KAP TC2016-IE-151120 User manual

D A T E .
www.kaptrade.com
Korea Auto Parts
MODEL.
Instruction Manual
2019.04.29
TOYOTA CAMRY 2016
VIDEO INTERFACE
TC2016-IE-151120
for CAMRY / RAV4

Serviceable Model
8 Inch Model
Supported : 8 Inch Model Headunit
Unsupported : 7 Inch Model Headunit
CAMRY 7 "monitor is not supported because there is no LVDS connector

TOYOTA CAMRY 2016
Spec
1. Input Spec. (MULTI VIDEO INTERFACE)
•1 x Digital RGB Input (Navigation System output)
•1 x Analog RGB Input (Navigation System output)
•2 x A/V Input (External video source)
•1 x LVDS Input. (Car Command System)
2. Output Spec.
•2 x CVBS Output (Video out for Installing Headrest Monitor)
•1 x Audio L/R Output.
•1 x LCD Output (LCD Operation)
•1 x Virtual Analog Touch (Navigation System source)
•1 x UART Digital Touch (Navigation System source)
3. Power Spec.
•Input Power : 8VDC ~ 24VDC
•Consumption Power : 12Watt, Max
4. Switch Input Mode
•Possible to select CAR model while switching mode by DIP S/W

TOYOTA CAMRY 2016
External Appearance
PROGRAMDIP S/WIMAGELED
POWER/
CAN
Touch Digital
RGB
NAVI
POWER
LVDSA/VAnalog
RGB
MODE

TOYOTA CAMRY 2016
1 2 3 4 5 6 7 8
Connector Pin Assignment
1POWER Connect (8Pin)
12345678
■■■■■■■■
RED YELLOW ORANGE GREEN BLUE BROEN RED BLACK
ACC BATTERY IE+ IE- KEY
REAR DETECT
REAR POWER
GND
No
Color
Connect
1 2 3 4
1 2 3 4
3NAVI POWER Connect (4Pin)
1 2 3 4
■■■
YELLOW RED BLACK
BATTERY ACC N.C GND
No
Color
Connect
1 2 3 4
2NAVI TOUCH Connect (4Pin)
1 2 3 4
■■■■
RED GREEN BLUE WHITE
Y- X- Y+ X+
No
Color
Connect
1 2 3 4 5 6 7
4NAVI Connect (7Pin)
1 2 3 4 5 6 7
■■■■■■■
RED GREEN BLUE WHITE BLACK GREEN ORANGE
R DATA G DATA B DATA SYNC GND DMB IR DVD IR
No
Color
Connect

TOYOTA CAMRY 2016
Product Composition
Board Power Cable NAVI Power Cable
LVDS Cable A/V Cable RGB NAVI Cable
OSD Board Bolt (4EA)

TOYOTA CAMRY 2016
Car Type Select
Dip Switch Setting
PIN FUNCTION DIP S/W Selection
1NAVI ON : Not Used
OFF : Used
2DVB-T(AV1) ON : Not Used
OFF : Used
3DVD(AV2) ON : Not Used
OFF : Used
4 N.C
5 N.C
6
Car Type Select Bottom Picture7
8
OFF : ▲UP
ON : ▼DOWN
TOYOTA 2016
CAMRY
TOYOTA 2016
RAV4
FUJITSUTEN
(Headunit)
PANASONIC
(Headunit)

TOYOTA CAMRY 2016
Mode Change
Mode Change Button : MAP

TOYOTA CAMRY 2016
Touch Control
Touch Calibration / DVBT, DVD Control
Press Touch (Anywhere) Press Icon
•Touch the screen for 11 seconds
Method 1 Method 2
OR
•+ Touch according to the
shape coordinates.
Touch Calibration
•OSD menu ▶Utility ▶Calibration
DVBT
DVD

TOYOTA CAMRY 2016
OSD Control
OSD(On Screen Display) Control Board
MENU SEL UP DOWN
First Menu Second Menu Third Menu
Mode State
MENU •The OSD screen can be switched ON/OFF
•Return to previous menu
SEL •Select the currently active item
•If the OSD screen is off, mode changes can be made.
UP •Move up from the menu
•Increase the selected item value
DOWN •Move down from the menu
•Decrease the selected item value

TOYOTA CAMRY 2016
OSD Control
Option
First Menu Second Menu Third Menu Description
Option
RearCam-Type
OEM Original Camera
ExtDevice Equipped with external camera
RearCam-Power
ON + 12V continuous supply
AUTO + 12V supply only in Rear camera mode
OFF + 12V off
RearCam-Det
CAN Detected by IEBUS
WIRE Detected by Rear-Det Wire
HomeIcon
ON Activate the UI icon
Off Disable feature
AV OUT
AV1
In the NAVI, AV1, and MHL screens, set A /
V OUT to AV1.
AV2
In the NAVI, AV2, and MHL screens, set A /
V OUT to AV2.
USER In the NAVI, MHL screen, A / V OUT
displays the previous step screen.

TOYOTA CAMRY 2016
OSD Control
Option
First Menu Second Menu Third Menu Description
Option
Handle Button
ON Using the SteeringWheel buttons
OFF Disable feature
UI DVB-T (DMB)
ON DVB-T device control UI output function
OFF Disable feature
UI DVD
ON DVD device control UI output function
OFF Disable feature
NAVI COM
HMS
FINE
:
Set up manufacturer of woodworking
device for UART Touch use
OFF Disable feature
Reset Execute Option Menu all Reset

TOYOTA CAMRY 2016
OSD Control
Contrast
Brightness
Saturation
First Menu Second Menu Third Menu Description
Brightness Adjust the value of brightness
Contrast Adjust the value of contrast
Color-RED Adjust the value of RED
Color-GREEN Adjust the value of GREEN
Color-BLUE Adjust the value of BLUE
Reset Execute Option Menu all Reset
NAVI –RGB Menu
First Menu Second Menu Third Menu Description
Brightness Adjust the value of brightness
Contrast Adjust the value of contrast
Saturation Adjust the value of Saturation
Hue Adjust the value of Hue
Sharpness Adjust the value of Sharpness
Reset Execute Option Menu all Reset
DVD / DVBT / NAVI-AV,REAR,FRONT Menu

TOYOTA CAMRY 2016
OSD Control
Screen
First Menu Second Menu Third Menu Description
Screen
Horizontal Output screen horizontal movement
Vertical Output screen vertical movement
Scale X Up
Reduce / increase output screen width
Scale X Down
Scale Y Up
Reduce / Increase Output Screen Height
Scale Y Down
Reset Screen menu all reset

TOYOTA CAMRY 2016
OSD Control
OSD
First Menu Second Menu Third Menu Description
OSD
Horizontal value OSD Menu Horizontal Shift
Vertical value OSD menu vertical Shift
Display Time value OSD Menu Display Time (in seconds)
Transparency value OSD menu transparency
Language OSD menu display language
Reset Execute Initialize OSD settings

TOYOTA CAMRY 2016
•In order to work with the IR learning function,
a separate IR cable is required.
OSD Control
IR learning function
1. In DVB-T / DVD menu, select User in Sys (OSD list) or User (learned contents).
2. Select Learn from the OSD menu.
3. Before using IR learning function, select All-Clear to delete existing stored data.
4. Press the remote control button to be used in each ICON once in New Code, press
once again in Cfm Code to confirm it is the same and save it.

TOYOTA CAMRY 2016
OSD Control
Utility
First Menu Second Menu Third Menu Description
Utility
Factory Reset Execute Initialize all settings
Calibration Execute Run Calibration mode
Version FDS302KRX-171004
(Check for future upgrades)
•Last Source : FDS302KRX-171004
Motor Model
FD=FORD
BM=BMW
BE=BENZ
MA=MASERATI
LX=LEXUS
PIP
Model
S3=Sync3
PP=PIP
V=LVDS
Hardware
Version
National
CN=CHINA
KR=KOREA
JP=JAPAN
US=U.S.A
Special
Version
FD S3 02 KR X - 17 10 04
Software
Year
Software
Month
Software
Version

TOYOTA CAMRY 2016
Install Manual
1. Installation Diagram
Monitor /
HeadUnit
CAMRY 2016
VIDEO INTERFACE
POWER/CAN
NAVI
RGB
TOUCH LVDS
DIGITAL
NAVI
POWER A/V
MODE
LVDSPOWERIE

TOYOTA CAMRY 2016
Install Manual
2. Installation Navigation Connection
DVD-IR
DVBT-IR
GND
SYNC
BLUE
GREEN
RED
X+
Y+
X-
Y-
Resistive Touch
Analog RGB
Navigation
CAMRY 2016
VIDEO INTERFACE
POWER/CAN
NAVI
RGB
TOUCH LVDS
DIGITAL
NAVI
POWER A/V
MODE
GND
ACC
Bettery
POWER

TOYOTA CAMRY 2016
Install Manual
3. Installation DVB-T Remote Control Connection
DVD-IR
DVBT-IR
GND
SYNC
BLUE
GREEN
RED
CAMRY 2016
VIDEO INTERFACE
POWER/CAN
NAVI
RGB
TOUCH LVDS
DIGITAL
NAVI
POWER A/V
MODE
GND
ACC
Bettery
POWER
GEX-909DTV
OR
TUE-T440
