Juniper JRR200 Installation instructions

JRR200 Route Reector Hardware Guide
Published
2022-11-29

Juniper Networks, Inc.
1133 Innovaon Way
Sunnyvale, California 94089
USA
408-745-2000
www.juniper.net
Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc.
in the United States and other countries. All other trademarks, service marks, registered marks, or registered service
marks are the property of their respecve owners.
Juniper Networks assumes no responsibility for any inaccuracies in this document. Juniper Networks reserves the right
to change, modify, transfer, or otherwise revise this publicaon without noce.
JRR200 Route Reector Hardware Guide
Copyright © 2022 Juniper Networks, Inc. All rights reserved.
The informaon in this document is current as of the date on the tle page.
YEAR 2000 NOTICE
Juniper Networks hardware and soware products are Year 2000 compliant. Junos OS has no known me-related
limitaons through the year 2038. However, the NTP applicaon is known to have some diculty in the year 2036.
END USER LICENSE AGREEMENT
The Juniper Networks product that is the subject of this technical documentaon consists of (or is intended for use
with) Juniper Networks soware. Use of such soware is subject to the terms and condions of the End User License
Agreement ("EULA") posted at hps://support.juniper.net/support/eula/. By downloading, installing or using such
soware, you agree to the terms and condions of that EULA.
ii

Table of Contents
About This Guide | viii
1
Overview
JRR200 Route Reector Overview | 2
JRR200 Route Reector System Overview | 2
JRR200 Route Reector Field-Replaceable Units | 2
JRR200 Chassis | 3
JRR200 Route Reector Chassis Front Panel | 3
JRR200 Route Reector Chassis Rear Panel | 7
JRR200 Route Reector Physical Specicaons | 8
JRR200 Route Reector Cooling System | 9
JRR200 Route Reector Air Flow and Cooling System | 9
JRR200 Power System | 10
JRR200 Route Reector AC Power Supply | 11
JRR200 Route Reector AC Power Supply Specicaons | 12
JRR200 Route Reector AC Power Cord Specicaons | 13
JRR200 Route Reector DC Power Supply | 15
JRR200 Route Reector DC Power Supply Specicaons | 16
2
Site Planning, Preparaon, and Specicaons
Site Preparaon Checklist for the JRR200 Route Reector | 19
JRR200 Site Guidelines and Requirements | 20
JRR200 Route Reector Environmental Specicaons | 21
General Site Guidelines | 21
Site Electrical Wiring Guidelines | 22
Clearance Requirements for JRR200 Route Reector Airow and Hardware Maintenance | 23
iii

JRR200 Rack and Cabinet Requirements | 24
JRR200 Route Reector Rack Requirements | 24
JRR200 Route Reector Cabinet Requirements | 25
JRR200 Network Cable and Transceiver Planning | 26
Pluggable Transceivers Supported on JRR200 Route Reector | 27
SFP+ Direct Aach Copper Cables for JRR200 Route Reector | 27
JRR200 Management and Console Port Connector Pinout Specicaons | 28
Management Port Connector Pinout Informaon for the JRR200 Route Reector | 28
Console Port Connector Pinout Informaon for the JRR200 Route Reector | 29
3
Inial Installaon and Conguraon
JRR200 Route Reector Installaon Overview | 32
Installing and Connecng an JRR200 Route Reector Installaon Overview | 32
Unpacking the JRR200 | 33
Unpacking the JRR200 Route Reector | 33
Verifying Parts Received with the JRR200 Route Reector | 33
Installing the JRR200 Route Reector in a Rack | 35
Connecng the JRR200 to Power | 38
Connect the Grounding Cable | 38
Connecng Power to an AC-Powered JRR200 Route Reector | 39
Connecng Power to a DC-Powered JRR200 Route Reector | 41
Connecng JRR200 Route Reector to External Devices | 43
Connecng JRR200 Route Reector to Management Devices | 43
Performing the Inial Conguraon for JRR200 | 44
JRR200 Route Reector Inial Conguraon Using the CLI | 44
JRR200 Route Reector Factory-Default Sengs | 46
Viewing Factory-Default Sengs of JRR200 Route Reector | 48
4
Maintaining Components
iv

Maintaining the JRR200 Chassis | 51
Roune Maintenance Procedures for the JRR200 Route Reector | 51
Maintaining the JRR200 Cooling System | 51
Maintaining the Fan Trays on the JRR200 Route Reector | 52
Replacing the JRR200 Route Reector Fan Tray | 53
Maintaining the JRR200 Power System | 54
Maintaining the JRR200 Route Reector Power Supplies | 54
Replacing the JRR200 Route Reector AC Power Supply | 55
Removing a JRR200 Route Reector AC Power Supply | 56
Installing a JRR200 Route Reector AC Power Supply | 57
Replacing the JRR200 Route Reector DC Power Supply | 58
Removing a JRR200 Route Reector DC Power Supply | 58
Installing a JRR200 Route Reector DC Power Supply | 59
Maintaining the JRR200 Cables and Connectors | 60
Maintaining JRR200 Route Reector Network Cables | 60
Replacing an SFP+ Transceiver on JRR200 Route Reector | 62
Removing an SFP+ Transceiver | 62
Installing an SFP+ Transceiver | 63
5
Troubleshoong Hardware
Troubleshoong the JRR200 | 66
Troubleshoong Resources for JRR200 Route Reector | 66
Chassis Component Alarm Condions on JRR200 Route Reector | 66
6
Contacng Customer Support and Returning the Chassis or Components
Returning the JRR200 Chassis or Components | 72
Returning a JRR200 Route Reector or Hardware Component to Juniper Networks | 72
Lisng the JRR200 Route Reector Component Details with the CLI | 73
Locang the Serial Number on the JRR200 Route Reector or Component | 74
Locang the Chassis Serial Number ID Label | 74
Locang the Serial Number ID Labels on FRUs | 74
v

Contacng Customer Support | 74
Packing a JRR200 Route Reector or its Components for Shipping | 75
Packing the JRR200 Route Reector for Shipment | 76
Packing the JRR200 Route Reector Components for Shipment | 76
7
Safety and Compliance Informaon
General Safety Guidelines and Warnings | 80
Denions of Safety Warning Levels | 81
Restricted Access Warning | 83
Fire Safety Requirements | 84
Qualied Personnel Warning | 85
Warning Statement for Norway and Sweden | 86
Installaon Instrucons Warning | 86
Chassis and Component Liing Guidelines | 87
Ramp Warning | 88
Rack-Mounng and Cabinet-Mounng Warnings | 88
Grounded Equipment Warning | 92
Laser and LED Safety Guidelines and Warnings | 93
Radiaon from Open Port Apertures Warning | 96
Maintenance and Operaonal Safety Guidelines and Warnings | 97
General Electrical Safety Guidelines and Warnings | 103
Prevenon of Electrostac Discharge Damage | 104
AC Power Electrical Safety Guidelines | 106
AC Power Disconnecon Warning | 107
DC Power Disconnecon Warning | 108
DC Power Grounding Requirements and Warning | 109
DC Power Wiring Sequence Warning | 110
vi

DC Power Wiring Terminaons Warning | 112
Mulple Power Supplies Disconnecon Warning | 113
TN Power Warning | 114
Acon to Take Aer an Electrical Accident | 114
JRR200 Agency Approvals and Regulatory Compliance Informaon | 115
Agency Approvals | 115
Acousc Noise Compliance Statements | 117
EMC Requirements | 117
vii

About This Guide
Use this guide to install hardware and perform inial soware conguraon, roune maintenance, and
troubleshoong for the JRR200 Route Reector.
Aer compleng the installaon and basic conguraon procedures covered in this guide, refer to the
Junos OS documentaon for informaon about further soware conguraon.
RELATED DOCUMENTATION
JRR200 Route Reector Quick Start
viii

1
CHAPTER
Overview
JRR200 Route Reector Overview | 2
JRR200 Chassis | 3
JRR200 Route Reector Cooling System | 9
JRR200 Power System | 10

JRR200 Route Reector Overview
IN THIS SECTION
JRR200 Route Reector System Overview | 2
JRR200 Route Reector Field-Replaceable Units | 2
JRR200 Route Reector System Overview
The Juniper Networks JRR200 Route Reector is a 1U form factor appliance with a mulcore x86 CPU
and preinstalled vRR soware that can host one route reector instance. The JRR200 route reector is
suitable for large enterprises, data centers and service providers for hosng vRR soware to scale up to
30 million roung informaon base (RIB) entries.
The JRR200 route reector comes with eight 1/10 Gigabit Ethernet SFP+ ports, 64 GB of DDR4
memory, and two 240-GB solid-state drives (SSDs) in a RAID1 conguraon. The JRR200 route reector
is available in both AC and DC models which support Zero Touch Provisioning mode (ZTP) to ensure
seamless inseron into the network and provide operaonal simplicity.
• JRR200 Route Reector (AC) — JRR200 Route Reector with dual redundant AC power supplies
• JRR200 Route Reector (DC) — JRR200 Route Reector with dual redundant DC power supplies
JRR200 Route Reector Field-Replaceable Units
Field-replaceable units (FRUs) are components that you can replace at your site. The FRUs on the
JRR200 route reector can be removed and replaced without powering o the route reector. The
JRR200 route reector supports the following FRUs:
• AC power supply units
• DC power supply units
• Fan trays
2

JRR200 Chassis
IN THIS SECTION
JRR200 Route Reector Chassis Front Panel | 3
JRR200 Route Reector Chassis Rear Panel | 7
JRR200 Route Reector Physical Specicaons | 8
JRR200 Route Reector Chassis Front Panel
IN THIS SECTION
JRR200 Route Reector Chassis Status LEDs | 4
Management Port LEDs | 5
Network Port LEDs | 6
Figure 1 on page 3 shows the front panel of the JRR200 route reector.
Figure 1: JRR200 Route Reector Front Panel
Table 1 on page 4 lists the components on the front panel of the JRR200 route reector.
3

Table 1: JRR200 Route Reector Components on the Front Panel
Number Component Descripon
1 Management port Gigabit Ethernet port to connect to the device over the network.
2 USB ports Two USB 2.0 ports that accept a USB storage device.
3 HA ports The two HA ports are not supported on the JRR200 route reector.
4 SFP+ ports Eight 1-Gigabit Ethernet/10-Gigabit Ethernet SFP+ ports for network trac.
5 LEDs Indicate component and system status at a glance.
6 Console port Connects a laptop to the JRR200 route reector for CLI management. The port
uses an RJ-45 serial connecon, is congured as DTE, and supports the RS-232
(EIA-232) standard.
7RESET buon Returns the JRR200 route reector to the factory-default conguraon.
JRR200 Route Reector Chassis Status LEDs
Figure 2 on page 4 shows the chassis status LEDs that are located on the front panel of the JRR200
route reector. Table 2 on page 5 describes the LEDs.
Figure 2: JRR200 Route Reector Chassis Status LEDs
4

Table 2: JRR200 Route Reector Chassis Status LEDs
LED Descripon
Power •Solid green—receiving power
Status •Solid green—operang normally
•Solid red—crical alarm
•Hardware component failure
•Soware module failure
•Fan failure (atleast one)
•Blinking red—noncrical alarm
•O—the system is not receiving power
SSD •Blinking green—indicates hard disk drive (SSD) acvity
Management Port LEDs
The management port has two LEDs that indicate link acvity and status of the management port.
Table 3 on page 5 describes the LEDs.
Table 3: Management Port LEDs
LED Descripon
Link/Acvity (LED on
the le)
•Solid amber—A link is established, but there is no acvity on the link.
•Blinking amber—There is link acvity.
•O—There is no link established.
5

Table 3: Management Port LEDs (Connued)
LED Descripon
Speed (LED on the right) •Solid green—100-Mbps link is established.
•Solid amber—1000-Mbps link is established.
•O—There is no link established.
Network Port LEDs
Each SFP+ port has two status LEDs located above the port. Table 4 on page 6 describes the LEDs.
Figure 3 on page 6 shows the LEDs.
Figure 3: Network Port LEDs
Table 4: Network Port LEDs
Callout LED Descripon
1 Link (LED on the
le)
•Solid green—There is link acvity.
•O—There is no link established.
2Speed/Acvity
(LED on the right)
•Solid amber—10G/1G link is established.
•Blinking amber—There is acvity on the 10G/1G link.
•O—There is no link established.
6

JRR200 Route Reector Chassis Rear Panel
Figure 4 on page 7 shows the rear panel of the JRR200 Route Reector. Table 5 on page 7 lists and
describes the rear panel components.
Figure 4: JRR200 Route Reector Rear Panel
Table 5: JRR200 Route Reector Rear Panel Components
Number Component Descripon
1 Grounding point Connects the JRR200 route reector chassis to earth ground.
2 Power switch Use the Power switch to power on or power o the JRR200 route reector.
3 Alarm O buon Use this buon to turn o an alarm triggered because of an abnormal DC output
voltage caused by any of the following:
•Only one power supply unit is plugged in.
•The AC power cord is not plugged in.
•The power supply unit is not funconal and there is no DC output.
4 ESD point For personal safety, while working on the JRR200 route reector, use the ESD
outlet to plug in an ESD grounding strap to prevent your body from sending stac
charges to the route reector.
7

Table 5: JRR200 Route Reector Rear Panel Components (Connued)
Number Component Descripon
5 Fan trays Four fan trays for cooling the JRR200 route reector and its components. Each fan
tray contains two fans.
Three fan trays are required for proper air ow across the chassis internal
components. The fourth fan tray provides redundancy.
6 Power supply Two power supply slots. Each power supply contains a power cord outlet. Two
650-W DC or AC power supplies are provided with the JRR200 route reector.
JRR200 Route Reector Physical Specicaons
The JRR200 Route Reector chassis is a rigid sheet metal structure that houses all the components.
Table 6 on page 8 lists the physical specicaons of the chassis.
Table 6: Physical Specicaons of the JRR200 Route Reector Chassis
Descripon Value
Chassis height 1.75 in. (4.45 cm)
Chassis width 17.48 in. (44.40 cm)
Chassis depth 25 in. (63.50 cm)
Weight •JRR200 route reector with 2 AC power supplies: 29 lb (13.16 kg)
•JRR200 route reector with 2 DC power supplies: 28.8 lb (13.06 kg)
You can mount the JRR200 route reector on a standard 19-in. four-post rack or in a standard 19-in.
enclosed cabinet.
8

JRR200 Route Reector Cooling System
IN THIS SECTION
JRR200 Route Reector Air Flow and Cooling System | 9
JRR200 Route Reector Air Flow and Cooling System
The cooling system for the JRR200 Route Reector consists of four fan trays located at the rear of the
chassis. Each fan tray contains two fans, so there are a total of eight fans. The fans draw cool air through
vents on the front of the chassis and exhaust the air through the back of the chassis. See Figure 5 on
page 10. The airow produced by the fans keeps device components within the acceptable
temperature range.
If any one of the four fan trays fails, the JRR200 route reector generates a warning but keeps the
system running. If the temperature keeps rising, the JRR200 route reector lowers the power
consumpon by reducing the performance or shung down some of the chassis components. However,
if the ambient maximum temperature exceeds the warning level and the system cannot be adequately
cooled, then the JRR200 route reector shuts down the system and hardware components completely.
9

The fan tray is a eld-replaceable unit (FRU)and you can install it without powering o the JRR200 route
reector or disrupng the route reector funcon.
Figure 5: Airow Through the Chassis
JRR200 Power System
IN THIS SECTION
JRR200 Route Reector AC Power Supply | 11
JRR200 Route Reector AC Power Supply Specicaons | 12
JRR200 Route Reector AC Power Cord Specicaons | 13
JRR200 Route Reector DC Power Supply | 15
JRR200 Route Reector DC Power Supply Specicaons | 16
10

JRR200 Route Reector AC Power Supply
The JRR200 Route Reector is shipped with two redundant AC power supply units pre-installed in the
rear panel of the chassis. The AC power supply unit is a eld-replaceable unit (FRU) and you can install it
without powering o the JRR200 route reector or disrupng the route reector funcon. If one power
supply unit fails or is removed, the other power supply unit redistributes the electrical load without
interrupon. Each power supply unit is cooled by its own internal cooling system.
Each AC power supply unit weighs approximately 2.3 lb and consists of one AC appliance inlet, a fan,
and LEDs for monitoring the status of the power supply unit. It gives an output of 650 W and supports
both low line voltage (100–127 VAC) and high line voltage (200–240 VAC). Figure 6 on page 11 shows
the AC power supply unit.
Figure 6: AC Power Supply Unit
Each AC power supply unit faceplate contains three LEDs that indicate the status of the power supply.
Figure 7 on page 11 shows the locaon of the LEDs on an AC power supply unit.
Figure 7: AC Power Supply Unit LEDs
Table 7 on page 12 describes the AC power supply unit LEDs.
11

Table 7: AC Power Supply Unit LEDs
LED Color State Descripon
AC Unlit O Indicates one of the following:
•Power input voltage is not within the normal
operang range.
•No power input.
Green Steady Input power present and is within the normal operang
range.
DC Unlit O No DC power output or abnormal DC output.
Green On steadily DC power output is within the normal operang range.
! (Fault) Amber On steadily Power supply unit failure.
Blinking Invalid power supply unit.
Unlit O Power supply unit is funconing normally.
NOTE:
• If both the AC LED and the DC LED are unlit, either the AC power cord is not installed
properly or the power supply unit fuse has failed.
• If the AC LED is lit and the DC LED is unlit, the AC power supply unit is installed properly, but
the power supply unit has an internal failure.
JRR200 Route Reector AC Power Supply Specicaons
Table 8 on page 13 lists the specicaons for an AC power supply.
12
