JVC KV-C10 User manual

3351398B01-0
[E]
ENGLISH
INSTRUCTIONS
BEDIENUNGSANLEITUNG
MANUEL D’INSTRUCTIONS
GEBRUIKSAANWIJZING
DEUTSCH
FRANÇAIS
MOBILE TV TUNER SYSTEM
TRAGBARER TV-TUNER
SYSTEME DE TUNER DE TELEVISION MOBILE
MOBIEL TV-TUNERSYSTEEM
NEDERLANDS
KV-C10
* This system is designed to enjoy TV programs by connecting JVC mobile
colormonitorsystemKV-M700(soldseparately).Alloperationsandfunctions
of the system including KV-M700 connected are explained in this
instructions.
* Dieses System wurde entwickelt, um mit dem tragbaren JVC-Farbmonitor
KV-M700 (separat erhältlich) Fernsehprogramme betrachten zu können.
Alle Funktionen und die Bedienung des Systems, einschl. Anschluss an
den KV-M700, sind in diesem Handbuch erklärt.
* Ce système est conçu pour vous permettre de regarder des émissions de
télévision en connectant le système de moniteur couleur mobile KV-M700
deJVC(venduséparément).Le fonctionnement etlesfonctionsdusystème
avec le KV-M700 connecté sont expliqués dans ce manuel d’instructions.
* Het systeem is ontworpen om op een aangesloten mobiel
kleurenmonitorsysteem van JVC (de KV-M700, apart leverbaar) naar TV-
programma’s te kijken en luisteren. Alle bediening en alle functies en
voorzieningenvan het systeem,met inbegrip vandeaangesloten KV-M700,
worden in deze handleiding besproken.
For installation and connections, refer to
the separate manual.
Fürden Einbau und dieAnschlüsse siehe
das eigenständige Handbuch.
Pour l’installation et les raccordements,
se référer au manuel séparé.
Bijzonderheden over de installatie en
aansluiting van het apparaat vindt u in
de desbetreffende handleiding.
HEADPHONE
ANTENNA INPUT INPUT 2 INPUT 1
12
234
VIDEO L R VIDEO
CONTAUDIO L RAUDIOVIDEO1
OUTPUT
RL
VIDEO TO DISPLAY VOCAL POWER
SUPPLY
AUDIO
COVER.KV-C10_3351398B01-0 01.1.17, 10:04 AM3

2
ENGLISH
Safety points (Be sure to follow these points)
CAUTIONS • THE DRIVER MUST NOT WATCH THE TELEVISION
OR VIDEOS WHILE DRIVING.
IF THE DRIVER WATCHES THE TELEVISION OR A
VIDEO WHILE DRIVING, IT MAY LEAD TO
CARELESSNESS AND CAUSE AN ACCIDENT.
• DO NOT USE THE TV TUNER SYSTEM WHEN THERE
IS A PROBLEM OR MALFUNCTION.
IF THE TV TUNER SYSTEM IS USED IN AN
ABNORMAL CONDITION SUCH AS WHEN THE TV
TUNER SYSTEM IS EMITTING SMOKE OR AN
UNUSUAL SMELL, IT MAY CAUSE AFIRE OR SOME
OTHER PROBLEM.
* IMMEDIATELY STOP USING THE TUNER SYSTEM AND
CONSULT THE SALES OUTLET WHERE YOU PURCHASED
THE TUNER SYSTEM.
• DO NOT DISASSEMBLE THE TV TUNER SYSTEM OR
MAKE ANY CHANGES.
IF THE TUNER SYSTEM IS DISASSEMBLED OR
MODIFIED, IT MAY CAUSE MALFUNCTIONS OR A
FIRE OR OTHER ACCIDENTS.
• DO NOT PUT YOUR EYES OR FACE NEAR THE
ANTENNA ELEMENT.
IF YOU PUT YOUR EYES OR FACE NEAR THE
ANTENNA ELEMENT, YOU COULD BE INJURED.
• WHEN LIGHTNING OCCURS, DO NOT TOUCH THE
ANTENNA WIRE OR THE TV TUNER SYSTEM.
TOUCHING THEANTENNAWIRE OR THE TV TUNER
SYSTEM UNDER SUCH CONDITIONS MAY CAUSE
ELECTROCUTION.
• KEEPTHETVTUNER SYSTEMATANAPPROPRIATE
SOUND LEVEL WHILE DRIVING.
DRIVING WITH THE SOUND AT A LEVEL WHICH
PREVENTSYOU FROM HEARING SOUNDS OUTSIDE
OF AND AROUND THE VEHICLE MAY CAUSE AN
ACCIDENT.
• ASK A TRAINED TECHNICIAN TO INSTALL THE TV
TUNER SYSTEM.
INSTALLATION AND WIRING REQUIRE TRAINING
AND EXPERIENCE.
* TO BE SAFE, ASK THE SALES OUTLET WHERE YOU
PURCHASED THE TV TUNER SYSTEM TO PERFORM THE
INSTALLATION.
• DO NOT LET THE TV TUNER SYSTEM FALL OR BE
STRONGLY IMPACTED.
BESURE NOT TO LET THE TV TUNER SYSTEM FALL
OR BE STRONGLY IMPACTED SINCE THIS MAY
CAUSE A MALFUNCTION OR FIRE.
• DO NOT WATCH THE MONITOR WITH THE ENGINE
OFF.
WATCHING THE MONITOR WITH THE ENGINE OFF
WILL CONSUME BATTERY POWER AND MAY
PREVENT THE ENGINE FROM STARTING.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's enclosure
that may be of sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
WARNING:
TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS
UNIT TO RAIN OR MOISTURE.
CAUTION:
ThisTV tuner unit or system should be used with DC 12 V
only.
To prevent electric shocksand fire hazards, DO NOT use
any other power source.
WARNINGS
• BE SURE TO INSTALL THE MONITOR ON TOP OF
THE DASHBOARD TO PREVENT IT FROM
OBSTRUCTING VISIBILITY.
• IF THE MONITOR HAS BEEN INSTALLED FOR THE
REAR SEAT PASSENGERS, THEY MUST BE
CAREFUL NOT TO BE INJURED BY HITTING THEIR
HEAD ON THE MONITOR IN CASE OFAN ACCIDENT.
• DO NOT INSTALL THE TV TUNER SYSTEM IN A
LOCATION WHICH OBSTRUCTS DRIVING,
VISIBILITY OR WHICH IS PROHIBITED BY
APPLICABLE LAWS AND REGULATIONS.
• THERE MAY BE LEGAL REGULATIONS DEFINING
THEPERMISSIBLE INSTALLATIONLOCATIONS FOR
THE MONITOR SYSTEM WHICH DIFFER BY
COUNTRY OR BY STATE, BE SURE TO INSTALL THE
MONITOR SYSTEM IN A CORRECT LOCATION
ACCORDING TO SUCH LAWS.
• DO NOT INSTALL THE TV TUNER SYSTEM IN A
LOCATION WHICH OBSTRUCTS THE OPERATION
OF AN AIR BAG.
• THE DRIVER MUST NOT OPERATE THE TV TUNER
SYSTEM WHILE DRIVING.
OPERATING THE TV TUNER SYSTEM WHILE
DRIVING MAY LEAD TO CARELESSNESS AND
CAUSE AN ACCIDENT.
* STOP YOUR VEHICLE IN A SAFE LOCATION WHEN
OPERATING THE TV TUNER SYSTEM.
EN02-08.KV-C10[E]f 01.1.17, 10:05 AM2

3
ENGLISH
Cautions for the liquid crystal panel (sold separately)
• There are red spots, blue spots and green
spots on the panel surface. This is a
characteristic of liquid crystal panels and is
not a problem.
Spots
The liquid crystal panel is built with very high
precisiontechnology and hasatleast 99.99%
effective image pixels. Be aware that on
0.01% of the panel there may be missing
pixels or constantly light pixels.
• When the temperature is very cold or very
hot, the image may not appear clearly or may
move slowly.
Inaddition,movementofthe image mayseem
to be out of sync or the image quality may
decline in such environments. Note that this
is not a malfunction or problem.
(usage temperature range: 0°C to +40°C)
0°C or colder
40°C or hotter
When the liquid crystal panel reaches high
temperatures or low temperatures, chemical
changes occur within the liquid crystal panel
which may cause malfunctions.
• Do not leave the liquid crystal panel surface
facing upwards on top of the dashboard.
(storagetemperaturerange:–20°Cto +80°C)
• Donotstronglyimpactthe liquid crystalpanel.
During the summer,
temperatures can
reach as high as
100°C.
+80°C
–20°C
–20°C to +80°C
EN02-08.KV-C10[E]f 01.1.17, 10:05 AM3

4
ENGLISH
Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to
ensure your complete understanding and to obtain the best possible performance from the unit.
CONTENTS
CONTROLS AND FEATURES .........................................5
TV tuner unit ..................................................................................5
Color monitor (KV-M700, sold separately)..................................6
Remote controller (supplied with KV-M700)...............................7
Installing the batteries ................................................................. 8
BASIC OPERATIONS ....................................................9
Watching television.........................................................................9
Storing channels in memory (Auto memory) .............................11
Setting the channel selection........................................................12
Watching playback of external component ................................13
OTHER FUNCTIONS ..................................................15
Setting the RF input .....................................................................15
ADJUSTMENTS .........................................................16
Adjusting the color .......................................................................16
Adjusting the brightness ..............................................................17
Adjusting the contrast ..................................................................18
Adjusting the headphone volume................................................19
MAINTENANCE.........................................................20
TROUBLESHOOTING .................................................21
SPECIFICATIONS .......................................................23
BEFORE USE
* For safety....
• Do not raise the volume level too much, as this
will block outside sounds, making driving
dangerous.
• Stop the car before performing any complicated
operations.
* Temperature inside the car....
If you have parked the car for a long time in hot
or cold weather, wait until the temperature in the
car becomes normal before operating the unit.
EN02-08.KV-C10[E]f 01.1.17, 10:05 AM4

5
ENGLISH
CONTROLS AND FEATURES
TV tuner unit
Back
Front
13
24
ANTENNA INPUT
1234
INPUT 2
VIDEO L AUDIO R VIDEO
CONT
INPUT 1
VIDEO L AUDIO R
See pages in the parentheses for details.
Front
1ANTENNAINPUTjacks(forconnectingthe
diversity antenna)
2INPUT 2 jacks
• VIDEO
• AUDIO L
• AUDIO R
3VIDEO CONT (Control) jack
4INPUT 1 jacks
• VIDEO
• AUDIO L
• AUDIO R
Back
5POWER SUPPLY connector
6This jack is not in use.
7TO DISPLAY connector
8OUTPUT jacks
• VIDEO
• AUDIO L
• AUDIO R
9HEADPHONE 1 and 2 jacks (19)
5 6 7 89
POWER
SUPPLY
VOCALTO DISPLAY
OUTPUT
VIDEO
LAUDIOR
HEADPHONE
2
1
EN02-08.KV-C10[E]f 01.1.17, 10:05 AM5

6
ENGLISH
Front Back
Top
54
698 p
7
DOWN UP MODE POWER
AUTO/MANU
1
2
3
Color monitor (KV-M700, sold separately)
See pages in the parentheses for details.
Front
1STANDBY lamp
2Remote sensor (8)
3Screen (Liquid crystal panel)
Back
4System connection cable
5Monitor stand guide slot
•When you use the monitor stand to install
JVC mobile color monitor system KV-M700
in your car, attach the monitor stand here.
For installation, refer to the Installation/
Connection Manual supplied with KV-M700.
Top
6DOWN button (10)
7UP button (10)
8AUTO/MANU (Auto/Manual) button
(11,12)
9MODE button (10, 11, 12, 13)
pPOWER button (9)
EN02-08.KV-C10[E]f 01.1.17, 10:05 AM6

7
ENGLISH
Remote controller (supplied with KV-M700)
1
2
4
5
7
8
3
6
9
y
t
e
p
w
q
r
CH
CH
COLOR BRIGHT CONTRA
H/P
VOL H/P VOL
MODE
SKIP
A.MEMO CALL
VOCAL
RF
MONI
VCR
RM-RK37RM-RK37
VCR section
VCR
;
ou
i
a
VCR section
tRF (Radio frequency) button (15)
yCALL button (14)
VCR section
The buttonsin thissection are usedforoperating
JVC mobile video cassette player KV-V8 or JVC
mobile video cassette recorder KV-V10. For the
operation, refer to the instructions of KV-V8 or
KV-V10.
u(Power) button
i1(Rewind) button
o7(Stop) button
;¡(Fast-forward) button
a
3 (Play) button
See pages in the parentheses for details.
1(Power) button (9)
2
3 H/P VOL (Headphone volume up)
button (19)
3
2 H/P VOL (Headphone volume down)
button (19)
4BRIGHT button (17)
5COLOR button (16)
6
2 (Down) button (16, 17, 18)
7This button does not function for this
system.
8A.MEMO (Auto memory) button (11)
9SKIP button (12)
p5CH (Channel up) button (10)
qMODE button (10, 11, 12, 13)
w∞CH (Channel down) button (10)
eCONTRA (Contrast) button (18)
r
3 (Up) button (16, 17, 18)
EN02-08.KV-C10[E]f 01.1.17, 10:05 AM7

8
ENGLISH
Installing the batteries
When the controllable range or effectiveness of the remote controller decreases, replace the
batteries.
1. Remove the back cover.
Whilepushing on the backcover,slide it in the direction
of the arrow.
2. Install the batteries.
Place the two batteries R03(UM-4)/AAA(24F) supplied
into the remote controller as illustrated.
3. Close the back cover.
Slide the back cover in the direction of the arrow until a
click is heard.
Before using the remote controller:
• Aim the remote controller directly at
the remote sensor on the color
monitor. Make sure there is no
obstacle in between.
• Do not expose the remote sensor to
strong light (direct sunlight or artificial
lighting).
Remote sensor
EN02-08.KV-C10[E]f 01.1.17, 10:05 AM8

9
ENGLISH
CH
CH
COLOR BRIGHT CONTRA
H/P
VOL H/P VOL
MONI
MODE
BASIC OPERATIONS
Preparation
Before operating the system, make sure that all external components are correctly
connected and installed. For connecting the external components, refer to the
instructions and the installations supplied with the external components.
Watching television
1
If the system is connected to the parking brake
system:
Engage the parking brake and turn on the
engine.
If the system is not connected to the parking brake
system:
Turn on the engine.
Note:
For installation and connections, refer to the Installation/
Connection Manual supplied with KV-M700.
2
Turn on the power.
Press the POWER button on the monitor or the
(power) button on the remote controller.
DOWN UP AUTO/MANU MODE POWER
POWER
Monitor Remote
ACC
ON
ACC
ON
CONTINUED TO THE NEXT PAGE
234 2
34
KV-M700 color monitor KV-M700 remote controller
EN09-15.KV-C10[E]f 01.1.17, 10:05 AM9

10
ENGLISH
3
Select TV as the input source.
Press the MODE button on the monitor or the remote
controller repeatedly to select TV.
4
Select the channel you want to watch.
Press the UP or DOWN button on the monitor or the 5CH
or ∞CH on the remote controller to change the channels.
If the channel selection is set to “AUTO” (See page 12.)
You can select only the channels preset by the auto
memory function. (See page 11.)
If the channel selection is set to “MANUAL” (See page
12.)
You can select all the channels. (Channel coverage: VHF
channels 1 to 12, UHF channels 21 to 69)
5
Adjust the volume level on the car receiver.
To turn off the power
Press the POWER button on the monitor or the (power) button on the remote controller.
• Turning off the engine will also turn off the TV tuner system.
08
VIDEO1
TV VIDEO2
Selected channel number appears
on the screen for a while.
Monitor Remote
UP
DOWN
or
CH
CH
H/P
VOL H/P VOL
MODE
Monitor Remote
CH
CH
H/P
VOL H/P VOL
MODE
MODE
EN09-15.KV-C10[E]f 01.1.17, 10:05 AM10

11
ENGLISH
Storing channels in memory (Auto memory)
The auto memory function picks up theTV broadcast signals in the area where you are and
stores them automatically in memory.
1
Select TV as the input source.
Press the MODE button on the monitor or the remote
controller repeatedly to select TV.
2
Start scanning TV broadcast signals.
Press and hold the AUTO/MANU button on the monitor or
press the A.MEMO button on the remote controller.
The auto memory function starts and TV broadcast signals
are picked up and stored in memory while scanning.
When scanning is over, the screen shows theTV program of the smallest channel number in
memory.
Notes:
• TV stations with weak signals are not be picked up, therefore not being stored in memory.
• If you drive from one broadcasting area to another, the stored channels will not be tuned in. In this
case, perform the auto memory function again to store the stations in another area.
Monitor Remote
Monitor Remote
MODE
CH
CH
H/P
VOL H/P VOL
MODE
AUTO/MANU
A.MEMO
VIDEO1
TV VIDEO2
DOWN UP AUTO/MANU MODE POWER
KV-M700 color monitor
CH
CH
COLOR BRIGHT CONTRA
H/P
VOL H/P VOL
MODE
SKIP
A.MEMO CALL
VOCAL
RF
MONI
VCR
KV-M700 remote
controller
1
2
12
SCAN
AUTO MEMORY
22
EN09-15.KV-C10[E]f 01.1.17, 10:05 AM11

12
ENGLISH
Setting the channel selection
You can set the channel selection method either to select only the receivable channels in
memory or to select all the channels.
Rememberthatif youwantto select only thereceivablechannels,youmuststorethe channels
first.To store them, see page 11.
CH
CH
COLOR BRIGHT CONTRA
H/P
VOL H/P VOL
MODE
SKIP
A.MEMO CALL
VOCAL
RF
MONI
VCR
1
2
Monitor Remote
Monitor Remote
MODE
CH
CH
H/P
VOL H/P VOL
MODE
VIDEO1
TV VIDEO2
1
Select TV as the input source.
Press the MODE button on the monitor or the remote
controller repeatedly to select TV.
2
Set the channel selection to “AUTO” or
“MANUAL.”
Press the AUTO/MANU button on the monitor or the SKIP
button on the remote controller.
Each time you press the button, the channel selection
alternates between “AUTO” and “MANUAL.”
AUTO: Onlythereceivablechannels storedin memory
canbeselected.Whenyouchangethechannel,
channel number and “AUTO” appear on the
screen for a while.
MANUAL: All the channels can be selected. (Channel
coverage:VHFchannels1to12, UHF channels
21 to 69)
AUTO/MANU
SKIP
DOWN UP AUTO/MANU MODE POWER
KV-M700 color monitor
12
KV-M700 remote controller
AUTO
08
EN09-15.KV-C10[E]f 01.1.17, 10:05 AM12

13
ENGLISH
Watching playback of external component
You can connect up to 2 external video components to the TV tuner unit.
To watch the playback, first follow steps 1 and 2 on page 9, then perform the following steps.
1
Select the input source.
Press the MODE button on the monitor or the remote
controller to select the input source you want.
Each time you press the button, the input source changes as
follows:
The selected input source name also appears on the screen
for 3 seconds.
2
Play back the external component.
To operate the external components, refer to the manuals of the connected
components.
3
Adjust the volume level on the car receiver.
Monitor Remote
MODE
CH
CH
H/P
VOL H/P VOL
MODE
VIDEO1
EX:When VIDEO1 is selected.
CH
CH
COLOR BRIGHT CONTRA
H/P
VOL H/P VOL
MODE
MONI
1
KV-M700 remote controller
1
DOWN UP AUTO/MANU MODE POWER
KV-M700 color monitor
VIDEO1
TV VIDEO2
EN09-15.KV-C10[E]f 01.1.17, 10:05 AM13

14
ENGLISH
SKIP
A.MEMO CALL
VOCAL
RF
RM-RK37RM-RK37
CALL
KV-M700 remote controller
To check the current input source
Press the CALL button on the remote controller.
The current input source name appears on the screen for
3 seconds.
To turn off the power
Press the POWER button on the monitor or the (power) button on the remote controller.
• Turning off the engine will also turn off the TV tuner system.
Notes:
•When you watch the screen aslant, the picture might not be clear. This is not a malfunction. The
finest picture can be seen when you watch the screen straight.
•When JVC mobile video cassette player KV-V8 or JVC mobile video cassette recorder KV-V10 is
connected to the system, you can also operate it by using the remote controller supplied with this
system. For the operation, refer to the instructions of KV-V8 or KV-V10.
EN09-15.KV-C10[E]f 01.1.17, 10:05 AM14

15
ENGLISH
OTHER FUNCTIONS
Setting the RF input
This system provides RF input selector.When you use JVC FM modulator KS-IF200, you can
listen to the sounds from the system through the receiver equipped with no line input. For
connecting and setting KS-IF200, refer to the instructions of KS-IF200.
Press the RF button on the remote controller.Each time you press
the button, “RF ON” and “RF OFF” alternate, and the selected setting
appears on the screen.
RF ON: When reproducing the sound from the system through the
receiver equipped with no line input. (When using KS-
IF200)
RF OFF: Select this when you listen to the radio using the receiver
connected to this unit. (When using KS-IF200)
SKIP
A.MEMO CALL
VOCAL
RF
RM-RK37RM-RK37
KV-M700 remote controller
RF ON
RF OFF
RF
RF
EN09-15.KV-C10[E]f 01.1.17, 10:05 AM15

16
ENGLISH
ADJUSTMENTS
Adjusting the color
You can adjust the color of the monitor system of KV-M700.
This function can be operated only by using the remote controller supplied with
KV-M700.
CH
CH
COLOR BRIGHT CONTRA
H/P
VOL H/P VOL
MODE
SKIP
A.MEMO CALL
VOCAL
RF
MONI
VCR
RM-RK37RM-RK37
1 Press the COLOR button.
The color level appears on the screen.
2 Pressthe 3 (up)or 2 (down)buttontoadjust
the color.
You can adjust the color level between 0 and 15.
2
3
COLOR
Gets deeper
(=15)
08 COLOR
COLOR
Gets softer
(0 +)
EN16-19.KV-C10[E]f 01.1.17, 10:05 AM16

17
ENGLISH
Adjusting the brightness
You can adjust the brightness of the monitor system of KV-M700.
This function can be operated only by using the remote controller supplied with
KV-M700.
1 Press the BRIGHT button.
The brightness level appears on the screen.
2 Pressthe 3 (up)or 2 (down)buttontoadjust
the brightness.
You can adjust the brightness level between 0 and 15.
CH
CH
COLOR BRIGHT CONTRA
H/P
VOL H/P VOL
MODE
SKIP
A.MEMO CALL
VOCAL
RF
MONI
VCR
RM-RK37RM-RK37
3
Gets brighter
(=15)
BRIGHT
2
BRIGHT
08 BRIGHT
Gets darker
(0 +)
EN16-19.KV-C10[E]f 01.1.17, 10:05 AM17

18
ENGLISH
Adjusting the contrast
You can adjust the contrast of the monitor system of KV-M700.
This function can be operated only by using the remote controller supplied with
KV-M700.
1 Press the CONTRA button.
The contrast level appears on the screen.
2 Pressthe 3 (up)or 2 (down)buttontoadjust
the contrast.
You can adjust the contrast level between 0 and 15.
CH
CH
COLOR BRIGHT CONTRA
H/P
VOL H/P VOL
MODE
SKIP
A.MEMO CALL
VOCAL
RF
MONI
VCR
RM-RK37RM-RK37
2
3
CONTRA
Gets higher
(=15)
CONTRA
08 CONTRAST
Gets lower
(0 +)
EN16-19.KV-C10[E]f 01.1.17, 10:05 AM18

19
ENGLISH
Adjusting the headphone volume
You can connect two pairs of headphones. When adjusting the headphone volume, the
adjustment applies to both connected headphones at the same time.
• You cannot adjust the headphone volume separately for the HEADPHONE 1 and 2 jacks.
This function can be operated only by using the remote controller supplied with
KV-M700.
CH
CH
COLOR BRIGHT CONTRA
H/P
VOL H/P VOL
SKIP
A.MEMO CALL
VOCAL
RF
MONI
VCR
RM-RK37
MODE
Press and hold the 3 (up) H/P VOL or 2
(down) H/PVOL button to adjust the
headphone volume.
You can adjust the volume level between 0 and 35.
The headphone volume level appears on the screen.
Note:
This adjustment is only for the connected headphones but not for the speakers in the car.When adjusting
the speaker volume, adjust it by using the car receiver.
2 and 3
H/P VOL
CH
CH
H/P
VOL H/P VOL
MODE
CH
CH
H/P
VOL H/P VOL
MODE
Gets smaller (0 +)Gets louder (=35)
15 VOLUME
EN16-19.KV-C10[E]f 01.1.17, 10:05 AM19

20
ENGLISH
MAINTENANCE
To prevent damage to the system exterior
• Do not apply pesticides, benzine, thinner or other volatile substances to the unit.
The cabinet surface primarily consists of plastic materials.
• Donotwipewith benzine, thinner or similarsubstancesbecausethiswillresultindiscoloration
or removal of the paint.
• When a cloth with a cleansing chemical is used, follow the caution points:
– Do not leave the unit in contact with rubber or vinyl products for long periods of time.
– Donotusecleanserswhichhavepolishinggranulesbecausethiscoulddamagethesurface
of the unit.
Clean dirt by wiping lightly with a soft cloth
When the unit is very dirty, wipe with a well-wrung cloth dipped in a kitchen cleanser (neutral)
thinned by water and then go over the same surface with a dry cloth.
(Since there is the possibility of water drops getting inside of the unit, do not directly apply
cleanser to the surface.)
Caution:
If water drops or similar wet substances get inside of the monitor via the liquid crystal panel surface,
it may cause a malfunction.
EN20-23.KV-C10[E]f 01.1.17, 10:05 AM20
