SERVICE MANUAL
COPYRIGHT © 2010 Victor Company of Japan, Limited No.MB744<Rev.001>
2010/5
COMPACT COMPONENT SYSTEM
MB744<Rev.001>20105SERVICE MANUAL
NX-T5B, NX-T5E, NX-T5EN,
NX-T5EV, NX-T5EE
COPYRIGHT © 2010 Victor Company of Japan, Limited
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
CA-NXT5SP-NXT5F SP-NXT5F SP-NXT5W

1-2 (No.MB744<Rev.001>)
SPECIFICATION
Main unit-CA-NXT5
Input/output
HDMI output HDMI OUT
USB terminal USB MEMORY PLAY
Analog audio input AUDIO IN 500 mV/50 kΩ
Digital audio input DIGITAL IN (OPTICAL) -21 dBm to -15 dBm (660 nm±30 nm)
Analog video output VIDEO OUT Color system PAL
Composite video, 1 V(p-p)/75Ω
Tuner
FM tuning range 87.50 MHz - 108.00 MHz
Disc player
Playable disc DVD Video/CD/VCD/SVCD
CD-R/CD-RW (CD/SVCD/VCD/MP3/JPEG/MPEG-1/MPEG-2/DivX format)
DVD-R/-RW (DVD Video/DVDVR/MP3/JPEG/MPEG-1/MPEG-2/DivX format)
+R/+RW (DVD Video/MP3/JPEG/MPEG-1/MPEG-2/DivX format)
Dynamic range 80 dB
Horizontal resolution 500 lines
Wow and flutter Immeasurable
USB
Playable files MP3/JPEG/MPEG-1/MPEG-2/DivX format
USB specification Compatible with USB 2.0 Full Speed
Compatible device Mass storage class
Compatible system FAT16, FAT32
Bus power supply DC 5 V 500 mA
HDMI
Video resolution 576p, 720p, 1080i, 1080p
Output power (HDMI OUT) DC 5 V 55 mA
General
Mass (approx.) 2.3 kg
Dimensions (approx.) Placed vertically A: 240 mm B: 420 mm C: 64 mm D: 70 mm E: 134 mm
Placed horizontally F: 420 mm G: 70 mm H: 240 mm
Subwoofer-SP-NXT5W
Output power Front 100 W (50 W + 50 W) at 6 Ω(10% THD)
Subwoofer 100 W at 3 Ω(10% THD)
Speaker Bass reflex type 16 cm cone x 1
Power handling capacity 100 W
Frequency range 40 Hz - 150 Hz
Sound pressure level 77 dB/W ·m
G
F
H
CD
E
A
B

(No.MB744<Rev.001>)1-3
Design and specifications are subject to change without notice.
Power requirements AC 230 V , 50 Hz
Power consumption 40 W (at operation of the System)
1.00 W or less (on standby)
Mass (approx.) 9.2 kg
Dimensions (approx.) 231 mm ×393 mm ×370.5 mm (W/H/D)
Speakers-SP-NXT5F
Speaker 1 way bass reflex type 8 cm cone x 1
Impedance 6 Ω
Power handling capacity 50 W
Frequency range 75 Hz - 20 kHz
Sound pressure level 82 dB/W ·m
Mass (approx.) 0.83 kg each
Dimensions (approx.) 100 mm ×240 mm ×128 mm (W/H/D)

1-4 (No.MB744<Rev.001>)
SECTION 1
PRECAUTION
1.1 Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purpos-
es. For continued protection, no changes should be made
to the original design unless authorized in writing by the
manufacturer. Replacement parts must be identical to
those used in the original circuits. Services should be per-
formed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteris-
tics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by us-
ing replacement components rated for higher voltage, watt-
age, etc. Replacement parts which have these special
safety characteristics are identified in the Parts List of Ser-
vice Manual. Electrical components having such features
are identified by shading on the schematics and by ( ) on
the Parts List in the Service Manual. The use of a substitute
replacement which does not have the same safety charac-
teristics as the recommended replacement parts shown in
the Parts List of Service Manual may create shock, fire, or
other hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassem-
bling.
(5) Leakage shock hazard testing
After reassembling the product, always perform an isola-
tion check on the exposed metal parts of the product (an-
tenna terminals, knobs, metal cabinet, screw heads,
headphone jack, control shafts, etc.) to be sure the product
is safe to operate without danger of electrical shock.Do not
use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particular-
ly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage cur-
rent must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an
AC voltmeter having, 1,000Ωper volt or more sensitivity
in the following manner. Connect a 1,500Ω10W resistor
paralleled by a 0.15µF AC-type capacitor between an ex-
posed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal
part, particularly any exposed metal part having a return
path to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Voltage measured any must
not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5
mA AC (r.m.s.).
1.2 Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for local
voltage.
1.3 Caution
Burrs formed during molding may be left over on some parts
of the chassis.
Therefore, pay attention to such burrs in the case of pre-
forming repair of this system.
1.4 Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety. When replacing them, be sure to use the parts of the
same type and rating as specified by the manufacturer.
(This regulation dose not Except the J and C version)
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE

(No.MB744<Rev.001>)1-5
1.5 Preventing static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser
diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
1.5.1 Grounding to prevent damage by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.
Be careful to use proper grounding in the area where repairs are being performed.
(1) Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.
(2) Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
(3) Handling the optical pickup
• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.
1.6 Handling the traverse unit (optical pickup)
(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the
replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a
time when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4) I t is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.
1M
Conductive material
(conductive sheet) or iron palate
(caption)
Anti-static wrist strap

1-6 (No.MB744<Rev.001>)
1.7 Important for laser products
1.CLASS 1 LASER PRODUCT
2.CAUTION :
(For U.S.A.) Visible and/or invisible class II laser radiation
when open. Do not stare into beam.
(Others) Visible and/or invisible class 1M laser radiation
when open. Do not view directly with optical instruments.
3.CAUTION : Visible and/or invisible laser radiation when
open and inter lock failed or defeated. Avoid direct
exposure to beam.
4.CAUTION : This laser product uses visible and/or invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.
REPRODUCTION AND POSITION OF LABELS and PRINT
!Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
WARNING LABEL and PRINT

(No.MB744<Rev.001>)1-7
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.
SECTION 3
DISASSEMBLY
3.1 Main body (Used model: NX-T5E)
3.1.1 Removing the DVD door
(1) Connect the Main unit and Subwoofer.
(2) Power to ON and then open the DVD door.
(3) Slide to front side and pull up the DVD door.
3.1.2 Removing the Top cabinet (See Fig.1,2, 3, 4)
(1) Disconnect the card wire from DVD MPEG board connect-
ed to connector CNC1 and CNC5 of the Connect board.
(See Fig.1)
Fig.1
(2) Remove the four screws Aattaching the Top cabinet. (See
Fig.2)
Fig.2
(3) Remove the three screws Battaching the Top cabinet.
(See Fig.3)
Fig.3
(4) Disconnect the card wire from DVD MPEG board connect-
ed to connector CON401 of the Display board. (See Fig.4)
Fig.4
3.1.3 Removing the DVD mechanism (See Fig.5)
(1) Remove the four screws Cattaching the DVD mechanism.
(2) Remove the two screws Dattaching the Connect board.
Fig.5
CNC5CNC1
A
B
CON401
CC
D

1-8 (No.MB744<Rev.001>)
3.1.4 Removing the Display board (See Fig.6)
(1) Remove the six screws Eattaching the Display board.
(2) Disconnect the card wire from Key board connected to con-
nector CON402 and CON403 of the Display board.
Fig.6
3.1.5 Removing the DVD MPEG board (See Fig.7, 8)
(1) Remove the two screws F attaching the DVD MPEG board.
(See Fig.7)
Fig.7
(2) Disconnect the card wire from DVD MPEG board connect-
ed to connector SCON1 of the UPGRADE board. (See
Fig.8)
(3) Disconnect the connector wire from DVD VCC board con-
nected to connector SCON2 of the DVD MPEG board.
(See Fig.8)
(4) Disconnect the card wire from Main board connected to
connector CN702 of the DVD MPEG board. (See Fig.8)
(5) Disconnect the connector wire from Main board connected
to connector CON101 of the DVD MPEG board. (See
Fig.8)
(6) Disconnect the connector wire from USB board connected
to connector CON703 of the DVD MPEG board. (See
Fig.8)
Fig.8
3.1.6 Removing the USB board (See Fig.9)
(1) Disconnect the connector wire from USB board connected
to connector CON301 of the Main board.
(2) Disconnect the card wire from USB board connected to
connector CON201 of the Main board.
(3) Remove the two screws Gattaching the USB board.
Fig.9
3.1.7 Removing the Main board (See Fig.10, 11, 12)
(1) Remove the two screws Hattaching the Main board. (See
Fig.10)
Fig.10
(2) Remove the three screws Jand two screws Kattaching the
DC motor. (See Fig.11)
(3) Disconnect the connector wire from DC motor connected to
connector MTCON1 of the Main board. (See Fig.11)
(4) Disconnect he card wire from Tuner pack connected to
connector CON603 of the Main board. (See Fig.11)
Fig.11
CON403
CON402
E
E
F
SCON1CON703
SCON2 CN702CON101
CON301 CON201
G
H
JM
M
JK CON603
MTCON1

(No.MB744<Rev.001>)1-9
(5) Remove the four screws Lattaching the bracket. (See
Fig.12)
Fig.12
(6) Remove the three screws Mattaching the Main board.
(See Fig.11)
3.2 Subwoofer (Used model: SP-NXT5WE)
3.2.1 Removing the Power amp unit (See Fig.1, 2, 3)
(1) Remove the six screws Aattaching the Power amp unit.
(See Fig.1)
Fig.1
(2) Remove the three screws Battaching the Power amp unit.
(See Fig.2)
Fig.2
(3) Pull out the Power amp unit for half way; disconnect the
connector wire from Subwoofer speaker connected to con-
nector CON805 of the Power amp board. (See Fig.3)
Fig.3
3.2.2 Removing the Power cover and Amp cover (See Fig.4,
5, 6, 7)
(1) Remove the five screws Cattaching the Cover. (See Fig.4)
Fig.4
(2) Remove the three screws Dattaching the Cover. (See
Fig.5)
Fig.5
(3) Remove the six screws Eattaching the Cover. (See Fig.6)
Fig.6
L
A
A
B
CN805
C
D
E

1-10 (No.MB744<Rev.001>)
(4) Lift up the cover; remove the two screws Fattaching the
Cover. (See Fig.7)
Fig.7
3.2.3 Removing the Power board (See Fig.8)
(1) Disconnect the power cord connected to connector CON01
of the Power board.
(2) Disconnect the connector wires from Amp board connect-
ed to connectors CON901 and CON902 of the Power
board.
(3) Remove the eight screws Gattaching the Power board.
Fig.8
3.2.4 Removing the Amp board (See Fig.9, 10)
(1) Remove the four screws Hattaching the Back plate. (See
Fig.9)
Fig.9
(2) Remove the four screws Jattaching the Amp board. (See
Fig.10)
Fig.10
F
GG
G
CON902 CON901
CON01
H
JJ

(No.MB744<Rev.001>)1-11
SECTION 4
ADJUSTMENT
This service manual does not describe ADJUSTMENT.
SECTION 5
TROUBLESHOOTING
This service manual does not describe TROUBLESHOOTING.

(No.MB744<Rev.001>)
VSE
Printed in Japan
Victor Company of Japan, Limited
Home Entertainment Business Division Personal AV Operation 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan

SCHEMATIC DIAGRAMS
NX-T5B,NX-T5E,NX-T5EN,
NX-T5EV,NX-T5EE
Contents
Block diagrams
Standard schematic diagrams
Printed circuit boards
2-1
2-3
2-18 to 22
COMPACT COMPONENT SYSTEM
No.MB744SCH<Rev.001>
2010/5
COPYRIGHT 2010 Victor Company of Japan, Limited.
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
CA-NXT5SP-NXT5F SP-NXT5F SP-NXT5W

In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the
parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " "
mark nearby are critical for safety.

2-1
Block diagram 1
USB+5V DVD+5V DVD+5V
External USB USB HOST 2.0 Motor Driver Slot Type DVD Mechanism
Device Full Speed U702 Slot L33+ Sanyo HD850
DVD/CD Servo
Serial Flash Serial Flash Controller
16M-Bits Interface
U706 VCC+3V3
CVBS LC Low Pass CVBS
SDRAM 16-Bits Width Filter OUT
1Mx4x16 Bit SDRAM Interface
U705 VCC+3V3 HDVCC+5V STB+3V3
UP-Scaler
3D De-Interlacer ESD PROTECTOR HDMI OUT
MPEG RESET 1080P HDMI 1.2 TX U709
HDCP 1.1 HDMI_TV_HPD
MPEG_CLK HDMI CEC Translator 9950_RST
MPEG_DAT Sunplus MPEG IC I2C Controller U708 9950_INT
MPEG_STB U703
SPDIF_IN Optical Receiver OPTICAL_IN STB+3V3
OPT1
MCLK
VCC+1V8 SCLK
LRCLK
VCC+3V3 D0 DSP Sound Processor LPF OP MPEG_R_OUT
D1 U710 Audio DAC
D2 U700 MPEG_L_OUT
I2C
SCP_BSY
MCU_LOAD_DISC+ CD DOOR SCP_IRQ
MOTER DRIVER +5V /CS48540_RST DAC+5V +12VA
MCU_LOAD_DISC- U701
VCC+3V3 A+1V8

2-2
Block diagram 2
Tuner+5V
MCU_VCC FM Tuner Tuner_L +8V5
MCU_I2C_2 (With RDS +12VA
Decode Tuner_R MPEG_R_OUT
MPEG_L_OUT
Touch Panel KEY[1,2,3,4] I2C PRE_OUT_L
8 Keys MCU_I2C_1
EEPROM TU24C02CS2 Tuner_L Volume Control Buffer OP
Tuner_R Treble/Bass
IR RECEIVER IR_IN HDMI_TV_HPD STB_3V3 Sound Processor PRE_OUT_R
IR401,IR402 IR MCU MPEG_STB AUX_L U201
2PCS U601 MPEG_CLK AUX_R
MPEG_DAT I2C
/CS48540_RST
FLVFD (5x7 Dots,
8 Digits, Icons)
SCP_BSY
VFD_CONTROL SCP_IRQ
with COG Driver 9950_INT
9950_RST VCC+3V3 Regulator IC
Character ROM
VFD_DATA
MCU_LOAD_DISC+
MCU_LOAD_DISC- VCC+1V8 Regulator IC DVD+5V
MCU RESET RESET AMP_STB
POWER_EN AMP_MUTE
DVD_PWR A+1V8 Regulator IC +12VV
Level Detection +12V
+12VV +12VV AMP+25V and Transistor Switch 12V FAN +8V5
Regulator
Regulator AMP+25V
PRE_OUT_L HPF Class-D SPK_L_OUT
OP AMP OP AMP Amplifier (50W,6 Ohms) DAC+5V
Regulator +12VA
U803,U806
PRE_OUT_R SPK_R_OUT
AMP_STB (50W,6 Ohms) VFD+12V POWER_EN POWER_EN
AMP_MUTE VFD-28V DC/DC DC/DC +12V
Converter Converter
Summer LPF Class-D U301,U302 AC CORD
OP AMP OP AMP Amplifier SUB_OUT DVD+5V SMPS
U803,U806 (100w 3 Ohm) POWER_EN STB+5V
AMP_STB DVD_PWR
+12VV +12VV AMP+25V VFD+5V
Tuner+5V +5V DC/DC
USB+5V MCU_VCC Converter
HDVCC+5V U301,U302
POWER_EN
STB+3V3 Regulator IC
VFD_CLK
VFD_STB
Fc=150Hz
Fc=150Hz
9V/200mA
5V1/200mA
12V/200mA

2-3
Standard schematic diagrams
+
+
+
+
+
+
+
++
+
++
+
+
+
+
+
L
N
1
2
3
4
24 24
FB
2
HV
8
OUT 5
CS 3
ADJ
1
GND
4
NC
7
VCC 6
1
2
3
2
1
4
4
2
3
14
1
2
3
12
2
6
4
3
5
GND
8
1
VCC 7
1
3
2
5
4
6
24
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
15V
SR3100
104
NC
30uH
+25V
+25V
CN901 F901
T2.5A 250V
C929
0.1uF 275V
5R 4A
L906
0.22uF 275V
CX901
R911
2M 1/2W 152 250V
CY902
CY901
152 250V
LF901
D903
NC
R937 R939
VD902
R942
R941
V906
V907
R940
U908
C926
R938
C906
VD903
R949
NC
C931 C907
47uF 25V
L901
56R 1/4W
D904
FR104
D916
NC
T902B
MT-EF20/8P
D906
FR104
C928
47uF 50V
VD904
ST2N5551
3.3K 1/4W
R916
47uF 25V
CX902
0.22uF 275V
R901
2M 1/2W
R909
10K 1/6W
U904B
EL817
10K 1/6W
V902
SS8050
U903B
EL817
C904
471
V904
R915
22R 1/8W
U905B
EL817
R917
33R 2W
D907
UF802
C912 L902
15uH
C916
2200uF 35V
2200uF 35V 220uF 35V
C934 C918
104 50V
R919
2.2K 2W
CN902
R922
22K 1/8W
R944
4.7K 1/8W
VD901
R921
2.2K 1/8W
12V
GND
GND
2.2K 1/8W
R928
CN903
ECO
+12V
+12V
100uF 16V
C932
C924
C922
100uF 16V
1000uF 16V
10uH
L904
C921
1000uF 16V
SR3100
D911
D912
D913
1.8K 1/16W
68K 1/8W
R950
C927
105 63V
AZ431
U907
U905A
EL817
6.8K 1/8W
R934
6.8K 1/8W
2.7K 1/16W
R933
470uF 16V
CY904
102 250V
1N5819
C903
47K 2W
R903
FR107
V901
220uF 200V
220uF 200V
C901
D905
1N4148
R907
22R 1/8W
R910
1K 1/8W
MT-ER35 14P
AZ431
U906
EL817
U903A
1R 2W
R905
1R 2W
R904
C930
10K 1/6W
C905
471
R908
6.8K 1/8W
Drian
Drian
CSSofts
NC
FB
47K 2W
T902A
FR107
D915
10uF 400V
C935
102 250V
2R 1/4W2R 1/4W
R913 R914
1uF 50V
C908
103
C909
IC_ICE3B1565
U902
MT-ER35/14P
T901B
U901
IC_NCP1216
KBL10
D901
NC
D916
C911
105 63V
R924
33K 1/8W
R923
2.7K 1/16W
R931
10K 1/6W
R932
100R 1/8W
V905
SS8050
1N4148
D910
R929
NC
U904A
EL817C
<SMPS section>
Parts that are shaded are critical
electrical shock.
With respect to risk of fire or
NOTE)
To Power Amplifier Section 1 CON801
To Power Amplifier Section 1 CON802
2PP=7.92mm
13
RT902
30mH
R947
13
30mH
23
RL901
BEAD 3.5*6*0.8
L908
472 1KV
D902
L905
BEAD 3.5*6*0.8
T901A
SPA11N60C3
R948
472 1KV
EEL-22
R935
R936
CY903
Warning
L909
13
5VS
GND
GND
6P P=2.5mm
4P P=3.96mm
472 1KV
C914
C923
R902
C902
C910

2-4
<Main section 1>
AUX_L
AUX_R
J201-B
J201-A
T50
AUX_L
AUX_R
FB624
AGND
J202
T8
C239
FB628
CVBS_OUT
D205
D206
TV18
FB627 VGND
FB205 Q201
R217
AGND
MPEG_R_OUT
R242 C222
C220
R678
AGND
C221
R241
MPEG_L_OUT
C219 R679
AGND
AUX_R
R202 C206
C202 C204 R206
AGND
AUX_L R201
C201 C203
AGND
R205
C205
TUNER_R R240
C212
AGND
R238
C214 TU_R_IN
TUNER_L R239 C213
C211 R237
AGND
TU_L_IN
TUNER_L
AUX_L
AUX_R
MPEG_L
MPEG_R
AUDIO-L-O
AUDIO-R-O
MC201
MC202
C240
MC204
R210
C226
R208
R204
MC203
R209
C225
U201
2314_CLK
2314_DATA R219
R218
EC209
C227
C228
EC207
EC208
MC208
MC206
MC207
MC205
C241
R203
R207
R216
R215
AGND
R221
R222 EC204 C236
AGND
ROUT
AGND
LOUT
R220
EC203 C235
AGND
R230
R224
R226
AGND
C230 R228
U202-B
EC210 R234
AUDIO-R-O
R236
C232
R232
R229
R223
R225 C229
AGND
R227
U202-A
EC211
C231
R231
R233
R235
AGND
AUDIO-L-O
D+D-_CONNECT
CON201
T1
T2
TV21
T3
T4
T5
T6
T7
VFD_MODE_O
MODE_H_IN
FB204
VFD_V_H_MODE
MODE_H_IN
AGC3
AGC1
AGND
C200
VGND GND
C233
EC201
D207 C234
EC202
To This sheet
To This sheet
To USB section CON501
T51
To Main section 2
TUNER_R
To Main section 2
To Main section 2
LOAD_UP_DOWN+
GND
AGND
AGND
LOAD_UP_DOWN+

2-5
<Main section 2>
MCU_DOWM(SW)_DETECT-
MCU_UP(SW)_DETECT+
MCU_LOAD_DISC-
MCU_A(SW)_DETECT+
MCU_LOAD_DISC+
BLINK_3KEY_1
VFD_V_H_MODE
VFD_STB
VFD_DATA
VFD_CLK
MCU_B(SW)_DETECT+
BLINK_4KEY_2
R649
R646
R642
R643
R644
R603
R624
R600
R653
R650
R626
R645
R633
R618
R619
R615
R614
R617
R611
R610
R659
R601
R651
R602
R612
R634
U601
TUNER_NORMAL_PULSE
CS48540_RESET
9950_INT
R660
R652
R609
R654
R661
R616
R630
R662
R620
R673
R674
R606
R605
R604
C611
C608
AVREF
TV19
+4V8_MCU
TUNER+5V
FB606
EC603
9950_RST
SCP_IRQ
MPEG_STB
TXD
MPEG_CLK
MPEG_DATA
+4V8_MCU
CON604
T43
T44
T45
T46
T47
CON603
T37
T59
T38
TV20
T39
T40
TV22
T41
T42
VGND
FB612
FB625
FB620
FB619
FB611
FB609
FB610
FB607
FB621
FB622
FB626
FB623
RXD
TXD
FLMDO
C612
C614 FB605
FB618
AGND
R664
FB601
FB602
FB603
FB604
TU_I2C_CLK
TU_I2C_DATA
TU_RESET
CVBS_OUT
CS48540_RESET
MPEG_L_OUT
MPEG_R_OUT
SCP_IRQ
HPD_TV
MPEG_CLK
9950_DATA
9950_CLK
9950_INT
9950_RST
MCU_B(SW)_DETECT+
MCU_UP(SW)_DETECT+
MCU_A(SW)_DETECT+
MPEG_STB
MPEG_DATA
AGND
GND
T10
T57
T9
T12
T58
T11
T15
T13
T14
T18
T16
T17
T21
T19
T20
T24
T22
T23
GND
CON602
T27
T25
T26
T30
T28
T29
T33
T31
T32
T36
T34
T35
FB615
FB613
FB614
VFD_DATA
VFD_STB
VFD_CLK
BLINK_3KEY_2
BLINK_3KEY_1
TRIANGLE_LED_ON
BLINK_4KEY_2
STB_R/B_LED_OFF
VFD_V_H_MODE
BLINK_4KEY_1
+5V
VFD+12V
+3V3STBY
VFD-28V
VFD+5V
R622
R628
R625
R627
R613
C605
C606
C607
R658
R629
R621
R672
R671
R670
R635
R648
R636
R647
9950_DATA
R668
LOAD_UP_DOWN+
LOAD_UP_DOWN-
MTR3
MTR4
STB_R/B_LED_OFF
AMP_STBY
TU_RESET
HPD_TV
TU_I2C_DATA
TU_I2C_CLK
R669
9950_CLK
DVD_PWR
+12V_MIC
MTEC2 MTEC1
MTD2 MTC2
MTD1
R212
R200
R213
R214
TU_I2C_CLK
TU_I2C_DATA
9950_DATA
9950_CLK
2314_DATA
2314_CLK
MTR11
MTQ3
MTR10 MTR9
GND
MTR8 MTR6
GND
GND
MTR7
MTR5
MTQ4
MTQ5
MTQ2
MTR2
MTR1
MTQ1
T48
MTC1
T49
GND
LOADER_UP_DOWN_MOTOR+
LOADER_UP_DOWN_MOTOR-
MTCON1
CNM1
MOTOR1
CM2
CM1
MOTOR2
C609
+4V8_MCU_VDD
R656
R666
C610
R665
R632
R680
R657
R607
R623
R663
R631
X602
NPO
C601 C602
R667
TV14
C615
EC601
FB608
+4V8_MCU
EXCLK
R243
D+D-_CONNECT
BLINK_4KEY_1
PWR_ON
SCP_BSY
BLINK_3KEY_2
FLMDO
RESET
R639
D601
EC604
+4V8_MCU
Q601
C613
R638
R637
CON601
To Display section CON401
To DVD MPEG section 2 CN702
To USB section SCON1
MODE_H_IN
To Main section 1
To Main section 1
TRIANGLE_LED_ON
TRIANGLE_LED_1/2
To Main section 1
RESET
EXCLK
MCU_BUS
RXD
AMP_MUTE
IR_IN
IR_IN
TRIANGLE_LED_1/2
MCU_DOWN(SW)_DETECT-
MCU_LOAD_DISC+
MCU_LOAD_DISC-
SCP_BSY
TUNER_NORMAL_PULSE
TUNER_L
TUNER_R

2-6
<Main section 3>
J301
T56
AGND
R301
FB312
TV1
FB306
T55
T54
TV23
T53
T52
FB305
FB304
FB303
FB302
FB301
EC301 EC302
AUDIO-L-O
AUDIO-R-O
PWR_ON
AMP_MUTE
AMP_STBY
C321
R327
PWR_ON
C301 R322 U301
C303
C302
R316
C315 R306
R307
U302
C318
C317
R308
D302
R309
C316
L302
R310
C319
W306
W301
W302
W303
W304
W305
W307
Q306
R305
R313
Q305
R304
R303
PWR_ON
D303
D308
TV16
TV13
TC301 C313
U303
R330 C314 TC302
NC1 NC2 NC3 NC4
R329 TV12
D309
FB307
EC306 C322
TV3
C304
TV7
R315
D301
R302
L301
R320
R350
R211
Q301
R321
R311
EC304
R317
Q302 R328
DVD_PWR
C305
C306
C307
D304
R318
D305
D306
C308
C309
D307
C310
TV9
R319
R312
Q304
R323
R324
PWR_ON
Q303
FB311
FB310
C320
TV4
TV5
CON301
TV2
GND
HS301
FB308
FB309
GND
TV10
TV11
TV17
TV15
TV6
EC303
C311
C312
TC303
To DVD MPEG section 4 CON101
To USB section CON503
