Step 1: Begin
IN THIS SECTION
Meet the EX4600 | 1
Install the EX4600 | 2
Power On | 4
In this guide, we provide a simple, three-step path, to quickly get you up and running with your new
EX4600. We’ve simplied and shortened the installaon and conguraon steps, and included how-to
videos. You’ll learn how to install an AC-powered EX4600, power it up, and congure basic sengs.
NOTE: Are you interested in geng hands-on experience with the topics and operaons covered
in this guide? Visit Juniper Networks Virtual Labs and reserve your free sandbox today! You’ll nd
the Junos Day One Experience sandbox in the stand alone category. EX switches are not
virtualized. In the demonstraon, focus on the virtual QFX device. Both the EX and QFX
switches are congured with the same Junos commands.
Meet the EX4600
The Juniper Networks® EX4600 oers a compact, highly scalable, high-performance 10GbE soluon for
enterprise campus distribuon deployments as well as low-density data center top-of-rack
environments. A single EX4600 can support up to 72 10GbE ports (using 10GbE breakout cables on
40GbE xed ports) at line rate. In addion, Virtual Chassis technology makes it easy to scale the network
while reducing management complexity. By adding switches to a Virtual Chassis conguraon, you can
grow the number of switch ports without increasing the number of devices to manage.
The base EX4600 model has:
• 24 xed small form-factor pluggable (SFP) or SFP+ access ports
• Four xed quad SFP+ (QSFP+) high-speed uplinks
• Two power supplies
1

• Five fan modules
• Management interface ports: RJ-45 console (CON) port, RJ-45 management Ethernet port (CO), SFP
management Ethernet port (C1), and a USB port
• Two expansion slots for oponal expansion modules
The EX4600 is available in AC-powered or DC-powered models with air-ow in or air-ow out cooling.
You can install the switch in a two-post or four-post rack. In this guide, we show you how to install an
AC-powered EX4600 in a four-post rack. If you need instrucons for installing a DC-powered EX4600,
see the EX4600 Ethernet Switch Hardware Guide.
Install the EX4600
IN THIS SECTION
What’s in the Box? | 2
What Else Do I Need? | 3
Rack It | 3
Let’s get going and install the EX4600 in a four-post rack.
What’s in the Box?
• EX4600 switch with two power supplies and ve fan modules pre-installed
• Two power cords appropriate for your geographic locaon
• Rack mount kit
The rack mount kit contains one pair of mounng rails, one pair of mounng blades, and 12 at-head
Phillips mounng screws.
2

What Else Do I Need?
• Someone to help you secure the switch to the rack
• A number two Phillips (+) screwdriver
• Eight rack mount screws
• Cage nuts and washers, if your rack requires them
• Grounding lug and aached cable
• Two 10-32 x 0.25 screws with #10 split-lock washers
• An electrostac discharge (ESD) grounding strap
• Management host, such as a laptop or desktop PC
• Serial-to-USB adapter (if your laptop or desktop PC doesn’t have a serial port)
• An Ethernet cable with RJ-45 connectors aached and an RJ-45 to DB-9 serial port adapter
NOTE: We no longer include a DB-9 to RJ-45 cable or a DB-9 to RJ-45 adapter with a CAT5E
copper cable as part of the device package. If you require a console cable, you can order it
separately with the part number JNP-CBL-RJ45-DB9 (DB-9 to RJ-45 adapter with a CAT5E
copper cable).
Rack It
1. Review General Safety Guidelines and Warnings.
2. Wrap the ESD grounding strap around your bare wrist and ground yourself to an ESD point or to the
rack.
3. Decide which end of the switch you want to place at the front of the rack: the eld-replaceable unit
(FRU) end or the port end. Posion it in the rack so that the AIR IN labels on the power supplies are
next to the cold aisle, and the AIR OUT labels on the power supplies are next to the hot aisle.
4. Aach the mounng rails to each side of the switch using the supplied at-head mounng screws.
3

5. Li the switch and posion it in the rack. Line up the boom hole in each mounng rail with a hole in
each rack rail, making sure the switch is level.
6. While you’re holding the switch in place, have a second person insert and ghten the rack mount
screws to secure the mounng rails to the rack rails. Make sure they ghten the screws in the two
boom holes rst, and then ghten the screws in the two top holes.
7. Connue holding the switch in place and have the second person slide the mounng blades into the
mounng rail grooves.
8. Screw the mounng blades to the rack using the rack mount screws (and cage nuts and washers, if
your rack requires them).
9. Double-check that the mounng brackets on each side of the rack are level.
Power On
Now that you’ve installed your EX4600 in the rack, you’re ready to connect it to power.
1. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other
end to one of the ESD grounding points on the chassis.
2. Secure the grounding lug and aached cable to the chassis using two 10-32 x 0.25 screws with #10
split-lock washers. Aach the lug to the chassis through the le rail and blade assembly.
4

3. Connect the other end of the grounding cable to a proper earth ground, such as the rack. Dress the
grounding cable and ensure that it doesn’t touch or block access to other device components, and
that it doesn’t drape where people could trip over it.
4. Plug in the coupler end of the AC power cord to the AC power cord inlet on each of the switch’s
power supplies.
5. Push the power cord retainer onto the power cord.
6. If the AC power source outlet has a power switch, turn it o.
7. Plug in the power cord to the AC power source outlet.
8. If the AC power source outlet has a power switch, turn it on.
The EX4600 powers up as soon as you connect it to power; there is no power switch. When the AC
and DC LEDs on each power supply are solid green, the EX4600 is ready to use.
5

Step 2: Up and Running
IN THIS SECTION
Plug and Play | 6
Customize the Basic Conguraon | 6
Now that the EX4600 is powered on, let’s do some inial conguraon to get it up and running on the
network. It’s simple to provision and manage the EX4600 using the CLI.
Plug and Play
The EX4600 switch ships with factory-default sengs that enable plug-and-play operaon. These
sengs load as soon as you power on the switch.
Customize the Basic Conguraon
You can easily customize the factory-default conguraon using CLI commands. You can revert to the
factory-default conguraon whenever you want.
Have the following informaon handy before you begin customizing switch sengs:
• Hostname
• Root authencaon password
• Management port IP address
• Default gateway IP address
•(Oponal) SNMP read community, locaon, and contact informaon
1. Verify that the serial port sengs for your laptop or desktop PC are set to the default:
• Baud Rate—9600
• Flow Control—None
6

• Data—8
• Parity—None
• Stop Bits—1
• DCD State—Disregard
2. Connect the console (CON) port on the switch’s management panel to a laptop or desktop PC using
the RJ-45 cable and RJ-45 to DB-9 adapter (not provided).
NOTE: If your laptop or desktop PC doesn't have a serial port, use a serial-to-USB adapter
(not provided).
3. At the Junos OS login prompt, type root to log in. You don't need to enter a password. If the
soware booted before you connected the laptop or desktop to the console port, you might need
to press the Enter key for the prompt to appear.
login: root
4. Start the CLI.
root@% cli
5. Enter conguraon mode.
root> configure
6. Add a password for the root administraon user account.
[edit]
root@# set system root-authentication plain-text-password
New password: password
Retype new password: password
7. (Oponal) Congure the name of the switch. If the name includes spaces, enclose the name in
quotaon marks (“ ”).
[edit]
root@# set system host-name host-name
7

8. Congure the default gateway.
[edit]
root@# set routing-options static route default next-hop address
9. Congure the IP address and prex length for the switch management interface.
[edit]
root@# set interfaces em0 unit 0 family inet address address/prefix-length
NOTE: Although the CLI lets you congure two management Ethernet interfaces within the
same subnet, only one interface is usable and supported at any point in me.
NOTE: The management ports, em0 (labeled C0), and em1 (labeled C1), are on the switch’s
management panel.
10. Congure the stac routes to remote prexes with access to the management port.
[edit]
root@# set routing-options static route remote-prefix next-hop destination-ip retain no-
readvertise
11. Enable Telnet service.
[edit]
root@# set system services telnet
NOTE: When Telnet is enabled, you cannot log in to the EX4600 through Telnet using root
credenals. Root login is allowed only for SSH access.
12. Commit the conguraon. Your changes become the acve conguraon for the switch.
[edit]
root@# commit
