JVC DLA-HD10K User manual

D-ILA®HD Projection Systems
DLA-HD10K
DLA-HD10KS
A Dream Come True
Ultimate Home Theater Performance with
Full HD Pictures and Stylish Design
DLA_HD10K_10KS_cata2.qxd 05.10.4 5:11 PM Page 4

Fill Your Screen With
The Amazing Film-Like Quality
Of Full HD Images.
— Indulge in the ultimate visionary experience.
DLA_HD10K_10KS_cata2.qxd 05.10.4 5:11 PM Page 7

Being able to watch a movie at home, while enjoying the same
superior resolution and excellent color reproduction that you get in a
movie theater, is a dream shared by film buffs the world over.
Now, with JVC's DLA-HD10K/KS, that dream has come true.
Thanks to our original D-ILA device, everything from skin tones to the
rough texture of a rock is reproduced with pristine, film-like quality.
With such extraordinary realism, you won’t just watch a movie,
you’ll experience it as if you were really there.
DLA_HD10K_10KS_cata2.qxd 05.10.4 5:11 PM Page 8

Advantages of 3-chip D-ILA technology
JVC’s original D-ILA technology
 Three D-ILA chips for smooth, flicker-free high-resolution images
JVC’s original 3-chip D-ILA (Direct Drive Image Light Amplifier) technology produces rich, natural colors without the annoying
flicker or “rainbow effect” that plagues single panel projectors. Images are as smooth as film, boasting incredible detail and
vibrant, breathtakingly natural colors.
 Cinema-quality picture with no visible grid
There is no visible grid or “screen door effect” with JVC’s D-ILA. You can enjoy the benefits of both film-like resolution and
accurate reproduction of natural colors.
Superior color reproduction
 Professional-standard gray scale reproduction
JVC’s unique optical engine produces rich, natural colors with smooth gradations and low noise. Color temperature is set at
6500K, providing optimal cinema reproduction.
 Analog gradation technology
JVC’s exclusive AG (Analog Gradation) technology produces highly accurate gradations with low noise, particularly in darker
areas of less than 20% brightness.
 High contrast ratio of 2000:1
High contrast of 2000:1 for excellent gray-scale reproduction enables reproduction of high-precision,
high-quality pictures without black paint even when the scene on screen is dark.
 True black reproduction
As the D-ILA’s liquid crystals are aligned vertically, the pixels are “normally black” when no voltage is applied. As a result, D-
ILA technology reproduces blacks that are truly black. It also offers a uniform response, irrespective of brightness, displaying
a wide range of intermediate tones.
 3 D-ILA chip imaging with
native 1080p resolution
JVC’s D-ILA imaging
chips with native 1920 x
1080 resolution utilize
“Non-Moving” mirror
reflective technology to
produce the full HD
resolution you need to enjoy Hollywood films
at their very best.
 High contrast ratio/
D65 color temperature
Thanks to the proven reliability of JVC’s optical
engine design and Dynamic Square Aperture,
high contrast is achieved in all modes from
Wide to Tele. The 2000:1 contrast ratio
produces intensely deep blacks for awesome
high-impact images. Accurate color
reproduction of video or film-originated
programming is ensured by the reference
standard D65 color temperature. An
illumination system with RGB-optimized
f-number delivers true D65 performance and
dynamic range.
Film-like Images and Excellent Color Reproduction
D65
SMPTE240
SMPTE240
D65
SMPTE240
DLA-HD2K
SMPTE240
DLA-HD10K Color Coordinates
(accurate colors with absolute
white and black)
Conventional projector (bluish white and
reddish black)
Comparison of gradation
characteristics
DLA_HD10K_10KS_cata2.qxd 05.10.4 5:16 PM Page 10

 Flexible installation
To accommodate the widest variety of theater sizes, two models
are available, each offering a different range of lens throw
distances. The DLA-HD10KS has a lens throw ratio of 1.5 –
2.1:1, while the DLA-HD10K has a lens throw ratio of 2.0 – 3.8:1.
Precision high-resolution all-glass lenses with motorized zoom
and focus make installation a snap, while installation flexibility is
further enhanced by lens shift capability. The light path is
centered horizontally, allowing the projector to be perfectly
centered in the theater.
The low-cost, long-life lamp (200 W NUP) can be easily replaced
without removing the projector from the ceiling.
 Low fan noise design
Any external noise can be annoying when you are trying to enjoy
a movie. That’s why JVC has developed an original new airflow
design that provides optimum cooling while keeping the noise
level down to a near silent 27 dB. Thanks to this low fan noise
design, subtle sounds in quiet scenes on-screen are not
overwhelmed by outside noise.
 Stylish design suitable for high-end
home theater
Designed as the centerpiece of the movie fan’s ultimate space,
this projector adds a touch of elegance and beauty to any home
theater. The projector’s gorgeous alumite finish compliments the
grandest home theater décor.
Sleek Design and Easy Setup
Two Processors Available
Installation flexibility is enhanced still
more by a compact 2-piece design.
Two types of processor are available.
Simply choose the one most
appropriate to your needs. Also ready
for the future with HTPC
compatibility.
 Convenient 2-piece
installation
The lightweight 37-lb. Projector is located in
the theater itself, while the critical Digital Video
Processor is mounted in the equipment rack
adjacent to the video sources. Only one DVI
interface cable is required between the
processor and projector, ensuring that
maximum signal integrity is maintained.
You can choose from 2 optional processors – a
standard one and an exclusive one developed
in cooperation with Faroudja.
DLA-HD10
LD-HD2K
LD-HD2KS
+
+
Designed to impress with a sleek stylishness that
will attract envious glances in any home theater,
these flagship projectors offer the flexibility you
need for home installation. Both long-focus and
short-focus models are available, and each
features a lens shift function to ensure the highest
degree of installation flexibility.
DLA_HD10K_10KS_cata2.qxd 05.10.4 5:16 PM Page 11

“JVC” is the trademark or registered trademark of Victor Company of Japan, Limited.
DISTRIBUTED BY
Design and specifications subject to change without notice.
D-ILA is a registered trademark of Victor Company of Japan, Limited.
All brand or product names may be trademarks and/or registered trademarks of their respective owners.
Any rights not expressly granted herein are reserved.
All photographs and screenshots in this catalog are simulated.
Copyright © 2005, Victor Company of Japan, Limited (JVC). All Rights Reserved.
Throw Distance vs. Screen Size
Dimensions
Connectors
Projector: Remote control unit, power cord, instructions
Processor: Remote control unit, power cord, two AA batteries,
instructions, warning card
JVC PROFESSIONAL PRODUCTS COMPANY
DIVISION OF JVC AMERICAS CORP.
1700 Valley Road, Wayne, N.J. 07470
TEL: [phone] Fax: [phone]
Internet Web Site http://www.jvc.com/pro
E-mail: [email protected]
JVC CANADA INC.
21 Finchdene Square, Scarborough, Ontario M1X1A7
Tel: [phone] Fax: [phone]s
Internet Web Site http://www.jvc.ca/en/pro/
Specifications
Projectors
Image Device 3-chip D-ILA®(0.82-inch diagonal)
Aspect Ratio 16:9
Throw Distance (16:9) Short focus: 6.43 ft to 30.57 ft (1.9 m to 9.3 m)
Long focus: 8.46 ft to 49.23 ft (2.5 m to 15.0 m)
Screen Size (16:9) 60" to 200" diagonal
Resolution 1920 x 1080 pixels (16:9) x 3 chips;
Total resolution: 6,220,800 pixels
Projection Lens Short focus: 1.3X zoom lens (1.5 – 2.1:1)
Long focus: 1.9X zoom lens (2 – 3.8:1)
Power zoom/focus, 0 - 60% offset with manual shift
Lamp 200 W NUP
Contrast Ratio 2000:1
Color Temperature D65/user selectable 1/user selectable 2
Gamma Control Normal, A, B, and CUSTOM
Noise Level 27 dB
TERMINALS
Input Digital x 1 (HDCP compatible DVI-D)
Serial Control RS-232C x 1, screen trigger (12 V) x 1
GENERAL
Power Requirement 100 V – 240 V AC, 50/60 Hz
Power Consumption 350 W (5 W at standby)
Calorific Power 1260 kJ/h (1194 Btu)
Dimensions (WHD) 20-1/4" x 7-11/16" x 22-1/16" (513 x 193.7 x 558.5 mm)
Weight Approx. 37 lbs. (17 kg)
CONTROL TERMINALS
Serial Control 1 source (RS-232C)
Digital Video Processors
Provided accessories
Screen Size Throw Distance
Diagonal Width Wide Tele
in. mm ft. m ft. m ft.
60 1328 4.36 1.96 6.43 2.77 9.09
70 1550 5.08 2.29 7.51 3.23 10.59
80 1771 5.81 2.63 8.63 3.70 12.14
90 1992 6.53 2.96 9.71 4.17 13.68
100 2214 7.26 3.29 10.79 4.64 15.22
110 2435 7.99 3.63 11.91 5.11 16.76
120 2657 8.71 3.96 12.99 5.57 16.27
130 2878 9.44 4.29 14.07 6.04 19.81
140 3099 10.16 4.63 15.19 6.51 21.35
150 3321 10.89 4.96 16.27 6.98 22.89
160 3542 11.62 5.30 17.38 7.45 24.44
170 3764 12.35 5.63 18.47 7.91 25.94
180 3985 13.07 5.96 19.55 8.38 27.49
190 4206 13.80 6.30 20.66 8.85 29.03
200 4428 14.53 6.63 21.75 9.32 30.57
Short-focus Zoom (1.5 to 2.1: 1 lens, aspect ratio: 16:9)
Screen Size Throw Distance
Diagonal Width Wide Tele
in. mm ft. m ft. m ft.
60 1328 4.36 2.58 8.46 4.94 16.20
70 1550 5.08 3.02 9.91 5.78 18.96
80 1771 5.81 3.46 11.35 6.62 21.71
90 1992 6.53 3.90 12.79 7.46 24.47
100 2214 7.26 4.34 14.24 8.30 27.22
110 2435 7.99 4.79 15.71 9.14 29.98
120 2657 8.71 5.23 17.15 9.98 32.73
130 2878 9.44 5.67 18.60 10.82 35.49
140 3099 10.16 6.11 20.04 11.65 38.21
150 3321 10.89 6.55 21.48 12.49 40.97
160 3542 11.62 6.99 22.93 13.33 43.72
170 3764 12.35 7.43 24.37 14.17 46.48
180 3985 13.07 7.88 25.85 15.01 49.23
190 4206 13.80 8.32 27.29
200 4428 14.53 8.76 28.73
Long-focus Zoom (2.0 to 3.8, aspect ratio: 16:9)
Projector
LD-HD2K LD-HD1K
Input Signals 480i (H: 15.7 kHz, V: 29.97 Hz), 480p (H: 31.5 kHz, V: 59.97 Hz)
576i (H: 15.6 kHz, V: 25.00 Hz), 576p (H: 31.3 kHz, V: 50.00 Hz)
720p (H: 37.5 kHz, V; 50.00 Hz), 720p (H: 45.0 kHz, V: 59.97 Hz)
1080i (H: 28.1 kHz, V: 25.00 Hz), 1080i (H: 33.7 kHz, V: 29.97 Hz)
TERMINALS
Input Terminals RGBCs (BNC), DVI (HDCP compatible Coaxial x 2, Optical x 2,
DVI-D)*, Video (BNC), Y/C (Mini DIN), HDMI x 4, RCA (L/R) x 1
YPbPr (BNC), Serial Control:
1 source (RS-232C)
Output Terminals DVI (HDCP compatible DVI-D)* RGB/YPbPr (HDMI),
RGNHV/YPbPr/RGBs/RGB
(BNC),digital audio x 6
Control Terminals Remote: 1 source, Trigger: 1 source,
(Output active only when Serial Control: 1 source (RS-232C)
DVI-D output is not enabled.)
GENERAL
Power Requirement 100 V – 240 V AC, 50/60 Hz
Power Consumption 35 W
Calorific Power 126 kJ/h (119 Btu)
Dimensions (W x H x D) 17-1/4" x 1-3/4" x 11-15/16" 17-1/8" x 2-3/16" x 10-3/8"
(438 x 45 x 303 mm) (434 x 55 x 263 mm)
without protrusions
Weight 14 lbs. (6.3 kg) 6.4 lbs. (2.9 kg)
* Terminals other than DVI are not used
for D-ILA HD Projection System.
*HDMI compliant with optional
adapter cable
