Juna JAUX BT-02 User manual

www.juna.pl
ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND
JuNa PPHU Manufacturer
The JAUX_BT-02 device is started after pressing the button MEDIA
and then the SOURCE button on the radio control panel fig.1. Using
the main navigation knob of the AUDI system RNS-E select from
the list the Bluetooth/AUX option fig.1.
2.Start up
The JAUX_BT-02 module is operated using the factory system
multimedia Audi RNS-E. The device uses a platform Audi Music
Interface expanding multimedia capabilities of the vehicle by analog
line input connection and streaming sound from mobile devices via
Bluetooth. JAUX_BT-02 allows you to control basic playback functions
(PLAY, PAUSE, NEXT, PREV, FF, REW) as well as displaying the title,
album, artist of the currently played song.
Multimedia player for CAR
JAUX_BT-02 Model:
JAUX_BT-02_AUDI_RNS-E
1.Introduction
USER MANUAL
AUDI RNS-E
11111
11112
1111
1
11112
3
11111
11113
fig.1

2
4.2
3.AUX/Bluetooth support
The JAUX_BT-02 module allow to listen music from an analog input
linear AUX and wireless BT stream. Aux function is always available
when BT connection is not established. Aux input is automaticly
disconnected when BT connection is established fig.2.
The JAUX BT-02 module allows you to pair the device using the
function Bluetooth only if it is not currently connected to another mobile
device using this function fig.2.
4.2
4.Bluetooth support
IMPORTANT: AUX Line input can’t control external device.
Screen view in the absence of a connected device.
www.juna.pl
ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND
JuNa PPHU Manufacturer
fig.2

1
www.juna.pl
ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND
JuNa PPHU Manufacturer
4.2
4.2.Bluetooth support
Switching and rewinding of tracks is performed using lateral ones
function keys or by mobile device connected to the JAUX_BT-02
module fig.3.
After selecting a device from the list, you may need to enter the code
1234 fig.4.
fig.4
fig.3
Found the device.
Audi-BT
1234

www.juna.pl
ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND
JuNa PPHU Manufacturer
After properly pairing, the mobile device should connect to the
JAUX_BT-02 module starts automatically playing music.
Nazwa urządzenia
fig.5
4.2
4.3.Bluetooth support
Tytuł uworu
Nazwa albumu
Wykonawca
Czas utworu
Widok ekranu z podłączonym smartfonem przez bluetooth
Switching and rewinding of tracks is performed using lateral ones
function keys and using a connected mobile device to the JAUX_BT-02
module fig.6.
fig.6
Important: Some applications that play media on mobile devices can limit or not operate
functions (PLAY, PAUSE, NEXT, PREV, FF, REW) and displaying the title,
album, artist of the currently playing song, etc
