KD-DV7306/KD-DV7305

Installation/Connection Manual

GET0449-009A

[A]

0207DTSMDTJEIN

This unit is designed to operate on 12 V DC, NEGATIVE ground electrical systems. If your vehicle does not have this system, a voltage inverter is required, which can be purchased at JVC car audio dealers.

WARNINGS

• DO NOT install any unit in locations w ere;

– it may obstruct t e steering w eel and gears ift lever operations.

– it may obstruct t e operation of safety devices suc as air bags.

– it may obstruct visibility.

• DO NOT operate t e unit w ile driving.

• If you need to operate t e unit w ile driving, be sure to look a ead carefully.

• T e driver must not watc t e monitor w ile driving.

If t e parking brake is not engaged, “DRIVER MUST NOT WATCH THE MONITOR WHILE DRIVING.” appears on t e monitor, and no playback picture will be s own.

– T is warning appears only w en t e parking brake wire is connected to t e parking brake system built in t e car.

To prevent short circuits, we recommend that you disconnect the battery’s negative terminal and ma e all electrical connections before installing the unit.

• Be sure to ground t is unit to t e car’s c assis again after installation.

Notes:

• Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC car audio dealer.

• It is recommended to connect to the spea ers with maximum power of more than 50 W (both at the rear and at the front, with an impedance of 4 Ω to 8 Ω). If the maximum power is less than 50 W, change

“AMP GAIN” setting to prevent the spea ers from being damaged (see page 41 of the INSTRUCTIONS).

• To prevent short-circuit, cover the terminals of the UNUSED leads with insulating tape.

• The heat sin becomes very hot after use. Be careful not to touch it when removing this unit.

PRECAUTIONS on power supply and speaker connections:

• DO NOT connect t e speaker leads of t e power cord to t e car battery; ot erwise, t e unit will be seriously damaged.

• BEFORE connecting the spea er leads of the power cord to the spea ers, chec the spea er wiring in your car.

Rubber cushion

Crimp connector

Washer (ø5)

Loc nut (M5)

Mounting bolt (M5 × 20 mm)

Parts list for installation and connection

If any item is missing, consult your JVC car audio dealer immediately.

Handles

Remote controller

Battery

A / B

Hard case/Control panel

Sleeve

Trim plate

Power cord

Heat sin

Instal1-2_DV7306_009A_2.indd 1Instal1-2_DV7306_009A_2.indd 1 2/6/07 12:04:25 PM2/6/07 12:04:25 PM

INSTALLATION (IN-DASH MOUNTING)

The following illustration shows a typical installation. If you have any questions or require information regarding installation its, consult your JVC car audio dealer or a company supplying its.

• If you are not sure how to install this unit correctly, have it installed by a qualified technician.

Removing t e unit

Before removing the unit, release the rear section.

Do the required electrical connections.

Bend the appropriate tabs to hold

the sleeve firmly in place.

W en installing t e unit wit out using t e sleeve

In a Toyota car for example, first remove the car radio and install the unit in its place.

W en using t e optional stay

Note : When installing the unit on the mounting brac et, ma e sure to use the 8 mm-long screws. If longer screws

are used, they could damage the unit.

Install the unit at an angle of less than 30˚.

TROUBLESHOOTING

• T e fuse blows.

* Are the red and blac leads connected correctly?

• Power cannot be turned on.

* Is the yellow lead connected?

• No sound from t e speakers.

* Is the spea er output lead short-circuited?

• Sound is distorted.

* Is the spea er output lead grounded?

* Are the “–” terminals of L and R spea ers grounded in common?

• Noise interfere wit sounds.

* Is the rear ground terminal connected to the car’s chassis using shorter and thic er cords?

• T is unit becomes ot.

* Is the spea er output lead grounded?

* Are the “–” terminals of L and R spea ers grounded in common?

• T is unit does not work at all.

* Have you reset your unit?

Insert the two handles, then pull them as

illustrated so that the unit can be removed.

Screw (option)

Stay (option)

Fire wall

Dashboard

Brac et *2

Flat type screws (M5 × 8 mm) *2

Poc et

Flat type screws (M5 × 8 mm) *2

Brac et *2

*1 When you stand the unit, be careful not to damage the fuse on the rear.

*2 Not supplied for this unit.

Instal1-2_DV7306_009A_2.indd 2Instal1-2_DV7306_009A_2.indd 2 1/17/07 12:21:13 PM1/17/07 12:21:13 PM

Connecting the parking brake wire

When installing the monitor in a location where it can be seen by the driver

Connect the parking brake wire to the parking brake system built in the car.

When installing the monitor in a location where it cannot be seen by the driver

Connect the parking brake wire to metallic body or chassis of the car.

Connecting the crimp connector

Parking brake wire

(light green)

To metallic body or

chassis of the car

Parking brake switch

(inside the car)

Parking brake

Parking brake wire (light green)

Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious

damage to this unit.

The leads of the power cord and those of the connector from the car body may be different in color.

*1 Not supplied for this unit.

*2 efore checking the operation of this unit prior to installation, this lead must be connected, otherwise power cannot be turned on.

*3 To listen to disc playback sound while in Dual Zone operations (see page 28 of INSTRUCTIONS).

Wire connecting the battery and

the parking brake switch.

Attach the parking brake

wire to this point.

Contact the metallic part of the

crimp to the wires inside.

Pinch the crimp firmly.

Typical connections

ELECTRICAL CONNECTIONS

To external components (see diagram )

Light green

VIDEO (see diagram )

DIGITAL OUT (see diagram )

To parking brake, metallic body or chassis of the car

15 A fuse

lack

lue with white stripe

Red

Yellow *2

To metallic body or chassis of the car

Ignition switch

Fuse block

To an accessory terminal in the fuse block

To the remote lead of other equipment (200 mA max.)

To a live terminal in the fuse block connecting to the car battery

(bypassing the ignition switch) (constant 12 V)

LINE OUT (see diagram )

Rear ground terminal

Left speaker (front) Right speaker (front) Left speaker (rear) Right speaker (rear)

PurplePurple with black stripeGreenGreen with black stripeGrayGray with black stripeWhiteWhite with black stripe

LINE IN (see diagram )

To the automatic antenna if any

(250 mA max.)

lue

2nd AUDIO OUT (see diagram )

SW (Subwoofer) (see diagram )

Antenna connector

rown To cellular phone system

Orange with white stripe To car light control switch

Req ired connections for DVD playback

Audio/video control amplifier or the

decoder compatible with the multichannel

digital sources

KV-MR9010

9-INCH WIDESCREEN MONITOR *1

Digital optical cable *1

Video cord *1

KS-HP2 *1

Cordless headphones *3

Rear side

Signal cord *1

1 Connect the colored leads of the power cord in the order specified in the illustration below.

2 Connect the antenna cord.

3 Finally connect the wiring harness to the unit.

Instal3-4_DV7306_009A_2.indd 3Instal3-4_DV7306_009A_2.indd 3 1/17/07 12:41:18 PM1/17/07 12:41:18 PM

Rear speakers

JVC Amplifier

Y-connector (not supplied for this unit)

Remote lead (blue with white stripe)

To the remote lead of other equipment or automatic antenna

if any

Front speakers

JVC Amplifier

Front speakers

JVC Amplifier

Subwoofer

You can connect these components as illustrated below.

All the components, adapters, or signal cords need to be purchased separately.

CAUTION:

Before connecting the external components, make sure that the unit is turned off.

To use JVC CD changer, Apple iPod or JVC D. player, set the external input setting to “CHANGER” (see page 41 of the INSTRUCTIONS).

To use other external components via KS-U57 or KS-U58, set the external input setting to “EXT IN” (see page 41 of the INSTRUCTIONS).

Other external component

Connecting the external components

3.5 mm stereo mini plug

EConnecting the external amplifiers and subwoofer

You can connect amplifiers to upgrade your car stereo system.

Connect the remote lead (blue with white stripe) to the remote lead of the other equipment so that it can be controlled through this unit.

• Disconnect the speakers from this unit, connect them to the amplifier. Lea e the speaker leads of this unit unused.

External component

*4 Remote lead

*5 Firmly attach the ground wire to the metallic body or to the chassis of the car—to the place uncoated with paint (if coated with paint, remove the paint before attaching the wire). Failure to do so may cause damage to the unit.

*6 Signal cord (not supplied for this unit)

*7 JVC Bluetooth adapter

*8 Connecting cord supplied for your CD changer

*9 Interface adapter for iPod

*10 D. player interface adapter

*11 Line Input Adapter

*12 AUX Input Adapter

External component

To KS-BTA200 or KD-DV7306/KD-DV7305

JVC CD changer

Apple iPod

JVC D. player
