JVC KWAVX800 - EXAD - DVD Player User manual

For installation and connections, refer to the separate manual.
INSTRUCTIONS
LVT1667-001A
[A]
For canceling the display demonstration, see page 8.
DVD RECEIVER WITH MONITOR
KW-AVX800
Cover_KW-AVX800A_f.indd 2Cover_KW-AVX800A_f.indd 2 07.2.14 2:33:57 PM07.2.14 2:33:57 PM

2
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
IMPORTANT FOR LASER PRODUCTS
1. CLA 1 LA ER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with optical
instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUT IDE THE UNIT.
WARNINGS:
To prevent accidents and da age
• DO NOT install any unit and wire any cable in
locations where;
– it may obstruct the steering wheel and
gearshift lever operations.
– it may obstruct the operation of safety devices
such as air bags.
– it may obstruct visibility.
• DO NOT operate the unit while driving.
If you need to operate the unit while driving, be
sure to look around carefully.
• The driver must not watch the monitor while
driving.
• The driver must not put on the headphones while
driving.
Cautions on the onitor:
• The monitor built in this unit has been produced
with high precision, but it may have some
ineffective dots. This is inevitable and is not
malfunction.
• Do not expose the monitor to direct sunlight.
• Do not operate the touch panel using a ball-point
pen or similar tool with the sharp tip.
Touch the buttons on the touch panel with your
finger directly (if you wear a glove, take it off).
• When the temperature is very cold or very hot..
– Chemical changes occur inside, causing
malfunction.
– Pictures may not appear clearly or may move
slowly. Pictures may not be synchronized with
the sound or picture quality may decline in
such environments.
[European Union only]
EN02-07_KW-AVX800A_f.indd 2EN02-07_KW-AVX800A_f.indd 2 07.2.14 3:20:04 PM07.2.14 3:20:04 PM

3INTRODUCTION
How to reset your unit
• Your preset
adjustments will also
be erased.
How to forcibly eject a disc
• If this does not work, reset the unit.
For safety...
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• top the car before performing any complicated
operations.
Te perature inside the car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
Contents
INTRODUCTION
Playable disc type ............................ 4
Basic operations—
Monitor panel/touch panel ............ 5
Basic operations—
Re ote controller (RM-RK251) ...... 6
OPERATIONS
Before operating the unit ................ 8
Co on operations ........................ 9
Listening to the radio ...................... 10
Disc operations ................................ 13
Dual Zone operations ....................... 27
SD operations .................................. 30
USB operations ................................ 32
EXTERNAL DEVICES
Bluetooth® operations—
Cellular phone/audio player .......... 34
Listening to the CD changer .............. 41
Listening to the iPod/D. Player ......... 43
Using other external co ponents ..... 45
SETTINGS
Sound equalization .......................... 48
Assigning titles to the sources .......... 49
Menu operations ............................. 50
REFERENCES
Maintenance ................................... 60
More about this unit ........................ 61
Troubleshooting .............................. 67
Specifications .................................. 72
NO EJECT?
EMERGENCY EJECT?
Exit
ENTER
Back
11
3
2
at the same time
EN02-07_KW-AVX800A_f.indd 3EN02-07_KW-AVX800A_f.indd 3 07.2.14 3:20:07 PM07.2.14 3:20:07 PM

4
Disc type Recording format, file type, etc. Playable
DVD DVD Video (Region Code: 4)*1
DVD Audio
DVD-ROM
DVD Recordable/Rewritable
(DVD-R*2/-RW, +R/+RW*3)
• DVD Video: UDF bridge
• DVD-VR
• DivX/MPEG /MPEG2/JPEG/MP3/
WMA/WAV/AAC: ISO 9660 level
, level 2, Romeo, Joliet
• DVD-RAM cannot be played.
DVD Video
DVD-VR (non-CPRM only)
DivX/MPEG /MPEG2
JPEG
MP3/WMA/WAV/AAC*4
MPEG4
DVD+VR
D al Disc DVD side
Non-DVD side
CD/VCD Audio CD/CD Text (CD-DA)/DTS-CD
VCD (Video CD)
CD-ROM
CD-I (CD-I Ready)
CD Recordable/Rewritable
(CD-R/-RW)
• ISO 9660 level , level 2, Romeo,
Joliet
CD-DA
MP3/WMA/WAV/AAC*4
JPEG
DivX/MPEG /MPEG2
MPEG4
*1 If you insert a DVD Video disc of an incorrect Region Code, “Region code error” appears on the monitor.
*2 DVD-R recorded in multi-border format is also playable (e cept for dual layer discs).
*3 It is possible to play back finalized +R/+RW (Video format only) discs. However, the use of +R double layer disc is
not recommended.
*4 This unit can play back AAC files encoded using iTunes.
Ca tion for D alDisc playback
The Non-DVD side of a “DualDisc” does not comply with the “Compact Disc Digital Audio” standard. Therefore,
the use of Non-DVD side of a DualDisc on this product may not be recommended.
Playable disc type
EN02-07_KW-AVX800A_f.indd 4EN02-07_KW-AVX800A_f.indd 4 07.2.16 4:07:58 PM07.2.16 4:07:58 PM

5INTRODUCTION
Basic operations — Monitor panel/touch panel
• Turn on the power.
• Turn off the power [Hold].
• Attenuate the sound (if the power is on).
Change the sources.
• ☞ page 9.
Re ote sensor
Adjust the volu e.
Reset the unit.
• Use only when the internal system malfunctions.
Display <AV Menu>.
• ☞ page 50.
Display and erase the Short Cut windows.
Available functions vary among the sources. For details, see each source
operation section.
Change the display infor ation.
• [OPEN]: Open the onitor panel.
• [EJECT]: Eject the disc.
• [CLOSE]: Close the onitor panel.
• [TILT +/–]: Tilt the onitor panel.
• [Exit]: Erase this screen.
• haded icons cannot be used at that time.
• For details on the touch panel operations,
see each source operation sections.
Display <Source Menu>.
• ☞ pages 9 and 27.
• Display the <Open/Tilt> screen
• Eject the disc and display the <Open/Tilt>
screen [Hold].
• Close the onitor panel when the <Open/Tilt>
screen is displayed.
Display <AV Menu>.
• ☞ page 50.
EN02-07_KW-AVX800A_f.indd 5EN02-07_KW-AVX800A_f.indd 5 07.2.14 3:20:11 PM07.2.14 3:20:11 PM

6
Installing the battery
If the range or effectiveness of the remote controller
decreases, replace both batteries.
Before using the re ote controller:
• Aim the remote controller directly at the remote
sensor on the unit.
• DO NOT expose the remote sensor to bright light
(direct sunlight or artificial lighting).
Caution:
• Do not expose batteries to heat or flame.
IMPORTANT:
If Dual Zone is activated (☞ page 27), the remote
controller functions only for operating the DVD/CD
player.
Basic operations — Remote controller (RM-RK251
Main ele ents and features
i
o
;
a
s
1*1 • Turns on the power.
• Attenuates the sound if the power is on.
• Turns off the power if pressed and held (while
the power is on).
2*1 elects the source.
3*1 • Displays <Dial Menu>.
• Displays <Redial> list if pressed and held.
• Answers incoming calls.
4*1,2 Adjusts the volume level.
R03/LR03/AAA
EN02-07_KW-AVX800A_f.indd 6EN02-07_KW-AVX800A_f.indd 6 07.2.14 3:20:13 PM07.2.14 3:20:13 PM

7INTRODUCTION
w TUNER: elects the bands.
DI C/ D/U B: tops play.
Bluetooth PHONE: Ends the call.
Bluetooth AUDIO: Plays/pauses.
• This button does not function as the BACK
button for this model.
e*2 Adjusts the volume level through the 2nd AUDIO
OUT plug.
r*2 Activates or deactivates Dual Zone.
t*1,2 elects the sound mode.
y • DVD Video/DivX 6: hows the disc menu.
• VCD: Resumes PBC playback.
• DVD-VR: hows the Play List screen.
u RETURN button
• For VCD: Returns to the PBC menu.
i DI C/ D/U B: witches number entry mode.
• Also functions as CLEAR button to erase the
misentry after entering the wrong number.
o • Enter the numbers.
• FM/AM: elects the preset station directly.
• CD changer: elects the disc directly.
;*1 Changes the aspect ratio of the playback
pictures.
a Reverse search/forward search for disc/ D/U B
operations.
s • DVD Video: elects audio language ( ),
subtitles ( ), angle ( ).
• DVD Audio: elects audio stream ( ).
• DVD-VR: Turn on/off subtitles ( ), and
selects audio channel ( )
• DivX: elects audio language ( ),
subtitles ( ).
• VCD: elects audio channel ( ).
*1 If Dual Zone is activated, these buttons cannot be
used.
*2 These buttons can be used only when the slide cover is
closed.
*3 5 : Returns to the previous menu.
∞ : Confirms the selection.
5*1,2 elects surround mode.
6 • DVD/DivX 6: hows the disc menu.
• VCD: Resumes PBC playback.
• DVD-VR: hows the Original Program screen.
7 • Makes selection/settings.
• ~: kips back or forward by 5 minutes for
DivX/MPEG1/MPEG2.
• DI C +/– buttons: Changes discs for “CD-CH.”
8 hows the on-screen bar.
9*1 Changes the display information.
p Display or erase <AV Menu>.
q For disc/SD/USB operations:
• 6: Plays/pauses.
• 5 / ∞:
DVD: elects the title/group.
DVD-VR: elects the program/playlist.
D/U B/other discs (except VCD/CD): elects
the folders.
• 4 / ¢:
– Press briefly: reverse skip/forward skip.
– Press and hold: reverse search/forward
search.
For FM/AM operations:
• 5 / ∞: elects the preset stations.
• 4 / ¢: Functions to search for stations.
– Press briefly: Auto earch
– Press and hold: Manual earch
For Apple iPod/JVC D. player operations:
• ∞: Pauses/stops or resumes playback.
• 5: Enters the main menu (then 5 / ∞ /
4 / ¢ work as the menu selecting
buttons).*3
• 4 / ¢ (in menu selecting mode)
– elects an item if pressed briefly. (Then,
press ∞ to confirm the selection.)
– kips 10 items at a time if pressed and held.
For Bluetooth operations:
• 4 / ¢: reverse skip/forward skip (for
audio operation)
• 6: Answers incoming calls (for “Bluetooth
PHONE”), plays/pauses (for “Bluetooth
AUDIO”).
EN02-07_KW-AVX800A_f.indd 7EN02-07_KW-AVX800A_f.indd 7 07.2.14 3:20:14 PM07.2.14 3:20:14 PM

8
Cancel the display demonstration and set the clock (☞
pages 51 and 52 for details).
• Non-available items ill be displayed being shaded
on the AV Menu screens.
Indication language:
In this manual, English indications are used
for purpose of explanation. You can select the
indication language on the monitor. (☞ page 52)
~ Turn on the power.
Ÿ Display <AV Menu>.
! Display the <Setup> menu.
⁄ Cancel the display demonstrations.
Select < ff>.
@ Set the clock settings.
¤ Finish the procedure.
Before operating the unit
Moves to the succeeding menu page
Moves to the preceding menu page
Return to the previous screen.
EN08-12_KW-AVX800A_f.indd 8EN08-12_KW-AVX800A_f.indd 8 07.2.14 3:21:17 PM07.2.14 3:21:17 PM

OPERATIONS
9
Selecting the playback source
• Available sources depend on the external
components you have connected, media you have
attached, and the <Input> settings you have made
(☞ pages 55 and 56).
n the touch panel:
n the monitor panel:
TUNER = DISC (DVD/VCD/CD) = SD = USB =
CD-CH, iPod, D.PLAYER, or EXT-IN = Bluetooth
PH NE = Bluetooth AUDI = AV-IN = (back to
the beginning)
• You cannot select these sources if they are not ready.
Changing the display
information
• Available display information varies among the
playback sources.
n the monitor panel only:
• Each time you press DISP, the display changes to
sho the various information.
Ex. When the playback source is a DivX disc.
Exit Source information screen
Animation screen
Navigation screen
(When <Navigation> is
selected for <AV Input>):
(☞ page 55).
Back to the beginning
Playback picture screen
(only for video sources)
Preset station (service) list,
track (file) list, or phone
number list
Common operations
☞ page 27
EN08-12_KW-AVX800A_f.indd 9EN08-12_KW-AVX800A_f.indd 9 07.2.14 3:21:20 PM07.2.14 3:21:20 PM

10
When an FM stereo broadcast is
hard to receive
1 Press [AV MENU].
• You can also use AV MENU on the monitor panel.
2 Press [Mode].
Listening to the radio
~ Press [S URCE], then press [TUNER]. (☞ page 9)
• You can also use SOURCE on the monitor panel. Press it repeatedly.
Ÿ Press [BAND].
! Press [4] or [¢] to search for a station—Auto Search.
• Manual Search: Hold either [4]or [¢] until “Manual Search” appears on the display, then press it
repeatedly.
• The ST indicator lights up hen receiving an FM stereo broadcast ith sufficient signal strength.
3
Reception improves, but stereo effect ill be lost.
• The MONO indicator lights up.
To restore stereo effect, select < ff>.
Preset No.
Band
☞ page 9
Sound mode
(☞ page 48)
☞ page 11, 48
: Buttons on the
touch panel. In the
explanation, they
are indicated inside
[ ].
Tuner indicators
Assigned station name (☞ page 49). If no name is assigned,
“No Name” appears.
EN08-12_KW-AVX800A_f.indd 10EN08-12_KW-AVX800A_f.indd 10 07.2.14 3:21:21 PM07.2.14 3:21:21 PM

OPERATIONS
11
FM station automatic presetting
—SSM (Strong-station
Sequential Memory)
This function orks only for FM bands.
You can preset six stations for each band.
1 Press [AV MENU].
• You can also use AV MENU on the monitor panel.
2 Press [Mode].
3
Local FM stations ith the strongest signals are
searched and stored automatically in the FM band.
Tuning in to stations with
sufficient signal strength
This function orks only for FM bands. Once you have
activated this function (selected <Local>), it al ays
orks hen searching for FM stations.
1 Press [AV MENU].
• You can also use AV MENU on the monitor panel.
2 Press [Mode].
3
Only stations ith sufficient signal strength ill be
detected.
• The DX indicator goes off, then the LO indicator
lights up.
• You can also change <IF Band Width> setting
(for details, ☞ page 55).
<IF Band Width> menu can be accessed by
pressing [SH RT CUT] on the touch panel,
then... ☞ page 48
EN08-12_KW-AVX800A_f.indd 11EN08-12_KW-AVX800A_f.indd 11 07.2.14 3:21:23 PM07.2.14 3:21:23 PM

12
Selecting preset stations
n the remote:
1
2
or
n the unit:
To select directly on the touch panel
To select from the Preset List
1
2
Manual presetting
Ex.: Storing FM station of 92.5 MHz into preset
number 4 of the FM1 band.
1 Display the Preset List.
2 Tune in to a station you want to preset.
3 Select a preset number.
The station selected in step 2 is no stored in
preset number 4.
EN08-12_KW-AVX800A_f.indd 12EN08-12_KW-AVX800A_f.indd 12 07.2.14 3:21:25 PM07.2.14 3:21:25 PM

OPERATIONS
13
! Insert a disc.
Monitor panel closes automatically.
If not, press [CLOSE].
Caution:
Do not place your finger behind the monitor panel.
~ Open the monitor panel.
<Open/Tilt> menu appears.
• Shaded icons cannot be used at that time.
• y pressing and holding the button, you can
open the monitor panel and eject the disc.
Ÿ Press [OPEN].
Disc operations
The disc type is automatically detected, and playback starts automatically (for some discs: automatic start depends
on its internal program).
If a disc does not have any disc menu, all tracks in it will be played repeatedly until you change the source or eject the
disc.
If “ ” appears on the monitor, the unit cannot accept the operation you have tried to do.
• In some cases, without showing “ ,” operations will not be accepted.
Label side
Caution on volume settin :
Discs produce very little noise compared with other
sources. Lower the volume before playing a disc
to avoid damaging the speakers by the sudden
increase of the output level.
• [OPEN]: Open the monitor panel.
• [EJECT]: Eject the disc.
• [CLOSE]: Close the monitor panel.
• [TILT +/–]: Tilt the monitor panel.
• [Exit]: Erase this screen.
EN13-33_KW-AVX800A_f.indd 13EN13-33_KW-AVX800A_f.indd 13 07.2.14 3:27:16 PM07.2.14 3:27:16 PM

14
While playing the following discs, press .
• Each time you press the button, the display changes to show the different information (☞ page 9).
Audio format
DVD Video: Title no./Chapter no./Playing time
DVD-VR: Program no. (or Playlist no.)/Chapter no./Play time
Playback mode
Disc type *1
[3 / 8] Start and pause playback
[7] Stop playback
[4 ¢] Press: Select track
Hold: Reverse/forward search*2
[5 ∞] Select group
Group no./Track no./Playing time
Reproduced sound
indicator—
MULTI CH/LR ONLY
(☞ page 62 )
Sampling frequency/ it
rate/Recorded signal
channel no.
Speaker/signal
indicators
(☞ page 61)
☞ page 19
[3 / 8] Start and pause playback
[7] Stop playback
[4 ¢] Press: Select chapter
Hold: Reverse/forward search*2
[5 ∞] Select title/program/playlist
☞ page 19
.S.P indicator
(☞ page 23)
ONUS indicator
(☞ page 23)
*1 DVD-VR also indicates either PRG (program) or PLAY (playlist) playbac .
*2 Search speed: x2 ] x10.
Surround mode
(☞ page 24)
: uttons on the touch panel. In the explanation,
they are indicated inside [ ].
These buttons also work when they are not
shown on the touch panel (while watching
pictures on the screen).
EN13-33_KW-AVX800A_f.indd 14EN13-33_KW-AVX800A_f.indd 14 07.2.14 3:27:21 PM07.2.14 3:27:21 PM

OPERATIONS
15
Track no./Playing time
*2 Search speed: x2 ] x10.
*3 Surround mode and sound mode cannot be used at the same time.
*4 Search speed: ¡1 ] ¡2.
[3 / 8] Start and pause playback
[7] Stop playback
[4 ¢] Press: Select track
Hold: Reverse/forward search*2
For DivX/MPEG1/MPEG2: Folder no./Track no./Playing time
For JPEG: Folder no./Track no.
[3 / 8] Start and pause playback
[7] Stop playback
[4 ¢] Press: Select track
Hold: Reverse/forward search for DivX/MPEG1/MPEG2 *4
[5 ∞] Press: Select folder
Hold: Display Folder list
While playing the following discs, press .
• Each time you press the button, the display changes to show the different information (☞ page 9).
Surround mode *3
(☞ page 24)
Disc type
☞ page 19
☞ page 19
P C indicator
lights up when P C is
in use.
Total track no.
included in the
disc
Total track no.
included in the disc
Total play time
EN13-33_KW-AVX800A_f.indd 15EN13-33_KW-AVX800A_f.indd 15 07.2.14 3:27:23 PM07.2.14 3:27:23 PM

16
Track no./Playing time
Only for CD Text *5
Folder no./Track no./Playing time
Audio format
(MP3/WMA/WAV/AAC)
☞ page 19
*2 Search speed: x2 ] x10.
*5 “No Name” appears for conventional CDs.
Tag data appears
only when it is
recorded
Sound mode *3
(☞ page 48)
☞ page 19
[3 / 8] Start and pause playback
[7] Stop playback
[4 ¢] Press: Select track
Hold: Reverse/forward search*2
[5 ∞] Press: Select folder
Hold: Display Folder list
[3 / 8] Start and pause playback
[7] Stop playback
[4 ¢] Press: Select track
Hold: Reverse/forward search*2
Total track no.
included in the disc
Total play time
Total track no. included in the disc
Speaker/signal
indicators
(☞ page 61)
• While playing a DTS-CD
DTS indicator
EN13-33_KW-AVX800A_f.indd 16EN13-33_KW-AVX800A_f.indd 16 07.2.14 3:27:25 PM07.2.14 3:27:25 PM

OPERATIONS
17
Touch the screen (center portion).
Operation buttons on the monitor screen
You can display the following operation buttons while watching the playback pictures on the monitor.
• While the operation buttons are displayed, aspect ratio is fixed to Full> (☞ page 52).
• If no operation is done for about 5 seconds, the operation buttons disappears (except when a disc menu is
displayed).
Touch [KEY].
*
Touch [KEY].
Touch [KEY].
☞ pages 20 to 22 on how the operation buttons
particularly work for a variety of the discs
To erase the operations, touch the screen again.
A
[SOURCE] Display the Source Menu>
[AV MENU] Display the AV Menu>
[S ORT CUT] Display the Short Cut buttons
[3 / 8] Start and pause playback
[7] Stop playback
[4 ¢] Press: Select track
Hold: Reverse/forward search
[5 ∞] Select folders
• The above buttons also work when they are not shown on
the touch panel (while watching pictures on the screen).
* While a disc menu is played back for DVD, [KEY] is
automatically displayed. On the disc menu, you can select a
menu item directly by touchin it on the screen.
B
For DVD/VCD/DivX menu operation playback
[2 3 5 ∞] Select the menu items
[ENT] Confirm the selection
[TOP MENU] Display the disc menu
[MENU] Display the disc menu
[RETURN] Return to the previous menu or display the
menu (only for VCD with PBC)
C
For entering the numbers
[DIRECT CLR] Switch between chapter/track entry and
title/group/folder entry
Erase the last entry when you enter a wrong
number
[0]–[9]=[ENT] Enter the number
Ex. To enter “105”: press [1], [0], [5], then [ENT]
EN13-33_KW-AVX800A_f.indd 17EN13-33_KW-AVX800A_f.indd 17 07.2.15 10:57:24 AM07.2.15 10:57:24 AM

18
1
• You can also use AV MENU on the monitor panel.
2
3
When one of the playback modes is selected, the
corresponding indicator lights up on the source
information screen.
To cancel, select <Off>.
Selectin playback modes
You can use only one of the following playback modes—Intro/Repeat/Random.
Ex. To select Track Repeat
Disc type Intro Repeat Random
—
Chapter: Repeats current
chapter
Title: Repeats current title
—
—Track: Repeats current track —
—
Chapter: Repeats current
chapter
Pro ram: Repeats current
program (not available for
Playlist playback).
—
Track: Plays the first 15
seconds of each track (for
VCD: P C not in use)
Track: Repeats current track*1
(for VCD: P C not in use)
Disc (All): Randomly plays all
tracks (for VCD: P C not
in use)
Track: Plays the first 15
seconds of each track
Folder: Plays the first 15
seconds of the first track of
each folder
Track: Repeats current track*1
Folder: Repeats all tracks of
the current folder
Folder: Randomly plays all
tracks of current folder,
then tracks of next folders
Disc (All): Randomly plays all
tracks
—
Track: Repeats current track
Folder: Repeats current folder —
—Folder: Repeats current folder —
*1 You can also use [SHORT CUT] to turn on and off Trac Repeat
EN13-33_KW-AVX800A_f.indd 18EN13-33_KW-AVX800A_f.indd 18 07.2.14 3:27:31 PM07.2.14 3:27:31 PM

OPERATIONS
19
Selectin tracks on the list
If a disc includes folders, you can display the Folder/
Track (File) Lists, then start playback.
1
• You can also use AV MENU on the monitor panel.
2
3 Select a folder (1), then a track (2).
Selected track starts playing. (* Press to move to
the previous/next pages of the list)
1 Current folder list number/total folder list
number
2 Current track list number/total track list
number of the current folder
• Track List can also be accessed by pressing DISP
on the monitor panel.
Selected track starts playing.
Prohibitin disc ejection
You can lock a disc in the loading slot.
To cancel the prohibition, repeat the same
procedure to select <EJECT OK?>.
Usin Short Cut Icons
You can easily access the some frequently used
functions by using [SHORT CUT] on the touch panel.
1
• You can also use AV MENU on the monitor panel.
2
• For video software:
• For audio software:
at the same time
Sound mode
(☞ page 48)
Turn on or off Track Repeat
(Repeat play: ☞ page 18)
Aspect ratio
(☞ page 52)
Surround
(☞ page 24)
EN13-33_KW-AVX800A_f.indd 19EN13-33_KW-AVX800A_f.indd 19 07.2.14 3:27:33 PM07.2.14 3:27:33 PM

20
Operations usin the remote controller—RM-RK251
*1 Erases the misentry of the
number.
*2 Search speed: x2 ] x5 ]
x10 ] x20 ] x60
*3 Slow motion speed: 1/32 ]
1/16 ] 1/8 ] 1/4 ] 1/2
*4 Search speed: x2 ] x10
*5 Search speed: ¡1 ]
¡2 ] ¡3
*6 Search speed: ¡1 ]
¡2
: Stop playback.
: Start playback/pause (if pressed during playback).
: Reverse/forward search*2. (No sound can be heard.)
(Slow motion*3 during pause. No sound can be heard.)
: Press: Select chapter (during playback or pause).
Hold: Reverse/forward search*4.
: Select title (during playback or pause).
Usin menu driven
features
1
2 Select an item you want
to start play.
3
= = :
Select chapter.
Select title (when not playing).
(twice) = = :
Select title (during playback or pause).
: Select aspect ratio.
: Select audio language.
: Select subtitle language.
: Select view angle.
= = :
Select track.
(twice) = = :
Select group.
: Select aspect ratio.
: Select audio stream.
Usin menu driven
features
1
2 Select an item you want
to start play.
3
*1
: Stop playback.
: Start playback/pause (if pressed during playback).
: Reverse/forward search*2.
: Press: Select track.
Hold: Reverse/forward search*4.
: Select group.
EN13-33_KW-AVX800A_f.indd 20EN13-33_KW-AVX800A_f.indd 20 07.2.14 3:27:35 PM07.2.14 3:27:35 PM
