JVC KD-SH9101 User manual

ENGLISH
DEUTSCH
FRANÇAIS
LVT1005-001B
[E/EX]
INSTRUCTIONS
BEDIENUNGSANLEITUNG
MANUEL D’INSTRUCTIONS
GEBRUIKSAANWIJZING
NEDERLANDS
CD RECEIVER
CD-RECEIVER
RECEPTEUR CD
CD-RECEIVER
KD-SH9104/KD-SH9103/
KD-SH9102/KD-SH9101
For installation and connections, refer to the separate manual.
Angaben zu Einbau und Verkabelung entnehmen Sie bitte der gesonderten Anleitung.
Pour l’installation et les raccordements, se référer au manuel séparé.
Zie de afzonderlijke handleiding voor details aangaande het installeren en verbinden van het
toestel.
This unit is equipped with the display demonstration. To cancel it, see page 8.
Dieses Gerät ist mit einer Demonstrationsfunktion für das Display ausgestattet. Auf
Seite 8 wird beschrieben, wie Sie diese Demonstrationsfunktion deaktivieren können.
Cet appareil est équipé d’une démonstration des affichages. Pour l’annuler, référez-
vous à la page 8.
Dit toestel heeft een display-demonstratiefunctie. Zie bladzijde 8 voor het annuleren
van deze functie.
Detachable
ANGLE
RM-RK100
CD
FM
AM
CH
AUX SEL
VOLUME
R D
ATT
DAB
DISC
PRESET PRESET
DISC
EQ
KD-SH9101
MOSFET
3456 M21
D
SRC
DISP
ATT
SEL
T/P
MODE
COVER_SH9104[E_EX]f.p65 6/15/03, 10:12 PM3

2
ENGLISH
BEFORE USE
* For safety....
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• Stop the car before performing any complicated
operations.
* Temperature inside the car....
If you have parked the car for a long time in hot or
cold weather, wait until the temperature in the car
becomes normal before operating the unit.
How to reset your unit
Press the reset button on the control panel using a
ball-point pen or similar tool.
This will reset the built-in
microcomputer.
Note:
Your preset adjustments—such as
preset channels or sound
adjustments—will also be erased.
CAUTION:
NEVER insert
your finger in
between the
control panel and
the unit, as it may get
caught or hurt.
(See page 52.)
56 M
T/P
MODE
Note:
For security reasons, a numbered ID card is provided with this unit, and the same ID number is imprinted on
the unit’s chassis. Keep the card in a safe place, as it will help the authorities to identify your unit if stolen.
Position And Reproduction Of Labels
Name/Rating plate
Bottom panel of the main unit
IMPORTANT FOR LASER PRODUCTS
Precautions:
1.CLASS 1 LASER PRODUCT
2.CAUTION: Invisible laser radiation when open and
interlock failed or defeated. Avoid direct exposure to
beam.
3.CAUTION: Do not open the top cover. There are no
user-serviceable parts inside. Leave all servicing to
qualified service personnel.
4.CAUTION: This CD player uses invisible laser radiation
and is equipped with safety switches to prevent
radiation emission when unloading CDs. It is dangerous
to defeat the safety switches.
5.CAUTION: Use of controls, adjustments or performance
of procedures other than those specified herein may
result in hazardous radiation exposure.
Caution:
This product contains a laser component
of higher laser class than Class 1.
CLASS
LASER
1
PRODUCT
CAUTION: Invisible laser
radiation when open and
interlock failedor defeated.
AVOIDDIRECT EXPOSURE
TO BEAM. (e)
ADVARSEL: Usynlig laser-
stråling ved åbning, når
sikkerhedsafbrydere er ude
af funktion. Undgåudsæt-
telse for stråling. (d)
VARNING: Osynlig laser-
strålning när denna del är
öppnad och spärren är
urkopplad. Betrakta ej
strålen. (s)
VARO: Avattaessa ja
suojalukitus ohitettaessa
olet alttiina näkymättö-
mälle lasersäteilylle.
Älä katso säteeseen. (f)
EN02-06SH9101[E_EX]f.p65 03.2.27, 22:482

3
ENGLISH
CONTENTS
Thank you for purchasing a JVC product. Please read all instructions carefully before operation,
to ensure your complete understanding and to obtain the best possible performance from the unit.
How to reset your unit .............................. 2
LOCATION OF THE BUTTONS ........... 4
Control panel ............................................ 4
Remote controller ..................................... 5
Preparing the remote controller ................ 6
BASIC OPERATIONS ...................... 7
Turning on the power ............................... 7
Canceling the display demonstration ....... 8
Setting the clock ....................................... 8
Selecting the level meter .......................... 9
RADIO OPERATIONS ..................... 10
Listening to the radio ................................ 10
Storing stations in memory ...................... 12
Tuning in to a preset station ..................... 13
Changing the display pattern ................... 14
RDS OPERATIONS ........................ 15
What you can do with RDS ...................... 15
Other convenient RDS functions and
adjustments ........................................... 20
CD OPERATIONS .......................... 22
About MP3 and WMA discs ..................... 22
Playing a disc ........................................... 22
Locating a particular portion on a track ..... 24
Locating a track on a disc ........................ 25
Locating a folder on a disc ....................... 26
Selecting a folder and a track using the
name lists .............................................. 28
Selecting playback modes ....................... 29
Prohibiting disc ejection ........................... 30
Changing the display pattern ................... 31
DSP OPERATIONS ........................ 32
Selecting the DSP modes ........................ 32
EQUALIZER OPERATIONS ............... 35
Selecting preset sound modes
(iEQ: intelligent equalizer) ..................... 35
Storing your own sound modes ............... 36
CAUTION on Volume Setting:
Discs produce very little noise compared with
other sources. If the volume level is adjusted for
the tuner, for example, the speakers may be
damaged by the sudden increase in the output
level. Therefore, lower the volume before playing a
disc and adjust it as required during playback.
SOUND ADJUSTMENTS .................. 37
Performing the basic sound settings ........ 37
GRAPHIC DISPLAYS ...................... 39
Downloading images and animations ...... 40
Deleting unwanted files ............................ 42
Activating the downloaded images and
animations ............................................. 44
OTHER MAIN FUNCTIONS ............... 46
Changing the general settings (PSM) ...... 46
Selecting the dimmer mode ..................... 50
Assigning names to the sources .............. 51
Changing the control panel angle ............ 52
Detaching the control panel ..................... 53
CD CHANGER OPERATIONS ............. 54
Playing discs ............................................ 54
Locating a folder on a disc ....................... 57
Selecting a disc/folder/track using
the name lists ........................................ 58
Selecting playback modes ....................... 59
EXTERNAL COMPONENT OPERATIONS .... 61
Playing an external component ................ 61
DAB TUNER OPERATIONS ............... 62
Tuning in to an ensemble and one of the
services ................................................. 62
Storing DAB services in memory ............. 64
Tuning in to a preset DAB service ........... 64
What you can do more with DAB ............. 66
Changing the display pattern ................... 70
ADDITIONAL INFORMATION ............ 71
TROUBLESHOOTING ..................... 72
MAINTENANCE ............................ 74
Handling discs .......................................... 74
SPECIFICATIONS .......................... 75
Caution:
If the temperature inside the car is below 0°C, the
movement of animation and text scroll will be
halted on the display to prevent the display from
being blurred. (LOW TEMP.) indicator
appears on the display.
When the temperature increases, and the operating
temperature is resumed, these functions will start
working again.
EN02-06SH9101[E_EX]f.p65 03.2.27, 22:483

4
ENGLISH
LOCATION OF THE BUTTONS
Control panel
1SRC (source) button
2DISP (D) (display) button
35(up) button
44/¢buttons
5Display window
6•0(eject) button
•(angle) button
7T/P (traffic programme/programme type)
button
Illumination Navigation for easy operations:
If you use MODE (M) or SEL (select), the display and some controls (such as the number buttons,
4/¢, 5/ ∞, and control dial) enter the corresponding control mode, then the controls
start flashing to lead you to the next operational steps. (Illumination Navigation)
• The display show how these buttons function during this period.
Ex. When you press number button 1 after pressing MODE (M), to operate the FM tuner.
To use these controls for original functions again, wait until the controls stop flashing without
using these controls.
• Pressing MODE (M) again also restores original functions. However, pressing SEL (select)
makes the unit into a different mode.
3456 M21
D
SRC
DISP
ATT
SEL
T/P
MODE
1 2 3 6 57
89 q er t
pw
4
8•(standby/on/attenuator) button
•Control dial
9Remote sensor
p∞(down) button
qSEL (select) button
wNumber buttons
eMODE (M) button
r(control panel release) button
tReset button
M
MODE
Time countdown indicator
Appear only when selecting
the FM band
345621
EN02-06SH9101[E_EX]f.p65 03.2.27, 22:484

5
ENGLISH
Remote controller
1•Turns on the unit if pressed when the unit is
turned off.
•Turns off the unit if pressed and held for a
few seconds.
•Drops the volume level in a moment if
pressed briefly.
Press again to resume the volume.
2Changes the angle of the control panel to four
positions.
3Skips to the root while listening to an MP3
disc.
4•CD: Selects CD player.
•FM/DAB:
–Selects FM tuner if pressed briefly.
Each time you press the button, FM band
(FM1, FM2 and FM3) changes.
–Selects DAB tuner if pressed and held.*1
Each time you press and hold the button,
DAB band (DAB1, DAB2 and DAB3)
changes.
•AM: Selects AM tuner.
•CH: Selects CD changer.*1
•AUX: Selects the external component
(LINE IN).*2
5*3•Changes the volume.
6Selects the sound (iEQ) mode.
Each time you press the button, the sound
(iEQ) mode changes.
7•Searches stations while listening to the
radio.
•Selects ensembles while listening to the
DAB tuner.
•Fast-forwards or reverses the track if
pressed and held while listening to a disc.
•Skips to the beginning of the next track or
goes back to the beginning of the current (or
previous) tracks if pressed briefly while
listening to a disc.
8•Selects services while listening to the DAB
tuner.
•Changes the disc number while listening to
the CD changer. Each time you press and
hold the button, the disc number changes,
and the selected disc starts playing.
•Skips to the first track of a folder on a higher
hierarchy level or on a lower hierarchy level
if pressed briefly while listening to an MP3
or a WMA disc. (This does not function for
WMA discs on the MP3-compatible CD
changer).
•Adjusts the fader level on the fader/balance
adjustment screen.
9•Changes the preset channel number while
listening to the radio (or the DAB tuner).
Each time you press the button, the preset
channel number changes, and the selected
station (or service) is tuned in.
•Skips to the first track of the next folder or
the first track of the previous folder if
pressed and held while listening to an MP3
or a WMA disc.
•Skips to the first track of the next folder or
the first track of the previous folder on the
same hierarchy level if pressed briefly while
listening to an MP3 or a WMA disc. (This
does not function for WMA discs on the
MP3-compatible CD changer).
•Adjusts the balance level on the fader/
balance adjustment screen.
p*3Turns on or off the fader/balance adjustment
screen. Then you can adjust them using the
buttons explained above (8and 9).
*1Without connecting the DAB tuner or CD
changer, you cannot select it as the source to
play.
*2If the “Line In” setting is changed to “Off,” you
cannot select “LINE IN” (see pages 48 and 49).
*3These buttons do not function in the preferred
setting mode (PSM) adjustment.
ANGLE
RM-RK100
CD
FM
AM
CH
AUX SEL
VOLUME
R D
ATT
DAB
DISC
PRESET PRESET
DISC
EQ
6
7
8
9
p
1
2
3
4
5
EN02-06SH9101[E_EX]f.p65 03.2.27, 22:485

6
ENGLISH
Preparing the remote controller
Before using the remote controller:
•Aim the remote controller directly at the remote
sensor on the main unit. Make sure there is no
obstacle in between.
•Do not expose the remote sensor to strong light
(direct sunlight or artificial lighting).
Installing the battery
When the controllable range or effectiveness of the
remote controller decreases, replace the battery.
1. Remove the battery holder.
1) Push out the battery holder in the direction
indicated by the arrow using a ball-point
pen or a similar tool.
2) Remove the battery holder.
2. Place the battery.
Slide the battery into the holder with the + side
facing upwards so that the battery is fixed in
the holder.
3. Return the battery holder.
Insert again the battery holder pushing it until
you hear a clicking sound.
(back side)
Lithium coin battery
(product number:
CR2025)
(back side)
Remote sensor
WARNING:
• Store the battery in a place where children cannot
reach.
If a child accidentally swallows the battery,
consult a doctor immediately.
• Do not recharge, short, disassemble or heat the
battery or dispose of it in a fire.
Doing any of these things may cause the battery
to give off heat, crack or start a fire.
• Do not leave the battery with other metallic
materials.
Doing this may cause the battery to give off heat,
crack or start a fire.
• When throwing away or saving the battery, wrap
it in tape and insulate; otherwise, the battery may
start to give off heat, crack or start a fire.
• Do not poke the battery with tweezers or similar
tools.
Doing this may cause the battery to give off heat,
crack or start a fire.
CAUTION:
DO NOT leave the remote controller in a place
(such as dashboards) exposed to direct sunlight
for a long time. Otherwise, it may be damaged.
1)
2)
3421
D
SRC
DISP
ATT
SEL
This receiver is equipped with the steering
wheel remote control function.
If your car is equipped with the steering
wheel remote controller, you can operate this
receiver using the controller.
•See the Installation/Connection Manual
(separate volume) for connection to utilize
this function.
EN02-06SH9101[E_EX]f.p65 03.2.27, 22:486

7
ENGLISH
BASIC OPERATIONS
Turning on the power
1 Turn on the power.
Note on One-Touch Operation:
When you select a source in step 2 below, the
power automatically comes on. You do not have
to press this button to turn on the power.
2 Select the source.
Each time you press the button,
the source changes as follows.
*1Without connecting the DAB tuner or CD
changer, you cannot select it as the source to
play.
*2If a disc is not in the loading slot, you cannot
select CD as the source to play.
*3When “Line In” is set to “Off” in the PSM
setting, you cannot select “LINE IN” as the
source (see page 49).
3 Adjust the volume.
4 Select the DSP mode and sound
mode as you want.
To drop the volume in a moment
Press briefly while listening to any
source. “ATT” starts flashing on the display, and
the volume level will drop in a moment.
To resume the previous volume level, press the
button briefly again.
• If you turn the control dial, you can also restore
the sound.
To turn off the power
Press for more than 1 second.
•If you turn off the power while listening to a
disc, playback will start from where playback
has been stopped previously, next time you
turn on the power.
1, 3
2
3456 M21
D
SRC
DISP
ATT
SEL
T/P
MODE
ATT
SRC
Current sound (iEQ) mode (see page 35)
Current DSP mode (see page 32)
ATT
Clock time
Display indication:
If you have changed
some PSM items (see
pages 47 and 48), the
indications on the
display you see may be
different from those used
in this manual.
*1*2
*3
CD CD-CH
(CD changer)
LINE IN
TUNER DAB
(DAB tuner)
*1
EN07-09SH9101[E_EX]f.p65 03.2.27, 22:497

8
ENGLISH
Canceling the display
demonstration
When shipped from the factory, display
demonstration has been activated, and starts
automatically when no operations are done for
about 20 seconds.
•It is recommended to cancel the demonstration
before you use the unit for the first time.
To cancel the display demonstration, follow
the procedure below:
1 Press and hold SEL (select) for more
than 2 seconds so that one of the
PSM items appears on the display.
(PSM: see pages 47 and 48.)
2 Press number button 1 to select
“MOVIE”—Movie category of the PSM
settings.
The “Graphics”setting screen appears on
the display.
3 Select “Off.”
4 Finish the setting.
SEL
ATT
To activate the display demonstration, repeat
the same procedure and select “Int Demo”or
“All Demo”in step 3 .
•For more details, see “To show the graphics on
the display—Graphics”on page 48.
Setting the clock
You can also set the clock system to 24 hours or
12 hours.
1 Press and hold SEL (select) for more
than 2 seconds so that one of the
PSM items appears on the display.
(PSM: see pages 47 and 48.)
2 Press number button 2 to select
“CLOCK”—Clock category of the
PSM settings.
The “Clock Hr”setting screen appears on
the display.
3 Adjust the hour.
4 Set the minute.
1Select “Clock Min (minute).”
2Adjust the minute.
SEL
ATT
SEL
345621
12
345621
ATT
EN07-09SH9101[E_EX]f.p65 03.2.27, 22:498

9
ENGLISH
5 Set the clock system.
1Select “24H/12H.”
2Adjust “24Hours”or “12Hours.”
6 Finish the setting.
To check the current clock time when the unit
is turned off, press DISP (D).
The power turns on and the clock time is shown
for about 5 seconds, then the power turns off.
Selecting the level meter
You can show the level meters on the display
while playing any source. This unit is equipped
with three level meter patterns.
1 Press and hold SEL (select) for more
than 2 seconds so that one of the
PSM items appears on the display.
(PSM: see pages 47 and 48.)
2 Press number button 3 to select
“DISP”—Display category of the PSM
settings.
3 Select “Theme.”
ATT
12
SEL
4 Select the level meter pattern you
want.
As you turn the control
dial, the level meters
change as follows:
5 Finish the setting.
Standard:
No level meter appears on the display. (Initially
selected when shipped from the factory.)
Meter 1:
The left and right audio level meters appear.
Meter 2:
Level meters fluctuate horizontally from center to
both sides as audio levels changes.
Meter 3:
Signal waves fluctuate at the center and spread
outward.
SEL
ATT
Meter 1
Standard
Meter 2
Meter 3
SEL
3
EN07-09SH9101[E_EX]f.p65 03.2.27, 22:499

10
ENGLISH
RADIO OPERATIONS
Listening to the radio
You can use either automatic searching or manual
searching to tune in to a particular station.
Searching a station automatically:
Auto search
1 Select the band (FM1 – 3, AM).
1Press SRC (source)
repeatedly to select the tuner.
2Press and hold SRC for more
than 1 second.
The band indication on the
display starts flashing.
3Within about 5 seconds (while
the band indication is
flashing), press SRC again.
Each time you press the
button, the band changes.
Last received station of the selected band is
tuned in.
3456 M21
D
SRC
DISP
ATT
SEL
T/P
MODE
Lights up when receiving an FM stereo broadcast
with sufficient signal strength.
Note:
This receiver has three FM bands (FM1, FM2,
FM3). You can use any one of them to listen to an
FM broadcast.
2 Start searching a station.
When a station is received, searching stops.
To stop searching before a station is received,
press the same button you have pressed for
searching.
Press ¢to search
stations of higher
frequencies.
Press 4to search
stations of lower
frequencies.
FM1
FM2FM3
AM
Ex. When the band is FM
Program station (PS)
name (see page 14)
Programme type (PTY)
(see page 14)
SRC
EN10-14SH9101[E_EX]f.p65 03.2.27, 22:5010

11
ENGLISH
Searching a station manually:
Manual search
1 Select the band (FM1 –3, AM).
1Press SRC (source)
repeatedly to select the tuner.
2Press and hold SRC for more
than 1 second.
3Within about 5 seconds, press
SRC again.
Each time you press the
button, the band changes.
Note:
This receiver has three FM bands (FM1, FM2,
FM3). You can use any one of them to listen to an
FM broadcast.
2 Press and hold ¢or 4until
“Manual Search”appears on the
display.
3 Tune in to a station you want while
“Manual Search”is still on the display.
• If you release your finger from the button,
the manual mode will automatically turn off
after about 5 seconds.
• If you hold down the button, the frequency
keeps changing (in 50 kHz intervals for FM
and 9 kHz intervals for AM—MW/LW) until
you release the button.
Press ¢to tune in to
stations of higher
frequencies.
Press 4to tune in to
stations of lower
frequencies.
To tune in FM stations only with strong
signals—LO/DX (Local/Distant)
While searching FM stations (including SSM—
see page 12), this unit stops searching whenever
it detects signals (DX mode: The DX indicator is
lit—initial setting). If received signals are weak,
you may only hear noises.
By setting LO/DX to “Local,” you can make this
unit detects only stations with sufficient signal
strength.
1Press MODE (M) while listening to
an FM stereo broadcast.
“Mode” appears on the display, and
the number buttons start flashing.
2Press number button 2, while “Mode” is still
on the display.
Each time you press the button, the “LO/DX”
setting alternates between “Local” and “DX.”
LO indicator appears
After about
5 seconds
The display returns to the source indication
screen.
FM1
FM2FM3
AM
M
MODE
345621
See page 40 for this function.
SRC
EN10-14SH9101[E_EX]f.p65 03.2.27, 22:5111

12
ENGLISH
Storing stations in memory
You can use one of the following two methods to
store broadcasting stations in memory.
•Automatic preset of FM stations: SSM (Strong-
station Sequential Memory)
•Manual preset of both FM and AM stations
FM station automatic preset: SSM
You can preset 6 local FM stations in each FM band
(FM1, FM2 and FM3).
1 Select the FM band (FM1 –3) you want
to store FM stations into.
1Press SRC (source)
repeatedly to select the tuner.
2Press and hold SRC for more
than 1 second.
The band indication on the
display starts flashing.
3Within about 5 seconds (while
the band indication is
flashing), press SRC again.
Each time you press the
button, the band changes.
2 Start SSM.
1Press MODE (M).
“Mode”appears on the
display, and the number
buttons start flashing.
2Press and hold number
button 5 until “– SSM –”
appears.
Local FM stations with the strongest signals are
searched and stored automatically in the band
number you have selected (FM1, FM2 or FM3).
These stations are preset in the number buttons —
No.1 (lowest frequency) to No.6 (highest
frequency).
When automatic preset is over, the station stored
in number button 1 will be automatically tuned in.
When an FM stereo broadcast is hard to
receive:
Set the FM reception mode to “Mono On.”
1Press MODE (M) while listening to
an FM stereo broadcast.
“Mode”appears on the display, and
the number buttons start flashing.
2Press number button 1, while “Mode”is still
on the display.
Each time you press the button, “Mono On”
and “Mono Off”alternately appears.
MO indicator appears
After about
5 seconds
The display returns to the source indication
screen.
SRC
M
MODE
5
FM1
FM2FM3
AM
M
MODE
345621
If the sound quality decreases and the
stereo effect is lost while listening to an
FM station
In some areas, adjacent stations may
interfere with each other. If this interference
occurs, this unit can automatically reduce this
interference noise (initial factory setting).
However, in this case, the sound quality will
be degraded and the stereo effect will be also
lost.
If you do not want to degrade the sound
quality and to lose the stereo effect, rather
than to eliminate the interference noise, see
“To change the FM tuner selectivity—IF
Filter”on page 49.
EN10-14SH9101[E_EX]f.p65 03.2.27, 22:5112

13
ENGLISH
Manual preset
You can preset up to 6 stations in each band (FM1,
FM2, FM3 and AM) manually.
Ex.: Storing an FM station of 92.5 MHz into the
preset number 1 of the FM1 band.
1 Select the band (FM1 –3, AM) you
want to store stations into (in this
example, FM1).
1Press SRC (source)
repeatedly to select the tuner.
2Press and hold SRC for more
than 1 second.
3Within about 5 seconds, press
SRC again.
Each time you press the
button, the band changes.
2 Tune in to a station (in this example,
of 92.5 MHz).
3 Press and hold the number button (in
this example, 1) for more than 2
seconds.
The selected preset number
flashes for a while.
4 Repeat the above procedure to store
other stations into other preset
numbers.
Press ¢to tune in to
stations of higher
frequencies.
Press 4to tune in to
stations of lower frequencies.
SRC
1
FM1
FM2FM3
AM
SRC
FM1
FM2FM3
AM
345621
Notes:
• A previously preset station is erased when a new
station is stored in the same preset number.
• Preset stations are erased when the power supply to
the memory circuit is interrupted (for example,
during battery replacement). If this occurs, preset
the stations again.
Tuning in to a preset station
You can easily tune in to a preset station.
Remember that you must store stations first. If you
have not stored them yet, see “Storing stations in
memory”on pages 12 and 13.
Selecting a preset station directly
1 Select the band (FM1 –3, AM).
1Press SRC (source)
repeatedly to select the tuner.
2Press and hold SRC for more
than 1 second.
The band indication on the
display starts flashing.
3Within about 5 seconds (while
the band indication is
flashing), press SRC again.
Each time you press the
button, the band changes.
2 Select the number (1 –6) for the preset
station you want.
EN10-14SH9101[E_EX]f.p65 03.2.27, 22:5113

14
ENGLISH
Changing the display pattern
By pressing DISP (D), you can change the
information shown on the display.
Each time you press the button, the
display patterns change as follows:
•Initial display pattern:
•Programme station (PS) name is
emphasized:
Selecting a preset station using the
preset station list
If you forget what stations are stored in what
preset numbers, you can check the preset station
list, then select your desired station on the list.
1 Select the band (FM1 –3, AM).
1Press SRC (source)
repeatedly to select the tuner.
2Press and hold SRC for more
than 1 second.
3Within about 5 seconds, press
SRC again.
Each time you press the
button, the band changes.
2 Press and hold 5(up) or ∞(down) until
the preset station list for the current
band (FM1, FM2, FM3, or AM) appears
on the display.
The currently received station will
be highlighted on the display.
Notes:
•If one of FM band preset station lists (FM1,
FM2, or FM3) is shown on the display, you
can show the other lists by pressing 5(up) or
∞(down).
•If a preset station is an FM RDS station with
PS signal, PS name will be shown instead of
the station frequency.
3 Select the number (1 –6) for the preset
station you want.
SRC
FM1
FM2FM3
AM
345621
D
DISP
*1“No Name”always appears for AM or FM non-RDS
stations (see the following pages).
*2Appears only when selecting a preset station.
*3PTY code appears only when receiving an RDS
station.
*2
*1
*3
EN10-14SH9101[E_EX]f.p65 03.2.27, 22:5114

15
ENGLISH
RDS OPERATIONS
What you can do with RDS
RDS (Radio Data System) allows FM stations to
send an additional signal along with their regular
programme signals. For example, the stations
send their station names, as well as information
about what type of programme they broadcast,
such as sports or music, etc.
Another advantage of RDS function is called
“Enhanced Other Networks.” By using the
Enhanced Other Networks data sent from a
station, you can tune in to a different station of a
different network broadcasting your favorite
programme or traffic announcement while
listening to another programme or to another
source such as CD.
By receiving the RDS data, this unit can do the
following:
• Tracing the same programme automatically
(Network-Tracking Reception)
• Standby Reception of TA (Traffic
Announcement) or your favorite programme
• PTY (Programme Type) search
• Programme search
• And some other functions
Tracing the same programme
automatically (Network-Tracking
Reception)
When driving in an area where FM reception is
not good, the tuner built in this unit automatically
tunes in to another RDS station, broadcasting the
same programme with stronger signals. So, you
can continue to listen to the same programme in
its finest reception, no matter where you drive.
(See the illustration on page 21.)
Two types of the RDS data are used to make
Network-Tracking Reception work correctly
—PI (Programme Identification) and AF
(Alternative Frequency).
Without receiving these data correctly from the
RDS station you are listening to, Network-
Tracking Reception will not operate.
To use Network-Tracking Reception
You can select the different modes of network-
tracking reception to continue listening to the
same programme in its finest reception.
When shipped from the factory, “AF” is selected.
• AF: Network-Tracking Reception is
activated without Regionalization.
With this setting, the unit switches to
another station within the same
network when the receiving signals
from the current station become
weak. (In this mode, the programme
may differ from the one currently
received.)
The AF indicator lights up.
• AF Reg: Network-Tracking Reception is
activated with Regionalization.
With this setting, the unit switches to
another station, within the same
network, broadcasting the same
programme when the receiving
signals from the current station
become weak.
The REG indicator lights up.
• Off: Network-Tracking Reception is
deactivated.
Neither the AF nor the REG indicator
lights up.
Note:
If a DAB tuner is connected and Alternative Reception
(for DAB services) is activated, Network-Tracking
Reception is also activated (“AF”) automatically. On
the other hand, Network-Tracking Reception cannot
be deactivated without deactivating Alternative
Reception. (See page 69.)
AF or REG indicator lights up.
EN15-21SH9101[E_EX]f.p65 03.2.27, 22:5515

16
ENGLISH
1 Press and hold SEL (select) for more
than 2 seconds so that one of the
PSM items appears on the display.
(PSM: see pages 47 and 48.)
2 Press number button 4 to select
“TUNER”—Tuner category of the
PSM settings.
The “PTY Stnby” (standby) setting screen
appears on the display.
3 Select “AF-Regn’l” (alternative
frequency/regionalization
reception).
4 Select the desired mode—“AF,”
“AF Reg,” or “Off.”
5 Finish the setting.
Using TA Standby Reception
TA Standby Reception allows the unit to switch
temporarily to Traffic Announcement (TA) from
the current source (another FM station, CD, or
other connected components).
• TA Standby Reception will not work if you are
listening to an AM station.
Press T/P to activate TA Standby
Reception.
Each time your press the button,
this function is turned on and off
alternately.
• When the DAB tuner is connected, this also
turns on and off Road Traffic Flash Standby
Reception (see page 66).
7When the current source is FM, the TP
indicator either lights up or flashes.
•If the TP indicator lights up, TA Standby
Reception is activated.
If a station starts broadcasting a traffic
announcement, “Traffic Flash” appears on
the display, and this unit automatically tunes
in to the station. The volume changes to the
preset TA volume level (see page 20) and
the traffic announcement can be heard.
•If the TP indicator flashes, TA Standby
Reception is not yet activated since the
station being received does not provide the
signals used for TA Standby Reception.
To activate TA Standby Reception, you need
to tune in to another station providing these
signals. Press ¢or 4to search
for such a station.
When a station providing these signals is
tuned in, the TP indicator stops flashing and
remains lit. Now TA Standby Reception is
activated.
SEL
ATT
SEL
T/P
345621
TP indicator appears
(either lights up or flashes)
EN15-21SH9101[E_EX]f.p65 03.2.27, 22:5516

17
ENGLISH
CONTINUED ON THE NEXT PAGE
SEL
ATT
M
MODE
SEL
345621
3 Select one of the twenty-nine PTY
codes. (See page 21.)
Selected code name
appears on the display
and is stored into
memory.
4 Finish the setting.
To set PTY Standby Reception
When the DAB tuner is connected, the following
operations will set PTY Standby Reception both
for the FM tuner and the DAB tuner. (See page
69.)
1Press MODE (M) while listening to
an FM stereo broadcast.
“Mode”appears on the display, and
the number buttons start flashing.
7When the current source is other than FM,
the TP indicator lights up.
If a station starts broadcasting a traffic
announcement, “Traffic Flash”appears on the
display, and this unit automatically changes the
source and tunes in to the station.
Using PTY Standby Reception
PTY Standby Reception allows the unit to switch
temporarily to your favorite programme (PTY:
Programme Type) from any source except AM
stations.
To select your favorite PTY code for PTY
Standby Reception
When shipped from factory, PTY Standby
Reception has been set to work for searching for
“News”programmes.
You can select your favorite programme type for
PTY Standby Reception.
1 Press and hold SEL (select) for more
than 2 seconds so that one of the
PSM items appears on the display.
(PSM: see pages 47 and 48.)
2 Press number button 4 to select
“TUNER”—Tuner category of the
PSM settings.
The “PTY Stnby”(standby) setting screen
appears on the display.
EN15-21SH9101[E_EX]f.p65 03.2.27, 22:5517

18
ENGLISH
Note:
After turning on PTY Standby Reception, you can
change the source without canceling PTY Standby
Reception. In this case, the PTY indicator stops
flashing if it was. If a station starts broadcasting the
selected PTY programme, this unit automatically
changes the source and tunes in to the station.
• If you change the source to AM, PTY Standby
Reception will be temporarily canceled.
• You can only deactivate the PTY Standby Reception
when the source is FM.
Searching your favorite programme
You can search any one of the PTY codes.
In addition, you can store your 6 favorite
programme types in the number buttons.
When shipped from the factory, the following
6 programme types have been stored in the
number buttons (1 to 6).
To store your favorite programme types, see
below and page 19.
To search your favorite programme type, see
page 19.
To store your favorite programme types
1 Press and hold T/P for more than 2
seconds while listening to an FM
station.
The last selected PTY code appears.
Pop M
123
Rock M Easy M
456
Classics Affairs Varied
T/P
345621
Ex.: When the currently selected PTY code
for PTY Standby Reception is “News”
After about
5 seconds
The display returns to the source indication
screen.
PTY indicator appears
(either lights up or flashes)
2Press number button 3 repeatedly to activate
PTY Standby Reception while “Mode”is still
on the display.
Each time you press the button, PTY Standby
Reception turns on and off alternately.
The PTY indicator either lights up or flashes.
•If the PTY indicator lights up, PTY Standby
Reception is activated.
If a station starts broadcasting the selected
PTY programme, this unit automatically tunes
in to the station.
•If the PTY indicator flashes, PTY Standby
Reception is not yet activated since the station
being received does not provide the signals
used for PTY Standby Reception.
To activate PTY Standby Reception, you need
to tune in to another station providing these
signals. Press ¢or 4to search for
such a station.
When a station providing these signals is tuned
in, the PTY indicator stops flashing and
remains lit. Now PTY Standby Reception is
activated.
EN15-21SH9101[E_EX]f.p65 03.2.27, 22:5518

19
ENGLISH
2 To select one of your favorite
programme type
or
To select any one of the twenty-nine
PTY codes
How to use the 5 (up) or ∞ (down) button
By pressing 5(up) or ∞(down) repeatedly,
you can show the list of your preset PTY codes
and all twenty-nine PTY codes (six PTY codes
at a time). First, the list of your stored PTY
codes appears, then all twenty-nine PTY codes
(six PTY codes at a time) appears in sequence.
Press the number button to select your desired
PTY code on the list currently shown on the
display.
3 Start PTY search for your favorite
programme.
•If there is a station broadcasting a programme
of the same PTY code as you selected, that
station is tuned in.
•If there is no station broadcasting a
programme of the same PTY code as you
selected, the station will not change.
Note:
In some areas, the PTY search will not work correctly.
Ex.: When “Rock M”is selected
The last selected PTY code appears.
ATT
345621
T/P
T/P
345621
ATT
2 Select one of the twenty-nine PTY
codes. (See page 21.)
Selected code name
appears on the display.
3 Press and hold the number button
for more than 2 seconds to store the
PTY code selected into the preset
number you want.
Selected preset number flashes for a while.
4 Press and hold T/P for more than 2
seconds to exit from this mode.
To search your favorite programme type
1 Press and hold T/P for more than 2
seconds while listening to an FM
station.
EN15-21SH9101[E_EX]f.p65 03.2.27, 22:5519

20
ENGLISH
Setting the TA volume level
You can preset the volume level for TA Standby
Reception. When a traffic programme is received,
the volume level automatically changes to the
preset level.
•See also “Changing the general settings
(PSM)”on page 46.
1Press and hold SEL (select) for more than
2 seconds so that one of the PSM items
appears on the display.
2Press number button 4 to select “TUNER”—
Tuner category of the PSM settings.
3Press ¢or 4to select “TA
Volume.”
4Turn the control dial to set to the desired
volume.
You can set it from “Volume 0”to “Volume 50.”
5Press SEL (select) to finish the setting.
Automatic clock adjustment
When shipped from the factory, the clock built in
this unit is set to be readjusted automatically
using the CT (Clock Time) data in the RDS
signal.
If you do not want to use automatic clock
adjustment, follow the procedure below.
•See also “Changing the general settings
(PSM)”on page 46.
1Press and hold SEL (select) for more than
2 seconds so that one of the PSM items
appears on the display.
2Press number button 2 to select “CLOCK”—
Clock category of the PSM settings.
3Press ¢or 4to select “Auto Adj”
(adjustment).
4Turn the control dial counterclockwise to select
“Off.”
Now automatic clock adjustment is canceled.
5Press SEL (select) to finish the setting.
To reactivate clock adjustment, repeat the
same procedure and select “On”in step 4by
turning the control dial clockwise.
Note:
You must stay tuned to the same station for more than
2 minutes after setting “Auto Adj” to “On.”
Otherwise, the clock time will not be adjusted. (This is
because the unit takes up to 2 minutes to capture the
CT data in the RDS signal.)
Other convenient RDS
functions and adjustments
Automatic selection of the station
when using the number buttons
Usually when you press the number button, the
preset station is tuned in.
However, when the preset station is an RDS
station, something different will happen. If the
signals from that preset station are not sufficient
for good reception, this unit, using the AF data,
tunes in to another frequency broadcasting the
same programme as the original preset station is
broadcasting. (Programme search)
•The unit takes some time to tune in to another
station using programme search.
To activate programme search, follow the
procedure below.
•See also “Changing the general settings
(PSM)”on page 46.
1Press and hold SEL (select) for more than
2 seconds so that one of the PSM items
appears on the display.
2Press number button 4 to select “TUNER”—
Tuner category of the PSM settings.
3Press ¢or 4to select
“P(Programme)-Search.”
4Turn the control dial clockwise to select “On.”
Now programme search is activated.
5Press SEL (select) to finish the setting.
To cancel programme search, repeat the same
procedure and select “Off”in step 4by turning
the control dial counterclockwise.
EN15-21SH9101[E_EX]f.p65 03.2.27, 22:5520
