JVC KD-DV6108 Guide

KD-DV6108/KD-DV6105/
KD-DV5108/KD-DV5105
Installation/Connection Manual
GET0278-004A
[U/UT/A]
1204DTSMDTJEIN
EN, CT
ENGLISH
This receiver is designed to operate on 12 V DC, NEGATIVE ground electrical systems. If
your vehicle does not have this system, a voltage inverter is required, which can be purchased
at JVC car audio dealers.
J
Rubber cushion
F
Crimp connector
G
Washer (ø5)
H
Lock nut (M5)
I
Mounting bolt (M5 x 20 mm)
C
Sleeve
D
Trim plate
E
Power cord
Parts list for installation and connection
The following parts are provided for this receiver.
After checking them, please set them correctly.
K
Handles
L
Remote controller
A / B
Hard case/Control panel
M
Battery
WARNINGS
• DO NOT install any receiver in locations where;
– it may obstruct the steering wheel and gearshift lever operations, as this may result in a
traffic accident.
– it may obstruct the operation of safety devices such as air bags, as this may result in a fatal
accident.
– it may obstruct visibility.
• DO NOT operate any receiver while manipulating the steering wheel, as this may result in a
traffic accident.
• The driver must not watch the monitor while driving.
If the driver watches the monitor while driving, it may lead to carelessness and cause an
accident.
• The driver must not put on the headphones while driving. It is dangerous to shut off the outside
sounds while driving.
• If you need to operate the receiver while driving, be sure to look ahead carefully or you may be
involved in a traffic accident.
• If the parking brake is not engaged, “DRIVER MUST NOT WATCH THE MONITOR WHILE
DRIVING.” appears on the monitor, and no playback picture will be shown.
– This warning appears only when the parking brake wire is connected to the parking brake
system built in the car.
INSTALLATION (IN-DASH MOUNTING)
The following illustration shows a typical installation. If you have any questions or require
information regarding installation kits, consult your JVC car audio dealer or a company supplying
kits.
• If you are not sure how to install this receiver correctly, have it installed by a qualified
technician.
Do the required electrical connections.
Bend the appropriate tabs to hold
the sleeve firmly in place.
*1 When you stand the receiver,
be careful not to damage the
fuse on the rear.
1
PRECAUTIONS on power supply and speaker
connections:
• DO NOT connect the speaker leads of the power cord to
the car battery; otherwise, the receiver will be seriously
damaged.
• BEFORE connecting the speaker leads of the power cord to the
speakers, check the speaker wiring in your car.
Instal1-2_DV6108_004A.indd 2 12/21/04 2:10:32 PM

When installing the receiver without using the sleeve /
In a Toyota for example, first remove the car radio and install the receiver in its place.
When using the optional stay /
Note : When installing the receiver on the mounting bracket, make sure to use the 8 mm-long screws.
If longer screws are used, they could damage the receiver.
Install the receiver at an angle of less than 30˚.
2
Stay (option)
TROUBLESHOOTING
• The fuse blows.
* Are the red and black leads connected correctly?
• Power cannot be turned on.
* Is the yellow lead connected?
• No sound from the speakers.
* Is the speaker output lead short-circuited?
• Sound is distorted.
* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?
• Noise interfere with sounds.
* Is the rear ground terminal connected to the car’s chassis using shorter and thicker cords?
• Receiver becomes hot.
* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?
• This receiver does not work at all.
* Have you reset your receiver?
Removing the receiver
Before removing the receiver, release the rear section.
Dashboard
Fire wall
Screw (option) Bracket*2
Flat type screws (M5 x 8 mm)*2
Pocket
Bracket*2
Flat type screws (M5 x 8 mm)*2
*2 Not included for this receiver.
Insert the two handles, then pull
them as illustrated so that the
receiver can be removed.
ELECTRICAL CONNECTIONS
To prevent short circuits, we recommend that you disconnect the battery’s negative terminal and
make all electrical connections before installing the receiver.
• Be sure to ground this receiver to the car’s chassis again after installation.
Notes:
• Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC
car audio dealer.
• It is recommended to connect to the speakers with maximum power of more than 50 W (both
at the rear and at the front, with an impedance of 4 Ω to 8 Ω). If the maximum power is less
than 50 W, change “AMP GAIN” setting to prevent the speakers from being damaged (see
page 36 of the INSTRUCTIONS).
• To prevent short-circuit, cover the terminals of the UNUSED leads with insulating tape.
• The heat sink becomes very hot after use. Be careful not to touch it when removing this
receiver.
About sounds reproduced through the rear terminals
• Through the analog terminals (Speaker out/LINE OUT/2nd AUDIO OUT):
2-channel signal is emitted.
When playing a multi-channel encoded disc, multi-channel signals are downmixed.
(AUDIO—DOWN MIX: see page 28 of the INSTRUCTIONS.)
• Through DIGITAL OUT (optical):
Digital signals (Linear PCM, Dolby Digital*3, DTS*4, MPEG Audio) are emitted through this
terminal. (For more details, see page 49 of the INSTRUCTIONS.)
To reproduce multi-channel sounds such as Dolby Digital and DTS, connect an amplifier or
a decoder compatible with these multi-channel sources to this terminal, and set “DIGITAL
AUDIO OUTPUT” to the correct value. (See page 28 of the INSTRUCTIONS.)
*3 Manufactured under license from Dolby Laboratories. “Dolby,” “Pro Logic” and the
double-D symbol are trademarks of Dolby Laboratories.
*4 “DTS” and “DTS 2.0 + Digital Out” are trademarks of Digital Theater Systems, Inc.
Heat sink
Instal1-2_DV6108_004A.indd 3 12/21/04 7:58:34 PM

3
ENGLISH
ATypical Connections /
Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause
serious damage to this receiver.
The leads of the power cord and those of the connector from the car body may be different in
color.
1 Connect the colored leads of the power cord in the order specified in the illustration below.
2 Connect the antenna cord.
3 Finally connect the wiring harness to the receiver.
*2 Not included for this receiver Ignition switch
*1 Only for KD-DV6108/KD-DV6105
SUBWOOFER (see diagram )
To CD changer or another
external component (see
diagram )
Rear ground
terminal
15 A fuse
Black
To metallic body or chassis of the car
Yellow*3
To a live terminal in the fuse block connecting to the car battery
(bypassing the ignition switch) (constant 12 V)
Red
To an accessory terminal in the fuse block
Blue
To the automatic antenna if any (250 mA max.)
Blue with white stripe
To the remote lead of other equipment (200 mA max.)
Orange with white stripe
To car light control switch
To cellular phone system
Brown
White with black stripe White Gray with black stripe
Left speaker (front)
Gray Green with black stripe
Right speaker (front)
Green Purple with black stripe
Left speaker (rear)
Purple
Right speaker (rear)
Fuse block
Light green
Line out (see diagram )
VIDEO OUT (see diagram )
2nd AUDIO OUT (see diagram )
LINE IN (see diagram )
To parking brake, metallic body or chassis of the car
DIGITAL OUT
(see diagram )
BConnecting the parking brake wire /
When installing the monitor in a location where it can be seen by the driver
Connect the parking brake wire to the parking brake system built in the car.
Connecting the crimp connector /
C
Wire connecting the battery and the parking brake switch.
Attach the parking brake wire to this point.
Contact the metallic part of the crimp to the wires inside.
Pinch the crimp firmly.
Parking brake
Parking brake wire (light green)
To metallic body or chassis of the car
Parking brake switch
(inside the car)
When installing the monitor in a location where it cannot be
seen by the dirver
Connect the parking brake wire to metallic body or chassis of the
car.
Parking brake wire (light green)
*3 Before checking the operation of this
receiver prior to installation, this lead must be
connected, otherwise power cannot be turned
on.
Instal3-4_DV6108_004A.indd 4 12/21/04 8:01:56 PM

JVC CD changer /
AV1-IN
AV2-INPUT
4
Required connections for DVD playback /
D
Audio/video control amplifier or the decoder
compatible with the multichannel digital sources
KV-MR9010
9-INCH WIDESCREEN
MONITOR (not supplied)
Video cord (not supplied)
Stereo mini plug
RCA Pin plugs
Digital optical cable (not supplied) DIGITAL OUT
See “About sounds reproduced
through the rear terminals.”
*4
Only for KD-DV6108/KD-DV6105: To listen to disc playback sound while in Dual Zone operations (see page 32 of INSTRUCTIONS).
EConnecting the external amplifiers /
Only for KD-DV6108/KD-DV6105
To the remote lead of other equipment or auto antenna if any
Y-connector (not supplied for this receiver) /
Remote lead/
*5
Signal cord (not supplied for this receiver)
Front speakers
Rear speakers
JVC Amplifier
JVC Amplifier
JVC Amplifier
Subwoofer
Front speakers
Remote lead (Blue with white stripe)
*6 Firmly attach the ground wire to the
metallic body or to the chassis of the
car—to the place not coated with paint
(if coated with paint, remove the paint
before attaching the wire). Failure
to do so may cause damage to the
receiver.
CAUTION /
• Before connecting the CD changer, make sure that the receiver is turned off.
*7 Connecting cord supplied for your CD changer
FConnecting the external components /
• Refer also to page 39 of the INSTRUCTIONS.
JVC CD changer
External component /
*8 Line Input Adapter KS-U57 (not supplied for this receiver)
KS-U57*8
CD changer jack
External component
LINE IN
Set external input to “EXT IN” (See page 36 of the INSTRUCTIONS.)
Only for KD-DV5108/KD-DV5105
Only for KD-DV6108/KD-DV6105
External component
or /
Rear side
VIDEO OUT
When using JVC’s KV-MR9010
and KS-HP2, connect using a
conversioncable of this type (not
supplied).
2nd AUDIO OUT*1
*1
Headphones (not supplied)*4
KS-HP2
Cordless headphones (not supplied)*4
You can connect amplifiers to upgrade your car stereo system.
• Connect the remote lead (blue with white stripe) to the remote lead of the other equipment so that
it can be controlled through this receiver.
• For amplifier only:
– Disconnect the speakers from this receiver, connect them to the amplifier. Leave the
speaker leads of this receiver unused.
– For KD-DV6108/KD-DV6105: The line output level of this receiver is kept high to maintain the hi-
fi sounds reproduced from this receiver. When connecting an external amplifier to this receiver,
turn down the gain control on the external amplifier to obtain the best performance from this
receiver.
Instal3-4_DV6108_004A.indd 5 12/21/04 10:11:09 PM
