JVC LT-24C370 User manual

Instruction Manual
24” LED HD TV
LT-24C370

Contents
1 Safety Warnings ...........................................................................................................................................................................6
2 Preparation...................................................................................................................................................................................9
Unpacking the TV ...............................................................................................................................................................................................................9
Installing / Removing the Base Stand .......................................................................................................................................................................10
− Installing the Base Stand....................................................................................................................................................................................10
− Mounting the TV to a Wall.................................................................................................................................................................................10
Front View and Bottom View Controls .....................................................................................................................................................................12
Rear View and Sockets....................................................................................................................................................................................................13
Installing Batteries in the Remote Control ..............................................................................................................................................................14
Remote Control Operation Range..............................................................................................................................................................................14
Remote Control .................................................................................................................................................................................................................15
Joystick Function Button ...............................................................................................................................................................................................17
3 Connections................................................................................................................................................................................18
Making Video and Audio Connections.....................................................................................................................................................................18
Connecting an AV Device Using an HDMI Cable...................................................................................................................................................18
− Connecting a Soundbar - HDMI ARC (Audio Return Channel) ...........................................................................................................19
Connecting a Computer Using a VGA Cable ..........................................................................................................................................................19
Connecting an AV Device Using a Component (YPbPr) Cable ....................................................................................................................... 20
Connecting an AV Device Using a SCART Cable .................................................................................................................................................. 20
Connecting an AV Device Using Composite Cable..............................................................................................................................................21
Connecting an Audio Receiver....................................................................................................................................................................................21
Connecting to Network................................................................................................................................................................................................. 22
Connecting Headphones.............................................................................................................................................................................................. 22
4 Initial Setup ................................................................................................................................................................................23
Turning the TV On for the First Time ........................................................................................................................................................................ 23
− Target Region Setting (UK only)..................................................................................................................................................................... 24
− Eco Friendly / Auto Standby Function ......................................................................................................................................................... 25
− Selecting the Input Source............................................................................................................................................................................... 25
− Channel Selection .............................................................................................................................................................................................. 25
− Listening to the Radio (Radio Mode)............................................................................................................................................................ 25
− Display Channel Information .......................................................................................................................................................................... 26
− Volume Adjustment............................................................................................................................................................................................ 26
5 Customising TV Settings ...........................................................................................................................................................27
Channel Setting (TV, DTV or Radio Mode).............................................................................................................................................................. 27
− Auto Tuning ........................................................................................................................................................................................................... 27
− DTV Manual Tuning............................................................................................................................................................................................. 28
− ATV Manual Tuning............................................................................................................................................................................................. 28
− Channel Edit (ATV / DTV Mode)...................................................................................................................................................................... 29
− Signal Information (DTV Mode)...................................................................................................................................................................... 30
− CI (Common Interface) (DTV Mode)...............................................................................................................................................................31
− Software Update (Over Air Download) (DTV Mode)............................................................................................................................... 32
− Software Update (USB) (DTV Mode)............................................................................................................................................................. 32
Picture Setting .................................................................................................................................................................................................................. 33
Sound Setting ................................................................................................................................................................................................................... 35
− Stereo / Dual Sound Reception (ATV Mode).............................................................................................................................................. 36
− Speaker Sound Output Selection (DTV Mode)......................................................................................................................................... 36
Time Settings..................................................................................................................................................................................................................... 37
Option Setting .................................................................................................................................................................................................................. 38
− OSD Language...................................................................................................................................................................................................... 38
− Audio Language (DTV Mode).......................................................................................................................................................................... 38
− Subtitle Language (DTV Mode)...................................................................................................................................................................... 39
− Hearing Impaired................................................................................................................................................................................................. 40
− Country.................................................................................................................................................................................................................... 40
− PVR File System (DTV Mode)............................................................................................................................................................................ 40
− Restore Factory Default......................................................................................................................................................................................41
− Network Conguration ..................................................................................................................................................................................... 42

− HDMI CEC (Consumer Electronics Control)................................................................................................................................................ 43
Lock Setting ....................................................................................................................................................................................................................... 44
− Lock System ........................................................................................................................................................................................................... 44
− Set Password ......................................................................................................................................................................................................... 45
− Block Channel ....................................................................................................................................................................................................... 46
− Parental Guidance............................................................................................................................................................................................... 47
6 Using the Features .....................................................................................................................................................................48
EPG (Electronic Programme Guide) (DTV or Radio Mode) ............................................................................................................................... 48
− Switch On / O EPG............................................................................................................................................................................................. 48
− Select a Programme ........................................................................................................................................................................................... 48
Red Button (Interactive Services)............................................................................................................................................................................... 49
− Accessing the Information ............................................................................................................................................................................... 49
7 Entertainment ............................................................................................................................................................................50
Connecting a USB Storage Device............................................................................................................................................................................. 50
Viewing Movies ................................................................................................................................................................................................................ 50
Listening to Music.............................................................................................................................................................................................................51
Viewing Photos................................................................................................................................................................................................................. 52
My Text................................................................................................................................................................................................................................. 53
8 PVR (Personal Video Recorder).................................................................................................................................................54
Time Shift Function......................................................................................................................................................................................................... 54
Recording DTV Programme onto a USB Storage Device .................................................................................................................................. 55
Timer Programming ....................................................................................................................................................................................................... 56
Playing Recorded Programme ................................................................................................................................................................................... 57
9 Other Information......................................................................................................................................................................58
Maintenance.........................................................................................................................................................................58
Hints and Tips.......................................................................................................................................................................58
Display Modes................................................................................................................................................................................................................... 60
− YPbPr Mode ........................................................................................................................................................................................................... 60
− PC Mode.................................................................................................................................................................................................................. 60
− HDMI Mode ........................................................................................................................................................................................................... 60
Product Fiche and Specications ...............................................................................................................................................................................61
Remote Control Codes................................................................................................................................................................................................... 63
− Sky Codes ............................................................................................................................................................................................................... 63
Useful Information and Licences ............................................................................................................................................................................... 63

6
1 Safety Warnings
• Read all the instructions carefully before using the unit
and keep them for future reference.
• Retain the manual. If you pass the unit onto a third
party make sure to include this manual.
• Check that the voltage marked on the rating label
matches your mains voltage.
• WARNING: Never let people (including children) with
reduced physical, sensory or mental capabilities or lack
of experience and / or knowledge use electrical devices
unsupervised.
• To avoid danger of suffocation, keep plastic bags out of
reach of babies, children and domestic animals.
• Carefully attach the stand to the TV. If the stand is
provided with screws, tighten the screws firmly to
prevent the TV from tilting. Do not over tighten the
screws and mount the stand rubbers properly.
Damage
• Please inspect the unit for damage after unpacking.
• Do not continue to operate the unit if you are in any
doubt about it working normally, or if it is damaged
in any way - switch off, withdraw the mains plug and
consult your dealer.
Location of Unit
• The unit must be placed on a flat stable surface and
should not be subjected to vibrations.
• Do not place the unit on sloped or unstable surfaces
as the unit may fall off or tip over causing serious
personal injury or death.
• The mains socket must be located near the unit and
should be easily accessible.
• This unit is designed for indoor, domestic use only.
• Use this TV set at an altitude of less than 2000 meters
above sea level, in dry locations and in regions with
moderate or tropical climates.
Many injuries, particularly to children, can be avoided by
taking simple precautions such as;
• Using cabinets or stands recommended by the
manufacturer of the television set.
• Only use furniture that can safely support the
television set.
• Ensuring the television set is not overhanging the edge
of the supporting furniture.
• Not placing the television set on tall furniture (for
example, cupboards or bookcases) without anchoring
both furniture and the television set to a suitable
support.
• Not standing the television set on cloth or other
materials placed between the television and
supporting furniture.
• Educating children about the dangers of climbing
on furniture to reach the television set or its controls.
If your existing television set is being retained and
relocated, the same considerations as above should be
applied.
Wall Mounting
• Read the TV and wall mount instructions before
mounting your TV on the wall.
• For TVs over 40” in size, wall mounting requires 2
people to lift and position the TV on to the wall mount.
• The wall mount bracket is not supplied, they can be
purchased from your dealer.
• Do not install the TV on a ceiling or an inclined wall.
• Only use the screws supplied with the wall mount
bracket when attaching the TV to the bracket. See your
TV instructions for screw type.
• Tighten the wall mount screw firmly to prevent the TV
from falling. Do not over tighten the screws.
• If you are in any doubt how to mount your TV, contact
a professional.
Temperature
• Avoid extreme degrees of temperature, either hot or
cold. Place the unit well away from heat sources such
as radiators or gas / electric fires.
• Avoid exposure to direct sunlight and other sources of
heat.
Naked Flames
• Never place any type of candle or naked flame on the
top of or near the unit.
Moisture
• To reduce the risk of fire, electric shock or product
damage, do not expose this unit to rain, moisture,
dripping or splashing. No objects filled with liquids,
such as vases, should be placed on the unit.
• If you spill any liquid into the unit, it can cause serious
damage. Switch it off at the mains immediately.
Withdraw the mains plug and consult your dealer.
Ventilation
• To prevent the risk of electric shock or fire hazard
due to overheating, ensure that curtains and other
materials do not obstruct the ventilation vents.
• Do not install or place this unit in a bookcase, built-in
cabinet or in another confined space. Ensure the unit is
well ventilated.
• Make sure that there is a gap of at least 10 cm on both
sides and a gap of 20 cm at the top.
Chapter
1
10 cm 10 cm
20 cm
10 cm
Safety
• Always disconnect the unit from the mains supply
before connecting / disconnecting other devices or
moving the unit.
• Unplug the unit from the mains socket during a
lightning storm.

7
1
Safety Warnings
Mains Cable
• Make sure the unit or unit stand is not resting on top of
the mains cable, as the weight of the unit may damage
the mains cable and create a safety hazard.
• A damaged power cord/plug can cause fire or give you
an electric shock. Handle the power cord by the plug,
do not unplug the TV by pulling the power cord.
• Never touch the power cord/plug with wet hands as
this could cause a short circuit or electric shock.
• Never make a knot in the power cord or tie it with
other cords.
• If the mains cable is damaged it must be replaced
by the manufacturer, its service agent, or similarly
qualified persons in order to avoid a hazard.
Interference
• Do not place the unit on or near appliances which may
cause electromagnetic interference. If you do, it may
adversely affect the operating performance of the unit,
and cause a distorted picture or sound.
Optimum viewing
• View the unit in moderate light to prevent eye strain. It
is recommended to watch the unit from a distance
3-7 times that of the screen height.
LCD screen
• The LCD screen is manufactured using high-precision
technology. However, some tiny black points and /
or bright points (red, blue or green in colour) may
constantly appear on the LCD screen. These points
are generated in the manufacturing process and are
normal.
Screen Burn
• A characteristic of Plasma and TV Panels is that
displaying the same image for a long time may cause
a permanent after-image to remain on the screen. This
is called screen burn. Most pictures shown on the unit
will be constantly moving and fill the screen.
• Examples of images that you need to watch out for are
as follows (this is not an all-inclusive list):
1. Black Bars: If black bars appear at the left / right or
top / bottom of the screen, it is recommended to
change the format so that the picture fills the entire
screen.
2. TV Channel Logos: e.g. Shopping channel logos
and pricing displays - especially if they are bright
and stationary. Moving or low-contrast graphics are
less likely to cause ageing of the screen.
3. Time Displays
4. Teletext: Do not view a stationary page for long
periods of time.
5. TV Menus
6. Pause Mode: Do not leave the screen in pause
mode for long periods of time, e.g. when watching
videos.
• To prevent screen burn if viewing any of the above for
long periods of time, reduce contrast and brightness
when viewing. Once burn-in occurs it will never
disappear completely.
Earphones
• Listening to loud sounds for prolonged periods of time
may permanently damage your hearing.
• Before putting on earphones, turn the volume down
then put the earphones on and slowly increase the
volume until you reach a comfortable listening level.
Standby
• The button on the remote control does not switch
off the unit completely. The unit will continue to draw
electricity from the mains supply while in standby. In
the interests of safety and to avoid unnecessary energy
consumption, never leave the unit in standby while
unattended for long periods of time, e.g. overnight,
while on holiday or while out of the house. Disconnect
the mains plug from the mains socket.
Batteries
• Batteries used in the remote control for this unit
are easily swallowed by young children and this is
dangerous.
• Keep loose batteries away from young children and
make sure that the battery holder tray is secure in the
remote control. Seek medical advice if you believe a
cell has been swallowed.
• Please dispose of batteries correctly by following the
guidance in this manual.
• Do not dispose of batteries in fire or with hazardous or
flammable materials.
• The batteries shall not be exposed to excessive heat
such as sunshine, fire or the like.
Supervision
• Children should be supervised to ensure that they do
not play with the unit and the remote control.
• Never let anyone especially children push anything
into the holes, slots or any other openings in the case -
this could result in a fatal electric shock.
Earthing
• Apparatus connected to the protective earthing of the
building installation through the MAINS connection
or through other apparatus with a connection to
protective earthing - and to a television distribution
system using coaxial cable, may in some circumstances
create a fire hazard. Connection to a television
distribution system has therefore to be provided
through a device providing electrical isolation below a
certain frequency range (galvanic isolator,
see EN 60728-11).
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the unit’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
manual accompanying the unit.

8
1Safety Warnings
Service
• To reduce the risk of electric shock, do not remove
screws. The unit does not contain any user-serviceable
parts. Please leave all maintenance work to qualified
personnel.
• Do not open any fixed covers as this may expose
dangerous voltages.
Maintenance
• Ensure to unplug the unit from the mains socket before
cleaning.
• Do not use any type of abrasive pad or abrasive
cleaning solutions as these may damage the unit’s
surface.
• Do not use liquids to clean the unit.
• The wall socket plug is used as a disconnect device, the
disconnect device should be readily accessible.
• This equipment is a Class II or double insulated
electrical appliance. It has been designed in such
a way that it does not require a safety connection
to electrical earth.
To prevent the spread of fire,
keep candles or other open
flames away from this product
at all times.

9
2 Preparation
Unpacking the TV
Remove all packaging from the TV. Retain the packaging. If you dispose of it please do so according to local regulations.
The following items are included:
Thank you for purchasing your new JVC TV.
Your new TV has many features and incorporates the latest technology to enhance your viewing
experience. We recommend that you spend some time reading this instruction manual so that you fully
understand these features. You will also find some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual for future reference.
Chapter
2
Instruction Manual Quick Start Guide
Remote Control /
AAA Batteries x 2
TV Stand Base
SETUP
ANGLE
ZOOM STEP
MENU
TEXT
CANCEL
AUDIO
MIX
OK
SIZE
ASPECT S.MODE P.MODE GUIDE
LIST
PROG
MENU INPUT
BACK EXIT
OK
S
TITLE
TV.RD
FAV
HOLD REVEAL SUBPAGE INDEX
GOTO SLOW REPEAT A-B
TV
Screw x 4
Rear Spacer x 4
Spacer Screw x 4
Component Adapter Cable
(YPbPr)
• If items are missing, or damaged please contact Partmaster (UK only). Tel: [phone] for assistance.
• if you require additional assistance:
For UK, please call our UK Call Centre on 0344 561 1234.
For Ireland, please call our Ireland Call Center on 1 890 818 575.
Composite Adapter Cable
(AV)

2
10
Preparation
1. Disconnect all cables connected to the TV.
2. Lay the TV down on a flat surface with the back side facing up, and ideally at the edge of a table so that the base of the TV
slightly overhangs on it. Please make sure a soft cushioned material (such as a pillow or thick piece of foam) is placed beneath
the screen.
Installing the Base Stand
Attach the TV stand to the TV. Align the screw holes, then secure with a screw driver (not included) using the 4 screws provided.
Installing / Removing the Base Stand
The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that
no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert
pressure on the front of the TV at any time because the screen could crack.
• Please read this instruction manual carefully while setting up your TV.
• If you require additional assistance:
For UK, please call our UK Call Centre on 0344 561 1234.
For Ireland, please call our Ireland Call Center on 1 890 818 575.
1. To remove the stand assembly, untighten the screws holding the stand assembly at the rear of the TV. Remove the stand
assembly.
• Remove the stand assembly before mounting the TV onto the wall.
• If you are wall mounting your TV you may wish to buy a 90° HDMI adapter. This will help with your cable management.
Keep all the spare screws
should you want to use the
stand assembly option.
Mounting the TV to a Wall
TV Stand Base Front
(included)

2
Preparation
11
2. This TV is designed to be wall-mounted with a standard mounting kit (sold separately) designed for flat-panel TVs. Use the
supplied 4 rear spacers and screw to mount TV’s with curved / recessed back, recessed mounting holes, or to allow access
to A/V inputs. Mount this TV according to the instructions included in the mounting kit. Due to space restrictions, we
recommend that you make all connections (refer to page 18-22 and page 50 for details) before mounting on to the wall.
• Please read this instruction manual carefully while setting up your TV.
• If you require additional assistance:
For UK, please call our UK Call Centre on 0344 561 1234.
For Ireland, please call our Ireland Call Center on 1 890 818 575.
• Some models of TV are provided 4 screws inside the mounting holes. Be sure to use these supplied screws with your
mounting kit when attaching the mounting hooks to the TV set. The supplied screws are designed for the TV. Use of
screws other than those supplied may result in internal damage to the TV set or cause it to fall, etc.
• Before mounting on the wall, untighten the screws inside the mounting holes.
100 mm
100 mm
Four mounting holes
(size M4 x 5 screw)
M4
4.7-5mm
TV Weight (Without Stand): 2.6 kg
rear spacer
spacer screw

2
12
Preparation
Front View and Bottom View Controls
Item Description
1POWER LED Illuminates red when the TV is in standby mode. The LED will blink in red, confirming
that a timer recording programme has started in standby mode.
2IR (Infrared Receiver) Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
3 Joystick Function Button
• In STANDBY mode, press to switch the TV on from standby mode.
• In ON mode, press and hold to switch the TV back to standby mode.
• Press to display the input sources menu.
• Move up and down ( / ) to select a channel or select among different input
signal sources.
• Move left and right (+ / –) to adjust the volume or access the selection on the input
source menu.
1 2
3

2
Preparation
13
Rear View and Sockets
Item Description
1 Digital Audio Output
(Optical) Connects to the audio socket on the digital/standard 5.1 audio system.
2 HDMI1(ARC) / HDMI2 Connects to a High-Definition (HD) signal output device, such as a set-top box, blu-ray
disc player or AV receiver.
3 PC IN / PC AUDIO Connects to a computer or other devices with a VGA interface.
4 SCART Connects to a VCR, DVD Player, or other AV device with a SCART output socket.
5 USB Allows the insertion of a USB storage device to play video, audio, photo and text files
(USB mode) and record DTV programmes on to a USB storage device.
6 HEADPHONE Connects to the headphones.
7 AV IN Connects to the composite output sockets on external video devices.
8 YPbPr / AV IN Connects to a DVD player, Digital Set-Top-Box, or other AV devices with component
(YPbPr) video and audio output sockets.
9 COMMON INTERFACE Allows the insertion of a Common Access Module.
10 RF Aerial Connects to the aerial socket on the wall with the RF coaxial cable.
11 LAN Connects your TV to the internet router by an Ethernet cable.
SCARTHDMI1(ARC) HDMI2 PC IN USB
5V 500mA
Digital Audio Output
(optical)
LAN RF
COMMON INTERFACE (CI)
HEADPHONE
PC AUDIO YPbPr AV IN
6
7
9
3
10
11
8
4 51 32

2
14
Preparation
Remote Control Operation Range
Point the remote control at the TV no more than 5 metres from the
remote control sensor on the TV and within 60° in front of the TV.
The operating distance may vary depending on the brightness of the
room.
Installing Batteries in the Remote Control
1. Press and lift the back cover to open the battery compartment of the
remote control.
2. Insert two AAA size batteries. Make sure the (+) and ( - ) ends of
the batteries match the (+) and ( - ) ends indicated in the battery
compartment.
3. Close the battery compartment cover.
SETUP
ANGLE
ZOOM STEP
MENU
TEXT
CANCEL
AUDIO
MIX
OK
SIZE
ASPECT S.MODE P.MODE GUIDE
LIST
PROG
MENU INPUT
BACK EXIT
OK
S
TITLE
TV.RD
FAV
HOLD REVEAL SUBPAGE INDEX
GOTO SLOW REPEAT A-B
30° 30°
5M
Handling the Batteries
• Improper or incorrect use of batteries may cause
corrosion or battery leakage, which could cause fire,
personal injury or damage to property.
• Only use the battery type indicated in this manual.
• When the batteries are exhausted, the remote will
not function. Replace both batteries at the same time
with new ones.
• Do not install new batteries with used ones and do
not mix different types of batteries.
• Do not dispose of used batteries as domestic waste.
Dispose of them in accordance with local regulations.
Handling the Remote Control
• Take care of your fingernails when you press and hold
the battery release tab.
• Do not drop or cause impact to the remote control.
• Do not spill water or any liquid on the remote control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct sunlight
or near sources of excessive heat.
• Remove the battery from the remote control when
not in use for a long period of time, as it could
cause corrosion or battery leakage and may result
in physical injury and/or property damage including
fire.

2
Preparation
15
1.
Mute and restore your TV sound.
2.
Switch the TV between on and standby mode.
3. ASPECT
Watch the screen in various formats: Auto / 4:3 / 16:9 / Zoom /
Subtitle / SmartZoom.
4. S.MODE
Select sound mode: Standard / Music / Movie / Sports / User.
5. GUIDE
Displays the EPG Electronic Programme Guide. (DTV mode)
TITLE
No function.
6. P.MODE
Select picture mode: Standard / Movie / User / Dynamic.
7. 0-9 Number Button
Press to select a programme.
8. LIST
Display the channel list. (ATV / DTV mode)
9. (RECALL)
Return to the previous viewing channel. (ATV / DTV mode)
10. i
Display the present channel information such as the current
time and channel name. (ATV / DTV mode)
11. MENU
Display the OSD (On Screen Display) menu.
12. INPUT
Select among the dierent input signal sources:
DTV / ATV / SCART / YPbPr / PC / HDMI1 / HDMI2 / AV / USB
13.
Allows you to navigate the OSD menus and adjust the system
settings to your preference.
14. OK
Conrm the selection in the OSD menus.
15. BACK
Return to the previous menu in the OSD menus.
16. PROG
Display the channel edit menu. (ATV / DTV mode)
17. Exit
Exit the OSD menu.
18. TV.RD
A short-cut to switch input source to TV / Digital radio channels.
ANGLE
No function.
19. FAV
Display the favourite channel list. (ATV / DTV mode)
SETUP
No function.
20. VOL + / –
Adjust the volume.
Remote Control
SETUP
ANGLE
ZOOM STEP
MENU
TEXT
CANCEL
AUDIO
MIX
OK
SIZE
ASPECT S.MODE P.MODE GUIDE
LIST
PROG
MENU INPUT
BACK EXIT
OK
S
TITLE
TV.RD
FAV
HOLD REVEAL SUBPAGE INDEX
GOTO SLOW REPEAT A-B
1
3
8
11
15
20
13
14
16
18
19
10
7
4
2
5
9
12
17
6

2
16
Preparation
21. CH + / –
Select a channel.
22.
No function.
23.
To skip to the beginning of the previous chapter / track /
photo. (USB mode)
Skip to the beginning of the next chapter / track / photo.
(USB mode)
Reverse playback rapidly. (USB mode)
Advance playback rapidly. (USB mode)
HOLD / REVEAL / SUBPAGE / INDEX
No function.
24. TEXT
Turn on and o the teletext function. (DTV mode)
MENU
No function.
25. S (Subtitle)
Display subtitles which are broadcast with the programme.
(DTV mode)
26. / CANCEL / SIZE
No function.
OK / MIX
No function.
27. AUDIO
• Turn on / o the Audio Description function (only
applicable when the TV programme has this feature).
(DTV mode)
• Select Stereo / Dual Sound Reception. (ATV mode)
28. PL AY
Start playback. (USB mode)
29. REC
Record the current programme. (DTV mode).
ZOOM
No function.
30. Stop
Stop the playback or recording. (USB / DTV mode)
31. (Pause)
• Pause playback. (USB mode)
• Start the time-shift function (DTV mode)
STEP
No function.
32. Coloured buttons
• Access the TELETEXT items. (DTV mode)
• Access menu options.
GOTO (RED)
No function.
SLOW (GREEN)
No function.
REPEAT (YELLOW)
No function.
A–B (BLUE)
No function.
SETUP
ANGLE
ZOOM STEP
MENU
TEXT
CANCEL
AUDIO
MIX
OK
SIZE
ASPECT S.MODE P.MODE GUIDE
LIST
PROG
MENU INPUT
BACK EXIT
OK
S
TITLE
TV.RD
FAV
HOLD REVEAL SUBPAGE INDEX
GOTO SLOW REPEAT A-B
24
27
29
26
23
32
22
30
21
25
28
31

2
Preparation
17
Joystick Function Button
The button under the TV frame is like a joystick. You can simply
operate the TV functions by pressing or moving the button.
• Press the button to switch the TV on. Press and hold the button
to switch off.
• To change input source, press the button to access the INPUT
SOURCE menu. Move the button up / down ( / ) to select the
source, then move left and right (+/ –) to confirm.
• To change channel, move button up / down ( / ).
• To adjust the volume, move the button left and right (+/ –).

18
Connecting an AV Device Using an HDMI Cable
• This TV can accept High-Definition Multimedia Interface (HDMI) supports HDCP (High-Bandwidth Digital Content Protection)
Protocol.
• This TV has a total of 2 HDMI input sockets, please make sure the correct input source is selected and corresponds to your
connected HDMI input socket.
• When you connect to the output of an HD ready player (blu-ray disc player, game console, set-top box or computer) switch to
the HDMI function and the TV will automatically detect the resolution used by the HDMI source.
• To get the best picture quality, adjust the blu-ray disc player, game console or set-top box output resolution up to 1920 x
1080p.
1. Use an HDMI cable to connect the TV’s HDMI input
socket to the external AV device’s HDMI output socket.
2. Plug the connected devices into the mains socket
before switching on the TV.
3. Press the center of joystick function button under the
TV frame or the button on the remote control to
turn on your TV.
4. Press the INPUT button on the remote control to
display the Input Source menu. Use the buttons
on the remote control to select HDMI1 / HDMI2 and
then press the OK button to confirm.
Making Video and Audio Connections
Not all AV devices have the ability to connect to a TV, please refer to the owner’s manual of your AV device for compatibility and
connection procedures.
When connecting any external AV device, do not connect the mains cable to the mains socket until all other connections are
complete.
Signal Type Separate Audio
Connection Required
HDMI1
HDMI
(480i/480p/576i/576p/720p/1080i/1080p*) No
PC IN
PC
Yes
PC AUDIO
YPbPr
Component Video
(480i/480p/576i/576p/720p/1080i/1080p*)
Yes
AV IN
SCART
SCART (RGB Input) No
AV IN
Composite Video No
Best Video
Performance
3 Connections
Chapter
3
*1080i/1080p: Although this TV is compatible with a 1080i/1080p input, it is possible that
the screen may not display the exact resolution and consequently the picture
quality will be adjusted accordingly.
Although this TV is able to connect to an HDMI
device, it is possible that some devices may not
operate correctly.
SCARTHDMI1(ARC) HDMI2 PC IN USB
5V 500mA
Digital Audio Output
(optical)
Rear Bottom View of TV
HDMI Cable
(not included)
Blu-ray Player / DVD Player /
Recorder
Set-top BoxGame Console

19
3
Connections
Connecting a Soundbar - HDMI ARC (Audio Return Channel)
The ARC (Audio Return Channel) function allows you to send audio from your ARC-compliant TV to ARC-compliant audio devices
(e.g. soundbar) through a single HDMI connection.
To enjoy the ARC function, please ensure your ARC-compliant audio devices are connected by an HDMI cable that support the
ARC function to the HDMI 1(ARC) socket of your ARC-compliant TV. When correctly set up, you can use your TV remote control to
adjust the volume output (VOL +/– and MUTE) of the connected audio device.
Connecting a Computer Using a VGA Cable
1. Use a VGA cable to connect the TV’s PC IN input
socket to a computer’s VGA output socket. Use an
audio cable to connect the TV’s PC AUDIO input
socket to the computer’s audio output socket.
2. Plug the connected devices into the mains socket
before switching on the TV.
3. Press the center of joystick function button under the
TV frame or the button on the remote control to
turn on your TV.
4. Press the INPUT button on the remote control
to display the Input Source menu. Use the
buttons on the remote control to select PC and
then press the OK button to confirm.
• The best resolution is 1366 x 768.
• If your computer is set to shut down after a few
minutes in the idle mode, the TV will also switch
to standby due to no signal being received, this
is to save energy. Press the center of joystick
function button under the TV frame or the
button on the remote control to restart the TV.
• Ensure that audio device is HDMI CEC and ARC compliant and that the TV is connected to the device using an HDMI cable
attached to HDMI-ARC connectors.
• The HDMI 1 connector is HDMI Audio Return Channel (ARC) compliant. Use it to output digital audio to an HDMI home
theater system.
• If the ARC-compliant audio devices do not support sound that TV outputs, such as Dolby Digital, or Dolby Digital Plus,
then ARC function will not work and there may be no sound from ARC-compliant audio devices. In this case, additional
connection with digital optical cable is necessary.
• The HDMI CEC feature has different trade names on different brands. The compatibility performance may vary with
different CEC-enabled devices.
• Please refer to your ARC-compliant devices' guidebook for more details on the operation of the HDMI ARC function.
• Ensure HDMI_CEC is On (refer to page 43 for details on HDMI_CEC).
TV HDMI-ARC compliant device
HDMI port with
ARC Function
HDMI Cable
(not included)
HDMI 1(ARC)
Rear Bottom View of TV
Rear Right Side View of TV
Computer
SCARTHDMI1(ARC) HDMI2 PC IN USB
5V 500mA
Digital Audio Output
(optical)
LAN RF
COMMON INTERFACE (CI)
HEADPHONE
PC AUDIO YPbPr AV IN
VGA Cable
(not included) Audio Cable
(not included)
Rear Right Side View of TV
LAN
RF
PC AUDIO

20
3Connections
Connecting an AV Device Using a Component (YPbPr) Cable
1. Connect the component cable from the TV’s YPbPr
input sockets to an external AV device’s component
output sockets.
2. Use an AV cable to connect the TV’s AV IN input
sockets to the external AV device’s component audio
output sockets. (Audio Left = white, and Audio Right
= red)
Component port on the TV YPb Pr
Video output ports on DVD
player
YPb Pr
Y Cb Cr
3. Plug the connected devices into the mains socket
before switching on the TV.
4. Press the center of joystick function button under the
TV frame or the button on the remote control to
turn on your TV.
5. Press the INPUT button on the remote control to
display the Input Source menu. Use the buttons
on the remote control to select YPbPr and then press
the OK button to confirm.
Connecting an AV Device Using a SCART Cable
1. Use a SCART cable to connect the TV’s SCART input
socket to an external AV device’s SCART output
socket.
2. Plug the connected devices into the mains socket
before switching on the TV.
3. Press the center of joystick function button under the
TV frame or the button on the remote control to
turn on your TV.
4. The TV will change the input source to SCART
automatically once the AV device is switched on.
SCARTHDMI1(ARC) HDMI2 PC IN USB
5V 500mA
Digital Audio Output
(optical)
SCART Cable
(not included)
VCR
DVD Player / Recorder
Set-top Box
Satellite Receiver
Satellite
antenna
cable
Rear Bottom View of TV
Satellite Receiver
Satellite
antenna
cable
Rear Right Side View of TV
LAN RF
COMMON INTERFACE (CI)
HEADPHONE
PC AUDIO YPbPr AV IN
Video Camera
Blu-ray Player / DVD Player /
Recorder
Set-top Box
Game Console
COMPONENT
OUT
L
R
Y
Pr
Pb
AV Cable
(not included)
Yellow Red White
Yellow (Video) Red (R)
White (L)
Composite
Adapter Cable
(included)
Red (R) White (L)
Yellow (Video)
Component
Cable
(not included)
Pb/Cb
Pr/Cr
Y
Pb/Cb Pr/Cr Y
Component
Adapter Cable
(included)
Blue (Pb/Cb) Red (Pr/Cr) Green (Y)
