Quick Start Guide
1. Unpack monitor and check supplied components are correct
2. Insert Battery (see section 3.0)
3. Insert Sensor
4. When new, plug in the power adaptor and turn on your monitor
(with sensor head installed) for 24hrs. Note: The battery requires
15hrs from full discharge. The sensor requires a run in period.
Thereafter, the normal warm up takes only 10 minutes. If your unit
is new or unused for a long period, a warm up message may dis-
play for several hours, then will disappear.
5. Follow the operating instructions to understand how to make the
most of your monitor
Warning:
•Do not expose the monitor to gas concentrations above the recommended
maximum range
•Do not place the sensor head in a gas stream – the monitor is designed to
measure ambient levels of ozone and uses ‘active sampling’ to achieve this.
1. Sensor Head
2. Power and Stand By
3. Display
4. Enter
5. Battery case. For battery installation, see
section 3.0 of your user guide
ZERO CAL: Please refer to section 4.5 of your user guide when using this
option, as this can uncalibrate your unit if performed incorrectly
CONC UNIT: To change the units of measurement, use the power key,
then press to return to the main menu. See section 4.6 of your user
guide for more information
MAX / MIN AV: To adjust the max / min av, press to alternate between
start and stop. See section 4.7 of your user guide for more information
EXIT
ZERO CAL
CONC UNIT
MAX MIN AV
netzerotools.com
netzerotools.com

2
Contents
1.0 Monitor Components 3
2.0 About Your Monitor 4
3.0 Assembly and Installation 5
3.1 Battery pack 5
3.2 Sensor warm up 8
3.3 Monitor and Sensor Versions 8
4.0 Operating Instructions 9
4.1 Turning the Monitor on and off 9
4.2 Operating under battery power 10
4.3 Sensor Head Failure 10
4.4 Using the Menus & Key Functions 11
4.5 Zero Calibration 11
4.6 Changing Unit of Measurement 12
4.7 Max Min Average Measurement Cycle 12
4.8 Alarm Mute (Perc only) 13
4.9 Alarm (Perc only) 13
4.10 Alarm Level (Perc only) 14
5.0 Troubleshooting 15
6.0 Specifications 17
7.0 Drawings 18
8.0 Care and Maintenance 18
9.0 For Your Safety 20
10.0 Statements of Compliance 21
11.0 Warranty 22
12.0 Copyright 24
13.0 Guidelines on how to measure ozone 25
14.0 Zero calibration additional information 26
15.0 Sensors and accessories 27
08.11.2010 V1.1
netzerotools.com
netzerotools.com

3
1.0 Monitor Components
Series 200 Monitor
The following components are supplied with the Series 200
Monitor:
•Series 200 monitor base
•Gas sensor head
•12 VDC 800 mA AC/DC adaptor
•User guide
•Battery pack – 9.6 V
Please check that all these components have been supplied and
contact your dealer if anyof the components aremissing.
Replacements
Replacement batteries, sensor heads and other accessories can be
purchased separately.
Note:
All sensors deteriorate over time. It will be necessary to replace your
sensor head with either a new or refurbished head. This must be
done on a scheduled basis or when the “sensor aging” or sensor
failure” diagnostic appears. Bump tests, zero and span calibration
can be performed under specified conditions with appropriate tools.
netzerotools.com
netzerotools.com

4
2.0 About Your Monitor
The Aeroqual Series 200 Monitor has been specifically designed to
incorporate Aeroqual’s in-depth knowledge of accurate ambient gas
measurement. Different sensor heads are used for specific gases or
depending upon whether high or low concentrations are to be meas-
ured. The all sensor heads are interchangeable on the same base unit.
The following information details the operation and features of the moni-
tor:
1. The monitor is modular in design and is comprised of two main
components, a Series 200 monitor and a sensor head. This affords
the user the ability to replace faulty sensor heads without having to
replace the monitor. The monitor can be mains and/or battery pow-
ered and either permanently mounted or used as a portable unit.
2. The Aeroqual Series 200 Monitor comes with in-built diagnostics,
which will inform the user if the sensor is not operating correctly.
3. An audible alarm is available with perchloroethylene sensors only.
Both temporary and permanent mute functions are also included
with the audible alarm.
4. Concentration unit selection. The concentration can be displayed
in either ppm or mg/m3.
5. Min / max / average measurement cycle. The monitor will display
the minimum, maximum, average and 15-minute average gas con-
centrations over the measurement period.
netzerotools.com
netzerotools.com

5
3.0 Assembly and Installation
Assembly
The following needs to be completed before the Monitor is ready
for use: -
•Insert the sensor head into the top of the monitor. The sen-
sor head is keyed to ensure the head is inserted correctly.
•If the monitor is a mains only unit it is ready for use. If the
monitor is to be used as a portable unit with batteries then
the batteries must be installed and charged prior to use.
3.1 Battery Pack
•Remove the battery cover from
the monitor.
•Insert the battery power connector
into the monitor power socket in
the back of the monitor.
•Lay the battery cable into the slot
on
the back of the monitor and insert
the tail end of the battery pack into
the hinge points at the bottom of
the monitor back cover.
•Clip the top end of the battery pack
into the top clips, taking note to
orientate the battery pack per the
instructions on the battery pack.
•Replace the battery cover on the
monitor.
netzerotools.com
netzerotools.com

6
Removing the Battery Pack
•Remove the battery cover from the monitor.
•Insert your thumb under the top left hand side of the battery
pack and carefully lever the battery pack out from the retain-
ing clips.
•Unclip the connector from the monitor.
•Replace the battery cover.
Rechargeable Batteries
The optional Ni-MH (Nickel Metal Hydride) battery pack is used to
power the monitor as a portable unit. Please read the following infor-
mation carefully before using the battery pack to operate the Aero-
qual monitor.
Safety
•Do not use the battery pack for any other purpose than oper-
ating the Aeroqual monitor
•Do not disassemble or mutilate the batteries as this may
cause burns
•Do not incinerate or heat as this may cause burns, the batter-
ies may burst or cause the release of toxic materials
•Do not short circuit as this may cause burns
•Use only batteries approved by Aeroqual and recharge your
battery only with the AC/DC adaptors supplied by Aeroqual.
•Never use any charger or battery that is damaged or worn
out.
•Batteries must be recycled or disposed of properly. They
must not be disposed of in municipal waste.
•Never charge a Ni-MH in a hermitically sealed container.
Using the battery pack
The life of the battery pack will be affected by the way it is handled.
Take good care of the battery pack and follow the guidelines sug-
gested in the following section.
netzerotools.com
netzerotools.com

7
Charging and Discharging the Batteries
New Ni-MH batteries must be fully charged prior to use. A new Ni-
MH battery's full performance is achieved only after a number of
complete charge and discharge cycles. A fully charged battery will
run for approximately 4-5 hours. (Note: Perc sensor heads require
more power and will run for a shorter time)
Charging Instructions
1) Plug in the adaptor
2) Turn the monitor on
3) Allow 15 hours for the battery to fully charge.
Note:
•During charging the battery symbol on the display flashes
slowly.
•The battery can be charged with the sensor head installed or
removed from the base. (Remember to switch off the monitor
before removing the sensor head).
•Unplugging the main power will reset the above charging condi-
tions.
•The batteries can be charged and discharged many times but
will eventually wear out. When the operating time is noticeably
shorter than normal, it is time to replace the batteries.
•It is not necessary to fully discharge the batteries. When not
using the Series 200 Monitor as a portable unit, always plug in
the mains adaptor to recharge the batteries with the monitor
switched on.
•If left unused a fully charged battery will discharge itself over
time.
Note:
If you have difficulty charging the battery, either:
A) Replace the battery
B) Contact Aeroqual with the software version number
(see section 3.3 to locate the version number.)
netzerotools.com
netzerotools.com

8
Installing the AC/DC adaptor
•Connect the AC/DC adaptor to the mains supply. Ensure that
the adaptor is correctly rated for the power supply.
•Plug the adaptor into the monitor. The monitor can now be
used as a mains unit. If the monitor is to be used as a port-
able unit the batteries will need to be charged.
3.2 Sensor warm up
Prior to operation the monitor must be warmed up to burn off
contaminants on the sensor. When the monitor is first switched
on it will warm up for 3 minutes. Then the reading will flash for
the next 7 minutes to indicate that the sensor is still in the warm
up phase. It is recommended that the monitor is kept in Stand By
mode when not being used to keep the sensor heated and
prevent the build up of contaminants. If the sensor is new (or
unused for long periods) it can take up to 24 hours for the
message “sensor warming up” (or “sensor failure” in older
models) to disappear. Should the message remain after this time,
agenuine sensor failure may have occurred. See the trouble-
shooting guide.
Since O3 is an oxidising gas the warm up period can be reduced
by subjecting the sensor to elevated O3 levels for a short period.
For example, 100 ppb of O3 for 5 minutes typically reduces the
warm up time to 30 minutes.
24hrs is a conservative time for an ozone sensor to burn off con-
taminants and achieve its stated performance specification. In
most instances this will be achieved well within 24hrs.
Warning: Do not remove the sensor head while the monitor
is switched on. This may damage the unit. If the sensor head is
removed under these conditions, the unit will automatically shut
down.
3.3 Monitor and Sensor Versions
Turning the monitor on will display “AEROQUAL MONITOR
Vx.x”, where "V x.x" represents the version of the monitor
base. The display will then show “SVXX”which indicates the soft-
ware version installed on the sensor head.
netzerotools.com
netzerotools.com

9
4.0 Operating Instructions
The following instructions detail the operation and set up of the
monitor.
4.1 Turning the monitor on and off
To turn the monitor on, press & hold the power button until
the screen activates.The monitor will turn on and the display
will show “AEROQUAL MONITOR S200 / S205 Vx.x”,.After 5
seconds the display will change to indicate the type of sensor
head. The monitor will warm up as described in “Warm up”
in section 3.2. Once warm up is complete the main display will
appear (for example):
To turn the monitor off, press and hold the power button for
2seconds until the monitor beeps.The display will now be
blank and operation of the monitor will cease.
Power
button
Enter
Key
O3 LOW
0.009
ppm
Note:
The number of decimal
places shown will vary de-
pending on the sensor head
type
netzerotools.com
netzerotools.com

10
Turning Standby Mode on and off
To activate Standby Mode with the monitor on, press the power
button once.This will stop operation of the monitor; however the
sensor will be kept warm. This mode is used to conserve power
between operations but keep the sensor ready to measure the
gas concentration with only a short warm up phase as described
in “Warm up” in section 3.2. In this mode the display will be as
shown below:
To return the monitor to operational mode press the power but-
ton once.
NOTE: When using a Carbon Dioxide sensor head in
standby mode, the sensor runs at full power and the fan
remains on.
4.2 Operating under Battery power
Abattery indicator will appear at the bottom of the display when
the monitor is operating under battery power only. The indicator
shows the battery life remaining.
4.3 Sensor Head Failure
There are two possible Sensor failure modes, which will be
indicated by one of the following messages on the display: -
“Sensor Failure, Replace sensor” – The sensor head should
be replaced as this indicates that there has been component
failure.
“Sensor aging”:-This indicates that the sensor has reached
the end of its usable life and the sensor head should be replaced
as soon as possible. The measurement readings can no longer
be relied upon to be within specification.
O3 LOW
0.080 ppm
NH3
netzerotools.com
netzerotools.com

11
4.4 Using the Menus and Key Functions
To enter the setup menu press The following menus will
appear: -
Normal Menu Special Perc Menu
Press or to scroll to the desired menu.
4.5 Zero Calibration
The “ZERO CAL” routine resets the zero point of the monitor.
"ZERO CAL" must be carried out under carefully controlled
conditions, as specified below.
Minimum 24 hours warm up
Clean air (charcoal filtered is best), no cross-sensitive gases
Stable and low air flow around the monitor
No vibration or movement of the monitor
Temperature at 20°C ± 2°C(68°F ± 3.5°F)
Relative Humidity of 50% ± 5%
An incorrect "ZERO CAL" does not cause permanent damage.
The process should be repeated under the above conditions.
NOTE: Carbon Dioxide sensors MUST be calibrated in a cer-
tified Zero Air environment. If in doubt contact Aeroqual
Limited.
Press and hold until the word GO appears next to Reset
Routine. The routine will run for up to ten minutes (depending on
the gas sensor installed) and then beep to indicate completion.
Talk to your supplier or distributor if you have questions.
Press to scroll down to the next menu choice.
•See section 13.0 for more information
EXIT
ZERO CAL
CONC UNIT
MIN MAX AV
EXIT
ZERO CAL
CONC UNIT
MIN MAX AV
ALARM MUTE
ALARM
ALARM LEVEL
netzerotools.com
netzerotools.com

12
4.6 Changing Unit Of Measurement (Concentration Unit)
To enter the ‘CONC UNIT’ menu press . The unit display
will appear.
Press to scroll between ‘ppm’ or ‘mg/m3’
Press to confirm the unit selection
Press to scroll down to the next Menu choice
4.7 The Max/Min/Average Measurement Cycle
Pressing starts the Min Max Av routine
Press to scroll to ‘EXIT’
Press to Exit out of Menu Setup.
The following display will appear:-
.
Repeat the above sequence to stop the Min Max Av routine.
Note:
The MIN, MAX and AVE readings are the minimum, maximum
and average readings over the period from the start of the cycle.
The ST value is the average over the last 15 minutes
OZONE UNIT:
ppm (or)
mg/m3
O3 LOW
MIN
0 005
MAX
0 024
AV 0 015
VOC
MIN 5
MAX 25
AV 15
ST 17
ppm ppm
0.008 18
netzerotools.com
netzerotools.com

13
4.8 ALARM MUTE (for PERC only)
Note: With “Alarm Mute ON” (enabled) the alarm condition will be
muted only until the gas concentration drops below the alarm
level – remember this is a temporary mute function.
To enter the “ALARM MUTE” menu press and the following
screen will appear: -
Press to toggle between “ALARM MUTE OFF” and
“ALARM MUTE ON”. Press to confirm your choice and
you will return to the main menu. If you select “Alarm Mute On”
and exit the menu, the symbol will be displayed on the gas
concentration screen.
Press to scroll down to the next menu choice.
4.9 ALARM (for PERC only)
To enter the “ALARM” menu press and the following
screen will appear: -
Press to toggle between “ALARM PERMANENT ON” and
“ALARM PERMANENT OFF”. Press to confirm your
choice and you will return to the main menu.
ALARM MUTE
OFF
ALARM
PERMANENT
ON
netzerotools.com
netzerotools.com

14
If you select “Alarm Permanent OFF” and exit the menu, the
symbol Pwill be displayed on the gas concentration
screen to indicate that the alarm has been permanently muted.
Press to scroll down to the next menu choice.
4.10 ALARM LEVEL (for PERC only)
To enter the “ALARM LEVEL” menu press and the follow-
ing screen will appear: -
Press to toggle between 50PPM, 100PPM, 150PPM and
35PPM.
Press to confirm your choice and you will return to the
main menu.
Whatever alarm level you have chosen will be displayed on the
bottom left of the main display screen.
NOTE: The altered alarm level will remain active until the Moni-
tor is switched off after which it will revert to the 50PPM default
level.
Press to scroll up to the “EXIT” menu choice and press
to exit to the main screen.
ALARM LEVEL
50PPM
netzerotools.com
netzerotools.com

15
5.0 Troubleshooting
Series 200/205
Fault Description Possible cause Remedy
No power Lead connection broken
Power supply failure
Battery flat
S200 damaged
Sensor head damaged
Reconnect power lead
Replace 12V DC power supply
Recharge battery
Replace unit
Replace sensor head
Sensor failure
when the sensor
is new
Insufficient warm up
Air contaminated
Sensor damaged
Run the sensor on full power for
24-48 hours.
If an ozone source is available,
exposure to 100 ppb for 5 min-
utes will speed up the decon-
tamination process
(approximately 30 minutes)
Move the sensor to cleaner
environment and check reading
Replace sensor
Reading high
under zero gas
conditions
Background gas level higher
than normal
Interferent gas present
Sensor damaged
Move sensor to clean air and
recheck baseline
Move sensor to clean air and
recheck baseline
Replace sensor
Reading lower
than expected
reading in the
presence of sen-
sor gas
Sensor correct
Sensor inlet contaminated
Sensor fan failed
Interferent gas present
Gas reactive and decompos-
ing before detection
Local air flow too high (ozone
sensors) or
too low (VOC and ammonia
sensors)
Sensor calibration lost
Check calibration of gas genera-
tor.
Clean sensor inlet filter and
mesh
Replace sensor
Move sensor to clean air and
check reading upon exposure to
known gas concentration
Move the monitor closer to the
source of the gas
Modify the airflow into and
around sensor head.
Replace /refurbish sensor
netzerotools.com
netzerotools.com

16
Fault Description Possible cause Remedy
Reading higher than
expected in the pres-
ence of sensor gas
Sensor correct
Interferent gas pre-
sent
Sensor calibration lost
Check calibration of gas
generator.
Move sensor to clean air
and check reading upon
exposure to known gas
concentration
Replace /refurbish sensor
Reading unstable Power supply unsta-
ble
Power supply current
rating incorrect
Local air flow too high
Environmental condi-
tions fluctua ing
Install stable power supply
Install power supply with
correct rating
Reduce air flow
Reduce fluctuations
netzerotools.com
netzerotools.com

17
6.0 Specifications
*Perc sensor only
Measurement units PPM or mg/m3
Removable / replaceable sensor
head
Yes
On-board alarm* Yes
Alarm status displayed * Yes
Low battery indication Yes
Alarm mute function* Yes
Sensor condition status Yes
Stand-by mode Yes
External signal for alarms & control None
Series 200 Monitor Base
External signal functions None
Analogue output None
Power supply 12 VDC, 800 mA
Rechargeable battery pack 9.6V (2100mA/hr Ni-MH )
Portable Yes
Permanently fixable Screw fix
Remote Sensor Capability Yes
Enclosure rating IP20 & NEMA 1 equivalent
Size (with sensor head) 195 x 122 x 54 (mm);
7Rx4¾ x 2T(in)
Weight (with sensor head and
battery)
<460 g; < 16 oz
Approvals Part 15 of FCC Rules
EN 50082-1: 1997
EN50081-1: 1992
netzerotools.com
netzerotools.com

18
Depressions in the
battery cover
demarcating the
screw-hole posi-
tions for fixing the
unit to the wall
7.0 Drawings
netzerotools.com
netzerotools.com

19
8.0 Care and Maintenance
Your Aeroqual Monitor is a product of superior design and
quality and should be treated with care. When using your
Aeroqual Monitor:
•Keep it and all its parts and accessories out of the reach of
small children.
•Keep it dry. Avoid water and/or condensation as humidity
and liquids containing minerals may corrode electronic cir-
cuits.
•Do not use or store in dusty, dirty areas.
•Do not store or turn off the monitor in temperatures below
10°C.
•This unit is designed for use at temperatures between -5°C
and +50°C (23°F and 120°F). Sudden changes in tem-
perature will cause condensation that may damage the
electronic componentry.
•Do not attempt to open. Non-expert handling of the device
may cause damage.
•Do not drop, knock or shake as this could lead to internal
damage.
•Do not use harsh chemicals, cleaning solvents or strong
detergents for cleaning. Wipe with a soft cloth slightly
dampened with a mild soap-and-water solution
In order to maintain measurement accuracy, Aeroqual
recommends that user’s replace or refurbish their sensor
heads on a yearly basis. Please contact your dealer or
Aeroqual to discuss your options.
Disposal / Recycling
Please note that this is an electronic product and disposal should be in line
with your local or country legislation. The plastic casing of the product is made
from a Polycarbonate / ABS blended material (PC + ABS) and is marked ac-
cordingly.
netzerotools.com
netzerotools.com
