Juniper MX10003 User manual

MX10003 3D Universal Edge Router Quick
Start
September 2017
Part Number: 530-080552
Revision 01
This document describes how to install the Juniper Networks®MX10003 3D Universal
Edge Router.
Contents MX10003QuickStartDescription.......................................3
Step 1: Prepare the Site for MX10003 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 4
RouterRackRequirements.........................................4
RouterClearanceRequirements.....................................5
Router Cooling and Airflow Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Tools Required to Prepare the MX10003 Router for Installation . . . . . . . . . . . 6
Step 2: Install the MX10003 Chassis in the Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Step3:ConnecttheGroundingCable....................................9
Step 4: Connect External Devices and Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting the Router to a Network for Out-of-Band Management . . . . . . . . 11
Connecting the Router to a Console Device . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connecting the Router to External Clocking and Timing Devices . . . . . . . . . . 13
Connecting 1-PPS and 10-MHz Timing Devices to the Router . . . . . . . . . 13
Connecting a Time-of-Day Device to the Router . . . . . . . . . . . . . . . . . . . 14
Connecting a BITS External Clocking Device to the Router . . . . . . . . . . . 14
Step5:ConnectPowerCables.........................................15
ConnectPowertoanACRouter....................................15
ConnectPowertoaDCRouter.....................................17
Step6:InstalltheAirFilterUnit........................................19
Step 7: Perform Initial Software Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
EnterConfigurationMode........................................20
Configure User Accounts and Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
ConfigureSystemAttributes.......................................21
CommittheConfiguration........................................22
SafetyWarnings....................................................22
1Copyright © 2017, Juniper Networks, Inc.

ComplianceStatementsforNEBS.....................................24
Compliance Statements for EMC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Canada .......................................................25
EuropeanCommunity............................................25
Israel .........................................................25
Japan .........................................................25
UnitedStates...................................................25
Junos OS Documentation and Release Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
RequestingTechnicalSupport........................................26
Self-Help Online Tools and Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
OpeningaCasewithJTAC........................................27
Revision History ....................................................27
Copyright © 2017, Juniper Networks, Inc.2
MX10003 3D Universal Edge Router Quick Start

MX10003 Quick Start Description
This Quick Start contains information you need to install and configure the router quickly.
For complete installation instructions, see the MX10003 3D Universal Edge Router Hardware
Guide at http://www.juniper.net/techpubs/.
WARNING: This Quick Start contains a summary of safety warnings in “Safety
Warnings” on page 22. For a complete list of warnings for this router, including
translations, see the MX10003 3D Universal Edge Router Hardware Guide at
http://www.juniper.net/techpubs/.
The Juniper Networks MX10003 3D Universal Edge Router is an Ethernet-optimized edge
router with 2.4-Tb capacity that provides both switching and carrier-class Ethernet
routing. The MX10003 router runs Junos operating system (Junos OS), enabling a wide
range of business and residential applications and services, including high-speed transport
and virtual private network (VPN) services, next-generation broadband multiplay services,
and high-volume Internet data center internetworking. Each router provides full duplex,
high-density Ethernet interfaces and high-capacity switching throughput and uses the
Junos Trio chipset for increased scalability of Layer 2 and Layer 3 packet forwarding,
buffering, and queuing.
The MX10003 router is compact and three rack units (3U) tall. Several routers can be
stacked in a single floor-to-ceiling rack for increased port density per unit of floor space.
The router provides two dedicated line card slots for Modular Port Concentrators (MPCs).
MPCs install into the line-card slots. The router supports two redundant Routing and
Control Board (RCB). The RCBs house the Routing Engines (see Figure 1 on page 4).
The router is powered by six dedicated AC or DC power modules. Cooling is handled by
four fan modules. The RCBs and MPCs install into the front of the chassis, whereas the
power and fan modules install into the rear of the chassis.
The MX10003 line card has six built in QSFP+ optics ports and one slot for a MIC. For a
list of MPCs and MICs supported on the MX10003 router, see MX Series Interface Module
Reference.
3Copyright © 2017, Juniper Networks, Inc.
MX10003 Quick Start Description

Figure 1: Front View of the MX10003 Router
3—1— MIC installed in MPC1 Routing and Control Board (RCB)
4—2— MIC installed in MPC0 MPCs
Step 1: Prepare the Site for MX10003 Installation
•Router Rack Requirements on page 4
•Router Clearance Requirements on page 5
•Router Cooling and Airflow Requirements on page 5
•Tools Required to Prepare the MX10003 Router for Installation on page 6
Router Rack Requirements
•You can install the router in a four-post rack or cabinet or an open-frame rack.
•The rack must be strong enough to support the weight of the fully configured router:
up to 157.4 lb (71.4 kg) for AC-powered chassis, and up to 163.4 lb (74.1 kg) for
DC-powered chassis.
•Material handling systems (such as levers, slings, lifts, and so on) must be used to lift
any equipment weighing more than 121.2 lb (55 kg). In installation sites where using a
lift is not practical, specially trained persons or systems must be used (riggers or
movers).
•The rack rails must be spaced widely enough to accommodate the external dimension
of the chassis: 5.21 in. (13.23 cm) high, 30 in. (76.2 cm) deep, and 17.3 in. (43.9 cm)
wide. The outer edges of the mounting brackets extend the width to 19 in. (48.3 cm).
•Ensure that the cabinet allows the hot exhaust air of the chassis to exit from the cabinet
without recirculating into the router.
•The router must be installed in a rack that is secured to the building structure.
•Mount the router at the bottom of the rack if it is the only unit in the rack.
•When mounting the router in a partially filled rack, load the rack from the bottom to
the top with the heaviest component at the bottom of the rack.
Copyright © 2017, Juniper Networks, Inc.4
MX10003 3D Universal Edge Router Quick Start

Router Clearance Requirements
For the cooling system to function properly, the airflow around the chassis must be
unrestricted. You must allow sufficient clearance around the installed chassis for cooling
and maintenance. See Figure 2 on page 5.
If you are mounting an MX10003 in a rack with other equipment, ensure that the exhaust
from the other equipment does not blow into the intake vents of the MX10003 chassis.
Figure 2: Clearance Requirements for Airflow and Hardware Maintenance
for the MX10003
Router Cooling and Airflow Requirements
•The router has front-to-back or airflow out (AFO) cooling system. Air is pulled through
the front of the chassis toward the fan tray, from where it is exhausted out of the
system. The power supplies are self-cooling and are located in the rear of the router.
See Figure 3 on page 6.
•For the cooling system to function properly, the airflow around the chassis must be
unrestricted. Allow at least 6 in. (15.2 cm) of clearance between side-cooled routers.
Allow 2.8 in. (7 cm) between the side of the chassis and any non-heat-producing
surface such as a wall.
•For service personnel to remove and install hardware components, there must be
adequate space at the front and back of the router. Allow at least 30 in. (76.2 cm) in
front of the router and 24 in. (61 cm) behind the router.
•The rack or cabinet must have an adequate supply of cooling air.
5Copyright © 2017, Juniper Networks, Inc.
Router Clearance Requirements

Figure 3: Airflow Through the MX10003 Router
Tools Required to Prepare the MX10003 Router for Installation
•Blank panels to cover any slots not occupied by a component
•Mounting brackets, supplied with the router
•Eight screws for securing the mounting brackets to the chassis, supplied with the router
•Phillips (+) screwdriver, number 2, not supplied
•Four mounting screws, supplied with the router
•Cable management bracket, supplied with the router
•Two screws for securing the cable management bracket, supplied with the router
Step 2: Install the MX10003 Chassis in the Rack
To install the router in a rack or cabinet:
1. Position the router in front of the rack or cabinet.
2. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist and to a
site ESD point.
3. Using a Phillips (+) number 2 screwdriver, remove the screw on each side of the chassis
that holds the rear-mounting brackets, and slide the brackets out of the chassis (see
Figure 4 on page 7). Keep the brackets safely to be used in later stage.
The rear-mounting brackets on each side of the chassis are movable. You can adjust
the brackets according to the depth of the rack. However, the front-mounting brackets
on each side of the chassis are fixed to the chassis.
Copyright © 2017, Juniper Networks, Inc.6
MX10003 3D Universal Edge Router Quick Start

Figure 4: Removing the Rear-Mounting Brackets
4. Install the cable management brackets on each side of the front of the chassis, and
secure each bracket with screws at the bottom and top of the bracket (see
Figure 5 on page 7).
Figure 5: Installing the Cable Management Brackets
5. With one person on each side, hold on to the bottom of the chassis and carefully lift
it so that the mounting brackets contact the rack rails.
6. Carefully slide the router onto the mounting brackets until the front-mounting brackets
attached to the chassis contact the rack rails (see Figure 6 on page 7). The mounting
brackets ensure that the holes in the front-mounting brackets attached to the chassis
align with the holes in the rack rails.
Figure 6: Installing the Router in a Four-Post Rack
g009844
7Copyright © 2017, Juniper Networks, Inc.
Step 2: Install the MX10003 Chassis in the Rack

7. Install mounting screws into each of the open front-mounting holes aligned with the
rack, starting from the bottom, and secure them tightly.
8. On the rear of the chassis, slide the rear-mounting brackets on either side of the chassis
until the rear-mounting brackets contact the rack rails.
9. Install mounting screws into each of the open rear-mounting holes aligned with the
rack, starting from the bottom, and secure them tightly.
10. Visually inspect the alignment of the chassis. If the chassis is installed properly in the
rack, all the mounting screws on one side of the rack are aligned with the mounting
screws on the opposite side and the router is level. Figure 7 on page 8 shows the
router fully secured and installed in a four-post rack.
Figure 7: Router Installed in the Rack
g009845
Copyright © 2017, Juniper Networks, Inc.8
MX10003 3D Universal Edge Router Quick Start

Step 3: Connect the Grounding Cable
To meet safety and electromagnetic interference (EMI) requirements and to ensure
proper operation, the router must be adequately grounded before power is connected.
A protective earthing terminal bracket is required for connecting the chassis to earth
ground. This two-holed bracket attaches on the side of the chassis through the mounting
rail and provides a protective earthing terminal for the switch. The grounding points are
in the form of studs sized for M5 Pan Head screws. The M5 Pan Head screws with
integrated washers are provided in the accessory kit. The grounding points are spaced
at 0.75-in. (19.1-mm) centers.
You ground the router by connecting a grounding cable to earth ground and then attaching
it to the chassis grounding points by using two M5 Pan Head screws. You must provide
the grounding cables (the cable lugs are supplied with the router).
NOTE: The grounding lug required is a Panduit LCD10-14B-L or equivalent
(not provided). The grounding lug accommodates 14–10 AWG (2–5.3 mm²)
stranded wire. The grounding cable that you provide for the chassis must be
the same size or heavier than the input wire of each power supply. Minimum
recommendations are 14–10 AWG (2–5.3 mm²) stranded wire, 60° C wire,
or as permitted by local code.
To ground the MX10003 router:
1. Verify that a licensed electrician has attached the cable lug provided with the router
to the grounding cable.
2. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
the strap to an approved site ESD grounding point. See the instructions for your site.
3. Ensure that all grounding surfaces are clean and brought to a bright finish before
grounding connections are made.
4. Connect the grounding cable to a proper earth ground.
5. Detach the ESD grounding strap from the site ESD grounding point.
6. Attach an ESD grounding strap to your bare wrist and connect the strap to one of the
ESD points on the chassis.
7. Place the grounding cable lug over the grounding points on the side of the chassis
(see Figure 8 on page 10).
9Copyright © 2017, Juniper Networks, Inc.
Step 3: Connect the Grounding Cable

8. Secure the grounding cable lug with the screws. The holes are sized to accommodate
M5 Pan Head screws.
9. Dress the grounding cable and verify that it does not touch or block access to router
components, and that it does not drape where people could trip on it.
Figure 8: Grounding the MX10003 Router
Step 4: Connect External Devices and Cables
Figure 9 on page 11 shows the front panel of the MX10003 RCB. All the connections to
the router are made through the RCBs. The external devices are connected through the
RCBs.
Copyright © 2017, Juniper Networks, Inc.10
MX10003 3D Universal Edge Router Quick Start

Figure 9: Routing and Control Board (RCB) Ports
g009824
1 2 3 4 5 6 7 8 9 10
11121314
8—1— Time of day (ToD) port with LEDs USB port
9—2— BITS port with LEDsManagement (MGMT) port
10—3— Clocking ports
Console (CON) port
11—4— OFFLINE button SSD LEDs
12—5— ONLINE LEDSSD slots (0and 1)
13—6— OK/FAIL LEDMaster (MST) LED
14—7— RESET buttonAlarm (ALM) LED
•Connecting the Router to a Network for Out-of-Band Management on page 11
•Connecting the Router to a Console Device on page 12
•Connecting the Router to External Clocking and Timing Devices on page 13
Connecting the Router to a Network for Out-of-Band Management
To connect the RCB to a network for out-of-band management, connect an Ethernet
cable with RJ-45 connectors to the MGMT port on the RCB interface. One Ethernet cable
is provided with the router. To connect to the MGMT port on the RCB faceplate:
NOTE: Use shielded CAT5e cable for the CON and MGMT ports on the RCB.
1. Turn off power to the management device.
2. Plug one end of the Ethernet cable (Figure 10 on page 11 shows the connector) into
the MGMT port on the RCB interface.
3. Plug the other end of the cable into the network device.
Figure 10: Out-of-Band Management Cable Connector
11Copyright © 2017, Juniper Networks, Inc.
Connecting the Router to a Network for Out-of-Band Management

Table 1: Out-of-Band Management Port on the RCB
DescriptionLabelCallout (See Figure 9)
Dedicated management channel for
device maintenance. It is also used by
system administrators to monitor and
manage the router remotely.
MGMT2
Connecting the Router to a Console Device
To use a system console to configure and manage the router, connect it to the appropriate
CON port on the RCB interface. The console port is used to connect a laptop or console
terminal to configure the router (see Figure 12 on page 13 and Figure 13 on page 13). The
console port accepts a cable with an RJ-45 connector. One serial cable with an RJ-45
connector and a DB-9 connector is provided with the router.
NOTE: Use shielded CAT5e cable for connecting the CON and MGMT ports
in RCB.
To connect a management console:
1. Turn off power to the console device.
2. Plug the RJ-45 end of the serial cable (see Figure 11 on page 12) into the CON port on
the RCB interface.
3. Plug the female DB-9 end into the device's serial port.
NOTE:
For console devices, configure the serial port to the following values:
•Baud rate—9600
•Parity—N
•Data bits—8
•Stop bits—1
•Flow control—none
Figure 11: Console and Auxiliary Cable Connector
Copyright © 2017, Juniper Networks, Inc.12
MX10003 3D Universal Edge Router Quick Start

Figure 12: Connecting the MX10003 Router to a Management Console
Through a Console Server
g020547
CON
To Console
port Console server PC
Figure 13: Connecting the MX10003 Router Directly to a Management
Console
Table 2: Console Port on the RCB
DescriptionLabelCallout (See Figure 9)
Connect a laptop or console terminal
to configure the router.
CON3
Connecting the Router to External Clocking and Timing Devices
The router supports external clock synchronization for Synchronous Ethernet, and external
inputs.
•Connecting 1-PPS and 10-MHz Timing Devices to the Router on page 13
•Connecting a Time-of-Day Device to the Router on page 14
•Connecting a BITS External Clocking Device to the Router on page 14
Connecting 1-PPS and 10-MHz Timing Devices to the Router
The router has four SubMiniature B (SMB) connectors that support 1-PPS and 10-MHz
timing devices.
NOTE: Ensure that a cable of 3 m or less in length is used for the 10-MHz and
1-PPS connectors.
To connect the SMB coaxial cable to the external clocking input port:
1. Connect one end of the SMB coaxial cable to either the 1-PPS SMB connector or the
10-MHz SMB connector on the router.
2. Connect the other end of the SMB coaxial cable to the 10-MHz or 1-PPS source network
equipment.
13Copyright © 2017, Juniper Networks, Inc.
Connecting the Router to External Clocking and Timing Devices

NOTE: Ensure that the 10-MHz or 1-PPS source network equipment
contains Low Voltage Complementary Metal Oxide Semiconductor
(LVCMOS) or is compatible with low-voltage (3.3 V) transistor-transistor
logic (LVTTL).
Table 3: Clocking Port on the RCB
DescriptionLabelCallout (See Figure 9)
GPS input and output ports.10MHz
PPS
10
Connecting a Time-of-Day Device to the Router
A time-of-day port labeled ToD on the front panel of the RCB enables you to connect
external timing devices.
To connect the router to a ToD external timing device:
1. Attach an electrostatic discharge (ESD) grounding trap on your bare wrist, and connect
the strap to one of the ESD points on the chassis.
2. Plug one end of the RJ-45 cable into the ToD port on the front panel of the RCB.
3. Plug the other end of the RJ-45 cable into the ToD timing device.
4. Verify that the LEDs for the ToD port on the router are lit steadily green.
5. Configure the port. See Configuring Clock Synchronization Interface on MX Series Routers.
Table 4: Time-of-Day Port on the RCB
DescriptionLabelCallout (See Figure 9)
ToD RJ-45 port with LED.ToD8
Connecting a BITS External Clocking Device to the Router
The router has an external building-integrated timing supply (BITS) port labeled BITS
on the front panel of the RCB.
Copyright © 2017, Juniper Networks, Inc.14
MX10003 3D Universal Edge Router Quick Start

To connect the router to a BITS external clocking device:
1. Attach an electrostatic discharge (ESD) grounding trap on your bare wrist, and connect
the strap to one of the ESD points on the chassis.
2. Plug one end of the RJ-45 cable into the internal clock port on the craft interface.
3. Plug the other end of the RJ-45 cable into the BITS external clocking device.
4. Verify that the LEDs for the BITS port are lit steadily green.
5. Configure the port. See Configuring Clock Synchronization Interface on MX Series Routers.
Table 5: BITS Port on the RCB
DescriptionLabelCallout (See Figure 9)
Building-Integrated Timing Supply
(BITS) clock interface port with LED.
BITS9
Step 5: Connect Power Cables
Depending on the configuration, your router uses either AC or DC power supplies. Perform
the appropriate procedures for each power supply in your router. The power supplies are
hot-insertable and are field-replaceable units (FRUs). You can install up to six power
supplies in an MX10003 router. The power supplies install in the rear of the chassis in the
slots provided.
WARNING: You must ground the router before connecting either the AC
power cord or the DC power cable.
CAUTION: Do not mix AC and DC power supplies in the same chassis.
•Connect Power to an AC Router on page 15
•Connect Power to a DC Router on page 17
Connect Power to an AC Router
Table 6: MX10003 AC Power System Input Voltage
SpecificationItem
Operating range: 90–264 VACAC input voltage
15Copyright © 2017, Juniper Networks, Inc.
Step 5: Connect Power Cables

1. Locate power cords that have a plug appropriate for your geographical location. For
more information, see the MX10003 3D Universal Edge Router Hardware Guide at
http://www.juniper.net/techpubs/.
2. Attach an ESD grounding strap to your bare wrist and connect the strap to one of the
ESD points on the chassis.
3. Connect the power cord to the power supply.
4. Insert the power cord plug into an external AC power source receptacle.
NOTE: Each power supply must be connected to a dedicated AC power
feed and a dedicated customer-site circuit breaker. We recommend that
you use a dedicated customer-site circuit breaker rated for either
15 A (110 VAC) minimum or 10 A (220 VAC) minimum, or as required by
local code.
5. Fasten the cord retainer by lowering the clip over the cord and pushing the cord into
the adjustment nut of the cord retainer. Rotate the nut until it is tight against the base
of the cord (see Figure 14 on page 17).
6. Dress the power cord appropriately. Verify that the power cord does not block the air
exhaust and access to router components, or drape where people could trip on it.
7. Repeat Step 1through Step 6for the remaining power supply.
8. Switch the AC switch on each power supply to the on position (I) and observe the
status LED on each power supply faceplate. If an AC power supply is correctly installed
and functioning normally, the status LED lights green steadily.
If the status LED indicates that the power supply is not functioning normally, repeat
the installation and cabling procedures.
Copyright © 2017, Juniper Networks, Inc.16
MX10003 3D Universal Edge Router Quick Start

Figure 14: Connecting an AC Power Cord to an MX10003 AC Power Supply
Connect Power to a DC Router
Table 7: MX10003 DC Power System Input Voltage
SpecificationItem
Operating range: –40 through –72 VDCDC input voltage
1. Switch off the dedicated customer-site circuit breakers. Ensure that the voltage across
the DC power source cable leads is 0 V and that there is no chance that the cable
leads might become active during installation.
2. Verify that the DC power cables are correctly labeled before making connections to
the power supply. In a typical power distribution scheme where the return is connected
to chassis ground at the battery plant, you can use a multimeter to verify the resistance
of the –48V and RTN DC cables to chassis ground:
•The cable with very large resistance (indicating an open circuit) to chassis ground
is –48V.
•The cable with very low resistance (indicating a closed circuit) to chassis ground is
RTN.
3. Remove the screws from the terminals.
4. Secure each power cable lug to the terminal with the screw (see Figure 15 on page 19).
Apply between 5 lb-in. (0.6 Nm) and 6 lb-in. (0.7 Nm) of torque to the screw. Do not
overtighten the nut. (Use a number 2 Phillips screwdriver.)
a. Secure the positive (+) DC source power cable lug to the RTN (return) terminal.
b. Secure the negative (–) DC source power cable lug to the –48V (input) terminal.
CAUTION: Ensure that each power cable lug seats flush against the surface
of the terminal block as you are tightening the screws. Ensure that each
17Copyright © 2017, Juniper Networks, Inc.
Connect Power to a DC Router

screw is properly threaded into the terminal. Applying installation torque
to the screw when improperly threaded might result in damage to the
terminal.
CAUTION: The maximum torque rating of the terminal screws on the DC
power supply is 6 lb-in. (0.7 Nm). The terminal screws might be damaged
if excessive torque is applied. Use only a torque-controlled driver to tighten
screws on the DC power supply terminals. Use an appropriately-sized
driver, with a maximum torque capacity of 6 lb-in. or less. Ensure that the
driver is undamaged and properly calibrated and that you have been
trained in its use. You might want to use a driver that is designed to prevent
overtorque when the preset torque level is achieved.
5. Repeat Step 2through Step 4for the remaining power supplies.
6. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
the strap to an approved site ESD grounding point. See the instructions for your site.
7. Connect each DC power cable to the appropriate external DC power source.
NOTE: For information about connecting to external DC power sources,
see the instructions for your site.
8. Switch on the external circuit breakers to provide voltage to the DC power source
cable leads.
9. Switch on the circuit breakers on each power supply to the on position (|). Observe
the status LED on each power supply faceplate. If a DC power supply is correctly
installed and functioning normally, the status LED lights green steadily.
If the status LED indicates that the power supply is not functioning normally, repeat
the installation and cabling procedures.
Copyright © 2017, Juniper Networks, Inc.18
MX10003 3D Universal Edge Router Quick Start

Figure 15: Connecting a DC Power Cable to an MX10003 DC Power Supply
Step 6: Install the Air Filter Unit
The air filter unit is installed on the cable management brackets. Before installing the air
filter unit, ensure that the cable management brackets are already installed on the front
of the router.
To install the air filter:
1. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
the strap to one of the ESD points on the chassis.
2. Ensure that the air filter unit is right side up.
3. Grasp the air filter unit and slide into the rails on the cable management brackets until
it stops (see Figure 16 on page 19). The air filter unit fits snugly on the cable
management brackets.
Figure 16: Installing the Air Filter
19Copyright © 2017, Juniper Networks, Inc.
Step 6: Install the Air Filter Unit

4. Tighten the captive screws to secure the air filter unit.
5. Route the interface cables appropriately. Verify that the cables does not block the
access to router components.
Step 7: Perform Initial Software Configuration
This procedure connects the router to the network but does not enable it to forward
traffic. For complete information about configuring the router to forward traffic, including
examples, see the Junos OS configuration guides.
To configure the software:
•Enter Configuration Mode on page 20
•Configure User Accounts and Passwords on page 20
•Configure System Attributes on page 21
•Commit the Configuration on page 22
Enter Configuration Mode
1. Verify that the router is powered on.
2. Log in as the root user. There is no password.
3. Start the CLI.
root# cli
root@>
4. Enter configuration mode.
cli> configure
[edit]
root@#
Configure User Accounts and Passwords
For information about using an encrypted password or an SSH public key string (DSA or
RSA), see Configuring the Root Password and authentication (Login) in the User Access
and Authentication Feature Guide for Routing Devices.
1. Add a password to the root administration user account. Enter a clear-text password.
[edit]
root# set system root-authentication plain-text-password
New password: password
Retype new password: password
2. Create a management console user account.
Copyright © 2017, Juniper Networks, Inc.20
MX10003 3D Universal Edge Router Quick Start
