2011 JVC Product Tech Guide
CS-GD1200/G1200
C M Y K
Subwoofers
Conventional SubwooferCS-G1200
drvn Series Subwoofer
✹High-Density Foam Surround
The strong and light urethane surround allows quick response for clear,
natural sound.
✹Wider Surround
The surround is 50% wider than the previous model, with increased sound
pressure levels in the low frequencies.
The unit features superior sound in the most audible range with quick-responding high-density foam surround.
Key Benefits
CS-G1200
12” (30cm) Subwoofer Unit
250W
RMS
1200W
Peak Power
High-Density
Foam Surround
Aggressive
Design
Quick Response for Sound Pressure

2011 JVC Product Tech Guide
C M Y K
CS-GD1200/CS-G1200
NTK-0786-35
Key Specifications
CS-G1200
Size 12” (30 cm)
Power Handling Capacity (Peak) 1200W
Power Handling Capacity (RMS) 250W
Sensitivity 87.5dB/W.m
Frequency Response 25 - 2,500Hz
Impedance 4Ω
Fs 34.4Hz
Qts 0.747
Vas 2.08 ft3
Magnet Mass 39 oz
Hole Cutout Diameter Dia. 10 31/32” (278 mm)
Mounting Depth 5 3/8” (136.3 mm)
Weight (NET) 4.0kg (8.9 lbs.)
✹Rigid Structure
The full-covering cap prevents the woofer from deforming and increases its strength, to provide clear, distortion-free bass.
12-25/32 inch (324.6 mm)
12-1/16 inch (306 mm)
10-29/32 inch (276.5 mm)
7/32 inch (5.2 mm) x
8 HOLES
5-17/32 inch
(140 mm)
12-27/32 inch (325.5 mm)
5-3/8 inch (136.3 mm)
1-7/32 inch (30.2 mm)
6-9/16 inch
(166.3 mm)
6-15/32 inch
(164.3 mm)
CS-G1200
Dimensions
CS-G1200 Conventional Subwoofer
Recommended System
CS-VS607 CS-VS607
Front
Rear
Front
Rear
KW-AVX740
KS-AX3101D
CS-V6947 CS-V6947
KS-AX3104
CS-G1200
Recommended Enclosure Size
0.75-1.5 cu/ft
(1 cu/ft recommended)
Sealed Type
1-1.8 cu/ft
(1.2 cu/ft recommended)
Ported Type
CS-G1200 12” (30cm) Subwoofer Unit
