Quick Start Guide
MX10004
IN THIS GUIDE
Step 1: Begin | 1
Step 2: Up and Running | 8
Step 3: Keep Going | 12
Step 1: Begin
SUMMARY
In this guide, we provide a simple, three-step path, to quickly
get you up and running with your new MX10004 router.
We've simplied and shortened the installaon and
conguraon steps. You'll learn how to install the MX10004
in a rack, power it up, and congure basic sengs.
IN THIS SECTION
Meet the MX10004 | 1
Rack It | 2
Power On | 7
Meet the MX10004
The Juniper Networks® MX10004 is the most compact, high-density, and power-ecient modular chassis in the
MX10000 line of modular packet-roung transport routers. At only 7 U in height, the MX10004 is designed for today’s
space-constrained facilies. The MX10004 supports Juniper’s 400 GbE architecture with inline Media Access Control
Security (MACsec) on all ports for point-to-point security on Ethernet links. MX10004 provides 1 GbE, 10 GbE, 25 GbE,
40 GbE, 50 GbE, 100 GbE, or 400 GbE modular soluons that support up to 38.4 Tbps of throughput.

Rack It
IN THIS SECTION
What's in the Box? | 2
What Else Do I Need? | 3
Assemble the Rack Mount Kit | 3
Mount the MX10004 in the Rack and Ground the Chassis | 4
What's in the Box?
Along with your MX10004 router, you’ll nd:
• Rack-mount kit
• Twelve Phillips 8-32 x .375 in. at-head screws
• Two mounng blades
• A mounng tray
• A rear safety restraint
• Front door
• An accessory kit with:
• RJ-45 Ethernet cable
• RJ-45 to DB9 rollover cable
•Electrostac discharge (ESD) wrist strap with cable
• Media kit (ash drives, PCMCIA card adapter)
• Ground chassis lug, 2-hole, 10-32, 6 AWG
• Six power cord retainer clips, for AC conguraons
2

What Else Do I Need?
• A mechanical li rated for 250 lb (113.4 kg). You can mount an MX10004 router manually or by using a mechanical
li. Because of the router's size and weight, we strongly recommend that you use a mechanical li to mount the
MX10004. In this guide, we show you how to mount the router using a mechanical li.
• 4 AWG (21.1 mm²) stranded wire grounding cable rated 75° C or per local electrical code
• A Phillips (+) screwdriver, number 2 or number 3, depending on the size of your rack-mount screws
• Twenty eight rack mount screws appropriate for your rack to secure the mounng blades, mounng tray, chassis,
and safety restraint to the rack
• A number 3 Pozidriv or Phillips (+) screwdriver for the grounding screws
CAUTION: Ensure that a licensed electrician aaches the appropriate grounding lug to your grounding
cable. Using a grounding cable with an incorrectly aached lug can damage the router.
Assemble the Rack Mount Kit
Here's how to assemble the MX10004 rack-mount kit in a four-post rack:
1. Review the General Safety Guidelines and Warnings.
2. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other end to a site
ESD point.
3. Aach the mounng blades to the front rack posts by using six rack mount screws.
4. From the rear of the rack, slide the mounng tray into the rear posts of the rack such that the mounng blades slide
into the grooves on the mounng tray.
3

5. Aach the mounng tray to the rear rack posts by using eight rack mount screws.
6. Check that the mounng tray is level.
7. Aach the mounng tray to the mounng blades in the rack with the 12 Phillips 8-32 x .375 in. at-head screws.
Mount the MX10004 in the Rack and Ground the Chassis
Here’s how to install the MX10004 in a four-post rack:
1. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other end to a site
ESD point.
2. Load the router onto the li, making sure it rests securely on the li plaorm.
4

3. Align the router in front of the rack, centering it in front of the mounng tray.
4. Li the chassis approximately 0.75 in. (1.9 cm) above the surface of the mounng tray. Align the chassis as close as
possible to the mounng tray.
5. Carefully slide the chassis onto the mounng tray unl the chassis anges touch the rack rails.
6. Starng at the boom, aach the chassis to the rack by inserng eight rack mount screws through each open
ange hole and rack hole.
7. Move the li away from the rack.
8. Check the alignment of the router. The rack mount screws on each side of the rack should line up, and the router
should be level. Tighten the screws.
9. Insert the safety restraint between the rear posts of the rack. It should rest on the top of the chassis and align with
the holes in the rack.
10. Aach the restraint to the rack by inserng six mounng screws through each ange hole and rack hole and
ghtening the screws.
5

11. Install the line cards:
a. Remove the line card cover by grasping the handles and pulling straight out to expose the slot for the line card.
Save the cover.
NOTE: If you are not installing a line card do not remove the line card cover.
b. Slide the line card all the way into the slot unl the handle holes line up.
c. Rotate the handles simultaneously into the chassis unl the card is fully seated and the handles are vercal.
12. Install the opcs and oponal cable management system.
13. Li the front door and line up the capve screws in the door with the holes in the chassis ange.
Aach the door to the chassis and rack using the capve screws. Turn the screws unl they are nger ght.
14. Have a licensed electrician aach the cable lug (provided in the accessory kit) to the grounding cable.
15. Remove the two M6 screws with aached washers below the boom power supply using a Pozidriv or Phillips
screwdriver.
16. Place the chassis grounding lug and cable over the screw holes with the cable connecon poinng to the le. Place
the two screws with aached washers over the grounding lug and grounding cable. Tighten the two M-6 screws
using a Pozidriv or Phillips screwdriver.
6

Power On
Now that you’ve installed your MX10004 in the rack and grounded the chassis, you’re ready to connect it to power.
The MX10004 supports AC, DC, high-voltage alternang current (HVAC), and high-voltage direct current (HVDC). In
this guide, we show you how to connect AC power. For DC, HVAC, and HVDC installaons, see MX10004 Universal
Roung Plaorm Hardware Guide.
1. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other end to one of
the ESD grounding points on the router.
2. Turn o the power switch on the power supply.
3. If the power source outlet has a power switch, turn it o.
4. Aach each AC power supply to a dedicated power source.
NOTE: If you need power source redundancy, you can aach each power cable to separate power sources.
5. For each AC power cable, insert the end of the cable with the Anderson connector into the power supply. The
connector snaps and locks the cable into posion.
WARNING: Ensure that the power cord does not block access to router components or drape
where people can trip on it.
6. Set the three DIP switches on the power supply to indicate whether one or both power feeds are used, and to
indicate the amperage of the feeds. Together, these switches determine if the chassis operates at 3,000 W, 5,000
W, or 5,500 W. If you're using both power feeds, set switch 1 and switch 2 to the on (|) posion. Power is shared. If
you’re not using power source redundancy, set the unused source to the o (O) posion. The LED turns red and
indicates an error if a power source input is not in use and the DIP switch is on (|).
7

Switch State Descripon
1 On INP1 is present.
O INP1 is not present.
2 On INP2 is present.
O INP2 is not present.
3 On Enabled for 30-A feed; 5,000 W for
single feed, 5,500 W for dual feeds.
O Enabled for 20-A feed; power supply
capacity is 3,000 W.
7. Plug the AC power cord into the power outlet.
8. If the power source outlet has a power switch, turn it on.
9. Turn on the power switch on the power supply.
10. If you’re using two power feeds, verify that the 1 and 2 LEDs on the power supply faceplates are steadily lit. These
LEDs correspond to INP1 and INP2.
Step 2: Up and Running
SUMMARY
Now that the MX10004 is powered on, let’s do some inial
conguraon to get the router up and running on the
network. It’s simple to provision and manage the MX10004
on your network.
IN THIS SECTION
Connect to the Router and Enter Conguraon
Mode | 8
Connect to the Router and Enter Conguraon Mode
Before you begin conguring the router:
• Ensure that the Roung Control Board (RCB) has the Junos OS Release 22.3R1 or later operang system installed.
8

• If you want to use an RCB that has Junos OS release prior to 22.3R1 or if the show version command displays the
router model as mx10016-olive, you must use the USB install method (not the CLI method) to upgrade the Junos OS
release on the RCB to 22.3R1 or later.
1. Connect the console port on the MX10004 to a laptop or PC using the supplied RJ-45 cable and RJ-45 to DB-9
adapter. The console (CONSOLE) port is located on the Roung and Control Board (RCB).
2. Verify that your laptop or PC has the following default values:
• Baud Rate—9600
• Flow Control—None
• Data—8
• Parity—None
• Stop Bits—1
• DCD State—Disregard
3. Log in as root. There is no password. If the soware boots before you connect to the console port, you might need
to press the Enter key for the prompt to appear.
login: root
4. Start the CLI.
root@% cli
5. Enter conguraon mode.
root> configure
6. Add a password to the root administraon user account.
[edit]
root@# set system root-authentication plain-text-password
New password: password
Retype new password: password
9

NOTE: Oponally, instead of conguring the root password at the [edit system] hierarchy level, you can use
a conguraon group to strengthen security.
7. (Oponal) Congure the name of the router. If the name includes spaces, enclose the name in quotaon marks (“ ”).
You can congure the router name at the [edit system] hierarchy level.
[edit]
root@# set system host-name
host-name
If your MX10004 router has two RCBs, it is recommended you use a conguraon group. You can use group-name
as re0 or re1.
[edit]
root@# set groups group-name system host-name host-name
For Example:
[edit]
root@# set groups re0 system host-name alpha-router0
[edit]
root@# set groups re1 system host-name alpha-router1
8. Congure the default gateway.
[edit]
root@# set routing-options static route default next-hop address
9. Congure the IP address and prex length for the router management interface.
[edit]
root@# set interfaces em0 unit 0 family inet address address/prefix-length
NOTE: The management port, em0 (MGMT for RJ-45 connecons) is found on the front of the RCBs of the
MX10004 router.
If your MX10004 router has two RCBs, you can congure each RCB with a separate IP address for the
management Ethernet interface.
10

You can use group-name as re0 or re1.
[edit]
root@# set groups group-name interfaces em0 unit 0 family inet address address/prefix-length
For Example:
[edit]
root@# set groups re0 interfaces em0 unit 0 family inet address address/prefix-length
[edit]
root@# set groups re1 interfaces em0 unit 0 family inet address address/prefix-length
10. (Oponal) Congure the stac routes to remote prexes with access to the management port.
[edit]
root@# set routing-options static route remote-prefix next-hop destination-ip retain no-readvertise
For example:
[edit]
root@# set routing-options static route 192.168.0.0/24 next-hop 10.0.3.2 retain no-readvertise
11. (Oponal) Enable Telnet service.
[edit]
root@# set system services telnet
NOTE: When Telnet is enabled, you cannot log in to an MX10004 through Telnet using root credenals.
Root login is allowed only for SSH access.
12. (Oponal) If you used one or more conguraon groups, apply the conguraon groups, substung the
appropriate group name.
[edit]
root@# set apply-groups group name
11

For example:
[edit]
root@# set apply-groups global
global is a group where user log in details, routes, and other informaon is stored.
[edit]
root@# set apply-groups re0
[edit]
root@# set apply-groups re1
13. Commit the conguraon to acvate it on the router.
[edit]
root@# commit
Step 3: Keep Going
IN THIS SECTION
What's Next | 12
General Informaon | 13
Learn With Videos | 13
Congratulaons! You’ve completed the inial steps to get your MX10004 up and running. Let’s keep going and learn
more about what you can do with the MX10004 router.
What's Next
Now that you've done the inial conguraon, here's some things you might want to do next.
12

If you want to Then
Congure interfaces See the Interfaces Fundamentals for Junos OS Guide
Manage soware upgrades for your MX10004 See the Junos® OS Soware Installaon and Upgrade Guide
Download, acvate, and manage your soware licenses to
unlock addional features for your MX Series router
See Acvate Junos OS Licenses in the Juniper Licensing Guide
See, automate, and protect your network with Juniper Security Visit the Security Design Center
General Informaon
If you want to Do this
See all documentaon available for the MX10004 Visit the MX10004 Documentaon for Junos OS page in the
Juniper TechLibrary
Find more in-depth informaon about how to install and
congure the MX10004
See the MX10004 Universal Roung Plaorm Hardware Guide
Learn about Junos OS See Junos OS
Stay up-to-date on new and changed features and known and
resolved issues
See Junos OS Release Notes
Learn With Videos
Our video library connues to grow! We’ve created many, many videos that demonstrate how to do everything from
install your hardware to congure advanced Junos OS network features. Here are some great video and training
resources that will help you expand your knowledge of Junos OS.
13

If you want to Then
Watch a video that shows you the appropriate connecon and
terminal requirements for connecng to a factory-defaulted
Junos device
See Juniper Basics: Connecng to a Junos Device
Get short and concise ps and instrucons that provide quick
answers, clarity, and insight into specic features and funcons
of Juniper technologies
See Learning with Juniper on Juniper Networks main YouTube
page
View a list of the many free technical trainings we oer at
Juniper
Visit the Geng Started page on the Juniper Learning Portal
Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the
United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the
property of their respecve owners. Juniper Networks assumes no responsibility for any inaccuracies in this document.
Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publicaon without noce.
Copyright © 2022 Juniper Networks, Inc. All rights reserved.
14
