JVC KD-S811R User manual

GET0013-001A
[E]
INSTRUCTIONS
BEDIENUNGSANLEITUNG
MANUEL D’INSTRUCTIONS
GEBRUIKSAANWIJZING
CD RECEIVER
CD-RECEIVER
RECEPTEUR CD
CD-RECEIVER
ENGLISH
DEUTSCH
FRANÇAIS
For installation and connections, refer to the separate manual.
Für den Einbau und die Anschlüsse siehe das eigenständige Handbuch.
Pour l’installation et les raccordements, se référer au manuel séparé.
Bijzonderheden over de installatie en aansluiting van het apparaat vindt u in de desbetreffende
handleiding.
COMPACT
DIGITAL AUDIO
KD-S811R/KD-S713R/
KD-S711R
NEDERLANDS
KD-S811R
KD-S713R
KD-S711R
COVER.KD-S811R[E].001A/5 07/12/2000, 05:05 PM3

2
ENGLISH
Position And Reproduction Of Labels
DANGER: Invisible laser
radiationwhenopen and
interlock failedordefeated.
AVOID DIRECTEXPOSURE
TOBEAM. (e)
ADVARSEL:Usynliglaser-
stråling ved åbning,når
sikkerhedsafbrydereerude
af funktion.Undgåudsæt-
telseforstråling. (d)
VARNING:Osynliglaser-
strålning när dennadel
är öppnadochspärren
är
urkopplad. Betrakta
ej
strålen. (s)
VARO: Avattaessa jasuo-
jalukitus ohitettaessaolet
alttiina näkymättömälle
lasersäteilylle. Älä katso
säteeseen. (f)
Caution:
This product contains a laser component
of higher laser class than Class 1.
IMPORTANT FOR LASER PRODUCTS
Precautions:
1.CLASS 1 LASER PRODUCT
2.DANGER: Invisible laser radiation when open and
interlock failed or defeated.Avoid direct exposure to
beam.
3.CAUTION: Do not open the top cover.There are no
user-serviceable parts inside. Leave all servicing to
qualified service personnel.
4.CAUTION:This CD player uses invisible laser
radiation and is equipped with safety switches to
prevent radiation emission when unloading CDs. It is
dangerous to defeat the safety switches.
5.CAUTION: Use of controls, adjustments or
performance of procedures other than those specified
herein may result in hazardous radiation exposure.
Name/Rating plate
Bottom panel of the main unit
How to reset your unit
Press and hold both the SEL (select) and (standby/on/attenuator) buttons at the same
time for several seconds.
This will reset the built-in microcomputer.
Notes:
• Your preset adjustments — such as preset channels or sound adjustments — will also be erased.
• If a CD is in the unit, it will eject when you reset the unit. Pay attention not to drop the CD.
SEL (Select)
(Standby/On/Attenuator)
EN02-03.KD-S811/713/711R[E]12 07/12/2000, 05:12 PM2

3
ENGLISH
BEFORE USE
* For safety....
•Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
•Stop the car before performing any complicated
operations.
*
Temperature inside the car....
If you have parked the car for a long time in hot or
cold weather, wait until the temperature in the car
becomes normal before operating the unit.
Thank you for purchasing a JVC product. Please read all instructions carefully before operation,
to ensure your complete understanding and to obtain the best possible performance from the unit.
Note:
For security reasons, a numbered ID card is provided with this unit, and the same ID number is imprinted on
the unit’s chassis. Keep the card in a safe place, as it will help the authorities to identify your unit if stolen.
CONTENTS
How to reset your unit............................... 2
LOCATION OF THE BUTTONS............ 4
Control panel ............................................ 4
BASIC OPERATIONS ...................... 5
Turning on the power ................................ 5
RADIO BASIC OPERATIONS ............. 6
Listening to the radio ................................ 6
Storing stations in memory....................... 7
Tuning into a preset station....................... 8
RDS OPERATIONS ........................ 9
What you can do with RDS EON.............. 9
Other convenient RDS functions and
adjustments........................................... 12
CD OPERATIONS .......................... 14
Playing a CD ............................................ 14
Locating a track or a particular portion on a
CD ......................................................... 15
Selecting CD playback modes.................. 15
Prohibiting CD ejection ............................. 16
SOUND ADJUSTMENTS .................. 17
Adjusting the sound ................................. 17
Using the
Sound Control Memory (SCM) .............. 17
Storing your own sound adjustments ....... 18
OTHER MAIN FUNCTIONS ............... 19
Setting the clock ...................................... 19
Changing the general settings (PSM) ...... 19
Detaching the control panel...................... 22
REMOTE CONTROLLER .................. 23
(With an optionally purchased remote
controller) (only for KD-S811R)
Installing the battery ................................. 23
Using the remote controller ...................... 24
TROUBLESHOOTING...................... 25
MAINTENANCE ............................ 26
Handling CDs .......................................... 26
SPECIFICATIONS .......................... 27
EN02-03.KD-S811/713/711R[E]12 07/12/2000, 05:12 PM3

ENGLISH
4
LOCATION OF THE BUTTONS
Control panel
1(standby/on/attenuator) button
2Control dial
3DISP (display) button
4AM button
5CD button
6FM button
70(eject) button
84/¢buttons
• Also functions as SSM buttons when pressed
together.
9SEL (select) button
pRemote sensor (only for KD-S811R)
qMO (monaural) button
RND (random) button
wNumber buttons
eTP (traffic programme)
RDS (radio data system) button
rPTY (programme type) button
tSCM (sound control memory) button
y(control panel release) button
;as
uoi
Display window
Display window
uVolume (or audio) level indicator
Equalization Pattern indicator
iTuner reception indicators
STEREO, MONO
oRND (random) indicator
;RDS indicators
AF, EON, REG, TP, PTY
a“SCM” indicator
sLOUD indicator
dSound mode indicators
BEAT, SOFT, POP
fCD indicator
gBand indicators
FM1, FM2, FM3
AM
hMain display
jCD IN indicator
d
treq9 pyw
23 54 67 8
1
fh
j
g
EN04-04.KD-S811/713/711R[E]15 07/12/2000, 05:11 PM4

5
ENGLISH
BASIC OPERATIONS
4 Adjust the sound as you want (see
page 17.)
To drop the volume in a moment
Press briefly while listening to any
source. “ATT” starts flashing on the display, and
the volume level will drop in a moment.
To resume the previous volume level, press the
button briefly again.
• If you rotate the control dial clockwise, you can
also restore the sound.
To turn off the power
Press and hold for more than 1 second.
Note:
When you use this unit for the first time, set the built-in
clock correctly, see page 19.
CAUTION on Volume Setting
CDs produce very little noise compared with other
sources. If the volume level is adjusted for the tuner,
for example, the speakers may be damaged by the
sudden increase in the output level. Therefore, lower
the volume before playing a disc and adjust it as
required during playback.
To increase the volume.
132
Volume level appears.
Volume level indicator
To decrease the volume.
Turning on the power
1 Turn on the power.
Note on One-Touch Operation:
Whenyouselect a source instep2below, the power
automatically comes on. You do not have to press
this button to turn on the power.
2 Select the source.
To operate the tuner (AM or FM),
see pages 6 –13.
To operate the CD player,
see pages 14 –16.
3 Adjust the volume.
EN05-05.KD-S811/713/711R[E]13 07/12/2000, 05:10 PM5

6
ENGLISH
RADIO BASIC OPERATIONS
To stop searching before a station is received,
press the same button you have pressed for
searching.
Searching a station manually:
Manual search
1 Select the band (AM, FM1 – 3).
Note:
This receiver has three FM bands (FM1, FM2,
FM3). You can use any one of them to listen to an
FM broadcast.
2 Press and hold ¢or 4until
"M"(manual) starts flashing on the
display.
Listening to the radio
You can use either automatic searching or manual
searching to tune into a particular station.
Searching a station automatically:
Auto search
1 Select the band (AM, FM1 –3).
Note:
This receiver has three FM bands (FM1, FM2,
FM3). You can use any one of them to listen to an
FM broadcast.
2 Start searching a station.
When a station is received, searching
stops.
Press ¢to search
stations of higher
frequencies.
Press 4to search
stations of lower
frequencies.
FM1 FM2 FM3
Selected band appears.
FM1 FM2 FM3
AM
Selected band appears.
Audio (see page 21) or volume level
indicator
AM
EN06-08.KD-S811/713/711R[E]14 07/12/2000, 05:15 PM6

7
ENGLISH
Storing stations in memory
You can use one of the following two methods to
store broadcasting stations in memory.
• Automatic preset of FM stations: SSM (Strong-
station Sequential Memory)
• Manual preset of both FM and AM stations
FM station automatic preset: SSM
You can preset 6 local FM stations in each FM band
(FM1, FM2 and FM3).
1 Select the FM band (FM1 –3) you want
to store FM stations into.
• Each time you press the button, the FM
band changes as follows:
2 Press and hold both buttons for more
than 2 seconds.
Local FM stations with the strongest signals are
searched and stored automatically in the band
number you have selected (FM1, FM2 or FM3.)
These stations are preset in the number buttons —
No.1(lowestfrequency) toNo.6(highestfrequency).
When automatic preset is over, the station stored
in number button 1 will be automatically tuned in.
Lights up when receiving an
FM broadcast in stereo.
3 Tune into a station you want while“M”
is flashing.
•If you release your finger from the button,
the manual mode will automatically turn off
after 5 seconds.
•If you hold down the button, the frequency
keeps changing (in 50 kHz intervals for FM
and 9 kHz intervals for AM –MW/LW) until
you release the button.
When an FM stereo broadcast is hard to
receive:
Press MO RND (monaural/random) while listening
to an FM stereo broadcast.
•Eachtimeyoupress the button,the MO indicator
lights up and goes off alternately.
When the MO indicator is lit on the display, the
sound you hear becomes monaural but the
receptionwill be improved (theST indicatorgoes
off).
Press ¢to search
stations of higher
frequencies.
Press 4to search
stations of lower
frequencies.
FM1 FM2 FM3
“SSM”appears, then disappears when automatic
preset is over.
EN06-08.KD-S811/713/711R[E]14 07/12/2000, 05:15 PM7

8
ENGLISH
Manual preset
You canpresetupto6 stations ineachband(FM1,
FM2, FM3 and AM) manually.
Ex: Storing an FM station of 88.3 MHz into the
preset number 1 of the FM1 band
1 Select the FM band (FM1 –3) you
want to store FM stations into (in
this example, FM1).
•Each time you press the button, the FM
band changes as follows:
2 Tune into a station of 88.3 MHz.
3 Press and hold the number button (in
this example, 1) for more than 2
seconds.
4 Repeat the above procedure to store
other stations into other preset
numbers.
Notes:
• Apreviously preset station is erased when a new station
is stored in the same preset number.
• Preset stations are erased when the power supply to the
memory circuit is interrupted (for example, during
battery replacement). If this occurs, preset the stations
again.
Tuning into a preset station
You can easily tune into a preset station.
Remember that you must store stations first. If you
have not stored them yet, see “Storing stations in
memory”on page 7.
1 Select the band (AM, FM1 –3).
2 Select the number (1 –6) for the preset
station you want.
Press ¢to tune in
stations of higher
frequencies.
Press 4to tune in
stations of lower
frequencies.
FM1 FM2 FM3
“P1”flashes for a few
seconds.
FM1 FM2 FM3
AM
EN06-08.KD-S811/713/711R[E]14 07/12/2000, 05:15 PM8

9
ENGLISH
RDS OPERATIONS
What you can do with RDS EON
RDS (Radio Data System) allows FM stations to
send an additional signal along with their regular
programmesignals.Forexample, the stations send
their station names, as well as information about
what type of programme they broadcast, such as
sports or music, etc.
Another advantage of RDS function is called “EON
(Enhanced Other Networks).” The EON indicator
lightsup while receiving anFMstationwiththe EON
data. By using the EON data sent from a station,
you can tune into a different station of a different
network broadcasting your favorite programme or
traffic announcement while listening to another
programme or to another source such as CD.
By receiving the RDS data, this unit can do the
following:
• Tracing the same programme automatically
(Network-Tracking Reception)
• StandbyReception ofTA(TrafficAnnouncement)
or your favorite programme
• PTY (Programme Type) search
• Programme search
• And some other functions
Tracing the same programme
automatically (Network-Tracking
Reception)
When driving in an area where FM reception is not
good, the tuner built in this unit automatically tunes
into another RDS station, broadcasting the same
programme with stronger signals. So, you can
continue to listen to the same programme in its
finest reception, no matter where you drive. (See
the illustration on the next page.)
Two types of the RDS data are used to make
Network-Tracking Reception work correctly — PI
(Programme Identification) and AF (Alternative
Frequency.)
Withoutreceiving these datacorrectlyfromthe RDS
station you are listening to, Network-Tracking
Reception will not operate.
To use Network-Tracking Reception, press and
hold TP RDS (Traffic Programme/Radio Data
System) for more than 1 second. Each time you
press and hold the button, Network-Tracking
Reception modes change as follows:
Mode 1
The AF indicator lights up but the REG indicator
does not.
Network-Tracking Reception is activated with
Regionalization set to “off.”
Switchesto another stationwithinthesame network
when the receiving signals from the current station
become weak.
•In this mode, the programme may differ from the one
currently received.
Mode 2
Both the AF indicator and the REG indicator light
up.
Network-Tracking Reception is activated with
Regionalization set to “on.”
Switches to another station, within the same
network, broadcasting the same programme when
the receiving signals from the current station
become weak.
Mode 3
Neitherthe AF indicator northeREGindicatorlights
up.
Network-Tracking Reception is deactivated.
Mode 1 Mode 2 Mode 3
REG indicator
AF indicator
EN09-13.KD-S811/713/711R[E]14 07/12/2000, 05:14 PM9

10
ENGLISH
The same programme can be received on
different frequencies. To deactivate the TA standby mode, press TP
RDS again.
PTY Standby Reception
When you press PTY while listening to
an FM station, the PTY indicator is lit
during reception of a PTY stationand the
PTY standby mode is engaged. The
selected PTY name stored on page 11
flashes for 5 seconds.
•When the station being received is not a PTY station,
the PTY indicator flashes. Press ¢or 4
toengagethePTYstandbymode. “SEARCH” appears
on the display, and PTY station search starts. When a
PTY station is tuned in, the PTY indicator is lit.
7If you are listening to a CD and wish to listen to a
selected PTY broadcast, press PTY to enter the
PTYstandbymode.(The PTY indicatorlightsup.)
IftheselectedPTYprogrammestarts broadcasting
whilethe PTY standby mode isactive,the selected
PTY name appears and the playback source
changes to the FM band. The selected PTY
programme can then be heard.
To deactivate the PTY standby mode, press PTY
again.
Selecting your favorite programme for
PTY Standby Reception
You can select your favorite programme for PTY
Standby Reception to store in memory.
When shipped from the factory, “NEWS”is stored
asthe programmetype forPTYStandbyReception.
1 Press and hold SEL (select) for more
than 2 seconds so that one of the PSM
items appears on the display.
(PSM: see page 20.)
Using Standby Reception
Standby Reception allows the unit to switch
temporarily to your favorite programme (PTY:
Programme Type) and Traffic Announcement (TA)
from the current source (another FM station and
CD)
•Standby Reception will not work if you are listening
to an AM station.
TA Standby Reception
When you pressTP RDS while listening
to an FM station, the TP indicator is lit
during reception of a TP (Traffic
Programme) station and theTA standby
mode is engaged.
•When the station being received is not a TP station,
the TP indicator flashes. Press ¢or 4
to engage the TA standby mode. “SEARCH”appears
on the display, and TP station search starts. When a
TP station is tuned in, the TP indicator is lit.
7If you are listening to a CD and wish to listen to a
TPstation,pressTP RDS to enter theTAstandby
mode. (The TP indicator lights up.)
Ifa trafficprogrammestarts broadcastingwhile the
TAstandbymode is active,“TRAFFIC”appearsand
the playback source changes to the FM band.The
volumeincreasesto the presetTAvolumelevel(see
page 13) and the traffic programme can be heard.
Programme 1
broadcasting
on frequency C Programme 1
broadcasting
on frequency D
Programme 1
broadcasting
on frequency B
Programme 1
broadcasting
on frequency E
Programme 1
broadcasting
on frequency A
EN09-13.KD-S811/713/711R[E]14 07/12/2000, 05:14 PM10

11
ENGLISH
Searching your favorite programme
You can search one of your 6 favorite programme
types stored in memory. When shipped from the
factory,thefollowing 6 programmetypes have been
stored in the number buttons (1 to 6).
To store your favorite programme types,
see below.
To search your favorite programme type, see
page 12.
To store your favorite programme types
1 Press and hold SEL (select) for more
than 2 seconds so that one of the PSM
items appears on the display.
(PSM: see page 20.)
2 Select “PTY STBY” (standby) if not
shown on the display.
3 Select one of twenty-nine PTY codes.
Selectedcodename appears
on the display and is stored
into memory.
•For details, see the table
below.
4 Finish the setting.
PTY codes
NEWS: News
AFFAIRS: Topical programmes expanding
on current news or affairs
INFO: Programmes which impart
advice on a wide variety of
topics
SPORT: Sport events
EDUCATE: Educational programmes
DRAMA: Radio plays
CULTURE: Programmes on national or
regional culture
SCIENCE: Programmes on natural science
and technology
VARIED: Other programmes like comedies
or ceremonies
POP M: Pop music
ROCK M: Rock music
EASY M: Easy-listening music
LIGHT M: Light music
CLASSICS: Classical music
OTHER M: Other music
WEATHER: Weather information
FINANCE: Reports on commerce, trading,
the Stock Market, etc.
CHILDREN: Entertainment programmes for
children
SOCIAL: Programmes on social
activities
RELIGION: Programmes dealing with any
aspect of belief or faith, or the
nature of existence or ethics
PHONE IN: Programmes where people can
express their views either by
phone or in a public forum
TRAVEL: Programmes about travel
destinations, package tours,
and travel ideas and
opportunities
LEISURE: Programmes concerned with
recreational activities such as
gardening, cooking, fishing,
etc.
JAZZ: Jazz music
COUNTRY: Country music
NATION M: Current popular music from
another nation or region, in that
country’s language
OLDIES: Classic pop music
FOLK M: Folk music
DOCUMENT: Programmes dealing with
factual matters, presented in
an investigative style
POP M
123
ROCK M EASY M
456
CLASSICS AFFAIRS VARIED
CONTINUED ON THE NEXT PAGE
EN09-13.KD-S811/713/711R[E]14 07/12/2000, 05:14 PM11

12
ENGLISH
2 Select “PTY SRCH”(search) if not
shown on the display.
3 Select one of twenty-nine PTY codes.
(See page 11.)Selected codenameappears
on the display.
•If the code already stored
in memory is selected, it
will flash on the display.
4 Press and hold the number button
for more than 2 seconds to store the
PTY code selected into the preset
number you want.
The selected code name will flash on
the display.
5 Finish the setting.
To search your favorite programme type
1 Press and hold PTY (programme type)
for more than 1 second while listening
to an FM station.
The last selected PTY code appears.
2 Select one of PTY codes stored in
preset number buttons (1 to 6).
PTYsearchfor your favorite programme starts
after 5 seconds.
•If there is a station broadcasting a programme of
the same PTY code you selected, that station is
tuned in.
•If there is no station broadcasting a programme
of the same PTY code you selected, the station
will not change.
Note:
In some areas, the PTY search will not work correctly.
OtherconvenientRDSfunctions
and adjustments
Automatic selection of the station
when using the number buttons
Usually when you press the number button, the
preset station is tuned in.
However,when the presetstationisanRDS station,
something different will happen. If the signals from
that preset station are not sufficient for good
reception, this unit, using the AF data, tunes in
another frequency broadcasting the same
programme as the original preset station is
broadcasting. (Programme search)
Ex.When “ROCK M”is stored in preset number
button 2
EN09-13.KD-S811/713/711R[E]14 07/12/2000, 05:14 PM12

13
ENGLISH
Toactivateprogrammesearch,followthe procedure
below.
•Programme search takes a while.
•See also “Changing the general settings (PSM)”
on page 19.
1Press and hold SEL (select) for more than 2
seconds so that one of the PSM items appears
on the display.
2Press ¢or 4to select
“P(Programme)-SEARCH.”
3Rotate the control dial clockwise to select “ON.”
Now programme search is activated.
To cancel programme search, repeat the same
procedure and select“OFF”in step 3 by rotating the
control dial counterclockwise.
Changing the display mode while
listening to an FM station
You can change the initial indication on the display
to station name (PS NAME), station frequency
(FREQ) or Clock time (CLOCK) while listening to
an FM RDS station.
•See also “Changing the general settings (PSM)”
on page 19.
1Press and hold SEL (select) for more than 2
seconds so that one of the PSM items appears
on the display.
2Press ¢or 4to select “DISPMODE”
(display mode).
3Rotate the control dial to set to the desired
indication (“PS NAME”, “FREQ”or "CLOCK").
Note:
By pressing DISP, you can also change the display while
listening to an FM RDS station.
Eachtimeyoupress the button, the following information
appears on the display:
•Then, the display goes back to the original indication
in several seconds.
Setting the TA volume level
You can preset the volume level for TA Standby
Reception.When a traffic programme is received,
thevolumelevelautomatically changestothe preset
level.
•See also “Changing the general settings (PSM)”
on page 19.
1Press and hold SEL (select) for more than 2
seconds so that one of the PSM items appears
on the display.
2Press ¢or 4to select “TA VOL.”
3Rotate the control dial to set to the desired
volume.
You can set it from “VOL 00”to “VOL 50.”
Automatic clock adjustment
When shipped from the factory, the clock built in
this unit is set to be readjusted automatically using
the CT (ClockTime) data in the RDS signal.
If you do not want to use automatic clock
adjustment, follow the procedure below.
•See also “Changing the general settings (PSM)”
on page 19.
1Press and hold SEL (select) for more than 2
seconds so that one of the PSM items appears
on the display.
2Press ¢or 4to select “AUTO ADJ.”
3Rotatethecontrol dial counterclockwisetoselect
“OFF.”
Now automatic clock adjustment is canceled.
To reactivate clock adjustment, repeat the same
procedure and select“ON”in step 3 by rotating the
control dial clockwise.
Note:
It takes about 2 minutes to adjust the time using the CT
data. So, you should not change the station for more
than 2 minutes continuously; otherwise, the clock time
will not be adjusted.
Station name
(PS NAME) Station frequency
(FREQ)
Programme type
(PTY)
CLOCK
(Clock time)
EN09-13.KD-S811/713/711R[E]14 07/12/2000, 05:14 PM13

14
ENGLISH
CD OPERATIONS
To stop play and eject the CD
Press 0.
CDplay stops and the CD automatically ejects from
the loading slot.
If you change the source to FM or AM, the CD play
also stops (without ejecting the CD this time).
Notes:
• If the ejected disc is not removed for about 15 seconds,
the disc is automatically inserted again into the
loading slot to protect it from dust. (CD play will not
start this time.)
• You can eject the CD even when the unit is turned off.
Playing a CD
1 Insert a disc into the loading slot.
The unit turns on,
draws a CD and starts
playback automatically.
Note:
• When a CD is inserted
upside down, the CD
automatically ejects.
The CD IN indicator lights up.
Total playing time of
the inserted disc Total track number of the inserted disc
Note on One-Touch Operation:
When a CD is already in the loading slot, pressing CD
turns on the unit and starts playback automatically.
Elapsed playing
time Current track
EN14-16.KD-S811/713/711R[E]15 07/12/2000, 05:13 PM14

15
ENGLISH
Selecting CD playback modes
Toplaybacktracksatrandom(RandomPlay)
You can play back all tracks on the CD at random.
Each time you press MO RND (monaural/random)
while playing a CD, CD random play mode turns
on and off alternately.
When the random mode is turned on, the RND
indicator lights up on the display and a track
randomly selected starts playing.
Locating a track or a particular
portion on a CD
To fast-forward or reverse the track
To go to the next tracks or the previous
tracks
To go to a particular track directly
Press the number button corresponding to the
track number to start its playback.
• To select a track number from 1 – 6:
Press 1 (7) – 6 (12) briefly.
• To select a track number from 7 – 12:
Press and hold 1 (7) – 6 (12) for more than 1
second.
Press and hold ¢, while
playing a CD, to fast-forward the
track.
Press and hold 4, while
playing a CD, to reverse the
track.
Press ¢briefly, while
playing a CD, to go ahead to the
beginning of the next track. Each
time you press the button
consecutively, the beginning of
the next tracks is located and
played back.
Press 4briefly, while
playing a CD, to go back to the
beginning of the current track.
Each time you press the button
consecutively, the beginning of
the previous tracks is located
and played back.
The RND indicator
EN14-16.KD-S811/713/711R[E]15 07/12/2000, 05:13 PM15

16
ENGLISH
Prohibiting CD ejection
You can prohibit CD ejection and can lock a CD in
the loading slot.
Press and hold CD and 0for more than 2
seconds.
“EJECT”flashes on the display for about 5
seconds, and the CD is locked and cannot be
ejected.
To cancel the prohibition and unlock the CD,
press and hold CD and 0again for more than 2
seconds, while pressing CD. “EJECT”appears on
thedisplay,and the CD ejects from the loading slot.
EN14-16.KD-S811/713/711R[E]15 07/12/2000, 05:13 PM16

17
ENGLISH
2 Adjust the level.
Note:
Normally the control dial works for volume
adjustment. So you do not have to select “VOL” to
adjust the volume level.
Using the Sound Control
Memory (SCM)
You can select andstoreapresetsoundadjustment
suitable for each playback source.
(Advanced SCM)
Selecting and storing the sound modes
Once you select a sound mode, it is stored in
memory. It will be recalled every time you select
the same source and will be shown on the display.
A sound mode can be stored for each of the
following sources — FM1, FM2, FM3, AM and CD.
• If you do not want to store the sound mode
separately for each playback source, but want to
use the same sound mode for all the sources,
see “To cancel Advanced SCM” on page 21.
Select the sound mode you want.
Each time you press the button, the
sound mode changes as follows:
SOUND ADJUSTMENTS
FAD
BAL
VOL
BAS TRE
(volume)
LOUD
(loudness)
(bass) (treble) (fader)
(balance)
Adjusting the sound
You can adjust the sound characteristics to your
preference.
1 Select the item you want to adjust.
Eachtime youpressthebutton,the
adjustable items change as
follows:
Indication To do: Range
BAS Adjust the bass. –06 (min.)
|
+06 (max.)
TRE Adjust the treble. –06 (min.)
|
+06 (max.)
FAD* Adjust the front R06 (Rear only)
and rear speaker |
balance. F06 (Front only)
BAL Adjust the left L06 (Left only)
and right speaker |
balance. R06 (Right only)
LOUD Boost low and high
frequencies to LOUD ON
produce a well- |
balanced sound LOUD OFF
at low volume
level.
VOL Adjust the volume. 00 (min.)
|
50 (max.)
*If you are using a two-speaker system, set the fader
level to “00.”
Equalization pattern changes as you adjust
the bass or treble.
To increase the level.
To decrease the level.
BEAT SOFT POP SCM OFF
EN17-18.KD-S811.713.711R[E]16 07/12/2000, 05:18 PM17

18
ENGLISH
•When “SCM LINK”is set to “LINK ON”, the
selected sound mode can be stored in memory
for the current source and the effect applies only
to the current source.Each time you change the
playback source, the SCM indicator flashes on
the display.
•When “SCM LINK”is set to “LINK OFF”, the
selectedsound modeeffect appliestoanysource.
Indication For: Preset values
BAS TRE LOUD
BEAT Rock or disco +02 00 ON
music
SOFT Quiet +01 –03 OFF
background
music
POP Light music +04 +01 OFF
SCM OFF (Flat sound) 00 00 ON
Storing your own sound
adjustments
You can adjust the sound modes (BEAT, SOFT,
POP) to your preference and store your own
adjustments in memory.
•There is a time limit in doing the following
procedure. If the setting is canceled before you
finish, start from step 1 again.
1 Call up the sound mode you want to
adjust.
•See the left column for details.
2 Select “BAS (Bass),” “TRE (Treble)”
or “LOUD (Loudness).”
3 Adjust the bass or treble level or turn
the loudness function ON/OFF.
•See page 17 for details.
4 Repeat steps 2 and 3 to adjust the
other items.
5 Press and hold SCM until the sound
mode you have selected in step 1
flashes on the display.
Your adjustment made for the selected
sound mode is stored in memory.
6 Repeat the same procedure to store
other sound modes.
To reset to the factory settings
Repeat the same procedure and reassign the
preset values listed in the table on the left
column.
Recalling the sound modes
When “SCM LINK”is set to “LINK ON,”
Select the source.
The sound mode stored in memory for the
selected source is recalled.
Notes:
•You can adjust each sound mode to your preference,
and store it in memory.
If you want to adjust and store your original sound
mode, see “Storing your own sound adjustments”on
the right column.
•To adjust the bass and treble reinforcement levels or
to turn on/off the loudness function temporarily, see
page 17. (Your adjustments will be canceled if another
source is selected.)
EN17-18.KD-S811.713.711R[E]16 07/12/2000, 05:18 PM18

19
ENGLISH
Setting the clock
You can also set the clock system either 24 hours
or 12 hours.
1 Press and hold SEL (select) for more
than 2 seconds so that one of the PSM
items appears on the display.
(See page 20.)
2 Set the hour.
1Select “CLOCK H” if not shown on the
display.
2Adjust the hour.
3 Set the minute.
1Select “CLOCK M.”
2Adjust the minute.
4 Set the clock system.
1Select “24H/12H.”
2Select “24H” or “12H.”
5 Finish the setting.
Tocheckthe current clock time while theunit
is turned off, press DISP (display).
The power turns on, the clock time is shown for
5 seconds, then the power turns off.
Changing the general settings
(PSM)
You can change the items listed on the next page
byusingthePSM(PreferredSettingMode)control.
Basic Procedure
1 Press and hold SEL (select) for more
than 2 seconds so that one of the PSM
items appears on the display.
(See page 20.)
2 Select the PSM item you want to
adjust. (See page 20.)
3 Adjust the PSM item selected above.
4 Repeat steps 2 and 3 to adjust the
other PSM items if necessary.
5 Finish the setting.
OTHER MAIN FUNCTIONS
2
1
12
12
EN19-22.KD-S811/713/711R[E]-1 07/12/2000, 05:17 PM19

20
ENGLISH
Preferred Setting Mode (PSM) items
LINK ON
0:00
24H
24H
12H
ON
OFF
LINK OFF
19
18, 21
19
13
LINK ON
Back Advance
AdvanceBack
ON
See
page
Factory-
preset
settings
Hold. Select.
2
13
Clockwise
Set.
Counter-
clockwise
OFF ON
VOL 00 –VOL 50
AUDIO 2
OFF
MUTING 1 MUTING 2
29 programme types
(see page 11.)
13
13
OFF
VOL 20
21
OFF
AUDIO 2
21
CLOCK H Hour adjustment
CLOCK M Minute adjustment
SCM LINK Sound control
memory linkage
24H/12H 24/12-hour time
display
AUTO ADJ Automatic clock
setting
DISPMODE Display mode
PTY STBY PTY standby
PTY SRCH PTY search
TA VOL Traffic announcement
volume
P-SEARCH Programme search
LEVEL Level display
TEL Telephone muting
OFF
AUDIO 1
CLOCK
FREQ
PS NAME
(See page 11.)
11
NEWS 11
13
PS NAME
•Press SEL (select) to finish the setting.
EN19-22.KD-S811/713/711R[E]-1 07/12/2000, 05:17 PM20
