JVC GR-SXM335U User manual

BATTERY PACK BN-V11U BN-V11U BN-V11U BN-V11U BN-V20BU
BODY COLOR Silver Silver Silver Metallic gray Metallic gray
DSC Used Used Used Not used Not used
LCD MONITOR 3" 2.5" 3" 2.5" 2.5"
PC CONNECTION CABLE Optional Provided Provided Optional Optional
VIEW FINDER Color Color Black/White Black/White Black/White
TABLE OF CONTENTS
DIFFERENT TABLE ....................................................................................................................................................................1 to 3
4. CHARTS AND DIAGRAMS
4.1 BOARD INTERCONNECTIONS ................................................................................................................................... 4-1
4.2 DSP SCHEMATIC DIAGRAM ....................................................................................................................................... 4-3
4.3 IRIS & AF/ZOOM SCHEMATIC DIAGRAM................................................................................................................... 4-5
4.4 REGULATOR SCHEMATIC DIAGRAM ........................................................................................................................ 4-7
4.5 LCD CTL SCHEMATIC DIAGRAM (FOR SXM735)...................................................................................................... 4-9
4.6 MAIN CIRCUIT BOARD...............................................................................................................................................4-11
5. PARTS LIST
5.1 PACKING AND ACCESSORY ASSEMBLY <M1> ........................................................................................................ 5-1
5.2 FINAL ASSEMBLY <M2> .............................................................................................................................................. 5-3
5.3 ELECTRICAL PARTS LIST
MAIN BOARD ASSEMBLY <01> .................................................................................................................................. 5-6
The following table indicate main different points between models GR-SXM930U, SXM735U, SXM730U/UC, SXM330U and
GR-SXM335U.
MODEL
ITEM
The following table indicate different parts number between models GR-SXM930U, SXM735U, SXM730U/UC, SXM330U and
GR-SXM335U.
PACKING AND ACCESSORY ASSEMBLY <M1> Note: As for IB (INSTRUCTIONS), refer to sec.5
1
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
REF. NO.
1 PACKING CASE LY32179-005A LY32179-004A
7 REGIST.CARD/WARRANTY CARD BT-51020-2 BT-52004-1 BT-51020-2
!11 BATTERY PACK YQ10629A LY31199-001A
14 CORE FILTER QQR0491-002 ––
15 PC CONNECTION CABLE QAM0084-001 ––
16 REMOTE CONTROL UNIT LY42129-001A –
18 AAA(R03)BATTERY,X2 Used Used Used Used Used Not Used
19 CD ROM * LY31133-001B LY32210-007A ––
20 POLY BAG * LY30023-010A – – – – –
21 SER.NET CARD – – – BT-20071B – –
22 SOFT WARE PERM. YU30843-4 ––
26 SHEET (INSTALL) LYT0309-004A ––
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U GR-SXM730UC GR-SXM330U GR-SXM335U
Note: Mark – is not used. Mark is same as left. Mark * reference model was also changed.

2
FINAL ASSEMBLY <M2>
Note: Mark –is not used. Mark is same as left. Mark * reference model was also changed.
MONITOR ASSEMBLY <M5>
REF. NO.
101 LOWER CASEASSY LY20684-009A LY20684-008A
102 COVER(JACK) * LY31945-001B LY31945-001C * LY31945-001B LY31945-001C
104 FRONT COVER ASSY LY20683-015A LY20683-005B
105 CASS.COVER(M)ASSY * LY20694-002A LY20694-002B * LY20694-004A LY20694-004B
106 UPPER CASE(M) LY10257-018A LY10257-037A LY10257-036A LY10257-015A LY10257-039A
109 TOP OPE UNIT LY20614-008B LY20614-012B
114 STICKER(D) LY32061-004A LY32061-005A
115 SCREW * QYSLSF2060D,X5 QYSLSF2060D,X4 * QYSLSF2060D,X5 QYSLSF2060D,X4
136 SCREW/SPECIAL SCREW * QYSLSF2060D LY42981-001A * QYSLSF2060D LY42981-001A
154 HOLDER(DSC P.) LY20645-001A ––
155 SCREW QYSLSF2060D ––
156 FPC(DSC)ASSY LY42875-001A ––
156A S.SHEET(DSC FPC) LY42876-001A ––
157 INSULATER YU40341 ––
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
ELECTRONIC VIEWFINDER ASSEMBLY <M4>
REF. NO.
!300 E.VF ASSY LYH20242-001A –––
303 SPACER(HOLDER) * LY42221-001C LY43013-001A –––
!350 E.VF ASSY ––LY20701-001A
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
REF. NO.
!500 MONITOR ASSY * LYH20217-014A LYH20217-019B LYH20217-014B * LYH20217-015A LYH20217-005B
!501 M.COVER ASSY LY20679-008A LY20679-009A
502 M.CASE(3/2.5)ASSY LY32035-001A LY32036-001A LY32035-001A LY32036-001A
504 HINGE COVER(U) LY31939-001A LY31939-004A
515 HOLDER(3/2.5PWB) LY20647-001A LY20672-001B LY20647-001A LY20672-001B
519 BACK LIGHT QLL0094-001 QLL0093-001 QLL0094-001 QLL0093-001
520 LCD MODULE QLD0118-001 QLD0176-001 QLD0118-001 QLD0176-001
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
MAIN BOARD ASSEMBLY <01>
REF. NO.
PW MAIN BOARDASSY YB10310UG-02 YB10310VA YB10310UZ YB10310UD-01 YB10310UY
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U

3
C-VF BL BOARD ASSEMBLY <06>
MONITOR BOARD ASSEMBLY <07>
DSC BOARD ASSEMBLY <08>
E.VF BOARD ASSEMBLY <60>
Note: Mark –is not used. Mark is same as left. Mark * reference model was also changed.
REF. NO.
PW C-VF BL BOARDASSY YB20901A –––
R7562 MG RESISTOR * NRSA63J-470X NRSA63J-360X –––
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
REF. NO.
PW MONITOR BOARD ASSY * YB20900A-01 YB20900D YB20900C * YB20900B-01 YB20900D
IC7501 IC * TC7WH34FK ––* TC7WH34FK –
R7511,R7512 MG RESISTOR NRSA63J-223X –NRSA63J-223X ––
R7513 MG RESISTOR –NRSA63J-103X –NRSA63J-103X
R7514 MG RESISTOR NRSA63J-333X –NRSA63J-333X ––
R7515 MG RESISTOR NRSA63J-562X NRSA63J-302X NRSA63J-562X NRSA63J-302X
R7519 to R7521 MG RESISTOR * –NRSA63J-0R0X *–NRSA63J-0R0X
C7502 CAPACITOR * NCB31EK-103X ––* NCB31EK-103X –
C7510 CAPACITOR NCB31EK-103X –NCB31EK-103X ––
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
REF. NO.
PW DSC BOARD ASSY YB20898B ––
WR1 E-SI C WIRE C-F,JP8001/JP8002 * WJM0179-001A WJM0179-001B ––
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U
REF. NO.
PW E.VF BOARD ASSY ––LY41289-002A
MODEL
ITEM
GR-SXM930U GR-SXM735U GR-SXM730U/UC GR-SXM330U GR-SXM335U

SECTION 5
PARTS LIST
SAFETY PRECAUTION
Parts identified by the symbol are critical for safety. Replace only with specified part numbers.
5.1 PACKING AND ACCESSORY ASSEMBLY <M1>
The instruction manual to be provided with this product will differ according to the destination.
2
1
4
12
19
FINAL ASSY
<M2>
10 5
LABEL
(SERIAL)
326
25
22
18
17
16
11
14
13
15
21
7
6
5-1

5-2
# REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- -----------------------------------------------------
******************************
PACKING AND ACCESSORY ASSEMBLY <M1>
1 LY32179-004A PACKING CASE,A
LY32179-005A PACKING CASE,B,C,D
2 LY32065-001A CUSHION
3 LY30023-002A POLY BAG
4 QPA02003506 POLY BAG
! 5 LYT0692-001B IB(EN),A
! LYT0705-001B IB(EN),B,C
! LYT0721-001B IB(FR),C
! LYT0778-001A IB(EN),D
6 LY41538-002B LENS CAP
7 BT-51020-2 REGIST.CARD,A,B,D
BT-52004-1 WARRANTYCARD,C
! 10 LY20739-001A AC ADAPTER,AP-V10U
! 11 YQ10629A BATTERY PACK,BN-V11U,B,C,D
! LY31199-001A BATTERY PACK, BN-V20BU,A
12 LY20186-001A SHOULDER STRAP
13 YQ31963A-3 CASSETTE ADAPTER
or YQ31963B-3 CASSETTE ADAPTER
14 QQR0491-002 CORE FILTER,B,C,D
15 QAM0084-001 PC CONNECTION CABLE,B,C,D
16 LY42129-001A REMOTE CONTROL UNIT,RM-V715U,B,C,D
17 – AA(R6)BATTERY,FOR CASSETTE ADAPTER
18 – AAA(R03)BATTERY,FOR RCU,X2 B,C,D
19 LY32210-007A CD ROM,B,C,D
21 BT-20071B SER.NET CARD,C
22 YU30843-4 SOFT WARE PERM. B,C,D
! 25 LYT0309-001B IB(SOFT)(EN),B,C,D
26 LYT0309-004A SHEET(INSTALL),B,C,D
•INSTRUCTIONS
EN....... ENGLISH
FR ....... FRENCH
MODEL MARK
GR-SXM335U A
GR-SXM730U B
GR-SXM730UC C
GR-SXM735U D

5-3
5.2 FINALASSEMBLY <M2>
t
137
251C
251C
251C
251C
251C
251C
251C
251D
251B
251C251C
251A
254
251
253 255 257252
CCD
<02>
252
y
e
OPTICAL BLOCK
SECTION
256
ELECTRONIC
VIEWFINDER
<M4>
nn
v
u
126 124
124
123
102
121
121
101C
103
u
124
125
125 122 124
101A
101E
101D
r
j
h
g
101F
101B
101
n
s
ff
p
115
115
115 110
115
MAIN
<01>
136
ee dd
jj
r
cc
n
ss
hh
nn
ff
y
gg
bb
z
w
x
138
104G
104
104C
104B
104A
104H
104E
104D
104D
104D
104J
m
jj
b
k
104D
104F
117
117
104K
aa
(ONLY USE
156
156A
157
q
(ONLY USE FOR B , C , D )

5-4
127
105C
kk
105A
105C
105
LABEL
/CAUTION
127
105B
120
120
f
gg 109
114
121
121
121
133
132 131
130C
a
b
130A
h130E
130E
130F
130B130B
119
RATING
LABEL
130D
130D
133
135
130
135
c
f
pp
m
rr
d
k
v
w
j
p
e116
g
116
116
111
0
4D
D
117
04D
4
F
MECHANISM
<M3>
151
152
151
cc
pp
x
ee
dd bb
z
151
151
150
145
144
141
141
140
140A
153
kk
149
143
142
134
149 148 cd
MONITOR
<M5>
118
118
mm
a
hh
128
128
106
mm
rr
aa
qq
155
t
qq
s
q
DSC
<08>
L
Y USE FOR B , C , D )
154
ss

5-5
# REF No. PARTNo. PARTNAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
132 QYSPSTU1725M SCREW
133 LY41173-001A SPECIAL SCREW,X2
134 QYSLSF1750D SCREW
135 LY30018-050A SPECIAL SCREW,X2
136 LY42981-001A SPECIAL SCREW
137 WJT0039-001A E-CARD WIRE,OP-MAIN CN15
138 QYSLSF2060D SCREW
140 LY31790-001A FRONT FRAMEASSY
140A YQ44144-1-1 TAPE GUIDE
141 SPSH1725M SCREW,X2
142 LY31807-001A SIDE BRACKET L
143 LY42722-003A SCREW
144 LY31806-001A SIDE BRACKET R
145 LY42722-003A SCREW
148 LY31816-001A BRACKET(MECHA)
149 LY42722-003A SCREW,X2
150 LY31808-001A CASS.HOUSINGASSY
151 LY42722-003A SCREW,X4
152 LY30176-001A CASS.COV.INSIDE
153 LY31956-001A BRACKET(C.COV)
154 LY20645-001A HOLDER(DSC P.),B,C,D
155 QYSLSF2060D SCREW,B,C,D
156 LY42875-001A FPC(DSC)ASSY,B,C,D
156A LY42876-001A S.SHEET(DSC FPC),B,C,D
157 YU40341 INSULATER,B,C,D
– OPTICAL BLOCK SECTION –
251 LY30948-003A OP BLOCK ASSY
251A PTY30948-002 FOCUS MOTOR
251B PTY30948-321 ZOOM MOTOR
251C PTY30151-016 SCREW,X9
251D PTY30948-006 IRIS MOTOR UNIT,INCL.FPC
252 QYSPSGU2080Z SCREW,X2
253 LY31441-001A SPACER RUBBER
254 LY41757-001A OPTICAL LPF
255 LY20346-001A CCD SPACER
256 LY30018-072A SPECIAL SCREW
257 LYH40018-006A CCD BASEASSY
******************************
FINAL ASSEMBLY <M2>
101 LY20684-008A LOWER CASEASSY,A
LY20684-009A LOWER CASEASSY,B,C,D
101A LY40081-001A CAPACITOR
101B LY20682-001A GRIP BELT
101C LY30018-003A SPECIAL SCREW
101D QAS0061-001 SPEAKER
101E LY42764-001B HOLDER(SPEAKER)
101F QYSLSF2050Z SCREW
102 LY31945-001C COVER(JACK)
103 LY31946-001A COVER(JIG)
104 LY20683-005B FRONT COVERASSY,A
LY20683-015A FRONT COVERASSY,B,C,D
104A LY31937-001A HOOD
104B LY31938-001A COVER(HOOD)
104C LY31936-001A RING
104D QYSLSF2060D SCREW,X4
104E LY32040-001A DC LIGHT
104F LY30029-0B4A SPACER(A)
104G LY32043-001A MICROPHONE
104H YQ44341-6 CAUTION LABEL
104J LY32058-002A STICKER(A)
104K LY32060-003A STICKER(C)
105 LY20694-002B CASS.COVER(M)ASSY,B,C,D
LY20694-004B CASS.COVER(M)ASSY,A
105A LY42883-001A MARK
105B LY40559-001A SHIELD SHEET
105C LY40076-001A SPACER,X2
106 LY10257-036A UPPER CASE(M),B,C
LY10257-037A UPPER CASE(M),D
LY10257-039A UPPER CASE(M),A
109 LY20614-008B TOP OPE UNIT,B,C,D
LY20614-012B TOP OPE UNIT,A
110 LY20613-001A ZOOM UNIT
111 LY20615-005A REAR UNIT
114 LY32061-004A STICKER(D),B,C,D
LY32061-005A STICKER(D),A
115 QYSLSF2060D SCREW,X4
116 QYSLSF2060D SCREW,X3
117 QYSLSF2060D SCREW,X3
118 QYSLSF2060D SCREW,X2
119 QYSLSP2030D SCREW
120 QYSLSF2060D SCREW,X2
121 QYSLSF2050Z SCREW,X3
122 QYSLSF2060D SCREW
123 QYSLSF2060D SCREW
124 QYSLSF2060D SCREW,X4
125 QYSLSF2060D SCREW,X2
126 QYSLSF2060D SCREW
127 QYSLSP2030D SCREW,X2
128 QYSLSP2030D SCREW,X2
130 LY20678-001A FRAMEASSY
130A YQ31843 BASE
130B QYSLSF2060D SCREW,X2
130C LY30029-0A4A SPACER(A)
130D LY41082-001A CUSHION(OP),X2
130E YQ43810-1-1 CONTACT(LIGHT),X2
130F WJM0167-001A E-SI C WIRE C-F,MAIN CN4
131 LY42758-001A S.CASE(MAIN)

5-6
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
5.3 ELECTRICAL PARTS LIST
******************************
MAIN BOARD ASSEMBLY <01>
PW YB10310UY MAIN BOARDASSY,A
YB10310UZ MAIN BOARDASSY,B,C
YB10310VA MAIN BOARDASSY,D
IC101 UPD703039-029 IC(MICRO C ROM)
or UPD70F3040-029 IC(MICRO C ROM)
IC102 TC7S86FU IC(DIGITAL)
or SN74AHC1G86K IC
or MC74VHC1G86DF IC
IC104 AT25080N-10SC-X IC
or X25170S8I-2.5-X IC
or 25LC080-I/SN-X IC
IC105 M62367GP IC
IC106 IC-PST9327U-X IC
IC107 RS5C314 IC
! IC1601 BD6630KV IC
IC1801 PIC-26043S IR DETECT UNIT,B,C,D
IC2001 MC74AC04DT IC
IC2401 NJM2149V-X IC
IC3001 JCY0130 IC
IC3002 SN74AHC1G04K-X IC
IC3501 HA118224F IC
IC4001 JCY0149 IC
IC4002 TMS4C2973-28-X IC
IC4003 UPD6467GR-506-X IC(MICRO C ROM)
IC4004 MM1385NN-X IC
IC4201 UPC358G2/5/-W IC
IC4202 BA10324AF-XE IC
IC4251 BA10358F-XE IC
IC4501 UPD16835G3 IC
IC5201 HD49326BF IC
IC5202 JCY0098 IC
IC6001 FA3698F IC
IC7001 CXD3518R IC,D
IC7002 MN5814 IC
IC7005 BA4558F IC,D
IC7006 BA4558F IC
IC7007 TC7S04FU IC(DIGITAL),A,D
or MC74VHC1G04DF IC,A,D
or SN74AHC1G04K IC,A,D
IC7008 SN74LV4052APW IC
Q101 2SA1774/RS/-X TRANSISTOR
Q102 DTC144EE TRANSISTOR
Q103 2SC4617/QR/-X TRANSISTOR
Q104 DTC144EE TRANSISTOR
Q105 2SA1774/RS/-X TRANSISTOR
Q110 DTC144EE TRANSISTOR
Q111 DTC114EE TRANSISTOR
Q112 DTC114EE TRANSISTOR
Q113 2SC4097/QR/-X TRANSISTOR
Q2001 DTA114TE TRANSISTOR
Q2007 PUMX1 PAIR TRANSISTOR
or UMX1N PAIR TRANSISTOR
or HN1C01FU/G/-X PAIR TRANSISTOR
Q2008 PUMT1 PAIR TRANSISTOR
or HN1A01FU/G/-X PAIR TRANSISTOR
Q2021 DTC144EE TRANSISTOR
Q2022 DTC144EE TRANSISTOR
Q2023 2SC4617/QR/-X TRANSISTOR
Q2071 2SC4617/QR/-X TRANSISTOR
Q2401 DTC144EE TRANSISTOR
Q3002 PUMX1 PAIR TRANSISTOR
or UMX1N PAIR TRANSISTOR
or HN1C01FU/G/-X PAIR TRANSISTOR
Q3003 2SC4097/QR/-X TRANSISTOR
Q3006 DTC144EE TRANSISTOR
Q3501 HN1C01FU/G/-X PAIR TRANSISTOR
Q3502 HN1C01FU/G/-X PAIR TRANSISTOR
Q3505 DTC144EE TRANSISTOR
Q3901 HN1A01FU/G/-X PAIR TRANSISTOR
Q4201 2SC4617/QR/-X TRANSISTOR
Q4251 RPM-22PB PHOTO TRANSISTOR
Q4501 DTC114EE TRANSISTOR
Q4701 PUMX1 PAIR TRANSISTOR
or UMX1N PAIR TRANSISTOR
or HN1C01FU/G/-X PAIR TRANSISTOR
Q4702 2SC4617/QR/-X TRANSISTOR
Q4703 PUMX1 PAIR TRANSISTOR
or UMX1N PAIR TRANSISTOR
or HN1C01FU/G/-X PAIR TRANSISTOR
Q4704 PUMT1 PAIR TRANSISTOR
or HN1A01FU/G/-X PAIR TRANSISTOR
Q4705 2SC4617/QR/-X TRANSISTOR
Q4706 2SC4617/QR/-X TRANSISTOR
Q4707 2SC4617/QR/-X TRANSISTOR
Q4711 PUMX1 PAIR TRANSISTOR
or HN1C01FU/G/-X PAIR TRANSISTOR
or UMX1N PAIR TRANSISTOR
Q4712 PUMT1 PAIR TRANSISTOR
or HN1A01FU/G/-X PAIR TRANSISTOR
Q4713 PUMX1 PAIR TRANSISTOR
or UMX1N PAIR TRANSISTOR
or HN1C01FU/G/-X PAIR TRANSISTOR
Q4714 PUMT1 PAIR TRANSISTOR
or HN1A01FU/G/-X PAIR TRANSISTOR
Q4715 PUMX1 PAIR TRANSISTOR
or HN1C01FU/G/-X PAIR TRANSISTOR
or UMX1N PAIR TRANSISTOR
Q6101 SSM6J07FU MOS FET
Q6201 SSM6J07FU MOS FET
Q6301 CPH3304 MOS FET
Q6306 SSM3K02F MOS FET
Q6307 2SC4617/QR/-X TRANSISTOR
Q6308 CPH3101 TRANSISTOR
Q6401 SSM6J07FU MOS FET
Q6501 SSM6J07FU MOS FET
Q6601 CPH3305 MOS FET
Q6608 DTC144EE TRANSISTOR
Q6621 HN1C01FU/G/-X PAIR TRANSISTOR
Q6622 2SA1577/QR/-X TRANSISTOR
Q6701 FX802 TRANSISTOR
Q6702 2SC4097/QR/-X TRANSISTOR
Q6801 2SA1577/QR/-X TRANSISTOR
Q6811 2SB1121/TU/-X TRANSISTOR
Q7001 PUMX1 PAIR TRANSISTOR,D
Q7003 PUMX1 PAIR TRANSISTOR
Q7005 PUMX1 PAIR TRANSISTOR,D
Q7011 PUMX1 PAIR TRANSISTOR
Q7013 PUMX1 PAIR TRANSISTOR
MODEL MARK
GR-SXM335U A
GR-SXM730U B
GR-SXM730UC C
GR-SXM735U D

5-7
# REF No. PARTNo. PARTNAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
Q7015 PUMX1 PAIR TRANSISTOR
Q7017 2SC4617/QR/-X TRANSISTOR
Q7018 2SA1774/QR/-X TRANSISTOR
Q7019 2SC4617/QR/-X TRANSISTOR
Q7020 2SA1774/QR/-X TRANSISTOR
Q7022 DTC144EE TRANSISTOR,A,D
! D101 SB007W03Q SB DIODE
D102 UDZS7.5B ZENER DIODE
D105 1SS355 DIODE
D106 1SS355 DIODE
D107 SB007W03Q SB DIODE
D3001 DAN222 DIODE
D5201 1SS355 DIODE
D6001 CRS03 SB DIODE
D6101 CRS03 SB DIODE
D6106 1SS357 SB DIODE
D6201 CRS03 SB DIODE
D6301 CRS03 SB DIODE
D6401 CRS03 SB DIODE
D6501 CRS03 SB DIODE
D6601 1SS383 SB DIODE
D6616 UDZS8.2B ZENER DIODE
D7001 MA365 VARI CAP DIODE,D
D7002 MA365 VARI CAP DIODE
D7004 RB471E SB DIODE
R101 NRSA63J-104X MG RESISTOR 100kØ,1/16W
! R104 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R105 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R106 NRSA63J-561X MG RESISTOR 560Ø,1/16W
R107 NRVA63D-153X CMF RESISTOR 15kØ,1/16W
R108 NRVA63D-243X CMF RESISTOR 24kØ,1/16W
R109 NRVA63D-183X CMF RESISTOR 18kØ,1/16W
R110 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R111 NRSA63J-273X MG RESISTOR 27kØ,1/16W
R112 NRSA63J-331X MG RESISTOR 330Ø,1/16W
R113 NRSA63J-562X MG RESISTOR 5.6kØ,1/16W
R114 NRSA63J-821X MG RESISTOR 820Ø,1/16W
R115 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R116 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R118 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R119 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R120 NRSA63J-273X MG RESISTOR 27kØ,1/16W
R121 NRSA63J-273X MG RESISTOR 27kØ,1/16W
R122 NRSA63J-393X MG RESISTOR 39kØ,1/16W
R123 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R124 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R125 NRSA63J-273X MG RESISTOR 27kØ,1/16W
R126 NRSA63J-153X MG RESISTOR 15kØ,1/16W
R127 NRSA63J-221X MG RESISTOR 220Ø,1/16W
R128 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R129 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R130 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R131 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R132 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R133 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R134 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R135 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R136 NRSA63J-474X MG RESISTOR 470kØ,1/16W
R138 NRSA63J-333X MG RESISTOR 33kØ,1/16W
R139 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R140 NRSA63J-753X MG RESISTOR 75kØ,1/16W
R141 NRSA63J-334X MG RESISTOR 330kØ,1/16W
R142 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R143 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R144 NRSA63J-221X MG RESISTOR 220Ø,1/16W
R145 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R146 NRSA63J-474X MG RESISTOR 470kØ,1/16W
R147 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R148 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R149 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R150 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R151 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R152 NRSA63J-474X MG RESISTOR 470kØ,1/16W
R153 NRSA63J-474X MG RESISTOR 470kØ,1/16W
R158 NRSA63J-474X MG RESISTOR 470kØ,1/16W
R159 NRSA63J-474X MG RESISTOR 470kØ,1/16W
R160 NRSA63J-474X MG RESISTOR 470kØ,1/16W
R161 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R162 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R163 NRSA63J-221X MG RESISTOR 220Ø,1/16W
R164 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R166 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R167 NRSA63J-183X MG RESISTOR 18kØ,1/16W
R168 NRSA63J-562X MG RESISTOR 5.6kØ,1/16W
R170 NRSA63J-333X MG RESISTOR 33kØ,1/16W
R171 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R172 NRSA63J-151X MG RESISTOR 150Ø,1/16W
R173 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R174 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R175 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R176 NRSA63J-221X MG RESISTOR 220Ø,1/16W
R180 NRSA63J-331X MG RESISTOR 330Ø,1/16W
R182 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R183 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R184 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R188 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R190 NRSA63J-331X MG RESISTOR 330Ø,1/16W
R191 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R192 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R195 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R1601 NRV142F-R33X CMF RESISTOR 0.33Ø,1/4W
R1602 NRV142F-R33X CMF RESISTOR 0.33Ø,1/4W
R1603 NRSA63J-154X MG RESISTOR 150kØ,1/16W
R1604 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R1605 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R1606 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R1607 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R1608 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R1609 NRSA63J-333X MG RESISTOR 33kØ,1/16W
R1610 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R1612 NRSA63J-392X MG RESISTOR 3.9kØ,1/16W
R1613 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R1614 NRSA63J-333X MG RESISTOR 33kØ,1/16W
R1615 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R1617 NRSA63J-183X MG RESISTOR 18kØ,1/16W
R1618 NRSA63J-154X MG RESISTOR 150kØ,1/16W
R1619 NRSA63J-471X MG RESISTOR 470Ø,1/16W
R1620 NRSA63J-684X MG RESISTOR 680kØ,1/16W
R1621 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R1622 NRSA63J-224X MG RESISTOR 220kØ,1/16W
R1623 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R1624 NRSA63J-104X MG RESISTOR 100kØ,1/16W

5-8
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
R1625 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R1626 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R1628 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R1629 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R1630 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R1631 NRSA63J-122X MG RESISTOR 1.2kØ,1/16W
R1632 NRSA63J-153X MG RESISTOR 15kØ,1/16W
R1633 NRSA63J-683X MG RESISTOR 68kØ,1/16W
R2001 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R2002 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R2003 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R2004 NRSA63J-681X MG RESISTOR 680Ø,1/16W
R2005 NRSA63J-272X MG RESISTOR 2.7kØ,1/16W
R2006 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R2011 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R2012 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R2021 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R2022 NRSA63J-334X MG RESISTOR 330kØ,1/16W
R2023 NRSA63J-151X MG RESISTOR 150Ø,1/16W
R2024 NRVA63D-133X CMF RESISTOR 13kØ,1/16W
R2025 NRSA63J-823X MG RESISTOR 82kØ,1/16W
R2026 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R2027 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R2028 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R2030 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R2031 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R2032 NRSA63J-270X MG RESISTOR 27Ø,1/16W
R2051 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R2071 NRSA63J-473X MG RESISTOR 47kØ,1/16W
R2072 NRSA63J-562X MG RESISTOR 5.6kØ,1/16W
R2401 NRSA63J-392X MG RESISTOR 3.9kØ,1/16W
R2402 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R2403 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R3001 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R3002 NRVA63D-471X CMF RESISTOR 470Ø,1/16W
R3004 NRVA63D-273X CMF RESISTOR 27kØ,1/16W
R3006 NRVA63D-561X CMF RESISTOR 560Ø,1/16W
R3007 NRVA63D-153X CMF RESISTOR 15kØ,1/16W
R3008 NRSA63J-393X MG RESISTOR 39kØ,1/16W
R3009 NRSA63J-272X MG RESISTOR 2.7kØ,1/16W
R3010 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R3014 NRSA63J-681X MG RESISTOR 680Ø,1/16W
R3015 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R3016 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R3018 NRSA63J-271X MG RESISTOR 270Ø,1/16W
R3023 NRSA63J-331X MG RESISTOR 330Ø,1/16W
R3027 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R3028 NRVA63D-472X CMF RESISTOR 4.7kØ,1/16W
R3029 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R3030 NRSA63J-561X MG RESISTOR 560Ø,1/16W
R3034 NRSA63J-220X MG RESISTOR 22Ø,1/16W
R3038 NRSA63J-392X MG RESISTOR 3.9kØ,1/16W
R3501 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R3502 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R3504 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R3505 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R3506 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R3507 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R3508 NRSA63J-153X MG RESISTOR 15kØ,1/16W
R3901 NRSA63J-100X MG RESISTOR 10Ø,1/16W
R3902 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R3903 NRSA63J-182X MG RESISTOR 1.8kØ,1/16W
R4001 NRSA63J-113X MG RESISTOR 11kØ,1/16W
R4002 NRSA63J-123X MG RESISTOR 12kØ,1/16W
R4003 NRSA63J-153X MG RESISTOR 15kØ,1/16W
R4004 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R4006 NRVA63D-103X CMF RESISTOR 10kØ,1/16W
R4007 NRVA63D-432X CMF RESISTOR 4.3kØ,1/16W
R4008 NRVA63D-272X CMF RESISTOR 2.7kØ,1/16W
R4009 NRVA63D-152X CMF RESISTOR 1.5kØ,1/16W
R4010 NRVA63D-122X CMF RESISTOR 1.2kØ,1/16W
R4035 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R4037 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R4038 NRSA63J-101X MG RESISTOR,B,C,D 100Ø,1/16W
R4201 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R4202 NRSA63J-563X MG RESISTOR 56kØ,1/16W
R4203 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R4204 NRSA63J-331X MG RESISTOR 330Ø,1/16W
R4205 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R4206 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R4207 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R4208 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R4209 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R4210 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R4211 NRSA63J-243X MG RESISTOR 24kØ,1/16W
R4214 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R4215 NRSA63J-683X MG RESISTOR 68kØ,1/16W
R4216 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R4217 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R4218 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R4219 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R4220 NRSA63J-152X MG RESISTOR 1.5kØ,1/16W
R4221 NRSA63J-334X MG RESISTOR 330kØ,1/16W
R4222 NRSA63J-154X MG RESISTOR 150kØ,1/16W
R4223 NRSA63J-333X MG RESISTOR 33kØ,1/16W
R4224 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R4251 NRSA63J-182X MG RESISTOR 1.8kØ,1/16W
R4252 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R4253 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R4254 NRSA63J-684X MG RESISTOR 680kØ,1/16W
R4255 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R4256 NRSA63J-824X MG RESISTOR 820kØ,1/16W
R4257 NRSA63J-822X MG RESISTOR 8.2kØ,1/16W
R4258 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R4259 NRSA63J-683X MG RESISTOR 68kØ,1/16W
R4262 NRSA63J-302X MG RESISTOR 3kØ,1/16W
! R4501 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W
! R4502 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W
! R4503 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W
! R4504 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W
R4505 NRSA63J-271X MG RESISTOR 270Ø,1/16W
R4507 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R4508 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R4514 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R4515 NRSA63J-182X MG RESISTOR 1.8kØ,1/16W
R4702 NRSA63J-820X MG RESISTOR 82Ø,1/16W
R4703 NRVA63D-561X CMF RESISTOR 560Ø,1/16W
R4704 NRVA63D-272X CMF RESISTOR 2.7kØ,1/16W
R4705 NRVA63D-562X CMF RESISTOR 5.6kØ,1/16W
R4706 NRSA63J-681X MG RESISTOR 680Ø,1/16W
R4707 NRSA63J-122X MG RESISTOR 1.2kØ,1/16W
R4708 NRSA63J-104X MG RESISTOR 100kØ,1/16W

5-9
# REF No. PARTNo. PARTNAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
R4709 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R4710 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R4711 NRSA63J-121X MG RESISTOR 120Ø,1/16W
R4712 NRVA63D-561X CMF RESISTOR 560Ø,1/16W
R4713 NRSA63J-681X MG RESISTOR 680Ø,1/16W
R4714 NRSA63J-122X MG RESISTOR 1.2kØ,1/16W
R4715 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R4716 NRVA63D-511X CMF RESISTOR 510Ø,1/16W
R4717 NRVA63D-222X CMF RESISTOR 2.2kØ,1/16W
R4718 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R4719 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R4721 NRVA63D-680X CMF RESISTOR 68Ø,1/16W
R4722 NRVA63D-680X CMF RESISTOR 68Ø,1/16W
R4723 NRVA63D-680X CMF RESISTOR 68Ø,1/16W
R4735 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R4736 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R4737 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R4738 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R4739 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R4741 NRVA63D-152X CMF RESISTOR 1.5kØ,1/16W
R4743 NRVA63D-223X CMF RESISTOR 22kØ,1/16W
R4744 NRVA63D-222X CMF RESISTOR 2.2kØ,1/16W
R4745 NRVA63D-681X CMF RESISTOR 680Ø,1/16W
R4746 NRVA63D-222X CMF RESISTOR 2.2kØ,1/16W
R4747 NRVA63D-681X CMF RESISTOR 680Ø,1/16W
R5201 NRSA63J-243X MG RESISTOR 24kØ,1/16W
R5202 NRSA63J-220X MG RESISTOR 22Ø,1/16W
R5204 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5212 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R5213 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R5214 NRSA63J-101X MG RESISTOR 100Ø,1/16W
R5215 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R5216 NRSA63J-100X MG RESISTOR 10Ø,1/16W
R5217 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R5218 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R5220 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R6001 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R6002 NRSA63J-333X MG RESISTOR 33kØ,1/16W
R6003 NRVA63D-912X CMF RESISTOR 9.1kØ,1/16W
R6004 NRVA63D-471X CMF RESISTOR 470Ø,1/16W
R6005 NRVA63D-183X CMF RESISTOR 18kØ,1/16W
R6006 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R6008 NRVA63D-183X CMF RESISTOR 18kØ,1/16W
R6009 NRSA63J-224X MG RESISTOR 220kØ,1/16W
R6010 NRSA63J-473X MG RESISTOR 47kØ,1/16W
R6011 NRSA63J-473X MG RESISTOR 47kØ,1/16W
R6012 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R6015 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R6016 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R6019 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R6020 NRSA63J-224X MG RESISTOR 220kØ,1/16W
R6021 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R6022 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R6023 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R6103 NRVA63D-223X CMF RESISTOR 22kØ,1/16W
R6104 NRVA63D-103X CMF RESISTOR 10kØ,1/16W
R6203 NRVA63D-103X CMF RESISTOR 10kØ,1/16W
R6204 NRVA63D-103X CMF RESISTOR 10kØ,1/16W
R6303 NRVA63D-183X CMF RESISTOR 18kØ,1/16W
R6304 NRVA63D-472X CMF RESISTOR 4.7kØ,1/16W
R6306 NRS12BK-R47W MG RESISTOR 0.47Ø,1/2W
R6307 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R6309 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R6310 NRSA63J-152X MG RESISTOR 1.5kØ,1/16W
R6311 NRSA63J-473X MG RESISTOR 47kØ,1/16W
R6403 NRSA63J-473X MG RESISTOR 47kØ,1/16W
R6404 NRSA63J-302X MG RESISTOR 3kØ,1/16W
R6406 NRSA63J-183X MG RESISTOR 18kØ,1/16W
R6407 NRSA63J-823X MG RESISTOR 82kØ,1/16W
R6503 NRSA63J-243X MG RESISTOR 24kØ,1/16W
R6504 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R6506 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R6507 NRSA63J-823X MG RESISTOR 82kØ,1/16W
R6603 NRVA63D-683X CMF RESISTOR 68kØ,1/16W
R6604 NRVA63D-392X CMF RESISTOR 3.9kØ,1/16W
R6605 NRSA63J-274X MG RESISTOR 270kØ,1/16W
R6606 NRSA63J-272X MG RESISTOR 2.7kØ,1/16W
R6612 NRSA63J-823X MG RESISTOR 82kØ,1/16W
R6613 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R6614 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R6616 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R6622 NRVA63D-104X CMF RESISTOR 100kØ,1/16W
R6623 NRVA63D-473X CMF RESISTOR 47kØ,1/16W
R6624 NRSA63J-273X MG RESISTOR 27kØ,1/16W
R6625 NRSA63J-822X MG RESISTOR 8.2kØ,1/16W
R6626 NRVA63D-563X CMF RESISTOR 56kØ,1/16W
R6627 NRVA63D-363X CMF RESISTOR 36kØ,1/16W
R6701 NRSA63J-680X MG RESISTOR 68Ø,1/16W
R6702 NRSA63J-221X MG RESISTOR 220Ø,1/16W
R6704 NRVA63D-472X CMF RESISTOR 4.7kØ,1/16W
R6706 NRZ0058-R20X MG RESISTOR 0.2Ø,1/2W
R6707 NRS016J-121X MG RESISTOR 120Ø,1W
R6708 NRS016J-121X MG RESISTOR 120Ø,1W
R6709 NRS016J-121X MG RESISTOR 120Ø,1W
R6710 NRVA63D-823X CMF RESISTOR 82kØ,1/16W
R6711 NRVA63D-333X CMF RESISTOR 33kØ,1/16W
R6712 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W
R6713 NRSA63J-562X MG RESISTOR 5.6kØ,1/16W
R6801 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R6803 NRVA63D-223X CMF RESISTOR 22kØ,1/16W
R6804 NRVA63D-103X CMF RESISTOR 10kØ,1/16W
R6810 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R6811 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R6813 NRVA63D-104X CMF RESISTOR 100kØ,1/16W
R6814 NRVA63D-683X CMF RESISTOR 68kØ,1/16W
R6820 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R6961 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R7002 NRSA63J-102X MG RESISTOR,D 1kØ,1/16W
R7003 NRSA63J-103X MG RESISTOR,D 10kØ,1/16W
R7004 NRSA63J-333X MG RESISTOR,D 33kØ,1/16W
R7005 NRSA63J-103X MG RESISTOR,D 10kØ,1/16W
R7007 NRVA63D-473X CMF RESISTOR,D 47kØ,1/16W
R7008 NRVA63D-913X CMF RESISTOR,D 91kØ,1/16W
R7009 NRSA63J-0R0X MG RESISTOR,D 0Ø,1/16W
R7021 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R7029 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R7031 NRSA63J-474X MG RESISTOR 470kØ,1/16W
R7032 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R7033 NRSA63J-104X MG RESISTOR 100kØ,1/16W
R7035 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R7040 NRVA63D-333X CMF RESISTOR 33kØ,1/16W
R7042 NRVA63D-123X CMF RESISTOR 12kØ,1/16W

5-10
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
R7043 NRVA63D-123X CMF RESISTOR 12kØ,1/16W
R7044 NRVA63D-432X CMF RESISTOR,B,C 4.3kØ,1/16W
NRVA63D-752X CMF RESISTOR,A,D 7.5kØ,1/16W
R7045 NRVA63D-103X CMF RESISTOR 10kØ,1/16W
R7046 NRSA63J-103X MG RESISTOR,A,D 10kØ,1/16W
R7049 NRSA63J-680X MG RESISTOR 68Ø,1/16W
R7050 NRSA63J-680X MG RESISTOR 68Ø,1/16W
R7051 NRSA63J-680X MG RESISTOR 68Ø,1/16W
R7058 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R7061 NRVA63D-183X CMF RESISTOR,D 18kØ,1/16W
R7062 NRVA63D-334X CMF RESISTOR,D 330kØ,1/16W
R7067 NRSA63J-223X MG RESISTOR,A,D 22kØ,1/16W
NRSA63J-682X MG RESISTOR,B,C 6.8kØ,1/16W
R7068 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R7069 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R7070 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R7071 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R7072 NRSA02J-122X MG RESISTOR,B,C 1.2kØ,1/10W
NRSA02J-182X MG RESISTOR,A,D 1.8kØ,1/10W
R7073 NRSA02J-331X MG RESISTOR,A,D 330Ø,1/10W
NRSA02J-821X MG RESISTOR,B,C 820Ø,1/10W
R7074 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R7077 NRVA63D-682X CMF RESISTOR 6.8kØ,1/16W
R7078 NRVA63D-822X CMF RESISTOR,D 8.2kØ,1/16W
R7079 NRSA63J-0R0X MG RESISTOR,D 0Ø,1/16W
R7083 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R7085 NRVA63D-822X CMF RESISTOR,D 8.2kØ,1/16W
R7086 NRVA63D-123X CMF RESISTOR 12kØ,1/16W
R7088 NRVA63D-223X CMF RESISTOR,D 22kØ,1/16W
R7090 NRVA63D-822X CMF RESISTOR,D 8.2kØ,1/16W
R7091 NRVA63D-123X CMF RESISTOR 12kØ,1/16W
R7093 NRVA63D-223X CMF RESISTOR 22kØ,1/16W
R7095 NRVA63D-822X CMF RESISTOR,D 8.2kØ,1/16W
R7096 NRVA63D-123X CMF RESISTOR 12kØ,1/16W
R7098 NRVA63D-223X CMF RESISTOR,D 22kØ,1/16W
R7099 NRVA63D-103X CMF RESISTOR,D 10kØ,1/16W
R7100 NRVA63D-103X CMF RESISTOR,D 10kØ,1/16W
R7101 NRVA63D-103X CMF RESISTOR,D 10kØ,1/16W
R7102 NRVA63D-103X CMF RESISTOR,D 10kØ,1/16W
R7103 NRVA63D-103X CMF RESISTOR,D 10kØ,1/16W
R7110 NRSA63J-105X MG RESISTOR 1MØ,1/16W
R7112 NRVA63D-332X CMF RESISTOR 3.3kØ,1/16W
R7114 NRVA63D-223X CMF RESISTOR 22kØ,1/16W
R7116 NRVA63D-332X CMF RESISTOR 3.3kØ,1/16W
R7118 NRVA63D-223X CMF RESISTOR 22kØ,1/16W
R7120 NRVA63D-332X CMF RESISTOR 3.3kØ,1/16W
R7122 NRVA63D-223X CMF RESISTOR 22kØ,1/16W
R7124 NRVA63D-103X CMF RESISTOR 10kØ,1/16W
R7127 NRVA63D-103X CMF RESISTOR 10kØ,1/16W
R7128 NRVA63D-103X CMF RESISTOR 10kØ,1/16W
R7129 NRVA63D-103X CMF RESISTOR 10kØ,1/16W
R7130 NRVA63D-103X CMF RESISTOR 10kØ,1/16W
R7131 NRVA63D-103X CMF RESISTOR 10kØ,1/16W
R7132 NRVA63D-103X CMF RESISTOR 10kØ,1/16W
R7139 NRVA63D-911X CMF RESISTOR,A,B,C 910Ø,1/16W
R7142 NRSA63J-0R0X MG RESISTOR,B,C 0Ø,1/16W
R7143 NRSA63J-0R0X MG RESISTOR,A,D 0Ø,1/16W
R7212 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
R7213 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
RA101 NRZ0038-222X NET RESISTOR
RA102 NRZ0038-222X NET RESISTOR
RA103 NRZ0038-222X NET RESISTOR
RA104 NRZ0038-222X NET RESISTOR
RA105 NRZ0038-473X NET RESISTOR
RA106 NRZ0037-331X NET RESISTOR
RA107 NRZ0034-102W NET RESISTOR
RA108 NRZ0034-102W NET RESISTOR
RA109 NRZ0038-474X NET RESISTOR
RA4001 NRZ0034-100W NET RESISTOR,B,C,D
RA4002 NRZ0034-100W NET RESISTOR,B,C,D
RA4003 NRZ0034-100W NET RESISTOR,B,C,D
C102 NCF31EZ-104X CAPACITOR 0.1µF,25V
C103 NBE41AM-106X T CAPACITOR 10µF,10V
C104 NCB31EK-103X CAPACITOR 0.01µF,25V
C105 NCB21CK-224X CAPACITOR 0.22µF,16V
C106 NCF31EZ-104X CAPACITOR 0.1µF,25V
C107 NCB31EK-103X CAPACITOR 0.01µF,25V
C108 NBE21AM-225X T CAPACITOR 2.2µF,10V
C109 NBE41AM-106X T CAPACITOR 10µF,10V
C110 NDC31HJ-101X CAPACITOR 100pF,50V
C111 NEA70JM-226X E CAPACITOR 22µF,6.3V
C112 NEA70JM-226X E CAPACITOR 22µF,6.3V
C113 NCB31EK-103X CAPACITOR 0.01µF,25V
C114 NCB31EK-103X CAPACITOR 0.01µF,25V
C115 NCF31EZ-104X CAPACITOR 0.1µF,25V
C116 NCB31EK-103X CAPACITOR 0.01µF,25V
C118 NCF31EZ-104X CAPACITOR 0.1µF,25V
C119 NCB31EK-103X CAPACITOR 0.01µF,25V
C120 NCB31EK-103X CAPACITOR 0.01µF,25V
C121 NCF31EZ-104X CAPACITOR 0.1µF,25V
C122 NCF31EZ-104X CAPACITOR 0.1µF,25V
C123 NDC31HJ-100X CAPACITOR 10pF,50V
C124 NDC31HJ-100X CAPACITOR 10pF,50V
C125 NCB31EK-103X CAPACITOR 0.01µF,25V
C126 NDC31HJ-120X CAPACITOR 12pF,50V
C127 NCB31CK-333X CAPACITOR 0.033µF,16V
C128 NCB21CK-474X CAPACITOR 0.47µF,16V
C129 NCB31CK-333X CAPACITOR 0.033µF,16V
C131 NCF31EZ-104X CAPACITOR 0.1µF,25V
C132 NCF31EZ-104X CAPACITOR 0.1µF,25V
C133 NCF31EZ-104X CAPACITOR 0.1µF,25V
C134 NCF31EZ-104X CAPACITOR 0.1µF,25V
C1201 NCB31HK-102X CAPACITOR 0.001µF,50V
C1202 NBE20JM-106X T CAPACITOR 10µF,6.3V
C1205 NCB31EK-153X CAPACITOR 0.015µF,25V
C1206 NBE20JM-106X T CAPACITOR 10µF,6.3V
C1601 NCB31EK-103X CAPACITOR 0.01µF,25V
C1602 NCB21CK-224X CAPACITOR 0.22µF,16V
C1603 NCB31CK-223X CAPACITOR 0.022µF,16V
C1604 NCB31CK-223X CAPACITOR 0.022µF,16V
C1605 NCB31CK-223X CAPACITOR 0.022µF,16V
C1606 NCB31CK-104X CAPACITOR 0.1µF,16V
C1607 NCB31CK-104X CAPACITOR 0.1µF,16V
C1608 NCB31CK-683X CAPACITOR 0.068µF,16V
C1609 NCB31CK-104X CAPACITOR 0.1µF,16V
C1610 NCB31CK-104X CAPACITOR 0.1µF,16V
C1611 NCB31CK-104X CAPACITOR 0.1µF,16V
C1612 NDC31HJ-331X CAPACITOR 330pF,50V
C1613 NCB21CK-334X CAPACITOR 0.33µF,16V
C1614 NBE41AM-226X T CAPACITOR 22µF,10V
C1615 NCB31HK-681X CAPACITOR 680pF,50V
C1616 NCB21CK-474X CAPACITOR 0.47µF,16V

5-11
# REF No. PARTNo. PARTNAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
C1617 NCB31HK-152X CAPACITOR 0.0015µF,50V
C1618 NBE21AM-106X TCAPACITOR 10µF,10V
C1619 NCB31CK-223X CAPACITOR 0.022µF,16V
C1621 NBP41CM-106X TCAPACITOR 10µF,16V
C2001 NBE20JM-106X T CAPACITOR 10µF,6.3V
C2002 NFV41HJ-183X MPPS CAPACITOR 0.018µF,50V
C2003 NDC31HJ-331X CAPACITOR 330pF,50V
C2004 NBE20JM-226X T CAPACITOR 22µF,6.3V
C2005 NCB21CK-105X CAPACITOR 1µF,16V
C2021 NCB31EK-682X CAPACITOR 0.0068µF,25V
C2022 NBE20JM-106X T CAPACITOR 10µF,6.3V
C2023 NBP21CM-105X TCAPACITOR 1µF,16V
C2024 NCB31HK-122X CAPACITOR 0.0012µF,50V
C2025 NCB30JK-105X CAPACITOR 1µF,6.3V
C2026 NCB31HK-222X CAPACITOR 0.0022µF,50V
C2027 NCB30JK-474X CAPACITOR 0.47µF,6.3V
C2028 NCB30JK-105X CAPACITOR 1µF,6.3V
C2029 NCB30JK-105X CAPACITOR 1µF,6.3V
C2031 NCB31CK-104X CAPACITOR 0.1µF,16V
C2032 NCB31HK-472X CAPACITOR 0.0047µF,50V
C2033 NBE20JM-475X T CAPACITOR 4.7µF,6.3V
C2034 NCB31CK-104X CAPACITOR 0.1µF,16V
C2035 NBE20JM-226X T CAPACITOR 22µF,6.3V
C2036 NBE20JM-106X T CAPACITOR 10µF,6.3V
C2037 NBE20JM-226X T CAPACITOR 22µF,6.3V
C2038 NCB30JK-474X CAPACITOR 0.47µF,6.3V
C2051 NCB31EK-103X CAPACITOR 0.01µF,25V
C2071 NBE20JM-106X T CAPACITOR 10µF,6.3V
C2072 NCB31HK-222X CAPACITOR 0.0022µF,50V
C2401 NEA70GM-476X E CAPACITOR 47µF,4.0V
C2402 NCB30JK-105X CAPACITOR 1µF,6.3V
C2403 NBE20JM-475X T CAPACITOR 4.7µF,6.3V
C2404 NCF31EZ-104X CAPACITOR 0.1µF,25V
C3002 NCB21CK-105X CAPACITOR 1µF,16V
C3003 NCB21CK-105X CAPACITOR 1µF,16V
C3004 NCF31EZ-104X CAPACITOR 0.1µF,25V
C3005 NCF31EZ-104X CAPACITOR 0.1µF,25V
C3006 NDC31HG-100X CAPACITOR 10pF,50V
C3007 NDC31HG-100X CAPACITOR 10pF,50V
C3009 NCF31EZ-104X CAPACITOR 0.1µF,25V
C3011 NCF31EZ-104X CAPACITOR 0.1µF,25V
C3012 NCF31EZ-104X CAPACITOR 0.1µF,25V
C3013 NCF31EZ-104X CAPACITOR 0.1µF,25V
C3014 NCF31EZ-104X CAPACITOR 0.1µF,25V
C3015 NCF31EZ-104X CAPACITOR 0.1µF,25V
C3017 NCF31EZ-104X CAPACITOR 0.1µF,25V
C3019 NCB31EK-103X CAPACITOR 0.01µF,25V
C3020 NCB31EK-103X CAPACITOR 0.01µF,25V
C3027 NCB31EK-103X CAPACITOR 0.01µF,25V
C3028 NCB31EK-103X CAPACITOR 0.01µF,25V
C3033 NCB31CK-104X CAPACITOR 0.1µF,16V
C3037 NDC31HJ-100X CAPACITOR 10pF,50V
C3506 NCB31EK-103X CAPACITOR 0.01µF,25V
C3507 NCB31EK-103X CAPACITOR 0.01µF,25V
C3508 NCB31EK-103X CAPACITOR 0.01µF,25V
C3510 NCB31CK-104X CAPACITOR 0.1µF,16V
C3512 NCB10JK-106X CAPACITOR 10µF,6.3V
C3513 NCB31CK-223X CAPACITOR 0.022µF,16V
C3514 NCB21CK-105X CAPACITOR 1µF,16V
C3515 NCB31EK-103X CAPACITOR 0.01µF,25V
C3902 NCB31EK-103X CAPACITOR 0.01µF,25V
C3903 NDC31HJ-3R0X CAPACITOR 3pF,50V
C4006 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4008 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4009 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4010 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4012 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4014 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4017 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4019 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4022 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4024 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4028 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4029 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4030 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4036 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4040 NCB21CK-105X CAPACITOR 1µF,16V
C4044 NCB21CK-105X CAPACITOR 1µF,16V
C4048 NCB10JK-106X CAPACITOR 10µF,6.3V
C4049 NDC31HJ-100X CAPACITOR 10pF,50V
C4051 NDC31HJ-221X CAPACITOR 220pF,50V
C4052 NCB21CK-105X CAPACITOR 1µF,16V
C4053 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4201 NEA71HM-225X E CAPACITOR 2.2µF,50V
C4202 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4203 NCB31CK-104X CAPACITOR 0.1µF,16V
C4205 NCB31EK-103X CAPACITOR 0.01µF,25V
C4206 NCB31CK-104X CAPACITOR 0.1µF,16V
C4207 NCB31EK-103X CAPACITOR 0.01µF,25V
C4208 NCB31CK-104X CAPACITOR 0.1µF,16V
C4209 NCF21CZ-105X CAPACITOR 1µF,16V
C4210 NCF21CZ-105X CAPACITOR 1µF,16V
C4251 NEA71HM-335X E CAPACITOR 3.3µF,50V
C4252 NCB31CK-104X CAPACITOR 0.1µF,16V
C4253 NCB31EK-153X CAPACITOR 0.015µF,25V
C4254 NCB31EK-153X CAPACITOR 0.015µF,25V
C4256 NEA71CM-106X E CAPACITOR 10µF,16V
C4502 NBE21AM-106X TCAPACITOR 10µF,10V
C4504 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4505 NDC31HJ-330X CAPACITOR 33pF,50V
C4506 NCB31HK-102X CAPACITOR 0.001µF,50V
C4507 NCB31HK-102X CAPACITOR 0.001µF,50V
C4508 NCB31HK-102X CAPACITOR 0.001µF,50V
C4509 NCB31HK-102X CAPACITOR 0.001µF,50V
C4510 NCB31CK-104X CAPACITOR 0.1µF,16V
C4511 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4701 NBE20JM-106X T CAPACITOR 10µF,6.3V
C4702 NCF31EZ-104X CAPACITOR 0.1µF,25V
C4703 NBE20JM-106X T CAPACITOR 10µF,6.3V
C4704 NCB21CK-105X CAPACITOR 1µF,16V
C4705 NDC31HJ-820X CAPACITOR 82pF,50V
C4706 NDC31HJ-150X CAPACITOR 15pF,50V
C4707 NCB21CK-105X CAPACITOR 1µF,16V
C4708 NDC31HJ-820X CAPACITOR 82pF,50V
C4709 NDC31HJ-150X CAPACITOR 15pF,50V
C4710 NCB31EK-103X CAPACITOR 0.01µF,25V
C4711 NCB21CK-105X CAPACITOR 1µF,16V
C4715 NCB21CK-105X CAPACITOR 1µF,16V
C4719 NCB31EK-103X CAPACITOR 0.01µF,25V
C5203 NCB10JK-106X CAPACITOR 10µF,6.3V
C5207 NCB31EK-103X CAPACITOR 0.01µF,25V
C5208 NCB31EK-103X CAPACITOR 0.01µF,25V

5-12
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
C5209 NCB31EK-103X CAPACITOR 0.01µF,25V
C5210 NCF31EZ-104X CAPACITOR 0.1µF,25V
C5211 NCB21CK-105X CAPACITOR 1µF,16V
C5212 NCB21CK-105X CAPACITOR 1µF,16V
C5213 NCB31HK-332X CAPACITOR 0.0033µF,50V
C5214 NCB31EK-103X CAPACITOR 0.01µF,25V
C5218 NCF31EZ-104X CAPACITOR 0.1µF,25V
C5219 NBP21CM-685X TCAPACITOR 6.8µF,16V
C5221 NCB11EK-105X CAPACITOR 1µF,25V
C5222 NCB31CK-104X CAPACITOR 0.1µF,16V
C5223 NCF31EZ-104X CAPACITOR 0.1µF,25V
C5225 NCF31EZ-104X CAPACITOR 0.1µF,25V
C5227 NCB31CK-104X CAPACITOR 0.1µF,16V
C5228 NCF31EZ-104X CAPACITOR 0.1µF,25V
C5229 NCB11EK-105X CAPACITOR 1µF,25V
C5230 NCB21EK-104X CAPACITOR 0.1µF,25V
C5232 NDC31HJ-100X CAPACITOR 10pF,50V
C5233 NDC31HJ-100X CAPACITOR 10pF,50V
C5234 NDC31HJ-100X CAPACITOR 10pF,50V
C5235 NDC31HJ-100X CAPACITOR 10pF,50V
C5236 NDC31HJ-100X CAPACITOR 10pF,50V
C5237 NDC31HJ-100X CAPACITOR 10pF,50V
C6002 NEA71CM-106X E CAPACITOR 10µF,16V
C6004 NCF21CZ-105X CAPACITOR 1µF,16V
C6005 NCB21CK-105X CAPACITOR 1µF,16V
C6006 NCF21CZ-105X CAPACITOR 1µF,16V
C6007 NCB21CK-105X CAPACITOR 1µF,16V
C6009 NDC31HJ-820X CAPACITOR 82pF,50V
C6010 NCB21CK-224X CAPACITOR 0.22µF,16V
C6011 NCB21CK-104X CAPACITOR 0.1µF,16V
C6012 NCB21CK-224X CAPACITOR 0.22µF,16V
C6013 NCB31EK-473X CAPACITOR 0.047µF,25V
C6014 NCB31EK-473X CAPACITOR 0.047µF,25V
C6015 NCB31EK-473X CAPACITOR 0.047µF,25V
C6016 NCB31EK-473X CAPACITOR 0.047µF,25V
C6017 NCF21CZ-105X CAPACITOR 1µF,16V
C6101 NCB21CK-105X CAPACITOR 1µF,16V
C6102 NCB10JK-106X CAPACITOR 10µF,6.3V
C6105 NCB31HK-102X CAPACITOR 0.001µF,50V
C6106 NCF21CZ-105X CAPACITOR 1µF,16V
C6107 NCF21CZ-105X CAPACITOR 1µF,16V
C6110 NCB31HK-152X CAPACITOR 0.0015µF,50V
C6201 NCB21CK-105X CAPACITOR 1µF,16V
C6202 NCB10JK-106X CAPACITOR 10µF,6.3V
C6203 NEA70JM-476X E CAPACITOR 47µF,6.3V
C6205 NCB31HK-472X CAPACITOR 0.0047µF,50V
C6210 NCB31EK-103X CAPACITOR 0.01µF,25V
C6301 NCB11CK-225X CAPACITOR 2.2µF,16V
C6302 NCB10JK-106X CAPACITOR 10µF,6.3V
C6303 NEA70JM-226X E CAPACITOR 22µF,6.3V
C6305 NCB31HK-561X CAPACITOR 560pF,50V
C6307 NEA71CM-106X E CAPACITOR 10µF,16V
C6308 NBE20JM-106X T CAPACITOR 10µF,6.3V
C6310 NCB31HK-102X CAPACITOR 0.001µF,50V
C6401 NCB21CK-105X CAPACITOR 1µF,16V
C6402 NCF21CZ-105X CAPACITOR 1µF,16V
C6406 NCB31CK-683X CAPACITOR 0.068µF,16V
C6410 NCB21CK-474X CAPACITOR 0.47µF,16V
C6501 NCB21CK-105X CAPACITOR 1µF,16V
C6502 NCF21CZ-105X CAPACITOR 1µF,16V
C6506 NCB21CK-224X CAPACITOR 0.22µF,16V
C6510 NCB31CK-104X CAPACITOR 0.1µF,16V
C6601 NCB11CK-225X CAPACITOR 2.2µF,16V
C6602 NCF21CZ-105X CAPACITOR 1µF,16V
C6603 NCB11CK-475X CAPACITOR 4.7µF,16V
C6605 NDC31HJ-331X CAPACITOR 330pF,50V
C6606 NCF21CZ-105X CAPACITOR 1µF,16V
C6607 NCB11EK-105X CAPACITOR 1µF,25V
C6610 NCB31EK-103X CAPACITOR 0.01µF,25V
C6616 NCB21CK-105X CAPACITOR 1µF,16V
C6622 NCB21CK-105X CAPACITOR 1µF,16V
C6700 NCB31HK-272X CAPACITOR 0.0027µF,50V
C6701 NCF21CZ-105X CAPACITOR 1µF,16V
C6702 NCB41CK-106X CAPACITOR 10µF,16V
C6711 NCB21HK-472X CAPACITOR 0.0047µF,50V
C6802 NCF21CZ-105X CAPACITOR 1µF,16V
C6805 NCB31HK-102X CAPACITOR 0.001µF,50V
C6810 NCB31EK-103X CAPACITOR 0.01µF,25V
C6812 NCF21CZ-105X CAPACITOR 1µF,16V
C6820 NCB31HK-102X CAPACITOR 0.001µF,50V
C7001 NCB31EK-103X CAPACITOR 0.01µF,25V
C7002 NBE20JM-106X T CAPACITOR 10µF,6.3V
C7003 NBE20JM-335X T CAPACITOR,D 3.3µF,6.3V
C7004 NCB31HK-332X CAPACITOR,D 0.0033µF,50V
C7005 NCB31EK-103X CAPACITOR,D 0.01µF,25V
C7006 NDC31HJ-390X CAPACITOR,D 39pF,50V
C7007 NCB31HK-102X CAPACITOR,D 0.001µF,50V
C7008 NCB31EK-103X CAPACITOR,D 0.01µF,25V
C7012 NCB31CK-104X CAPACITOR,D 0.1µF,16V
C7013 NCB30JK-105X CAPACITOR 1µF,6.3V
C7019 NDC31HJ-121X CAPACITOR 120pF,50V
C7020 NDC31HJ-151X CAPACITOR 150pF,50V
C7021 NBP41EM-475X T CAPACITOR 4.7µF,25V
C7022 NCB31EK-103X CAPACITOR 0.01µF,25V
C7023 NCB31EK-103X CAPACITOR 0.01µF,25V
C7024 NBP41EM-475X T CAPACITOR 4.7µF,25V
C7025 NCB31EK-103X CAPACITOR 0.01µF,25V
C7026 NBE20JM-106X T CAPACITOR 10µF,6.3V
C7028 NCB31EK-103X CAPACITOR 0.01µF,25V
C7029 NCB31CK-104X CAPACITOR,A,D 0.1µF,16V
C7030 NCB31EK-103X CAPACITOR 0.01µF,25V
C7031 NDC31HJ-220X CAPACITOR 22pF,50V
C7032 NCB31CK-104X CAPACITOR 0.1µF,16V
C7033 NCB21CK-334X CAPACITOR 0.33µF,16V
C7034 NDC31HJ-331X CAPACITOR 330pF,50V
C7035 NDC31HJ-330X CAPACITOR 33pF,50V
C7036 NCB31CK-104X CAPACITOR 0.1µF,16V
C7037 NDC31HJ-330X CAPACITOR 33pF,50V
C7038 NCB31EK-103X CAPACITOR 0.01µF,25V
C7039 NBP41CM-106X T CAPACITOR 10µF,16V
C7041 NBE21AM-106X T CAPACITOR,D 10µF,10V
C7042 NCB31EK-103X CAPACITOR 0.01µF,25V
C7045 NDC31HJ-100X CAPACITOR,A,B,C 10pF,50V
C7046 NDC31HJ-100X CAPACITOR,A,B,C 10pF,50V
C7047 NDC31HJ-100X CAPACITOR,A,B,C 10pF,50V
C7048 NBE20JM-106X T CAPACITOR,A,B,C 10µF,6.3V
C7051 NCB31EK-103X CAPACITOR 0.01µF,25V
C7052 NBE20JM-106X T CAPACITOR 10µF,6.3V
C7053 NCB31EK-103X CAPACITOR 0.01µF,25V
C7054 NBP41EM-475X T CAPACITOR 4.7µF,25V
C7056 NCB21CK-104X CAPACITOR,D 0.1µF,16V
C7057 NCB31EK-682X CAPACITOR,A 0.0068µF,25V

5-13
# REF No. PARTNo. PARTNAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
C7058 NCB31CK-104X CAPACITOR,D 0.1µF,16V
C7059 NBP41EM-475X TCAPACITOR 4.7µF,25V
C7060 NCB11CK-225X CAPACITOR 2.2µF,16V
C7061 NCB11CK-475X CAPACITOR,D 4.7µF,16V
C7062 NCB11CK-475X CAPACITOR,D 4.7µF,16V
C7063 NCB11CK-475X CAPACITOR,D 4.7µF,16V
C7064 NCB11EK-105X CAPACITOR 1µF,25V
C7065 NCB11EK-105X CAPACITOR 1µF,25V
C7066 NCB11EK-105X CAPACITOR 1µF,25V
C7067 NCB31CK-104X CAPACITOR 0.1µF,16V
C7069 NCB31EK-103X CAPACITOR 0.01µF,25V
L101 NQL034K-330X COIL 33µH
L1601 NQL38DK-100X COIL 10µH
L1602 NQL144K-100X COIL 10µH
L2001 NQL144K-101X COIL 100µH
L2003 NQL034K-470X COIL 47µH
L2021 NQL144K-470X COIL 47µH
L2401 NQL144K-470X COIL 47µH
L3002 NQR0006-001X FERRITE BEAD
L3003 NQR0129-002X FERRITE BEAD
L3502 NQL38DK-220X COIL 22µH
L4201 NQR0006-001X FERRITE BEAD
L4501 NQR0006-001X FERRITE BEAD
L4502 NQL034K-220X COIL 22µH
L4701 NQL38DK-220X COIL 22µH
L5201 NQL38DK-470X COIL 47µH
L5202 NQL38DK-220X COIL 22µH
L5203 NQL38DK-220X COIL 22µH
L6001 NQL52EM-100X COIL 10µH
L6002 NQL52EM-100X COIL 10µH
L6101 NQL52EM-390X COIL 39µH
L6106 NQL144K-101X COIL 100µH
L6107 NQL144K-101X COIL 100µH
L6201 NQL52EM-470X COIL 47µH
L6301 NQL52EM-390X COIL 39µH
L6306 NQL52EM-470X COIL 47µH
L6401 NQL52EM-470X COIL 47µH
L6501 NQL52EM-470X COIL 47µH
L6601 NQL52EM-221X COIL 220µH
L6602 NQL144K-221X COIL 220µH
L6606 NQL144K-220X COIL 22µH
L6701 NQL52EM-100X COIL 10µH
L7001 NQL38DK-220X COIL 22µH
L7002 NQL085J-8R2X COIL,D 8.2µH
L7005 NQL38DK-220X COIL 22µH
L7006 NQL38DK-220X COIL 22µH
L7007 NQL38DK-220X COIL 22µH
L7008 NQL38DK-220X COIL 22µH
L7009 NQL38DK-220X COIL 22µH
L7010 NQL085J-4R7X INDUCTOR 4.7µH
L7012 NQL144K-100X COIL,A,B,C 10µH
X101 NAX0251-001X CRYSTALRESONATOR
X102 NAX0325-001X CRYSTALRESONATOR
X3001 QAX0565-001 CRYSTALRESONATOR
WR1 WJV0039-001A E-PRIMARY WIRE,JUMP WIRE
WR2 WJM0180-001B E-SI C WIRE C-F,JP4001/JP4002,B,C,D
WR3 YU40017-025-1 THIN WIRE,JP2005-SD1,B,C,D
! J101 QAB0022-001 LI BATTERY
J504 LY31356-002A JACK UNIT
J505 QND0068-001 S JACK
CN1 QGF0507F3-10X FFC/FPC CONNECTOR
CN2 QGF0507F3-14X FFC/FPC CONNECTOR
CN3 QGF0505F2-18X FPC CONNECTOR
CN4 QGA1201F2-06X CONNECTOR
CN5 QGF0507F1-11X FPC CONNECTOR
CN7 QGF0507F3-11X FFC/FPC CONNECTOR
CN8 QGA1201C2-02X CONNECTOR
CN11 QGF0507F1-20X FPC CONNECTOR,D
CN12 QGA1201F2-05X CONNECTOR,A,B,C
CN13 QGF0507F3-14X FFC/FPC CONNECTOR
CN15 QGF0507F1-22X FPC CONNECTOR
CN16 QGF0305F1-33X FPC CONNECTOR
CN18 QGF0507F3-12X FFC/FPC CONNECTOR
CN19 QGF0301F1-39X FPC CONNECTOR,B,C,D
CN22 QGF0507F3-14X FFC/FPC CONNECTOR
CN25 QGB0506L1-30X CONNECTOR
CN27 QGA1201C2-02X CONNECTOR
CN28 QGA1002F1-13X CONNECTOR
! F6001 NMFZ007-2R0X-K FUSE T2.0A
! F6002 NMFZ010-R50X-A FUSE T0.5A
SD1 LY42845-001A SHIELD SHEET,B,C,D
OT1 LY30016-049A SPACER-A,FOR WR1
OT2 LY30029-0B6A SPACER(A),FOR LI BATTERY
(Ozaki)-M1C723/C835/C8S5
GR-SXM335U, SXM730U/UC,SXM735U

0This Schematic Diagrams is printed on 100% recycled paper.
COPYRIGHT ©2001 VICTOR COMPANY OF JAPAN, LTD.
SCHEMATIC DIAGRAMS
CD-ROM No. SML200103
No. 86616SCH
March 2001
COMPACT VHS CAMCORDER
Digital : ø2.5 mm, 4-pole, mini-head
jack
S-Video :Y:1V
( p-p
)
, 75 Ω,
analog output
C: 0.29 V
( p-p
)
, 75 Ω,
analog output
AC Adapter AP-V10U
Power requirement
U.S.A. and Canada : AC 120 V`, 60 Hz
Other countries : AC 110 V to 240 V`,
50 Hz/60 Hz
Output : DC 11 V , 1 A
Dimensions : 59 mm x 31 mm x 69 mm
(W x H x D) (2-3/8" x 1-1/4" x 2-3/4")
Weight : Approx. 130 g (0.29 lbs)
Optional Accessories
•Battery Packs BN-V12U, BN-V20U, BN-V400U
•A/V (Audio/Video) Cable
•S-Video Cable QAM0004-004
• Compact S-VHS ( ) Cassettes ST-C-40/30/20
•Compact VHS ( ) Cassettes TC-40/30/20
•Active Carrying Bag CB-V7U
Camcorder
General
Format : S-VHS/VHS NTSC standard
Power source : DC 11 V
(Using AC Adapter)
DC 6 V
(Using battery pack)
Power consumption
Viewfinder on : 4.7 W
LCD monitor on : 5.4 W
Video light : 3.0 W
Signal system : NTSC-type
Video recording system
Luminance : FM recording
Color : Converted sub-carrier
direct recording
Conforms to VHS standard
Cassette :/cassette
Tape speed
SP : 33.35 mm/sec. (1-5/16 ips)
EP : 11.12 mm/sec. (7/16 ips)
Recording time (max.)
SP : 40 minutes
EP : 120 minutes (with TC-40)
D.S.C. format
Recording format : Digital data storage
(based on JPEG)
Recording medium : Built-in flash memory,
2 Mbyte
Number of storable shots
FINE mode : approx. 30 shots
STANDARD mode: approx. 60 shots
Image size : 640 x 480 pixels
(when captured on a PC)
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to change
without notice.
Operating
temperature :0°C to 40°C (32°F to 104°F)
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C
(–4°F to 122°F)
Weight : Approx. 900 g (2.0 lbs)
Dimensions : 206 mm x 112 mm x 118 mm
(8-1/8" x 4-7/16" x 4-11/16")
(with the LCD monitor closed
and with the viewfinder fully
tilted downward)
Pickup : 1/4" format CCD
Lens : F1.6, f = 3.9 mm to 62.4 mm,
16:1 power zoom lens with
auto iris and macro control,
filter diameter 40.5 mm
Viewfinder : Electronic viewfinder with
0.55" color LCD
White balance
adjustment : Auto/Manual adjustment
LCD monitor : 2.5" diagonally measured,
LCD panel/TFT active matrix
system
Speaker : Monaural
Connectors
Video : 1 V
( p-p
)
, 75 Ωunbalanced,
analog output
(via Video output connector)
Audio : 300 mV (rms), 1 kΩanalog
output
(via Audio output connector)
Some accessories are not available in some areas.
Please consult your nearest JVC dealer for details on
accessories and their availability.
SPECIFICATIONS (The specifications shown pertain specifically to the model GR-SXM735U)
JVC SERVICE & ENGINEERING COMPANY OF AMERICA
DIVISION OF JVC AMERICAS CORP.
Head office
East Coast
Midwest
West Coast
Atlanta
Hawaii
:
:
:
:
:
:
1700 Valley Road Wayne, New Jersey 07470-9976
10 New Maple Avenue Pine Brook, New Jersey 07058-9641
705 Enterprise Street Aurora, Illinois 60504-8149
5665 Corporate Avenue Cypress, California 90630-0024
1500 Lakes Parkway Lawrenceville, Georgia 30043-5857
2969 Mapunapuna Place Honolulu, Hawaii 96819-2040
[phone]
[phone]
[phone]
[phone]
[phone]
[phone]
JVC CANADA INC.
Head office
Montreal
Vancouver
:
:
:
21 Finchdene Square Scarborough, Ontario M1X 1A7
16800 Rte Trans-Canadienne, Kirkland, Quebec H9H 5G7
13040 Worster Court Richmond, B.C. V6V 2B3
[phone]
[phone]
[phone]
Printed in Japan
S40895-03
GR-SXM335U, SXM730U,
SXM735U
Regarding service information other than these sections, refer to the GR-SXM330U, SXM930U service manual (No. 86595).
Also, be sure to note important safety precautions provided in the service manual.

SECTION 4
CHARTS AND DIAGRAMS
4.1 BOARD INTERCONNECTIONS
5
4
1
2
3
ABCD
4-1
(Only for SXM735)

4-2
EFGH
Note1: How to find the page showing the continuative schematic diagram
Example)
TO CPU (Page 4-5): Refer to the GR-SXM330U, SXM930U service manaul (No. 86595)
TO REG (Page 4-7): Refer to this service manual
2: The mark
夝 means modified points.
(Only for SXM730, SXM735)
