JVC TH-D337B User manual

Remove the Plastic Strip from the Remote Control
The unit has a pre-installed
lithium CR2025 battery. Remove
the protective tab to activate the
remote control battery.
Connections
•
Soundbar Sockets Overview
•
Quick Start Guide
2.1 Ch Wireless Soundbar with
wired subwoofer
TH-D337B
Thank you for purchasing your new JVC Soundbar.
We recommend that you spend some time reading this Quick Start
Guide in order that you fully understand how to connect your
Soundbar to your TV.
Use your Soundbar instruction manual and TV instruction manual to
choose the best way to connect your Soundbar and TV together.
Unpacking
•
Remove all packaging from the unit. Retain the packaging. If you
dispose of it please do so according to any local regulations.
To get the most from this product, you may need to buy an
Optical cable.
Battery Replacement for the Remote Control
1. Gently push the tab of the battery tray in and slide it free
from the remote control.
2. Replace with a new
battery
3. Slide the battery tray back into the remote
control.
Main Unit
Remote Control
(battery included)
Subwoofer
Wall Bracket × 2
Screw × 4
Dowel × 4
Mains Cable × 2
Coaxial Cable
3.5 mm to 3.5 mm
Stereo Audio Cable
Subwoofer Cable
Instruction Manual
Quick Start Guide
Connecting to the TV
Method 1: OPTICAL / COAXIAL Connection
Use an optical cable (not included) / coaxial cable
(included) to connect the soundbar’s OPTICAL /
COAXIAL socket to the OPTICAL OUT / COAXIAL
OUT socket of the external device. The simplest
option is to connect your soundbar directly to your
TV. If you connect the soundbar to another external
device (e.g. Blu-Ray player), you will hear the sound
from that device through the soundbar.
After the connection is complete,
1. Press on the unit or remote control to switch
on the unit.
2. Press SOURCE repeatedly to select Optical or
Coaxial mode.
The unit may not be able to decode all digital audio formats from the input
source. In this case, the Optical / Coaxial indicator will ash quickly, and
the unit will prompt “Unsupported sound format, please refer to the
Instruction Book”. This is NOT a defect. Ensure that the audio setting of
the input source (e.g. TV, game console, DVD player, etc.) is set to PCM with
optical / Coaxial input.
• DO NOT connect the soundbar with the
TV through its RCA sockets or headphone
socket.
• Before connecting the optical cable, remove
the protective cap of the OPTICAL socket.
Ensure the unit is disconnected from the mains socket before connecting it to other devices.
COAXIAL
(TV/BD/DVD)
OPTICAL
(TV/BD/DVD)
AC~
SERVICEONLY AUX(BD/DVD) SUBWOOFEROUT
COAXIAL
(TV/BD/DVD)
OPTICAL
(TV/BD/DVD)
AC~
SERVICE ONLY AUX (BD/DVD) SUBWOOFER OUT
1. COAXIAL Socket
2. AC~ Socket
3. OPTICAL Socket
1
2
34
5
6
4. SERVICE ONLY Socket
5. AUX Socket
6. SUBWOOFER OUT Socket
Install the battery correctly in the battery compartment. Normally the battery’s
positive polarity (+) will face up.
Operating Your Remote Control
•
Connecting an External
Audio Device
Use a 3.5mm to 3.5mm stereo audio cable
(included) to connect the soundbar’s AUX
socket to the headphone socket of the
external devices.
After the connection is complete,
1. Press on the unit or remote control to
switch on the unit.
2. Press SOURCE on the unit or remote
control repeatedly to select AUX IN
mode to play audio from your input
device.
• Ensure the colours on the cable plugs match with
the colours on the input and output sockets.
• DO NOT connect the soundbar and TV by using
the AUX socket.
COAXIAL
(TV/BD/DVD)
OPTICAL
(TV/BD/DVD)
AC~
SERVICE ONLY AUX (BD/DVD) SUBWOOFER OUT
3.5mm to 3.5mm stereo
audio cable (included)
Rear View of the Soundbar
3.5mm to RCA Stereo Audio Cable
(not included)
or
Blu-ray Player / DVD
Player / Recorder
Set-top Box
Satellite Receiver Game
Console
Video
Camera
MP3 Player or
Mobile Device
COAXIAL
(TV/BD/DVD)
OPTICAL
(TV/BD/DVD)
AC~
SERVICE ONLY AUX (BD/DVD) SUBWOOFER OUT
1
2
Optical cable (not included)
TV
Rear View of the Soundbar
Coaxial cable (included)
Blu-ray Player / DVD
Player / Recorder
Set-top Box
Satellite Receiver Game Console Video Camera
or
TH-D337B_QSG_Final200611V5.indd 1 15/06/2020 16:59

•Connecting to the Mains Supply
Soundbar
Unwind the mains cable to its full length. Connect the end of
the mains cable to the AC~ socket at the rear of the soundbar
then connect the mains plug to the mains socket.
Subwoofer
Connect the other mains cable to the AC~ socket at the rear
of the subwoofer then connect the mains plug to the mains
socket.
• The mains cables are designed for this JVC soundbar only. DO NOT use the mains cable for other purposes. Connecting the unit to any other power source may
damage the unit.
• Ensure all audio connections of the unit are connected before connecting to the mains power socket.
• Make sure the mains plug is rmly inserted into the mains socket.
• To switch the unit o completely, remove the mains plug from the mains socket.
• Please turn the unit o completely to save energy when not in use.
Well done, your new soundbar is now ready to use. You will nd that there are many exciting features available. To get to know all
these features, please take some time to read the instruction manual provided with your soundbar.
(QSG-TH-D337B-200611V5)
COAXIAL
(TV/BD/DVD)
OPTICAL
(TV/BD/DVD)
AC~
SERVICE ONLY AUX (BD/DVD) SUBWOOFER OUT
To the mains
socket
Rear View of the Soundbar
SUBWOOFERIN
AC~
To the mains
socket
Rear View of the Subwoofer
Connecting the Subwoofer
•
SUBWOOFERIN
AC~
COAXIAL
(TV/BD/DVD)
OPTICAL
(TV/BD/DVD)
AC~
SERVICEONLY AUX (BD/DVD) SUBWOOFEROUT
Rear View of the Subwoofer
Rear View of the Soundbar
Use the Subwoofer cable (included) to connect the SUBWOOFER IN socket of the Subwoofer and the SUBWOOFER OUT socket of the
main unit.
• For optimal sound, always use the supplied subwoofer.
• Make sure that the Subwoofer cable is connected rmly with the main unit and subwoofer. If there is no connection between the main unit and the subwoofer, the
subwoofer indicator will ash.
Front view of the main unit
(while pressing BASS/TREBLE button)
AUX IN
Indicator
(Green)
BT
Indicator
(Blue)
OPTICAL
Indicator
(White)
COAXIAL
Indicator
(Orange)
Select Equaliser (EQ) Eect
Press the EQ button on the unit or the CUSTOM/MOVIE/MUSIC button on the remote control to select the preset equaliser eects.
• When CUSTOM (Default) is selected, the COAXIAL indicator will ash (Orange) once.
• When MOVIE EQ is selected, the OPTICAL indicator will ash (White) once.
• When MUSIC EQ is selected, the BT indicator will ash (Blue) once.
• While the unit is in COAXIAL, OPTICAL, or AUDIO IN mode, it will automatically switch into MOVIE EQ eect.
• While the unit is in Bluetooth mode, it will automatically switch into MUSIC EQ eect.
Adjusting the Bass/Treble Level in CUSTOM EQ mode
1. Make sure that the EQ is set to CUSTOM mode.
2. Press BASS/TREBLE on the remote control. The AUX IN, BT, OPTICAL and COAXIAL indicators
will ash once.
3. Press VOL+/VOL– to adjust the bass/treble level.
4. After about 5 seconds, the AUX IN, BT, OPTICAL and COAXIAL indicators will ash once again to
indicate that the unit has exited BASS/TREBLE setup.
5. You may now press VOL+/VOL– to adjust volume.
• While adjusting the bass/treble level, the status indicator ashes quickly.
• While the BASS/TREBLE reaches its maximum or minimum level, the status will ash once if
you press VOL+/VOL– again.
The table below also shows the EQ mode supporting bass/treble adjustment.
EQ Mode Adjusting Bass Level? Adjusting Treble Level?
Custom 3 3
Movie N/A N/A
Music N/A N/A
•EQ and Bass/Treble Level Settings
Subwoofer Cable (included)
