Juniper ERX - RELEASE 11.1.X MODULE GUIDE 4-6-2010 User manual

E Series™Broadband Services Routers
ERX™Module Guide
Release 11.1.x
Juniper Networks, Inc.
1194 North Mathilda Avenue
Sunnyvale, California 94089
USA
408-745-2000
www.juniper.net
Published: 2010-04-06

This guide provides an overview and description of the line modules (LMs), switch
route processor (SRP) modules, and I/O modules available for the following Juniper
Networks E Series Broadband Services Routers: ERX14xx models, ERX7xx models,
and the ERX310 router.
Unless otherwise specified, all line modules pair with I/O modules to create a module
combination. Each module combination provides particular capabilities and
connections in an ERX router.
NOTE: A release may support multiple versions of a module. For information, see
Software Compatibility in JUNOSe System Basics Configuration Guide, Chapter 6,
Managing Modules.
Table 1 on page 3 lists the module combinations supported by ERX routers.
This book also contains three appendixes:
■Module Protocol Support on page 107
■Module LEDs on page 133
■Module Name Cross-Reference Information on page 139
■Product Reclamation and Recycling Program on page 143
For more information about ERX routers and modules, refer to the following books:
■Modules that have reached end-of-life—ERX End-of-Life Module Guide
■Module installation and maintenance—ERX Hardware Guide
■Managing ERX routers—JUNOSe System Basics Configuration Guide
■Configuring ERX modules—JUNOSe Link Layer Configuration Guide
2■
ERX 11.1.x Module Guide

Table 1: ERX Module Combinations
Page
First
JUNOSe
Support
I/O Module
Label
Line Module
LabelCombination Name and Type
Channelized OC3/STM1
92.2.0cOC3 STM1 F0
I/O
MULTIMODE
cOCx/STMx
F0
cOC3/STM1 multimode
112.2.0cOC3 STM1 F0
I/O
SINGLE MODE
cOCx/STMx
F0
cOC3/STM1 single-mode intermediate
reach
132.2.0cOC3 STM1 F0
I/O
LONG HAUL
cOCx/STMx
F0
cOC3/STM1 single-mode long reach
Channelized OC12/STM4
152.2.0cOC12 STM4
F0 I/O
MULTI MODE
cOCx/STMx
F0
cOC12/STM4 multimode without APS/MSP
redundancy
172.2.0cOC12 STM4
F0 I/O
SINGLE MODE
cOCx/STMx
F0
cOC12/STM4 single-mode intermediate
reach without APS/MSP redundancy
196.1.3,
7.0.2,
7.2.0
COC12 F0 APS
SINGLE MODE
cOCx/STMx
F0
cOC12/STM4 single-mode intermediate
reach with APS/MSP redundancy
212.2.0cOC12 STM4
LONG HAUL
cOCx/STMx
F0
cOC12/STM4 single-mode long reach
Channelized T3
233.2.0CT3/T3 12 I/OCT3/T3-F0CT3/T3 12 (12 ports)
E3
244.0.2E3-12
FRAME I/O
COCX-F3E3 Frame (12 ports)
Fast Ethernet
255.0.0FE-8 I/OGE/FEFE-8 (8 ports) (256-MB memory)
266.0.0FE-8 SFP I/OGE/FEFE-8 SFP (8 ports) (256-MB memory)
Gigabit Ethernet (1-port)
285.0.0GE I/O SFPGE/FEGE 1000Base-SX (256-MB memory)
■3

Table 1: ERX Module Combinations (continued)
Page
First
JUNOSe
Support
I/O Module
Label
Line Module
LabelCombination Name and Type
305.0.0GE I/O SFPGE/FEGE 1000Base-LH (256-MB memory)
325.0.0GE I/O SFPGE/FEGE 1000Base-ZX (256-MB memory)
342.0.0GE I/O
MULTI MODE
GE/FEGE multimode
362.0.0GE I/O
SINGLE MODE
GE/FEGE single-mode
Gigabit Ethernet (2-port)
385.3.0GE-2 SFP I/O
or
2XGE APS I/O
SFP or
GE-2 APS I/O
SFP
GE-2GE2 1000Base-SX
405.3.0GE-2 SFP I/O
or
2XGE APS I/O
SFP or
GE-2 APS I/O
SFP
GE-2GE2 1000Base-LH
425.3.0GE-2 SFP I/O
or
2XGE APS I/O
SFP or
GE-2 APS I/O
SFP
GE-2GE2 1000Base-ZX
GE High Density (HDE)
447.0.0GE-2 SFP I/O
or
2XGE APS I/O
SFP or
GE-2 APS I/O
SFP
GE-HDEGE High Density (2 ports)
467.0.0GE-8 I/OGE-HDEGE High Density (8 ports)
4■
ERX 11.1.x Module Guide

Table 1: ERX Module Combinations (continued)
Page
First
JUNOSe
Support
I/O Module
Label
Line Module
LabelCombination Name and Type
IPSec Service
484.0.2No I/O moduleIPSEC
SERVICE
IPSec Service
OC3/STM1 ATM
495.0.0,
5.3.0
OC3-4 I/O
MULTI MODE
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
OC3/STM1 ATM multimode without
APS/MSP redundancy (256-MB memory)
515.1.2
5.2.0
(APS/MSP)
4XOC3 APS
I/O
MULTI MODE
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
OC3/STM1 ATM multimode with APS/MSP
redundancy
535.0.0,
5.3.0
OC3-4 I/O
SINGLE MODE
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
OC3/STM1 ATM single-mode intermediate
reach without APS/MSP redundancy
(256-MB memory)
555.1.2
5.2.0
(APS/MSP)
4XOC3
APS I/O
SINGLE MODE
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
OC3/STM1 ATM single-mode intermediate
reach with APS/MSP redundancy
575.0.0,
5.3.0
OC3-4 I/O
LONG HAUL
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
OC3/STM1 ATM single-mode long reach
without APS/MSP redundancy (256-MB
memory)
OC3/STM1 GE/FE
596.1.0OC3–2 GE
APS I/O
OC3/STM1
GE/FE
OC3/STM1 GE/FE
OC3/STM1 POS
632.0.0OC3-4 I/O
MULTI MODE
OCx/STMx
POS
OC3/STM1 POS multimode without
APS/MSP redundancy
655.1.2
5.2.0
(APS/MSP)
4XOC3 APS
I/O
MULTI MODE
OCx/STMx
POS
OC3/STM1 POS multimode with APS/MSP
redundancy
672.0.0OC3-4 I/O
SINGLE MODE
OCx/STMx
POS
OC3/STM1 POS single-mode intermediate
reach without APS/MSP redundancy
■5

Table 1: ERX Module Combinations (continued)
Page
First
JUNOSe
Support
I/O Module
Label
Line Module
LabelCombination Name and Type
695.1.2
5.2.0
(APS/MSP)
4XOC3 APS
I/O
SINGLE MODE
OCx/STMx
POS
OC3/STM1 POS single-mode intermediate
reach with APS/MSP redundancy
712.0.0OC3-4 I/O
LONG HAUL
OCx/STMx
POS
OC3/STM1 POS single-mode long reach
OC12/STM4 ATM
735.0.0,
5.3.0
OC12 STM4
I/O
MULTI MODE
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
OC12/STM4 ATM multimode without
APS/MSP redundancy (256-MB memory)
752.0.0 (128
MB)
5.0.0 (256
MB)
OC12 STM4
APS
MULTI MODE
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
OC12/STM4 ATM multimode with
APS/MSP redundancy
775.0.0,
5.3.0
OC12 STM4
I/O
SINGLE MODE
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
OC12/STM4 ATM single-mode
intermediate reach without APS/MSP
redundancy (256-MB memory)
792.0.0 (128
MB)
5.0.0 (256
MB)
OC12 STM4
APS
SINGLE MODE
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
OC12/STM4 ATM single-mode
intermediate reach with APS/MSP
redundancy
815.0.0,
5.3.0
OC12 STM4
I/O
LONG HAUL
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
OC12/STM4 ATM single-mode long reach
without APS/MSP redundancy (256-MB
memory)
832.0.0 (128
MB)
5.0.0 (256
MB)
OC12 STM4
APS
LONG HAUL
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
OC12/STM4 ATM single-mode long reach
with APS/MSP redundancy
OC12/STM4 POS
852.0.0OC12 STM4
I/O
MULTI MODE
OCx/STMx
POS
OC12/STM4 POS multimode without
APS/MSP redundancy
6■
ERX 11.1.x Module Guide

Table 1: ERX Module Combinations (continued)
Page
First
JUNOSe
Support
I/O Module
Label
Line Module
LabelCombination Name and Type
872.0.0OC12 STM4
APS
MULTI MODE
OCx/STMx
POS
OC12/STM4 POS multimode with
APS/MSP redundancy
892.0.0OC12 STM4
I/O
SINGLE MODE
OCx/STMx
POS
OC12/STM4 POS single-mode
intermediate reach without APS/MSP
redundancy
912.0.0OC12 STM4
APS
SINGLE MODE
OCx/STMx
POS
OC12/STM4 POS single-mode
intermediate reach with APS/MSP
redundancy
932.0.0OC12 STM4
I/O
LONG HAUL
OCx/STMx
POS
OC12/STM4 POS single-mode long reach
without APS/MSP redundancy
952.0.0OC12 STM4
APS
LONG HAUL
OCx/STMx
POS
OC12/STM4 POS single-mode long reach
with APS/MSP redundancy
OC48/STM16
974.1.xOC48 FRAME
APS
OC48OC48/STM16 POS single-mode short reach
Service Module (SM)
985.1.0No I/O moduleSERVICE
MODULE
SM
SRPs
994.1.3,
5.0.4,
5.1.2,
5.2.0
SRP I/OSRP-5G+SRP-5G+ (1-GB memory)
1004.1.3,
5.0.4,
5.1.2,
5.2.0
SRP I/OSRP-5G+SRP-5G+ (2-GB memory)
1014.1.3,
5.0.4,
5.1.2,
5.2.0
SRP I/OSRP-10GSRP-10G (2-GB memory)
1024.0.0SRP I/OSRP-40G
PLUS
SRP-40G PLUS (2-GB memory)
■7

Table 1: ERX Module Combinations (continued)
Page
First
JUNOSe
Support
I/O Module
Label
Line Module
LabelCombination Name and Type
1035.3.0SRP-SE I/OSRP-SE10GSRP-SE10G (1-GB memory)
T3
1044.1.0 (128
MB)
5.0.0 (256
MB)
4xDS3 ATM
I/O
OCx/STMx
ATM or
OCx/STMx
/DS3-ATM
T3 ATM (4 ports)
1054.0.2CT3/T3 12 I/OCOCX-F3T3 Frame (12 ports)
8■
ERX 11.1.x Module Guide

cOC3/STM1 Multimode Module Combination
cOCx/STMx F0
Line module label
cOC3 STM1 F0 I/O
MULTI MODE
I/O module label
■4
Number of I/O ports
■First supported: 2.2.0
■Final supported: Not applicable
Software release
■130 W
■OC3/STM1 channelized to DS3, DS1, E1, and DS0
■Supports either E1 or T1 operation, but not E1 and T1 operation simultaneously
Description
■EFA ASIC
Type
■OC3/STM1
■DS3
■T1, E1
■DS0
■HDLC framing
Capability
■See “Channelized OCx/STMx Modules”on page 107 for information about the layer
2 and layer 3 protocols and applications that this module combination supports.
Software features
■ERX7xx models
■ERX14xx models
■ERX310 router
Model compatibility
■SRP-5G+
■SRP-10G
■SRP-40G
■SRP-40G PLUS
■SRP-SE10G
SRP module compatibility
■1:N redundancy
■NOTE: Line module redundancy is not supported on the ERX310 router.
Module redundancy support
cOC3/STM1 Multimode Module Combination ■9
cOC3/STM1 Multimode Module Combination

■Up to four SC full duplex connectors
■Tx power:
■min: –19 dBm
■max: –14 dBm
■Center wavelength: 1310 nm
■Rx input power:
■min: –30 dBm
■max: –14 dBm
■Rated for 2 km (1.2 miles) over 62.5-micron core cable with an optical loss of
0–9 dB or 50-micron core cable with an optical loss of 7 dB
■See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
Cables and connectors
■See “Module LEDs”on page 133.
LEDs
■See Monitoring Interfaces in JUNOSe Physical Layer Configuration Guide, Chapter 4,
Configuring Channelized OCx/STMx Interfaces.
Alarms, errors, and events
10 ■cOC3/STM1 Multimode Module Combination
ERX 11.1.x Module Guide

cOC3/STM1 Single-Mode Intermediate Reach Module Combination
cOCx/STMx F0
Line module label
cOC3 STM1 F0 I/O
SINGLE MODE
I/O module label
■4
Number of I/O ports
■First supported: 2.2.0
■Final supported: Not applicable
Software release
■130 W
■OC3/STM1 channelized to DS3, DS1, E1, and DS0
Description
■EFA ASIC
Type
■OC3/STM1
■DS3, DS1
■T1, E1
■DS0
■HDLC framing
Capability
■See “Channelized OCx/STMx Modules”on page 107 for information about the
layer 2 and layer 3 protocols and applications that this module combination
supports.
Software features
■ERX7xx models
■ERX14xx models
■ERX310 router
Model compatibility
■SRP-5G+
■SRP-10G
■SRP-40G
■SRP-40G PLUS
■SRP-SE10G
SRP module compatibility
■1:N redundancy
■NOTE: Line module redundancy is not supported on the ERX310 router.
Module redundancy support
cOC3/STM1 Single-Mode Intermediate Reach Module Combination ■11
cOC3/STM1 Single-Mode Intermediate Reach Module Combination

■Up to four SC full duplex connectors
■Tx power:
■min: –15 dBm
■max: –8 dBm
■Center wavelength: 1310 nm
■Rx input power:
■min: –31 dBm
■max: –8 dBm
■Rated for 15 km (9.3 miles) of 9-micron core cable
■See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
Cables and connectors
■See “Module LEDs”on page 133.
LEDs
■See Monitoring Interfaces in JUNOSe Physical Layer Configuration Guide, Chapter 4,
Configuring Channelized OCx/STMx Interfaces.
Alarms, errors, and events
12 ■cOC3/STM1 Single-Mode Intermediate Reach Module Combination
ERX 11.1.x Module Guide

cOC3/STM1 Single-Mode Long Reach Module Combination
cOCx/STMx F0
Line module label
cOC3 STM1 F0 I/O
LONG HAUL
I/O module label
■4
Number of I/O ports
■First supported: 2.2.0
■Final supported: Not applicable
Software release
■130 W
■OC3/STM1 channelized to DS3, DS1, E1, and DS0
Description
■EFA ASIC
Type
■OC3/STM1
■DS3, DS1
■T1, E1
■DS0
■HDLC framing
Capability
■See “Channelized OCx/STMx Modules”on page 107 for information about the
layer 2 and layer 3 protocols and applications that this module combination
supports.
Software features
■ERX7xx models
■ERX14xx models
■ERX310 router
Model compatibility
■SRP-5G+
■SRP-10G
■SRP-40G
■SRP-40G PLUS
■SRP-SE10G
SRP module compatibility
■1:N redundancy
■NOTE: Line module redundancy is not supported on the ERX310 router.
Module redundancy support
cOC3/STM1 Single-Mode Long Reach Module Combination ■13
cOC3/STM1 Single-Mode Long Reach Module Combination

■Up to four SC full duplex connectors
■Tx power:
■min: –5.0 dBm
■max: 0 dBm
■Center wavelength: 1310 nm
■Rx input power:
■min: –34 dBm
■max: –7 dBm
■Fiber type: 9-micron core
■Rated for 40 km (24.8 miles) of 9-micron core cable
■See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
Cables and connectors
■See “Module LEDs”on page 133.
LEDs
■See Monitoring Interfaces in JUNOSe Physical Layer Configuration Guide, Chapter 4,
Configuring Channelized OCx/STMx Interfaces.
Alarms, errors, and events
14 ■cOC3/STM1 Single-Mode Long Reach Module Combination
ERX 11.1.x Module Guide

cOC12/STM4 Multimode Without APS/MSP Redundancy Module
Combination
cOCx/STMx F0
Line module label
cOC12 STM4 F0 I/O
MULTI MODE
I/O module label
■1
Number of I/O ports
■First supported: 2.2.0
■Final supported: Not applicable
Software release
■130 W
■OC12/STM4 channelized to DS3, DS1, E1, and DS0
Description
■EFA ASIC
Type
■OC12/STM4
■OC3/STM1
■DS3, DS1
■T1, E1
■DS0
■HDLC framing
Capability
■See “Channelized OCx/STMx Modules”on page 107 for information about the layer
2 and layer 3 protocols and applications that this module combination supports.
Software features
■ERX7xx models
■ERX14xx models
■ERX310 router
Model compatibility
■SRP-5G+
■SRP-10G
■SRP-40G
■SRP-40G PLUS
■SRP-SE10G
SRP module compatibility
■1:N redundancy
■NOTE: Line module redundancy is not supported on the ERX310 router.
Module redundancy support
cOC12/STM4 Multimode Without APS/MSP Redundancy Module Combination ■15
cOC12/STM4 Multimode Without APS/MSP Redundancy Module Combination

■SC full duplex connector
■Tx power:
■min: –19 dBm
■max: –14 dBm
■Center wavelength: 1310 nm
■Rx input power:
■min: –30 dBm
■max: –14 dBm
■Rated for 2 km (1.2 miles) over 62.5-micron core cable with an optical loss of 0–9
dB or 50-micron core cable with an optical loss of 7 dB
■See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
Cables and connectors
■See “Module LEDs”on page 133.
LEDs
■See Monitoring Interfaces in JUNOSe Physical Layer Configuration Guide, Chapter 4,
Configuring Channelized OCx/STMx Interfaces.
Alarms, errors, and events
16 ■cOC12/STM4 Multimode Without APS/MSP Redundancy Module Combination
ERX 11.1.x Module Guide

cOC12/STM4 Single-Mode Intermediate Reach Without APS/MSP
Redundancy Module Combination
cOCx/STMx F0
Line module label
cOC12 STM4 F0 I/O
SINGLE MODE
I/O module label
■1
Number of I/O ports
■First supported: 2.2.0
■Final supported: Not applicable
Software release
■130 W
■OC12/STM4 channelized to DS3, DS1, E1, and DS0
Description
■EFA ASIC
Type
■OC12/STM4
■OC3/STM1
■DS3, DS1
■T1, E1
■DS0
■HDLC framing
Capability
■See “Channelized OCx/STMx Modules”on page 107 for information about the
layer 2 and layer 3 protocols and applications that this module combination
supports.
Software features
■ERX7xx models
■ERX14xx models
■ERX310 router
Model compatibility
■SRP-5G+
■SRP-10G
■SRP-40G
■SRP-40G PLUS
■SRP-SE10G
SRP module compatibility
■1:N redundancy
■NOTE: Line module redundancy is not supported on the ERX310 router.
Module redundancy support
cOC12/STM4 Single-Mode Intermediate Reach Without APS/MSP Redundancy Module Combination ■17
cOC12/STM4 Single-Mode Intermediate Reach Without APS/MSP Redundancy Module Combination

■SC full duplex connector
■Tx power:
■min: –15 dBm
■max: –8 dBm
■Center wavelength: 1310 nm
■Rx input power:
■min: –31 dBm
■max: –8 dBm
■Rated for 15 km (9.3 miles) of 9-micron core cable
■See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
Cables and connectors
■See “Module LEDs”on page 133.
LEDs
■See Monitoring Interfaces in JUNOSe Physical Layer Configuration Guide, Chapter 4,
Configuring Channelized OCx/STMx Interfaces.
Alarms, errors, and events
18 ■cOC12/STM4 Single-Mode Intermediate Reach Without APS/MSP Redundancy Module Combination
ERX 11.1.x Module Guide

cOC12/STM4 Single-Mode Intermediate Reach With APS/MSP
Redundancy Module Combination
cOCx/STMx F0
Line module label
COC12 F0 APS
SINGLE MODE
I/O module label
■2
■1 active, 1 redundant
Number of I/O ports
■First supported: 6.1.3 or later 6.1.x release, 7.0.2 or later 7.0.x release, 7.2.0 and
higher-numbered release
Software release
■130 W
■OC12/STM4 channelized to DS3, DS1, E1, and DS0
Description
■EFA ASIC
Type
■OC12/STM4
■OC3/STM1
■DS3, DS1
■T1, E1
■DS0
■HDLC framing
Capability
■See “Channelized OCx/STMx Modules”on page 107 for information about the layer
2 and layer 3 protocols and applications that this module combination supports.
Software features
■ERX7xx models
■ERX14xx models
■ERX310 router
Model compatibility
■SRP-5G+
■SRP-10G
■SRP-40G
■SRP-40G PLUS
■SRP-SE10G
SRP module compatibility
■1:N redundancy
■NOTE: Line module redundancy is not supported on the ERX310 router.
Module redundancy support
cOC12/STM4 Single-Mode Intermediate Reach With APS/MSP Redundancy Module Combination ■19
cOC12/STM4 Single-Mode Intermediate Reach With APS/MSP Redundancy Module Combination

■SC full duplex connector
■Tx power:
■min: –15 dBm
■max: –8 dBm
■Center wavelength: 1310 nm
■Rx input power:
■min: –31 dBm
■max: –7 dBm
■Rated for 15 km (9.3 miles) of 9-micron core cable
■See ERX Hardware Guide, Chapter 5, Cabling ERX Routers for more information.
Cables and connectors
■See “Module LEDs”on page 133.
LEDs
■See Monitoring Interfaces in JUNOSe Physical Layer Configuration Guide, Chapter 4,
Configuring Channelized OCx/STMx Interfaces.
Alarms, errors, and events
20 ■cOC12/STM4 Single-Mode Intermediate Reach With APS/MSP Redundancy Module Combination
ERX 11.1.x Module Guide
