Juna JRDAB-01 User manual

DAB/DAB+ module for CAR
JRDAB-01 Model:
JRDAB-01 MOST for MMI
INSTALLATION MANUAL
1. INTRODUCTION ....................................................................
2. RECOMMENDATIONS ..........................................................
3. CONNECTION DIAGRAM OF KIT COMPONENTS ..............
4. ANTENNA CONNECTING ....................................................
5. DAB/DAB+ MODULE CONNECTION DIAGRAM ..................
6. BASIC TECHNICAL PARAMETERS ......................................
7. ELEMENTS OF THE SET .......................................................
ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND
JuNa PPHU Manufacturer
Table of Contents
2
2
4
5
6
7
7
FAQ

1. INTRODUCTION
ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND
JuNa PPHU Manufacturer
Digital DAB/DAB+ tuner for factory AUDI MMI systems. JRDAB-01 allows to receive
digital radio services DAB/DAB+. The device has function of tracking selected service
while driving SERVICE FOLLOWING. Fully integrates with MOST optical system.
Easy Installation.
2. RECOMMENDATIONS
Copyright
All assembly and operating instructions are protected by copyright. Distributing
documentation via print or online media is only allowed with the prior consent of
JUNA electronics.
Important
Please read installation manual very careful and keep it in right way. During
installation, pay attention to all relevant aspects related to safety of installation and
use of the device.
The priority during the design and production of all devices by JUNA electronics
company is security and service comfort. It has been achieved by applying the
modern techniques of design and production processes of electronic devices.
Module should be installed in technical workshops by qualified personnel or
by people who have experience in this type of installations. Installation of devices by
not qualification people can cause injury to persons or damage to property.
It is recommended keep to the general safety rules and pay attention for any
threat that can cause of damage to the vehicle.
We advice to mount device in safety place, where it is not exposed for moisture,
water or too high temperatures.
2

ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND
JuNa PPHU Manufacturer
Device should not be installed in places where it could difficult safe driving or
operating efficiency of other units installed in vehicle.
The devices can be connected only to 12V. Modules can't be used in vehicles with
24V and higher voltage.
Please note that most of our devices are based on software that may require an
update. That's why you should always mount the device in easily available place in
the vehicle.
In some countries it may be necessary to check the legal provisions before
installation and startup of the device. In the interest of high quality and development
of our products, JUNA Electronics reserves the right to make technical changes.
In the case of a warranty claim, the device should be sent back to the seller in
original packaging with a detailed description of the problem with attached
purchase invoice.
Warranty claims as well as exploitation rights expire due:
A) Not authorized changes in devices or accessories, which have not been approved
or have not been provided by the manufacturer or his partners.
B) Opening the device's box
C) Yourself repair the device
D) Improper use / improper operation of the device
E) Mechanical damage
F) Flooding with water or other liquids
2.2 RECOMMENDATIONS
3

ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND
JuNa PPHU Manufacturer
3. CONNECTION DIAGRAM OF KIT COMPONENTS
4
The correct location of the JRDAB-01 assembly components.
1. Connection point for the JRDAB-01 radio module for: AUDI A8 4H
2. Connection point for the JRDAB-01 radio module for: AUDI A4, AUDI A5,
AUDI A6, AUDI A7, AUDI A8 4E, AUDI Q5
3. Connection point for the JRDAB-01 radio module for: AUDI Q7 4L
4. Place of mounting the antenna from the set (as an option if not used
factory antenna)
4
3
2
12
2
2
1
3
33
4
Pic.1

ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND
JuNa PPHU Manufacturer
4. ANTENNA CONNECTION
The device in addition to the possibility of connecting the DAB/DAB+ antenna included
in the set, allow to connect the factory antenna set which includes the factory antenna with
the antenna amplifier mounted most often on the tailgate of the luggage compartment.
The amplifier is powered from the JRDAB module with 12 voltage.
Important:
During installation antenna cable along the pistol it is necessary to pay attention for side airbags.
Cable must be installed in way to not disturb the proper operation of the air curtain.
Installation process:
1) Installation of antenna is not recommended when windscreen is very cold
2) Antenna should be mounted on windscreen from passenger side
3) Carefully remove the passenger side pistol cover
4) Clean a place where antenna will be mounted
5) Antenna should be mounted 15 cm from top edge and 7 cm from side edge of windscreen
6) Ground element of antenna amplifier should touch metal part of post. It can be join to factory
painted part of pistol
7) Antenna cable should be mounted in way to not interference with side airbag
15cm
7cm
Grounding the antenna
with the vehicle body
Antenna
Antenna amplifier
Antenna cable - 6m
Grounding element
Example of mounting a DAB/DAB+ antenna
Antenna DAB/DAB+
To join a metal ground component of antenna
amplifier remove top safety cover. Join copper
ground component with metal part of cars pistol.
Before antenna installation on windscreen remove
top safety cover.
5
Pic.2

1. Turn off the ignition and MMI system in the vehicle
2. Disconnect the original fiber optic connector
3. Connect the K-SW101 socket to the original fiber optic connector
4. Connect the K-SW101 plug to the original fiber optic socket
5. Connect the K-SW101 plug to the JRDAB-01 module socket
6. Connect the W-ZAS101 plug to the JRDAB-01 module socket
7. Connect the red and black wires to the QUADLOCK
8. Connect the FAKRA antenna plug to the aerial socket
9. Turn on the ignition switch and start the vehicle radio
10. Perform the station search process
ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND
JuNa PPHU Manufacturer
Important:
We recommend connecting the JRDAB module power supply to QUADLOCK
due to the constant power supply of the system.
Pic.3
1
2
2
1
33
3
4
4
5
5
6
5. DAB/DAB+ MODULE CONNECTION DIAGRAM

6. BASIC TECHNICAL PARAMETERS
ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND
JuNa PPHU Manufacturer
1. Power supply voltage
2. Communication and control
3. Housing
4. Dimensions
5. Weight
7. ELEMENTS OF THE SET
1. DAB/DAB+ radio module [JRDAB-01]
2. Connection cables [W-ZAS101]
3. Fiber optic cable- [K-SW101]
4. Antenna [TLG7205]
- 12V (+10,5V - 14,8V)
- MOST bus
- Metal
- 90mm x 35mm x 65mm
- 95g
7
Pic.4
