Kanto YUMI POWERED SPEAKER User manual

User Manual
YUMI Powered Speakers
Supporting your digital lifestyle™
English
YUMI
POWERED SPEAKERS

2
Table of Contents
Important Safety Precautions . . . . . . . 2
Introduction / What’s in the Box? . . . . . 3
Front & Rear Panels . . . . . . . . . . . . 4
Remote Control . . . . . . . . . . . . . . 5
Setting Up Your Speakers. . . . . . . . . . 6
Connecting Audio Sources . . . . . . . . . 7
USB Charging . . . . . . . . . . . . . . . 9
Connecting a Sub-Woofer. . . . . . . . . . 10
Specifications . . . . . . . . . . . . . . . .11
Warranty . . . . . . . . . . . . . . . . . .12
Important Safety Precautions
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
• Protect the power-supply cord from being walked on or
pinched, particularly at plugs, convenience receptacles and
the point where they exit from the apparatus.
• Only use attachments / accessories specified by the
manufacturer.
• Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
• Unplug this apparatus during lightning storms or when
unused for long periods of time.
• Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, the
apparatus does not operate normally, or the apparatus has
been dropped.
• Apparatus shall be connected to a MAINS socket outlet with
a protective earthing connection.
• An appliance input coupler is used as the disconnect device
- the disconnect device shall remain readily operable.
• Batteries or battery packs shall not be exposed to excessive
heat such as sunshine, fire or the like.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE BACK PANEL.
NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
DANGEROUS VOLTAGE
The lightning flash with arrowhead, within an
equilateral triangle, is intended to alert the user
of the presence of non-insulated “dangerous
voltage” within the product’s enclosure that
may be of sufficient magnitude to constitute a
risk of electric shock to persons.
ATTENTION
The exclamation point within an
equilateral triangle is intended to
alert the user of the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the apparatus.
FCC Warnings
• Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
• This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules.
FCC Notice:
• This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Industry Canada Notice:
• Complies with CAN ICES-3(B) / NMB-3(B)

3Supporting your digital lifestyle™
Introduction
Thank you for choosing the YUMI Powered Speaker System, designed by Kanto in Canada. YUMI
outputs 30 W RMS (60 W peak) per side into 6 Ohm speakers, for remarkably bold and clean
sound. Excellent sensitivity and frequency response specs provide deep thumping lows and
clear, scintillating highs. YUMI is a truly flexible speaker system that can accept five input sources
(including optical and Bluetooth®), drive a sub-woofer, charge USB devices and switch between
115 V and 230 V inputs.
We recommend you read all instructions carefully before using the system, and keep them for
future reference. Ensure that the Voltage Select switch is set to the correct input voltage for
your location. Kanto cannot be liable for damage or injury caused by incorrect setup or use of
this product.
This powered speaker system was carefully tested and inspected during production, and before
packaging and shipping. After unpacking, please check for any damage. It is rare that a unit is
damaged during shipping, but if this happens contact your retailer immediately. You can also
call Kanto directly at 1-888-848-2643 or email [email protected].
What’s In the Box?
Power
Cord
User
Manuals
x3
x8
Self-Adhesive
Rubber Feet
Speaker
Wire (10’)
x2
‘AAA’
Batteries
YUMI Active
Speaker
(Left Channel)
YUMI Passive
Speaker
(Right Channel)
BASS TREBLE
RESET
YUMI
YUMI
Remote
RCA - 3.5 mm
‘Y’ cable (10’)

Front & Rear Panels
4
YUMI’s volume knob functions as an input
select knob as well.
Push the knob to select an input source
- it cycles through the following inputs
depending on what input source was last
used.
BLUETOOTH RCA 3.5mm OPT1 OPT2
Volume/Input Select Knob
FRONT PANEL
1 1” Silk Dome Tweeter
2 Signal LED (White) -
ON - Paired Device in Range
SLOW FLASH - Bluetooth Pairing Mode
FAST FLASH - USB Charging Mode
OFF - Bluetooth Input Not Selected
3 Power LED -
BLUE - Operating Mode
AMBER - Standby Mode
AMBER FLASHING - Mute
4 Remote Receiver
5 Volume / Input Select Knob
6 5” Kevlar Mid-Range Driver
REAR PANEL
7 Bass Reflex Port Tube
8 RCA Left and Right Input Connectors
9 3.5 mm Stereo Mini-Jack Input
Connector
10 Sub Woofer Output
11 Optical 1 and Optical 2
TOSLINK Input Connectors
12 Right Channel Output Terminals
(+ and −) for Passive Speaker
Connection
13 USB Charge Port (1 x 5V 1 A)
14 Voltage Select Switch
(115V 60 Hz / 230V 50 Hz)
15 ON/OFF Switch
16 AC Input Connection (IEC320/C14)
7
5
6
4
3
1
8
9
10
11
12
13
14
15
16
2

5Supporting your digital lifestyle™
Remote Control
1 Mute
2 USB Charge Mode - see page 9
3 Standby - press to enter
Standby Mode
BLUETOOTH CONTROLS
4 Previous Track
5 Play / Pause
6 Next Track
INPUT SELECTIONS
7 Bluetooth Input Select
8 RCA Input Select
9 3.5 mm Stereo Mini-Jack
Input Select
10 Optical 1 Input Select
11 Optical 2 Input Select
AUDIO EQUALIZATION
12 Reset Bass and Treble
13 Increase Bass Output
14 Increase Treble Output
15 Decrease Bass Output
16 Decrease Treble Output
VOLUME CONTROL
17 Increase Volume
18 Decrease Volume
BASS TREBLE
RESET
YUMI
2
1 3
5
4 6
8
7 9
10
1112
17
18
14
13
16
15
Install two supplied AAA batteries in the back of your YUMI remote. Remote Control functions
are listed below.

6
Setting Up Your Speakers
The YUMI powered speaker system is designed for either bookshelf or stand mounting. The
stands should be of rigid construction, between 45 cm to 69 cm high and preferably have
spikes. We recommend the Kanto SP130 speaker stands to go with your YUMI.
The space between the two speakers and the distance from the listener is important. If the
speakers are positioned too close or too far apart, stereo imaging will not be fully developed.
YUMI is designed to perform optimally positioned at least 20 cm from the rear wall in an
average listening room. However, it may not be possible to install the speakers in this position
and since rooms vary in shape, size, and furnishing, a certain amount of experimentation is
necessary to determine the most suitable position.
Moving the speakers very close to the rear wall will enhance the bass frequencies but will tend
to reduce soundstage depth, while moving the speakers away from the rear wall will tend
to have the opposite effect. Avoid positioning the speakers close to or in the corners of the
room, as this will excite undesirable room coupling in the low and middle frequencies. If the
width of the rear wall is limited then toe-in the speakers slightly to reduce reflections. Room
characteristics and positioning have a profound effect on the performance of the speakers, so
time and effort devoted to achieving the optimum positions will be rewarded.
Ensure that the ON/OFF Switch is in the OFF position.
Connect the two speakers together as shown below using the supplied speaker cable.
Connect the RED (+) and BLACK (−) terminals from the active speaker (left channel) to the
corresponding terminals on the passive speaker (right channel). If you wish to place your
speakers farther apart than the supplied cable will reach, we recommend that you purchase a
heavier gauge of speaker cable to minimize signal loss.
Follow the instructions on the ensuing pages to connect your audio sources to YUMI. The
examples in the following pages are not meant to be exhaustive - just examples.
Connect the power cord from YUMI’s active speaker to the wall outlet.
ATTENTION
When connecting audio cables the ON/OFF Switch must be turned OFF. After connecting all cables, the unit can be
turned ON.
When the volume is high, this system can produce noise levels that could permanently damage your hearing.
YUMI is a self-powered speaker system. Do not connect the speaker terminals to the speaker outputs of a stereo
amplifier. Damage may occur. Use only the power cord provided with the speakers.

7Supporting your digital lifestyle™
Connecting Audio Sources
RCA & 3.5 mm Stereo Mini-Jack (AUX) Connection
YUMI has five inputs, including dual RCA, 3.5 mm stereo mini-jack, two OPTICAL TOSLINK
connections, and Bluetooth.
Use the appropriate audio cable to connect your audio source components to your speakers.
Refer to the following diagrams on connectivity options.
• 3.5 mm stereo mini-jack AUX cable
• Stereo RCA to 3.5 mm stereo mini-jack ‘Y’ cable
• Optical Toslink cable
PHONO PRE-AMP
TURNTABLE
LAPTOP
MP3
AUDIO
IN
OUT
CD / DVD
MP3 DOCK
R
3.5 mm
L
R
L
(if necessary)*
ATTENTION
*Some models of turntables include a built-in Phono Pre-Amp.

8
Bluetooth Pairing
Optical & Bluetooth Connection
MOBILE
DEVICES
OPT 1
OPT 2
GAME CONSOLES
DIGITAL DOCK
MEDIA PLAYERS
YUMI features Bluetooth technology, and can be paired with many devices for wireless audio
playback from your phone, MP3 player or tablet. Pairing is easy.
1. Press the Standby Button on YUMI’s remote to wake YUMI, and press the Bluetooth button
on the YUMI remote. The Bluetooth LED will flash slowly to indicate that YUMI is in pairing
mode. (Note that if the Bluetooth LED stays solid, YUMI has likely found a previously paired
device in range.)
2. Enable your Bluetooth device to search for a new device. Select ‘YUMI by Kanto’ from the
list of Bluetooth devices. If prompted for a pairing code enter ‘1234’.
3. If pairing is successful, the Bluetooth LED will remain solid. You will not need to pair the
same Bluetooth device again - ‘YUMI by Kanto’ will remain on your device list.
4. If the device does not pair with YUMI, turn YUMI’s ON/OFF Switch to the OFF position,
then repeat Steps 1 and 2.

9Supporting your digital lifestyle™
Bluetooth Operation
1. If not previously paired, pair your Bluetooth device as described above.
2. If YUMI has been switched OFF or gone to standby mode, if another device has been
connected to YUMI’s Bluetooth input, or if you have disconnected from YUMI’s Bluetooth
input, you will need to reconnect by selecting ‘YUMI by Kanto’ from your device menu.
3. If another device is connected to YUMI’s Bluetooth input, your device will not be able to
connect to YUMI, and you will receive a connection error. Terminate the connection of the
other device first and try to Connect to ‘YUMI by Kanto’ again.
4. When you are successfully connected, the Bluetooth LED will be lit solid, and your device
will show as Connected to ‘YUMI by Kanto’.
5. Once connected, you can control the playback from your Bluetooth enabled device using
the second row of buttons on YUMI’s remote control.
USB Charging Operation
YUMI features one 5V 1 A USB charging port on the back panel. This is a convenient power
connection to charge your devices.
When YUMI is in Operating Mode (Power LED blue), the port is active, and whatever device is
connected can draw up to 1 A of power. When YUMI is in Standby Mode (Power LED amber),
the USB charging port will automatically turn off.
The USB charging port can be enabled even though YUMI is not operating, by simply pressing
the USB Charge button on the YUMI remote. When in USB Charge Mode, the Power LED will
be off, and the Signal LED will flash twice quickly, followed by a delay, and repeat. Pressing the
USB Charge button on the YUMI remote again will put the unit into Operating Mode.

10
Connecting a Subwoofer
YUMI is equipped with an RCA connector to provide output signal to a powered subwoofer.
Simply connect a single RCA subwoofer cable from the SUB OUT connection on YUMI to the
AUDIO INPUT on your subwoofer. If your subwoofer has a stereo L/R RCA input, either left or
right inputs will work.
We recommend the Kanto sub6 or sub8 powered subwoofer with crossover and volume
controls. Most quality subwoofers offer these controls, which allow you to customize the
amount of bass you will experience.
Look for details on the Kanto website at: www.kantospeakers.com.
U
U

11 Supporting your digital lifestyle™
Specifications
Tweeters 1 inch silk dome
Woofers 5 inch Kevlar
Nominal Impedance 6 Ohm
Sensitivity 2.83V (/1W/1m) 87 dB
Power Output 30 Watts RMS per channel
Frequency Response 60 Hz - 20 kHz @ ± 3 dB
Input Sensitivity 350 mV (Line RCA)
Frequency Range 20 Hz - 20 kHz @ ± 6 dB
Total Harmonic Distortion < 0.7%
Crossover System 2-way
Amplifier Type Class AB
Inputs 1 x RCA L/R
1 x 3.5 mm stereo mini-jack
2 x TOSLINK Optical
1 x Bluetooth
Outputs 1 x Sub-Woofer
1 x USB Power (5V 1 A)
Speaker Terminals Left and Right Binding Posts
Remote Control Included
Dimensions (each speaker) 6.9” x 8.1” x 10.7” (175 x 205 x 272 mm)
Net Weight (active) 14.1 lbs (6.4 kg)
Net Weight (passive) 9.3 lbs (4.2 kg)
Gross Weight 26.7 lbs (12.1 kg)
Input Voltage / Frequency 115V 60 Hz / 220V 50 Hz (manually switchable)
Standby Power Consumption < 0.5 W
YUMI POWERED SPEAKER SYSTEM
NOTICE: The Bluetooth®word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Kanto Distribution Inc. is under license.
NOTICE: © 2014 CSR plc and its group companies.The aptX®mark and the aptX logo are
trade marks of CSR plc or one of its group companies and may be registered in one or more
jurisdictions.

15A
Limited Warranty To Original Purchaser
Kanto Distribution Inc. (Kanto) warrants the equipment it manufactures to be free from defects in material
and workmanship for the following limited warranty period of:
24 months parts and labour
If equipment fails because of such defects and Kanto or an authorized dealer is notified within 24 months
from the date of shipment with proof of original invoice. Kanto will, at its option, repair or replace the
equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse
or modifications. Equipment that fails under conditions other than those covered will be repaired at the
current price of parts and labor in effect at the repair. Such repairs are warranted for 90 days from the day
of reshipment to the original purchaser. This warranty is in lieu of all other warranties expressed or implied,
including without limitation, any implied warranty or merchantability or fitness for any particular purpose, all
of which are expressly disclaimed.
The information in the owner’s manual has been carefully checked and is believed to be accurate. However,
Kanto assumes no responsibility for any inaccuracies that may be contained in the manual. In no event will
Kanto, be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect
or omission in this manual, even if advised of the possibility of such damages.
Warranty
www.kantoliving.com | [email protected]
Tel [phone]
To learn more about all our products, visit www.kantoliving.com
• Check out our full line of bookshelf and desktop speaker systems
• Available in a stunning array of colors
Kanto Speakers
• Full line of Audio and Video Cables
• White or Black Cables available
• HDMI, Optical, Mini-jack, RCA, USB
• Switchers, Hubs, and Adapters
• Visit kantoliving.com/products/cables
• Visit kantospeakers.com for more!
by
Kanto Living @kantoliving kantoliving
U
Check out more great products from Kanto!
