This camera has been designed to assure precise colour
reproduction in low light situations. It is possible to identify
image colours in much darker places.
Printed in Japan
KCN-1856D TK-C2201E(EX) 2011/9
Design and specifications subject to change without notice.
DISTRIBUTED BY
High-Resolution Day & Night Surveillance Camera with
Ultra-Compact, Vandal-Resistant Design
■Super LoLux 2TM “COLOUR IN VIRTUAL ZERO LUX”
Normal camera JVC Super LoLuxTM
For assisting focusing to the finest point, the Variable-Focal
lens now incorporates a newly developed focus gear
mechanism (Patent Pending).
■Fine Focus Adjustment Technology
An external monitor can be
connected via the RCA jack.
You can easily check the
camera angle on the spot
during or after installation.
■RCA Monitor Output for Quick Installation
Normal Focus ring and
lock screw
New “Fine Adjust”
mechanism
With a very subtle movement, finer,
more accurate adjustment is
possible.
Patent
Pending
Note: Screen images are explanatory purpose and not actual images attained using this product.
All brand or product names may be trademarks and/or registered trademarks of their respective owners.
Copyright © 2011, Victor Company of Japan, Limited. All Rights Reserved.
3DNR is the powerful method to improve image quality even
though it’s shot in the dark. Noise data is detected by
comparing some continuous frames and reduced by blending
it into other frames over time.
■3D Noise Reduction (3DNR)
Normal 3DNR
Specifications
Unit: mm
Ceiling recessed installation with
WB-S2205 optional bracket
TK-C2201E(EX)
Signal system PAL
Image device 1/3 type IT CCD
Number of effective pixels 440,000 (752H x 582V)
Sync system Internal
Scanning system 2:1 interlace, 625 lines
Scanning frequency 15.625kHz (H), 50Hz (V)
Video output Composite video signal: 1.0V (p-p), 75 ohms (BNC)
Video S/N ratio 52 dB (AGC off)
Horizontal resolution 600 TV lines
Minimum illumination (typical) 0.05 lx (50%, F1.2, AGC HIGH)
0.025 lx (25%, F1.2, AGC HIGH)
B&W mode 0.03 lx (50%, F1.2, AGC HIGH)
0.015 lx (25%, F1.2, AGC HIGH)
Iris control DC iris
White balance ATW (wide/narrow) / AWC / Manual
(ATW colour temp. range: 2300K to 10,000K)
Day/Night Easy D/N
3DNR NORMAL / HIGH
Display mode (Monitor type) LCD1/LCD2/CRT
BLC off/on (4 patterns)
AGC OFF/MID/HIGH
Sens-up off / x2 to x128
Digital zoom x1, x1.4, x2
Privacy mask 4 areas
Focus adjustment mode Yes
Lens Focal length 2.8mm to 10.5mm, 3.75x vari-focal
(angle of vision) (100 (H) x 73 (V) to 24 (H) x 21( V))
Aperture ratio F1.2 (f=2.8mm) to F3.6 (f=10.5mm)
Angle Adjustment range Horizontal: 350°, Vertical: ±80°, Rotation: ±100°
Power supply 24VAC (50Hz/60Hz) / 12VDC
Power consumption 190 mA
Operating temperature range -10°C to 50°C
(0°C to 40°C recommended)
Vandal protection Vandal Resistant
Dimensions (WxHxD) ø110mm x 97mm (H)
Weight (approx.) 330g
Optional accessory WB-S2205 Ceiling recessed bracket
Dimensions
