Kanguru Defender KDH3B User manual

Kanguru Defender
HDD / SSD
User Manual
Copyright 2013, All Rights Reserved
Model no:
KDH3B, KDH3B-SSD

2
NOTICES AND INFORMATION
Please be aware of the following points before using your Kanguru Defender
Copyright © 2013 Kanguru Solutions. All rights reserved.
Windows 2000®, Windows XP®, Windows Vista®, Windows 7® and Windows 8® are registered
trademarks of Microsoft Inc. All other brands or product names are trademarks of their respective
companies or organizations.
Kanguru Solutions will not be held responsible for any illegal use of this product nor any losses incurred
while using this product. The user is solely responsible for the copyright laws, and is fully responsible
for any illegal actions taken.
Customer Service
To obtain service or technical support for your system, please contact Kanguru Solutions Technical
Support Department at 508-376-4245, or visit www.Kanguru.com for web support.
Legal notice
In no event shall Kanguru Solutions’ liability exceed the price paid for the product from direct, indirect,
special, incidental, or consequential software, or its documentation. Kanguru Solutions offers no refunds
for its products. Kanguru Solutions makes no warranty or representation, expressed, implied, or statutory,
with respect to its products or the contents or use of this documentation and all accompanying software,
and specifically disclaims its quality, performance, merchantability, or fitness for any particular purpose.
Kanguru Solutions reserves the right to revise or update its products, software, or documentation without
obligation to notify any individual or entity.
Export Law Compliance
Regardless of any disclosure made to Kanguru Solutions pertaining to the ultimate destination of the
specific Kanguru product, you warrant that you will not export, directly or indirectly, any Kanguru
product without first obtaining the approval of Kanguru Solutions and the appropriate export license from
the Department of Commerce or other agency of the United States Government. Kanguru Solutions has
a wide range of products and each product family has different license requirements relative to exports.
Defragmenting Flash Memory Warning
Do not attempt to defragment a Kanguru Defender Solid State Drive. Flash memory does not need to be
defragmented and does not gain any performance by doing so. Defragmenting your solid state drive can
actually degrade the flash memory which may reduce the drive’s total capacity and lifespan.
Notices and Information

3
Table of Contents
Table of Contents
1. Introduction ...............................................................................................................4
1.1 Package Contents..................................................................................................4
1.2 System Requirements ...........................................................................................4
1.3 Features.................................................................................................................5
1.4 Technical Specifications .......................................................................................6
2. General Operation ....................................................................................................7
2.1 Parts and Functions...............................................................................................7
2.2 Hardware Setup ....................................................................................................8
3. Kanguru Defender Manager ....................................................................................9
3.1 Running KDM ......................................................................................................9
3.2 The Setup Wizard .................................................................................................11
3.2.1 Selecting a Setup Language........................................................................11
3.2.2 Resetting the Device through the Setup Wizard .........................................12
3.2.3 Activating On-board Antivirus Protection ..................................................13
3.2.4 Setting a Password ......................................................................................14
3.2.5 KRMC Cloud..............................................................................................15
3.2.6 Contact Info ................................................................................................16
3.3 Unlocking the Security Partition ..........................................................................17
3.3.1 Resetting from the Login Screen ................................................................18
3.4 Using the Virtual Keyboard to Enter Your Password ...........................................19
3.5 Encrypting Files and Folders................................................................................20
3.6 On-board Antivirus...............................................................................................21
3.6.1 Device Scan ................................................................................................22
3.6.2 Path Scan.....................................................................................................23
3.6.3 File Scan......................................................................................................24
3.7 Changing Your Password......................................................................................25
3.8 KRMC Cloud Settings .........................................................................................26
3.9 Changing Languages ............................................................................................27
3.10 Online Documentation........................................................................................28
3.11 About KDM ........................................................................................................28
4. Updating Your Defender HDD.................................................................................29
4.1 Updating standard edition drives..........................................................................29
4.2 Updating KRMC enterprise edition drives...........................................................29
4.3 Verifying the download checksum........................................................................30
5. Safely Removing Your Kanguru Defender .............................................................31
5.1 Unmounting Your Defender .................................................................................31
5.2 Safely Removing from Windows .........................................................................32
6. Warranty Information..............................................................................................33
7. Tech Support..............................................................................................................33
Appendix A - Proxy Support ...............................................................................................34
Appendix B - Windows XP Settings ...................................................................................35

4
Introduction / Package Contents / System Requirements
1. Introduction
The Kanguru Defender is a hardware encrypted, tamper proof drive. The Defender contains two
partitions: a read-only, CD-ROM partition and a secure, encrypted partition. The CD-ROM partition
contains the login application that will allow you to access the secured partition.The secure partition is
where you store your data.
The Kanguru Defender drive secures your important data through:
• 256-bit AES hardware encryption (XTS-mode)
• Secure password protection
1.1 Package Contents
Please check the contents of the package you received. If any of the parts listed below are missing, please
contact Kanguru Solutions (508-376-4245) and you will be shipped replacement parts immediately.
• Kanguru Defender Drive
• USB3.0 Cable
• Carry pouch
• Quick Start Guide
• Registration Form
1.2 System Requirements
• 1 Available USB port (USB 3.0 recommended)
• 256MB of internal DDR RAM (1GB or higher recommended)
• 500MHz internal CPU (1GHz or faster recommended)
• Supported operating system (32 and 64 bit compatible)
○Windows 2000 SP 4, Windows XP SP 3, Windows Server 2003, Win Vista, Win 7, Win 8
Note: Windows XP requires a few modifications that need to be made by a user with administrator
privileges in order to use this device properly. See Appendix B: Windows XP Settings on page 33
for more details.

5
Features / Remote Management Capability
1.3 Features
√256-bit AES hardware encryption (XTS-mode)
√Password protected data partition for your secure files
√Does NOT require Admin privileges
√Driverless installation (Plug & Play)
√High-strength aluminum housing
√Tamper-proof design
√Water resistant
√On-board antivirus protection
Remote Management Capability
Kanguru Defender drives can be remotely managed using the Kanguru Remote Management Console
(KRMC). KRMC is a web-based application that gives administrators a complete USB management
system. KRMC is available in two different options: Customer hosted enterprise version or a Kanguru
hosted Cloud version. Please contact Kanguru Solutions if you have any questions about which option
would be the best fit for your organization.
With KRMC you will be able to:
√Create and manage a master password for your Defenders
√Remotely delete all data on a target drive
√Schedule actions for present or future times
√Audit at administrator and super administrator level
√Locate devices via IP address (IP Address / network location)
√Locate devices via hostname
√Create remote policy modifications like:
○Password strength and length (e.g. 10 characters: 2 upper, 2 numbers, etc)
○Limit invalid login attempts (e.g. 3 retries before drive is wiped)
○Rate at which password should be changed (e.g. every 30, 60, or 90 days)
○Change user password
○Change master password
√Create user groups
Your Kanguru Defender does not come with KRMC enabled by default.
For more information about KRMC, visit: https://www.kanguru.com/index.php/flash-management

6
1.4 Technical Specifications
General Specifications
Interface USB3.0 5Gbps (backwards compatible with USB2.0)
Encryption Features Hardware based 256-bit AES encryption (XTS-mode)
Drive interface SATA II 3Gbps
Operating Temp 32°F ~ 158°F (0°C – 70°C)
Dimensions 5.5” x 3.5” x 1”
Kanguru Defender HDD
Capacities1250GB, 500GB, 1TB
Rotation Speed 5400
Cache Size 8MB
Reliability 750,000 hrs
Access Time 8.5 - 11ms
Weight 10.3 oz
Kanguru Defender SSD
Capacities1128GB, 256GB
Write Cycles 10,000 write cycles / block
Mean Time Between Failure 1,000,000 hours
Access Time 0.4ms
Weight 9.6 oz
1Kanguru Solutions defines a gigabyte (GB) as 1,000,000,000 bytes.
Technical Specifications

7
2. General Operation
This chapter contains information on how to use your Kanguru Defender. Please read these sections
carefully.
2.1 Parts and Functions
Activity Indicator LED
Power Indicator LED
USB A
USB Micro-B
USB Cable
General Operation / Parts and Functions
USB Cover

8
2.2 Hardware Setup
Follow these instructions to connect the Defender drive to your computer:
1. Remove the USB cable from the side of the Defender. The easiest way to release the cable is by
pulling out the USB A side first, as shown in the image below.
2. On the other side of the drive, pull open the rubber USB cover to reveal the USB port.
3. Connect the Micro B side of the USB cable to the Defender’s USB port. Connect the A side of the
USB cable to your computer. The LED indicators on the side of the drive will light up. You are now
ready to begin using your Kanguru Defender drive.
↓
↓
USB A
to computer
USB Micro-B
to drive
Hardware Setup
↓

9
3. Kanguru Defender Manager
Kanguru Defender Manager (referred to throughout this manual as “KDM”) is the client program
preloaded on the Defender’s CD-ROM partition. The user needs to login to KDM in order to access the
secure, encrypted partition. KDM comes pre-installed on your Defender drive. No installation on your
PC is necessary.
3.1 Running KDM
To run KDM from a Windows operating system, simply connect your Defender drive to your computer
through a USB port. The KDM application should start automatically if Autorun is enabled.
If KDM does not start automatically:
1. Open My Computer and open the Defender’s CD-ROM partition. The drive letter (e.g. D:, E:, F:)
will depend on your computer.
2. Double-click on the KDM.exe file to launch the KDM application.
If it is your first time running KDM you will need to complete the setup wizard in order to set your
security password (see section 3.2 The Setup Wizard on page 11). If you have already setup your
security password, you will be prompted to login (see section 3.3 Unlocking the Security Partition on
page 17)
Caution! The KDM.exe file needs to remain on your Defender’s CD-ROM partition at all times. Always
run the application from the Defender’s CD-ROM partition. Do not try to copy KDM.exe or run KDM.
exe from your computer’s hard drive.
Note: Windows 7 users may not see the removable disk partition until you have logged into KDM. If
you are running Windows 7 and for any reason need to see the removable disk before you log into KDM
please refer to the instructions on p.10.
Kanguru Defender Manager / Running KDM

10
Attention Windows 7 Users
Windows 7 users may not see the removable disk partition until you have logged into KDM. This is
normal.
If you are running Windows 7 and for any reason need to see the removable disk before you log into
KDM, you will need to configure Windows in the following manner:
Note: This is user preference only. There is no need to configure Windows in order to use your Defender.
1. From My Computer, click on the Organize menu and then select Folder and search options.
2. The Folder Options window appears. Scroll down to the option for “Hidden Files and Folders” and
select Show hidden files, folders, and drives.
3. Click on the OK button to finish configuring Windows. The removable disk is now visible before
you log into KDM.
Running KDM

11
3.2 The Setup Wizard
When you start KDM for the first time you will be greeted by the Setup Wizard. Follow the Setup Wizard
instructions to create a security password for your Defender’s secure, encrypted partition.
Caution! Once the Setup Wizard has started, you should not disconnect your Defender without either
first completing the Setup Wizard or closing the Setup Wizard by clicking on the X button.
3.2.1 Selecting a Setup Language
The default language for the Setup Wizard is set to English. To run the Setup Wizard in a different
language:
1. From the Start screen, click on the icon next to the Language Menu.
2. A list of available languages will appear in a drop down menu. Select your desired language from
the drop down menu. The Setup Wizard will switch to the new language.
3. Click on the Next button to continue to the next step.
The Setup Wizard / Selecting a Setup Language

12
3.2.2 Resetting the Device through the Setup Wizard
If you experience any problems while completing the Setup Wizard, you may have to perform a device
reset before you can complete the setup process.
To perform a device reset while in the Setup Wizard:
1. From anywhere in the Setup Wizard, click on the Prev button until you return to the Start Screen.
2. On the Start Screen you will see a Reset button in the bottom-left corner of the application window.
Click on the Reset button.
3. A dialog box appears asking you to confirm the reset. Click on Ye s to reset your device to the
factory default settings.
After the device has been reset to the factory default setting you will be required to restart the Setup
Wizard.
Resetting the Device through the Setup Wizard

13
3.2.3 Activating On-board Antivirus Protection
Note: This section does not apply to Enterprise Edition users. Antivirus for Enterprise Edition is activated
through Kanguru Remote Management Console (KRMC). Enterprise Edition users, please contact your
administrator.
KDM will automatically check if your device has a valid antivirus license key.
Note: Your Defender will need to be connected to a computer with internet access in order to register
for on-board antivirus protection.
If your Defender does not already have a valid antivirus license key, then you must fill out the following
registration form with the required information and then click on the Apply button in order to activate
your one (1) year of free antivirus protection.
Click on the Skip button if you do not wish to activate antivirus protection.
Important! If you decide to skip activating your antivirus now, you will not be able to activate it in the
future without first resetting your drive to the factory default setting.
Click on the Next button to continue with setting up your Defender’s security password.
Activating On-board Antivirus Protection

14
3.2.4 Setting a Password
From the Set Password screen:
1. Enter your password in the Password data field. You can enter your password using KDM’s Virtual
Keyboard by clicking the VK button. For more information on using the Virtual Keyboard see
section 3.4 Using the Virtual Keyboard to Enter Your Password on page 19.
Note: For security reasons, it is recommended that you incorporate letters, numbers and symbols
to achieve maximum security.
2. Enter the same password in the Confirm Password field for verification. If your passwords do not
match or there is any other issue with the password which you have entered in the Set Password
section, an explanation will be visible in the Password Info window.
Note: The Password Info window will inform you if there are any password requirements. It
updates in real time. Disregard the messages in the Password Info box until you have finished
entering your password into both the Password and Confirm Password fields.
3. Click on the Apply button to set your password. Once the password has been set, you will see the
following message in the Password Info box:
4. Click the Next button and KDM will begin configuring the security parameters.
Note: If you are managing your Defender with an administrative program like KLA or KRMC, you can
set a Master Password which can be used to reset the user password if it is lost or forgotten.
Setting a Password

15
3.2.5 KRMC Cloud
Note: This section does not apply to Enterprise Edition users.
Kanguru Defender drives can be remotely managed using the Kanguru Remote Management Console
(KRMC). KRMC Cloud is hosted on Kanguru’s server and can be enabled on any non-Enterprise
Defender drive.
To Enable KRMC Cloud functionality:
1. Select the Enable KRMC Cloud option and then click on the Apply button.
2. A dialog box will appear asking if you want to register your device with KRMC Cloud. Click on
the Yes button.
3. Your web browser will open and direct you to the KRMC Cloud login page.
4. Purchase a license for your drive in order to use it with KRMC Cloud.
If you choose not to remotely manage your Defender using KRMC Cloud, select the Disable KRMC
Cloud option and then click on the Apply button. Important! You will not be able to enable KRMC
Cloud functionality again, unless you reset your drive to the factory default.
Click on the Next button to continue setting up your drive.
KRMC Cloud

16
3.2.6 Contact Info
Note: This section does not apply to Enterprise Edition users.
Your contact info will be saved to the drive. If you are managing your drive using KRMC Cloud, the
information entered here will be automatically be imported to the KRMC Cloud server when you register
your drive.
Fill in your information in the appropriate fields and then click on the Apply button. A window will
appear confirming that your data has been saved. Click on the OK button to close the window and then
click on the Next button to finish setting up your drive.
Congratulations! Your Defender’s secure, encrypted partition is now ready to use.
Contact Info

17
3.3 Unlocking the Security Partition
After you have set a password you will be asked to login using your security password every time you
run KDM. You need to provide the correct password in order to access the Defender’s secure partition.
When the login screen appears:
1. Enter your password in the Password field.
2. Click on the Login button.
Caution! If you exceed the number of allowed incorrect password entries (6 entries is the default setting,
but this may be different depending on your setup), for security purposes any data stored on the secure
partition will automatically be erased. You will be issued an on-screen warning when you have one
attempt remaining, to prevent accidental erasure. To cancel the login process, click on the Cancel button.
Unplugging and then reinserting your Defender or manually running KDM.exe will bring the login
window back.
Once you have successfully logged in to KDM, the Defender’s secure partition will be accessible through
My Computer or Windows Explorer. For more information on accessing the secure partition, see section
3.5 Encrypting Files and Folders on page 20.
Caution! Once KDM has started, you should never disconnect your device without first closing the
KDM application by clicking the KDM task bar icon and selecting Unmount Kanguru Defender as
described in section 5.1 Unmounting Your Defender on page 31.
Note: If your Defender drive is being managed by KRMC, you may see an Autorun checkbox. This
means that your administrator has configured your drive to auto-execute a file saved on your drive’s secure
partition every time you successfully login. You can disable the Autorun functionality by unchecking
this box.
Unlocking the Security Partition

18
3.3.1 Resetting from the Login Screen
In the event you have forgotten your password, you can use the ‘Reset to Factory Default’ function
to reset your password. This function will restore the device to the factory settings, erasing all saved
passwords and data residing on the device’s secure partition.
Caution! Using the ‘Reset to Factory Default’ function will format and wipe all data off the secure
partition ! All personal data on the device will be lost!
To reset your Defender to the factory default:
1. Start KDM.
2. When the login screen appears, click on the Reset button.
3. When you are prompted to confirm the reset, click on the Yes button.
4. When your password and data stored on the secure partition have been erased, the following
message will appear. Click on the OK button to complete the reset.
The next time you run KDM, you will have to complete the Setup Wizard again before you are able to
access the secure partition. Please see section 3.2 The Setup Wizard on page 11 for instructions on
completing the Setup Wizard.
Resetting from the Login Screen

19
3.4 Using the Virtual Keyboard to Enter Your Password
The virtual keyboard feature can be accessed anytime you are required to enter your password in order to
prevent key logging applications from recording your key strokes and potentially stealing your password.
To use the virtual keyboard to enter your password:
1. Click on VK button which is located near the password entry field.
2. The virtual keyboard will appear below the Setup Wizard window. Click on the keys on the virtual
keyboard to enter your password.
3. Click on the VK button again to close the virtual keyboard.
Note: You can click on the Shuffle key located at the bottom, right-hand corner of the virtual keyboard
to randomize the virtual keyboard layout. Shuffling the keyboard layout protects your password from
mouse tracking applications designed to thwart virtual keyboards.
Using the Virtual Keyboard to Enter Your Password

20
3.5 Encrypting Files and Folders
A key feature of the Defender is drag & drop encryption; allowing you to simply drag files directly onto
the drive. The Defender automatically encrypts these files as they are transferred to the secure partition,
ensuring that your data stays safe and private.
To open the secure partition:
1. Start KDM.
2. Login to KDM to gain access to the secure partition.
3. Click on the KDM icon located in the task bar and then select Explore Security Drive from
the popup menu.
The Defender’s security partition opens in a new window.
We recommend using either the drag & drop action, right-click copy/paste action, or the shortcut keys
(Ctrl+C and Ctrl+V) to copy and paste files and folders directly to and from the secure partition.
Note: Data saved on the Defender’s secure partition are only accessible after you have successfully
logged into KDM.
Encrypting Files and Folders
