JVC KD-X560BT User manual

• For detailed operations and information, refer to the INSTRUCTION MANUAL on the following website:
• Pour plus d’informations et de détails sur les opérations, reportez-vous au MODE D’EMPLOI sur le site Internet suivant :
• Para obtener información y detalles sobre las operaciones, consulte el MANUAL DE INSTRUCCIONES en el siguiente sitio
web:
<http://www.jvc.net/cs/car/>
KD-X560BT
DIGITAL MEDIA RECEIVER
Quick Start Guide
RÉCEPTEUR MÉDIA NUMÉRIQUE
Guide de démarrage rapide
RECEPTOR DE MEDIOS DIGITALES
Guía de inicio rápido
B5K-0634-10 (K)© 2019 JVC KENWOOD Corporation
B5K-0634-10_K_EnFrEs.indb 1 2019/03/05 20:36

2
Before use
Before use................................................................................ 2
How to read this manual..................................................................................2
Precautions ...............................................................................................................2
Getting Started...................................................................... 3
Initial Settings..........................................................................................................3
Clock settings..........................................................................................................3
Basics ......................................................................................... 4
Common operations..........................................................................................4
How to attach/detach the faceplate........................................................4
Select a source........................................................................................................4
USB/iPod................................................................................... 5
Preparation................................................................................................................5
Playback operations............................................................................................5
Tuner.......................................................................................... 6
Tuner Basic Operations .....................................................................................6
Tuner function settings ....................................................................................6
External Components ......................................................... 7
Rear view camera..................................................................................................7
Bluetooth® smartphone..................................................... 8
Register your smartphone to the unit ....................................................8
Receive a call............................................................................................................8
Make a phone call.................................................................................................8
Playing Bluetooth Audio Device.................................................................8
Setup.......................................................................................... 9
Settings........................................................................................................................9
Sound settings........................................................................................................9
Installation.............................................................................10
Before Installation...............................................................................................10
Installing the unit................................................................................................11
About this Unit..................................................................... 14
Maintenance..........................................................................................................14
Note for specifications.....................................................................................14
Copyrights...............................................................................................................14
Precautions
#WARNING
Ñ To prevent injury or fire, take the
following precautions:
• To prevent a short circuit, never put or leave any
metallic objects (such as coins or metal tools)
inside the unit.
• Do not watch or fix your eyes on the unit’s display
when you are driving for any extended period.
• If you experience problems during installation,
consult your JVC dealer.
Ñ Precautions on using this unit
• When you purchase optional accessories, check
with your JVC dealer to make sure that they work
with your model and in your area.
• The Radio Data System or Radio Broadcast Data
System feature won’t work where the service is
not supported by any broadcasting station.
Ñ Protecting the monitor
• To protect the monitor from damage, do not
operate the monitor using a ballpoint pen or
similar tool with the sharp tip.
Ñ How to reset your unit
If the unit or the connected unit fails to operate
properly, reset the unit.
1
2
3
Reset button
Contents
How to read this manual
• The panels shown in this guide are examples used to
provide clear explanations of the operations. For this
reason, they may be different from the actual panels.
• In operation procedures, bracket shape indicates the
item you should control.
[ ]: indicates the selected items or menu.
< >: indicates the name of panel buttons.
• Display language: English is used for the purpose of
explanation. You can select a display language from
the [Language] menu. See Language (P.9).
B5K-0634-10_K_EnFrEs.indb 2 2019/03/05 20:36

3
English |
Continued on the next page...
Getting Started
Initial settings
1 Turn the ignition key of your car to ACC.
The unit is turned on.
2 Turn the volume knob to select the item to set
(see the table below), then press the knob to
make a selection.
Language
Select the language used for the control screen and
setting items. Default is “English”.
Area
N.AMERICA (Default): For North America, AM/FM
intervals: 10 kHz/200 kHz
S.AMERICA: For Central/South America, AM/FM
intervals: 10 kHz/50 kHz
EUROPE: For Europe, AM/FM intervals: 9 kHz/50 kHz.
Date/Clock
Adjust the date, then adjust the time.
Hour / Minute / Month / Day / Year
Demo
Set the demonstration mode. Default is “ON”.
3 Turn the volume knob to select [Finish], then
press the knob.
Clock settings
Ñ Synchronizing the clock time with FM
RDS
Activate [RDS Clock Sync]. See“Tuner function
settings”(P.6).
Ñ Adjusting the clock manually
✎NOTE
• Deactivate [RDS Clock Sync] before adjusting the
clock. See “Tuner function settings” (P.6).
1 Press and hold < > to display the settings.
2 Press <E>/<F> to select [ ].
3 Turn the volume knob to select [Time Format],
then press the knob to select the time format
([12h] or [24h]).
4 Turn the volume knob to select [Date/Clock],
then press the knob.
Clock screen appears.
5 Turn the volume knob to adjust the hour, then
press the knob.
6 Turn the volume knob to adjust the minute,
then press the knob.
7 Turn the volume knob to adjust the month,
then press the knob.
8 Turn the volume knob to adjust the day, then
press the knob.
9 Turn the volume knob to adjust the year, then
press the knob.
10 Press < >.
B5K-0634-10_K_EnFrEs.indb 3 2019/03/05 20:36

4
BasicsBasics
Common operations
Ñ Turning on the power
1 Press < >.
Ñ Turning off the power
1 Press and hold < >.
Ñ Adjusting the volume
1 Turn the volume knob.
Ñ Mutes the sound
1 Press and hold the volume knob.
appears when the mute function is active.
⿠To restore the sound, press and hold again, or
adjust the volume.
Ñ Display the clock
1 Press and hold the <DIM> button.
Ñ Select dimmer mode
1 Press the <DIM> button.
Dimmer 1, Dimmer 2, Dimmer 3
How to attach/detach the faceplate
1
2
1
2
AttachDetach
Select a source
1 Press < > to display the HOME screen.
HOME screen appears.
2 Turn the volume knob to select the source, then
press the knob.
2
5
3
6
4
1
1Clock display
2Switches to the FM tuner broadcast. (P.6)
3Switches to the AM tuner broadcast. (P.6)
4Plays a Bluetooth audio player. (P.8)
5[USB]
Plays files on a USB device. (P.5)
[iPod]
Plays an iPod/iPhone. (P.5)
• When iPod/iPhone is connected.
6Switches to an external component connected to
the AUX input terminal.
Volume knob (turn/press)
MonitorDetach button
Remote sensor
B5K-0634-10_K_EnFrEs.indb 4 2019/03/05 20:36

5
English |
USB/iPod
Continued on the next page...
USB/iPod
Preparation
Ñ Connecting a USB device/iPod/iPhone
1 Open the front port cover.
2 Connect the USB device with the USB cable
(sold separately).
Connect the iPod/iPhone using the KS-U62
(optional accessory).
The unit reads the device and playback starts.
• USB maximum power supply current :
DC 5 V = 1 A
Ñ To disconnect the USB device/iPod/
iPhone
1 Press < > to display the HOME screen.
2 Turn the volume knob to select other than
[USB] and [iPod], then press the knob.
3 Detach the USB device/iPod/iPhone.
Ñ Usable USB device
This unit can play MP3/ WMA/ AAC/ WAV/ FLAC/
OGG/ MPEG1/ MPEG2/ MPEG4/ H.264/ MKV/ JPEG/
BMP/ PNG files stored in a USB mass storage class
device.
Ñ Connectable iPod/iPhone
The following models can be connected to this unit.
Made for
• iPhone X
• iPhone 8 Plus
• iPhone 8
• iPhone 7 Plus
• iPhone 7
• iPhone SE
• iPhone 6s Plus
• iPhone 6s
• iPhone 6 Plus
• iPhone 6
• iPhone 5s
• iPod touch (6th
generation)
Playback operations
To Do this
Play/pause Press the volume knob.
Select a file Press <E>/<F> repeatedly.
Fast-backward/
Fast-forward
Press and hold <E>/<F>.
• Video files: Each time you press
the button, the search speed
changes.
Ñ Selecting a track/content in a list
(Searches file)
1 Press < > to display the LIST screen.
2 Press <E>/<F> to select whether you
search by audio files [ ], video files [ ] or
picture files [ ]. (USB only)
3 Turn the volume knob to select the desired
folder/category, then press the knob.
• When you select a folder its contents are
displayed.
• To return to the previous layer, press < >.
4 Turn the volume knob to select the desired
item, then press the knob.
Playback starts.
B5K-0634-10_K_EnFrEs.indb 5 2019/03/05 20:36

6
Tuner
Tuner
Tuner basic operations
1 Press < > to display the HOME screen.
2 Turn the volume knob to select [FM] or [AM],
then press the knob.
3 Press <E>/<F> to search for a station
automatically.
“Auto Seek” appears.
(or)
Press and hold <E>/<F> repeatedly to
search for a station manually.
“Manual Seek” appears.
✎NOTE
• To store stations, perform [Manual Store] or [Auto
Store].
Ñ Select a stored station
You can preset 15 stations for FM and 15 stations
for AM.
1 Press < > to display the LIST screen.
2 Turn the volume knob to select a preset
number, then press the knob.
✎NOTE
• To exit, press < >.
Tuner function settings
1 Press < > to display the function menu.
2 Turn the volume knob to select the item to set
(see the table below), then press the knob to
make a selection.
3 Press < >.
Manual
Store
Stores a station manually.
While listening to a station you want to
store, turn the volume knob to select a
preset number, then press the knob.
Auto
Store
Automatically searches and stores the 15
stations with the strongest signals for the
selected band.
• “Auto Store” appears.
Local
Seek
Tunes in only to the stations with sufficient
signal strength.
“ON”, “OFF” (Default)
Area N.AMERICA (Default): For North America,
AM/FM intervals: 10 kHz/200 kHz
S.AMERICA: For Central/South America,
AM/FM intervals: 10 kHz/50 kHz
EUROPE: For Europe, AM/FM intervals: 9
kHz/50 kHz.
Mono *1Determines whether to receive stereo
broadcasts in the stereo mode or
monaural mode.
“ON”, “OFF” (Default)
RDS
Clock
Sync *1
Synchronizing the Radio Data System
station time data and this unit’s clock.
“ON” (Default), “OFF”
*1 FM only
B5K-0634-10_K_EnFrEs.indb 6 2019/03/05 20:36

7
English |
Continued on the next page...
External Components
Rear view camera
To use a rear view camera, the REVERSE lead
connection is required. For connecting a rear view
camera. (P.12)
Ñ Displaying the picture from the rear
view camera
The rear view screen is displayed when you shift the
gear to the reverse (R) position.
Ñ To display the picture from the rear view
camera manually
1 Press <CAMERA>.
B5K-0634-10_K_EnFrEs.indb 7 2019/03/05 20:36

8
Bluetooth® smartphoneBluetooth® smartphone
Register your smartphone to the
unit
You can use your Bluetooth smartphone when
paired to this unit.
• You can pair the device and the unit using SSP
(Secure Simple Pairing) which only requires
confirmation.
• One device can be connected at a time.
• When you register a new Bluetooth device,
disconnect the Bluetooth device currently
connected and then register the new device.
1 Turn on the Bluetooth function on your
smartphone/cell-phone.
2 Search the unit (“KD-X56*”) from your
smartphone/cell-phone.
If a PIN code is required, enter the PIN code
(“0000”).
Ñ Disconnecting the device
• Turn off the Bluetooth function from your
smartphone/cell-phone.
• Turn off the ignition switch.
Ñ About smartphone compatible with
Phone book Access Profile (PBAP)
If your smartphone supports PBAP, you can display
the following items when the smartphone is
connected.
• Phone book
• Dialed calls, received calls, and missed calls
Receive a call
To Do this
Answer a call Press < >.
Ñ Operations during a call
To Do this
End a call Press < >.
Adjust the phone
volume
Turn the volume knob.
Switching between
hands-free mode and
phone mode
Press < >.
Each time you press the
button, “Transfer!” appears
and talking method is
switched between hands-
free mode and phone mode.
Make a phone call
1 Press < > to enter Bluetooth mode.
2 Press <E>/<F> to select a method to make
a call ([ ]: from the calls history/[ ]: from
the phone book).
3 Turn the volume knob to select the target, then
press the knob to make a call.
Playing Bluetooth Audio Device
1 Press < > to display the HOME screen.
2 Turn the volume knob to select [BT Audio], then
press the knob.
To Do this
Play/pause Press the volume knob.
Select a file Press <E>/<F> repeatedly.
Fast-backward/
Fast-forward
Press and hold <E>/<F>.
✎NOTE
• Operations and display indications may differ
according to their availability on the connected
device.
Ñ Selecting a content in a list
1 Press < > to display the LIST screen.
2 Turn the volume knob to select an item, then
press the knob.
• To return to the previous layer, press < >.
B5K-0634-10_K_EnFrEs.indb 8 2019/03/05 20:36

9
English |
Setup
Continued on the next page...
Setup
Settings
1 Press and hold < > to display the settings.
2 Press <E>/<F> to select the category.
3 Turn the volume knob to select an item (see the
following table), then press the knob.
4 Repeat step 3 until the desired item is selected/
activated or follow the instructions stated on
the selected item.
5 Press < >.
Audio Settings
Fader R12 — F12 (00): Adjusts the front and
rear speaker output balance.
Balance L12 — R12 (00): Adjusts the left and
right speaker output balance.
General Settings
Beep ON/OFF: Activates or deactivates the
keypress tone. Default is “ON”.
Date/Clock Adjusts the date and clock. (P.3)
Language Selects the text language used for on-
screen information.
Time
Format
12h/24h: Selects time format. Default
is “12h”.
Wallpaper Black/Blue: Selects the wallpaper
image.
Demo Set the demonstration mode. Default
is “ON”.
Initialize Select [Initialize] and then select [Yes]
to set all the settings to the initial
default settings.
Bluetooth Settings
Sync
Phonebook
ON/OFF: Activates or deactivates the
synchronization of the phonebook
in the connected smartphone with
the unit.
BT
Information
Displays the information about the
connected Bluetooth device (device
name, phone name, and mac address).
Sound settings
1 Press < > to display the sound setting.
2 Turn the volume knob to select an item (see the
following table), then press the knob.
3 Repeat step 2 until the desired item is selected/
activated or follow the instructions stated on
the selected item.
4 Press < >.
Graphic
Equalizer
Selects a preset equalizer suitable to the
music genre.
Flat / DRVN / Hard Rock / Hip Hop / Jazz
/ Pop/ R & B / User / Classical
Select [User] to use the settings made
1) Press the volume knob to select the
frequency.
2) Turn the volume knob to adjust the
level.
3) Press < >.
Loudness Sets the amounts of boost of low and
high tones.
“ON”, “OFF” (Default)
X’over You can set the crossover frequency of
speakers.
1) Press <E>/<F> to select the
speaker.
2) Press the volume knob to select the
item.
3) Turn the volume knob to adjust the
value.
4) Press < >.
Delay Adjust the sound delay time so that the
sounds from different speakers arrive at
the listener sitting on the selected seat
at the same time.
1) Press <E>/<F> to select the
speaker.
2) Turn the volume knob to adjust the
value.
3) Press < >.
B5K-0634-10_K_EnFrEs.indb 9 2019/03/05 20:36

10
InstallationInstallation
Before installation
Before installation of this unit, please note the
following precautions.
#WARNINGS
• If you connect the ignition wire (red) and the battery
wire (yellow) to the car chassis (ground), you may
cause a short circuit, that in turn may start a fire.
Always connect those wires to the power source
running through the fuse box.
• Do not cut out the fuse from the ignition wire (red)
and the battery wire (yellow). The power supply
must be connected to the wires via the fuse.
#CAUTION
• Install this unit in the console of your vehicle.
Do not touch the metal part of this unit during and
shortly after the use of the unit. Metal part such as
the heat sink and enclosure become hot.
✎NOTE
• Mounting and wiring this product requires skills and
experience. For best safety, leave the mounting and
wiring work to professionals.
• Make sure to ground the unit to a negative 12V DC
power supply.
• Do not install the unit in a spot exposed to direct
sunlight or excessive heat or humidity. Also avoid
places with too much dust or the possibility of water
splashing.
• Do not use your own screws. Use only the screws
provided. If you use the wrong screws, you could
damage the unit.
• If your car’s ignition does not have an ACC position,
connect the ignition wires to a power source that
can be turned on and off with the ignition key. If you
connect the ignition wire to a power source with a
constant voltage supply, such as with battery wires,
the battery may be drained.
• If the console has a lid, make sure to install the unit
so that the front panel will not hit the lid when
closing and opening.
• If the fuse blows, first make sure the wires aren’t
touching to cause a short circuit, then replace the
old fuse with one with the same rating.
• Insulate unconnected wires with vinyl tape or other
similar material. To prevent a short circuit, do not
remove the caps on the ends of the unconnected
wires or the terminals.
• Secure the wires with cable clamps and wrap vinyl
tape around the wires that comes into contact with
metal parts to protect the wires and to prevent short
circuit.
• Connect the speaker wires correctly to the terminals
to which they correspond. The unit may be
damaged or fail to work if you share the ¤wires or
ground them to any metal part in the car.
• When only two speakers are being connected to
the system, connect the connectors either to both
the front output terminals or to both the rear output
terminals (do not mix front and rear). For example,
if you connect the ¢connector of the left speaker
to a front output terminal, do not connect the ¤
connector to a rear output terminal.
• After the unit is installed, check whether the brake
lamps, blinkers, wipers, etc. on the car are working
properly.
• Mount the unit so that the mounting angle is 30°
or less.
• Do not press hard on the panel surface when installing
the unit to the vehicle. Otherwise scars, damage, or
failure may result.
• Reception may drop if there are metal objects near
the Bluetooth antenna.
Bluetooth antenna unit
Ñ Supplied accessories for installation
1
x1
2
x1
3
x2
4
x1
5(3 m)
x1
6
x1
7
x1
8
(M5 × 6 mm) x6
9
(M5 × 8 mm) x6
B5K-0634-10_K_EnFrEs.indb 10 2019/03/05 20:36
