Kamstrup OMNIPOWER User manual

Instlltion mnul
OMNIPOWER – single-phase
Kamstrup A/S · Industrivej 28, Stilling · DK-8660 Skanderborg · T: [phone] · [email protected] · kamstrup.com

2 Kmstrup A/S • 55121312_E1_GB_09.2015
OMNIPOWER – single-phase
Installation manual
Connect the meter in ccordnce with the instlltion digrm on the meter’s type lbel.
Depending on the configurtion,  fixed vlue is displyed, or the disply chnges be-
tween selected indictions every 10 seconds.
It is possible to chnge the disply reding mnully by ctivting the push button on the
meter. The vilble redings depend on the meter’s configurtion.
Security and installation guidelines
The meter is only to be used for mesuring electricl energy nd shll operte within the
specified vlues only.
The meter must be disconnected when working on it. It cn be highly dngerous to touch
the meter prts when the meter is switched on.
Therefore, the relevnt security fuse must be removed nd kept in  plce where it cn-
not be inserted by unuthorized persons.
Current locl stndrds, guidelines, regultions nd instructions must be observed. Only
uthorized personnel is permitted to instll electricity meters.
Meters for direct connection must be protected ginst short circuit by  security fuse in
ccordnce with the mximum current stted on the meter.
Filing to obey the ”Guidelines for sfety nd instlltion”, the gurntee no longer p-
plies.

3Kmstrup A/S • 55121312_E1_GB_09.2015
OMNIPOWER – single-phase
Installation manual
LCD disply
Opticl interfce
LED (meter constnt)
LED breker sttus
(only meters with
internl breker)
Utility sels
Type lbel
Secondry module
Push button
Selble push button
The meter constnt LED blinks proportionlly to the consumed ctive energy.
Only uthorized personnel my brek the utility seling.

4 Kmstrup A/S • 55121312_E1_GB_09.2015
OMNIPOWER – single-phase
Installation manual
The phse indictions hve vrious functions. They indicte the two situtions described
below.
From the connection of the meter:
Indications L1 Indicate
On Voltge is bove minimum limit (160V))
Off Voltge is below minimum limit (160V)
Indications Indicate
On Lod is bove minimum limit (2.3W)
Off Lod is below minimum limit (2.3W)
If the lod exceeds the minimum limit nd the meter is configured with this reding, con-
sumption will be indicted vi the qudrnt reding. The direction of the phse current is
lso indicted by the rrow of L1, regrdless of configurtion.
7-digit identifiction field
Qudrnt indiction
Module indiction Text field
Unit field
Breker symbol
Tmper symbol
Triff indiction
Rdio network symbol
Error symbol
9-digit vlue field
Phse current indiction
Prepyment symbol
Supply voltge indiction

5Kmstrup A/S • 55121312_E1_GB_09.2015
OMNIPOWER – single-phase
Installation manual
Terminals OMNIPOWER OMNIPOWER ST-meter
Multi-core 7-core Mssive / terminls Multi-
core
7-core
35 mm2≥ 6 mm2≥ 6 mm2≥ 2.5 mm2> 6 mm2 > 6 mm2
Screw: Pz 2 or stright slot Screw: Pz 2 or stright slot
Torch: 2.5 – 3 Nm Torch: 3 – 3.5 Nm
Load control, installation
For meters with lod control rely(s). Due to the dely in the meter, it is importnt to re-
strt the meter (off/on) when the time is set correctly in the meter. This plces the relys
in the correct position nd stops the dely timer.
With built-in radio
If the meter is supplied with integrl rdio for estblishment of remote reding, the meter
utomticlly strts to connect to  rdio network. The integrl rdio is equipped with n
internl ntenn. The rdio signl strength cn be red vi the system. If the rdio signl
is not sufficient, n externl ntenn must be connected. Plese see current documen-
ttion on vilble ntenns.
Mounting  communiction module in the meter my influence the rdio communic-
tion. Plese contct Kmstrup A/S.
With disconnect function
With this type of meter, it must be checked tht the red diode is switched off. This indi-
ctes tht the consumer’s supply is disconnected.

6 Kmstrup A/S • 55121312_E1_GB_09.2015
OMNIPOWER – single-phase
Installation manual
Installation dimensions
OMNIPOWER OMNIPOWER ST
237,7
81,6
128,7
177,7
81,6
81.6
177.7
237,7
81,6
128,7
177,7
81,6
237,7
81,6
128,7
177,7
81,6
81.6
237.7
128.7
128,7
233,6
81,6
174,7
81,6
128.7
81.6
81.6
233.6
174.7
Connection diagrams
The vlid connection digrm ppers from the type lbel.
OMNIPOWER OMNIPOWER ST
123456
L1
N
S0 +
20
-
21
P+
N
1
L
325 46
N
L
Main Load
S0 +
20
-
21
P+

7Kmstrup A/S • 55121312_E1_GB_09.2015
OMNIPOWER – single-phase
Connection diagram for modules
Tilslutningsskema for moduler (DK)
Connection diagram for modules (GB)
Anschlussschema für Module (DE)
Schéma de raccordement pour modules (FR)
Serial
63
64 GND
REQ
62 DATA
Pulse in/tariff 1+2/max reset
M-Bus network
25
24 M-Bus
230 VAC relay output for Load Control
Current loop
+
÷
32/144
33/145
230V supply
65
66
+
÷
Red/brown 2
Blue 11
3 System, 4 wire
Red/brown 2
Blue 8
3 System, 3 wire
Tariff 1+2
230 V
13 15
Tariff 3+4
230 V
15 33
18
19
RS-485
137 TX- / RX-
138 TX+ / RX+
17/17A NC
18/18A Common
19/19A NO
LON-Bus
55
56
LON 1/A
LON 2/B
Pulse out relay
A+
140
141
A-/R+
142
143
SO-supply
A+
40
41
+
÷

8 Kmstrup A/S • 55121312_E1_GB_09.2015
OMNIPOWER – single-phase
