MODEL:JYX-66BT
USER MANUAL
A/0

Dear users:
Thanks for your purchasing.Please read the directions carefully before
using and follow the correct instructions.
Matters needing attention：
To ensure safety, please read carefully and follow the following safety
instructions：
1.The equipment is up to The China Compulsory Certification.
2.The equipment should be used in a dry environment.
3.Do not place a fire source near the equipment.
4.Do not use near water source to avoid corrosion of products and
accessories.
5.Do not open or disassemble or repair the battery module by
yourself.There will be a risk of explosion if the battery is not replaced
properly.Do not put the battery into water, fire or any overheated
environment.
6.When taking an airplane, please follow the relevant regulations and
regulations of the airline company to turn off this product before the
airplane takes off to avoid any hidden danger.
7.The charging cable cannot be squeezed, pulled, bent, knotted, or
suspended from heavy objects in order to avoid damage to the insulation
layer of it and cause electric shock.
Introduction....................................................................1
Product functions.........................................................2-4
Remote control............................................................ 5-6
Wireless microphone.......................................................7
Technical Indicators........................................................8
Packing list....................................................................8
FQA..............................................................................9
Catalogue
We provide phone support from 9AM to 6AM, if you
have any questions, please call our customer service
hotline: [phone]

Operation Guide
1.Master: Main volume control knob
2.Number Key: Press to switch to the program with the corresponding
serial number
3.Previous: Short press to switch to the last program; long press to fast
backward.
4.Reverb: Adjust reverb.
5.Play/Pause: Short press to play/pause; In radio mode,long press for
automatic radio station search; In bluetooth mode,long press for
TWS(only valid for the same model)
6.Next: Short press to switch to the next program; long press to fast
forward.
7.Bass: Adjust bass sound.
8.REC: Long press to record audio,during this process, short press to
stop recording.When there is a recording file in the storage device,short
press is to play the recording file.(The recording function is only
available when a storage device is pluged in)
9.Mode: short press to switch between bluetooth,flash card,TF card and
FM radio.When bluetooth has already connected,long press to
disconnect.
10.Treble: Adjust treble sound
11.MIC VOL: Adjust microphone volume
12.MIC Priority:When use microphone while playing audio, press this
button to reduce the sound of the background audio
13.Dynamic Microphone jack(6.35mm)
14.Condenser Microphone jack(3.55mm)
15.AUX IN Jack
16.TF Card Port
17.USB Port
18.Charging Indicator Light
19.5V Charging Port
20.Power
21.Sound Receiver Hole
11
12
13
14
1516
1
2345678 9 10
17
18
19
20
21
MASTE R
5V 1A
USB
01 2 3 4
6 7 8 9
5
MIC.V OL ECHO BASS
OFF
ON
POWER
PREV PLAY/PAUSE NEX T REC MODE
TREB LE
TF Card AUX IN MIC 1MIC 2Priori ty M IC

Bluetooth Connection
1.Turn on bluetooth on your mobile device.
2.Press “Mode” key and switch the speaker to BT mode.
3.Select “JYX-66BT” from available devices.(If JYX-66BT is
unavailable,please switch back to Bluetooth mode and try again )
AUX- IN
Transmit audio without Bluetooth by plug 3.5mm audio cable into AUX IN
jack,the speaker will play the audio from input device automatically.
USB and TF Input
When insert USB or TF card into speaker,the speaker will play the audio
from USB/TF card automatically.
FM Radio
1.Pull out the antenna on the top of speaker.
2.Press “Mode” key to switch to radio station.
3.Long press “Play/Pause” key to search and save more available
stations automatically.
4.The station searching completed when it no longer switch automatically.
5.Press “Next” or “Previous” to select your own station.
REC
1.Plug in a TF card or flash card
2.Long press “REC” to start recording,short press to end recording.
3.Short press “REC” again to play the recording audio.
TWS Function
To use this feature,two JYX-66BT systems are required.
1.Turn on the two JYX-66BT and turn them both into Bluetooth mode.Two
machines will flash “BLUE” on screen.
2.Long press the “PLAY/PAUSE” button of either of the two
machines(Only need to press one button),the other machine will make a
prompt tone and stop flashing. TWS function will be activated by then.
3.Connect your device with the speaker and play music.
4.Long press “PLAY/PAUSE” button again to inactivate TWS function.
If you're still wondering about these steps, please contact customer
service team for a video tutorial:[e-mail]
Remote control

26 9. 50
CH 1 6 8 Display
Push up to turn on,
Push down to turn off .
Battery compartment
Microphone Pickup
Directions of Remote Control
1.Silent:press to Silent ON,press again to Silent OFF.
2.Mode:Press to switch the system between USB,TF card,Radio
station,AUX IN and Bluetooth modes.
3.BT:Press to switch to Bluetooth mode in any working state.
4.Play/Pause:When in USB/TF card mode,short press to play/pause the
program,long press to repeat.When FM works,short press to silent
ON,long press is for searching radio stations.
5.Next.
6.REC
7.Digital keys:Press to play the program with the corresponding serial
number.
8.Repeat:Press for single loop and list loop.
9.Vol+
10.PREV.
11.Vol-
12.REC Play:Press to play the recording file.
Instructions for Microphone Operation
(Notes:The microphone included in the package will be automatically
connected to the speaker system when it’s turned on without additional
operation)
Wireless microphone

Product Parameters
Model：JYX-65BT
Speaker size: 6.5 inch bass + 2 inch treble
RMS: 15W
Input voltage: 5V
Package includes
Speaker system.................................................................... 1PC
Wireless microphone.............................................................2PC
Charging cable......................................................................1PC
User manual..........................................................................1PC
Remote control......................................................................1PC
3.55mm audio cable...............................................................1PC
Adjustable shoulder strap.......................................................1PC
FAQ
Q:The system can not start up.
A:Charging the built-in battery;
Check if the adapter is connected securely.
Q:The system provides no sound.
A:Check if the system is power on.
Adjust the volume.
Q:The Bluetooth connection is not available.
A:Move your device closer to the system.
Check to see if the Bluetooth is engaged.
Q:Unable to connect two system with TWS feature.
A:Make sure the two systems are within one meter of each other.
Q:Reset the system.
A:If the system does not respond to any operations,long press “Power”
key for 8 seconds to reset the system.
(Notes:If necessary,contact after-sales team)
Contact Information
SHENZHEN CITY JIAYUXIANG ACOUSTICS ELECTRONIC CO.,LTD.
JIA YU XIANG(HK)INTERNATIONAL ELECTRONICS CO.,LIMITED
Factor address:NO.7th Building,Houhaixufa Industrial Zone,
Loucun,Gongming town,Guangming District,Shenzhen,China
TEL:+(86)-0755-23410725 FAX:+(86)-0755-27508507
Website:www.szjyx.com.cn E-mail:[e-mail]
