USER MANUAL
330 Yards 100% Waterproof & Rechargeable Dog
Training Collar with Remote

1
◎Features
1. 100 levels of vibration and shock stimulation
2. Four modes: shock, vibration, LED light, and tone
3. Remote transmitter controls one or two collars at a time
4. Range: 330 yards in outdoor areas, with advanced RF434Mhz technology
5. 100% Waterproof
6. Power saving design: automatic standby and memory function
◎Remote Transmitter

2
◎Charging
1. Charging the remote transmitter
Connect the power cord to the charging port. After plugging
the charger into a standard outlet, the LED light on the receiver
should flash red. Charge the transmitter at least 6 hours for the
first charge. After fully charged, the LED light will automatically
turnoff.
2. Charging the receiver
After plugging the charger into a standard outlet, the LED light on the
receiver collar will be lighted. Charge the receiver at least 6 hours for
the first charge. After fully charged, the LED light will turn green.
Is charging Fully charged
Low battery indicator: the symbol will show on the right bottom corner of the LCD
screen.
Note:
l Insert the power cord into the charging port vertically. Do NOT insert it in a
skewed angle. Doing so may damage the cord or the port.
l Adapter charger not included. Please DO NOT use a charger over 5V1A.
Otherwise, you may damage the remote or the receiver!!!
◎Setting it up
1. Press the button on the controller, then the controller should be turned on. Press
the CHANNEL button and select CHANNEL1 (the small icon can be seen at

3
the upper right corner of the LED screen).
Press the mode button for 5 seconds to turn off the remote transmitter.
2. Press the button on the collar, and you should hear a beep, and the green LED light
should turn on. Then hold the button for 5 seconds and the green LED light keep on, 5
seconds a ft er the green light will flashing and hear “beep” again.
Power Button / Synchronization Button: Press the button to turn on / off the receiver. Press
the button for at least 5 seconds to enter into synchronization mode.
LED Light: Flashes when turned on; fast flashes when synchronizing.
3. Now press to switch mode, and press the button on the remote. An icon will
show it is paired successfully. If not, please, press the RESET button and repeat the steps
above.
◎Matching the second receiver
If you have another receiver, press the CHANNEL button and select CHANNEL 2
(the icon will appear at the upper right corner of the LED screen).
Please follow steps 1 to 3 above to finish matching the receiver.
◎Intensity Regulation
The shock and vibration function has levels 0 to 100. Use the UP/DOWN
buttons on the right hand side to increase/decrease levels as needed.

4
◎Install the receiver’s conductors
According to your dog’s size and hair length, select either a short or tall conductor.
◎Thread the collar strap through the slots on the receiver.
1. If the collar is too long, you can use scissors to cut any excess belt.
2. Adjustable tightness

5
◎Testing the four modes
The following guidelines should help you test whether the training system functions properly.
●Test the LED Light function
①Press the button of the transmitter, switch to LED Light Mode.
②Then press the button and then the receiver collar will flash.
●Test the Sound function
① Press the button on the transmitter, then switch to sound mode.
②Then press the button and the collar will beep.
●Test the Vibration function
①Press the button on the transmitter, switch to vibration mode, then check if the LCD
display is not 0.
②You can press the UP/DOWN buttons on the right side to adjust. Then press the
button and the collar will vibrate.
●Test the Static Shock function
① Take out the test unit from the package and put it on the receiver’s conductors.
② Press the button on the transmitter, switch to Shock Mode, then check if the LCD
display is not 0.
③You can press the UP/DOWN buttons on the right side to adjust. Then press the
button and the test unit will turn on.
◎ Package includes:
1 x Remote transmitter
1 x Receiver Collar / 2 x Receiver Collar
1 x Belt / 2 x Belt
2 x Conductor / 4 x Conductor
1 x Charger
1 x USB Cable
1 x Test Unit
1 x User Manual

6
Notes on use:
1. The lifetime of the batteries varies according to how often you use the product. Make
sure to replace the batteries if either the receiver doesn’t beep or the LCD screen on the
transmitter doesn’t turn on.
2. The valid distance of Controller means the straight-line distance between the Controller
and the Receiver Collar without obstacles in between. If there are interference signals
or signal screening around, the actual remote Controller distance may vary.
3. This product is intended for pet training. You can expect results after a couple of pet
training sessions.
4. Training sessions should be kept positive and short, about 10-15 minutes each.
5. This product is the most effective and safest tool for training pets. Please, follow the
instructions to avoid harming your pet.
