KAP CDR3.0 TD User manual

D A T E .
www.kaptrade.com
Korea Auto Parts
MODEL.
Instruction Manual
2019.07.05
CDR3.0 TD –CARPLAY
VIDEO INTERFACE
CDR-31-190521
PORSCHE INTERFACE

Car Compatibility Sheet
CDR3.1 and PCM3.1
BRAND MODEL YEAR
PORSCHE
Boxter 2012 -
Cayenne 2010 -
Cayman 2013 -
911 Carrera 2011 -
Macan 2014 -
Panamera 2009 -
Check slot in center
CDR3.1 - Support PCM3.1 - not support

CDR3.0 TD
Spec
1. Input Spec. (MULTI VIDEO INTERFACE)
•Interface
•1 x Digital RGB Input (Navigation System source)
•1 x Analog RGB Input (Navigation System output)
•1 x CVBS(REAR CAMERA) Input. (Rear camera source)
•1 x CVBS(Front CAMERA) Input. (Front camera source)
•2 x A/V Input (External video source)
CarPlay
•1 x USB Input
•1 x Microphone Input
•1 x Real Analog Touch Input
2. Output Spec.
•Interface
•2 x CVBS Output (Video out for Installing Headrest Monitor)
•1 x Audio L/R Output.
•1 x LCD Output (LCD Operation)
•1 x Virtual Analog Touch (Navigation System source)
•1 x UART Digital Touch (Navigation System source)
CarPlay
•1 x LVDS(HDMI Connector) Output
•1 x Audio L/R (3.5Ф Stereo Jack) Output
3. Power Spec.
•Input Power : 8VDC ~ 24VDC
•Consumption Power : 12Watt, Max
4. Switch Input Mode
•Possible to select CAR model while switching mode by DIP S/W
•By button on the Commander in the car via CAN

CDR3.0 TD
External Appearance
Interface
PROGRAM
DIP S/W
LED
POWER
/CAN
R
Touch
DIGITAL
RGB
RGB
OUT
LVDS
OUT
ANALOG
RGB
REAR A/V
IN/OUT

CDR3.0 TD
Connector Pin Assignment
1POWER Connect (10Pin)
12345678910
■■■■■■
RED BLACK RED BROEN BLUE RED
ACC GND N.C N.C REAR VCC N.C REAR DET N.C
FRONT DET
FRONT VCC
No
Color
Connect
1234
2TOUCH Connect (4Pin)
1 2 3 4
■■■■
RED GREEN BLUE WHITE
Y- X- Y+ X+
No
Color
Connect
1234567
3NAVI Connect (7Pin)
1 2 3 4 5 6 7
■■■■■■■
RED GREEN BLUE WHITE BLACK GREEN ORANGE
R DATA G DATA B DATA SYNC GND DVB-T IR DVD IR
No
Color
Connect
1 2 3
123456789
10

CDR3.0 TD
External Appearance / Connector Pin Assignment
CARPLAY
Smartphone
Connection
Mode Switch
To Enter Setting
Microphone In
AUX
Touch
LVDS&UART OUT
POWER/CAN
1234
1R-TOUCH Connect (4Pin)
1 2 3 4
■■■■
RED GREEN BLUE WHITE
Y- X- Y+ X+
No
Color
Connect
1 2
2POWER/CAN Connect (2Pin)
1 2
■■
RED BLACK
ACC GND
No
Color
Connect
12
R-TOUCH POWER/CAN

CDR3.0 TD
Product Composition
FFC Cable
Board Power Cable RGB NAVI Cable
RGB SUB Cable Mode Switch
OSD Board FPC Cable
LVDS CableSUB Board A/V Cable

CDR3.0 TD
Product Composition
CarPlay Power Cable (800mm) HDMI Cable
AUX Cable Microphone

CDR3.0 TD
Car Type Select
Dip Switch Setting
PIN FUNCTION DIP S/W Selection
1NAVI ON : Not Used
OFF : Used
2DVB-T(AV1) ON : Not Used
OFF : Used
3DVD(AV2) ON : Not Used
OFF : Used
4 N.C
5 N.C
6
CAR type SEL Bottom Picture7
8
OFF : ▲UP
ON : ▼DOWN
CDR3.1

CDR3.0 TD
Mode Change
OEM Button Usage
Mode Change Button
BACK Button
•Other buttons are changed to OEM SCREEN

CDR3.0 TD
Touch Control
Touch Calibration / DVBT, DVD Control
Press Touch (Anywhere) Press Icon
•Touch the screen for 11 seconds
Method 1 Method 2
OR
•+ Touch according to the
shape coordinates.
Touch Calibration
•OSD menu ▶Utility ▶Calibration
DVBT
DVD

CDR3.0 TD
OSD Control
OSD(On Screen Display) Control Board
MENU SEL UP DOWN
MENU •The OSD screen can be switched ON/OFF
•Return to previous menu
SEL •Select the currently active item
•If the OSD screen is off, mode changes can be made.
UP •Move up from the menu
•Increase the selected item value
DOWN •Move down from the menu
•Decrease the selected item value
First Menu Second Menu Third Menu
Mode State

CDR3.0 TD
OSD Control
Config
First Menu Second Menu Third Menu Description
Config
NAVI-RGB
DIGTAL-
INAVI
:
Setting the Connected NAVI Model
DVB-T(DMB) ELT_DVBT20
:Setting the Connected DVB-T Model
DVD
ELT_980XU
Slim
:
Setting the Connected DVD Model
Reset Execute Reset to default value of Config menu

CDR3.0 TD
OSD Control
Option
First Menu Second Menu Third Menu Description
Option
NAVI COM
HMS
FINE
:
Set up manufacturer of woodworking
device for UART Touch use
OFF Disable feature
RearCam-Type
OEM Original Camera
ExtDevice Equipped with external camera
RearCam-Power
ON + 12V continuous supply
AUTO + 12V supply only in Rear camera mode
OFF + 12V off
RearCam-Det
CAN Detected by CAN
ExtWire Detected by Rear-Det Wire
FrontCam-Type
OEM Original Camera
ExtDevice Equipped with external camera
FrontCam-Power
ON + 12V continuous supply
AUTO + 12V supply only in Front camera mode
OFF + 12V off
FrontCam-Det
CAN Detected by CAN
ExtWire Detected by Front-Det Wire
FrontCam-
RcvOpt
ON After RearCam shows FrontCam and
returns to previous state
OFF Disable feature

CDR3.0 TD
OSD Control
Option
First Menu Second Menu Third Menu Description
Option
AV OUT
AV1
In the NAVI, AV1, and MHL screens, set A /
V OUT to AV1.
AV2
In the NAVI, AV2, and MHL screens, set A /
V OUT to AV2.
USER In the NAVI, MHL screen, A / V OUT
displays the previous step screen.
UI DVB-T (DMB)
ON DVB-T device control UI output function
OFF Disable feature
UI DVD
ON DVD device control UI output function
OFF Disable feature
Reset Execute Option Menu all Reset

CDR3.0 TD
OSD Control
Option ▶FrontCam-RcvOpt
Front Camera Auto Mode
1~30 second
FrontCam-RcvOpt Menu ON & time control
OEM or
INTERFACE
REAR
CAMERA
FRONT
CAMERA
OEM or
INTERFACE
Select time of display
0~30 second
0 second
FrontCam-RcvOpt Menu OFF

CDR3.0 TD
Contrast
Brightness
Saturation
OSD Control
First Menu Second Menu Third Menu Description
Brightness Adjust the value of brightness
Contrast Adjust the value of contrast
Color-RED Adjust the value of RED
Color-GREEN Adjust the value of GREEN
Color-BLUE Adjust the value of BLUE
Reset Execute Option Menu all Reset
NAVI –RGB Menu
First Menu Second Menu Third Menu Description
Brightness Adjust the value of brightness
Contrast Adjust the value of contrast
Saturation Adjust the value of Saturation
Hue Adjust the value of Hue
Sharpness Adjust the value of Sharpness
Reset Execute Option Menu all Reset
DVD / DVBT / NAVI-AV,REAR,FRONT Menu

CDR3.0 TD
OSD Control
Screen
First Menu Second Menu Third Menu Description
Screen
Horizontal Output screen horizontal movement
Vertical Output screen vertical movement
Scale X Up
Reduce / increase output screen width
Scale X Down
Scale Y Up
Reduce / Increase Output Screen Height
Scale Y Down
Reset Screen menu all reset

CDR3.0 TD
OSD Control
OSD
First Menu Second Menu Third Menu Description
OSD
Horizontal value OSD Menu Horizontal Shift
Vertical value OSD menu vertical Shift
Display Time value OSD Menu Display Time (in seconds)
Transparency value OSD menu transparency
Language OSD menu display language
Reset Execute Initialize OSD settings

CDR3.0 TD
•In order to work with the IR learning function,
a separate IR cable is required.
OSD Control
IR learning function
1. In DVB-T / DVD menu, select User in Sys (OSD list) or User (learned contents).
2. Select Learn from the OSD menu.
3. Before using IR learning function, select All-Clear to delete existing stored data.
4. Press the remote control button to be used in each ICON once in New Code, press
once again in Cfm Code to confirm it is the same and save it.
