Model 7251 XD
LED Work Light Instruction Sheet
J.W. Speaker Corporation • Germantown, WI U.S.A. • www.jwspeaker.com • [email protected] • 262.251.6660 6544110aRev: 05/27/2015
INSTRUCTION INFORMATION
Tools Needed Screwdriver
Estimated Time 15 minutes
Wire Functions Black = Ground
Red = Power
In the Box (x1) Model 7251 XD
For a complete list of product
specifications, scan the QR code to
the right, or visit www.jwspeaker.com
and search “Model 7251 XD.”
Product SpecificationsApproval Logos
Input Voltage
Operating Voltage
12-24V DC
10-32V DC
Hardware Required (x4) #8 Screws
(Not Included; See reverse for diagram)
CONTINUED ON NEXT PAGE
Installation Guidelines
• Abuse, neglect and/or accidents
• Modifications and/or alterations
• Improper installation and/or use
• Chemicals and/or cleaners
• Voltage transients and/or spikes
Please refer to the warranty statement for full details.
IMPORTANT NOTE:
The warranty on this product does not cover claims resulting from:
INSTALLATION:
1. Turn off the equipment and disconnect the power supply.
2. Ensure that the light is mounted to/on a FLAT, SOLID surface of
the same (or larger) size as the bracket or light. This will prevent
warping or distortion that can cause cracking or damage to the light
and/or bracket.
3. Carefully connect the wires using the “Wire Functions” and
“Voltage” information above to power the light.
4. All connections should be adequately protected against
moisture. Shrink tubing is recommended.
5. Lay and secure wiring/connectors to avoid any pulling or
abrasion that may damage the wires.
6. Frequently check the light to make sure that it is working
properly and is securely attached.
Complete warranty information is available at www.jwspeaker.com/warranty.
BEFORE INSTALLATION:
1. Read all safety notes and mounting guidelines before installing
the product. Verify that all parts listed under “In the Box” are
present and complete.
2. Inspect the product for damage. DO NOT install the product if
there is any damage. Contact the distributor where you purchased
it to initiate a warranty claim if there is damage.
3. Verify that all power supply and/or charging systems comply to
the specified voltage limits for the light .

5.15"
130.9mm
3.40"
86.4mm
4.55"
115.5mm
6.61"
168.0mm
Ø 0.22"
5.54mm
