Kärcher HDS 3.0/20 C Ea User manual

Register
your product
www.kaercher.com/welcome
HDS 3.0/20 C Ea
59681220 12/18
English 6
Français 16
Español 28

1
4
2
3
30 1322928
25
26
24
5
19
15
17
11 12
20
18
21
22
31
13
4
4
23
6
7
9 8
10 14
16
27
2

MIN
MAX
35 36
33 34
37
38
40
41
39
42
44
43
3

2
3
4
5
6
7
8
A
45
687
12
3
1.
1.
2.
2.
2.
1.
1.
2.3.
2.
2.
2.
4.5.
6.
4

9
10
8.
9.
7.
5

몇WARNING
When using this product basic precautions
should always be followed, including the
following:
1 Read all the instructions before using
the product.
2 High pressure jets can be dangerous if
misused. The jet must not be directed at
persons, animals, electrical devices, or
the unit itself.
3 To reduce the risk of injury, close super-
vision is necessary when a product is
used near children.
4 Know how to stop the product and
bleed pressures quickly. Be thoroughly
familiar with the controls.
5 Stay alert – watch what you are doing.
6 Wear safety goggles.
7 Do not use acids, alkaline, solvents, or
any flammable material in this product.
These products can cause physical in-
juries to the operator and irreversible
damage to the machine.
8 Do not operate the product when fa-
tigued or under the influence of alcohol
or drugs.
9 Do not overreach or stand on unstable
support. Keep good footing and bal-
ance at all times.
10 To reduce the risk of electrocution,
keep all connections dry and off the
ground. Do not touch plug with wet
hands.
11 The Trigger Gun Safety Lock prevents
the trigger from accidentally being en-
gaged. This safety feature DOES NOT
lock trigger in the ON position.
12 Keep operating area clear of all per-
sons.
13 Close cover before operating the ma-
chine.
14 This appliance is intended for commer-
cial use.
15 Follow the maintenance instructions
specified in the manual.
16 This machine has been designed for
use with cleaning chemicals supplied or
recommended by the manufacturer.
The use of other cleaning chemicals
may affect the operation of the machine
and void the warranty.
17 This product is provided with a Ground
Fault Circuit Interrupter built into the
power cord plug. If replacement of the
plug or cord is needed, use only identi-
cal replacement parts.
18 Do not use extension cord with this
product.
–Injection hazard: equipment can cause
serious injury if the spray penetrates the
skin. Do not point the gun at anyone or
any part of the body. In case of penetra-
tion seek medical aid immediately.
–This system is capable of producing
2000 psi/13.7 MPa.
To avoid rupture and injury, do not op-
erate this pump with components rated
less than 2000 psi/13.7 MPa working
pressure (including but not limited to
spray guns, hose and hose connec-
tions).
–Before servicing, cleaning, or removal
of any part, shut off power and relieve
pressure.
–Do not spray electrical apparatus and
wiring.
–High Pressure. Keep clear of nozzle.
–If connection is made to a potable water
system, the system shall be protected
against backflow.
IMPORTANT SAFETY INSTRUCTIONS
6 EN

–The owner and/or user must have an
understanding of the manufacturer’s
operating instructions and warnings be-
fore using this pressure washer.
–Warning information should be empha-
sized and understood.
–If the operator is not fluent in English,
the manufacturer’s instructions and
warnings shall be read to and dis-
cussed with the operator in the opera-
tor’s native language by the purchaser/
owner, making sure that the operator
comprehends its contents.
–Owner and/or user must study and
maintain for future reference the manu-
facturers’ instructions.
This product must be grounded. If it should
malfunction or breakdown, grounding pro-
vides a path of least resistance for electric
current to reduce the risk of electric shock.
This product is equipped with a cord having
an equipment-grounding conductor and a
grounding plug. The plug must be plugged
into an appropriate outlet that is properly in-
stalled and grounded in accordance with all
local codes and ordinances.
DANGER
Improper connection of the equipment-
grounding conductor can result in a risk of
electrocution. Check with a qualified electri-
cian or service personnel if you are in doubt
as to whether the outlet is properly ground-
ed. Do not modify the plug provided with
the product - if it will not fit the outlet, have
a proper outlet installed by a qualified elec-
trician. Do not use any type of adapter with
this product.
This product is supplied with a Ground
Fault Circuit Interrupter (GFCI) built into the
power cord plug. This device provides addi-
tional protection from the risk of electric
shock. If power is interrupted in the line, the
GFCI will automatically re-close the circuit
to the load after power is restored. Depend-
ing on the GFCI model, it may be neces-
sary to manually operate the reset button to
restore power to the GFCI load circuit. If re-
placement of the plug or cord is needed use
identical replacement parts.
몇CAUTION
When connecting the water inlet to the wa-
ter supply mains, local regulations of your
water company must be observed. In some
areas the unit must not be connected di-
rectly to the public drinking water supply.
This is to ensure that there is no feedback
of chemicals into the water supply. Direct
connection via a receiver tank or backflow
preventer, for example, is permitted.
Dirt in the feed water will damage the unit.
To avoid this risk, we recommend fitting a
water filter.
–Garden hose must be at least 3/4 inch
in diameter.
–Flow rate of water supply must not fall
below 4.0 GPM (gallons per minute).
–Flow rate can be determined by running
the water for one minute into an empty
5-gallon container.
–The water supply temperature must not
exceed 86°F/30°C.
–Never use the pressure washer to draw
in water contaminated with solvents,
e.g. paint thinners, gasoline, oil, etc.
–Always prevent debris from being
drawn into the unit by using a clean wa-
ter source. Use additional water filter.
SAVE THESE INSTRUCTIONS!
Owner/User Responsibility
GROUNDING INSTRUCTIONS
GROUND FAULT CIRCUIT
INTERRUPTER PROTECTION
WATER SUPPLY
7EN

– 1
Please read and comply with these origi-
nal instructions prior to the initial opera-
tion of your appliance and store them for
later use or subsequent owners.
– Before first start-up it is definitely necessary to read
the operating instructions and safety indications Nr.
5.951-949.0!
– In case of transport damage inform vendor immedi-
ately.
– Check the contents of the pack before unpacking.
For scope of delivery see illustration 1.
– At operating elevations of approx. 800 m above
sea level or higher, please contact your dealer to
have the burner setting adjusted to the elevation
and reduced oxygen content.
Electrical and electronic devices often contain compo-
nents which could potentially pose a danger to human
health and the environment if handled or disposed of in-
correctly. However, these components are necessary
for the proper operation of the device. Devices marked
with this symbol must not be disposed of with regular
household rubbish.
Notes about the ingredients (REACH)
You will find current information about the ingredients
at:
www.kaercher.com/REACH
DANGER
Pointer to immediate danger, which leads to severe in-
juries or death.
몇WARNING
Pointer to a possibly dangerous situation, which can
lead to severe injuries or death.
몇CAUTION
Pointer to a possibly dangerous situation, which can
lead to minor injuries.
ATTENTION
Pointer to a possibly dangerous situation, which can
lead to property damage.
Figure 1
1 Support for spray lance
2 Manometer
3 Recess for detergent suction hose
4 Recessed grip (both sides)
5 Connection for water supply with filter
6 Water connection adapter
7 High-pressure connection EASY!Lock
8 High pressure hose EASY!Lock
9 Spray lance EASY!Lock
10 High-pressure nozzle (stainless steel)
11 Pouring vent for detergent
12 Steering roller with fixed position brake
13 Fuel sieve
14 Safety lever
15 Power supply
16 Trigger
17 Tool bag
18 Safety latch of the hand spray gun
19 Trigger gun EASY!Force
20 Pouring vent for fuel
21 Dosage valve for detergent
22 Operating field
23 Storage for hand spray gun
24 Step depression
25 Handle
26 Nameplate
27 Cover lock
28 Storage compartment for accessories
29 Burner
30 Recess for spray pipe
31 Cover
32 Fill opening for system care RM 110
33 Pressure/quantity regulation of the pump unit
34 Oil tank
35 Oil drain screw
36 Backflow valve of the detergent infeed
37 Detergent suction hose with filter
38 Fuel filter
39 Fastening clamp
40 Hose (soft damping system) of the water shortage
safeguard
41 Water shortage safeguard
42 Sieve in the water shortage safeguard
43 Fine filter (water)
44 Float tank
Contents
Environmental protection EN 1
Danger or hazard levels EN 1
Overview EN 1
Symbols on the machine EN 2
Proper use EN 2
Safety instructions EN 2
Safety Devices EN 2
Start up EN 3
GFCI INSTRUCTIONS EN 4
Operation EN 4
Storage EN 5
Transport EN 6
Care and maintenance EN 6
Troubleshooting EN 6
Warranty EN 7
Accessories and Spare Parts EN 7
Technical specifications EN 8
Environmental protection
The packaging material can be recycled.
Please do not throw the packaging mate-
rial into household waste; please send it
for recycling.
Old appliances contain valuable materi-
als that can be recycled; these should be
sent for recycling. Batteries, oil, and sim-
ilar substances must not enter the envi-
ronment. Please dispose of your old ap-
pliances using appropriate collection sys-
tems.
Please do not release engine oil, fuel oil, diesel and
petrol into the environment Protect the ground and dis-
pose of used oil in an environmentally-clean manner.
Danger or hazard levels
Overview
Device elements
8 EN

– 2
Figure 2
A Power switch
1 Operating mode: Cold water operation
2 Operating mode: Hot water operation (e = Eco
mode, hot water max. 140 °F/60 °C)
3 Operating mode: Stream operation
4 “Ready for use” indicator lamp
5 Fuel indicator lamp
6 Indicator lamp service
7 Indicator lamp for detergent
8 Indicator lamp system care
– The operating elements for the cleaning process
are yellow.
– The controls for the maintenance and service are
light gray.
High-pressure jets can be dangerous if im-
properly used. The jet may not be directed
at persons, animals, live electrical equip-
ment or at the appliance itself.
Cleaning of: Machines, Vehicles, Structures, Tools, Fa-
cades, Terraces, Gardening tools, etc.
DANGER
Risk of injury! Follow the respective safety regulations
when operating at gas stations or other dangerous are-
as.
Quality requirements for water:
ATTENTION
Only clean water may be used as high pressure medi-
um. Impurities will lead to increased wear and tear or
formation of deposits in the appliance and accessories.
If recycled water is used, the following limit values must
not be exceeded.
–Please follow the national rules and regulations for
fluid spray jets of the respective country.
–Please follow the national rules and regulations for
accident prevention of the respective country. Fluid
spray jets must be tested regularly and the results
of these tests must be documented in writing.
–The heating appliance of the machine is an ignition
plant. All national laws and regulations about heat-
ing systems must also be followed.
–As per the applicable national guidelines, the first
time this high-pressure cleaner must be taken into
operation by a skilled person. KÄRCHER has al-
ready performed this initial start-up for you and has
documented it accordingly. The documentation can
be requested at your KÄRCHER partner. Please
have the part and plant number of the appliance
available when enquiring about the documentation.
–We would like to point out that the appliance must
be repeatedly checked by a skilled person as pre-
scribed by the applicable national regulations.
Please contact your KÄRCHER partner.
–The appliance/accessories must not be modified.
Safety devices serve for the protection of the user and
must not be put out of operation or bypassed with re-
spect to their function.
Operating field
0/OFF = Off
Colour coding
Symbols on the machine
Risk of electric shock!
Only electricians or authorised techni-
cians are permitted to work on parts of
the plant.
Risk of burns on account of hot surfaces!
Risk of poisoning! Do not inhale exhaust
fumes.
Proper use
Please do not let mineral oil contaminated waste water
reach soil, water or the sewage system. Perform en-
gine cleaning and bottom cleaning therefore only on
specified places with an oil trap.
pH value 6,5...9,5
electrical conductivity * Conductivity fresh
water +1200 µS/
cm
settleable solids ** < 0,5 mg/l
total suspended solids *** < 50 mg/l
Hydrocarbons < 20 mg/l
Chloride < 300 mg/l
Sulphate < 240 mg/l
Calcium < 200 mg/l
Total hardness < 28 °dH
< 50 °TH
< 500 ppm (mg
CaCO3/l)
Iron < 0,5 mg/l
Manganese < 0,05 mg/l
Copper < 2 mg/l
Active chloride < 0,3 mg/l
free of bad odours
* Maximum total 2000 µS/cm
** Test volume 1 l, settling time 30 min
*** no abrasive substances
Safety instructions
PROPOSITION 65
WARNING
The burner exhaust from this product contains chemi-
cals known to the State of California to cause cancer,
birth defects or other reproductive harm.
Safety Devices
9EN

– 3
– While reducing the water supply at the pump head
or with the Servopress - regulation the overflow
valve opens and part of the water flows back to the
pump suck side.
– If the hand-spray gun is closed, so that the whole
water flows back to the pump suck side, the pres-
sure switch at the overflow valve shuts down the
pump.
– If the hand spray gun is opened, the pressure
switch on the cylinder head turns the pump back
on.
The overflow valve is set by the manufacturer and
sealed. Setting only by customer service.
– The safety valve opens, when the overflow valve
resp. the pressure switch is broken.
The safety valve is set by the manufacturer and sealed.
Setting only by customer service.
– The water shortage safeguard prevents the burner
to be turned on when there is water shortage.
– A sieve prevents the contamination of the safe-
guard and must be cleaned regular.
– The temperature stop switches off the machine
when the waste gases have reached very high tem-
peratures.
몇WARNING
Risk of injury! Appliance, accessories, supply lines and
connections must be in fault-free condition. If they are
not in a perfect state then the appliance must not be
used.
Lock parking brake.
Figure 3
Screw tightening torque: 6.5-7.0 Nm
Figure 4
Hook the tool bag onto the top tabs on the appli-
ance.
Tilt the tool bag down and lock it into place.
Fasten the tool bag with 2 screws (torque: 6.5 -
7.0 Nm).
Note: The EASY!Lock system joins components with a
quick-fasten thread solidly and securely with just one
turn.
Figure 5
Join the spray lance with the trigger gun and tighten
until hand-tight (EASY!Lock).
Insert the high pressure nozzle onto the spray
lance.
Install union nut and hand-tighten it (EASY!Lock).
Join the high-pressure hose with trigger gun and
high-pressure connection of the appliance and
tighten until hand-tight (EASY!Lock).
– The system care prevents the calcification of the
heating spiral while operating with calciferous tap
water. It is dosed into the supply in the float con-
tainer drop by drop.
– The metering is set to medium water rigidity by the
manufacturer
Note: A sample bundle of system care is included.
Refill system care.
DANGER
Danger of explosion! Only refill diesel oil or light fuel oil.
Inappropriate fuels, e.g. petrol, must not be used.
ATTENTION
Risk of damage! Never operate device with an empty
fuel tank. The fuel pump will otherwise be destroyed.
Refill fuel.
Close tank lock.
Wipe off spilled fuel.
DANGER
Risk of injury!
– Use Kärcher products only.
– Under no circumstances fill solvents (petrol, ace-
ton, diluting agent etc.)
– Avoid eye and skin contact.
– Observe safety and handling instructions by the de-
tergent manufacturer.
Kärcher offers an individual cleaning and care ap-
pliances program.
Your dealer will consult you gladly.
Refill detergent.
For connection values refer to technical specifications.
Connect the supply hose (minimum length 24.6 ft/
7.5 m, minimum diameter 3/4“) to the water con-
nection of the unit and to the water inlet (e.g. tap)
using the water connection adapter.
Note: The supply hose is not included in the scope of
delivery.
If you want to suck in water from an external vessel, the
following modification is necessary:
Figure 6
Remove the two screws on the burner casing.
Figure 7
Unscrew the back wall and remove it.
Figure 8
Remove water connection from the fine filter.
Unscrew the fine filter from the pump head.
Remove the system care reservoir.
Figure 9
Unscrew the top supply hose to the swimmer con-
tainer.
Connect the top supply hose at pump head.
Replug the rinse line of the detergent dosing valve
to blind plugs.
Connect suction hose (minimum diameter 3/4“)
with filter (accessory) to the water connection point.
– Max. suck height: 1.6 ft (0.5 m)
Until the pump sucked in water, you should:
Overflow valve with two pressure switches
Safety valve
Water shortage safeguard
Temperature stop for exhaust gases
Start up
Installing the handle
Install the tool bag
Install the hand-spray gun, the jet pipe, the
nozzle and the high pressure hose
Refill system care
Refill fuel
Refill detergent
Water connection
Suck in water from vessel
10 EN

– 4
Set the pressure/quantity regulation at the pump
unit to maximum quantity.
Close the dosing valve for the detergent.
DANGER
Risk of personal injury or damage! Never suck in water
from a drinking water container. Never suck in liquids
which contain solvents like lacquer thinner, petrol, oil or
unfiltered water. The sealings within the device are not
solvent resistant. The spray mist of solvents is highly in-
flammable, explosive and poisonous.
Assembly in reverse order.
Note: Ensure that the solenoid valve cable on the res-
ervoir of the system care is not pinched.
– For connection values, see technical data and type
plate.
– The electrical connections must be done by an
electrician according to NEC and local codes.
STEP 1: Plug the Ground Fault Circuit Interrupter
(GFCI) into a working outlet.
STEP 2: Press ’’TEST’’, then press ’’RESET’’ to as-
sure proper connection to power.
Note: The actual appearance of the GFCI may be
different from this illustration.
DANGER
Danger of explosion! Do not spray flammable liquids.
DANGER
Risk of injury! Never use the appliance without the spray
lance attached. Check and ensure proper fitting of the
spray lance prior to each use. The screw connection of
the spray lance must be finger-tight.
DANGER
Risk of injury! Hold the hand spray gun and the spray
pipe firmly with both hands.
DANGER
Risk of injury! The trigger and safety lever may not be
locked during the operation.
DANGER
Risk of injury! Contact Customer Service if the safety le-
ver is damaged.
ATTENTION
Risk of damage! Never operate device with an empty
fuel tank. The fuel pump will otherwise be destroyed.
To open the trigger gun: Actuate the safety lever
and trigger.
To close the hand spray gun: Release the safety le-
ver and trigger.
DANGER
Risk of injury! Switch the appliance off prior to replacing
nozzle and activate hand spray gun until device is pres-
sureless.
Secure the trigger gun. To do so, push the safety
catch towards the front.
Replacing the nozzle.
Set appliance switch to desired operating mode.
Indicator lamp for operational readiness lights up.
The device starts briefly and turns off, as soon as the
working pressure is reached.
Release the trigger gun. To do so, push the safety
catch towards the back.
When activating the hand spray gun the device switch-
es back on.
Note: If no water comes out of the high pressure nozzle,
vent pump. Refer to "Help with malfunctions - appliance
is not building up pressure".
Set device switch to desired temperature.
86°F/30°C to 208°F/98°C:
– Clean with hot water.
212 °F/100 °C to 302 °F/150 °C
– Clean using steam.

In steam operation (> 100°C), use the steam noz-
zle available as an accessory (see “Steam opera-
tion”).
Turn the regulation spindle in a clockwise direction:
Increase working pressure (MAX).
Turn the regulation spindle in an anti-clockwise di-
rection: Reduce working pressure (MIN).
– For considerate treatment of the environment use
detergent economically.
– The detergent must be suitable for the surface to
be cleaned.
With support of the detergent dose valve set deter-
gent concentration as determined by the manufac-
turer.
Note: Recommended values at the control panel at
maximum working pressure.
Note: If detergent is be suctioned from an external con-
tainer, route the detergent suction hose through the re-
cess to the outside.
Set pressure/temperature and detergent concen-
tration according to the surface to be cleaned.
Note: To prevent damage due to too much pressure, al-
ways position high pressure ray first from a greater dis-
tance towards object to be cleaned.
Power connection
GFCI INSTRUCTIONS
Operation
Opening/closing the trigger gun
Replace the nozzle
Turning on the Appliance
Adjust cleaning temperature
Set working pressure and flow rate
Pressure/quantity regulation of the pump unit
Operation with detergent
Cleaning
11EN

– 5
– Loosen the dirt:
Spray detergent economically and let it work for
1...5 minutes but do not let it dry up.
– Remove the dirt:
Spray off loosened dirt with the high pressure jet.
Removal of light contaminations and clear rinse, i.e.:
Gardening tools, terrace, tools, etc.
Set operating pressure according to need.
The appliance works in the most economical tempera-
ture range (max. 140 °F/60 °C).
We recommend the following cleaning temperatures:
– Light contaminations
86 °F/30 °C-122 °F/50 °C
– Contaminations containing protein, i.e. in the food
processing industry
max. 140 °F/60 °C
– Vehicle cleaning, machine cleaning
140 °F/60 °C-194 °F/90 °C
– De-preserve, contaminations containing strong fat
contents
212 °F/100 °C-230 °F/110 °C
– De-frosting of surcharge substances, partially fa-
cade cleaning
up to 284 °F/140 °C
DANGER
Scalding danger!
Set device switch to desired temperature.
DANGER
Scalding danger!
Therefore the following measures must definitely be
performed:

In steam operation (> 100°C), use the steam
nozzle available as an accessory (for part no.,
see technical data).
Set the working pressure/quantity regulation at the
pump unit to the minimum quantity.
Set device switch to min. 212 °F/100 °C.
Secure the trigger gun. To do so, push the safety
catch towards the front.
Set dosing value for detergent to "0".
Set the appliance switch to "1" (operation with cold
water).
Open the hand spray gun and rinse the appliance
for at least 1 minute.
DANGER
Danger of scalding from hot water! After the operation
with hot water or steam, the device must be operated
with opened gun with cold water for at least two min-
utes.
Shut off water supply.
Open the hand spray gun.
Switch on the pump with the power switch and al-
low to run for about 5-10 seconds.
Close the hand spray gun.
Set the appliance switch to "0/OFF“.
Pull main plug out of socket with dry hands only.
Remove water connection.
Activate hand spray gun until device is pressure
less.
Secure the trigger gun. To do so, push the safety
catch towards the front.
Lock in the steel pipe into the holder of the appli-
ance hood.
Roll up high pressure hose and electrical conduit
and hang them into the respective holders.
Note: Do not twist high pressure hose and electrical
conduit.
ATTENTION
Risk of damage! Frost will destroy the appliance if the
water has not been completely drained.
Store in a frost free area.
If the device is connected to a chimney, the following
must be observed:
ATTENTION
Threat of damage by penetrating cold air through the
chimney.
Disconnect device from chimney when outside
temperature drops below 32 °F/0 °C.
If it is not possible to store frost free, shut down device.
For longer work breaks or if a frost free storage is not
possible:
Empty detergent tank.
Drain water.
Flush device with anti-freeze agent.
Screw off water supply hose and high pressure
hose.
Screw off supply hose at boiler bottom and drain
heating spiral empty.
Operate device for max. 1 minute until the pump
and conduits are empty.
Note: Observe handling instructions of the anti-freeze
agent manufacturer.
Fill anti-freeze agent of the trade into swimmer con-
tainer.
Switch on appliance (without heater) till the appli-
ance has been completely rinsed.
A certain corrosion protection is achieved with this as
well.
몇CAUTION
Risk of personal injury or damage! Consider the weight
of the appliance when storing it.
Recommended cleaning method
Operating with cold water
Eco level
Operating with hot water/steam
Operating with hot water
Operating with steam
Interrupting operation
After operation with detergent
Turn off the appliance
Storing the Appliance
Frost protection
Shutdown
Dump water
Flush device with anti-freeze agent
Storage
12 EN

– 6
Figure 10
ATTENTION
Risk of damage! When loading the appliance with a
forklift, observe the illustration.
ATTENTION
Protect the trigger from damage during transport.
몇CAUTION
Risk of personal injury or damage! Mind the weight of
the appliance during transport.
When transporting in vehicles, secure the appli-
ance according to the guidelines from slipping and
tipping over.
DANGER
Risk of injury by inadvertent start-up of appliance and
electric shock. Prior to all work on the appliance, switch
off the appliance and pull the power plug.
Shut off water supply.
Open the hand spray gun.
Switch on the pump with the power switch and al-
low to run for about 5-10 seconds.
Close the hand spray gun.
Set the appliance switch to "0/OFF“.
Pull main plug out of socket with dry hands only.
Remove water connection.
Activate hand spray gun until device is pressure
less.
Secure the trigger gun. To do so, push the safety
catch towards the front.
Allow device to cool down.
Your Kärcher vender will inform you about the per-
formance of a periodic safety inspection resp. sign-
ing of a maintenance contract.
Clean the sieve in the water connection.
Clean the fine filter.
Clean the fuel sieve.
Check oil level.
ATTENTION
Risk of damage! In case of lacteous oil inform Kärcher
customer service immediately.
Clean sieve in the water shortage safe guard.
Clean filter at the detergent suck hose.
Oil change.
Have the maintenance of the device performed by
the customer service.
Perform the pressure test as per manufacturer's in-
structions.
Take out sieve.
Clean sieve in water and reinstall.
Unpressurize the appliance.
Unscrew the fine filter from the pump head.
Remove the fine filter and the filter insert.
Clean the filter with clean water or compressed air.
Reinstall in reverse sequence.
Knock the dirt off of the fuel sieve. Do not let the
fuel enter the environment.
Unpressurize the appliance.
Remove the fastening clamp and pull out the hose
(soft damping system) of the lack of water fuse.
Take out sieve.
Note: If necessary turn in screw M8 appr. 0.2 in/5 mm
inwards and therewith pull out sieve.
Clean sieve in water.
Push sieve inwards.
Slide the hose adapter all the way into the lack of
water fuse and secure it with a fastening clamp.
Take out detergent suck supports.
Clean filter in water and reinstall.
Ready a catch bin for appr. 0.26 gal/1 Liter oil.
Loosen release screw.
Tighten release screw.
Fill oil slowly up to the MAX marking.
Note: Air pockets must be able to leak out.
For oil type refer to technical specifications.
DANGER
Risk of injury by inadvertent start-up of appliance and
electric shock. Prior to all work on the appliance, switch
off the appliance and pull the power plug.
– No line voltage, see "Appliance is not running".
– Water shortage
Check water supply, check connections.
– Leak in the high pressure system
Check high pressure system and connections for
tightness.
– Fault in the voltage supply or current pickup of the
motor too high.
Check main connections and mains fuse.
Inform Customer Service.
– Engine overload/overheat
Set the appliance switch to "0/OFF“.
Allow device to cool down.
Turn on the appliance.
– Error occurs repeatedly.
Inform Customer Service.
Transport
Care and maintenance
Maintenance intervals
Weekly
Monthly
Every 500 operating hours, at least annually
At least every 5 years, recurring
Maintenance Works
Clean the sieve in the water connection
Cleaning the fine filter
Clean the fuel sieve
Clean sieve in the water shortage safe guard
Clean filter at the detergent suck hose
Oil change
Dispose of old oil ecologically or turn in at a gathering
point.
Troubleshooting
Indicator lamp "Ready for use" turns off
Indicator lamp service
1x blinking
2x blinking
3x blinking
13EN

– 7
– The exhaust temperature limiter has been trig-
gered.
Set the appliance switch to "0/OFF“.
Allow device to cool down.
Turn on the appliance.
– Error occurs repeatedly.
Inform Customer Service.
– Obstructed reed switch in the lack of water fuse or
magnetic piston stuck.
Inform Customer Service.
– The flame sensor turned the burner off.
Inform Customer Service.
– Fuel tank empty.
Refill fuel.
– System care container is empty.
Refill system care.
– Detergent tank is empty.
Refill detergent.
– No power
Check power connection/conduit.
– Air within the system
Vent pump:
Set dosing value for detergent to "0".
With open hand spray gun turn device on and off
multiple times with the device switch.
Open and close the pressure/quantity regulation at
the pump unit with the hand spray gun open.
Note: By dismantling the high pressure hose from the
high pressure connection the venting process is accel-
erated.
If detergent tank is empty, refill.
Check connections and conduits.
– Pressure is set to MIN
Set pressure to MAX.
– Sieve in the water connection is dirty
Clean sieve.
Clean the fine filter; replace it, if necessary.
– Amount of water supply is too low.
Check water supply level (refer to technical data).
– Pump leaky
Note: 3 drops/minute are allowed.
With stronger leak, have device checked by cus-
tomer service.
– Leak in the high pressure system
Check high pressure system and connections for
tightness.
Leave device running with open detergent dosage
valve and closed water supply, until the swimmer
tank is sucked empty and the pressure falls to "0".
Open the water supply again.
If the pump still is not sucking in any detergent, it could
be because of the following reasons:
– Filter in the detergent suck hose dirty
Clean filter.
– Backflow valve stuck
Remove the detergent hose and loosen the back-
flow valve using a blunt object.
– Fuel tank empty.
Refill fuel.
– Water shortage
Check water supply, check connections.
Clean sieve in the water shortage safe guard.
– Fuel filter dirty
Change fuel filter.
– No ignition spark
If device is in use and no ignition spark can be seen
through the viewing glass, have device checked by
customer service.
– Working pressure/flow rate to high
Reduce working pressure/flow quantity at the pres-
sure/volume regulator in the pump unit.
– Sooty heating spiral
Have device de-sooted by customer service.
If malfunction can not be fixed, the device must be
checked by customer service.
The warranty terms published by the relevant sales
company are applicable in each country. We will repair
potential failures of your appliance within the warranty
period free of charge, provided that such failure is
caused by faulty material or defects in manufacturing. In
the event of a warranty claim please contact your dealer
or the nearest authorized Customer Service centre.
Please submit the proof of purchase.
Note: When connecting the appliance to a chimney or if
the device cannot be accessed visually, we recommend
the installation of a flame monitor (option).
Only use original accessories and spare parts, they en-
sure the safe and trouble-free operation of the device.
For information about accessories and spare parts,
please visit www.kaercher.com.
4x blinking
5 x blink
6 x blink
Fuel indicator lamp glows
Indicator lamp system care is illuminated
Indicator lamp for detergent glows
Appliance is not running
Device is not building up pressure
Device leaks, water drips from the bottom of
the device
Device turns on and off while hand spray gun
is closed
Device is not sucking in detergent
Burner does not start
Set temperature is not achieved while using
hot water
Customer Service
Warranty
Accessories and Spare Parts
14 EN

– 8
Technical specifications
HDS 3.0/20 C Ea
Main Supply
Voltage V 220-240
Current type Hz 1~ 60
Connected load hp (kW) 5.6 (4.2)
Protection (slow) A 20
Type of protection -- IPX5
Protective class -- I
Water connection
Max. feed temperature °F (°C) 86 (30)
Min. feed volume gpm (l/min) 4.0 (15)
Suck height from open container (68 °F/20 °C) ft (m) 1.6 (0.5)
Max. feed pressure psi (MPa) 145 (1)
Performance data
Water flow rate gpm (l/min) 1.32-2.9 (5-11)
Operating pressure of water (using standard nozzle) psi (MPa) 460-2000 (3.1-13.7)
Max. excess operating pressure (safety valve) psi (MPa) 2460 (17)
Steam flow rate gpm (l/min) 1.32-1.5 (5-5.7)
Max. operating pressure for working with steam (using steam nozzle) psi (MPa) 464 (3.2)
Part no. of steam nozzle -- 2.114-001.0
Max. operating temperature of hot water °F (°C) 208 (98)
Working temperature steam operation °F (°C) 311 (155)
Detergent suck in gpm (l/min) 0-0.16 (0-0.62)
Burner performance hp (BTU/h) 58 (148,000)
Maximum consumption of heating oil kg/h (gph) 4.15 (1.35)
Max. recoil force of trigger gun N 25.6
Size of standard nozzle -- 042
Values determined as per EN 60335-2-79
Noise emission
Sound pressure level LpA dB(A) 76
Uncertainty KpA dB(A) 3
Sound power level LWA + Uncertainty KWA dB(A) 94
Hand-arm vibration value
Hand spray gun m/s22.7
Spray lance m/s25.4
Uncertainty K m/s20.3
Fuel
Fuel -- Fuel oil EL or Diesel
Amount of oil gal (l) 0.08 (0.3)
Oil grade -- 0W40
Dimensions and weights
Length x width x height in (mm) 41.7 x 25.6 x 36.2 (1060 x
650 x 920)
Typical operating weight lbs (kg) 206.6 (93.7)
Fuel tank gal (l) 4.1 (15.5)
Detergent Tank gal (l) 4.1 (15.5)
15EN

몇AVERTISSEMENT
En utilisant ce produit, toujours observer
une certaine prudence élémentaire, in-
cluant notamment :
1 Lire toutes les instructions de service
avant d'utiliser l'appareil.
2 En cas d'utilisation incorrecte, les jets
haute pression peuvent être dange-
reux. Ne jamais diriger les jets de va-
peur en direction d'individus,
d'animaux, de dispositifs électriques ou
de l'appareil lui-même.
3 Afin de minimiser les risques de bles-
sure, ne jamais laisser l'appareil sans
surveillance lorsque celui-ci est utilisé à
proximité d'enfants.
4 Il est impératif de savoir arrêter et
mettre l'appareil hors pression rapide-
ment. Une connaissance approfondie
des commandes est nécessaire.
5 Rester attentif – se concentrer sur la
tâche en cours.
6 Le port de lunettes de protection est
obligatoire.
7 N'utiliser en aucun cas d'acides, de so-
lutions alcalines, de solvants ou de pro-
duits inflammables dans cet appareil.
Ces produits peuvent être à l'origine de
blessures graves ou d'endommage-
ment irréversible de l'appareil.
8 L'utilisateur ne doit jamais faire usage
de l'appareil lorsqu'il est fatigué ou sous
l'emprise d'alcool ou de drogues.
9 Ne jamais passer ou monter sur des
supports instables. Toujours rester
stable et équilibré.
10 Afin de réduire le risque d'électrocution,
garder toutes les connexions au sec et
ne pas les laisser à terre. Ne pas tou-
cher la fiche avec les mains mouillées.
11 Le dispositif de sécurité de la poignée-
pistolet permet d'éviter tout actionne-
ment accidentel de la gâchette. Ce dis-
positif de sécurité NE verrouille PAS la
gâchette en position marche (ON).
12 Veiller à ce qu'aucun individu ne se
trouve dans la zone de travail.
13 Fermer le couvercle avant d'utiliser la
machine.
14 Cet appareil est prévu pour un usage
commercial.
15 Respecter les consignes d'entretien fi-
gurant dans le manuel.
16 Cette machine a été conçue pour une
utilisation avec des produits chimiques
utilisés pour le nettoyage, fournis ou re-
commandés par le fabricant. L'utilisa-
tion d'autres produits chimiques pour le
nettoyage peut influer sur le fonctionne-
ment de la machine et annuler la garan-
tie.
17 Ce produit est fourni avec un disjonc-
teur différentiel monté dans la fiche du
cordon d'alimentation. Si le remplace-
ment de la fiche ou du cordon d'alimen-
tation s'avère nécessaire, n'utiliser que
des pièces de rechange identiques.
18 Ne pas utiliser que des rallonges.
–Risque d'injection : le produit peut pro-
vo-quer de graves blessures en cas de
péné-tration dans la peau. Ne pas diri-
ger le ca-non vers quelqu'un ou vers
une partie du corps. En cas de pénétra-
tion, consulter im-médiatement un mé-
decin.
–Ce système peut produire 2000 psi/
13.7 MPa.
Afin d'éviter une rupture et des bles-
sures, ne pas utiliser cette pompe avec
des composants ayant une puissance
nominale inférieure à une pression de
service de 2000 psi/13.7 MPa (com-
prend des pistolets pulvérisateurs, des
tuyaux et des raccords de tuyaux).
–Avant d'effectuer l'entretien, le net-
toyage ou le retrait de toute pièce, cou-
per le cou-rant et réduire la pression.
–Ne pas pulvériser sur des appareils ou
des fils électriques.
–Haute pression. Maintenir sans tuyères.
CONSIGNES DE SÉCURITÉ IMPORTANTES
16 FR

–Si le branchement à un système d'eau
potable est effectué, le système doit
être protégé contre un retour de cou-
rant.
–Avant d'utiliser ce nettoyeur pression, le
propriétaire et/ou l'utilisateur doit impé-
rativement avoir pris connaissance des
consignes d'utilisation et mises en
garde du fabricant.
–Il est nécessaire d'insister sur les aver-
tissements et de les comprendre.
–Si l'utilisateur ne parle pas couramment
l'anglais, l'acheteur/le propriétaire doit
lire les consignes et mises en garde du
fabricant avec l'utilisateur dans la
langue maternelle de ce dernier et s'as-
surer qu'il en comprend bien le contenu.
–Le propriétaire et/ou l'utilisateur doit se
familiariser avec les consignes du fabri-
cant et les conserver afin de pouvoir s'y
référer ultérieurement.
Ce produit doit-être mis à la terre. En cas
de mauvais fonctionnement ou de panne,
la mise à la terre établit un chemin de
moindre résistance pour le courant élec-
trique afin de réduire le risque de décharge
électrique. Ce produit est équipé d'un cor-
don doté d'un conducteur de mise à la terre
de l'équipement et d'une prise de mise à la
terre. La prise doit être branchée dans une
prise appropriée qui est correctement ins-
tallée et mise à la terre en conformité avec
les codes et ordonnances locaux.
DANGER
Un conducteur de mise à la terre d'équipe-
ment incorrectement branché peut entraî-
ner un risque d'électrocution. Vérifier avec
un électricien ou un technicien d'entretien
qualifié en cas de doute sur la mise à terre
correcte de la prise. Ne pas modifier la
fiche fournie avec le produit - si elle ne peut
pas être branchée, faire installer une prise
appropriée par un électricien qualifié. Ne
pas utiliser n'importe quel type d'adapta-
teur avec ce produit.
Ce produit est fourni avec un disjoncteur
différentiel intégré dans la fiche de cordon
d'alimentation. Ce dispositif fournit une pro-
tection supplémentaire contre les risques
de décharges électriques. En cas de cou-
pure de courant, le disjoncteur différentiel
referme automatiquement le circuit lorsque
le courant est rétabli. Selon le modèle de
disjoncteur différentiel, il peut s’avérer né-
cessaire d’actionner manuellement le bou-
ton de réinitialisation pour rétablir
l’alimentation du circuit de charge. Utiliser
des pièces de rechange identiques en cas
de remplacement du cordon ou de la fiche.
Responsabilité du propriétaire/de
l'utilisateur
INSTRUCTIONS DE MISE À
LA TERRE
PROTECTION PAR
DISJONCTEUR
DIFFÉRENTIEL
17FR

몇ATTENTION
Lors de la connexion de l'entrée d'eau à la
canalisation d'alimentation en eau, les ré-
gulations locales de votre compagnie d'eau
doivent être observées. Dans certaines
zones, l'appareil ne doit pas être connecté
directement à l'alimentation en eau potable
publique. Il s'agit de s'assurer qu'il n'y a pas
de retour de produits chimiques dans l'ali-
mentation en eau. Une connexion directe
par l'intermédiaire d'un réservoir de récep-
tion ou d'un disconnecteur hydraulique par
exemple est autorisée.
D'éventuelles impuretés dans l'eau d'ali-
mentation endommagent l'appareil. Pour
prévenir ce risque, nous recommandons
d'installer un filtre à eau.
–Le tuyau d'arrosage doit avoir un dia-
mètre minimum de 3/4 pouces.
–Le débit de l'alimentation en eau ne doit
pas être inférieur à 4.0 GPM (gallons
par minute)
–Pour calculer le débit, faire couler l'eau
pendant une minute dans un récipient
vide d'une contenance de 5 gallons.
–La température de l'eau d'alimentation
ne doit pas excéder 86 °F/30 °C.
–Ne jamais aspirer d'eau contaminée par
des solvants, par exemple des diluants
pour peinture, de l'essence, de l'huile,
etc..
–Toujours utiliser une source d'eau
propre afin d'éviter toute infiltration de
débris dans l'appareil. Utiliser un filtre à
eau supplémentaire.
CONSERVER CES INSTRUCTIONS!
ALIMENTATION EN EAU
18 FR

– 1
Lire ce manuel d'utilisation original avant
la première utilisation de votre appareil, le
respecter et le conserver pour une utilisa-
tion ultérieure ou pour le futur propriétaire.
– Avant la première mise en service, vous devez im-
pérativement avoir lu les consignes de sécurité N°
5.951-949.0 !
– Contactez immédiatement le revendeur en cas
d'avarie de transport.
– Vérifier le contenu de l'emballage à l'ouverture.
Étendue de livraison cf. figure 1.
– À partir d'une altitude de fonctionnement d'environ
800 m au-dessus du niveau de la mer, veuillez
contacter votre revendeur pour adapter le réglage
du brûleur à l'altitude et à la quantité réduite d'oxy-
gène.
Les appareils électriques et électroniques renferment
souvent des composants qui peuvent représenter un
danger potentiel pour l'intégrité physique et l'environne-
ment s'ils sont mal utilisés ou éliminés. Ces composants
sont pourtant nécessaires au bon fonctionnement de
l'appareil. Les appareils qui présentent ce symbole ne
doivent pas être jetés avec les déchets ménagers.
Instructions relatives aux ingrédients (REACH)
Les informations actuelles relatives aux ingrédients se
trouvent sous :
www.kaercher.com/REACH
DANGER
Signale la présence d'un danger imminent entraînant de
graves blessures corporelles et pouvant avoir une issue
mortelle.
몇AVERTISSEMENT
Signale la présence d'une situation éventuellement
dangereuse pouvant entraîner de graves blessures cor-
porelles et même avoir une issue mortelle.
몇PRÉCAUTION
Remarque relative à une situation potentiellement dan-
gereuse pouvant entraîner des blessures légères.
ATTENTION
Remarque relative à une situation éventuellement dan-
gereuse pouvant entraîner des dommages matériels.
Figure 1
1 Dispositif de fixation de la lance
2 Manomètre
3 Évidement pour le flexible d'aspiration de détergent
4 Poignée encastrée (des deux côtés)
5 Arrivée d'eau avec tamis
6 Adaptateur de raccord d'alimentation en eau
7 Raccordement haute pression EASY!Lock
8 Flexible haute pression EASY!Lock
9 Lance EASY!Lock
10 Buse haute pression (acier inoxydable)
11 Orifice de remplissage pour détergent
12 Roulettes pivotantes et frein de stationnement
13 Tamis de combustible
14 Manette de sécurité
15 Alimentation électrique
16 Levier de départ
17 Trousse à outils
18 Cran de sécurité de la poignée-pistolet
19 Pistolet de pulvérisation à main EASY!Force
20 Orifice de remplissage pour combustible
21 Vanne de dosage du détergent
22 Pupitre de commande
23 Support pour la poignée pistolet
24 Cavité de marche
25 Poignée
26 Plaque signalétique
27 Fermeture du capot
28 Compartiment de rangement pour accessoires
29 Brûleur
30 Support pour la lance
31 Capot
32 Orifice de remplissage pour l'entretien système
RM 110
33 Réglage de la pression/ du débit de l'unité de
pompe
34 Réservoir d'huile
35 Bouchon de vidange d'huile
36 Soupape anti-retour de l'aspiration de détergent
37 Flexible d'aspiration du détergent avec filtre
38 Filtre de combustible
39 Agrafe de fixation
Table des matières
Protection de l’environnement FR 1
Niveaux de danger FR 1
Aperçu général FR 1
Symboles sur l'appareil FR 2
Utilisation conforme FR 2
Consignes de sécurité FR 2
Dispositifs de sécurité FR 3
Mise en service FR 3
DISJONCTEUR DIFFERENTIEL FR 4
Utilisation FR 4
Entreposage FR 6
Transport FR 6
Entretien et maintenance FR 6
Assistance en cas de panne FR 7
Garantie FR 8
Accessoires et pièces de rechange FR 8
Caractéristiques techniques FR 9
Protection de l’environnement
Les matériaux constitutifs de l’emballage
sont recyclables. Ne pas jeter les embal-
lages dans les ordures ménagères, mais
les remettre à un système de recyclage.
Les appareils usés contiennent des ma-
tériaux précieux recyclables lesquels
doivent être apportés à un système de re-
cyclage. Il est interdit de jeter les batte-
ries, l'huile et les substances similaires
dans l'environnement. Pour cette raison,
utiliser des systèmes de collecte adé-
quats afin d'éliminer les appareils hors
d'usage.
Ne jetez pas l'huile moteur, le fuel, le diesel ou l'es-
sence dans la nature. Protéger le sol et évacuer l'huile
usée de façon favorable à l'environnement.
Niveaux de danger
Aperçu général
Éléments de l'appareil
19FR

– 2
40 Flexible (système d'amortissage souple) de la sé-
curité contre le manque d'eau
41 Dispositif de sécurité en cas de manque d'eau
42 Le tamis du dispositif de sécurité en cas de
manque d'eau
43 Filtre fin (eau)
44 Réservoir flottant
Figure 2
A Interrupteur principal
1 Mode de fonctionnement : Fonctionnement avec
de l’eau froide
2 Mode de fonctionnement : Fonctionnement avec
de l’eau chaude (e = niveau Eco, eau chaude max.
140 °F/60 °C)
3 Mode de fonctionnement : Fonctionnement avec
de la vapeur
4 Témoin de contrôle d’état de service
5 Témoin de contrôle Combustible
6 Lampe témoin service
7 Voyant de contrôle Détergent
8 Lampe témoin soin système
– Les éléments de commande pour le processus de
nettoyage sont jaunes.
– Les éléments de commande pour la maintenance
et l'entretien sont en gris clair.
Une utilisation incorrecte des jets haute
pression peut présenter des dangers. Le
jet ne doit pas être dirigé sur des per-
sonnes, animaux, installations électriques
actives ni sur l'appareil lui-même.
Nettoyage de : machines, véhicules, bâtiments, outils,
façades, terrasses, appareils de jardinage, etc.
DANGER
Risque de blessure ! En cas d'utilisation dans l'enceinte
d'une station service ou dans d'autres zones à risque,
respecter les consignes de sécurité correspondantes.
Exigences à la qualité d'eau :
ATTENTION
Utiliser uniquement de l'eau propre comme fluide haute
pression. Les salissures entraînent l'usure prématurée
ou des dépôts dans l'appareil et les accessoires.
Si de l'eau de recyclage est utilisée, les valeurs limites
suivantes ne doivent pas être dépassées.
–Respecter les dispositions légales nationales res-
pectives pour les jets de liquide.
–Respecter les dispositions légales nationales res-
pectives pour la prévention des accidents. Les jets
de liquides doivent être contrôlés régulièrement et
le résultat du contrôle consigné par écrit.
–Le dispositif de chauffage de l'appareil est une ins-
tallation de combustion. Les installations d'allu-
mage doivent être contrôlées régulièrement en
concordance avec les dispositions légales natio-
nales respectives.
Zone de commande
0/OFF = Arrêt
Repérage de couleur
Symboles sur l'appareil
Danger lié à la tension électrique !
Seul les électriciens spécialisés ou le
personnel autorisé sont habilités à réali-
ser des travaux sur des composants de
l'appareil.
Risque de brûlure provoqué par les
pièces chaudes de l'installation!
Danger d'intoxication ! Ne pas inspirer
les gaz d'échappement.
Utilisation conforme
Ne pas évacuer les eaux usées contenant de l'huile
minérale dans la terre, les dispositifs pour eaux usées
ou les canalisations. Dès lors, effectuer le nettoyage
du moteur ou du bas de caisse uniquement aux postes
de lavage appropriés et équipés d'un séparateur
d'huile.
Valeur de pH 6,5...9,5
conductivité électrique * Conductivité de
l'eau du robinet
+1200 µS/cm
substances qui se déposent ** < 0,5 mg/l
substances qui peuvent être fil-
trées ***
< 50 mg/l
Hydrocarbures < 20 mg/l
Chlorure < 300 mg/l
Sulfate < 240 mg/l
calcium < 200 mg/l
Dureté globale < 28 °dH
< 50 °TH
< 500 ppm (mg
CaCO3/l)
Fer < 0,5 mg/l
Manganèse < 0,05 mg/l
Cuivre < 2 mg/l
Chlore actif < 0,3 mg/l
exempt de mauvaises odeurs
* Total maximal 2000 µS/cm
** Volume d'essai 1 l, temps de dépose 30 min
*** pas de substance abrasive
Consignes de sécurité
PROPOSITION 65
AVERTISSEMENT
L'échappement de ce brûleur contient des produits
chimiques connus de l'Etat de Californie qui pro-
voquent le cancer, des malformations congénitales et
d'autres dommages de reproduction.
20 FR
