (cSt). Heat measurement calculations performance will be
affected by the viscosity.
While initially lling the system take care to not produce any water hammer
at the sensor. Slowly increase initial ow and pressure to the sensor. Failure to
do so can cause the sensor to fail.
INSTALLATION
No pipe tape/dope
should be used on
threads.
Sensor can be mounted
Vetically or horizontally
within a 180 arc.
Sensor CANNOT be
mounted pointing below
this line or downwards.

© 2021 HBX Controls8
INSTALLATION
Installation with Optional Solenoid Valves
Standard Pressure and Temperature Sensor Installation
