Kalorik USK WCL 32964 User manual


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.

Front cover page (first page)
Assembly page 1/32
Fax [phone]
Wine cellar
Bodega
Cave à vin
WCL 32964
115V~130W
www.KALORIK.com


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
2 WCL 32964 - 140728
Assembly page 2/32
Fax [phone]
N S F
1 Fan Mask Máscara de Ventilador Cache ventilateur
2 Light Luz Eclairage
3 Control panel Panel de control Panneau de contrôle
4 Shelf Estante Étagère
5 Feet Pata/Pié Pied
6 Hinge cover Cobertura de Bisagra Cache charnière
7 Glass door Puerta de vidrio Porte en verre
8 Handle Manija Poignée


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
3 WCL 32964 - 140728
Assembly page 3/32
Fax [phone]
N
9 Light on/off switch
10 “Temp +” for upper zone
11 “Temp –“ for upper zone
12 LCD display
13 “Temp +” for lower zone
14 “Temp –“ for lower zone
15 C/F button
F
9 Interrupteur pour l’éclairage
10 “Temp +” pour zone supérieure
11 “Temp –“ pour zone supérieure
12 Ecran LCD
13 “Temp +” pour zone inférieure
14 “Temp –“ pour zone inférieure
15 Sélection Celsius / Fahrenheit
S
9 Interruptor luminoso de
encendido/apagado
10 “Temp +” de la zona superior
11 “Temp –“ de la zona superior
12 Pantalla LCD
13 “Temp +” de la zona inferior
14 “Temp –“ de la zona inferior
15 Botón C/F
[CELSI S/FAHRENHEIT]


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
4 WCL 32964 - 140728

Back cover page (last page)
Assembly page 4/32
Fax [phone]
IMPORTANT SAF GUARDS
When using electrical appliances, basic safety precautions should
always be followed, including the following:
 After removing the wine cooler from the package, make sure it is
in good condition. In case of doubt, do not use it and contact
the customer service centre.
 Plastic bags, nails, etc. should be kept out of the reach of
children
 Check that your mains voltage corresponds to that stated on the
appliance.
 Never leave the appliance unsupervised when in use.
 Never leave the appliance unsupervised when taking beverages
out or putting them in the cooler. Keep out of reach of children or
incompetent persons.
 From time to time check the cord for damages. Never use the
appliance if cord or appliance shows any signs of damage.
 Never move the appliance by pulling the cord. Make sure the
cord cannot get caught in any way. Do not wind the cord
around the appliance and do not bend it. Keep the power cord
away from sources of heat.
 Only use the appliance for domestic purposes and in the way
indicated in these instructions.
 Should the cord be damaged, it must be replaced by a qualified
service.
 Never use the appliance near hot surfaces or in the sunlight.
 Never use the appliance outside and always place it in a dry
environment.
 Stand the appliance on a table or flat surface in order to avoid its
fall. Ensure that there is at least a 10cm / 4 in. clearance at the
sides; and 8cm / 3 in. clearance at the back of the cooler, in
order to allow adequate ventilation. Kitchen units (cupboards)
should be at least 5cm / 2 in. away from the appliance in order to
assure adequate ventilation.
 Do not place any other object on top of the appliance.


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
5 WCL 32964 - 140728

Back cover page (last page)
Assembly page 5/32
Fax [phone]
 Never use accessories that are not recommended by the
producer. They could constitute a danger to the user and risk to
damage the appliance.
 Plug the appliance directly into the power outlet; do not use any
extension cord or multiple power sockets.
 This cooler is designed to store wine bottles, however, if placing
food inside; ensure that there is sufficient airflow between items.
 Do not place hot beverages into the appliance but let them cool
down to room temperature before.
 Close the cooler door immediately after putting in any items so
the inside temperature will not rise dramatically.
 When positioned or if moving the appliance, ensure that it is not
set horizontally or declined less than 45° or turned upside down.
 Should you notice any kind of damage on the appliance, please
unplug it immediately and contact a qualified service.
 All repairs should be made by a qualified service.
 To reduce the risk of fire, replace only with same type fuse
 nplug the appliance before cleaning or when it is not in use.
 To avoid risk of child entrapment, leave the shelves in place so
children cannot easily climb inside even when the appliance is in
routine use or not in use at home.
 Avoid direct sunshine and high temperature.
SAV TH S INSTRUCTIONS
HOUS HOLD US ONLY
Save time and money. Before you call for service, check at the back
of this manual. It lists causes of minor operating can correct yourself.
Warning: Changes or modifications to this unit not expressly
approved by the manufacturer could void the user’s
authority to operate the equipment


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
6 WCL 32964 - 140728

Back cover page (last page)
Assembly page 6/32
Fax [phone]
3-PRONG PLUG INSTRUCTIONS
For your personal safety, this appliance must be grounded. This
appliance is equipped with a power supply cord having a 3-prong
grounding plug. To minimize possible shock hazard, the cord must be
plugged into a mating 3-prong, grounding type, wall receptacle,
grounded in accordance with the National Electrical Code
ANSI/NFPA 70 latest edition and all local codes and ordinances. If a
mating wall receptacle is not available, it is the personal
responsibility and obligation of the customer to have a properly
grounded, 3-prong, wall receptacle installed by a qualified
electrician.
T CHNICAL DATA
Volume 65 litres
Capacity 21 bottles of 750 ml
Adjustable temperature 45°F to 54°F (7°C – 12°C)
( pper Zone)
Adjustable temperature 54°F to 64°F (12°C – 18°C)
(Lower Zone)
Without CFC, no refrigerant gas
NOT : this appliance is not a standard refrigerator. The maximum
cooling capacity is around 30 degrees F (15 degrees C) below the
ambient temperature.
POSITIONING TH APPLIANC
For best results, use the height-adjustable foot to level the wine
cooler. This will allow it to stand perfectly horizontal, which allows for
stability.
The height-adjustable foot is located under the lower hinge. It is
smaller than the feet placed on the other 3 corners of the appliance.
It is positioned in a threaded insert on the hinge, marked by an arrow
in the picture below. Turn the foot clockwise or counter-clockwise to
adjust its height and to ensure the perfect horizontality of the unit.


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
7 WCL 32964 - 140728

Back cover page (last page)
Assembly page 7/32
Fax [phone]
CAUTION: The wine cooler should not be built-in. Standalone use
only!
OP RATION
CAUTION: Before connecting the appliance to electrical power
supply, leave it to stand for about 4 hours, which will reduce the
possibility of malfunctions in the cooling system due to transport
handling.
• Before use, clean the appliance thoroughly; especially in the
interior (See Cleaning and Maintenance).
• Rearrange the shelves in the cavity properly if they are not
correctly placed.
• Make sure that your mains voltage corresponds to that stated on
the appliance.
• Position the appliance in a cool place, on a stable surface near a
wall outlet, with sufficient clearance on all sides to allow proper
ventilation. Do not attempt to install the appliance into a built-in
unit!
• Plug in the appliance to an earthed wall outlet.
• Once connected to a power source, the fans will start turning
and the wine cooler will start cooling. The cooler will need up to
one and a half hours to reach 15°C/ 60°F and up to 4 hours to
reach the temperature set up as the factory standard.
NOTE: The inside temperature of the thermoelectric wine cooler
depends on the room temperature. To reach the minimum


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
8 WCL 32964 - 140728

Back cover page (last page)
Assembly page 8/32
Fax [phone]
temperatures indicated below, it should be located in a room whose
temperature is maximum 75°F / 25ºC.
Temperature control and display
The upper zone of the appliance is for storage of white wine with
temperature from 45°F to 54°F (7°C to 12°C) The lower zone is for
storage of red wine with temperature range from 54°F to 64°F (12°C
to 18°C).
The display usually shows the average temperature of the appliance
at that moment.
Manual temperature setting
The temperature is factory preset when the cellar is off the
assembling line. If you want to change the temperature in the
cabinet, please select the right zone and change accordingly.
The temperature of the wine cooler can be set by pressing the
temperature “up” and temperature “down” buttons as follows:
1) By pressing the button C/F on the control panel, select if you
want to display the temperature in Fahrenheit (F) or Celsius (C).
The temperatures in Fahrenheit are always the highest value.
2) There are four buttons on the panel: on the left, push “ P” to
increase the temperature or push “DOWN” to decrease the
temperature in upper zone. On the right, push “ P” to increase
the temperature or push “DOWN” to decrease the temperature
in lower zone.
3) When the power switch is connected, cooling system starts to
work. The temperature is set on certain temperature level, which
means that when the inner temperature reaches the set point,
the appliance will stop cooling, so that the temperature in the
cabinet rises gradually.
4) When the inside temperature rises above the set point, cooling
will resume until reaching this set point, the cellar enters into
cooling cycles.


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
9 WCL 32964 - 140728

Back cover page (last page)
Assembly page 9/32
Fax [phone]
You can turn the interior light ON or OFF by pressing the lights switch
on the control panel.
Note:
• This wine cooler needs to be placed on a flat floor, with 10cm
/4in. space on each side; and 8cm / 3 in. space at the
backside. This appliance is not designed to be built-in.
• Make sure to place the wine cooler perfectly level for best
function.
• Avoid placing in direct sunshine or near a heating source, or in
an unventilated area.
• Do not place heavy items on top of the appliance
CL ANING
• nplug the appliance from the wall outlet before cleaning it.
• Clean the exterior of the appliance with water and a mild
household detergent. Do not use abrasive cleaners as they can
damage the finish of the appliance.
• Clean the interior of the appliance with lukewarm water and a bit
of vinegar, or baking soda.
• If needed, remove the shelves in the cavity by sliding them out;
clean them with water and a mild liquid detergent. Do not put
any parts in the dishwasher.
• Never use metal utensils or harsh, abrasive products to clean the
appliance.
• Never immerse the appliance in water or any other liquid.


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
10 WCL 32964 - 140728

Back cover page (last page)
Assembly page 10/32
Fax [phone]
TROUBL SHOOTING
Symptoms Possible cause Solutions
No cooling
– No power
– Plug not put in
– Fuse broken
– Put in the plug
– Check socket is not
tripped
– Contact customer
service
Temperature
inside not cold
enough
– The refrigerator is
placed too close
to a heat source;
– Bad ventilation;
– Fans don’t work;
– The door is not
closed tightly or
opened too
frequently or for
too long time;
– Keep the refrigerator
away from sunshine or
other heat source;
– Place the refrigerator in
the area with good
ventilation and keep
things away from the
fans;
– Check whether the plug
is connected or change
the fan;
– Close the door tightly
and don’t open the
door too frequently or
for too long time.
Peculiar smell
inside
refrigerator
– Check whether
there is anything
sour inside
– Wrap the source or take
it out
– Clean the inside with
water and vinegar
Inside light
flashes
– Set temperature
higher than inner
temperature;
– Adjust the temperature
Frost inside the
appliance
– Too much humidity
or too low
temperature inside
the case
– Output the plug, stop
the power, and defrost
by hand, connect
power again when the
ice thaws


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
11 WCL 32964 - 140728

Back cover page (last page)
Assembly page 11/32
Fax [phone]
WARRANTY
We suggest that you complete and return the enclosed Product
Registration Card promptly to facilitate verification of the date of
original purchase. However, return of the Product Registration Card is
not a condition of these warranties. You can also fill out this warranty
card online, at the following address: www.KALORIK.com
This KALORIK product is warranted in the .S.A. for 1 year from the
date of purchase against defects in material and workmanship. This
warranty is not transferable. Keep the original sales receipt. Proof of
purchase is required to obtain warranty performance.
During this period, if the KALORIK product, upon inspection by
KALORIK, is proven defective, it will be repaired or replaced, at
Kalorik’s option, without charge to the customer. If a replacement
product is sent, it will carry the remaining warranty of the original
product.
This warranty does not apply to any defect arising from a buyer's or
user's misuse of the product, negligence, failure to follow KALORIK
instructions noted in the user’s manual, use on current or voltage
other than that stamped on the product, wear and tear, alteration
or repair not authorized by KALORIK, or use for commercial purposes.
There is no warranty for glass parts, glass containers, filter basket,
blades and agitators, and accessories in general. There is also no
warranty for parts lost by the user.
ANY WARRANTY OF MERCHANTABILITY OR FITNESS WITH RESPECT TO
THIS PROD CT IS ALSO LIMITED TO THE ONE YEAR LIMITED WARRANTY
PERIOD.
Some states do not allow limitation on how long an implied warranty
lasts or do not allow the exclusion of incidental or consequential
damages, so the above limitations may not apply to you. This
warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
12 WCL 32964 - 140728

Back cover page (last page)
Assembly page 12/32
Fax [phone]
If the appliance should become defective within the warranty
period and more than 30 days after date of purchase, do not return
the appliance to the store: often, our Customer Service
Representatives can help solve the problem without having the
product serviced. If servicing is needed, a Representative can
confirm whether the product is under warranty and direct you to the
nearest service location.
If this is the case, bring the product, or send it, postage prepaid by
the user (all Kalorik customers are responsible for the initial shipment
back to the warranty center), along with proof of purchase and a
return authorization number indicated on the outer package, given
by our Customer Service Representatives. Send to the authorized
KALORIK Service Center (please visit our website at
www.KALORIK.com or call our Customer Service Department for the
address of our authorized KALORIK Service Center).
When sending the product, please include a letter explaining the
nature of the claimed defect.
If you have additional questions, please call our Customer Service
Department (please see below for complete contact information),
Monday through Thursday from 9:00am - 5:00pm (EST) and Friday
from 9:00am - 4:00pm (EST). Please note hours are subject to change.
If you would like to write, please send your letter to:
KALORIK Customer Service Department
Team International Group of America Inc.
1400 N.W 159th Street, Suite 102
Miami Gardens, FL 33169 SA
Or call:
Toll Free: +1 888-521-TEAM / +1 888-KALORIK
Only letters can be accepted at this address above. Shipments and
packages that do not have a return authorization number will be
refused.


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
13 WCL 32964 - 140728

Back cover page (last page)
Assembly page 13/32
Fax [phone]
CONS JOS D S GURIDAD
Cuando use algún aparato eléctrico siempre deben seguirse
precauciones básicas de seguridad incluyendo las siguientes:
 Después de haber sacado la bodega de su embalaje, asegúrese
que está en buen estado. En caso de duda, no lo utilice y
contacte a un servicio cualificado competente.
 Bolsas de plástico, clavos, etc. deben mantenerse fuera del
alcance de los niños.
 Antes de utilizar el aparato, compruebe que el voltaje de la red
eléctrica coincide con el del aparato.
 No deje nunca su aparato sin vigilancia cuando esté en marcha.
 No deje el aparato sin vigilancia cuando saca bebidas o
cuando las pone en la bodega. Mantener fuera del alcance de
los niños o de personas incompetentes.
 Compruebe de vez en cuando que el aparato no esté dañado y
no utilice su aparato sí el cable o el aparato están dañados por
el motivo que sea.
 No mueva nunca el aparato estirando del cable. Procure que el
cable no se enganche en algún saliente, a fin de evitar posibles
caídas del mismo. Evite enrollar el cable alrededor del aparato y no
lo tuerza. No utilice el aparato cerca de fuentes de calor.
 tilice el aparato sólo para usos domésticos y de la manera
indicada en el modo de empleo.
 Si el cable está dañado, debe ser reemplazado por un servicio
cualificado competente(*)
 Nunca utilice su aparato cerca de fuentes de calor o a la luz del
sol.
 Nunca utilice su aparato en el exterior y siempre colóquelo en un
medio seco.
 Coloque el aparato en una mesa o una superficie estable para
evitar su caída. Asegúrese que haya al menos 10 centímetros
libres en los lados y al menos 8 centímetros en la parte trasera del
aparato para una ventilación adecuada. Los armarios deben
estar al menos a cinco centímetros del aparato para una
ventilación adecuada


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
14 WCL 32964 - 140728

Back cover page (last page)
Assembly page 14/32
Fax [phone]
 No coloque ningún objeto en la parte superior del aparato.
 No utilice alargadores.
 No utilice accesorios no recomendados por el fabricante, eso
puede ser peligroso y puede dañar el aparato.
 Conecte el aparato directamente en el enchufe, no utilice
ningún alargador o enchufes múltiples.
 Ese aparato permite almacenar botellas de vino, sin embargo, si
pone comida dentro, asegúrese de que haya aire suficiente
entre ellas.
 No coloque bebidas calientes en la bodega, sino que déjelas
resfriar previamente a la temperatura ambiente.
 Cierre la puerta de la bodega inmediatamente después de
colocar lo que sea dentro, de manera que la temperatura no
suba demasiado.
 na vez colocado o si se mueve el aparato, asegúrese que no
sea puesto horizontalmente o en un ángulo de menos de 45° o al
revés.
 Si se nota cualquier defecto en ele aparato, desenchúfelo
inmediatamente y contacte un servicio cualificado competente.
 Todas las reparaciones deben ser efectuadas por un servicio
cualificado competente.
 Para reducir el riesgo de fuego, siempre utilice el mismo tipo de
fusible.
 Desenchufe el aparato antes de limpiarlo o cuando no se utiliza.
 Para evitar que se encierre un niño, deje las parrillas tal cómo
están para que los niños no puedan ir dentro, incluso cuando el
aparato se utiliza regularmente o cuando no se utiliza en casa.
 E vite que el aparato esté expuesto directamente a la luz del sol
y a las temperaturas elevadas.
GUARD STAS INSTRUCCION S
SOLAM NT PARA USO DOM STICO


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
15 WCL 32964 - 140728

Back cover page (last page)
Assembly page 15/32
Fax [phone]
Ahorre tiempo y dinero. Antes de llamar al servicio post venta,
consulte el guía de reparaciones al final de ese manual. Describe las
causas de los problemas de funcionamiento que podría encontrar y
que puede resolver usted.
Aviso: los cambios o modificaciones hechas al aparato y que no
fueron expresamente aprobadas por el fabricante pueden impedir
que el aparato funcionara correctamente, a pesar de las
disposiciones tomadas por el utilizador para hacer funcionar el
aparato.
INSTRUCCION S PARA LA TOMA D TI RRA
Este aparato debe estar enchufado en una conexión con toma de
tierra. Ya que en caso de cortocircuito, la toma de tierra reduce el
riesgo de choque eléctrico, proporcionando una vía de escape
para la corriente eléctrico. Este aparato está equipado con un
cable que tiene un enchufe con toma de tierra. El enchufe debe
insertarse en una toma de corriente correctamente instalada.
No intente, de ninguna manera, modificar el enchufe.
DATOS T CNICOS
Volumen 65 litros
Capacidad 21 botellas de 750 ml.
Temperatura regulable 45°F - 54°F (7°C – 12°C)
(Zona superior)
Temperatura regulable 54°F - 64°F (12°C – 18°C)
(Zona inferior)
Sin CFC, sin refrigerante de gas
COLOCAR L APARATO
Para obtener los mejores resultados, utilice el marco de hierro
ajustable para poner el aparato totalmente horizontal para que
mantenga estable.
El marco ajustable se encuentra debajo de la bisagra inferior. Es más
pequeño que los marcos colocados en las otras 3 esquinas del
aparato. Se coloca en un inserto roscado en la bisagra, marcada


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
16 WCL 32964 - 140728

Back cover page (last page)
Assembly page 16/32
Fax [phone]
por una flecha en la imagen siguiente. Gire el marco hacia la
derecha o izquierda para ajustar la altura y para asegurar la
horizontalidad perfecta de la unidad.
AVISO: El aparato no debe ser integrado a gabinetes. Solo se debe
usar como una unidad independiente.
UTILIZACION
CUIDADO: Antes de conectar el aparato a la red eléctrica, déjelo tal
cual durante cuatro horas para reducir el riesgo de malo
funcionamiento del sistema de refrigeración causado por el
trasporte.
• Antes del uso, limpie el aparato cuidadosamente, especialmente
el interior (véase Limpieza y Mantenimiento).
• Si no estén bien colocados los accesorios dentro del aparato,
póngales correctamente de nuevo.
• Compruebe que el voltaje de la red eléctrica coincide con el del
aparato.
• Deje el aparato en una superficie estable y cerca de una toma
de corriente. l aparato no debe ser integrado a gabinetes!
• Conecte el aparato en una toma de corriente a la tierra.
• Los ventiladores comienzan a funcionar y la bodega empieza a
enfriar. El enfriador puede necesitar una hora y media para
llegar a la temperatura de 15 °C / 60 °F y hasta 4 horas para
llegar a la temperatura fijada en la fábrica.


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
17 WCL 32964 - 140728

Back cover page (last page)
Assembly page 17/32
Fax [phone]
NOTA: La temperatura dentro de la bodega termoeléctrica
depende de la temperatura ambiente. Para alcanzar las
temperaturas mínimas indicadas a continuación, el aparato debe
estar situado en una habitación cuya temperatura máxima es. 75 ° F
/ 25 º C.
Control de la temperatura y pantalla
La zona superior del aparato se utiliza para poner vino blanco, con
temperaturas de 45°F a 54°F (7°C a 12°C). La parte inferior se utiliza
para poner vino tinto, con temperaturas de 54°F a 64°F (12°C a
18°C).
La temperatura de la bodega va de 45°F a 64°F (7°C a 18°C).
La temperatura media por el vino tinto es entre 54°F y 64°F (12°C y
18°C).
La temperatura media por el vino blanco es entre 45°F y 54°F (7°C y
12°C).
La pantalla muestra la temperatura media del aparato en un
momento preciso.
lección manual de la temperatura
La temperatura está preajustada al salir de la fábrica. Si quiere
cambiar la temperatura, elija la zona del aparato y haga los
cambios necesarios.
La temperatura de la bodega puede programarse pulsando los
botones temperatura arriba “ P” y temperatura abajo “DOWN”.
1/ Al pulsar el botón C / F en el panel de control, seleccione si desea
visualizar la temperatura en grados Fahrenheit (F) o Celsius (C). Las
temperaturas en grados Fahrenheit son siempre el valor más alto.
2/ Hay cuatro botones en el panel de mandos. En la izquierda,
presione « P » para aumentar la temperatura o presione « DOWN»
para disminuir la temperatura en la zona superior. En la derecha,
presione « P » para aumentar la temperatura o presione « DOWN »
para disminuir la temperatura en la zona inferior.
3/Al conectar el aparato en la red, el sistema de resfrío se pone en
marcha. La temperatura está preajustada de alguna manera, lo


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
18 WCL 32964 - 140728

Back cover page (last page)
Assembly page 18/32
Fax [phone]
que significa que si la temperatura alcanza cierto punto, un sistema
automática de control de la temperatura va a parar el sistema de
resfrío y la temperatura dentro del aparato va a aumentar
progresivamente.
4/Cuando la temperatura dentro del aparato sobrepasa la
temperatura preajustada, el sistema de control automática de la
temperatura va a ponerse otra vez en marcha, lo que significa que
el aparato empieza a resfriar otra vez.
Puede encender o apagar la luz interna presionando el interruptor
situado en el panel de control.
Nota:
• Este refrigerador del vino tiene que ser colocado sobre un suelo
plano, con 2 cm / 1 pulgada de espacio a cada lado y 10 cm / 4
"de espacio en la parte trasera.
• Coloque la bodega en un lugar perfectamente nivelado para su
mejor funcionamiento.
• Evite colocarlo en un lugar donde le llegue la luz directa del sol,
cerca de una fuente de calor, o en un área sin ventilación.
• No coloque objetos pesados en la parte superior del aparato


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
19 WCL 32964 - 140728

Back cover page (last page)
Assembly page 19/32
Fax [phone]
PROBL MAS Y SOLUCION S
Problema Causa Solución posible
l refrigerador
no resfría
- Hay un problema de
electricidad.
- Voltaje demasiado
bajo
- El fusible saltó
- Compruebe que el enchufe
esté bien insertada en la
toma de corriente.
- tilice una toma de corriente
con un buen voltaje
- Compruebe el fusible de esa
toma de corriente.
La
temperatura
dentro del
aparato no es
bastante fría.
- El aparato está
colocado
demasiado cerca
de una fuente de
calor.
- La ventilación no es
suficiente.
- La ventilación no
funciona
- La puerta del
refrigerador ha sido
abierta demasiado
frecuentemente o
ha sido dejado
abierta durante
demasiado tiempo.
- Ponga el refrigerador lejos
del sol o de otras fuentes de
calor.
- Asegúrese que la ventilación
del refrigerador funcione
bien y no bloquee el
ventilador.
- Compruebe que el aparato
esté bien enchufado o
cambie el ventilador.
- Cierre la puerta
correctamente y no la abra
demasiado frecuentemente,
ni durante demasiado
tiempo.
l interior del
aparato huele
mal.
- Compruebe que no
haya nada podrido
dentro del aparato.
-
Remueva la causa del mal
olor.
La luz interna
parpadea
- La temperatura
preajustada es más
alta que la
temperatura interna
-
Ajuste la temperatura del
aparato.
Hay escarcha
en la pared
trasera interna
del aparato.
- Demasiada
humedad o
temperatura
demasiada baja
dentro del aparato.
-
Pare el aparato y
desenchúfelo. Saque la
escarcha manualmente y
vuelva a enchufar el
aparato en cuanto la
escarcha desaparezca.


Copies of the I/B. Please reproduce them without any
changes except under special instruction from Team
International BELGI M. The pages must be reproduced
and folded in order to obtain a booklet A5 (+/- 148.5 mm
width x 210 mm height). When folding, make sure you
keep the good numbering when you turn the pages of
the I/B. Don’t change the page numbering. Keep the
language integrity. Print only what is inside the frame.
20 WCL 32964 - 140728

Back cover page (last page)
Assembly page 20/32
Fax [phone]
LIMPI ZA
• Desenchufe el aparato antes de limpiarlo.
• Limpie el exterior del aparato con agua y detergente. No use
limpiadores abrasivos, ya que pueden dañar el acabado del
aparato.
• Limpie el interior del aparato con agua tibia y un poco de
vinagre o bicarbonato de sosa.
• Quite los accesorios amovibles del interior del aparato y límpielos
con agua y un detergente líquido. No ponga ninguna parte en
el lavavajillas.
• No utilice nunca objetos metálicos o productos abrasivos para
limpiar el aparato.
• No sumerja nunca el aparato en agua o en cualquier otro
líquido.
