Kaboodle 2x11L Side Mount Pullout Bin User manual

M5 16mm
screws x 4
Tools you will need
To put your kaboodle kitchen waste bins together you will need the following tools.
Hardware included
14mm
wood screws x 4
E FC
I
D
J
B
H
A
G
Cordless drill with:
• Number 2 screw tip
• 2mm drill bit
Tap e
measure
Adjustable
square
Clamps
(optional)
Spirit level
(optional)
Screw
driver
Safety
gearPencil
M5 8mm
screws x 2
p. 1
Ver. 2
W-50530
Things you need to know
M6 16mm
screws x 2
Follow these
instructions to
install your parts
and accessories.
• Always read the full instructions prior to installation.
• Consider possible obstructions to your parts & accessories,
like hinges inside the cabinet or adjacent cabinet doors and
handles, prior to installation.
• Make sure you leave plumbing and electrical work
to qualified trades people. Never try this yourself.
• Make sure you always use safety gear like a mask, ear muffs
and glasses when using tools.
• Tip: After marking out the pre-drill holes as per the
instructions, take the part that is to be installed and align
the appropriate holes with the markings to ensure they
match up prior to pre-drilling the holes.
• If you have any questions, contact us on:
Australia: 1800 666 078 Monday to Friday between
8:00am and 6:00pm AEST, New Zealand: 0800 522 663
Monday to Friday between 8:00am and 5:00pm NZST
or email: [e-mail].
2x11L side mount pullout bin
step 2
runners x 1 pair m4 8mm
screws x 4
door
brackets x 2
bin
frame x 1
16mm
wood screws x 12
lid
brackets x 2
installation guide

hardware key
kaboodle.com.au
A A
B
step 2
p. 2
Ver. 2
W-50530
1.
343mm
295mm
295mm
343mm
133mm
133mm
229mm
229mm
341mm
341mm
37mm
37mm
235mm
235mm
393mm
393mm
16mm
wood screws
runners
pre-drilling for runners
separating runners attaching runners
pre-drilling for lid brackets
3.
2.
4.
2 x 11L side mount pullout bin
A
A
B
On both sides of your cabinet, draw a horizontal line 343mm up
from the bottom. Measuring from the front of the cabinet along
these lines, mark out the pre-drill holes at 133mm, 229mm and
341mm as pictured above. Use a 2mm drill bit to pre-drill holes
to a depth of roughly 2.5mm.
Separate each runner (A) into two parts by extending the guide
(i) and pushing up on the lever (ii) while continuing to pull apart
the two components. The guide should separate easily from the
runner without too much force being applied.
Using the lower sets of pre-drilled holes, align with the
holes on the runners (A) and fix to the cabinet using
6 x 16mm wood screws (B) as pictured above.
On both sides of your cabinet, draw a horizontal line 295mm up
from the bottom. Measuring from the front of the cabinet along
these lines, mark out the pre-drill holes at 37mm, 235mm and
393mm as pictured above. Use a 2mm drill bit to pre-drill holes
to a depth of roughly 2.5mm.
(ii)
(i)

hardware key
kaboodle.com.au
A
B DC E
lid brackets m4 8mm
screws
16mm
wood screws bin frame
step 2
p. 3
Ver. 2
W-50530
attaching bin frame inserting bin lid
7. 8.
E
D
Place the bin frame (D) carefully onto the extended runners,
aligning the holes and then securing into place with the 4 x M4
8mm screws (E). Note: Support the runners from underneath
when screwing the frame into place. Do not tighten screws.
reassembling runnersattaching lid brackets
5. 6.
B
C
Using the top sets of pre-drilled holes, align with the 2nd, 5th
and 7th holes on the lid brackets (C) and fix to the cabinet using
6 x 16mm wood screws (B) as pictured above.
2 x 11L side mount pullout bin
Carefully slide the guide back into the runner. The runners
should open and close smoothly if assembled correctly.
Extend the runners once they have been correctly reassembled.
Slide the back plastic catches of the bin lid along the top of the
lid brackets until both plastic catches fall into the channels at
the back. The front two plastic catches should fit into the front
channels at the same time.

hardware key
A
F HG I J
H
14mm
wood screws
door brackets
G
I
J
J
m5 8mm
screws
m5 16mm
screws
m6 16mm
wood screws
p. 4
Ver. 2
W-50530
step 2
attaching door panel adjusting door panel
11. 12.
(ii)
(i)
attaching door brackets
9. 10.
Align each door mount bracket (F) with the pre-drilled holes and
fix to the door panel using 4 x 14mm wood screws (G) as pictured
above. Ensure the open side of the bracket faces inward and that
the height adjustment screw hole is facing down.
Half screw the 2 x M6 16mm screws (H) into the height adjustment
holes of the door mount brackets as pictured above.
Mark out and pre-drill four holes on the inner side of your cabinet
door as pictured above. Use a 2mm drill bit to pre-drill holes
to a depth of roughly 2.5mm.
2 x 11L side mount pullout bin
37mm
37mm
195mm
195mm
291mm
291mm
F
H
Slide the door mount brackets onto the runner brackets (i),
ensuring the height adjustment screws (H) slip into the notches
(ii). Screw through the top and bottom holes of the runner
brackets, ensuring they are as centred as possible, using 4 x M5
16mm screws (J). Next attach the 2 x M5 8mm screws (I) through
the middle holes of each runner bracket.
pre-drilling for door brackets
If required, you can now adjust the door panel by tightening
or loosening the screws as pictured above. Once door
is aligned, tighten the four screws that secure the bin frame
to the runners.

step 1
step 2
step 3
step 4
Next, follow the
instructions to fit
your doors and
panels.
Finish off your
Kaboodle Kitchen
by installing your
benchtop.
You’ve finished
adding your
parts and
accessories.
Your Kaboodle
cabinet is now
complete.
step 2
p. 5
Ver. 2
W-50530
13.
installing bins
2x11L side mount pullout bin
Place the bins into the frame to complete assembly.
Note: Max weight capacity, including door if attached, is 25kg.
Caring for your kaboodle parts and accessories
Looking after your parts and accessories is really easy and with the right care and
maintenance they will last you for many years. Just follow these simple steps.
Hinges, runners and other parts and accessories should be kept dry at all times.
To keep the mechanisms performing at their best, regularly wipe them with a dry
cloth removing any dust and grime that may build up. In case of spills, clean
immediately with a dry cloth. Do not use harsh abrasives.
