SERVICE MANUAL
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LIMITED No.52062C
2003/10
COLOUR TELEVISION
52062C200310 AV-2968TEE/SK
AV-2969TEE/SK
Supplementary
OUTLINE
HOW TO IDENTIFY MODELS
We have changed the production country for some parts. As a result, some parts number have been changed.
Therefore, this service manual describes only these parts number.
For others, please use the service manual for AV-2968TEE (No.52062, Sep. 2002).
Since the production country was changed, we have issued the SERVICE MANUAL for AV-2968TEE/SK, AV-
2969TEE/SK.
“AV-2968TEE-SK” and “AV-2969TEE-SK” are added to the serial No. under at the Rating label.
MODEL
Indicated
SERIAL No. AV-2968TEE-SK
AV-2969TEE-SK
AV-2968TEE
AV-2969TEE
BASIC CHASSIS
CH

1-2 (No.52062C)
DIFFERENCE LIST
USING P.W. BOARD (Page 43)
EXPLODED VIEW PARTS LIST (l) (Page 43)
EXPLODED VIEW PARTS LIST (ll) (Page 44)
PACKING PARTS LIST (Page 62)
P.W.B ASS'Y Name AV-2968TEE AV-2968TEE/SK DESCRIPTION
MAIN PWB SCH-1104A-H2 SCH-1601A-H2 Non compatible
CRT SOKET P.W.B SCH-3005A-H2 SCH-3603A-H2 Non compatible
FRONT CONTROL P.W.B SCH-8004A-H2 SCH-8601A-H2 Non compatible
P.W.B ASS'Y Name AV-2968TEE AV-2969TEE/SK DESCRIPTION
MAIN PWB SCH-1104A-H2 SCH-1602A-H2 Non compatible
CRT SOKET P.W.B SCH-3005A-H2 SCH-3604A-H2 Non compatible
FRONT CONTROL P.W.B SCH-8004A-H2 SCH-8602A-H2 Non compatible
Ref. No. PARTS No. PARTS NAME DESCRIPTION
AV-2968TEE AV-2968TEE/SK
AV-2969TEE/SK
25 LC11193-021C-H LC11193-021C-HK F.CABINET ASSY
Ref. No. PARTS No. PARTS NAME DESCRIPTION
AV-2968TEE AV-2968TEE/SK
AV-2969TEE/SK
V01 A68QCU257X75K A68QCU257X77ND PICTURE TUBE (ITC) Inc.DEF YOKE
1 LC11061-001A-H LC11061-001A-HK CHASSIS BASE
18 LC10763-004A-HH LC10763-004A-HK REAR COVER
Ref. No. PARTS No. PARTS NAME DESCRIPTION
AV-2968TEE AV-2969TEE-SK
6 LCT1178-001A-H LCT1519-001A-H INST BOOK
12 GG20025-003A-H LC21271-001A-H CORNER LABEL

(No.52062C)1-3
PRINTED WIRING BOARD PARTS LIST [AV-2968TEE/SK]
MAIN P.W. BOARD ASS'Y (SCH-1601A-H2)
 Ref No. Part No. Part Name Description Local
IC1130 M52342SP IC
IC1301 TDA9181T/N1-X IC
IC1401 LA78041 IC
IC1461 JLC1562BF-X IC
IC1480 UPC358G2-XE IC
IC1602 NJW1136GL1-W IC
IC1650 AN5277 IC
IC1701 TDA9365N23S0874 IC
IC1702 AT24C08-21WS3 IC (SERVICE)
IC1801 MM1492AF IC
IC1901 STR-F6256S-F7 IC
IC1951 SE135N IC
IC1972 L88M33T-X IC
IC1973 BA17812T IC
IC1974 BA51W12ST-V5 IC
Q1101 2SC5083/L-P/-T TRANSISTOR
Q1102 UN2212-X DIGI TRANSISTOR
Q1104 2SB709A/QR/-X TRANSISTOR
Q1105 2SD601A/QR/-X TRANSISTOR
Q1106 2SB709A/QR/-X TRANSISTOR
Q1107 UN2212-X DIGI TRANSISTOR
Q1108 2SD601A/QR/-X TRANSISTOR
Q1109 UN2212-X DIGI TRANSISTOR
Q1110 UN2212-X DIGI TRANSISTOR
Q1130 2SB709A/QR/-X TRANSISTOR
Q1131 UN2212-X DIGI TRANSISTOR
Q1132 2SD601A/QR/-X TRANSISTOR
Q1133 2SB709A/QR/-X TRANSISTOR
Q1134 UN2212-X DIGI TRANSISTOR
Q1135 UN2212-X DIGI TRANSISTOR
Q1136 2SD601A/QR/-X TRANSISTOR
Q1137 2SD601A/QR/-X TRANSISTOR
Q1138 UN2212-X DIGI TRANSISTOR
Q1301 2SB709A/QR/-X TRANSISTOR
Q1302 2SB709A/QR/-X TRANSISTOR
Q1303 UN2212-X DIGI TRANSISTOR
Q1304 2SD601A/QR/-X TRANSISTOR
Q1480 2SD1408/OY/-LB POW TRANSISTOR
Q1521 2SC2655/Y/-T TRANSISTOR
 Q1522 2SD2634-YD TRANSISTOR H.OUT
Q1591 2SA1208/ST/Z1-T TRANSISTOR
Q1592 UN2212-X DIGI TRANSISTOR
Q1660 2SD601A/QR/-X TRANSISTOR
Q1661 2SD601A/QR/-X TRANSISTOR
Q1683 2SB709A/QR/-X TRANSISTOR
Q1684 2SB709A/QR/-X TRANSISTOR
Q1685 DTC323TK-X DIGI TRANSISTOR
Q1686 DTC323TK-X DIGI TRANSISTOR
Q1701 2SB709A/QR/-X TRANSISTOR
Q1702 2SB709A/QR/-X TRANSISTOR
Q1720 2SB709A/QR/-X TRANSISTOR
Q1801 DTC323TK-X DIGI TRANSISTOR
Q1802 DTC323TK-X DIGI TRANSISTOR
Q1803 2SB709A/QR/-X TRANSISTOR
Q1804 2SC1740S/QR/-T TRANSISTOR
Q1860 2SD601A/QR/-X TRANSISTOR
Q1861 2SB709A/QR/-X TRANSISTOR
Q1862 2SB709A/QR/-X TRANSISTOR
Q1901 2SC3852A SI TRANSISTOR
Q1951 2SA1013/RO/-T SI TRANSISTOR
Q1952 2SD601A/QR/-X TRANSISTOR
Q1953 2SD601A/QR/-X TRANSISTOR
Q1954 2SD601A/QR/-X TRANSISTOR
Q1955 2SD601A/QR/-X TRANSISTOR
D1101 1SS268-X SI DIODE
D1301 MTZJ5.1B-T2 Z DIODE
D1401 RGP10J-5025-T3 SI DIODE
D1402 MTZJ75-T2 Z DIODE
D1405 1N4003-T2 SI DIODE
D1408 MA111-X SI DIODE
D1480 MTZJ4.3A-T2 Z DIODE
D1521 RH3G-F1 SI DIODE
D1522 31DF6N-FC5 FR DIODE
D1523 RGP10J-5025-T3 SI DIODE
D1541 RGP10J-5025-T3 SI DIODE
D1550 MA111-X SI DIODE
D1551 EU2-T3 SI DIODE
D1553 RGP10J-5025-T3 SI DIODE
D1554 RGP10J-5025-T3 SI DIODE
D1592 MA3075/H/-X CHIP ZENER DIODE
D1652 MA3330/L/-X Z DIODE
D1653 MA3330/L/-X Z DIODE
D1655 MA111-X SI DIODE
D1657 MA111-X SI DIODE
D1701 MA111-X SI DIODE
D1702 MA3020-X CHIP ZENER DIODE
D1703 MA3036-X CHIP ZENER DIODE
D1730 MA111-X SI DIODE
D1731 MA111-X SI DIODE
D1732 MA111-X SI DIODE
D1733 MA111-X SI DIODE
D1801 MA3120/M/-X Z DIODE
D1802 MA3120/M/-X Z DIODE
D1901 GSIB460 BRIDGE DIODE
D1902 MTZJ33B-T2 Z DIODE
D1906 MTZJ27B-T2 Z DIODE
D1907 MTZJ33B-T2 Z DIODE
D1908 MA3200/M/-X CHIP ZENER DIODE
D1909 1SS133-T2 DIODE
D1911 RGP10J-5025-T3 SI DIODE
D1912 RGP10J-5025-T3 SI DIODE
D1913 RGP10M-5010-T3 SI DIODE
D1914 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
D1915 MTZJ39B-T2 Z DIODE
D1916 MTZJ15B-T2 Z DIODE
D1917 1SS133-T2 DIODE
D1919 1SS133-T2 DIODE
D1920 MTZJ15B-T2 Z DIODE
D1950 RGP10J-5025-T3 SI DIODE
D1952 ERC30-02L38 SI DIODE
D1953 RGP10J-5025-T3 SI DIODE
D1954 RU30A-F1 SI DIODE
D1955 1SR35-400A-T2 SI DIODE
D1956 31DF6N-FC5 FR DIODE
D1958 MTZJ5.1A-T2 Z DIODE
D1960 MA111-X SI DIODE
D1964 MA3330/L/-X Z DIODE
D1966 MA3047/L/-X CHIP ZENER DIODE
D1968 MA111-X SI DIODE
D1969 MA111-X SI DIODE
D1970 MTZJ9.1B-T2 Z DIODE
D1971 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
C1001 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1002 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1003 QFV71HJ-104Z MF CAPACITOR 0.1uF 50V J
C1004 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1005 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1006 QETN1CM-336Z E CAPACITOR 33uF 16V M
C1007 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1101 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1102 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1103 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1104 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1105 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1106 NDC31HJ-180X C CAPACITOR 18pF 50V J
C1107 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1109 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1130 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1131 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1132 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1133 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1134 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1135 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1136 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1137 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1138 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1139 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1140 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1141 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1142 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1143 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1144 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C1301 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1302 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1304 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1305 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1306 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1307 NDC31HJ-330X C CAPACITOR 33pF 50V J
C1308 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1315 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1401 QETN1HM-336Z E CAPACITOR 33uF 50V M
C1402 QCB31HK-682Z C CAPACITOR 6800pF 50V K
C1403 QEHR1VM-107Z E CAPACITOR 100uF 35V M
C1406 QFLC2AJ-683Z M CAPACITOR 0.068uF 100V J
C1407 QCS32HJ-560Z C CAPACITOR 56pF 500V J
C1411 NCF21HZ-334X C CAPACITOR 0.33uF 50V Z
C1412 NCF21HZ-334X C CAPACITOR 0.33uF 50V Z
 Ref No. Part No. Part Name Description Local

1-4 (No.52062C)
C1413 QFLC2AJ-563Z M CAPACITOR 0.056uF 100V J
C1422 QEHQ1VM-108 E CAPACITOR 1000uF 35V M
C1471 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1480 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1483 QEZ0195-475Z BP E CAPACITOR 4.7uF 50V M
C1485 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1521 QETN1VM-476Z E CAPACITOR 47uF 35V M
C1522 QFLC1HJ-332Z M CAPACITOR 3300pF 50V J
C1523 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C1524 QFZ0196-382 MPP CAPACITOR 3800pF 1.5kV H
C1525 QFZ0200-143 MPP CAPACITOR 0.014uF 1.5kV H
C1526 QFP32JJ-223 PP CAPACITOR 0.022uF 630V J
C1527 QFZ0199-224 MPP CAPACITOR 0.22uF
C1528 QFZ0199-224 MPP CAPACITOR 0.22uF
C1529 QENC2AM-225Z BP E CAPACITOR 2.2uF 100V M
C1530 QCB32HK-561Z C CAPACITOR 560pF 500V K
C1531 QEHR1EM-108Z E CAPACITOR 1000uF 25V M
C1532 QCB32HK-561Z C CAPACITOR 560pF 500V K
C1533 QEHR1EM-108Z E CAPACITOR 1000uF 25V M
C1534 QCB32HK-561Z C CAPACITOR 560pF 500V K
C1536 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C1540 QFV71HJ-104Z MF CAPACITOR 0.1uF 50V J
C1541 QETN2EM-106Z E CAPACITOR 10uF 250V M
C1550 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1561 QFV21HJ-154Z MF CAPACITOR 0.15uF 50V J
C1566 QFZ0196-113 MPP CAPACITOR 0.011uF 1.5kV H
C1591 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1592 QETM2CM-227 E CAPACITOR 220uF 160V M
C1593 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1625 NCF21EZ-474X C CAPACITOR 0.47uF 25V Z
C1626 NCB31HK-333X C CAPACITOR 0.033uF 50V K
C1627 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C1628 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C1629 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1630 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1631 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1632 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1633 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1634 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1635 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1636 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1637 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1638 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1639 QETN1HM-107Z E CAPACITOR 100uF 50V M
C1640 NCF21HZ-334X C CAPACITOR 0.33uF 50V Z
C1641 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1643 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1644 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1645 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1646 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1647 NCF21EZ-474X C CAPACITOR 0.47uF 25V Z
C1648 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C1649 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C1650 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1651 QEHR1HM-107Z E CAPACITOR 100uF 50V M
C1652 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1653 NCF21HZ-224X C CAPACITOR 0.22uF 50V Z
C1654 NCF21HZ-224X C CAPACITOR 0.22uF 50V Z
C1655 NCF21HZ-224X C CAPACITOR 0.22uF 50V Z
C1656 NCF21HZ-224X C CAPACITOR 0.22uF 50V Z
C1662 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1681 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1682 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1683 QETN1CM-336Z E CAPACITOR 33uF 16V M
C1684 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1702 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1703 NDC31HJ-330X C CAPACITOR 33pF 50V J
C1704 NDC31HJ-330X C CAPACITOR 33pF 50V J
C1706 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1707 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1709 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1710 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1711 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1712 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1713 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1720 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1725 NCB31HK-681X C CAPACITOR 680pF 50V K
C1729 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1730 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1731 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1732 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1733 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1734 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1735 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1736 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1737 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1738 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1739 NFV41CJ-104X MPPS CAPACITOR 0.1uF 16V J
C1740 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
 Ref No. Part No. Part Name Description Local
C1741 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1742 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1743 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1744 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1745 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C1747 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C1749 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1751 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1752 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1753 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1801 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1802 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1803 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1804 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1805 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1807 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1808 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1810 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1811 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1812 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1813 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1814 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1815 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1817 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1819 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1820 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1821 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1822 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1823 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1824 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1825 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1826 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1827 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1829 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1830 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1831 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1833 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1834 NDC31HJ-181X C CAPACITOR 180pF 50V J
 C1902 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K
 C1903 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z
 C1904 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z
 C1905 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z
C1907 QEZ0633-337 E CAPACITOR 330uF
C1909 QCZ0325-102 C CAPACITOR 1000pF 2kV K
C1910 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C1911 QETN1VM-107Z E CAPACITOR 100uF 35V M
C1913 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
C1915 QCB32HK-222Z C CAPACITOR 2200pF 500V K
C1916 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1917 QCB32HK-181Z C CAPACITOR 180pF 500V K
C1918 QCB32HK-103 C CAPACITOR 0.01uF 500V K
C1919 QCZ0325-391 C CAPACITOR 390pF 2kV K
C1920 QCZ0122-471 C CAPACITOR 470pF 2kV K
C1921 QFN31HJ-473Z M CAPACITOR 0.047uF 50V J
C1922 QETN2AM-226Z E CAPACITOR 22uF 100V M
C1952 QCB32HK-471Z C CAPACITOR 470pF 500V K
C1953 QEHQ1VM-228 E CAPACITOR 2200uF 35V M
C1955 QCB32HK-471Z C CAPACITOR 470pF 500V K
C1956 QETN1VM-107Z E CAPACITOR 100uF 35V M
C1957 QCB31HK-471Z C CAPACITOR 470pF 50V K
C1958 QEHR1CM-108Z E CAPACITOR 1000uF 16V M
C1959 QCZ0364-561 C CAPACITOR 560pF 2kV K
C1960 QEZ0203-227 E CAPACITOR 220uF 160V M
C1961 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1962 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1963 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1964 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1965 QETN1VM-476Z E CAPACITOR 47uF 35V M
C1966 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1968 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1970 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1972 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1974 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1975 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1977 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1978 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1980 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1981 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1982 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1983 QETN1CM-227Z E CAPACITOR 220uF 16V M
 C1991 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C1992 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C1993 QCZ9079-102 C CAPACITOR 1000pF AC250V M
R1001 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R1002 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R1003 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R1004 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1005 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
 Ref No. Part No. Part Name Description Local

(No.52062C)1-5
R1006 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1101 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R1102 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R1103 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R1104 NRSA63J-181X MG RESISTOR 180 Ω 1/16W J
R1105 NRSA63J-220X MG RESISTOR 22 Ω 1/16W J
R1106 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1107 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R1108 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1109 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1111 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1113 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1114 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1115 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1117 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1130 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R1131 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1132 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1133 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R1134 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R1135 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R1136 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1137 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1138 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R1139 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1140 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R1141 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R1142 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R1143 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1144 NRSA63J-220X MG RESISTOR 22 Ω 1/16W J
R1145 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R1146 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1147 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1148 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R1149 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1155 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1301 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1302 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1303 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1304 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1305 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1306 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1307 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1308 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1309 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1310 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1311 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R1317 QRL029J-101 OMF RESISTOR 100 Ω 2W J
R1401 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R1403 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1405 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R1406 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1408 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R1410 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1411 QRG01GJ-221 OMF RESISTOR 220 Ω 1W J
R1412 QRE121J-1R0Y C RESISTOR 1
Ω 1/2W J
R1413 QRX01GJ-1R2 MF RESISTOR 1.2 Ω 1W J
R1414 QRE121J-2R2Y C RESISTOR 2.2
Ω 1/2W J
R1415 QRE121J-120Y C RESISTOR 12 Ω 1/2W J
R1416 QRE141J-225Y C RESISTOR 2.2M
Ω 1/4W J
R1425 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R1478 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1479 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1480 QRE121J-681Y C RESISTOR 680 Ω 1/2W J
R1481 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R1482 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1483 NRSA63J-823X MG RESISTOR 82k
Ω 1/16W J
R1484 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R1485 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R1486 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R1487 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1489 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R1490 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1491 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R1492 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R1493 QRE121J-223Y C RESISTOR 22k
Ω 1/2W J
R1494 QRL039J-330 OMF RESISTOR 33 Ω 3W J
R1521 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1522 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1523 QRL039J-151 OMF RESISTOR 150
Ω 3W J
R1524 QRL039J-151 OMF RESISTOR 150 Ω 3W J
R1526 QRL029J-271 OMF RESISTOR 270
Ω 2W J
R1527 QRL039J-103 OMF RESISTOR 10k Ω 3W J
 R1528 QRZ9021-1R0 FUSI RESISTOR 1 Ω 1W J
 R1529 QRZ9021-1R0 FUSI RESISTOR 1 Ω 1W J
R1531 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
 R1532 QRZ9017-4R7 FUSI RESISTOR 4.7 Ω 1/4W J
R1541 QRE121J-124Y C RESISTOR 120k Ω 1/2W J
R1542 QRE121J-124Y C RESISTOR 120k Ω 1/2W J
 Ref No. Part No. Part Name Description Local
R1543 QRE121J-471Y C RESISTOR 470 Ω 1/2W J
R1545 QRE121J-220Y C RESISTOR 22 Ω 1/2W J
R1546 QRE121J-822Y C RESISTOR 8.2k Ω 1/2W J
 R1547 QRZ9011-4R7 FUSI RESISTOR 4.7 Ω 1/2W J
R1561 QRL029J-220 OMF RESISTOR 22 Ω 2W J
R1562 QRE121J-123Y C RESISTOR 12k Ω 1/2W J
R1563 QRZ0056-103Z COMP RESISTOR 10k Ω 1/2W K
R1591 QRA14CF-1202Y CMF RESISTOR 12k
Ω 1/4W F
R1592 QRZ0225-2R2 UNF RESISTOR 2.2
Ω 7W K
R1593 NRSA02F-332X MG RESISTOR 3.3k Ω 1/10W F
R1594 QRE121J-183Y C RESISTOR 18k Ω 1/2W J
R1595 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1621 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1622 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1623 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R1624 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1625 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1626 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1627 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1628 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1629 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1630 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1650 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1651 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1652 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1653 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1654 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1655 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1656 QRE121J-2R2Y C RESISTOR 2.2 Ω 1/2W J
R1657 QRE121J-2R2Y C RESISTOR 2.2 Ω 1/2W J
R1660 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1661 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R1662 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R1663 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1664 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1688 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R1690 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1691 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1695 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R1696 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1701 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1702 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1703 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1704 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1705 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1706 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1707 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1708 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1709 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1710 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1711 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1712 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1713 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1714 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1715 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1716 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1717 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1718 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R1719 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1720 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1721 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1722 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1723 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1724 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1725 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1726 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1727 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R1728 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1730 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R1731 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1732 NRSA02F-393X MG RESISTOR 39k
Ω 1/10W F
R1733 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R1734 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R1735 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R1736 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1737 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R1738 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1739 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1740 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1741 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1742 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1744 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R1745 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R1746 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1747 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1748 NRSA02J-225X MG RESISTOR 2.2M
Ω 1/10W J
R1749 NRSA02J-185X MG RESISTOR 1.8M
Ω 1/10W J
R1750 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1755 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
 Ref No. Part No. Part Name Description Local

1-6 (No.52062C)
CRT SOCKET P.W. BOARD ASS'Y (SCH-3603A-H2)
R1756 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1757 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1758 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1790 NRSA63J-270X MG RESISTOR 27 Ω 1/16W J
R1803 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R1804 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1805 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1806 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1807 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1808 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R1809 NRSA63J-391X MG RESISTOR 390 Ω 1/16W J
R1810 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R1811 NRSA63J-391X MG RESISTOR 390 Ω 1/16W J
R1812 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1813 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1815 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1818 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1820 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1821 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1823 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1824 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1826 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1829 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1830 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1831 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1832 NRSA63J-391X MG RESISTOR 390 Ω 1/16W J
R1833 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R1834 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1835 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1836 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1837 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1838 QRK126J-121X UNF C RESISTOR 120 Ω 1/2W J
R1839 QRE121J-221Y C RESISTOR 220 Ω 1/2W J
R1840 QRE121J-221Y C RESISTOR 220 Ω 1/2W J
R1841 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1842 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1843 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R1844 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1845 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1846 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1847 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1848 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1849 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1880 NRSA63J-202X MG RESISTOR 2k Ω 1/16W J
R1881 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1882 NRSA63J-181X MG RESISTOR 180 Ω 1/16W J
R1883 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1902 QRF154K-2R2 UNF WW RESISTOR 2.2 Ω 15W K
R1903 QRL039J-393 OMF RESISTOR 39k Ω 3W J
R1904 QRE121J-221Y C RESISTOR 220 Ω 1/2W J
R1905 QRM034J-R10 MP RESISTOR 0.1 Ω 3W J
R1906 QRE141J-1R5Y C RESISTOR 1.5 Ω 1/4W J
R1908 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1911 QRE121J-152Y C RESISTOR 1.5k Ω 1/2W J
R1912 QRE121J-123Y C RESISTOR 12k Ω 1/2W J
 R1913 QRZ9017-100 FUSI RESISTOR 10 Ω 1/4W J
R1914 QRL039J-473 OMF RESISTOR 47k Ω 3W J
R1915 NRSA63J-823X MG RESISTOR 82k
Ω 1/16W J
R1916 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R1951 QRE121J-223Y C RESISTOR 22k
Ω 1/2W J
R1952 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1953 QRE121J-152Y C RESISTOR 1.5k Ω 1/2W J
R1954 QRE121J-150Y C RESISTOR 15 Ω 1/2W J
R1955 QRG01GJ-330 OMF RESISTOR 33 Ω 1W J
R1956 QRE121J-120Y C RESISTOR 12
Ω 1/2W J
R1957 QRE121J-5R6Y C RESISTOR 5.6 Ω 1/2W J
R1958 QRL039J-820 OMF RESISTOR 82
Ω 3W J
R1959 QRE121J-820Y C RESISTOR 82
Ω 1/2W J
R1960 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R1961 QRL029J-223 OMF RESISTOR 22k
Ω 2W J
R1962 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R1963 QRE121J-332Y C RESISTOR 3.3k
Ω 1/2W J
R1964 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1965 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1966 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R1967 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R1968 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R1969 QRT029J-1R5 MF RESISTOR 1.5
Ω 2W J
R1970 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R1971 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R1972 QRE121J-182Y C RESISTOR 1.8k Ω 1/2W J
R1973 QRE121J-332Y C RESISTOR 3.3k
Ω 1/2W J
R1974 QRT029J-1R2 MF RESISTOR 1.2 Ω 2W J
 R1991 QRZ0057-825 C RESISTOR 8.2M Ω 1W J
L1001 QQL244K-8R2Z PEAKING COIL 8.2uH K
L1002 QQL244K-8R2Z PEAKING COIL 8.2uH K
L1101 QQLZ014-R82 COIL 0.82uH 100mA L
L1102 QQL244K-180Z PEAKING COIL 18uH K
 Ref No. Part No. Part Name Description Local
L1301 QQL244K-221Z PEAKING COIL 220uH K
L1401 QQL26AK-220Z CHOKE COIL 22uH K
L1480 QQR1138-001 CHOKE COIL
L1523 QQR1243-001 LINIARITY COIL
L1541 QQL244K-220Z PEAKING COIL 22uH K
L1561 QQLZ028-272 COIL 2.7mH
L1701 QQL244K-100Z PEAKING COIL 10uH K
L1702 QQL244K-100Z PEAKING COIL 10uH K
L1731 QQL244J-101Z PEAKING COIL 100uH J
L1951 QQLZ034-460 HEATER CHOKE 46uH
L1953 QQL244J-5R6Z COIL 5.6uH J
L1954 QQL26AK-820Z CHOKE COIL 82uH K
 T1521 QQR1229-001 DRIVE TRANSF
T1561 QQR1153-001 DAF TRANSF
 T1901 QQS0110-001 SW TRANSF
CF1103 QAX0639-001Z C TRAP 4.500MHz
CF1130 QAX0642-001Z C FILTER 4.500MHz
CF1140 QAX0695-001Z C FILTER 5.500MHz
CF1141 QAX0696-001Z C FILTER 6.000MHz
CF1142 QAX0697-001Z C FILTER 6.500MHz
CN1001 QGF1220C2-25 CONNECTOR FFC/FPC (1-25)
CN100A QGA2501C5-03Z CONNECTOR W-B (1-3)
CN100C QGA2501C5-06Z CONNECTOR W-B (1-6)
CN100D WJQ0003-002A E-SH C WIRE B-B
CN100S QGA2501C5-05Z CONNECTOR W-B (1-5)
CN100T QJK002-063231 SIN CR B-B WIRE
CN100U QGA2501C5-06Z CONNECTOR W-B (1-6)
CN100W QGA7901C1-02 CONNECTOR W-B (1-2)
CN10HV QGZ5004C1-06 CONNECTOR (1-6)
CN1DEG QGZ5004C1-02 CONNECTOR (1-2)
 CP1951 ICP-N75-Y IC PROTECTOR 2.7A
 CP1952 ICP-N38-Y IC PROTECTOR 1.5A
 CP1953 ICP-N38-Y IC PROTECTOR 1.5A
HS1401 LC30416-003A HEAT SINK
HS1480 LC32137-001A HEAT SINK/AL-F/
HS1522 LC31215-001A HEAT SINK/FE-P/
HS1650 GG30059-001A HEAT SINK
HS1901 LC31211-002A HEAT SINK/AL-F/
HS1974 CEHT11B-002QS HEAT SINK
J1801 QNN0349-001 PIN JACK S/V/L/R IN
J1802 QNN0349-002 PIN JACK V/L/R IN
J1803 QNN0348-001 PIN JACK L/R IN
J1804 QNN0349-001 PIN JACK V/L/R OUT
K1705 QQR1214-001Y FERRITE BEADS
K1706 QQR1113-001Z FERRITE BEADS
K1901 QQR1214-001Y FERRITE BEADS
K1902 QQR1214-001Y FERRITE BEADS
K1903 QQR1214-001Y FERRITE BEADS
K1904 QQR1113-001Z FERRITE BEADS
K1905 QQR1113-001Z FERRITE BEADS
K1951 QQR1214-001Y FERRITE BEADS
K1953 QQR1214-001Y FERRITE BEADS
K1954 QQR1214-001Y FERRITE BEADS
K1955 QQR1214-001Y FERRITE BEADS
 LF1901 QQR1356-001 LINE FILTER
 RY1901 QSK0061-001 RELAY
SF1101 QAX0325-001 SAW FILTER
SF1102 QAX0731-001 SAW FILTER
 TH1901 QAD0145-2R3 POSISTOR 2.3 Ω
TU1001 QAU0185-005 TUNER
X1701 QAX0737-001 CRYSTAL 12.000MHz
 Ref No. Part No. Part Name Description Local
Q3101 2SD601A/QR/-X TRANSISTOR
Q3102 2SD601A/QR/-X TRANSISTOR
Q3103 2SD601A/QR/-X TRANSISTOR
Q3104 2SD601A/QR/-X TRANSISTOR
Q3105 2SD601A/QR/-X TRANSISTOR
Q3106 2SD601A/QR/-X TRANSISTOR
Q3121 2SC1740S/QR/-T TRANSISTOR
Q3122 2SA933AS/QR/-T TRANSISTOR
Q3123 2SC4075/DE/YA11 POW TRANSISTOR
Q3124 2SC1740S/QR/-T TRANSISTOR
Q3125 2SC4075/DE/YA11 POW TRANSISTOR
Q3126 2SC1740S/QR/-T TRANSISTOR
Q3127 2SC4075/DE/YA11 POW TRANSISTOR
Q3128 2SC1740S/QR/-T TRANSISTOR
Q3129 2SC3334-T SI TRANSISTOR
Q3130 2SA1321-T SI TRANSISTOR
Q3131 2SC3334-T SI TRANSISTOR
Q3132 2SA1321-T SI TRANSISTOR
Q3133 2SC3334-T SI TRANSISTOR
 Ref No. Part No. Part Name Description Local

(No.52062C)1-7
Q3134 2SA1321-T SI TRANSISTOR
Q3135 2SB709A/QR/-X TRANSISTOR
Q3204 2SC1740S/QR/-T TRANSISTOR
Q3205 2SC1740S/QR/-T TRANSISTOR
Q3206 2SA933AS/QR/-T TRANSISTOR
Q3209 2SA1837 POW TRANSISTOR
Q3210 2SC4793 POW TRANSISTOR
Q3251 2SB709A/QR/-X TRANSISTOR
Q3252 2SD601A/QR/-X TRANSISTOR
Q3253 2SB709A/QR/-X TRANSISTOR
Q3261 2SB709A/QR/-X TRANSISTOR
Q3262 2SB709A/QR/-X TRANSISTOR
Q3263 2SB709A/QR/-X TRANSISTOR
Q3264 2SD601A/QR/-X TRANSISTOR
Q3265 2SD601A/QR/-X TRANSISTOR
Q3266 2SD601A/QR/-X TRANSISTOR
D3107 MA111-X SI DIODE
D3108 MA3075/H/-X CHIP ZENER DIODE
D3109 MA3051/H/-X Z DIODE
D3110 MA111-X SI DIODE
D3111 MA3051/H/-X Z DIODE
D3112 MA111-X SI DIODE
D3113 MA3051/H/-X Z DIODE
D3114 MA111-X SI DIODE
D3118 1SS244-T2 SI DIODE
D3119 1SS244-T2 SI DIODE
D3120 1SS244-T2 SI DIODE
D3121 1SS244-T2 SI DIODE
D3122 1SS244-T2 SI DIODE
D3123 1SS244-T2 SI DIODE
D3124 1N4003-T2 SI DIODE
D3125 1N4003-T2 SI DIODE
D3126 1N4003-T2 SI DIODE
D3127 MA111-X SI DIODE
D3131 MTZJ75-T2 Z DIODE
D3132 MA3043-X CHIP ZENER DIODE
D3134 1SS244-T2 SI DIODE
D3136 MA111-X SI DIODE
D3138 MA111-X SI DIODE
D3141 MTZJ30A-T2 Z DIODE
D3142 MTZJ30A-T2 Z DIODE
D3143 MTZJ30A-T2 Z DIODE
D3201 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
D3202 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
D3203 RGP10J-5025-T3 SI DIODE
D3204 RGP10J-5025-T3 SI DIODE
C3101 QETN1CM-477Z E CAPACITOR 470uF 16V M
C3107 QETM2EM-106 E CAPACITOR 10uF 250V M
C3108 QETM2EM-476 E CAPACITOR 47uF 250V M
C3110 QCZ0364-681 C CAPACITOR 680pF 2kV K
C3114 QCS31HJ-151Z C CAPACITOR 150pF 50V J
C3115 QETN1CM-476Z E CAPACITOR 47uF 16V M
C3116 NDC31HJ-561X C CAPACITOR 560pF 50V J
C3117 NCB31HK-471X C CAPACITOR 470pF 50V K
C3118 NCB31HK-471X C CAPACITOR 470pF 50V K
C3119 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C3120 QETN1HM-105Z E CAPACITOR 1uF 50V M
C3121 NCB31HK-102X C CAPACITOR 1000pF 50V K
C3204 NDC31HJ-561X C CAPACITOR 560pF 50V J
C3205 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C3206 QETN1HM-106Z E CAPACITOR 10uF 50V M
C3207 QCS31HJ-5R0Z C CAPACITOR 5pF 50V J
C3209 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3211 NDC31HJ-391X C CAPACITOR 390pF 50V J
C3212 QCB32HK-472Z C CAPACITOR 4700pF 500V K
C3213 NDC31HJ-561X C CAPACITOR 560pF 50V J
C3214 QETN2CM-106Z E CAPACITOR 10uF 160V M
C3215 QCB32HK-472Z C CAPACITOR 4700pF 500V K
C3216 QETN2CM-106Z E CAPACITOR 10uF 160V M
C3217 QETN1AM-107Z E CAPACITOR 100uF 10V M
C3218 QETN1AM-107Z E CAPACITOR 100uF 10V M
C3219 QETN1AM-337Z E CAPACITOR 330uF 10V M
C3220 QCS32HJ-680Z C CAPACITOR 68pF 500V J
C3251 QENC1HM-105Z BP E CAPACITOR 1uF 50V M
C3252 NDC31HJ-151X C CAPACITOR 150pF 50V J
C3253 NDC31HJ-560X C CAPACITOR 56pF 50V J
C3255 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C3261 NDC31HJ-820X C CAPACITOR 82pF 50V J
C3262 NDC31HJ-820X C CAPACITOR 82pF 50V J
C3263 NDC31HJ-820X C CAPACITOR 82pF 50V J
C3264 QETN1AM-107Z E CAPACITOR 100uF 10V M
C3265 QETN1AM-107Z E CAPACITOR 100uF 10V M
C3266 QETN1AM-107Z E CAPACITOR 100uF 10V M
C3267 QETN1CM-227Z E CAPACITOR 220uF 16V M
R3101 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R3102 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
 Ref No. Part No. Part Name Description Local
R3103 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R3104 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R3105 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3106 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R3107 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R3108 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3109 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R3110 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3111 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3112 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3113 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R3120 QRE121J-101Y C RESISTOR 100 Ω 1/2W J
R3121 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3122 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3123 QRE121J-152Y C RESISTOR 1.5k
Ω 1/2W J
R3124 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R3125 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3126 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3127 QRE121J-152Y C RESISTOR 1.5k Ω 1/2W J
R3128 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R3129 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3130 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3131 QRE121J-152Y C RESISTOR 1.5k
Ω 1/2W J
R3132 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R3133 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3136 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3137 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3138 QRL029J-223 OMF RESISTOR 22k Ω 2W J
R3139 QRL029J-223 OMF RESISTOR 22k Ω 2W J
R3140 QRZ0107-102Z C RESISTOR 1k Ω 1/2W K
R3141 QRL029J-223 OMF RESISTOR 22k Ω 2W J
R3143 QRL029J-223 OMF RESISTOR 22k Ω 2W J
R3144 QRZ0107-102Z C RESISTOR 1k Ω 1/2W K
R3145 QRL029J-223 OMF RESISTOR 22k Ω 2W J
R3146 QRL029J-223 OMF RESISTOR 22k Ω 2W J
R3147 QRZ0107-102Z C RESISTOR 1k Ω 1/2W K
R3148 QRE121J-124Y C RESISTOR 120k Ω 1/2W J
R3149 QRE121J-102Y C RESISTOR 1k Ω 1/2W J
R3151 QRE121J-124Y C RESISTOR 120k Ω 1/2W J
R3152 QRE121J-102Y C RESISTOR 1k Ω 1/2W J
R3153 QRE121J-124Y C RESISTOR 120k Ω 1/2W J
R3154 QRE121J-102Y C RESISTOR 1k Ω 1/2W J
R3155 QRE121J-474Y C RESISTOR 470k Ω 1/2W J
R3157 QRZ0107-474Z C RESISTOR 470k Ω 1/2W K
R3159 NRSA63J-184X MG RESISTOR 180k Ω 1/16W J
R3161 QRE121J-333Y C RESISTOR 33k Ω 1/2W J
R3164 QRE121J-560Y C RESISTOR 56 Ω 1/2W J
R3166 QRE121J-333Y C RESISTOR 33k Ω 1/2W J
R3167 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R3168 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3170 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R3171 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R3172 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3173 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3174 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R3211 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R3212 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R3213 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R3214 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R3215 NRSA63J-680X MG RESISTOR 68
Ω 1/16W J
R3216 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
 R3217 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R3221 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3222 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3224 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R3225 QRE121J-563Y C RESISTOR 56k Ω 1/2W J
R3226 QRE121J-563Y C RESISTOR 56k
Ω 1/2W J
R3227 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R3228 NRSA63J-390X MG RESISTOR 39
Ω 1/16W J
R3229 QRE121J-2R7Y C RESISTOR 2.7
Ω 1/2W J
R3230 QRE121J-2R7Y C RESISTOR 2.7
Ω 1/2W J
R3231 NRSA63J-390X MG RESISTOR 39
Ω 1/16W J
R3232 QRE121J-121Y C RESISTOR 120
Ω 1/2W J
R3233 QRL029J-391 OMF RESISTOR 390
Ω 2W J
R3251 NDC31HJ-331X C CAPACITOR 330pF 50V J
R3252 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R3253 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3254 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R3255 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R3256 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R3257 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3258 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R3259 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3260 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R3261 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3262 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3263 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R3264 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R3265 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
 Ref No. Part No. Part Name Description Local

1-8 (No.52062C)
FRONT CONTROL P.W. BOARD ASS'Y (SCH-8601A-H2)
R3266 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3267 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3268 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R3269 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3270 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3271 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3272 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R3273 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3274 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3275 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
L3121 QQL244J-5R6Z COIL 5.6uH J
L3122 QQLZ034-220 HEATER CHOKE 22uH
L3251 QQL244K-150Z PEAKING COIL 15uH K
CN300T QGA2501C5-06Z CONNECTOR W-B (1-6)
CN300U QJK002-063231 SIN CR B-B WIRE
CN30SC QGZ0017C1-01Z CONNECTOR (1-1)
CN30VM QGA2501C5-03 CONNECTOR W-B (1-3)
DL3261 CE41925-001 DELAY LINE
DL3262 CE41925-001 DELAY LINE
DL3263 CE41925-001 DELAY LINE
 FR3201 QRZ9021-561 FUSI RESISTOR 560 Ω 1W J
HS3123 CEHP00N-001QS HEAT SINK
HS3125 CEHP00N-001QS HEAT SINK
HS3127 CEHP00N-001QS HEAT SINK
HS3209 CEHP00N-001QS HEAT SINK
HS3210 CEHP00N-001QS HEAT SINK
K3201 CE41492-001Z CHOKE COIL
K3202 CE41492-001Z CHOKE COIL
K3203 CE41492-001Z CHOKE COIL
K3204 CE41492-001Z CHOKE COIL
K3205 QQR1113-001Z FERRITE BEADS
K3206 QQR1113-001Z FERRITE BEADS
K3207 QQR1113-001Z FERRITE BEADS
K3208 QQR1113-001Z FERRITE BEADS
 PC1901 PC123F2 PHOTO COUPLER
SG3101 QAF0056-501Z SURGE ABSORBER 500V M
SG3102 QAF0056-501Z SURGE ABSORBER 500V M
 SK3001 CE42670-001 CRT SOCKET
 Ref No. Part No. Part Name Description Local
IC8481 LA6515 IC
IC8801 GP1UM281QK IR DETECT UNIT 38kHz
Q8481 2SC2412K/QR/-X TRANSISTOR
Q8801 2SA1037AK/QR/-X TRANSISTOR
D8801 MA111-X SI DIODE
D8802 P1241-04 PHOTO CONDUCTOR
D8803 SLR-342VR-T16 LED POWER
C8481 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C8482 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C8483 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C8484 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C8485 QETN1EM-476Z E CAPACITOR 47uF 25V M
C8487 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C8660 QETM1VM-108 E CAPACITOR 1000uF 35V M
C8661 QETM1VM-108 E CAPACITOR 1000uF 35V M
C8801 QETN1HM-106Z E CAPACITOR 10uF 50V M
C8802 QETN1CM-107Z E CAPACITOR 100uF 16V M
C8803 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C8815 QETN1CM-107Z E CAPACITOR 100uF 16V M
 C8901 QFZ9072-224 MM CAPACITOR 0.22uF AC250V K
R8482 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R8483 NRSA63J-683X MG RESISTOR 68k
Ω 1/16W J
R8484 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R8485 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R8486 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R8487 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R8488 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R8489 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R8491 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R8492 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8495 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R8497 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R8499 QRE121J-561Y C RESISTOR 560
Ω 1/2W J
R8801 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R8802 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R8803 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R8805 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
R8807 NRSA63J-181X MG RESISTOR 180 Ω 1/16W J
R8808 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R8809 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R8810 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R8811 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R8812 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R8813 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R8815 QRE121J-271Y C RESISTOR 270
Ω 1/2W J
R8816 QRE121J-271Y C RESISTOR 270
Ω 1/2W J
R8817 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R8818 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R8819 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R8826 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8830 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R8831 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
 R8901 QRZ0111-474 C RESISTOR 470k Ω 1/2W K
L8401 QQL244K-820Z PEAKING COIL 82uH K
CN8001 QGF1220C2-25 CONNECTOR FFC/FPC (1-25)
CN8002 QJL001-123232 SIN CL B-B WIRE
CN8003 QGA2501C5-04Z CONNECTOR W-B (1-4)
CN800A QJB003-035433 SIN ID C-B WIRE
CN800R QGA2501C5-03Z CONNECTOR W-B (1-3)
CN800W CHGH0001-AB-GS CONNECTOR ASSY
CN80PW QGA7901C1-02 CONNECTOR W-B (1-2)
 F8901 QMF51E2-4R0J4 FUSE 4A AC250V
J8302 QNN0279-003 PIN JACK V IN
J8303 QNN0279-002 PIN JACK L/MONO IN
J8304 QNN0279-001 PIN JACK R IN
J8801 QNS0155-001 3.5 JACK HEADPHONE
 LF8901 QQR1356-001 LINE FILTER
S8801 QSW0619-003Z TACT SWITCH CH+
S8802 QSW0619-003Z TACT SWITCH CH-
S8803 QSW0619-003Z TACT SWITCH MENU
S8804 QSW0619-003Z TACT SWITCH TV/VIDEO
S8805 QSW0619-003Z TACT SWITCH VOL+
S8806 QSW0619-003Z TACT SWITCH VOL-
 S8901 QSW0750-001 PUSH SWITCH POWER
 VA8901 QAF0052-621 VARISTOR 620V
 Ref No. Part No. Part Name Description Local

(No.52062C)1-9
PRINTED WIRING BOARD PARTS LIST [AV-2969TEE/SK]
MAIN P.W. BOARD ASS'Y (SCH-1602A-H2)
 Ref No. Part No. Part Name Description Local
IC1130 M52342SP IC
IC1301 TDA9181T/N1-X IC
IC1401 LA78041 IC
IC1461 JLC1562BF-X IC
IC1480 UPC358G2-XE IC
IC1602 NJW1136GL1-W IC
IC1650 AN5277 IC
IC1701 TDA9365N23S0874 IC
IC1702 AT24C08-21WS3 IC (SERVICE)
IC1801 MM1492AF IC
IC1901 STR-F6256S-F7 IC
IC1951 SE135N IC
IC1972 L88M33T-X IC
IC1973 BA17812T IC
IC1974 BA51W12ST-V5 IC
Q1101 2SC5083/L-P/-T TRANSISTOR
Q1102 UN2212-X DIGI TRANSISTOR
Q1104 2SB709A/QR/-X TRANSISTOR
Q1105 2SD601A/QR/-X TRANSISTOR
Q1106 2SB709A/QR/-X TRANSISTOR
Q1107 UN2212-X DIGI TRANSISTOR
Q1108 2SD601A/QR/-X TRANSISTOR
Q1109 UN2212-X DIGI TRANSISTOR
Q1110 UN2212-X DIGI TRANSISTOR
Q1130 2SB709A/QR/-X TRANSISTOR
Q1131 UN2212-X DIGI TRANSISTOR
Q1132 2SD601A/QR/-X TRANSISTOR
Q1133 2SB709A/QR/-X TRANSISTOR
Q1134 UN2212-X DIGI TRANSISTOR
Q1135 UN2212-X DIGI TRANSISTOR
Q1136 2SD601A/QR/-X TRANSISTOR
Q1137 2SD601A/QR/-X TRANSISTOR
Q1138 UN2212-X DIGI TRANSISTOR
Q1301 2SB709A/QR/-X TRANSISTOR
Q1302 2SB709A/QR/-X TRANSISTOR
Q1303 UN2212-X DIGI TRANSISTOR
Q1304 2SD601A/QR/-X TRANSISTOR
Q1480 2SD1408/OY/-LB POW TRANSISTOR
Q1521 2SC2655/Y/-T TRANSISTOR
 Q1522 2SD2634-YD TRANSISTOR H.OUT
Q1591 2SA1208/ST/Z1-T TRANSISTOR
Q1592 UN2212-X DIGI TRANSISTOR
Q1660 2SD601A/QR/-X TRANSISTOR
Q1661 2SD601A/QR/-X TRANSISTOR
Q1683 2SB709A/QR/-X TRANSISTOR
Q1684 2SB709A/QR/-X TRANSISTOR
Q1685 DTC323TK-X DIGI TRANSISTOR
Q1686 DTC323TK-X DIGI TRANSISTOR
Q1701 2SB709A/QR/-X TRANSISTOR
Q1702 2SB709A/QR/-X TRANSISTOR
Q1720 2SB709A/QR/-X TRANSISTOR
Q1801 DTC323TK-X DIGI TRANSISTOR
Q1802 DTC323TK-X DIGI TRANSISTOR
Q1803 2SB709A/QR/-X TRANSISTOR
Q1804 2SC1740S/QR/-T TRANSISTOR
Q1860 2SD601A/QR/-X TRANSISTOR
Q1861 2SB709A/QR/-X TRANSISTOR
Q1862 2SB709A/QR/-X TRANSISTOR
Q1901 2SC3852A SI TRANSISTOR
Q1951 2SA1013/RO/-T SI TRANSISTOR
Q1952 2SD601A/QR/-X TRANSISTOR
Q1953 2SD601A/QR/-X TRANSISTOR
Q1954 2SD601A/QR/-X TRANSISTOR
Q1955 2SD601A/QR/-X TRANSISTOR
D1101 1SS268-X SI DIODE
D1301 MTZJ5.1B-T2 Z DIODE
D1401 RGP10J-5025-T3 SI DIODE
D1402 MTZJ75-T2 Z DIODE
D1405 1N4003-T2 SI DIODE
D1408 MA111-X SI DIODE
D1480 MTZJ4.3A-T2 Z DIODE
D1521 RH3G-F1 SI DIODE
D1522 31DF6N-FC5 FR DIODE
D1523 RGP10J-5025-T3 SI DIODE
D1541 RGP10J-5025-T3 SI DIODE
D1550 MA111-X SI DIODE
D1551 EU2-T3 SI DIODE
D1553 RGP10J-5025-T3 SI DIODE
D1554 RGP10J-5025-T3 SI DIODE
D1592 MA3075/H/-X CHIP ZENER DIODE
D1652 MA3330/L/-X Z DIODE
D1653 MA3330/L/-X Z DIODE
D1655 MA111-X SI DIODE
D1657 MA111-X SI DIODE
D1701 MA111-X SI DIODE
D1702 MA3020-X CHIP ZENER DIODE
D1703 MA3036-X CHIP ZENER DIODE
D1730 MA111-X SI DIODE
D1731 MA111-X SI DIODE
D1732 MA111-X SI DIODE
D1733 MA111-X SI DIODE
D1801 MA3120/M/-X Z DIODE
D1802 MA3120/M/-X Z DIODE
D1901 GSIB460 BRIDGE DIODE
D1902 MTZJ33B-T2 Z DIODE
D1906 MTZJ27B-T2 Z DIODE
D1907 MTZJ33B-T2 Z DIODE
D1908 MA3200/M/-X CHIP ZENER DIODE
D1909 1SS133-T2 DIODE
D1911 RGP10J-5025-T3 SI DIODE
D1912 RGP10J-5025-T3 SI DIODE
D1913 RGP10M-5010-T3 SI DIODE
D1914 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
D1915 MTZJ39B-T2 Z DIODE
D1916 MTZJ15B-T2 Z DIODE
D1917 1SS133-T2 DIODE
D1919 1SS133-T2 DIODE
D1920 MTZJ15B-T2 Z DIODE
D1950 RGP10J-5025-T3 SI DIODE
D1952 ERC30-02L38 SI DIODE
D1953 RGP10J-5025-T3 SI DIODE
D1954 RU30A-F1 SI DIODE
D1955 1SR35-400A-T2 SI DIODE
D1956 31DF6N-FC5 FR DIODE
D1958 MTZJ5.1A-T2 Z DIODE
D1960 MA111-X SI DIODE
D1964 MA3330/L/-X Z DIODE
D1966 MA3047/L/-X CHIP ZENER DIODE
D1968 MA111-X SI DIODE
D1969 MA111-X SI DIODE
D1970 MTZJ9.1B-T2 Z DIODE
D1971 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
C1001 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1002 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1003 QFV71HJ-104Z MF CAPACITOR 0.1uF 50V J
C1004 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1005 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1006 QETN1CM-336Z E CAPACITOR 33uF 16V M
C1007 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1101 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1102 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1103 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1104 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1105 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1106 NDC31HJ-180X C CAPACITOR 18pF 50V J
C1107 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1109 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1130 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1131 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1132 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1133 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1134 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1135 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1136 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1137 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1138 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1139 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1140 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1141 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1142 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1143 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1144 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C1301 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1302 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1304 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1305 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1306 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1307 NDC31HJ-330X C CAPACITOR 33pF 50V J
C1308 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1315 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C1401 QETN1HM-336Z E CAPACITOR 33uF 50V M
C1402 QCB31HK-682Z C CAPACITOR 6800pF 50V K
C1403 QEHR1VM-107Z E CAPACITOR 100uF 35V M
C1406 QFLC2AJ-683Z M CAPACITOR 0.068uF 100V J
C1407 QCS32HJ-560Z C CAPACITOR 56pF 500V J
C1411 NCF21HZ-334X C CAPACITOR 0.33uF 50V Z
C1412 NCF21HZ-334X C CAPACITOR 0.33uF 50V Z
 Ref No. Part No. Part Name Description Local

1-10 (No.52062C)
C1413 QFLC2AJ-563Z M CAPACITOR 0.056uF 100V J
C1422 QEHQ1VM-108 E CAPACITOR 1000uF 35V M
C1471 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1480 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1483 QEZ0195-475Z BP E CAPACITOR 4.7uF 50V M
C1485 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1521 QETN1VM-476Z E CAPACITOR 47uF 35V M
C1522 QFLC1HJ-332Z M CAPACITOR 3300pF 50V J
C1523 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C1524 QFZ0196-382 MPP CAPACITOR 3800pF 1.5kV H
C1525 QFZ0200-143 MPP CAPACITOR 0.014uF 1.5kV H
C1526 QFP32JJ-223 PP CAPACITOR 0.022uF 630V J
C1527 QFZ0199-224 MPP CAPACITOR 0.22uF
C1528 QFZ0199-224 MPP CAPACITOR 0.22uF
C1529 QENC2AM-225Z BP E CAPACITOR 2.2uF 100V M
C1530 QCB32HK-561Z C CAPACITOR 560pF 500V K
C1531 QEHR1EM-108Z E CAPACITOR 1000uF 25V M
C1532 QCB32HK-561Z C CAPACITOR 560pF 500V K
C1533 QEHR1EM-108Z E CAPACITOR 1000uF 25V M
C1534 QCB32HK-561Z C CAPACITOR 560pF 500V K
C1536 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C1540 QFV71HJ-104Z MF CAPACITOR 0.1uF 50V J
C1541 QETN2EM-106Z E CAPACITOR 10uF 250V M
C1550 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1561 QFVM2AJ-154Z MF CAPACITOR 0.15uF 100V J
C1566 QFZ0196-113 MPP CAPACITOR 0.011uF 1.5kV H
C1591 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1592 QETM2CM-227 E CAPACITOR 220uF 160V M
C1593 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1625 NCF21EZ-474X C CAPACITOR 0.47uF 25V Z
C1626 NCB31HK-333X C CAPACITOR 0.033uF 50V K
C1627 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C1628 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C1629 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1630 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1631 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1632 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1633 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1634 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1635 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1636 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1637 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1638 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1639 QETN1HM-107Z E CAPACITOR 100uF 50V M
C1640 NCF21HZ-334X C CAPACITOR 0.33uF 50V Z
C1641 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1643 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1644 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1645 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1646 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1647 NCF21EZ-474X C CAPACITOR 0.47uF 25V Z
C1648 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C1649 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C1650 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1651 QEHR1HM-107Z E CAPACITOR 100uF 50V M
C1652 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1653 NCF21HZ-224X C CAPACITOR 0.22uF 50V Z
C1654 NCF21HZ-224X C CAPACITOR 0.22uF 50V Z
C1655 NCF21HZ-224X C CAPACITOR 0.22uF 50V Z
C1656 NCF21HZ-224X C CAPACITOR 0.22uF 50V Z
C1662 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1681 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1682 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1683 QETN1CM-336Z E CAPACITOR 33uF 16V M
C1684 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1702 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1703 NDC31HJ-330X C CAPACITOR 33pF 50V J
C1704 NDC31HJ-330X C CAPACITOR 33pF 50V J
C1706 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1707 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1709 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1710 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1711 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1712 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1713 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1720 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1725 NCB31HK-681X C CAPACITOR 680pF 50V K
C1729 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1730 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1731 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C1732 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1733 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1734 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1735 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1736 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1737 QETN1HM-105Z E CAPACITOR 1uF 50V M
C1738 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1739 NFV41CJ-104X MPPS CAPACITOR 0.1uF 16V J
C1740 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
 Ref No. Part No. Part Name Description Local
C1741 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1742 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1743 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1744 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1745 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C1747 NCB31HK-473X C CAPACITOR 0.047uF 50V K
C1749 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1751 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1752 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1753 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1801 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1802 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1803 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1804 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1805 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1807 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1808 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1810 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1811 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1812 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1813 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1814 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1815 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1817 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1819 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1820 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1821 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1822 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1823 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1824 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1825 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1826 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1827 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1829 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1830 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1831 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1833 QETN1HM-226Z E CAPACITOR 22uF 50V M
C1834 NDC31HJ-181X C CAPACITOR 180pF 50V J
 C1902 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K
 C1903 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z
 C1904 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z
 C1905 QCZ9015-102Z C CAPACITOR 1000pF AC250V Z
C1907 QEZ0633-337 E CAPACITOR 330uF
C1909 QCZ0325-102 C CAPACITOR 1000pF 2kV K
C1910 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C1911 QETN1VM-107Z E CAPACITOR 100uF 35V M
C1913 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
C1915 QCB32HK-222Z C CAPACITOR 2200pF 500V K
C1916 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1917 QCB32HK-181Z C CAPACITOR 180pF 500V K
C1918 QCB32HK-103 C CAPACITOR 0.01uF 500V K
C1919 QCZ0325-391 C CAPACITOR 390pF 2kV K
C1920 QCZ0122-471 C CAPACITOR 470pF 2kV K
C1921 QFN31HJ-473Z M CAPACITOR 0.047uF 50V J
C1922 QETN2AM-226Z E CAPACITOR 22uF 100V M
C1952 QCB32HK-471Z C CAPACITOR 470pF 500V K
C1953 QEHQ1VM-228 E CAPACITOR 2200uF 35V M
C1955 QCB32HK-471Z C CAPACITOR 470pF 500V K
C1956 QETN1VM-107Z E CAPACITOR 100uF 35V M
C1957 QCB31HK-471Z C CAPACITOR 470pF 50V K
C1958 QEHR1CM-108Z E CAPACITOR 1000uF 16V M
C1959 QCZ0364-561 C CAPACITOR 560pF 2kV K
C1960 QEZ0203-227 E CAPACITOR 220uF 160V M
C1961 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1962 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1963 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1964 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1965 QETN1VM-476Z E CAPACITOR 47uF 35V M
C1966 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1968 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1970 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1972 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1974 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1975 QETN1CM-227Z E CAPACITOR 220uF 16V M
C1977 QETN1EM-476Z E CAPACITOR 47uF 25V M
C1978 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1980 QETN1CM-107Z E CAPACITOR 100uF 16V M
C1981 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1982 QETN1CM-476Z E CAPACITOR 47uF 16V M
C1983 QETN1CM-227Z E CAPACITOR 220uF 16V M
 C1991 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C1992 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C1993 QCZ9079-102 C CAPACITOR 1000pF AC250V M
R1001 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R1002 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R1003 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R1004 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1005 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
 Ref No. Part No. Part Name Description Local

(No.52062C)1-11
R1006 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1101 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R1102 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R1103 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R1104 NRSA63J-181X MG RESISTOR 180 Ω 1/16W J
R1105 NRSA63J-220X MG RESISTOR 22 Ω 1/16W J
R1106 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1107 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R1108 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1109 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1111 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1113 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1114 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1115 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1117 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1130 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R1131 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1132 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1133 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R1134 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R1135 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R1136 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1137 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1138 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R1139 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1140 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R1141 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R1142 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R1143 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1144 NRSA63J-220X MG RESISTOR 22 Ω 1/16W J
R1145 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R1146 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1147 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1148 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R1149 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1155 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1301 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1302 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1303 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1304 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1305 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1306 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1307 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1308 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1309 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1310 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1311 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R1317 QRL029J-101 OMF RESISTOR 100 Ω 2W J
R1401 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R1403 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1405 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R1406 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1408 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R1410 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1411 QRG01GJ-221 OMF RESISTOR 220 Ω 1W J
R1412 QRE121J-1R0Y C RESISTOR 1
Ω 1/2W J
R1413 QRX01GJ-1R2 MF RESISTOR 1.2 Ω 1W J
R1414 QRE121J-2R2Y C RESISTOR 2.2
Ω 1/2W J
R1415 QRE121J-120Y C RESISTOR 12 Ω 1/2W J
R1416 QRE141J-225Y C RESISTOR 2.2M
Ω 1/4W J
R1425 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R1478 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1479 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1480 QRE121J-681Y C RESISTOR 680 Ω 1/2W J
R1481 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R1482 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1483 NRSA63J-823X MG RESISTOR 82k
Ω 1/16W J
R1484 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R1485 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R1486 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R1487 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1489 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R1490 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1491 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R1492 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R1493 QRE121J-223Y C RESISTOR 22k
Ω 1/2W J
R1494 QRL039J-330 OMF RESISTOR 33 Ω 3W J
R1521 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1522 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1523 QRL039J-151 OMF RESISTOR 150
Ω 3W J
R1524 QRL039J-151 OMF RESISTOR 150 Ω 3W J
R1526 QRL029J-271 OMF RESISTOR 270
Ω 2W J
R1527 QRL039J-103 OMF RESISTOR 10k Ω 3W J
 R1528 QRZ9021-1R0 FUSI RESISTOR 1 Ω 1W J
 R1529 QRZ9021-1R0 FUSI RESISTOR 1 Ω 1W J
R1531 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
 R1532 QRZ9017-4R7 FUSI RESISTOR 4.7 Ω 1/4W J
R1541 QRE121J-124Y C RESISTOR 120k Ω 1/2W J
R1542 QRE121J-124Y C RESISTOR 120k Ω 1/2W J
 Ref No. Part No. Part Name Description Local
R1543 QRE121J-471Y C RESISTOR 470 Ω 1/2W J
R1545 QRE121J-220Y C RESISTOR 22 Ω 1/2W J
R1546 QRE121J-822Y C RESISTOR 8.2k Ω 1/2W J
 R1547 QRZ9011-4R7 FUSI RESISTOR 4.7 Ω 1/2W J
R1561 QRL029J-220 OMF RESISTOR 22 Ω 2W J
R1562 QRE121J-123Y C RESISTOR 12k Ω 1/2W J
R1563 QRZ0056-103Z COMP RESISTOR 10k Ω 1/2W K
R1591 QRA14CF-1202Y CMF RESISTOR 12k
Ω 1/4W F
R1592 QRZ0225-2R2 UNF RESISTOR 2.2
Ω 7W K
R1593 NRSA02F-332X MG RESISTOR 3.3k Ω 1/10W F
R1594 QRE121J-183Y C RESISTOR 18k Ω 1/2W J
R1595 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1621 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1622 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1623 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R1624 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1625 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1626 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1627 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1628 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1629 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1630 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1650 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1651 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1652 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1653 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1654 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1655 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1656 QRE121J-2R2Y C RESISTOR 2.2 Ω 1/2W J
R1657 QRE121J-2R2Y C RESISTOR 2.2 Ω 1/2W J
R1660 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1661 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R1662 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R1663 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1664 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1688 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R1690 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1691 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1695 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R1696 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1701 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1702 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1703 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1704 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1705 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1706 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1707 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1708 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1709 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1710 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1711 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1712 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1713 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1714 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1715 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1716 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1717 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1718 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R1719 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1720 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1721 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1722 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1723 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1724 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1725 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1726 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R1727 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R1728 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1730 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R1731 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1732 NRSA02F-393X MG RESISTOR 39k
Ω 1/10W F
R1733 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R1734 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R1735 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R1736 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1737 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R1738 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1739 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1740 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1741 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1742 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1744 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R1745 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R1746 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R1747 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1748 NRSA02J-225X MG RESISTOR 2.2M
Ω 1/10W J
R1749 NRSA02J-185X MG RESISTOR 1.8M
Ω 1/10W J
R1750 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1755 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
 Ref No. Part No. Part Name Description Local

1-12 (No.52062C)
CRT SOCKET P.W. BOARD ASS'Y (SCH-3601A-H2)
R1756 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1757 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1758 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1790 NRSA63J-270X MG RESISTOR 27 Ω 1/16W J
R1803 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R1804 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1805 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1806 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1807 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1808 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R1809 NRSA63J-391X MG RESISTOR 390 Ω 1/16W J
R1810 NRSA63J-823X MG RESISTOR 82k Ω 1/16W J
R1811 NRSA63J-391X MG RESISTOR 390 Ω 1/16W J
R1812 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1813 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1815 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R1818 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1820 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1821 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1823 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1824 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1826 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1829 NRSA63J-750X MG RESISTOR 75
Ω 1/16W J
R1830 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1831 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1832 NRSA63J-391X MG RESISTOR 390 Ω 1/16W J
R1833 NRSA63J-271X MG RESISTOR 270 Ω 1/16W J
R1834 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1835 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R1836 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R1837 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1838 QRK126J-121X UNF C RESISTOR 120 Ω 1/2W J
R1839 QRE121J-221Y C RESISTOR 220 Ω 1/2W J
R1840 QRE121J-221Y C RESISTOR 220 Ω 1/2W J
R1841 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1842 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R1843 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R1844 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1845 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R1846 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1847 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1848 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R1849 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1880 NRSA63J-202X MG RESISTOR 2k Ω 1/16W J
R1881 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1882 NRSA63J-181X MG RESISTOR 180 Ω 1/16W J
R1883 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1902 QRF154K-2R2 UNF WW RESISTOR 2.2 Ω 15W K
R1903 QRL039J-393 OMF RESISTOR 39k Ω 3W J
R1904 QRE121J-221Y C RESISTOR 220 Ω 1/2W J
R1905 QRM034J-R10 MP RESISTOR 0.1 Ω 3W J
R1906 QRE141J-1R5Y C RESISTOR 1.5 Ω 1/4W J
R1908 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1911 QRE121J-152Y C RESISTOR 1.5k Ω 1/2W J
R1912 QRE121J-123Y C RESISTOR 12k Ω 1/2W J
 R1913 QRZ9017-100 FUSI RESISTOR 10 Ω 1/4W J
R1914 QRL039J-473 OMF RESISTOR 47k Ω 3W J
R1915 NRSA63J-823X MG RESISTOR 82k
Ω 1/16W J
R1916 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R1951 QRE121J-223Y C RESISTOR 22k
Ω 1/2W J
R1952 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1953 QRE121J-152Y C RESISTOR 1.5k Ω 1/2W J
R1954 QRE121J-150Y C RESISTOR 15 Ω 1/2W J
R1955 QRG01GJ-330 OMF RESISTOR 33 Ω 1W J
R1956 QRE121J-120Y C RESISTOR 12
Ω 1/2W J
R1957 QRE121J-5R6Y C RESISTOR 5.6 Ω 1/2W J
R1958 QRL039J-820 OMF RESISTOR 82
Ω 3W J
R1959 QRE121J-820Y C RESISTOR 82
Ω 1/2W J
R1960 NRSA63J-391X MG RESISTOR 390
Ω 1/16W J
R1961 QRL029J-223 OMF RESISTOR 22k
Ω 2W J
R1962 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R1963 QRE121J-332Y C RESISTOR 3.3k
Ω 1/2W J
R1964 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R1965 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R1966 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R1967 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R1968 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R1969 QRT029J-1R5 MF RESISTOR 1.5
Ω 2W J
R1970 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R1971 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R1972 QRE121J-182Y C RESISTOR 1.8k Ω 1/2W J
R1973 QRE121J-332Y C RESISTOR 3.3k
Ω 1/2W J
R1974 QRT029J-1R2 MF RESISTOR 1.2 Ω 2W J
 R1991 QRZ0057-825 C RESISTOR 8.2M Ω 1W J
L1001 QQL244K-8R2Z PEAKING COIL 8.2uH K
L1002 QQL244K-8R2Z PEAKING COIL 8.2uH K
L1101 QQLZ014-R82 COIL 0.82uH 100mA L
L1102 QQL244K-180Z PEAKING COIL 18uH K
 Ref No. Part No. Part Name Description Local
L1301 QQL244K-221Z PEAKING COIL 220uH K
L1401 QQL26AK-220Z CHOKE COIL 22uH K
L1480 QQR1138-001 CHOKE COIL
L1523 QQR1243-001 LINIARITY COIL
L1541 QQL244K-220Z PEAKING COIL 22uH K
L1561 QQLZ028-272 COIL 2.7mH
L1701 QQL244K-100Z PEAKING COIL 10uH K
L1702 QQL244K-100Z PEAKING COIL 10uH K
L1731 QQL244J-101Z PEAKING COIL 100uH J
L1951 QQLZ034-460 HEATER CHOKE 46uH
L1953 QQL244J-5R6Z COIL 5.6uH J
L1954 QQL26AK-820Z CHOKE COIL 82uH K
 T1521 QQR1229-001 DRIVE TRANSF
T1561 QQR1153-001 DAF TRANSF
 T1901 QQS0110-001 SW TRANSF
CF1103 QAX0639-001Z C TRAP 4.500MHz
CF1130 QAX0642-001Z C FILTER 4.500MHz
CF1140 QAX0695-001Z C FILTER 5.500MHz
CF1141 QAX0696-001Z C FILTER 6.000MHz
CF1142 QAX0697-001Z C FILTER 6.500MHz
CN1001 QGF1220C2-25 CONNECTOR FFC/FPC (1-25)
CN100A QGA2501C5-03Z CONNECTOR W-B (1-3)
CN100C QGA2501C5-06Z CONNECTOR W-B (1-6)
CN100D WJQ0003-002A E-SH C WIRE B-B
CN100S QGA2501C5-05Z CONNECTOR W-B (1-5)
CN100T QJK002-063231 SIN CR B-B WIRE
CN100U QGA2501C5-06Z CONNECTOR W-B (1-6)
CN100W QGA7901C1-02 CONNECTOR W-B (1-2)
CN10HV QGZ5004C1-06 CONNECTOR (1-6)
CN1DEG QGZ5004C1-02 CONNECTOR (1-2)
 CP1951 ICP-N75-Y IC PROTECTOR 2.7A
 CP1952 ICP-N38-Y IC PROTECTOR 1.5A
 CP1953 ICP-N38-Y IC PROTECTOR 1.5A
HS1401 LC30416-003A HEAT SINK
HS1480 LC32137-001A HEAT SINK/AL-F/
HS1522 LC31215-001A HEAT SINK/FE-P/
HS1650 GG30059-001A HEAT SINK
HS1901 LC31211-002A HEAT SINK/AL-F/
HS1974 CEHT11B-002QS HEAT SINK
J1801 QNN0349-001 PIN JACK S/V/L/R IN
J1802 QNN0349-002 PIN JACK V/L/R IN
J1803 QNN0348-001 PIN JACK L/R IN
J1804 QNN0349-001 PIN JACK V/L/R OUT
K1705 QQR1214-001Y FERRITE BEADS
K1706 QQR1113-001Z FERRITE BEADS
K1901 QQR1214-001Y FERRITE BEADS
K1902 QQR1214-001Y FERRITE BEADS
K1903 QQR1214-001Y FERRITE BEADS
K1904 QQR1113-001Z FERRITE BEADS
K1905 QQR1113-001Z FERRITE BEADS
K1951 QQR1214-001Y FERRITE BEADS
K1953 QQR1214-001Y FERRITE BEADS
K1954 QQR1214-001Y FERRITE BEADS
K1955 QQR1214-001Y FERRITE BEADS
 LF1901 QQR1356-001 LINE FILTER
 PC1901 PC123F2 PHOTO COUPLER
 RY1901 QSK0061-001 RELAY
SF1101 QAX0325-001 SAW FILTER
SF1102 QAX0731-001 SAW FILTER
 TH1901 QAD0145-2R3 POSISTOR 2.3 Ω
TU1001 QAU0185-005 TUNER
X1701 QAX0737-001 CRYSTAL 12.000MHz
 Ref No. Part No. Part Name Description Local
Q3101 2SC3311A/QR/ TRANSISTOR
Q3102 2SC3311A/QR/ TRANSISTOR
Q3103 2SC3311A/QR/ TRANSISTOR
Q3104 2SC3311A/QR/ TRANSISTOR
Q3105 2SC3311A/QR/ TRANSISTOR
Q3106 2SC3311A/QR/ TRANSISTOR
Q3121 2SC3311A/QR/ TRANSISTOR
Q3122 2SA1309A/QR/ TRANSISTOR
Q3123 2SC4075/DE/YA11 POW TRANSISTOR
Q3124 2SC3311A/QR/ TRANSISTOR
Q3125 2SC4075/DE/YA11 POW TRANSISTOR
Q3126 2SC3311A/QR/ TRANSISTOR
Q3127 2SC4075/DE/YA11 POW TRANSISTOR
Q3128 2SC3311A/QR/ TRANSISTOR
Q3129 2SC3334-T SI TRANSISTOR
Q3130 2SA1321-T SI TRANSISTOR
Q3131 2SC3334-T SI TRANSISTOR
Q3132 2SA1321-T SI TRANSISTOR
 Ref No. Part No. Part Name Description Local

(No.52062C)1-13
Q3133 2SC3334-T SI TRANSISTOR
Q3134 2SA1321-T SI TRANSISTOR
Q3135 2SA1309A/QR/ TRANSISTOR
Q3204 2SC3311A/QR/ TRANSISTOR
Q3205 2SC3311A/QR/ TRANSISTOR
Q3206 2SA1309A/QR/ TRANSISTOR
Q3209 2SA1837 POW TRANSISTOR
Q3210 2SC4793 POW TRANSISTOR
Q3251 2SA1309A/QR/ TRANSISTOR
Q3252 2SC3311A/QR/ TRANSISTOR
Q3253 2SA1309A/QR/ TRANSISTOR
Q3261 2SA1309A/QR/ TRANSISTOR
Q3262 2SA1309A/QR/ TRANSISTOR
Q3263 2SA1309A/QR/ TRANSISTOR
Q3264 2SC3311A/QR/ TRANSISTOR
Q3265 2SC3311A/QR/ TRANSISTOR
Q3266 2SC3311A/QR/ TRANSISTOR
D3107 MA165 SI DIODE
D3108 MA4075/H/ Z DIODE
D3109 MA4051/H/ Z DIODE
D3110 MA165 SI DIODE
D3111 MA4051/H/ Z DIODE
D3112 MA165 SI DIODE
D3113 MA4051/H/ Z DIODE
D3114 MA165 SI DIODE
D3118 1SS244-T2 SI DIODE
D3119 1SS244-T2 SI DIODE
D3120 1SS244-T2 SI DIODE
D3121 1SS244-T2 SI DIODE
D3122 1SS244-T2 SI DIODE
D3123 1SS244-T2 SI DIODE
D3124 1N4003-T2 SI DIODE
D3125 1N4003-T2 SI DIODE
D3126 1N4003-T2 SI DIODE
D3127 MA165 SI DIODE
D3131 MTZJ75-T2 Z DIODE
D3132 MA4043 Z DIODE
D3134 1SS244-T2 SI DIODE
D3136 MA165 SI DIODE
D3138 MA165 SI DIODE
D3141 MTZJ30A-T2 Z DIODE
D3142 MTZJ30A-T2 Z DIODE
D3143 MTZJ30A-T2 Z DIODE
D3201 CH41005-H-05C FORMING BUS WIR
D3202 CH41005-H-05C FORMING BUS WIR
D3203 RGP10J-5025-T3 SI DIODE
D3204 RGP10J-5025-T3 SI DIODE
C3101 QETM1CM-477 E CAPACITOR 470uF 16V M
C3107 QETM2EM-106 E CAPACITOR 10uF 250V M
C3108 QETM2EM-476 E CAPACITOR 47uF 250V M
C3110 QCZ0364-681 C CAPACITOR 680pF 2kV K
C3114 QCS31HJ-151 C CAPACITOR 150pF 50V J
C3115 QETM1CM-476 E CAPACITOR 47uF 16V M
C3116 QCS31HJ-561 C CAPACITOR 560pF 50V J
C3117 QCB31HK-471 C CAPACITOR 470pF 50V K
C3118 QCB31HK-471 C CAPACITOR 470pF 50V K
C3119 QFLB1HJ-104 M CAPACITOR 0.1uF 50V J
C3120 QETM1HM-105 E CAPACITOR 1uF 50V M
C3121 QCB31HK-102 C CAPACITOR 1000pF 50V K
C3204 QCS31HJ-561 C CAPACITOR 560pF 50V J
C3205 QETM1HM-335 E CAPACITOR 3.3uF 50V M
C3206 QETM1HM-106 E CAPACITOR 10uF 50V M
C3207 QCS31HJ-5R0 C CAPACITOR 5pF 50V J
C3209 QETM1CM-107 E CAPACITOR 100uF 16V M
C3211 QCS31HJ-391 C CAPACITOR 390pF 50V J
C3212 QCB32HK-472 C CAPACITOR 4700pF 500V K
C3213 QCS31HJ-561 C CAPACITOR 560pF 50V J
C3214 QETM2CM-106 E CAPACITOR 10uF 160V M
C3215 QCB32HK-472 C CAPACITOR 4700pF 500V K
C3216 QETM2CM-106 E CAPACITOR 10uF 160V M
C3217 QETM1AM-107 E CAPACITOR 100uF 10V M
C3218 QETM1AM-107 E CAPACITOR 100uF 10V M
C3219 QETM1AM-337 E CAPACITOR 330uF 10V M
C3220 QCS32HJ-680 C CAPACITOR 68pF 500V J
C3251 QENB1HM-105 BP E CAPACITOR 1uF 50V M
C3252 QCS31HJ-151 C CAPACITOR 150pF 50V J
C3253 QDC31HJ-560 C CAPACITOR 56pF 50V J
C3255 QFLB1HJ-104 M CAPACITOR 0.1uF 50V J
C3261 QDC31HJ-820 C CAPACITOR 82pF 50V J
C3262 QDC31HJ-820 C CAPACITOR 82pF 50V J
C3263 QDC31HJ-820 C CAPACITOR 82pF 50V J
C3264 QETM1AM-107 E CAPACITOR 100uF 10V M
C3265 QETM1AM-107 E CAPACITOR 100uF 10V M
C3266 QETM1AM-107 E CAPACITOR 100uF 10V M
C3267 QETM1CM-227 E CAPACITOR 220uF 16V M
R3101 QRE142J-682 C RESISTOR 6.8k Ω 1/4W J
 Ref No. Part No. Part Name Description Local
R3102 QRE142J-102 C RESISTOR 1k Ω 1/4W J
R3103 QRE142J-153 C RESISTOR 15k Ω 1/4W J
R3104 QRE142J-682 C RESISTOR 6.8k Ω 1/4W J
R3105 QRE142J-102 C RESISTOR 1k Ω 1/4W J
R3106 QRE142J-272 C RESISTOR 2.7k Ω 1/4W J
R3107 QRE142J-682 C RESISTOR 6.8k Ω 1/4W J
R3108 QRE142J-102 C RESISTOR 1k Ω 1/4W J
R3109 QRE142J-562 C RESISTOR 5.6k
Ω 1/4W J
R3110 QRE142J-101 C RESISTOR 100
Ω 1/4W J
R3111 QRE142J-101 C RESISTOR 100 Ω 1/4W J
R3112 QRE142J-101 C RESISTOR 100 Ω 1/4W J
R3113 QRE142J-563 C RESISTOR 56k Ω 1/4W J
R3120 QRE122J-101 C RESISTOR 100 Ω 1/2W J
R3121 QRE142J-101 C RESISTOR 100 Ω 1/4W J
R3122 QRE142J-101 C RESISTOR 100
Ω 1/4W J
R3123 QRE122J-152 C RESISTOR 1.5k
Ω 1/2W J
R3124 QRE142J-221 C RESISTOR 220 Ω 1/4W J
R3125 QRE142J-101 C RESISTOR 100 Ω 1/4W J
R3126 QRE142J-101 C RESISTOR 100 Ω 1/4W J
R3127 QRE122J-152 C RESISTOR 1.5k Ω 1/2W J
R3128 QRE142J-221 C RESISTOR 220 Ω 1/4W J
R3129 QRE142J-101 C RESISTOR 100 Ω 1/4W J
R3130 QRE142J-101 C RESISTOR 100
Ω 1/4W J
R3131 QRE122J-152 C RESISTOR 1.5k
Ω 1/2W J
R3132 QRE142J-221 C RESISTOR 220 Ω 1/4W J
R3133 QRE142J-470 C RESISTOR 47 Ω 1/4W J
R3136 QRE142J-470 C RESISTOR 47 Ω 1/4W J
R3137 QRE142J-470 C RESISTOR 47 Ω 1/4W J
R3138 QRL029J-223 OMF RESISTOR 22k Ω 2W J
R3139 QRL029J-223 OMF RESISTOR 22k Ω 2W J
R3140 QRZ0111-102 C RESISTOR 1k Ω 1/2W K
R3141 QRL029J-223 OMF RESISTOR 22k Ω 2W J
R3143 QRL029J-223 OMF RESISTOR 22k Ω 2W J
R3144 QRZ0111-102 C RESISTOR 1k Ω 1/2W K
R3145 QRL029J-223 OMF RESISTOR 22k Ω 2W J
R3146 QRL029J-223 OMF RESISTOR 22k Ω 2W J
R3147 QRZ0111-102 C RESISTOR 1k Ω 1/2W K
R3148 QRE122J-124 C RESISTOR 120k Ω 1/2W J
R3149 QRE122J-102 C RESISTOR 1k Ω 1/2W J
R3151 QRE122J-124 C RESISTOR 120k Ω 1/2W J
R3152 QRE122J-102 C RESISTOR 1k Ω 1/2W J
R3153 QRE122J-124 C RESISTOR 120k Ω 1/2W J
R3154 QRE122J-102 C RESISTOR 1k Ω 1/2W J
R3155 QRE122J-474 C RESISTOR 470k Ω 1/2W J
R3157 QRZ0111-474 C RESISTOR 470k Ω 1/2W K
R3159 QRE142J-184 C RESISTOR 180k Ω 1/4W J
R3161 QRE122J-333 C RESISTOR 33k Ω 1/2W J
R3162 CH41005-H-05C FORMING BUS WIR
R3163 CH41005-H-05C FORMING BUS WIR
R3164 QRE122J-560 C RESISTOR 56 Ω 1/2W J
R3166 QRE122J-333 C RESISTOR 33k Ω 1/2W J
R3167 QRE142J-222 C RESISTOR 2.2k Ω 1/4W J
R3168 QRE142J-103 C RESISTOR 10k Ω 1/4W J
R3170 QRE142J-332 C RESISTOR 3.3k Ω 1/4W J
R3171 QRE142J-681 C RESISTOR 680 Ω 1/4W J
R3172 CH41005-H-05C FORMING BUS WIR
R3173 CH41005-H-05C FORMING BUS WIR
R3174 CH41005-H-05C FORMING BUS WIR
R3211 CH41005-H-05C FORMING BUS WIR
R3212 QRE142J-153 C RESISTOR 15k
Ω 1/4W J
R3213 QRE142J-222 C RESISTOR 2.2k Ω 1/4W J
R3214 QRE142J-152 C RESISTOR 1.5k Ω 1/4W J
R3215 QRE142J-680 C RESISTOR 68 Ω 1/4W J
R3216 QRE142J-221 C RESISTOR 220 Ω 1/4W J
 R3217 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R3221 QRE142J-470 C RESISTOR 47 Ω 1/4W J
R3222 QRE142J-470 C RESISTOR 47
Ω 1/4W J
R3224 QRE142J-122 C RESISTOR 1.2k
Ω 1/4W J
R3225 QRE122J-563 C RESISTOR 56k
Ω 1/2W J
R3226 QRE122J-563 C RESISTOR 56k
Ω 1/2W J
R3227 QRE142J-122 C RESISTOR 1.2k
Ω 1/4W J
R3228 QRE142J-390 C RESISTOR 39
Ω 1/4W J
R3229 QRE122J-2R7 C RESISTOR 2.7
Ω 1/2W J
R3230 QRE122J-2R7 C RESISTOR 2.7
Ω 1/2W J
R3231 QRE142J-390 C RESISTOR 39
Ω 1/4W J
R3232 QRE122J-121 C RESISTOR 120
Ω 1/2W J
R3233 QRL029J-391 OMF RESISTOR 390 Ω 2W J
R3251 QCS31HJ-331 C CAPACITOR 330pF 50V J
R3252 QRE142J-222 C RESISTOR 2.2k
Ω 1/4W J
R3253 QRE142J-101 C RESISTOR 100
Ω 1/4W J
R3254 QRE142J-563 C RESISTOR 56k Ω 1/4W J
R3255 QRE142J-223 C RESISTOR 22k
Ω 1/4W J
R3256 QRE142J-681 C RESISTOR 680 Ω 1/4W J
R3257 QRE142J-102 C RESISTOR 1k
Ω 1/4W J
R3258 QRE142J-182 C RESISTOR 1.8k Ω 1/4W J
R3259 QRE142J-102 C RESISTOR 1k
Ω 1/4W J
R3260 QRE142J-271 C RESISTOR 270
Ω 1/4W J
R3261 QRE142J-101 C RESISTOR 100 Ω 1/4W J
R3262 QRE142J-101 C RESISTOR 100 Ω 1/4W J
 Ref No. Part No. Part Name Description Local

(No.52062C)
AV & MULTIMEDIA COMPANY VIDEO DISPLAY CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan
VICTOR COMPANY OF JAPAN, LIMITED
WPC
Printed in Japan
FRONT CONTROL P.W. BOARD ASS'Y (SCH-8602A-H2)
R3263 QRE142J-101 C RESISTOR 100 Ω 1/4W J
R3264 QRE142J-222 C RESISTOR 2.2k Ω 1/4W J
R3265 QRE142J-102 C RESISTOR 1k Ω 1/4W J
R3266 QRE142J-103 C RESISTOR 10k Ω 1/4W J
R3267 QRE142J-102 C RESISTOR 1k Ω 1/4W J
R3268 QRE142J-222 C RESISTOR 2.2k Ω 1/4W J
R3269 QRE142J-102 C RESISTOR 1k Ω 1/4W J
R3270 QRE142J-103 C RESISTOR 10k
Ω 1/4W J
R3271 QRE142J-102 C RESISTOR 1k
Ω 1/4W J
R3272 QRE142J-222 C RESISTOR 2.2k Ω 1/4W J
R3273 QRE142J-102 C RESISTOR 1k Ω 1/4W J
R3274 QRE142J-103 C RESISTOR 10k Ω 1/4W J
R3275 QRE142J-102 C RESISTOR 1k Ω 1/4W J
L3121 QQL244J-5R6Z COIL 5.6uH J
L3122 QQLZ034-220 HEATER CHOKE 22uH
L3123 CH41005-H-05C FORMING BUS WIR
L3124 CH41005-H-05C FORMING BUS WIR
L3125 CH41005-H-05C FORMING BUS WIR
L3251 QQL242K-150 PEAKING COIL 15uH K
CN300T QGA2501C5-06 CONNECTOR W-B (1-6)
CN300U QJK002-063231 SIN CR B-B WIRE
CN30VM QGA2501C1-03 CONNECTOR W-B (1-3)
DL3261 CE41925-001 DELAY LINE
DL3262 CE41925-001 DELAY LINE
DL3263 CE41925-001 DELAY LINE
 FR3201 QRZ9021-561 FUSI RESISTOR 560 Ω 1W J
HS3123 CEHP00N-001QS HEAT SINK
HS3125 CEHP00N-001QS HEAT SINK
HS3127 CEHP00N-001QS HEAT SINK
HS3209 CEHP00N-001QS HEAT SINK
HS3210 CEHP00N-001QS HEAT SINK
K3201 CE41492-001Z CHOKE COIL
K3202 CE41492-001Z CHOKE COIL
K3203 CE41492-001Z CHOKE COIL
K3204 CE41492-001Z CHOKE COIL
K3205 QQR1113-001Z FERRITE BEADS
K3206 QQR1113-001Z FERRITE BEADS
K3207 QQR1113-001Z FERRITE BEADS
K3208 QQR1113-001Z FERRITE BEADS
SG3101 QAF0056-501Z SURGE ABSORBER 500V M
SG3102 QAF0056-501Z SURGE ABSORBER 500V M
SG3104 QAF0056-501Z SURGE ABSORBER 500V M
 SK3001 CE42670-001 CRT SOCKET
 Ref No. Part No. Part Name Description Local
IC8481 LA6515 IC
IC8801 GP1UM281QK IR DETECT UNIT 38kHz
Q8481 2SC2412K/QR/-X TRANSISTOR
Q8801 2SA1037AK/QR/-X TRANSISTOR
D8801 MA111-X SI DIODE
D8802 P1241-04 PHOTO CONDUCTOR
D8803 SLR-342VR-T16 LED POWER
C8481 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C8482 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C8483 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C8484 NCB21EK-224X C CAPACITOR 0.22uF 25V K
 Ref No. Part No. Part Name Description Local
C8485 QETN1EM-476Z E CAPACITOR 47uF 25V M
C8487 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C8660 QETM1VM-108 E CAPACITOR 1000uF 35V M
C8661 QETM1VM-108 E CAPACITOR 1000uF 35V M
C8801 QETN1HM-106Z E CAPACITOR 10uF 50V M
C8802 QETN1CM-107Z E CAPACITOR 100uF 16V M
C8803 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C8815 QETN1CM-107Z E CAPACITOR 100uF 16V M
 C8901 QFZ9072-224 MM CAPACITOR 0.22uF AC250V K
R8482 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R8483 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R8484 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R8485 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R8486 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R8487 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R8488 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R8489 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R8491 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8492 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8495 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R8497 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R8499 QRE121J-561Y C RESISTOR 560
Ω 1/2W J
R8801 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R8802 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R8803 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R8805 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R8807 NRSA63J-181X MG RESISTOR 180 Ω 1/16W J
R8808 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R8809 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R8810 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R8811 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R8812 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R8813 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R8815 QRE121J-271Y C RESISTOR 270 Ω 1/2W J
R8816 QRE121J-271Y C RESISTOR 270 Ω 1/2W J
R8817 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R8818 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R8819 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R8826 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8830 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R8831 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
 R8901 QRZ0111-474 C RESISTOR 470k Ω 1/2W K
L8401 QQL244K-820Z PEAKING COIL 82uH K
CN8001 QGF1220C2-25 CONNECTOR FFC/FPC (1-25)
CN8002 QJL001-123232 SIN CL B-B WIRE
CN8003 QGA2501C5-04Z CONNECTOR W-B (1-4)
CN800A QJB003-035433 SIN ID C-B WIRE
CN800R QGA2501C5-03Z CONNECTOR W-B (1-3)
CN800W CHGH0001-AB-GS CONNECTOR ASSY
CN80PW QGA7901C1-02 CONNECTOR W-B (1-2)
 F8901 QMF51E2-4R0J4 FUSE 4A AC250V
J8302 QNN0279-003 PIN JACK V IN
J8303 QNN0279-002 PIN JACK L/MONO IN
J8304 QNN0279-001 PIN JACK R IN
J8801 QNS0155-001 3.5 JACK HEADPHONE
 LF8901 QQR1356-001 LINE FILTER
S8801 QSW0619-003Z TACT SWITCH CH+
S8802 QSW0619-003Z TACT SWITCH CH-
S8803 QSW0619-003Z TACT SWITCH MENU
S8804 QSW0619-003Z TACT SWITCH TV/VIDEO
S8805 QSW0619-003Z TACT SWITCH VOL+
S8806 QSW0619-003Z TACT SWITCH VOL-
 S8901 QSW0750-001 PUSH SWITCH POWER
 VA8901 QAF0052-621 VARISTOR 620V
 Ref No. Part No. Part Name Description Local

MUTING
OFF
TIMER
ECO
SENSOR
MODE
CHANNEL
SCAN
REVEAL
SUBPAGE CANCEL
TV
TEXT
HOLD
RM-C1023
INDEX
STORE MODE
SIZE
SYSTEM
COLOUR SOUND
MENU
CHANNEL
RETURN+
POWER
DISPLAY
TV/TEXT
TV/VIDEO
VOLUME
123
456
789
0-/--
MUTING
OFF
TIMER
ECO
SENSOR
MODE
CHANNEL
SCAN
REVEAL
SUBPAGE CANCEL
TV
TEXT
HOLD
RM-C1020
INDEX
STORE MODE
SIZE
SYSTEM
COLOUR SOUND
MENU
CHANNEL
RETURN+
POWER
DISPLAY
TV/TEXT
TV/VIDEO
VOLUME
123
456
789
0-/--
I / II
MUTING
OFF
TIMER
ECO
SENSOR
MODE
CHANNEL
SCAN
SYSTEM
COLOUR SOUND
MENU
CHANNEL
RETURN+
POWER
DISPLAY
TV/VIDEO
VOLUME
123
456
789
0-/--
TV
RM-C1024
RM-C1023-1H
[AV-2968TEE]
RM-C1020-1H
[AV-29LS2]
RM-C1024-1H
[AV-29LX2]
[AV-29LX2
/A ]
AV-29LS2
AV-29LX2
AV-29LX2 /A
AV-2968TEE
No. 52062
Sep. 2002
AV-29LS2
AV-29LX2
AV-2968TEE
BASIC CHASSIS
CH
COPYRIGHT © 2002 VICTOR COMPANY OF JAPAN, LTD.
SERVICE MANUAL
COLOUR TELEVISION
CONTENTS
aSPECIFICATIONS ....................................................................................................................................2
aOPERATING INSTRUCTIONS (APPENDIX)
aSAFETY PRECAUTIONS ........................................................................................................................3
aFEATURES ..............................................................................................................................................4
aFUNCTIONS .............................................................................................................................................5
aSPECIFIC SERVICE INSTRUCTIONS ....................................................................................................6
aSERVICE ADJUSTMENTS ....................................................................................................................14
aSTANDARD CIRCUIT DIAGRAM (APPENDIX) .................................................................................. 2-1
aPARTS LIST ...........................................................................................................................................41

2No. 52062
AV-29LS2
AV-29LX2
AV-2968TEE
SPECIFICATIONS
Design & specifications are subject to change without notice.
Dimensions (W ×H ×D) 73.2cm ×58.8cm ×51.8cm
Mass 47kg
TV RF System B, G, I, D, K, K1, M
Colour System TV Mode PAL / SECAM / NTSC3.58 / NTSC4.43
VIDEO Mode PAL / SECAM / NTSC3.58 / NTSC4.43
Stereo system A2 / NICAM (B/G, I, D/K) system Playback only
Teletext system
FLOF(Fastext), Q—Q
WST(World Standard Text)
Receiving Frequency VHF (VL) 46.25MHz – 140.25MHz (AS0 – S6)
VHF (VH) 147.25MHz – 423.25MHz (S7 – S36)
UHF 431.25MHz – 863.25MHz (S37 – CHINA 57)
CATV ●Cable TVs of Mid (X-Z, S1-S10)
Super (S11-S20) & Hyper (S21-S41) bands receivable
Intermediate VIF Carrier 38.0MHz
Frequency 31.5MHz (6.5MHz)
SIF Carrier 32.0MHz (6.0MHz)
32.5MHz (5.5MHz)
33.5MHz (4.5MHz)
Colour Sub Carrier Frequency PAL (4.43MHz), SECAM (4.40625MHz / 4.25MHz)
NTSC (3.58MHz / 4.43MHz)
Aerial Input Terminal 75ØUnbalanced
Power Input AC110 – 240V, 50 / 60Hz
Power Consumption 175W (Max.) / 116W (Avg.)
Picture Tube Visible size : 68cm measured diagonally
High Voltage 32.0kV +1/ – 1.5kV (at cut-off in service mode)
Speaker 5 ×12cm Oval type ×2
Audio Output 7W + 7W
Video / Audio Input (1 / 2 / 3) Video(1,3) : 1Vp-p, 75Ø(RCA pin jack)
Audio(1,2,3) : 500mVrms ( -4dBs ), High Impedance (RCA pin jack)
Component Input ( Input 2 )
Y:1Vp-p positive (negative sync provided, when terminated with 75Ø)
CB/CR:0.7Vp-p 75Ø
Video/Audio Output 1Vp-p, 75Ø(RCA pin jack)
500mVrms(-4dBs)
Low impedance (400Hz when modulated 100%) (RCA pin jack)
Headphone Jack Stereo mini jack (3.5φ)
Remote Control Unit RM-C1020-1H RM-C1024-1H RM-C1023-1H
(Battery size: AA/R06/UM-3 ×2)
Items
AV-2968TEE
Contents
AV-29LS2 AV-29LX2 AV-29LX2/A

No. 52062 3
AV-29LS2
AV-29LX2
AV-2968TEE
SAFETY PRECAUTIONS
1. The design of this product contains special hardware, many circuits
and components specially for safety purposes. For continued pro-
tection, no changes should be made to the original design unless
authorized in writing by the manufacturer. Replacement parts must
be identical to those used in the original circuits. Service should be
performed by qualified personnel only.
2. Alterations of the design or circuitry of the products should not be
made. Any design alterations or additions will void the manufactur-
er's warranty and will further relieve the manufacturer of responsi-
bility for personal injury or property damage resulting therefrom.
3. Many electrical and mechanical parts in the products have special
safety-related characteristics. These characteristics are often not
evident from visual inspection nor can the protection afforded by
them necessarily be obtained by using replacement components
rated for higher voltage, wattage, etc. Replacement parts which have
these special safety characteristics are identified in the parts list of
Service manual. Electrical components having such features are
identified by shading on the schematics and by (!) on the parts
list in Service manual. The use of a substitute replacement which
does not have the same safety characteristics as the recommended
replacement part shown in the parts list of Service manual may
cause shock, fire, or other hazards.
4. Don't short between the LIVE side ground and ISOLATED (NEU-
TRAL) side ground or EARTH side ground when repairing.
Some model's power circuit is partly different in the GND.The differ-
ence of the GND is shown by the LIVE : ( ) side GND, the ISO-
LATED (NEUTRAL) : ( ) side GND and EARTH : ( ) side GND.
Don't short between the LIVE side GND and ISOLATED (NEUTRAL)
side GND or EARTH side GND and never measure the LIVE side
GND and ISOLATED (NEUTRAL) side GND or EARTH side GND
at the same time with a measuring apparatus (oscilloscope etc.).
If above note will not be kept, a fuse or any parts will be broken.
5. If any repair has been made to the chassis, it is recommended that
the B1 setting should be checked or adjusted (See ADJUSTMENT
OF B1 POWER SUPPLY).
6. The high voltage applied to the picture tube must conform with that
specified in Service manual. Excessive high voltage can cause an
increase in X-Ray emission, arcing and possible component dam-
age, therefore operation under excessive high voltage conditions
should be kept to a minimum, or should be prevented. If severe
arcing occurs, remove the AC power immediately and determine
the cause by visual inspection (incorrect installation, cracked or
melted high voltage harness, poor soldering, etc.). To maintain the
proper minimum level of soft X-Ray emission, components in the
high voltage circuitry including the picture tube must be the exact
replacements or alternatives approved by the manufacturer of the
complete product.
7. Do not check high voltage by drawing an arc. Use a high voltage
meter or a high voltage probe with a VTVM. Discharge the picture
tube before attempting meter connection, by connecting a clip lead
to the ground frame and connecting the other end of the lead through
a 10kØ2W resistor to the anode button.
8. When service is required, observe the original lead dress. Extra
precaution should be given to assure correct lead dress in the high
voltage circuit area.Where a short circuit has occurred, those com-
ponents that indicate evidence of overheating should be replaced.
Always use the manufacturer's replacement components.
9. Isolation Check
(Safety for Electrical Shock Hazard)
After re-assembling the product, always perform an isolation check
on the exposed metal parts of the cabinet (antenna terminals, video/
audio input and output terminals, Control knobs, metal cabinet, screw
heads, earphone jack, control shafts, etc.) to be sure the product is
safe to operate without danger of electrical shock.
(1) Dielectric Strength Test
The isolation between the AC primary circuit and all metal parts
exposed to the user, particularly any exposed metal part having a
return path to the chassis should withstand a voltage of 3000V AC
(r.m.s.) for a period of one second.
(. . . .Withstand a voltage of 1100V AC (r.m.s.) to an appliance rated
up to 120V, and 3000V AC (r.m.s.) to an appliance rated 200V or
more, for a period of one second.)
This method of test requires a test equipment not generally found in
the service trade.
(2) Leakage Current Check
Plug the AC line cord directly into the AC outlet (do not use a line
isolation transformer during this check.). Using a "Leakage Current
Tester", measure the leakage current from each exposed metal part
of the cabinet, particularly any exposed metal part having a return
path to the chassis, to a known good earth ground (water pipe, etc.).
Any leakage current must not exceed 0.5mA AC (r.m.s.).
However, in tropical area, this must not exceed 0.2mA AC (r.m.s.).
●Alternate Check Method
Plug the AC line cord directly into the AC outlet (do not use a line
isolation transformer during this check.). Use an AC voltmeter hav-
ing 1000 ohms per volt or more sensitivity in the following manner.
Connect a 1500Ø10W resistor paralleled by a 0.15µF AC-type ca-
pacitor between an exposed metal part and a known good earth
ground (water pipe, etc.). Measure the AC voltage across the resis-
tor with the AC voltmeter. Move the resistor connection to each ex-
posed metal part, particularly any exposed metal part having a re-
turn path to the chassis, and measure the AC voltage across the
resistor. Now, reverse the plug in the AC outlet and repeat each
measurement. Any voltage measured must not exceed 0.75V AC
(r.m.s.). This corresponds to 0.5mA AC (r.m.s.).
However, in tropical area, this must not exceed 0.3V AC (r.m.s.).
This corresponds to 0.2mA AC (r.m.s.).
AC VOLTMETER
(HAVING 1000Ω/V,
OR MORE SENSITIVITY)
PLACE THIS PROBE
ON EACH EXPOSED
METAL PART
1500Ω10W
0.15µF AC-TYPE
GOOD EARTH GROUND

4No. 52062
AV-29LS2
AV-29LX2
AV-2968TEE
FEATURES
sNew chassis design enables use of an interactive on-screen control.
sPure flat CRT produces fine textured picture in every detail.
sWide range voltage (110V ~ 240V) for AC power input.
sWith AUDIO/VIDEO/COMPONENT input terminals.
sI 2C bus control utilizes single chip ICs.
sBy means of AUTO PROGRAM, the TV stations can be selected
automatically and the TV channels can also be rearranged auto-
matically.
sBuilt-in DIGITAL ECO MODE (ECONOMY, ECOLOGY).
In accordance with the brightness in a room, the brightness and/or
contrast of the picture can be adjusted automatically to make the
optimum picture which is easy on the eye.
sBuilt-in OFF TIMER & RETURN +.
MAIN DIFFERENCE LIST
!MODEL No. AV-29LS2 AV-29LX2 AV-29LX2/A AV-2968TEE
Part Name
!MAIN PWB SCH-1108A-H2 SCH-1095A-H2 SCH-1104A-H2
FRONT CABINET ASS’Y LC11193-020A-H LC11193-018A-H LC11193-021A-H
REMOTE CONTROL UNIT RM-C1020-1H RM-C1024-1H RM-C1023-1H

No. 52062 5
AV-29LS2
AV-29LX2
AV-2968TEE
FUNCTIONS
aREAR PANEL
aFRONT PANEL
aREMOTE CONTROL UNIT
RM-C1020-1H
[AV-29LS2]
L/MONOVR
IN (VIDEO-3)
VIDEO-1
INPUT OUTPUT
COMPONENT
(VIDEO-2)
INPUT
V
R
MONO
L
/
V
Y
/
V
R
L
R
MONO
L
/
C B
C R
MUTING
OFF
TIMER
ECO
SENSOR
MODE
CHANNEL
SCAN
REVEAL
SUBPAGE CANCEL
TV
TEXT
HOLD
RM-C1023
INDEX
STORE MODE
SIZE
SYSTEM
COLOUR SOUND
MENU
CHANNEL
RETURN+
POWER
DISPLAY
TV/TEXT
TV/VIDEO
VOLUME
123
456
789
0-/--
MUTING
OFF
TIMER
ECO
SENSOR
MODE
CHANNEL
SCAN
REVEAL
SUBPAGE CANCEL
TV
TEXT
HOLD
RM-C1020
INDEX
STORE MODE
SIZE
SYSTEM
COLOUR SOUND
MENU
CHANNEL
RETURN+
POWER
DISPLAY
TV/TEXT
TV/VIDEO
VOLUME
123
456
789
0-/--
I / II
MUTING
OFF
TIMER
ECO
SENSOR
MODE
CHANNEL
SCAN
SYSTEM
COLOUR SOUND
MENU
CHANNEL
RETURN+
POWER
DISPLAY
TV/VIDEO
VOLUME
123
456
789
0-/--
TV
RM-C1024
RM-C1024-1H
[AV-29LX2]
[AV-29LX2/A]
RM-C1023-1H
[AV-2968TEE]

6No. 52062
AV-29LS2
AV-29LX2
AV-2968TEE
DISASSEMBLY PROCEDURE
REMOVING THE REAR COVER
1. Unplug the power supply cord.
2. Remove the 16 screws marked Åas shown in Fig.1.
3. Withdraw the Rear cover toward you.
[CAUTION]
•When reinstalling the rear cover, carefully push it inward after in-
serting the Main PWB into the rear cover groove.
REMOVING THE CHASSIS (CHASSIS BASE AND
CONTROL BASE)
•After removing the rear cover.
1. Slightly raise the both sides of the chassis by hand and remove the
2 claws marked ıunder the chassis from the front cabinet as shown
in Fig.1.
2. Withdraw the chassis backward.
(If necessary, take off the wire clamp, connector’s etc.)
*When conducting a check with power supplied, be sure to confirm
that the CRT earth wire is connected to the CRT SOCKET PWB
and the Main PWB.
REMOVING THE AV TERMINAL BOARD
•After removing the rear cover.
1. Remove the 4 screws marked Ças shown in Fig.1.
2. When you pull out the AV Terminal board in the direction of arrow
marked Îas shown in Fig.1, it can be removed.
REMOVING THE CONTROL BASE
•After removing the rear cover and the chassis.
1. While pushing down the 2 claws marked ´as shown in Fig. 2 and
pull out the Control base in the direction of arrow marked Ïas
shown in Fig. 2, the control base can be removed.
(If necessary, take off the wire, connector’s etc.)
REMOVING THE SPEAKER
•After removing the rear cover.
1. Remove the 4 screws marked ˝and 2 screws marked Óas shown
in Fig.1.
2. Withdraw the speaker backward.
3. Follow the same steps when removing the other hand speaker.
SPECIFIC SERVICE INSTRUCTIONS
CHECKING THE MAIN PW BOARD
1. To check the back side of the Main PWB.
1) Pull out the chassis. (Refer to REMOVING THE CHASSIS).
2) Erect the chassis vertically so that you can easily check the back
side of the Main PWB.
[CAUTION]
•When erecting the chassis, be careful so that there will be no con-
tacting with other PW Board.
•Before turning on power, make sure that the CRT earth wire and
other connectors are properly connected.
•When repairing, connect the Deg. coil to the DEG. connector on the
Main PWB.
WIRE CLAMPING AND CABLE TYING
1. Be sure to clamp the wire.
2. Never remove the cable tie used for tying the wires together.
Should it be inadvertently removed, be sure to tie the wires with a
new cable tie.
