SERVICE MANUAL
COPYRIGHT © 2009 Victor Company of Japan, Limited No.YA697<Rev.001>
2009/5
INTEGRATED DIGITAL TERRESTRIAL/SATELLITE LCD TELEVISION
YA697<Rev.001>20095SERVICE MANUAL
LT-19DB1BU/AX
COPYRIGHT © 2009 Victor Company of Japan, Limited
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14

1-2 (No.YA697<Rev.001>)
Design & specifications are subject to change without notice.
Items Contents
Dimensions ( W ×H ×D ) 47.0 cm ×36.70 cm ×16.0 cm [47.0 cm ×33.5 cm ×7.3 cm (Without stand)]
Mass 5.6 kg [4.8 kg (Without stand)]
Power Input AC220V - AC240 V, 50 Hz
Power Consumption 50 W (Standby: 0.7 W)
TV RF System Analog CCIR (B/G, I, D/K, L)
Digital DVB-T / DVB-S
Colour System PAL, SECAM, NTSC 3.58/4.43 [EXT only]
Stereo System NICAM (B/G, I, D/K, L), A2 (B/G, D/K)
Receiving
Frequency
Analog VHF: 45.25 MHz - 470MHz
UHF: 470 MHz - 855.25 MHz
CATV: 116MHz - 172MHz / 220MHz - 469MHz
Digital Terrestrial: 7 MHz ~ 858 MHz(UHF), 77.5MHz ~ 6.5MHz (VHF)
Satellite: 950 MHz - 2150 MHz
Intermediate
Frequency
VIF 38.9MHz (B/G, I, D/K, L)
SIF 33.4MHz (5.5MHz:B/G)
32.9MHz (6.0MHz:I)
32.4MHz (6.5MHz:D/K)
Colour Sub
Carrier Frequency
PAL 4.43MHz
SECAM 4.40625MHz / 4.25MHz
NTSC 3.58MHz / 4.43MHz
Teletext System Analog FLOF (Fastext), TOP
Digital EBU TEXT
LCD panel 19-inch wide aspect (16 : 9)
Screen Size Diagonal : 48.0 cm (H: 40.8 cm ×V: 25.5 cm)
Display Pixels Horizontal : 1366 dots ×Vertical : 768 dots
Audio Power Output 3 W + 3 W
Speaker 3.0 cm ×11.0 cm, oval type ×2
Aerial terminal (VHF/UHF/BS) 75 Ωunbalanced, coaxial ×2
EXT-1 (Input/Output) 21-pin Euro connector (SCART socket ) ×1
EXT-3
(Input)
Component Video
750p / 1125i
625p / 525p / 625i / 525i
RCA pin jack ×3
Y: 1 V (p-p) (Sync signal: ±0.35V(p-p), 3-value sync.), 75Ω/ Pb/Pr: ±0.35V(p-p), 75 Ω
Y: 1 V (p-p), Positive (Negative sync.), 75 Ω/ Cb/Cr: 0.7V(p-p), 75 Ω
Audio 500 mV(rms) (-4dBs), high impedance, RCA pin jack ×2
EXT-4
(Input)
S-Video Mini-DIN 4 pin ×1
Y: 1 V (p-p), Positive (Negative sync provided), 75 Ω
C: 0.286 V (p-p) (Burst signal), 75 Ω
Video 1V (p-p), Positive (Negative sync provided), 75 Ω, RCA pin jack ×1
Audio 500 mV (rms), High impedance, RCA pin jack ×2
EXT-5 / EXT-6
(Digital Input)
Video / Audio HDMI 2-row 19pin connector ×2
(Digital-input terminal is not compatible with picture signals of personal computer)
• 576i(625i),576p(625p),480i(525i),480p(525p),720p(750p),1080i(1125i) signals are
available.
• All HDMI inputs support DVI video but only first HDMI input (EXT-5) supports DVI audio
through component audio input (EXT-2 or EXT-3).
PC (RGB) Input Video D-sub 15 pin ×1
R/G/B : 0.7 V (p-p), 75Ω
HD / VD : 1 V (p-p) to 5 V (p-p), high impedance
Audio 3.5 mm stereo mini jack ×1
Digital Audio Optical Output Digital SPDIF ×1
Headphone 3.5 mm stereo mini jack ×1
Remote Control Unit RM-C2503 (AAA/R03 dry cell battery ×2)

(No.YA697<Rev.001>)1-3
SECTION 1
PRECAUTION
1.1 SAFETY PRECAUTIONS
(1) The design of this product contains special hardware,
many circuits and components specially for safety
purposes. For continued protection, no changes should be
made to the original design unless authorized in writing by
the manufacturer. Replacement parts must be identical to
those used in the original circuits. Service should be
performed by qualified personnel only.
(2) Alterations of the design or circuitry of the products should
not be made. Any design alterations or additions will void
the manufacturer's warranty and will further relieve the
manufacturer of responsibility for personal injury or
property damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These
characteristics are often not evident from visual inspection
nor can the protection afforded by them necessarily be
obtained by using replacement components rated for
higher voltage, wattage, etc. Replacement parts which
have these special safety characteristics are identified in
the parts list of Service manual. Electrical components
having such features are identified by shading on the
schematics and by ( ) on the parts list in Service
manual. The use of a substitute replacement which does
not have the same safety characteristics as the
recommended replacement part shown in the parts list of
Service manual may cause shock, fire, or other hazards.
(4) Don't short between the LIVE side ground and
ISOLATED (NEUTRAL) side ground or EARTH side
ground when repairing.
Some model's power circuit is partly different in the GND.
The difference of the GND is shown by the LIVE : ( ) side
GND, the ISOLATED (NEUTRAL) : ( ) side GND and
EARTH : ( ) side GND.
Don't short between the LIVE side GND and ISOLATED
(NEUTRAL) side GND or EARTH side GND and never
measure the LIVE side GND and ISOLATED (NEUTRAL)
side GND or EARTH side GND at the same time with a
measuring apparatus (oscilloscope etc.). If above note will
not be kept, a fuse or any parts will be broken.
(5) When service is required, observe the original lead dress.
Extra precaution should be given to assure correct lead
dress in the high voltage circuit area. Where a short circuit
has occurred, those components that indicate evidence of
overheating should be replaced. Always use the
manufacturer's replacement components.
(6) Isolation Check (Safety for Electrical Shock Hazard)
After re-assembling the product, always perform an isola-
tion check on the exposed metal parts of the cabinet (an-
tenna terminals, video/audio input and output terminals,
Control knobs, metal cabinet, screw heads, earphone jack,
control shafts, etc.) to be sure the product is safe to operate
without danger of electrical shock.
a) Dielectric Strength Test
The isolation between the AC primary circuit and all metal
parts exposed to the user, particularly any exposed metal
part having a return path to the chassis should withstand a
voltage of 3000V AC (r.m.s.) for a period of one second. (.
. . . Withstand a voltage of 1100V AC (r.m.s.) to an appli-
ance rated up to 120V, and 3000V AC (r.m.s.) to an appli-
ance rated 200V or more, for a period of one second.)
This method of test requires a test equipment not generally
found in the service trade.
b) Leakage Current Check
Plug the AC line cord directly into the AC outlet (do not use
a line isolation transformer during this check.). Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal part of the cabinet, particularly
any exposed metal part having a return path to the chassis,
to a known good earth ground (water pipe, etc.). Any leak-
age current must not exceed 0.5mA AC (r.m.s.).
However, in tropical area, this must not exceed 0.2mA AC
(r.m.s.).
Alternate Check Method
Plug the AC line cord directly into the AC outlet (do not
use a line isolation transformer during this check.). Use
an AC voltmeter having 1000Ωper volt or more
sensitivity in the following manner. Connect a 1500Ω
10W resistor paralleled by a 0.15µF AC-type capacitor
between an exposed metal part and a known good earth
ground (water pipe, etc.). Measure the AC voltage
across the resistor with the AC voltmeter. Move the
resistor connection to each exposed metal part,
particularly any exposed metal part having a return path
to the chassis, and measure the AC voltage across the
resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Any voltage measured must
not exceed 0.75V AC (r.m.s.). This corresponds to
0.7mA AC (r.m.s.).
However, in tropical area, this must not exceed 0.35V
AC (r.m.s.). This corresponds to 0.3mA AC (r.m.s.).
AC VOLTMETER
(HAVING 1000 /V,
OR MORE SENSITIVITY)
PLACE THIS PROBE
ON EACH EXPOSED
METAL PART
1500 10W
0.15 F AC-TYPE
GOOD EARTH GROUND

1-4 (No.YA697<Rev.001>)
1.2 INSTALLATION
1.2.1 HEAT DISSIPATION
If the heat dissipation vent behind this unit is blocked, cooling
efficiency may deteriorate and temperature inside the unit will
rise. The temperature sensor that protects the unit will be
activated when internal temperature exceeds the pre-determined
level and power will be turned off automatically.Therefore,
please make sure pay attention not to block the heat dissipation
vent as well as the ventilation outlet behind the unit and ensure
that there is room for ventilation around it.
1.2.2 NOTES ON HANDLING
When taking the unit out of a packing case, do not grasp the
upper part of the unit. If you take the unit out while grasping the
upper part, the LCD PANEL may be damaged because of a
pressure. Instead of grasping the upper part, put your hands on
the lower backside or sides of the unit.
1.2.3 INSTALLATION REQUIREMENTS
Ensure that the minimal distance is maintained, as specified
below, between the unit with and the surrounding walls, as well
as the floor etc.Install the unit on stable flooring or stands.
To ensure safety in an emergency such as an earthquake, and
to prevent accidents, ensure that measures are taken to prevent
the TV dropping or falling over.
Ventilation hole
*Diagram differs from actual appearance.
*Diagram differs from actual appearance.
200 mm
150 mm 50 mm 150 mm 50 mm
It fixes in a band.
TV STAND
*Diagram differs from actual appearance.

(No.YA697<Rev.001>)1-5
1.3 HANDLING LCD PANEL
1.3.1 PRECAUTIONS FOR TRANSPORTATION
When transporting the unit, pressure exerted on the internal LCD
panel due to improper handling (such as tossing and dropping)
may cause damages even when the unit is carefully packed. To
prevent accidents from occurring during transportation, pay
careful attention before delivery, such as through explaining the
handling instructions to transporters.
Ensure that the following requirements are met during
transportation, as the LCD panel of this unit is made of glass and
therefore fragile:
(1) USE A SPECIAL PACKING CASE FOR THE LCD PANEL
When transporting the LCD panel of the unit, use a special
packing case (packing materials). A special packing case
is used when a LCD panel is supplied as a service spare
part.
(2) ATTACH PROTECTION SHEET TO THE FRONT
Since the front (display part) of the panel is vulnerable,
attach the protection sheet to the front of the LCD panel
before transportation. Protection sheet is used when a LCD
panel is supplied as a service spare part.
(3) AVOID VIBRATIONS AND IMPACTS
The unit may be broken if it is toppled sideways even when
properly packed. Continuous vibration may shift the gap of
the panel, and the unit may not be able to display images
properly. Ensure that the unit is carried by at least 2
persons and pay careful attention not to exert any vibration
or impact on it.
(4) DO NOT PLACE EQUIPMENT HORIZONTALLY
Ensure that it is placed upright and not horizontally during
transportation and storage as the LCD panel is very
vulnerable to lateral impacts and may break. During
transportation, ensure that the unit is loaded along the
traveling direction of the vehicle, and avoid stacking them
on one another. For storage, ensure that they are stacked
in 2 layers or less even when placed upright.
1.3.2 OPTICAL FILTER (ON THE FRONT OF THE LCD PANEL)
(1) Avoid placing the unit under direct sunlight over a
prolonged period of time. This may cause the optical filter
to deteriorate in quality and COLOUR.
(2) Clean the filter surface by wiping it softly and lightly with a
soft and lightly fuzz cloth (such as outing flannel).
(3) Do not use solvents such as benzene or thinner to wipe the
filter surface. This may cause the filter to deteriorate in
quality or the coating on the surface to come off. When
cleaning the filter, usually use the neutral detergent diluted
with water. When cleaning the dirty filter, use water-diluted
ethanol.
(4) Since the filter surface is fragile, do not scratch or hit it with
hard materials. Be careful enough not to touch the front
surface, especially when taking the unit out of the packing
case or during transportation.
1.3.3 PRECAUTIONS FOR REPLACEMENT OF EXTERIOR
PARTS
Take note of the following when replacing exterior parts (REAR
COVER, FRONT PANEL, etc.):
(1) Do not exert pressure on the front of the LCD panel (filter
surface). It may cause irregular COLOUR.
(2) Pay careful attention not to scratch or stain the front of the
LCD panel (filter surface) with hands.
(3) When replacing exterior parts, the front (LCD panel) should
be placed facing downward. Place a mat, etc. underneath
to avoid causing scratches to the front (filter surface).

1-6 (No.YA697<Rev.001>)
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
2.1 FEATURES
DIGITAL TUNER
This TV can receive both DVB-T (Digital terrestrial broadcasting),
DVB-S(Digital satellite broadcasting), and Analogue terrestrial
broadcasting.
HDMI INPUT
By connecting a HDMI compatible device, high definition
pictures can be displayed on your TV in their digital form.
PICTURE MODE
This function can adjust the picture settings automatically.
There are BRIGHT, STANDARD, SOFT and MANUAL in the
PICTURE MODE.
ZOOM
This function can change the screen size according to the
picture aspect ratio.
3D CINEMA SURROUND
You can enjoy sounds with a wider ambience.
2.2 21-PIN EURO CONNECTOR (SCART) : EXT-1 / EXT-2
(P-P= Peak to Peak, B-W= Blanking to white peak)
Pin No. Signal designation Matching value EXT-1 EXT-2
1 AUDIO R output 500mV(rms) (Nominal), Low impedance Used (TV OUT) Used (LINE OUT)
2 AUDIO R input 500mV(rms) (Nominal), High impedance Used (R1) Used (R2)
3 AUDIO L output 500mV(rms) (Nominal), Low impedance Used (TV OUT) Used (LINE OUT)
4 AUDIO GND Used Used
5 GND (B) Used Used
6 AUDIO L input 500mV(rms) (Nominal), High impedance Used (L1) Used (L2)
7 B input 700mV(B-W), 75ΩUsed Not used
8 FUNCTION SW
(SLOW SW)
Low : 0V-3V
High : 8V-12V, High impedance
Used Used
9 GND (G) Used Used
10 SCL Not used Used (SCL2)
11 G input 700mV(B-W), 75ΩUsed Not used
12 SDA Not used Used (SDA2)
13 GND (R) Used Used
14 GND (YS) Used Not used
15 R / C input R : 700mV(B-W), 75Ω
C : 300mV(P-P), 75ΩUsed (R) Used (C2)
16 Ys input (FAST SW) Low : 0V-0.4V, High : 1V-3V, 75ΩUsed Not used
17 GND (VIDEO output) Used Used
18 GND (VIDEO input) Used Used
19 VIDEO output 1V(P-P) (Negative sync), 75ΩUsed (TV OUT) Used (LINE OUT)
20 VIDEO / Y input 1V(P-P) (Negative sync), 75ΩUsed Used
21 COMMON GND Used Used
20 18 16 14 12 10 8 6 4 2
21 19 17 15 13 11 9 7 5 3 1
[Pin assignment]

(No.YA697<Rev.001>)1-7
2.3 TECHNICAL INFORMATION
2.3.1 LCD PANEL
This unit uses the flat type LCD (Liquid Crystal Display) panel that occupies little space, instead of using the conventional
CRT(Cathode Ray Tube). This panel adopts "normally white" mode where the transmittance or reflective rate is maximum, and the
screen is white when no voltage is applied.
2.3.1.1 SPECIFICATIONS
The following table shows the specifications of this unit.
2.3.1.2 PIXEL FAULT
There are three pixel faults - bright fault , dark fault and flicker fault - that are respectively defined as follows.
BRIGHT FAULT
In this pixel fault, a cell that should not light originally is lighting on and off.
For checking this pixel fault, input ALL BLACK SCREEN and find out the cell that is lighting on and off.
DARK FAULT
In this pixel fault, a cell that should light originally is not lighting or lighting with the brightness twice as brighter as originally lighting.
For checking this pixel fault, input 100% of each R/G/B colour and find out the cell that is not lighting.
FLICKER FAULT
In the pixel fault, a cell that should light originally or not light originally is flashing on and off.
For checking this pixel fault, input ALL BLACK SCREEN signal or 100% of each RGB colour and find out the cell that is flashing on
and off.
Item Specifications
Maximum dimensions ( W ×H ×D ) 430.37 mm ×254.60 mm ×16.5 mm
Weight 2.0 kg
Effective screen size Diagonal : 48.0 cm (H: 40.8 cm ×V: 25.5 cm)
Aspect ratio 16 : 9
Drive device / system a-Si-TFT active matrix system
Resolution Horizontally 1366 ×Vertically 768 ×RGB < W-XGA > 3147264 dots in total
Pixel pitch (pixel size) Horizontally: 0.300 mm, Vertically: 0.300 mm
Displayed color 16777216 colors 256 colors for R G and B
Brightness 300 cd/m2
Contrast ratio 1000 : 1
Response time ( G to G ) less than 5 ms
View angle (Horizontally) 178°
View angle (Vertically) 178°
Surface polarizer Anti-Glare type Low reflective coat
Color filter Vertical stripe
Backlight Cold cathode fluorescent lamp
Power supply voltage in LCD 5 V
Panel interface system LVDS (Low Voltage Differential Signaling)

1-8 (No.YA697<Rev.001>)
SECTION 3
DISASSEMBLY
3.1 CAUTION AT DISASSEMBLY
• Make sure that the power cord is disconnected from the outlet.
• Pay special attention not to break or damage the parts.
• Make sure that there is no bent or stain on the connectors before inserting, and firmly insert the connectors.
• Be sure to reattach the wire clamps removed during the procedure to the original positions. (Attaching the wire clamps in wrong
positions may affect the performance.)
REFERENCE:
When removing each board, remove the connector if necessary. The operation is easier if you write down the connection points
(connector numbers) of the connector. For connection of each board, refer to the "WIRING DIAGRAM" of the Standard Circuit
Diagram.
3.2 DISASSEMBLY PROCEDURE
3.2.1 REMOVING THE REAR COVER (Fig.3-1)
(1) Remove the 2 screws [A].
(2) Remove the CORD GUIDE.
(3) Remove the 4 screws [B] and 2 screws [C].
(4) Remove the REAR COVER.
3.2.2 REMOVING THE POWER UNIT (Fig.3-1)
• Remove the REAR COVER.
(1) Remove the 4 screws [D].
(2) Remove the POWER UNIT.
3.2.3 REMOVING THE MAIN PWB (Fig.3-1)
• Remove the REAR COVER.
(1) Remove the 2 screws [E].
(2) Remove the SIDE SHIELD.
(3) Remove the 6 screws [F].
(4) Remove the MAIN PWB.
3.2.4 REMOVING THE KEY PWB (Fig.3-1)
• Remove the REAR COVER.
(1) Remove the 2 screws [G].
(2) Remove the CONTROL BASE and KEY PWB together.
(3) Remove the 2 screws [H].
(4) Remove the KEY PWB from the CONTROL BASE.
3.2.5 REMOVING THE SPEAKER (Fig.3-1)
• Remove the REAR COVER.
(1) Remove the 4 screws [J].
(2) Remove the SPEAKER(L/R).
3.2.6 REMOVING THE IR PWB (Fig.3-1)
• Remove the REAR COVER.
(1) Remove the 1 screw [K].
(2) Remove the IR PWB.
3.2.7 REMOVING THE STAND (Fig.3-1)
• Remove the 2 screws [C] if the REAR COVER is not removed.
(1) Remove the 2 screws [L].
(2) Remove the STAND.
3.2.8 REMOVING THE BLUE LED MODULE (Fig.3-1)
• Remove the REAR COVER.
• Remove the STAND.
(1) Remove the 4 screws [M].
(2) Remove the FRONT BRACKET.
(3) Remove the BLUE LED MODULE.
3.2.9 REMOVING THE LCD PANEL UNIT (Fig.3-1)
• Remove the REAR COVER.
• Remove the STAND.
(1) Remove the 6 screws [N].
(2) Remove the MAIN SHIELD and LCD PANEL UNIT
together.
(3) Remove the 4 screws [P].
(4) Remove the LCD PANEL UNIT.

(No.YA697<Rev.001>)1-9
Fig.3-1
P
J
J
K
G
H
F
B
E
D
N
N
A
C
FRONT CABINET
LCD PANEL
POWER UNIT
MAIN
SHEILD
REAR COVER
CORD GUIDE
BLUE LED MODULE
KEY PWB
CONTROL KNOB
CONTROL BASE
IR PWB
SIDE SHIELD
MAIN PWB
L
M
STAND
FRONT BRACKET

1-10 (No.YA697<Rev.001>)
3.3 MEMORY IC REPLACEMENT
• This model uses the memory IC.
• This memory IC stores data for proper operation of the video and drive circuits.
• When replacing, be sure to use an IC containing this (initial value) data.
3.3.1 MEMORY IC REPLACEMENT PROCEDURE
1. Power off
Switch off the power and disconnect the power plug from the AC outlet.
2. Replace the memory IC
Be sure to use the memory IC written with the initial setting values.
3. Power on
Connect the power plug to the AC outlet and switch on the power.
4. Receiving channel setting
Refer to the OPERATING INSTRUCTIONS and set the receive channels (Channels Preset) as described.
5. User setting
Check the user setting items according to the given in page later. Where these do not agree, refer to the OPERATING
INSTRUCTIONS and set the items as described.
6. FACTORY MODE setting
Verify what to set in the FACTORY MODE, and set whatever is necessary.
3.3.2 FACTORY MODE SETTING
FACTORY MODE SCREEN SETTING ITEM
FACTORY MODE SCREEN
Factory Menu
ADC Calibration
White Balance
Miscellaneous
Engineering Menu
Panel Select xxxxxxxxxxx
Factry Default
Model Name : xxxxxx
Software Version : xxxxxx
OTA Loader Version : xxxxxx
MCU Version : xxxxxx
System Version : xxxxxx
Kernel Version : xxxxxx
Boot Loader Version : xxxxxx
Update Date : xxxxxx
Setting items Settings
ADC Calibration [Do not adjust]
White Balance Adjust
Miscellaneous [Do not adjust]
Engineering Menu [Do not adjust]
Panel Select [Do not adjust]
Factory Default ---

(No.YA697<Rev.001>)1-11
3.3.3 SETTINGS OF FACTORY SHIPMENT
3.3.3.1 BUTTON OPERATION 3.3.3.2 REMOTE CONTROL DIRECT OPERATION
3.3.3.3 REMOTE CONTROL MENU OPERATION
(1) Picture
(2) Sound
(3) Installation
(4) Feature
Setting item Setting position
POWER Off
CHANNEL PR1
VOLUME 10
AV TV
Setting item Setting position
CHANNEL PR1
VOLUME 10
ZOOM AUTO
SUB POWER OFF
Setting item Setting position
Mode Bright
Colour Temperature Cool
Noise Reduction Low
Fleshtone Off
24p Cinema On
Setting item Setting position
Bass 0
Treble 0
Balance 0
Auto Volume Control Off
Digital Audio Output PCM
3D Cinema surround Off
TV Speaker On
Setting item Setting item Setting position
Terrestrial Channel
Search
Antenna Power Off
Auto Channel
Numbering
Enable
Satellite Channel
Search
Antenna Type LNB Only
Software Update ---
Edit Channel List ---
Edit Favourite List ---
Signal Detection ---
Setting item Setting position
Language Setting Menu Language English
Audio Language German
Subtitle Language German
Subtitle Display Auto
Subtitle Font Variable
Audio Description Off
Time Setting Date --/--/20--
Local Time --:--
Sleep Timer Off
Power On Timer Off
Channel ---
Volume 20
Power Off Timer Off
Auto Shut Off Off
Parental Control Child Lock Disable
Maturity Rating View All
Change PIN Code ---
PC ---
Other Settings Zoom Auto
4 : 3 Aspect Setting Panoramic
OSD Transparency 30%
Blue Back Off
Power Lamp On
Control with HDMI On

1-12 (No.YA697<Rev.001>)
3.4 REPLACEMENT OF CHIP COMPONENT
3.4.1 CAUTIONS
(1) Avoid heating for more than 3 seconds.
(2) Do not rub the electrodes and the resist parts of the pattern.
(3) When removing a chip part, melt the solder adequately.
(4) Do not reuse a chip part after removing it.
3.4.2 SOLDERING IRON
(1) Use a high insulation soldering iron with a thin pointed end of it.
(2) A 30w soldering iron is recommended for easily removing parts.
3.4.3 REPLACEMENT STEPS
1. How to remove Chip parts
[Resistors, capacitors, etc.]
(1) As shown in the figure, push the part with tweezers and
alternately melt the solder at each end.
(2) Shift with the tweezers and remove the chip part.
[Transistors, diodes, variable resistors, etc.]
(1) Apply extra solder to each lead.
(2) As shown in the figure, push the part with tweezers and
alternately melt the solder at each lead. Shift and remove
the chip part.
NOTE :
After removing the part, remove remaining solder from the
pattern.
2. How to install Chip parts
[Resistors, capacitors, etc.]
(1) Apply solder to the pattern as indicated in the figure.
(2) Grasp the chip part with tweezers and place it on the
solder. Then heat and melt the solder at both ends of the
chip part.
[Transistors, diodes, variable resistors, etc.]
(1) Apply solder to the pattern as indicated in the figure.
(2) Grasp the chip part with tweezers and place it on the
solder.
(3) First solder lead Aas indicated in the figure.
(4) Then solder leads Band C.
SOLDER SOLDER
A
B
C
A
B
C

(No.YA697<Rev.001>)1-13
SECTION 4
ADJUSTMENT
4.1 ADJUSTMENT PREPARATION
(1) This TV is adjusted by using REMOTE CONTROL UNIT.
(2) The adjustment using the REMOTE CONTROL UNIT is made on the basis of the initial setting values. The setting values
which adjust the screen to the optimum condition can be different from the initial setting values.
(3) Make sure that connection is correctly made AC to AC power source.
(4) Turn on the power of the TV and measuring instruments for warming up for at least 30 minutes before starting adjustments.
(5) If the receive or input signal is not specified, use the most appropriate signal for adjustment.
(6) Never touch the parts (such as variable resistors, transformers and condensers) not shown in the adjustment items of this service
adjustment.
4.2 PRESET SETTING BEFORE ADJUSTMENTS
Unless otherwise specified in the adjustment items, preset the
following functions with the REMOTE CONTROL UNIT.
4.3 MEASURING INSTRUMENT AND FIXTURES
• Signal generator (Pattern generator)[PAL]
• Remote control unit
4.4 ADJUSTMENT ITEMS
VIDEO CIRCUIT
• WHITE BALANCE adjustment
4.5 BASIC OPERATION OF FACTORY MODE
4.5.1 HOW TO ENTER THE FACTORY MODE
(1) Press [INFORMATION] key and [MUTING] key on the
remote control unit simultaneously to enter the FACTORY
MODE SCREEN. (Fig.4-1)
4.5.2 HOW TO EXIT THE FACTORY MODE
Press the [OK] key to exit the factory mode.
4.5.3 CHANGE AND MEMORY OF SETTING VALUE
SELECTION OF SETTING ITEM
•[FUNCTION /] key.
For scrolling up / down the setting items.
•[FUNCTION /]key.
For select the setting items.
CHANGE OF SETTING VALUE (DATA)
•[FUNCTION /]key.
For scrolling up / down the setting values.
MEMORY OF SETTING VALUE (DATA)
The setting value will be stored automatically when release the
REMOTE CONTROL UNIT keys.
4.5.4 FACTORY MODE SELECT KEY LOCATION
4.6 SETTING ITEM IN THE FACTORY MODE
Setting item Settings position
Picture Mode Standard
Colour Temperature Normal
Fig.4-1
FACTORY MODE SCREEN
Factory Menu
ADC Calibration
White Balance
Miscellaneous
Engineering Menu
Panel Select xxxxxxxxxxx
Factry Default
Model Name : xxxxxx
Software Version : xxxxxx
OTA Loader Version : xxxxxx
MCU Version : xxxxxx
System Version : xxxxxx
Kernel Version : xxxxxx
Boot Loader Version : xxxxxx
Update Date : xxxxxx
[FUNCTION /] key
[Function/] key
[MUTING] key +
[INFORMATION] key
Enter The Factry Mode.
Scrolling up / down the
setting value. Select the setting item.

(No.YA697<Rev.001>)
VSE
Printed in Japan
4.7 ADJUSTMENT PROCEDURE
4.7.1 VIDEO CIRCUIT
SECTION 5
TROUBLESHOOTING
This service manual does not describe TROUBLESHOOTING.
Item Measuring
instrument Test point Adjustment part Description
WHITE
BALANCE
Remote
control unit
Signal
generator
[White Balance]
Normal R
Normal G
Normal B
(1) Set COLOUR TEMP. to "Normal".
(2) Enter the FACTRY MODE.
(3) Press []/ []key on the remote control unit
simultaneously to select the White balance.
(4) Press []key on the remote control unit
simultaneously to enter White balnce mode.
(5) Receive a PAL 75% all white signal.
(6) Adjust the setting values of <Normal R>,
<Normal G> and <Normal B> so that the
screen becomes maximum white.
NOTE:
When the normal mode is adjusted, other modes
(cool/ warm) are automatically adjusted.
WHITE BALANCE MODE
White Balance
Color Temp Normal
R XX
G XX
B XX
FACTORY MODE SCREEN
Factory Menu
ADC Calibration
White Balance
Miscellaneous
Engineering Menu
Panel Select xxxxxxxxxxx
Factry Default
Model Name : xxxxxx
Software Version : xxxxxx
OTA Loader Version : xxxxxx
MCU Version : xxxxxx
System Version : xxxxxx
Kernel Version : xxxxxx
Boot Loader Version : xxxxxx
Update Date : xxxxxx
Victor Company of Japan, Limited
Display Division 12, 3-chome, Moriya-cho, Kanagawa-ku, Yokohama-city, Kanagawa-prefecture, 221-8528, Japan

(No.YA697<Rev.001>)3-1
PARTS LIST
CAUTION
JThe parts identified by the symbol are important for the safety . Whenever replacing these parts, be sure to use specified ones to secure the
safety.
JThe parts not indicated in this Parts List and those which are filled with lines --- in the Parts No. columns will not be supplied.
JP.W. BOARD Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. columns will be supplied.
ABBREVIATIONS OF RESISTORS, CAPACITORS AND TOLERANCES
RESISTORS CAPACITORS
CR Carbon Resistor C CAP. Ceramic Capacitor
FR Fusible Resistor E CAP. Electrolytic Capacitor
PR Plate Resistor M CAP. Mylar Capacitor
VR Variable Resistor CH CAP. Chip Capacitor
HV R High Voltage Resistor HV CAP. High Voltage Capacitor
MF R Metal Film Resistor MF CAP. Metalized Film Capacitor
MG R Metal Glazed Resistor MM CAP. Metalized Mylar Capacitor
MP R Metal Plate Resistor MP CAP. Metalized Polystyrol Capacitor
OM R Metal Oxide Film Resistor PP CAP. Polypropylene Capacitor
CMF R Coating Metal Film Resistor PS CAP. Polystyrol Capacitor
UNF R Non-Flammable Resistor TF CAP. Thin Film Capacitor
CH V R Chip Variable Resistor MPP CAP. Metalized Polypropylene Capacitor
CH MG R Chip Metal Glazed Resistor TAN. CAP. Tantalum Capacitor
COMP. R Composition Resistor CH C CAP. Chip Ceramic Capacitor
LPTC R Linear Positive Temperature Coefficient Resistor BP E CAP. Bi-Polar Electrolytic Capacitor
CH AL E CAP. Chip Aluminum Electrolytic Capacitor
CH AL BP CAP. Chip Aluminum Bi-Polar Capacitor
CH TAN. E CAP. Chip Tantalum Electrolytic Capacitor
CH AL BP E CAP. Chip Tantalum Bi-Polar Electrolytic Capacitor
RESISTORS
FGJ KMNRHZP
±1% ±2% ±5% ±10% ±20% ±30% +30%
-10%
+50%
-10%
+80%
-20%
+100%
-0%

3-2(No.YA697<Rev.001>)
CONTENTS
USING P.W. BOARD & REMOTE CONTROL UNIT ................................................................................................... 3-2
EXPLODED VIEW PARTS LIST ................................................................................................................................. 3-2
EXPLODED VIEW ....................................................................................................................................................... 3-3
PRINTED WIRING BOARD PARTS LIST ................................................................................................................... 3-4
MAIN P.W. BOARD ASS'Y (HU-71100004) ...................................................................................................... 3-4
IR P.W. BOARD ASS'Y (HU-72200001) .......................................................................................................... 3-10
KEY P.W. BOARD ASS'Y (HU-72200002) ...................................................................................................... 3-10
PACKING ................................................................................................................................................................... 3-11
PACKING PARTS LIST ............................................................................................................................................. 3-11
USING P.W. BOARD & REMOTE CONTROL UNIT
EXPLODED VIEW PARTS LIST
P.W.B ASS'Y name
P.W.B ASS'Y No.
LT-19DB1BU/AX
MAIN P.W.B HU-71100004
IR P.W.B HU-72200001
KEY P.W.B HU-72200002
REMOTE CONTROL UNIT HU-0320200064
Ref.No. Part No. Part Name Description Local
LV1 HU-0130100078 DIGITAL(LVDS) CABLE MAIN-LCD PANEL UNIT
1 HU-014213341 REAR COVER
2 HU-014213980 FRONT CABINET
3 QLD0612-001-HUP LCD PANEL UNIT HU-0141300050
5 HU-0321700006 SPEAKER 12Ω5W 2pcs 1set / Inc.SPEAKER WIRE
7 HU-0130000014 POWER CORD
8 HU-3010309003CO SIDE SHIELD
9 HU-3010123001 MAIN SHIELD
14 HU-3011605001CO FRONT BRACKET
16 HU-3022115001PN STAND BASE
17 HU-014213361 HINGE BRACKET
18 HU-014213350CO BASE BRACKET
20 HU-3029202001PN CORD GUIDE
21 HU-3025220001PN CONTROL KNOB
22 HU-3029406001PN GUIDE KNOB
29 HU-3029305001CO CI GUIDE
32 HU-0210000001 BLUE LED MODULE
50 HU-M1305301017 SCREW M3x10(x4)
51 HU-M1101301017 SCREW M3x10(x2)
52 HU-0130100006 E-HARNESS ASSY MAIN-KEY
53 HU-0130100008 E-HARNESS ASSY MAIN-IR
54 HU-0130100079 E-HARNESS ASSY MAIN-POWER UNIT
55 HU-M1308420815 SCREW M4x8(x4)
56 HU-M1110400817 SCREW M4x8(x4)
200 HU-0140300044 POWER UNIT
202 HU-71100004 MAIN PWB Not writing program data
203 HU-72200002 KEY PWB
210 HU-72200001 IR PWB

(No.YA697<Rev.001>)3-3
EXPLODED VIEW
LV1
29
53
52
56


50
20
1


54
7
200

202
16
5
5
55
32
210
22
9
21

3

2


203
8
51
55
18
17
14
56

3-4(No.YA697<Rev.001>)
PRINTED WIRING BOARD PARTS LIST
MAIN P.W. BOARD ASS'Y (HU-71100004)
 Ref No. Part No. Part Name Description Local
U21 HU-000140583 IC DC-DC CONV
U22 HU-000091030 IC LDO REGULATOR
U23 HU-000140581 IC DC-DC CONV
U24 HU-0000900001 IC REGULATOR
U25 HU-000090090 IC REGULATOR
U81 HU-000990055 IC VOLTAGE DETECTOR
U82 HU-000010610 IC MICOM
U104 HU-0003400001 IC USB
U112 HU-0004300002 IC SCALER&MPEG2
U113 ------------ IC Not supply
U181 ------------ IC Not supply
U182 HU-000120590 IC CMOS
U183 SN74LVC244APW-X IC CMOS
U184 HU-000120210 IC BICMOS
U185 SN74LVC244APW-X IC CMOS
U186 SN74LVC244APW-X IC CMOS
U187 SN74LVC244APW-X IC CMOS
U188 SN74LVC244APW-X IC CMOS
U321 HU-0000400008 IC DDR2
U322 HU-0000400008 IC DDR2
U381 HU-000380010 IC VIDEO SWITCH
U382 HU-000550010 IC VIDEO FILTER
U522 ------------ IC Not supply
U523 HU-000120630 IC CMOS
U551 HU-0002300003 IC HDMI SWITCH
U552 HU-000091100 IC REGULATOR
U661 HU-000300001 IC DUAL COMPARATOR
U662 HU-000060007 IC OP AMP
U761 HU-0001000001 IC AUDIO AMP
U763 HU-000091100 IC REGULATOR
U764 HU-000060510 IC HEADPHONE AMP
U831 HU-000170030 IC RS232 DRIVER
U851 SN74LVC244APW-X IC CMOS
U852 SN74LVC244APW-X IC CMOS
U853 SN74LVC244APW-X IC CMOS
U881 HU-000090090 IC REGULATOR
U882 HU-000091100 IC REGULATOR
U883 HU-000091100 IC REGULATOR
U884 HU-0000900004 IC REGULATOR
U885 HU-000091100 IC REGULATOR
U921 HU-0140400027 TUNER
U922 HU-0009000001 IC POWER SW
U961 HU-000270090 IC DEMODULATOR
U1021 HU-0140400029 TUNER
U1022 HU-000091120 IC REG
U1051 HU-000270080 IC QPSK
U1081 HU-0001800001 IC LNB
U1201 HU-000091100 IC REGULATOR
Q1 HU-004000410 TRANSISTOR
Q2 HU-004000390 TRANSISTOR
Q3 HU-004000390 TRANSISTOR
Q81 HU-004000260 FET
Q82 HU-004000260 FET
Q83 HU-004000410 TRANSISTOR
Q111 HU-004000410 TRANSISTOR
Q221 HU-004020030 MOS FET
Q222 HU-004000410 TRANSISTOR
Q452 HU-004000410 TRANSISTOR
Q453 HU-004020030 MOS FET
Q454 HU-004000410 TRANSISTOR
Q456 HU-004000410 TRANSISTOR
Q457 HU-004020030 MOS FET
Q521 HU-004000410 TRANSISTOR
Q652 HU-0040200002 FET
Q653 HU-004000410 TRANSISTOR
Q661 HU-004000410 TRANSISTOR
Q662 HU-004000410 TRANSISTOR
Q663 HU-004000390 TRANSISTOR
Q664 HU-004000017 TRANSISTOR
Q665 HU-004000017 TRANSISTOR
Q706 HU-004000017 TRANSISTOR
Q707 HU-004000017 TRANSISTOR
Q831 HU-004000260 FET
Q832 HU-004000260 FET
Q851 HU-004000410 TRANSISTOR
Q924 HU-004000260 FET
Q925 HU-004000260 FET
Q1100 HU-004000410 TRANSISTOR
D521 HU-003041002 SI DIODE
D522 HU-003041002 SI DIODE
D523 HU-003041002 SI DIODE
D524 HU-003040008 SI DIODE
D651 HU-003100001 DIODE
D1081 HU-003060190 DIODE
D1083 HU-0030000002 DIODE
D1084 HU-003060190 DIODE
D1085 HU-0330000002 DIODE
Z741 HU-003010053 Z DIODE
Z742 HU-003010053 Z DIODE
C1 HU-001071194 E CAPACITOR 100uF 25V
C2 HU-001060318 C CAPACITOR 0.1uF 50V
C3 HU-001071228 E CAPACITOR 470uF 16V
C4 HU-001060318 C CAPACITOR 0.1uF 50V
C6 HU-001071194 E CAPACITOR 100uF 25V
C7 HU-001060318 C CAPACITOR 0.1uF 50V
C8 HU-001060250 C CAPACITOR 0.1uF 16V K
C21 HU-001060309 C CAPACITOR 10uF 16V K
C22 HU-001060297 C CAPACITOR 0.01pF 50V K
C23 HU-001060309 C CAPACITOR 10uF 16V K
C24 HU-001060286 C CAPACITOR 10uF 10V
C25 HU-001060250 C CAPACITOR 0.1uF 16V K
C26 HU-001071194 E CAPACITOR 100uF 25V
C27 HU-001060274 C CAPACITOR 3300pF 50V
C29 HU-001060250 C CAPACITOR 0.1uF 16V K
C31 HU-001060309 C CAPACITOR 10uF 16V K
C33 HU-001060346 C CAPACITOR 1uF 16V K
C34 HU-001060250 C CAPACITOR 0.1uF 16V K
C41 HU-001060286 C CAPACITOR 10uF 10V
C42 HU-001060286 C CAPACITOR 10uF 10V
C43 HU-001060297 C CAPACITOR 0.01pF 50V K
C44 HU-001060312 C CAPACITOR 22uF 6.3V M
C45 HU-001060250 C CAPACITOR 0.1uF 16V K
C46 HU-001060250 C CAPACITOR 0.1uF 16V K
C47 HU-001071223 E CAPACITOR 100uF 16V
C48 HU-001060250 C CAPACITOR 0.1uF 16V K
C49 HU-001060250 C CAPACITOR 0.1uF 16V K
C51 HU-001071223 E CAPACITOR 100uF 16V
C52 HU-001060309 C CAPACITOR 10uF 16V K
C53 HU-001060250 C CAPACITOR 0.1uF 16V K
C54 HU-001060286 C CAPACITOR 10uF 10V
C55 HU-001060250 C CAPACITOR 0.1uF 16V K
C56 HU-001060250 C CAPACITOR 0.1uF 16V K
C57 HU-001071194 E CAPACITOR 100uF 25V
C59 HU-001060346 C CAPACITOR 1uF 16V K
C60 HU-001060250 C CAPACITOR 0.1uF 16V K
C61 HU-001060312 C CAPACITOR 22uF 6.3V M
C62 HU-001071194 E CAPACITOR 100uF 25V
C63 HU-001060309 C CAPACITOR 10uF 16V K
C64 HU-001060250 C CAPACITOR 0.1uF 16V K
C66 HU-001060297 C CAPACITOR 0.01pF 50V K
C67 HU-001060286 C CAPACITOR 10uF 10V
C68 HU-001060250 C CAPACITOR 0.1uF 16V K
C69 HU-001060250 C CAPACITOR 0.1uF 16V K
C81 HU-001060250 C CAPACITOR 0.1uF 16V K
C82 HU-001060250 C CAPACITOR 0.1uF 16V K
C83 HU-001060309 C CAPACITOR 10uF 16V K
C84 HU-001060250 C CAPACITOR 0.1uF 16V K
C85 HU-001060250 C CAPACITOR 0.1uF 16V K
C86 HU-001060250 C CAPACITOR 0.1uF 16V K
C88 HU-001063073 C CAPACITOR 20pF 50V J
C89 HU-001063073 C CAPACITOR 20pF 50V J
C90 HU-001060250 C CAPACITOR 0.1uF 16V K
C91 HU-001060250 C CAPACITOR 0.1uF 16V K
C113 HU-001060256 C CAPACITOR 270pF 50V J
C114 HU-001060256 C CAPACITOR 270pF 50V J
C115 HU-001063073 C CAPACITOR 20pF 50V J
C116 HU-001060250 C CAPACITOR 0.1uF 16V K
C117 HU-001060250 C CAPACITOR 0.1uF 16V K
C118 HU-001071227 E CAPACITOR 47uF 16V
C119 HU-001060346 C CAPACITOR 1uF 16V K
C120 HU-001060250 C CAPACITOR 0.1uF 16V K
C121 HU-001060250 C CAPACITOR 0.1uF 16V K
C122 HU-001060250 C CAPACITOR 0.1uF 16V K
C123 HU-001060250 C CAPACITOR 0.1uF 16V K
C124 HU-001060286 C CAPACITOR 10uF 10V
C125 HU-001063055 C CAPACITOR 5pF 50V
C126 HU-001063055 C CAPACITOR 5pF 50V
C127 HU-001060309 C CAPACITOR 10uF 16V K
C128 HU-001060250 C CAPACITOR 0.1uF 16V K
C129 HU-001071194 E CAPACITOR 100uF 25V
C161 HU-001060286 C CAPACITOR 10uF 10V
C162 HU-001060250 C CAPACITOR 0.1uF 16V K
C165 HU-001060297 C CAPACITOR 0.01pF 50V K
C166 HU-001060297 C CAPACITOR 0.01pF 50V K
C181 HU-001060250 C CAPACITOR 0.1uF 16V K
C182 HU-001060286 C CAPACITOR 10uF 10V
C183 HU-001060250 C CAPACITOR 0.1uF 16V K
 Ref No. Part No. Part Name Description Local

(No.YA697<Rev.001>)3-5
C184 HU-001060250 C CAPACITOR 0.1uF 16V K
C185 HU-001060250 C CAPACITOR 0.1uF 16V K
C186 HU-001060250 C CAPACITOR 0.1uF 16V K
C187 HU-001060250 C CAPACITOR 0.1uF 16V K
C188 HU-001060250 C CAPACITOR 0.1uF 16V K
C189 HU-001060250 C CAPACITOR 0.1uF 16V K
C190 HU-001060250 C CAPACITOR 0.1uF 16V K
C191 HU-001060250 C CAPACITOR 0.1uF 16V K
C192 HU-001060250 C CAPACITOR 0.1uF 16V K
C193 HU-001060250 C CAPACITOR 0.1uF 16V K
C194 HU-001060250 C CAPACITOR 0.1uF 16V K
C195 HU-001060250 C CAPACITOR 0.1uF 16V K
C221 HU-001060250 C CAPACITOR 0.1uF 16V K
C222 HU-001060250 C CAPACITOR 0.1uF 16V K
C223 HU-001060250 C CAPACITOR 0.1uF 16V K
C226 HU-001060286 C CAPACITOR 10uF 10V
C227 HU-001060286 C CAPACITOR 10uF 10V
C228 HU-001060250 C CAPACITOR 0.1uF 16V K
C229 HU-001060250 C CAPACITOR 0.1uF 16V K
C251 HU-001060250 C CAPACITOR 0.1uF 16V K
C252 HU-001060250 C CAPACITOR 0.1uF 16V K
C253 HU-001060219 C CAPACITOR 1000pF 50V K
C254 HU-001060346 C CAPACITOR 1uF 16V K
C255 HU-001060312 C CAPACITOR 22uF 6.3V M
C256 HU-001060297 C CAPACITOR 0.01pF 50V K
C257 HU-001060297 C CAPACITOR 0.01pF 50V K
C258 HU-001060312 C CAPACITOR 22uF 6.3V M
C259 HU-001060312 C CAPACITOR 22uF 6.3V M
C260 HU-001060297 C CAPACITOR 0.01pF 50V K
C261 HU-001060297 C CAPACITOR 0.01pF 50V K
C262 HU-001060312 C CAPACITOR 22uF 6.3V M
C263 HU-001060297 C CAPACITOR 0.01pF 50V K
C264 HU-001060297 C CAPACITOR 0.01pF 50V K
C265 HU-001060297 C CAPACITOR 0.01pF 50V K
C266 HU-001060297 C CAPACITOR 0.01pF 50V K
C267 HU-001060250 C CAPACITOR 0.1uF 16V K
C268 HU-001060250 C CAPACITOR 0.1uF 16V K
C269 HU-001060250 C CAPACITOR 0.1uF 16V K
C270 HU-001060250 C CAPACITOR 0.1uF 16V K
C271 HU-001060250 C CAPACITOR 0.1uF 16V K
C272 HU-001060250 C CAPACITOR 0.1uF 16V K
C273 HU-001060250 C CAPACITOR 0.1uF 16V K
C274 HU-001060250 C CAPACITOR 0.1uF 16V K
C275 HU-001060250 C CAPACITOR 0.1uF 16V K
C276 HU-001060250 C CAPACITOR 0.1uF 16V K
C277 HU-001060250 C CAPACITOR 0.1uF 16V K
C278 HU-001060250 C CAPACITOR 0.1uF 16V K
C279 HU-001060250 C CAPACITOR 0.1uF 16V K
C280 HU-001060250 C CAPACITOR 0.1uF 16V K
C281 HU-001060250 C CAPACITOR 0.1uF 16V K
C282 HU-001060250 C CAPACITOR 0.1uF 16V K
C283 HU-001060250 C CAPACITOR 0.1uF 16V K
C284 HU-001060250 C CAPACITOR 0.1uF 16V K
C285 HU-001060219 C CAPACITOR 1000pF 50V K
C286 HU-001060219 C CAPACITOR 1000pF 50V K
C287 HU-001060219 C CAPACITOR 1000pF 50V K
C288 HU-001060219 C CAPACITOR 1000pF 50V K
C289 HU-001060219 C CAPACITOR 1000pF 50V K
C290 HU-001060219 C CAPACITOR 1000pF 50V K
C291 HU-001060219 C CAPACITOR 1000pF 50V K
C292 HU-001060219 C CAPACITOR 1000pF 50V K
C293 HU-001060219 C CAPACITOR 1000pF 50V K
C294 HU-001060219 C CAPACITOR 1000pF 50V K
C295 HU-001060219 C CAPACITOR 1000pF 50V K
C296 HU-001060219 C CAPACITOR 1000pF 50V K
C297 HU-001060346 C CAPACITOR 1uF 16V K
C298 HU-001060346 C CAPACITOR 1uF 16V K
C299 HU-001060312 C CAPACITOR 22uF 6.3V M
C300 HU-001060312 C CAPACITOR 22uF 6.3V M
C321 HU-001060250 C CAPACITOR 0.1uF 16V K
C322 HU-001060250 C CAPACITOR 0.1uF 16V K
C323 HU-001060219 C CAPACITOR 1000pF 50V K
C324 HU-001060312 C CAPACITOR 22uF 6.3V M
C325 HU-001060312 C CAPACITOR 22uF 6.3V M
C326 HU-001060219 C CAPACITOR 1000pF 50V K
C327 HU-001060346 C CAPACITOR 1uF 16V K
C328 HU-001060250 C CAPACITOR 0.1uF 16V K
C329 HU-001060250 C CAPACITOR 0.1uF 16V K
C330 HU-001060346 C CAPACITOR 1uF 16V K
C331 HU-001060312 C CAPACITOR 22uF 6.3V M
C332 HU-001060312 C CAPACITOR 22uF 6.3V M
C333 HU-001060312 C CAPACITOR 22uF 6.3V M
C334 HU-001060346 C CAPACITOR 1uF 16V K
C335 HU-001060346 C CAPACITOR 1uF 16V K
C336 HU-001060346 C CAPACITOR 1uF 16V K
C337 HU-001060250 C CAPACITOR 0.1uF 16V K
C338 HU-001060250 C CAPACITOR 0.1uF 16V K
C339 HU-001060250 C CAPACITOR 0.1uF 16V K
C340 HU-001060297 C CAPACITOR 0.01pF 50V K
 Ref No. Part No. Part Name Description Local
C341 HU-001060297 C CAPACITOR 0.01pF 50V K
C342 HU-001060297 C CAPACITOR 0.01pF 50V K
C343 HU-001060296 C CAPACITOR 47nF 16V
C344 HU-001060296 C CAPACITOR 47nF 16V
C345 HU-001060296 C CAPACITOR 47nF 16V
C346 HU-001060312 C CAPACITOR 22uF 6.3V M
C347 HU-001060312 C CAPACITOR 22uF 6.3V M
C348 HU-001060312 C CAPACITOR 22uF 6.3V M
C349 HU-001060346 C CAPACITOR 1uF 16V K
C350 HU-001060346 C CAPACITOR 1uF 16V K
C351 HU-001060346 C CAPACITOR 1uF 16V K
C352 HU-001060250 C CAPACITOR 0.1uF 16V K
C353 HU-001060250 C CAPACITOR 0.1uF 16V K
C354 HU-001060250 C CAPACITOR 0.1uF 16V K
C355 HU-001060297 C CAPACITOR 0.01pF 50V K
C356 HU-001060297 C CAPACITOR 0.01pF 50V K
C357 HU-001060297 C CAPACITOR 0.01pF 50V K
C358 HU-001060296 C CAPACITOR 47nF 16V
C359 HU-001060296 C CAPACITOR 47nF 16V
C360 HU-001060296 C CAPACITOR 47nF 16V
C381 HU-001060297 C CAPACITOR 0.01pF 50V K
C382 HU-001060297 C CAPACITOR 0.01pF 50V K
C383 HU-001060250 C CAPACITOR 0.1uF 16V K
C384 HU-001060250 C CAPACITOR 0.1uF 16V K
C385 HU-001060286 C CAPACITOR 10uF 10V
C386 HU-001060250 C CAPACITOR 0.1uF 16V K
C387 HU-001060250 C CAPACITOR 0.1uF 16V K
C388 HU-001060250 C CAPACITOR 0.1uF 16V K
C389 HU-001060250 C CAPACITOR 0.1uF 16V K
C390 HU-001060250 C CAPACITOR 0.1uF 16V K
C391 HU-001060250 C CAPACITOR 0.1uF 16V K
C392 HU-001060250 C CAPACITOR 0.1uF 16V K
C393 HU-001060250 C CAPACITOR 0.1uF 16V K
C394 HU-001060250 C CAPACITOR 0.1uF 16V K
C395 HU-001060250 C CAPACITOR 0.1uF 16V K
C396 HU-001060250 C CAPACITOR 0.1uF 16V K
C397 HU-001060286 C CAPACITOR 10uF 10V
C398 HU-001060286 C CAPACITOR 10uF 10V
C399 HU-001060250 C CAPACITOR 0.1uF 16V K
C400 HU-001060250 C CAPACITOR 0.1uF 16V K
C401 HU-001060250 C CAPACITOR 0.1uF 16V K
C402 HU-001060250 C CAPACITOR 0.1uF 16V K
C403 HU-001060250 C CAPACITOR 0.1uF 16V K
C404 HU-001060250 C CAPACITOR 0.1uF 16V K
C405 HU-001060250 C CAPACITOR 0.1uF 16V K
C406 HU-001060250 C CAPACITOR 0.1uF 16V K
C407 HU-001060250 C CAPACITOR 0.1uF 16V K
C408 HU-001060250 C CAPACITOR 0.1uF 16V K
C409 HU-001060250 C CAPACITOR 0.1uF 16V K
C410 HU-001060250 C CAPACITOR 0.1uF 16V K
C411 HU-001060250 C CAPACITOR 0.1uF 16V K
C412 HU-001060250 C CAPACITOR 0.1uF 16V K
C413 HU-001060250 C CAPACITOR 0.1uF 16V K
C414 HU-001060250 C CAPACITOR 0.1uF 16V K
C415 HU-001060250 C CAPACITOR 0.1uF 16V K
C416 HU-001060250 C CAPACITOR 0.1uF 16V K
C417 HU-001060286 C CAPACITOR 10uF 10V
C418 HU-001060250 C CAPACITOR 0.1uF 16V K
C419 HU-001060250 C CAPACITOR 0.1uF 16V K
C420 HU-001060250 C CAPACITOR 0.1uF 16V K
C421 HU-001060250 C CAPACITOR 0.1uF 16V K
C422 HU-001060250 C CAPACITOR 0.1uF 16V K
C423 HU-001060250 C CAPACITOR 0.1uF 16V K
C424 HU-001060250 C CAPACITOR 0.1uF 16V K
C425 HU-001060346 C CAPACITOR 1uF 16V K
C426 HU-001060346 C CAPACITOR 1uF 16V K
C427 HU-001060346 C CAPACITOR 1uF 16V K
C428 HU-001060346 C CAPACITOR 1uF 16V K
C429 HU-001060346 C CAPACITOR 1uF 16V K
C430 HU-001060346 C CAPACITOR 1uF 16V K
C431 HU-001060346 C CAPACITOR 1uF 16V K
C432 HU-001060286 C CAPACITOR 10uF 10V
C433 HU-001060250 C CAPACITOR 0.1uF 16V K
C434 HU-001060250 C CAPACITOR 0.1uF 16V K
C435 HU-001060346 C CAPACITOR 1uF 16V K
C438 HU-001060286 C CAPACITOR 10uF 10V
C439 HU-001071224 E CAPACITOR 220uF 16V
C441 HU-001060250 C CAPACITOR 0.1uF 16V K
C442 HU-001060286 C CAPACITOR 10uF 10V
C443 HU-001060250 C CAPACITOR 0.1uF 16V K
C444 HU-001060286 C CAPACITOR 10uF 10V
C446 HU-001060250 C CAPACITOR 0.1uF 16V K
C447 HU-001060286 C CAPACITOR 10uF 10V
C449 HU-001060250 C CAPACITOR 0.1uF 16V K
C451 HU-001060286 C CAPACITOR 10uF 10V
C452 HU-001060250 C CAPACITOR 0.1uF 16V K
C453 HU-001060250 C CAPACITOR 0.1uF 16V K
C454 HU-001060286 C CAPACITOR 10uF 10V
C455 HU-001060236 C CAPACITOR 10uF 25V
 Ref No. Part No. Part Name Description Local

3-6(No.YA697<Rev.001>)
C456 HU-001060318 C CAPACITOR 0.1uF 50V
C457 HU-001060222 C CAPACITOR 4.7uF 16V
C458 HU-001060318 C CAPACITOR 0.1uF 50V
C459 HU-001060236 C CAPACITOR 10uF 25V
C460 HU-001060222 C CAPACITOR 4.7uF 16V
C461 HU-001060236 C CAPACITOR 10uF 25V
C462 HU-001060318 C CAPACITOR 0.1uF 50V
C463 HU-001060318 C CAPACITOR 0.1uF 50V
C464 HU-001060236 C CAPACITOR 10uF 25V
C481 HU-001060312 C CAPACITOR 22uF 6.3V M
C482 HU-001060346 C CAPACITOR 1uF 16V K
C483 HU-001060346 C CAPACITOR 1uF 16V K
C484 HU-001060346 C CAPACITOR 1uF 16V K
C485 HU-001060346 C CAPACITOR 1uF 16V K
C486 HU-001060250 C CAPACITOR 0.1uF 16V K
C487 HU-001060250 C CAPACITOR 0.1uF 16V K
C488 HU-001060250 C CAPACITOR 0.1uF 16V K
C489 HU-001060250 C CAPACITOR 0.1uF 16V K
C490 HU-001060250 C CAPACITOR 0.1uF 16V K
C491 HU-001060250 C CAPACITOR 0.1uF 16V K
C492 HU-001060250 C CAPACITOR 0.1uF 16V K
C493 HU-001060250 C CAPACITOR 0.1uF 16V K
C494 HU-001060250 C CAPACITOR 0.1uF 16V K
C495 HU-001060312 C CAPACITOR 22uF 6.3V M
C496 HU-001060346 C CAPACITOR 1uF 16V K
C497 HU-001060346 C CAPACITOR 1uF 16V K
C498 HU-001060346 C CAPACITOR 1uF 16V K
C499 HU-001060346 C CAPACITOR 1uF 16V K
C500 HU-001060250 C CAPACITOR 0.1uF 16V K
C501 HU-001060250 C CAPACITOR 0.1uF 16V K
C502 HU-001060250 C CAPACITOR 0.1uF 16V K
C503 HU-001060250 C CAPACITOR 0.1uF 16V K
C504 HU-001060250 C CAPACITOR 0.1uF 16V K
C505 HU-001060250 C CAPACITOR 0.1uF 16V K
C506 HU-001060250 C CAPACITOR 0.1uF 16V K
C507 HU-001060250 C CAPACITOR 0.1uF 16V K
C508 HU-001060250 C CAPACITOR 0.1uF 16V K
C525 HU-001060250 C CAPACITOR 0.1uF 16V K
C527 HU-001060286 C CAPACITOR 10uF 10V
C528 HU-001060250 C CAPACITOR 0.1uF 16V K
C529 HU-001060250 C CAPACITOR 0.1uF 16V K
C530 HU-001060250 C CAPACITOR 0.1uF 16V K
C551 HU-001060286 C CAPACITOR 10uF 10V
C552 HU-001060250 C CAPACITOR 0.1uF 16V K
C553 HU-001060250 C CAPACITOR 0.1uF 16V K
C554 HU-001060250 C CAPACITOR 0.1uF 16V K
C555 HU-001060297 C CAPACITOR 0.01pF 50V K
C556 HU-001060297 C CAPACITOR 0.01pF 50V K
C557 HU-001060297 C CAPACITOR 0.01pF 50V K
C558 HU-001060286 C CAPACITOR 10uF 10V
C559 HU-001060250 C CAPACITOR 0.1uF 16V K
C560 HU-001060250 C CAPACITOR 0.1uF 16V K
C561 HU-001060250 C CAPACITOR 0.1uF 16V K
C562 HU-001060297 C CAPACITOR 0.01pF 50V K
C563 HU-001060297 C CAPACITOR 0.01pF 50V K
C564 HU-001060250 C CAPACITOR 0.1uF 16V K
C565 HU-001060250 C CAPACITOR 0.1uF 16V K
C569 HU-001060250 C CAPACITOR 0.1uF 16V K
C570 HU-001060250 C CAPACITOR 0.1uF 16V K
C571 HU-001060250 C CAPACITOR 0.1uF 16V K
C572 HU-001060250 C CAPACITOR 0.1uF 16V K
C573 HU-001060286 C CAPACITOR 10uF 10V
C574 HU-001060286 C CAPACITOR 10uF 10V
C575 HU-001060250 C CAPACITOR 0.1uF 16V K
C576 HU-001060250 C CAPACITOR 0.1uF 16V K
C577 HU-001060250 C CAPACITOR 0.1uF 16V K
C578 HU-001060250 C CAPACITOR 0.1uF 16V K
C579 HU-001060250 C CAPACITOR 0.1uF 16V K
C580 HU-001060286 C CAPACITOR 10uF 10V
C582 HU-001060250 C CAPACITOR 0.1uF 16V K
C583 HU-001060250 C CAPACITOR 0.1uF 16V K
C584 HU-001060250 C CAPACITOR 0.1uF 16V K
C585 HU-001060250 C CAPACITOR 0.1uF 16V K
C586 HU-001060286 C CAPACITOR 10uF 10V
C587 HU-001060286 C CAPACITOR 10uF 10V
C588 HU-001060286 C CAPACITOR 10uF 10V
C589 HU-001060250 C CAPACITOR 0.1uF 16V K
C590 HU-001060250 C CAPACITOR 0.1uF 16V K
C621 HU-001060309 C CAPACITOR 10uF 16V K
C622 HU-001060250 C CAPACITOR 0.1uF 16V K
C623 HU-001060309 C CAPACITOR 10uF 16V K
C624 HU-001060250 C CAPACITOR 0.1uF 16V K
C664 HU-001060219 C CAPACITOR 1000pF 50V K
C665 HU-001060219 C CAPACITOR 1000pF 50V K
C666 HU-001071210 E CAPACITOR 47uF 25V
C667 HU-001071190 E CAPACITOR 10uF 16V
C668 HU-001060318 C CAPACITOR 0.1uF 50V
C669 HU-001060236 C CAPACITOR 10uF 25V
C670 HU-001063035 C CAPACITOR 10pF 50V C
 Ref No. Part No. Part Name Description Local
C671 HU-001071190 E CAPACITOR 10uF 16V
C672 HU-001060219 C CAPACITOR 1000pF 50V K
C673 HU-001071190 E CAPACITOR 10uF 16V
C674 HU-001060219 C CAPACITOR 1000pF 50V K
C675 HU-001071190 E CAPACITOR 10uF 16V
C676 HU-001063035 C CAPACITOR 10pF 50V C
C677 HU-001060250 C CAPACITOR 0.1uF 16V K
C678 HU-001060318 C CAPACITOR 0.1uF 50V
C741 HU-001060219 C CAPACITOR 1000pF 50V K
C742 HU-001060219 C CAPACITOR 1000pF 50V K
C761 HU-001060318 C CAPACITOR 0.1uF 50V
C762 HU-001060270 C CAPACITOR 1uF 50V
C763 HU-001060297 C CAPACITOR 0.01pF 50V K
C764 HU-001071250 E CAPACITOR 470uF 25V
C765 HU-001060318 C CAPACITOR 0.1uF 50V
C766 HU-001060194 C CAPACITOR 0.022uF 50V
C767 HU-001060288 C CAPACITOR 1uF 25V
C768 HU-001060185 C CAPACITOR 390pF 50V J
C769 HU-001060297 C CAPACITOR 0.01pF 50V K
C770 HU-001060317 C CAPACITOR 470nF 50V
C771 HU-001060185 C CAPACITOR 390pF 50V J
C772 HU-001060286 C CAPACITOR 10uF 10V
C773 HU-001060194 C CAPACITOR 0.022uF 50V
C774 HU-001060318 C CAPACITOR 0.1uF 50V
C775 HU-001060297 C CAPACITOR 0.01pF 50V K
C776 HU-001060288 C CAPACITOR 1uF 25V
C777 HU-001060288 C CAPACITOR 1uF 25V
C778 HU-001060250 C CAPACITOR 0.1uF 16V K
C779 HU-001060194 C CAPACITOR 0.022uF 50V
C780 HU-001060219 C CAPACITOR 1000pF 50V K
C781 HU-001060318 C CAPACITOR 0.1uF 50V
C782 HU-001060297 C CAPACITOR 0.01pF 50V K
C783 HU-001060185 C CAPACITOR 390pF 50V J
C784 HU-001060317 C CAPACITOR 470nF 50V
C785 HU-001060250 C CAPACITOR 0.1uF 16V K
C786 HU-001060270 C CAPACITOR 1uF 50V
C787 HU-001060318 C CAPACITOR 0.1uF 50V
C788 HU-001071250 E CAPACITOR 470uF 25V
C789 HU-001060185 C CAPACITOR 390pF 50V J
C790 HU-001060286 C CAPACITOR 10uF 10V
C791 HU-001060249 C CAPACITOR 100pF 50V J
C792 HU-001060250 C CAPACITOR 0.1uF 16V K
C793 HU-001060219 C CAPACITOR 1000pF 50V K
C794 HU-001060318 C CAPACITOR 0.1uF 50V
C795 HU-001060297 C CAPACITOR 0.01pF 50V K
C796 HU-001060286 C CAPACITOR 10uF 10V
C797 HU-001060250 C CAPACITOR 0.1uF 16V K
C798 HU-001060286 C CAPACITOR 10uF 10V
C799 HU-001060250 C CAPACITOR 0.1uF 16V K
C800 HU-001060288 C CAPACITOR 1uF 25V
C801 HU-001060194 C CAPACITOR 0.022uF 50V
C802 HU-001060250 C CAPACITOR 0.1uF 16V K
C803 HU-001060286 C CAPACITOR 10uF 10V
C806 HU-001060219 C CAPACITOR 1000pF 50V K
C807 HU-001060288 C CAPACITOR 1uF 25V
C809 HU-001060230 C CAPACITOR 0.022uF 16V K
C810 HU-001071227 E CAPACITOR 47uF 16V
C812 HU-001060288 C CAPACITOR 1uF 25V
C813 HU-001071227 E CAPACITOR 47uF 16V
C814 HU-001060230 C CAPACITOR 0.022uF 16V K
C815 HU-001060288 C CAPACITOR 1uF 25V
C817 HU-001060286 C CAPACITOR 10uF 10V
C818 HU-001060288 C CAPACITOR 1uF 25V
C831 HU-001060318 C CAPACITOR 0.1uF 50V
C832 HU-001060318 C CAPACITOR 0.1uF 50V
C833 HU-001060309 C CAPACITOR 10uF 16V K
C834 HU-001060318 C CAPACITOR 0.1uF 50V
C835 HU-001060318 C CAPACITOR 0.1uF 50V
C851 HU-001060250 C CAPACITOR 0.1uF 16V K
C852 HU-001060250 C CAPACITOR 0.1uF 16V K
C853 HU-001060250 C CAPACITOR 0.1uF 16V K
C881 HU-001060309 C CAPACITOR 10uF 16V K
C882 HU-001060250 C CAPACITOR 0.1uF 16V K
C884 HU-001060309 C CAPACITOR 10uF 16V K
C885 HU-001060249 C CAPACITOR 100pF 50V J
C886 HU-001060309 C CAPACITOR 10uF 16V K
C888 HU-001060250 C CAPACITOR 0.1uF 16V K
C890 HU-001060250 C CAPACITOR 0.1uF 16V K
C891 HU-001060286 C CAPACITOR 10uF 10V
C892 HU-001060250 C CAPACITOR 0.1uF 16V K
C893 HU-001060312 C CAPACITOR 22uF 6.3V M
C894 HU-001060250 C CAPACITOR 0.1uF 16V K
C895 HU-001060312 C CAPACITOR 22uF 6.3V M
C896 HU-001060250 C CAPACITOR 0.1uF 16V K
C897 HU-001060250 C CAPACITOR 0.1uF 16V K
C898 HU-001060286 C CAPACITOR 10uF 10V
C899 HU-001060250 C CAPACITOR 0.1uF 16V K
C922 HU-001060250 C CAPACITOR 0.1uF 16V K
C923 HU-001060219 C CAPACITOR 1000pF 50V K
 Ref No. Part No. Part Name Description Local
