JVC KD SH1000 - Radio / CD User manual

ENGLISH
INDONESIA
CD RECEIVER KD-SH1000
ALAT PENERIMA CD KD-SH1000
For canceling the display demonstration, see page 8.
Untuk membatalkan tampilan demonstrasi, lihat halaman 8.
For installation and connections, refer to the separate manual.
Untuk instalasi dan penyambungan, lihat buku pedoman terpisah.
INSTRUCTIONS
BUKU PETUNJUK
GET0365-004A
[UN]
Cover_SH1000U_004A_f.indd 2Cover_SH1000U_004A_f.indd 2 1/16/06 12:48:49 PM1/16/06 12:48:49 PM

2
ENGLISH
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to
obtain the best possible performance from the unit.
IMPORTANT FOR LASER PRODUCTS
1. CLA 1 LA ER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave
all servicing to qualified service personnel.
3. CAUTION: Visible and invisible laser radiation when open and interlock failed or defeated.
Avoid direct exposure to beam.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUT IDE THE UNIT.
Warning:
If you need to operate the unit while driving,
be sure to look ahead carefully or you may be
involved in a traffic accident.
Caution on volume setting:
Discs produce very little noise compared
with other sources. Lower the volume
before playing a disc to avoid damaging
the speakers by the sudden increase of the
output level.
Noti e:
The display window built in this unit has
been produced with high precision, but
it may have some ineffective dots. This is
inevitable and is not malfunction.
How to reset your unit
• Your preset adjustments will also be erased.
How to for ibly eje t a dis
• If an D card is inserted, eject the D card
first (see page 11).
1
2
• If this does not work, reset your unit.
• Be careful not to drop the disc when it ejects.
EN02-09_SH1000U_001A_3.indd 2EN02-09_SH1000U_001A_3.indd 2 1/12/06 4:04:21 PM1/12/06 4:04:21 PM

ENGLISH
3
How to read this manual
• Button operations are mainly explained with
the illustrations in the table below.
• Some related tips and notes are explained in
“More about this unit” (see pages 27 – 1).
Press briefly.
Press repeatedly.
Press either
one.
Press A, then
B.
Press and hold until your
desired response begins.
Press and hold both
buttons at the same time.
The following marks are used to indicate...
: Built-in CD player operations.
: External CD changer operations.
: SD player operations.
: External USB memory operations.
For safety...
• Do not raise the volume level too much, as
this will block outside sounds, making driving
dangerous.
• Stop the car before performing any
complicated operations.
Temperature inside the car...
If you have parked the car for a long time in hot
or cold weather, wait until the temperature in
the car becomes normal before operating the
unit.
CONTENTS
Control panel ................................... 5
Remote controller — RM-RK3 ............ 6
Getting started ................................. 7
Basic operations ............................................... 7
Radio operations .............................. 8
Disc/SD card/USB memory
operations .................................... 11
Playing a disc in the unit .................................. 11
Playing discs in the CD changer ........................ 11
Playing from an SD card .................................... 11
Playing from a USB memory ............................. 12
Sound adjustments ........................... 15
Selecting the DSP modes (DSP) ........................ 1
Using the equalizer—EQ ................................. 16
Activating crossover network ........................... 18
Setting the sound modes—SEL ...................... 18
General settings — PSM ................... 2
Title assignment .............................. 23
iPod®/D. player operations ................ 24
Other external component operations ... 26
Maintenance .................................... 26
More about this unit ......................... 27
Troubleshooting ............................... 32
Specifications ................................... 36
EN02-09_SH1000U_001A_3.indd 3EN02-09_SH1000U_001A_3.indd 3 1/16/06 4:56:06 PM1/16/06 4:56:06 PM

4
ENGLISH
How to enter the various menus
The main menu contains seven menus (MODE,
P M, EL, TITLE, BBE, EQ, D P).
• If no operation is done for about 5 seconds,
menu screen is canceled.
1
2 Select a menu you want.
3 Enter the selected menu.
• To go back to the previous screen or
exit the MENU screen, press BACK
repeatedly.
4 Operate as instructed on the screen.
• To go back to the MENU screen, press
MENU.
How to deta h/atta h the ontrol
panel
How to hange the ontrol panel
angle
When using the remote controller
Caution:
Detaching...
Attaching...
Time countdown indicator
EN02-09_SH1000U_001A_2.indd 4EN02-09_SH1000U_001A_2.indd 4 1/6/06 3:00:20 PM1/6/06 3:00:20 PM

ENGLISH
5
How to hange the display information and patterns
1 BAND button
2 OURCE button
3 • Control dial
• POWER/ATT (attenuator)/ENTER
button
4 MENU button
5 5 (up) / ∞ (down) buttons
6 Display window
7 DI P (display) button
8 U B (Universal erial Bus) input terminal
Parts identifi ation
Control panel
9 (angle) button
p 0 (eject) button
q 4 /¢ buttons
w Remote sensor
DO NOT e pose the remote sensor to strong
light (direct sunlight or artificial lighting).
e BACK button
r Reset button
t (control panel release) button
Source operation display Clock time display
Small graphic displayLarge graphic display (full display size)
Ex.: When tuner is selected as the source
EN02-09_SH1000U_001A_2.indd 5EN02-09_SH1000U_001A_2.indd 5 1/6/06 3:00:21 PM1/6/06 3:00:21 PM

6
ENGLISH
Remote controller — RM-RK300
Installing the lithium oin battery
(CR2025)
Aim the remote controller directly at the
remote sensor on the unit. Make sure there is
no obstacle in between.
Warning:
• Do not install any battery other than
CR2025 or its equivalent; otherwise, it may
explode.
• tore the battery in a place where children
cannot reach to avoid risk of accident.
• To prevent the battery from over-heating,
cracking, or starting a fire:
– Do not recharge, short, disassemble, heat
the battery, or dispose of it in a fire.
– Do not leave the battery with other
metallic materials.
– Do not poke the battery with tweezers or
similar tools.
– Wrap the battery with tape and insulate
when throwing away or saving it.
Caution:
Main elements and features
1 (standby/on/attenuator) button
• Turns the power on if pressed briefly or
attenuates the sound when the power is
on.
• Turns the power off if pressed and held.
2 SO RCE button
elects the source.
EN02-09_SH1000U_001A_2.indd 6EN02-09_SH1000U_001A_2.indd 6 1/6/06 3:00:22 PM1/6/06 3:00:22 PM

ENGLISH
7
Continued on the next page
3 5 (up) / ∞ (down) buttons
• For FM/AM: Changes the preset stations.
• For MP3/WMA/SD/USB: Changes the
folders.
• While listening to an Apple iPod or a
JVC D. player:
– Pauses/stops or resumes playback with
∞.
– Enters the main menu with 5.
(Now 5/∞/4/¢ work as the menu
selecting buttons. *
4 VOL (volume) + / – buttons
Adjusts the volume level.
5 Number buttons
• For FM/AM: Selects the preset station if
pressed, or store a station if pressed and
held.
• For CD/CD Text: Selects the tracks.
• For MP3/WMA/SD/USB: Selects the
folders.
• For CD changer: Selects the discs.
6 ANGLE button
Adjusts the control panel angle.
7 BAND button
Selects the band.
8 4 / ¢ buttons
• For FM/AM: Searches for stations if
pressed, or skips frequencies after pressed
and held.
• For CD/CD Text/MP3/WMA/SD/USB:
Changes the tracks if pressed, or fast-
forwards or reverses the track if pressed
and held.
• While listening to an iPod or a D. player
(in menu selecting mode):
– Selects an item if pressed briefly. (Then,
press ∞ to confirm the selection.
– Skips 10 items at a time if pressed and
held.
* 5 : Returns to the previous menu.
∞ : Confirms the selection.
Getting started
Activates or deactivates crossover network
(see page 18 before turning on the power.
Basic operations
~ Turn on the power.
Ÿ
FM/AM = CD* = SD* = USB* =
CD-CH*/iPod*/D. player* (or EXT-IN
= LINE-IN = (back to the beginning
* You cannot select these sources if they
are not ready or not connected.
! For FM/AM tuner
⁄ Adjust the volume.
@ Adjust the sound as you want. (See
pages 15 – 19.)
EN02-09_SH1000U_001A_2.indd 7EN02-09_SH1000U_001A_2.indd 7 1/6/06 7:35:40 PM1/6/06 7:35:40 PM

8
ENGLISH
To drop the volume in a
moment (ATT)
To restore the sound, press
it again.
To turn off the power
Basic settings
• See also “General settings — PSM” on pages
20 – 22.
1 Enter the PSM menu (see page 4).
2
1 Canceling the display
demonstrations
Select “De o,” then “Off.”
2 Setting the clock
Select “Clock H” (hour), then adjust the
hour.
Select “Clock M” ( inute), then adjust
the inute.
Select “24H/12H,” then “24Hours” or
“12Hours.”
3 Finish the procedure.
To check the current clock time while the
power is turned off
Radio operations
~
Ÿ
! Start searching for a station.
When a station is received, searching
stops.
To stop searching press the sa e button
again.
To tune in to a station manually
In step ! above...
1
2 Select a desired station frequency.
When an FM stereo broadcast is hard
to receive
1 Enter the MODE menu (see page 4).
2
3
Selected band appears.
EN02-09_SH1000U_001A_3.indd 8EN02-09_SH1000U_001A_3.indd 8 1/16/06 4:58:43 PM1/16/06 4:58:43 PM

ENGLISH
9
4 MO indicator lights up.
Reception i proves, but stereo
effect will be lost.
To restore the stereo effect repeat the sa e
procedure and select “Off” in step 3. The MO
indicator goes off.
Tuning in to FM stations with strong
signals only LO (local)/DX (Distance-
Extreme)
1 Enter the MODE menu (see page 4).
2
3
4
DX indicator goes off and LO indicator
lights up.
Only stations with sufficient signal strength
will be detected.
To tune in to all receivable stations repeat the
sa e procedure and select “DX” in step 3. The
LO indicator goes off and DX indicator lights
up.
Storing stations in memory
You can preset six stations for each band.
FM station automatic presetting
SSM (Strong-station Sequential
Memory)
1 Select the FM band (FM1 – FM3) you
want to store into.
2 Enter the MODE menu (see page 4).
3
4
Local FM stations with the strongest signals are
searched and stored auto atically in the FM
band.
Manual presetting
Ex.: Storing FM station of 92.5 MHz into preset
nu ber 4 of the FM1 band.
1
2
3 Enter the MODE menu (see page 4).
• If you hold down 5/∞, the Preset Station
List appears (go to step 6).
Continued on the next page
EN02-09_SH1000U_001A_3.indd 9EN02-09_SH1000U_001A_3.indd 9 1/16/06 4:58:45 PM1/16/06 4:58:45 PM

10
ENGLISH
4
5
6 Select a preset number.
• You can move to the lists of the other FM
bands by turning the control dial.
7 Store the station.
When using the remote controller
After tuning in to a station you want to
preset...
Listening to a preset station
1
2
When using the remote controller
Directly select the preset number.
EN10-15_SH1000U_001A_f.indd 10EN10-15_SH1000U_001A_f.indd 10 1/23/06 10:13:17 AM1/23/06 10:13:17 AM

11
ENGLISH
Disc/SD card/USB memory
operations
Playing a disc in the unit
All tracks will be played repeatedly until you
change the source or eject the disc.
To stop play and eject the disc
Note:
f a USB memory is attached to the unit, you
cannot eject the disc. “Please Eject USB”
flashes on the display. f this happens, detach
the USB memory, then, press 0 button
again.
Playing discs in the CD changer
All discs in the magazine will be played
repeatedly until you change the source.
• Ejecting the magazine will also stop playback.
* If you have changed the external input setting
to “Ext In” (see page 21), you cannot select the
CD changer
Playing from an SD card
Before detaching the control panel, turn off the
power.
~
Ÿ
Press in the SD card until you hear a
clicking sound.
To eject the SD card press the SD card
again.
• Press the SD card softly (do not release
your finger quickly); otherwise, the SD
card may pop out from the unit.
SD loading slot
SD card
Continued on the next page
EN10-15_SH1000U_001A_2.indd 11EN10-15_SH1000U_001A_2.indd 11 1/6/06 2:59:08 PM1/6/06 2:59:08 PM

12
ENGLISH
! Attach the control panel.
⁄ • The control panel goes
back to the previous
position.
Playback starts automatically if tracks are
recorded.
Playing from a USB memory
This unit can play MP3/WMA tracks stored in a
USB memory.
All tracks in the USB memory will be played
repeatedly until you change the source.
• Removing the USB memory will also stop
playback.
~
Ÿ
To detach the USB memory straightly pull it
out from the unit.
USB memory
USB input terminal
Cautions:
• Avoid using the SD card/USB memory
when it might hinder your safety driving.
• Make sure all important data have been
backed up to avoid losing the data.
If an SD card or USB memory has been
attached...
Playback starts from where it has been stopped
previously.
• f a different SD card or USB memory is
currently attached, playback starts from the
beginning.
About P3 and W A tracks
MP3 and WMA “tracks” (words “file” and
“track” are used interchangeably) are recorded
in “folders.”
About the CD changer
t is recommended to use a JVC
MP3-compatible CD changer with your unit.
• You can also connect MP3-incompatible
CD changers. However, these units are not
compatible with MP3 discs.
• You cannot use the CH-X99, CH-X100, and
KD-MK series CD changers with this unit.
• You cannot play any WMA disc in the CD
changer.
• Disc text information recorded in the CD
Text can be displayed when a JVC CD Text
compatible CD changer is connected.
• For connection, see nstallation/Connection
Manual (separate volume).
To fast-forward or reverse the track
EN10-15_SH1000U_001A_2.indd 12EN10-15_SH1000U_001A_2.indd 12 1/6/06 2:59:09 PM1/6/06 2:59:09 PM

13
ENGLISH
To go to the next or previous tracks
To go to the next or previous folders (only for
MP3/WMA/SD/ SB)
For MP3 tracks:
For WMA tracks:
• Holding the buttons can display the Disc List
( and Folder List ( / /
, see the following.
Other main functions
Selecting a disc/folder/track on the list
• This function is not available for an audio CD
or a CD Text when the source is “CD.”
1 Enter the MODE menu (see page 4).
2
3 Select a list type.
*1 Selectable only when the source is
“CD-CH.”
*2 Appears only for MP3/ MA/SD/USB.
4 Confirm the selection.
The selected list appears on the display.
• You can move to the other list by turning
the control dial.
5 Select a disc/folder/file from the list.
Only for MP3/WMA/SD/USB:
If you select the current disc/folder
(highlighted on the screen , its Folder/File
List appears.
6 Starts playbac .
When using the remote controller
• To directly select a disc (
• To directly select a track of an audio CD or
a CD Text (
• To directly select an MP3/WMA folder
( / /
To select a number from 1 – 6:
To select a number from 7 (1 – 12 (6 :
For MP3/WMA folders:
It is required that folders are assigned with
2-digit numbers at the beginning of their
folder names—01, 02, 03, and so on.
Current folder
Ex.: When “Folder” is selected on step 3
EN10-15_SH1000U_001A_2.indd 13EN10-15_SH1000U_001A_2.indd 13 1/6/06 7:37:28 PM1/6/06 7:37:28 PM

14
ENGLISH
Prohibiting disc ejection
You can lock a disc in the loading slot.
1
2 After making sure “No Eject?” is
selected...
• “No Eject” flashes, and the
disc cannot be ejected.
To cancel the prohibition, repeat the same
procedure after making sure “Eject OK ” is
selected.
• “Eject OK” flashes on the display.
Selecting the playback modes
You can use only one of the following playback
modes at a time.
1 Enter the M DE menu (see page 4).
2 Select one of the playback modes.
3 Select one of the items (see the
following table).
4 Finish the procedure.
Intro Plays the beginning 15 seconds of...
Track : All tracks of the current playback
media. [ ]
Folder*1 : First track of all folders of the
current playback media. [ ]
Disc*2 : First track of all the inserted discs.
[ ]
Off : Cancels.
Repeat Plays repeatedly
Track : The current track. [ ]
Folder*1 : All tracks of the current folder.
[ ]
Disc*2 : All tracks of the inserted discs.
[ ]
Off : Cancels.
Random Plays at random
Folder*1 : All tracks of the current folder, then
tracks of the next folder and so on.
[ ]
Disc : All tracks of the current disc.
[ ]
All*3 : All tracks of the inserted discs/
media. [ ]
Off : Cancels.
*1 Only while playing a media (MP3/WMA/SD/
USB).
*2 Only when the sou ce is CD-CH.
*3 Only when the sou ce is CD-CH, SD, o USB.
EN10-15_SH1000U_001A_3.indd 14EN10-15_SH1000U_001A_3.indd 14 1/16/06 4:59:58 PM1/16/06 4:59:58 PM

15
ENGLISH
To make more precise settings, see the
following.
To cancel the acoustic effect, select “Defeat” in
step Ÿ.
Precise settings for the DSP modes
1 Select a DSP mode.
2 Select the number of the built-in
speakers.
• For “Defeat” and “V.Cancel,” the speaker
number is fixed to “4ch.”
3 Select your listening seat position.
4 Select the speaker to be adjusted.
* Appea s only when “4ch” is selected in step
2.
Sound adjustments
Selecting the DSP modes (DSP)
You can create a more acoustic sound field such
as in a theater, hall, etc.
• When crossover network (see page 18) is
activated, the DSP mode is fixed to “Defeat.”
DSP modes
Defeat (No acoustic effect is applied), Theater, Hall,
Club, Dome, Studio, V.Cancel (Voice Cancel: Reduces the
ocal sounds. Good for mastering your fa orite songs—
Karaoke.)
~ Enter the DSP menu (see page 4).
Ÿ Select one of the DSP modes.
• To finish the procedure
• To adjust the effect level
For “Defeat” and “V.Cancel,” the effect
level is not adjustable.
! Adjust the effect level.
• To finish the procedure
Go to step !.
Continued on the next page
EN10-15_SH1000U_001A_3.indd 15EN10-15_SH1000U_001A_3.indd 15 1/16/06 5:00:01 PM1/16/06 5:00:01 PM

16
ENGLISH
3 Finish the procedure.
Using the equalizer—EQ
You can adjust the sound equalization patterns
to your preference by using either Graphic EQ
or Parametric EQ.
• Adjust the equalizer to match the
reproducible frequency range of the
connected spea ers; otherwise, the
adjustments may not be effective.
Selecting preset sound modes—
Graphic EQ
Sound modes
Flat (No sound mode is applied), HardRock, R&B
(Rhythm&Blues), Pop, Jazz, Dance, ountry, Reggae,
lassic, User 1, User 2, User 3
1 Enter the EQ menu (see page 4).
2
3 Select a sound mode.
4 Finish the procedure.
5 Select the distance between the
selected speaker and the seat.
Once you have set the distance, it is
memorized for each seat position selected
in step 3. The memorized setting is recalled
next time you select the seat position.
To change the measuring unit
6 Repeat steps 4 and 5 to adjust the
distance or the other speakers.
7 Finish the procedure.
Activating BBE Digital
BBE Digital is a digital processing method to
restore the brilliance and clarity of the original
live sound in recording, broadcasts, etc. When
a spea er reproduces sound, it introduces
frequency-dependent phase shifting, causing
high-frequency sounds to ta e longer to reach
the ear than low frequency sounds.
BBE Digital adjusts the phase relationship
between the low, mid, and high frequencies by
adding a progressively longer delay time to the
low and mid frequencies, so that all frequencies
reach the listener’s ears at the proper time. A
more brilliance and clearer sound is heard.
1 Enter the BBE menu (see page 4).
2 Select the e ect level.
EN16-21_SH1000U_001A_3.indd 16EN16-21_SH1000U_001A_3.indd 16 1/16/06 5:17:52 PM1/16/06 5:17:52 PM

17
ENGLISH
3 Select a band.
Band1 : 20.0 Hz – 1.2 Hz
Band2 : 80.0 Hz – 5.0 Hz
Band : 315.0 Hz – 20 Hz
4 Adjust the enhanced level or the
selected band.
5 Select the requency.
• Band 1/2/3 are required to be preset at
least 5 steps (frequencies) away from each
other. (Only selectable frequencies are
shown on the display.)
6 Select the band width (Q).
• To adjust the other bands, press BACK.
Then repeat steps 3 to 6.
7 Finish the procedure.
Once you have made adjustments, it is
memorized. The memorized setting is recalled
next time you select Parametric EQ.
Storing your own sound modes
1 Select a sound mode.
2 Select a requency band.
3 Adjust the enhanced level or the
selected requency band.
4 Repeat steps 2 and 3 to adjust the
other requency bands.
5
6 Select one o the user modes.
7 Store the adjustments.
Adjusting Parametric EQ
1 Enter the EQ menu (see page 4).
2
EN16-21_SH1000U_001A_3.indd 17EN16-21_SH1000U_001A_3.indd 17 1/16/06 5:17:54 PM1/16/06 5:17:54 PM

18
ENGLISH
Activating crossover network
By activating crossover networ , you can
allocate different frequency range of sound
signals to different spea ers to match their
characteristic.
I you have installed the 3-way network
speaker system in the car, make sure o the
ollowing:
• Before using the system, activate crossover
networ and preset the appropriate cutoff
frequencies for HPF/LPF (especially
for HPF); otherwise, it may damage the
spea ers.
• For 3-way networ spea er system, see
Installation/Connection Manual (separate
volume).
You cannot perform other operations until you
finish the following procedure.
While the power is turned o ...
~
Ÿ
!
• To cancel the procedure, press and
hold POWER/ATT/ENTER. The power
turns off.
⁄ Finish the procedure.
• indicator
lights up (in sequence
with other indicators).
To cancel Crossover, repeat the same
procedure. Ma e sure that “X-Over Off OK?”
appears on the display.
• indicator goes off.
Setting the sound modes—SEL
You can adjust the sound characteristics to your
preference.
~ Enter the SEL menu (see page 4).
Ÿ Select a setting item.
* Appears only when crossover network is
activated (see left column).
When selecting “Fad/Bal,” “X-Over,” or
“S.woofer,” press POWER/ATT/ENTER
to enter its submenu.
! Adjust the selected setting item.
(See the ollowing or details.)
• To adjust other SEL settings, press
BACK. Then repeat steps Ÿ and !.
⁄ Finish the procedure.
To adjust fader and balance—Fad/Bal
• Fad ( ader)
Adjust the front and rear spea er balance.
• Bal (balance)
Adjust the left and right spea er balance.
EN16-21_SH1000U_001A_3.indd 18EN16-21_SH1000U_001A_3.indd 18 1/16/06 5:17:55 PM1/16/06 5:17:55 PM

19
ENGLISH
To adjust reproduced frequency
level—X-Over
This setting is available only when crossover
network (see page 18) is activated.
1 Select a filter.
HPF
(Front/Rear)
: Freq encies lower than the
selected level are c t-off.
LPF (Rear) : Freq encies higher than the
selected level are c t-off.
2 Select “On” to activate the selected filter.
• If yo connect high-range speakers to
Front or Rear o tp t, select “On” for
the corresponding HPF to prevent the
speakers from being damaged.
3 Select a c t-off freq ency according to the
connected speakers.
.6kHz – 6.0kHz : Front HPF and Rear LPF
3 .5 Hz – 200.0Hz : Rear HPF
4 Adj st the contin ity of the so nd among
speakers (slope).
To adjust subwoofer output—
S.woofer
1 Adj st the o tp t level.
2 Select a c t-off freq ency according to the
connected s bwoofer.
3 Adj st the contin ity of the so nd among
speakers (slope).
To adjust the input level of each
source—Vol Adj
This setting is req ired for each so rce except
for FM.
Once an adj stment is made, it will be
memorized. When yo change the so rce the
vol me level will a tomatically increase or
decrease according to the adj sted level.
1 Select a so rce before entering the SEL
men .
2 Adj st to match the inp t level to the FM
so nd level.
EN16-21_SH1000U_001A_f.indd 19EN16-21_SH1000U_001A_f.indd 19 1/24/06 8:57:16 AM1/24/06 8:57:16 AM

20
ENGLISH
3 Select or adjust the selected PSM item.
4 Repeat steps 2 and 3 to adjust the
other PSM items if necessary.
5 Finish the procedure.
You can change PSM (Preferred Setting Mode)
items listed in the table that follows.
1 Enter the PSM menu (see page 4).
2 Select a PSM item.
General settings — PSM
Indications Items Settings, [reference page]
Demo
Display demonstration
• On [Initial]
• Off
: Display demonstration will be activated automatically if no
operation is done for about 20 seconds, [8].
: ancels.
Anime
Animation
• On [Initial]
• Off
: An animation screen appears when you turn on or off the power,
change the source, and when you select an EQ, MENU, or DSP.
: ancels.
Clock H
Hour adjustment
1 – 12 (0 – 23)
[Initial: 1 (1:00AM)]
: See also page 8 for setting.
Clock
Minute adjustment
00 – 59
[Initial: 00 (1:00AM)]
: See also page 8 for setting.
24H/12H
Time display mode
• 12Hours [Initial]
• 24Hours
: See also page 8 for setting.
Scroll*1• Once [Initial]
• Auto
• Off
: Scrolls the track information once.
: Repeats scrolling (in 5-second intervals in between).
: ancels.
• Pressing DISP for more than one second can scroll the display
regardless of the setting.
Dimmer • Auto [Initial]
• Time Set
• Off
• On
: Dims the display when you turn on the headlights.
: Sets the timer for dimmer, see page 22 for setting.
From: Any hour; To: Any hour
: ancels.
: Activates dimmer. (Does not work if “Bright” is set to “1.”)
EN16-21_SH1000U_001A_3.indd 20EN16-21_SH1000U_001A_3.indd 20 1/12/06 4:08:31 PM1/12/06 4:08:31 PM
