JVC KW-M730BT User manual

B5A-1735-07 (X)© 2017 JVC KENWOOD Corporation
KW-M730BT
MONITOR WITH RECEIVER
INSTRUCTION MANUAL
• Updated information (the latest Instruction Manual, system updates, new
functions, etc.) is available from
<http://www.jvc.net/cs/car/>.
!B5A-1735-07_17KWV-X_En.indb 1 2017/02/15 10:38

2
Contents
Before Use 4
Precautions................................................................... 4
How to read this manual ......................................... 4
Basic Operations 5
Functions of the Buttons on the Front Panel ... 5
Turning on the Unit ................................................... 6
Initial Settings.............................................................. 6
Adjusting the volume............................................... 8
Touch screen operations ......................................... 9
HOME screen descriptions...................................... 9
Source selection screen descriptions................10
Source control screen descriptions ...................12
Popup menu ..............................................................13
List screen ...................................................................13
USB 14
Connecting a USB device ......................................14
USB Basic Operation................................................14
Search Operation......................................................16
iPod/iPhone 17
Preparation .................................................................17
iPod/iPhone Basic Operation ...............................18
Search Operation......................................................19
APPS—Android Auto™/
Apple CarPlay 20
Apple CarPlay Operation .......................................20
Android Auto™ Operation.....................................22
Spotify Operation.....................................................23
Tuner 25
Tuner Basic Operation ............................................25
Memory Operation ..................................................26
Selecting Operation ................................................26
Traffic Information ...................................................27
Tuner Setup ................................................................27
Bluetooth Control 29
Information for using Bluetooth® devices.......29
Register from the Bluetooth unit........................30
Bluetooth Setup........................................................31
Playing Bluetooth Audio Device.........................33
Using Hands-Free Unit............................................35
Hands-Free Setup.....................................................39
Other External Components 40
View Camera ..............................................................40
External audio/video players—AV-IN ...............41
!B5A-1735-07_17KWV-X_En.indb 2 2017/02/15 10:38

3English
Setting Up 42
Monitor Screen Setup.............................................42
System Setup .............................................................42
User Interface Setup................................................43
Special Setup .............................................................44
Display Setup.............................................................45
AV Setup ......................................................................46
Controlling Audio 47
Speaker/ X’over setup.............................................47
Controlling General Audio....................................50
Equalizer Control ......................................................50
Volume Offset............................................................51
Zone Control ..............................................................52
Sound Effect...............................................................52
Listening Position/ DTA ..........................................53
Remote control 55
Functions of the Remote control Buttons.......55
Connection/Installation 57
Before Installation ....................................................57
Installing the unit .....................................................59
Troubleshooting 63
Problems and Solutions.........................................63
Error Messages ..........................................................63
Appendix 64
Playable Media and Files........................................64
Specifications.............................................................65
About this Unit..........................................................67
!B5A-1735-07_17KWV-X_En.indb 3 2017/02/15 10:38

Before Use
4
Before Use
Precautions
#WARNINGS
Ñ To prevent injury or fire, take
the following precautions:
• To prevent a short circuit, never put or leave
any metallic objects (such as coins or metal
tools) inside the unit.
• Do not watch or fix your eyes on the unit’s
display when you are driving for any extended
period.
• If you experience problems during installation,
consult your JVC dealer.
Ñ Precautions on using this unit
• When you purchase optional accessories,
check with your JVC dealer to make sure that
they work with your model and in your area.
• You can select language to display menus,
audio file tags, etc. See User Interface Setup
(P.43).
• The Radio Data System or Radio Broadcast
Data System feature won’t work where the
service is not supported by any broadcasting
station.
• The unit may not function properly if the
connectors between the unit and front panel
are dirty. Detach the front panel and clean the
connector with a cotton swab gently, being
careful not to damage the connector.
Ñ Protecting the monitor
• To protect the monitor from damage, do not
operate the monitor using a ball point pen or
similar tool with the sharp tip.
Ñ Cleaning the unit
• If the faceplate of this unit is stained, wipe it
with a dry soft cloth such as a silicon cloth. If
the faceplate is stained badly, wipe the stain
off with a cloth moistened with neutral cleaner,
then wipe it again with a clean soft dry cloth.
NOTE
• Applying spray cleaner directly to the unit may
affect its mechanical parts. Wiping the faceplate
with a hard cloth or using a volatile liquid such
as thinner or alcohol may scratch the surface or
erase screened print.
Ñ Acquiring GPS signal
The first time you turn on this unit, you must
wait while the system acquires satellite signals
for the first time. This process could take up
to several minutes. Make sure your vehicle
is outdoors in an open area away from tall
buildings and trees for fastest acquisition.
After the system acquires satellites for the first
time, it will acquire satellites quickly each time
thereafter.
How to read this manual
• The screens and panels shown in this manual are
examples used to provide clear explanations of the
operations.
For this reason, they may be different from the actual
screens or panels used, or some display patterns may
be different.
• Indication language: English indications are used
for the purpose of explanation. You can select the
indication language from the [SETUP]menu. See
User Interface Setup (P.43).
!B5A-1735-07_17KWV-X_En.indb 4 2017/02/15 10:38

Basic Operations
5English
Basic Operations
Functions of the Buttons on the Front Panel
1 2 3
NOTE
• The panels shown in this guide are examples used to provide clear explanations of the operations. For this reason,
they may be different from the actual panels.
Number Name Motion
1
–, +
(Volume)
• Adjusts volume.
The volume will go up until 15 when you keep pressing [+].
2
FNC • Displays the popup menu screen.
• Pressing for 1 second displays the Voice Recognition screen (P.36).
• When the power off, turns the power on.
3
Remote
Sensor
• Receives the remote control signal.
!B5A-1735-07_17KWV-X_En.indb 5 2017/02/15 10:38

Basic Operations
6
Turning on the Unit
The method of turning on is different
depending on the model.
1
Press the [FNC]button.
 The unit is turned on.
NOTE
• If it is your first time turning the unit on after
installation, it will be necessary to perform Initial
setup (P.6).
●To turn off the unit:
1
Press the [FNC]button.
 Popup menu appears.
2
Touch [ ].
 HOME screen appears.
3
Touch [ ].
4
Touch [Power Off].
Initial Settings
Initial setup
Perform this setup when you use this unit first
time.
1
Set each item as follows.
■Language
Select the language used for the control
screen and setting items. Default is“British
English (en)”.
1Touch [Language].
2Touch [Language Select].
3Select the desired language.
4Touch [
].
For detailed operation, see User Interface
Setup (P.43).
■Clock
Sets the synchronization of the clock and
adjusts it.
For detailed operation, see Calendar/clock
settings (P.8).
■Display
If it is hard to see the image on the screen,
adjust the viewing angle.
1Touch [Display].
2Touch [Viewing Angle].
3Select an angle
4Touch [
].
For detailed operation, see Display Setup
(P.45).
!B5A-1735-07_17KWV-X_En.indb 6 2017/02/15 10:38

Basic Operations
7English
■Camera
Set the parameters for the camera.
1Touch [Camera].
2Set each item and touch [
].
For detailed operation, see Camera Setup
(P.40).
■DEMO
Set the demonstration mode. Default is “ON”.
1Touch [DEMO]and set ON or OFF.
2
Touch [Finish].
NOTE
• These settings can be set from the SETUP menu.
See Setting Up (P.42).
Security Code Setup
You can set up a security code to protect your
receiver system against theft.
When the Security Code function is activated,
the code cannot be changed and the function
cannot be released. Note the Security Code
can be set as 4 to 8-digit number of your
choice.
1
Press the [FNC]button.
 Popup menu appears.
2
Touch [ ].
 HOME screen appears.
3
Touch [ ].
4
Touch [Security].
 Security screen appears.
5
Touch [Security Code Set]on the Security
screen.
 Security Code Set screen appears.
6
Enter a security code with 4 to 8-digit
number and touch [Enter].
7
Enter the same code again and touch
[Enter].
Now, your security code is registered.
NOTE
• Touch [BS]to delete the last entry.
• If you enter a different security code, the screen
returns to step 6 (for the first code entry).
• If you have disconnected the Receiver from
battery, enter the correct security code as that
you have entered in step 6 and touch [Enter]. You
can use your receiver.
To change the security code:
1
Touch [Security Code Change]on the
Security screen, then repeat step 6 and 7.
To clear the security code:
1
Touch [Security Code Cancellation]on
the Security screen.
!B5A-1735-07_17KWV-X_En.indb 7 2017/02/15 10:38

Basic Operations
8
Calendar/clock settings
1
Press the [FNC]button.
 Popup menu appears.
2
Touch [ ].
 HOME screen appears.
3
Touch [ ].
4
Touch [User Interface].
 User Interface screen appears.
5
Set each item as follows.
Scroll the page to show the item.
■Clock
GPS-SYNC (Default): Synchronizes the clock
time with the GPS.
Manual: Sets the clock manually.
■Time Zone
Select the time zone.
■Clock Adjust
If you select [Manual]for Clock, adjust the
date and time manually. (P.43)
Adjusting the volume
To adjust the volume (0 to 40),
Press [+]to increase, and press [–]to decrease.
Holding [+]increases the volume continuously
to level 15.
!B5A-1735-07_17KWV-X_En.indb 8 2017/02/15 10:38

Basic Operations
9English
Touch screen operations
To perform operations on the screen, you need
to touch, touch and hold, flick or swipe to
select an item, display setting menu screen or
to change the page, etc.
●Touch
Touch the screen gently to
select an item on the screen.
●Touch and hold
Touch the screen and keep
your finger in place until
the display changes or a
message is displayed.
●Flick
Slide your finger quickly
to the left or right on the
screen to change the page.
You can scroll the list screen
by flicking the screen up/
down.
●Swipe
Slide your finger up or down
on the screen to scroll the
screen.
Monitor Touch Control:
You can also control playback by moving your
finger on the touch panel as follows (for some
sources, the gesture control is not available).
• Sliding the finger towards up/down: Functions
same as pressing []/ [](Media). Tuner
Preset broadcast stations are switched.
• Sliding the finger towards left/right: Functions
same as pressing [E]/ [F].
• Moving your finger clockwise or counter-
clockwise: increases/decreases the volume.
HOME screen descriptions
Most functions can be performed from the
HOME screen.
1
1 64 5
12 3
1
• Short-cut playback source icons (P.11)
2
• Current source information.
• Touch to displays the control screen of
current source.
3
• Widget
– You can change the widget by touching
[
]/[ ].
– Touch the widget to display the detailed
screen.
4
• Displays the SETUP Menu screen. (P.42)
5
• Displays the source selection screen. (P.10)
6
• Displays the Hands Free screen. (P.35)
• When connecting as Apple CarPlay or
Android Auto, it works as a phone provided
in Apple CarPlay or Android Auto.
Display the HOME
1
Press the [FNC]button.
 Popup menu appears.
2
Touch [ ].
 HOME screen appears.
!B5A-1735-07_17KWV-X_En.indb 9 2017/02/15 10:38

Basic Operations
10
Source selection screen
descriptions
You can display all playback sources and
options on the source selection screen.
3 5
2
4
1
1
• Changes the playback source.
For playback sources, see P.10.
2
• Changes the page. (Touch []/[ ].)
You can also change the page by flicking left
or right on the screen.
3
• Returns to previous screen.
4
• Page indication
5
• Displays the SETUP Menu screen. (P.42)
Select the playback source
1
Touch [ ].
From the screen, you can select the
following sources and functions.
• Switches to the Android Auto/ Apple
CarPlay screen from the connected iPod
touch/iPhone/Android device.*1(P.20)
• Switches to the Radio broadcast.
(P.25)
• Plays a Bluetooth audio player. (P.29)
• Plays an iPod/iPhone. (P.17)
• Plays files on a USB device. (P.14)
• Switches to the Spotify. (P.23)
• Switches to an external component
connected to the AV-IN input terminal.
(P.41)
• Displays the Audio screen. (P.47)
• Turns off the AV source. (P.11)
• Turn off the unit. (P.6)
*1When iPhone compatible with CarPlay is
connected, [Apple CarPlay]is displayed.
When an Android device compatible with
Android Auto is connected, [Android Auto]is
displayed.
!B5A-1735-07_17KWV-X_En.indb 10 2017/02/15 10:38

Basic Operations
11English
To select the playback source on the
HOME screen
The 3 items displayed on the source selection
screen as the large icons are shown on the
HOME screen.
You can change items displayed on this area
by customizing the source selection screen.
(P.11)
To select the playback source on the
source control screen
Display source selection buttons by touching
[ ]/[ ] or flicking left or right on the source
control screen, then select a playback source.
Put the unit in standby
1
Touch [ ].
2
Touch [AV Off].
Customize Short-cut buttons on
HOME screen
You can arrange the position of the source
icons as you like.
1
Touch [ ].
2
Touch and hold the icon which you want
to move to go into the customizing
mode.
3
Drag it where you want to move.
!B5A-1735-07_17KWV-X_En.indb 11 2017/02/15 10:38

Basic Operations
12
Source control screen
descriptions
There are some functions which can be
operated from most screens.
Indicators
1
2 3 4
Short-cut buttons
1
Connected Bluetooth device information.
• : Lights up when quick charging battery
of the connected iPod/ iPhone/ Smartphone.
2
All sources icon
Displays all sources.
3
Secondary screen
• [
]/[ ] : The Secondary screen changes every
time you touch it. You can also change the
Secondary screen by flicking left or right on
the screen.
• Indicators: Displays the current source
condition and so on.
– ATT: The attenuator is active.
– DUAL: The dual zone function is on.
– MUTE: The mute function is active.
– LOUD: The loudness control function is on.
• Short-cut buttons: The source changes to the
one you have set as a short-cut. For the short-
cut setting, refer to Customize Short-cut
buttons on HOME screen (P.11).
4
[Û]
Touch to display the Hands Free screen. (P.35)
When connecting as Apple CarPlay or Android
Auto, it works as a phone provided in Apple
CarPlay or Android Auto.
!B5A-1735-07_17KWV-X_En.indb 12 2017/02/15 10:38

Basic Operations
13English
Popup menu
1
Press the [FNC]button.
 Popup menu appears.
2
Touch to display the popup menu.
The contents of the menu are as follows.
• Displays the HOME screen. (P.9)
• Switches the screen.
The screen switched to depends on the
[DISP Key]setting in the [User Interface]
screen. (P.43).
• Touch and hold to turns the screen off.
• Display the Hands Free screen. (P.35)
When connecting as Apple CarPlay
or Android Auto, it works as a phone
provided in Apple CarPlay or Android
Auto.
• Displays the view camera. (P.40)
• Displays the Screen Adjustment screen.
(P.42)
• Displays the Graphic Equalizer screen.
(P.50)
• Close the popup menu.
• Short-cut buttons: The source changes to
the one you have set as a short-cut. For
the short-cut setting, refer to Customize
Short-cut buttons on HOME screen
(P.11).
• Touch to display the Hands Free screen.
(P.35)
• When connecting as Apple CarPlay
or Android Auto, it works as a phone
provided in Apple CarPlay or Android
Auto.
List screen
There are some common function keys in the
list screens of most sources.
61 2
3 4 5
1
Displays list type selection window.
2
Displays music/movie file list.
3
Text scroll
Scrolls the displayed text.
4
etc.
Keys with various functions are displayed here.
• : Plays all tracks in the folder containing
the current track.
• : Jump to the letter you entered
(alphabet search).
• : Moves to the upper hierarchy.
5
[ ] / [ ] / [ ] / [ ] Page scroll
You can change the page to display more items
by pressing [
]/[ ].
• [
]/[ ] : Displays the top or bottom page.
6
Return
Returns to previous screen.
NOTE
• Buttons which cannot be activated from the list
screen are not displayed.
!B5A-1735-07_17KWV-X_En.indb 13 2017/02/15 10:38

USB
14
USB
Connecting a USB device
1 Connect the USB device with the USB
cable. (P.62)
2 Press the [FNC]button.
 Popup menu appears.
3 Touch [ ].
 HOME screen appears.
4 Touch [ ].
5 Touch [USB]. (P.10)
Ñ Disconnect the USB device
1 Press the [FNC]button.
 Popup menu appears.
2 Touch [ ].
 HOME screen appears.
3 Touch [ ].
4 Touch a source other than [USB].
5 Detach the USB device.
Ñ Usable USB device
You can use a mass-storage-class USB device on
this unit.
The word“USB device”appearing in this manual
indicates a flash memory device.
●About file system
The file system should be the one of the
following.
• FAT16 • FAT32 • exFAT • NTFS
NOTE
• Install the USB device in the place where it will
not affect safe driving.
• You cannot connect a USB device via a USB hub
and Multi Card Reader.
• Take backups of the audio files used with this
unit. The files can be erased depending on the
operating conditions of the USB device.
We shall have no compensation for any damage
arising from any erased data.
USB Basic Operation
Most functions can be controlled from the
source control screen and playback screen.
Control screen
4
3
5
2
6
1
7
Content list panel
8
4
1
[ ] / [ ]
• [
]: Repeats the current track/folder. Each
time you touch the key, repeat mode switches
in the following sequence;
File repeat ( ), Folder repeat ( ), Repeat
all ( )
• [
]: Randomly plays all tracks in current
folder. Each time you touch the key, random
mode switches in the following sequence;
File random ( ), Random off ( )
• When a high-resolution source is played, its
format information is displayed.
!B5A-1735-07_17KWV-X_En.indb 14 2017/02/15 10:38

USB
15English
2
Track information
Displays the information of the current file.
Only a file name and a folder name are displayed
if there is no tag information.
3
[Function bar
• 1]: Searches track/file. For details on search
operation, see Search Operation (P.16).
• E][F]: Searches the previous/next track/
file.
Touch and hold to fast forward or fast
backward. (It will be cancelled automatically
after about 50 seconds.)
• [DH]: Plays or pauses.
• [
]: Touch to attenuates/restores the sound.
4
Function panel
Touch on the left side of the screen to display
the function panel. Touch again to close the
panel.
• [
][ ] : Searches previous/next folder.
• [USB DEVICE CHANGE]
Switches to another USB device when two USB
devices are connected.
5
Content list
Touch on the right side of the screen to display
the Content list. Touch again to close the list.
6
Indicator Items
• VIDEO: Identifies the video file.
• MUSIC: Identifies the music file.
7
Artwork/ Play mode indicator/ Playing
time
The jacket of the currently playing file is
displayed.
• D, B, etc.: Current play mode indicator
The meanings of each icon are as follows;
D(play), B(fast forward),
A(fast backward), H(pause).
8
Content list panel
Displays the playing list. When you touch a track/
file name on the list, playback will start.
Video screen
10
99
9
Searching file area (Video file only)
Touch to search the next/previous file.
10
Key display area (Video file only)
Touch to display the control screen.
!B5A-1735-07_17KWV-X_En.indb 15 2017/02/15 10:38

USB
16
Search Operation
You can search music or video files by the
following operations.
1 Touch [1].
2 Touch [S].
3 Select the list type.
NOTE
• For operations in the list screen, see List screen
(P.13).
Ñ Category search
You can search a file by selecting category.
1 Touch [Category List].
2 Select whether you search by audio files
or video files .
3 Touch the desired category.
 The list corresponding to your selection
appears.
4 Touch to select desired item in the list.
Repeat this step until you find the desired
file.
Ñ Link search
You can search a file of same artist/album/
genre as the current track.
1 Touch [Link Search].
2 Touch the desired tag type. You can select
from artist, album and genre.
 The list corresponding to your selection
appears.
3 Touch desired item from the content list.
Ñ Folder search
You can search a file according to hierarchy.
1 Touch [Folder List].
2 Touch the desired folder.
When you touch a folder its contents are
displayed.
3 Touch to select desired item in the list.
Repeat this step until you find the desired
file.
!B5A-1735-07_17KWV-X_En.indb 16 2017/02/15 10:38

iPod/iPhone
17English
iPod/iPhone
Preparation
Ñ Connectable iPod/iPhone
The following models can be connected to
this unit.
Made for
• iPhone 6s Plus
• iPhone 6s
• iPhone 6 Plus
• iPhone 6
• iPhone 5s
• iPhone 5c
• iPhone 5
• iPod touch (6th generation)
• iPod touch (5th generation)
NOTE
• By connecting your iPod/iPhone to this unit with
an optional accessory iPod connection cable KS-
U62, you can supply power to your iPod/iPhone
as well as charge it while playing music. However,
the power of this unit must be on.
• If you start playback after connecting the iPod,
the music that has been played by the iPod is
played first.
Ñ Connect iPod/iPhone
Wired connection
Preparation
• Connect an iPod/iPhone with the KS-U62
(optional accessory) while CarPlay is not
connected.
• With a CarPlay-capable iPhone, turn off CarPlay
by operating the iPhone at functional setup
before connecting iPhone. For details of the
setup method, contact the manufacturer of the
terminal.
• Plug the iPod/iPhone into the gray USB terminal
with the KS-U62 (optional accessory).
• Only one iPod/iPhone can be connected.
1 Connect the iPod/iPhone using KS-U62.
(P.62)
2 Press the [FNC]button.
 Popup menu appears.
3 Touch [ ].
 HOME screen appears.
4 Touch [ ].
5 Touch [iPod]. (P.10)
●To disconnect the iPod/iPhone connected
with the cable:
1 Detach the iPod/iPhone.
Bluetooth connection
Pair the iPhone through Bluetooth.
Preparation
• To connect an iPhone via Bluetooth, register it as
the Bluetooth device and do the profile setting of
the connection beforehand. See Register from
the Bluetooth unit (P.30) and Connect the
Bluetooth unit (P.32).
• Connect an iPhone on Bluetooth while CarPlay
and an iPod/iPhone are not connected on USB.
!B5A-1735-07_17KWV-X_En.indb 17 2017/02/15 10:38

iPod/iPhone
18
iPod/iPhone Basic Operation
Control screen
3
4
2
5
Content list panel
1
7
6
1
[ ] / [ ]
• [
]: Repeats the current track/album. Each
time you touch the key, repeat mode switches
in the following sequence;
Song repeat ( ), All songs repeat ( )
• [
]: Randomly plays all tracks in current
album. Each time you touch the key, random
mode switches in the following sequence;
Song random ( ), Album random ( ),
Random off ( )
2
Track information
• Displays the information of the current file.
• Touch to display the category list screen. See
Category search (P.19).
3
[Function bar
• 1]: Searches track/file. For details on search
operation, see Search Operation (P.19).
• E][F]: Searches the previous/next track/
file. Touch and hold to fast forward or fast
backward. (It will be cancelled automatically
after about 50 seconds.)
• [DH]: Plays or pauses.
• [
]: Touch to attenuates/restores the sound.
4
Content list
Touch on the right side of the screen to display
the Content list. Touch again to close the list.
5
Indicator Items
• MUSIC: Identifies the music file.
6
Artwork/ Play mode indicator/ Playing
time
The jacket of the currently playing file is
displayed.
• D, B, etc.: Current play mode indicator
The meanings of each icon are as follows;
D(play), B(fast forward),
A(fast backward), H(pause).
7
Content list panel
Displays the playing list. When you touch a track/
file name on the list, playback will start.
!B5A-1735-07_17KWV-X_En.indb 18 2017/02/15 10:38

iPod/iPhone
19English
Search Operation
You can search music files by the following
operations.
1 Touch [1].
2 Touch [S].
3 Select the list type.
NOTE
• For operations in the list screen, see List screen
(P.13).
Ñ Category search
You can search a file by selecting category.
1 Touch [Category List].
2 Touch the desired category.
 The list corresponding to your selection
appears.
3 Touch to select desired item in the list.
Repeat this step until you find the desired
file.
Ñ Link search
You can search a file of same artist/album/
genre/composer as the current track.
1 Touch [Link Search].
2 Touch the desired tag type. You can select
from artist, album, genre and composer.
 The list corresponding to your selection
appears.
3 Touch desired item from the content list.
!B5A-1735-07_17KWV-X_En.indb 19 2017/02/15 10:38

APPS—Android Auto™/Apple CarPlay
20
APPS—Android Auto™/Apple CarPlay
Apple CarPlay Operation
CarPlay is a smarter, safer way to use your
iPhone in the car. CarPlay takes the things
you want to do with iPhone while driving and
displays them on the screen of the product.
You can get directions, make calls, send and
receive messages, and listen to the music
from iPhone while driving. You can also use
Siri voice control to make it easier to operate
iPhone.
For details about CarPlay, visit https://ssl.
apple.com/ios/carplay/.
Compatible iPhone devices
You can use CarPlay with the following iPhone
models.
• iPhone 6s Plus
• iPhone 6s
• iPhone 6 Plus
• iPhone 6
• iPhone 5s
• iPhone 5c
• iPhone 5
Ñ Preparation
1 Connect iPhone using KS-U62 via USB
(Black) terminal. (P.62)
When iPhone compatible with CarPlay is
connected to the USB (Black) terminal, the
Bluetooth smartphone currently connected
is disconnected.
2 Unlock your iPhone.
Ñ Operation buttons and
available Apps on the home
screen of CarPlay
You can use the Apps of the connected iPhone.
The items displayed and the language used
on the screen differ among the connected
devices.
To enter CarPlay mode, touch [Apple CarPlay]
icon in the source selection screen. (P.10)
3
1
2
1
[ ]
• Displays the home screen of CarPlay.
• Touch and hold to activates Siri.
2
Application buttons
Starts the application.
3
[HOME]
Exits the CarPlay screen and displays the Home
screen.
To exit the CarPlay screen
1 Press the [FNC]button.
 Popup menu appears.
2 Touch [ ].
 HOME screen appears.
!B5A-1735-07_17KWV-X_En.indb 20 2017/02/15 10:38
