Karassn KS-200B Series User manual

100-Zone Wireless Alarm System
User Manual
V1.0
Limits Of This Safe System
As an advanced technical guard system, although it can reduce the occurrence of theft, robbery and fire, it can not
promise to have no any above-mentioned accidents happen or have no any personnel casualty and property losses
happen. And we invite you understanding that any alarm system ,whether it is used in business or at home, it may
alarm wrongly or failure to alarm because of various reasons. We remind you to pay attention to the following possible
reasons:
1.The system is not armed because of carelessness.
2.User or installation personnel misunderstand user’ manual or operate wrongly so that the system can not work
normally.
3.Intruder intrude the place where is beyond the detect areas or he can pass by the alarm detector or make it
malfunction. Passive infrared detector only can detect the areas like the introduction picture shows. it can not detect
hidden places, like behind wall, inside ceiling, inside floor, behind door, glass partition, glass door or being glazing.
4.The detect sensitivity of passive infrared detector will automatically change according to the changed environment
temperature. when the temperature of protected area reach to 32℃-40℃,the performance of infrared detector (detect
distance) will reduce. So we suggest you to check its working performance carefully when it reaches to such a
temperature, and then adjusting it.
5.There are no power or the battery is used out or damaged.
6.Alarm trumpet is installed at the other side of the door closed, so it may not be able to warn or wake the sleeper.
7.There are something wrong with telephone line which transfer alarm signals to alarm center ,or the lines are busy so
that it can not transfer signals in time.
8.When there are someone intrude ,the common reason why system can’t alarm is that the system don’t get normal
maintenance . Like other electrical equipments , the electronic elements of this equipment also may be damaged.
Therefore, user should check the system periodically everyday.
9.Other unpredicted reasons.
If you don’t agree with the above clauses ,within three days from you purchase,
you can send it back if only it is not damaged, and we will refund all money.
Otherwise, we view it as that you agree with the above clauses.
You should known that alarm equipment is not insurance substitution .So the users must be careful to protect your
life and property.

100-Zone Wireless Alarm System
-1-
We are honored that you select Karassn security products, thank you
very much. To make full use of its performance and keep it stable, please
carefully read this “User Manual” before operation. For any questions,
please don’t hesitate to contact with Karassn Client Service Department or
Agents.
Table Of Contents
2
1.Introduction………………………………………………………………………
2.Definition………………………………….……………………………………… 4
4
3.Operate Precautions………………………………………………………………
4.Main Functions And Characteristics………………………………………………5
5
5.Name And Usage Of Main Parts……………………………………………………
6.Interfaces Instruction……………………….……………………………………
9
7.System Installation……………………………………………………………… 9
8.Operation Guide………………………………………………………………… 11
19
9.How To Learn/Delete Codes Of Detectors……………..………………………
10.How To Set Transmit Functions Of Detectors…………..…………………… 20
11.Main Technical Specification………………………………………………… 22
12.Standard Packing List …………..…………………………………………… 22
13.Optional Packing List………………………………………………………… 22
23
14.Simple Failure Recovery………………………………………………………
100-Zone Wireless Alarm System
-24-
Defense Area Ta ble
Zone No. Zone Location Zone No. Zone Location Zone No Zone Location
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
00

100-Zone Wireless Alarm System
-23-
14.Simple Failure Recovery
Dialing function is abnormal
1.The telephone is not the type of
double-tone.2.Outside line is
connected with extension socket on
telephone.
1.Change the telephone to be the
type of double-tone.
2.Outside line should be connected
with line socket.
electrograph makes out urgent
“Beep” sound when working.
The outside line of alarm host don’t
connect with extension output of
electrograph.
Connect electrograph with extension
output of electrograph.
Fault Symptom Failure Reason Failure Recovery
No indicative sound and clock
display when power on.
1.The socket is badly connected or
the socket has no power.
2.Fuse has burnt out.
1.Check the plug and socket,
2.Check the fuse and replace it.
Backup battery can’t work normally
when power failure.
1. The polarity of backup battery is
wrongly connected.
2.Backup battery fuse has burnt out?
1.Check the polarity connection of
backup battery is correct .
2. Check the fuse and replace it.
There is low-voltage warning tone
when alarm host provides power by
backup battery.
1.Backup battery power lower.
2.Backup battery is invalid.
1.Recharge backup battery.
2.Change backup battery.
The receive distance of alarm host
becomes shorter
1.Antenna is damaged.
2.It shares the same socket with TV,
micro oven and etc.
3.It closes to TV, micro oven and etc.
1.Replace the antenna.
2.it is recommended to use an
independent power socket.
3.Avoid closing to devices with high
electromagnetic radiation.
It can not alarm in some defense area.
1.The code in this zone has been
deleted.
2.This zone has been disarmed.
1.Recover it under the direction of
the distributor.
2.Arm this zone again (refer to user
manual).
Detector Misinformation
1.The height of installationdoesn’t
comply withrequireme nts.
2.The jumper of de tector to adjust
the detect distance ha s been changed.
3.The environment temp erature is
larger than temp erature of hu ma n body.
1.Adjust the installation angle
according to installation requirements.
2.Change the jumper of detect
distance to improve detect sensitivity.
The detect distance of detector
becomes shorter.
1.Is the installation angle of the
detector suitable? Is the
environment temperature higher
than that of human body?
Adjust installation angle. Recovery
the detection jumper of the detector
change the detection jumper of the
detector and change the infrared
sensitivity
The distance of remote controller
become shorter.
The emit indicator light doesn’t
flash when emitting.
Battery power lower, it needs to
change battery.
Transmit function is abnormal.
1.The address jumper has been
changed.
2.Is the forward detector code
deleted or changed?
Recover the jumper setup: Recovery
the code under the directions of the
distributor.
Can’t enter setting state
1.The code entered is wrong.
2.The telephone is not the type of
double-tone.
1.Enter the correct code.
2.Change the telephone to be the
type of double-tone.
(9)Clock Module ( It works normally when alarm host power off)
(10) DC 12V 15W Wired Siren
100-Zone Wireless Alarm System
-2-
1. Introduction
KS-200B series wireless alarm system is a type of long-distance wireless alarm
system, which is a complete area alarm system composed of a main unit and 1 to
100 detectors. It can be widely used in industrial and mining establishments,
schools, warehouse, villas, office buildings and other locations.
Diagram Of System Components
KS-200B alarm system is composed of KS-200B main unit, KS-200 series
wireless infrared detectors and KS-50 series wireless emitter (Show as picture 1)
Picture 1
KS -5 0A I Wi r el ess E mi tt er
……
Mi cr o- wav e/ PIR
Detector
Em er ge ncy B ut ton
Ac ti ve P IR De te cto r
KS -5 0A I Wi r el ess E mi tt er
KS -5 0A I
Wi re le ss E m it ter
……
KS - 20 0D C T
Wi re le ss PI R
De te ct or
KS -1 0 Se ri e s
Wi re le ss R e mo te Co nt ro ll e r
Wired
Wired
Wired
Te le co mm u ni cat io n Of fi c e
100- Zone Wir eles s Alar m System
TIME ORIE NTATIO N
Telephone Beeper Mo bi le P ho n e
KS-20BW
Wi re le ss D o or S ens or
Wi re le ss PI R
De te ct or
KS-20BW
Wi re le ss D o or S ens or
Wi re le ss S m ok e Det ec to r
KS -2 00 AT /K S- 200 AC T
Wi re le ss PI R De tec to r
KS-200ATI/KS-200BTT
Wi re le ss PI R De tec to r
KS -2 00 ATI
Wi re le ss PI R De tec to r
……
KS-200BTI
Wi re le ss PI R De tec to r
KS -1 0 Series
Wi re le ss R e mo te Co nt ro ll e r
KS - 20 0D C T
Wi re le ss Ca ll er Wi re le ss
Em er ge ncy B ut ton

100-Zone Wireless Alarm System
-3-
100-Zone Wireless Alarm System
-22-
1、The transmit address code should not be empty (0000); otherwise, it cannot
transmit signals.
2、The detector being transmitted must be 315MHZ VD5026; it does not support
other forms.
3、It only can transmit in arm state, it cannot transmit in disarm state.
11. Main Technical Specification
1. KS-200B Series Alarm Host
Wireless Receive Sensitivity: 0.2μV (12dB)
Working Voltage: AC 220V ±15% 50Hz, DC 12V-13.8V
Working Current: standby current 75mA, Alarm Current 350mA.
Working Environment: -10℃~50℃
Alarm Loudness: 100 dB within 1m
2. Wireless PIR Detector
Working Voltage: AC 220V ±15% 50Hz, DC 12V-13.8V
Working Current:: standby current 10mA, Alarm Current 500mA.
Working Environment: -10℃~50℃
Infrared Detector Distance: 1-12m, 60°up and down, 110°right and left.
12. Standard Packing List
(1) KS-200B Alarm Host 1PC
(2) Antenna 1PC
(3) KS-200B User Manual 1PC
(4) Maintenance Card 1PC
13. Optional Packing List
(1)KS-200AT Wireless PIR Detector
(2)KS-200ACT Wireless PIR Detector
(3)KS-200ATI Wireless PIR Detector ( It can be armed independently, and it has
transmit function.
(4)KS-200BCT ( It can alarm on the spot)
(5)KS-200BTI Wireless PIR Detector ( It can be armed independently, and it can
alarm on the spot, moreover, it has transmit function.)
(6)KS-50AI Wireless Emitter ( It can transmit wired/wireless detectors)
(7)KS-10A Wireless Remote Controller
(8)12V 1.2Ah Backup Battery
≤
≤ ≤
≥
≤ ≤

100-Zone Wireless Alarm System
-21-
For example: Set the transmit address of KS-200ATI/BTI detector to be “0 TH,
1 TH, 3 TH, 4 TH, then the transmit address code of KS-200DCT detector, KS-
20BW detector, KS-11A Emergency Button should be set as picture 2.
Picture 2
Picture 1 (It is OTH when it is not inserted)
Picture 2 (KS-200DCT Passive PIR Detector It is OTH when it is not connected)
(KS-20BW Wireless Door Sensor KS-11A Wireless Emitter
It is 3TH when it is not inserted It is 3TH when it is not inserted
Note:
The address code can be read according to the position of address jumper. If it is
not inserted, which means it 0TH.
It only can be transferred when the address code of being transferred detector is
exactly the same as that of KS-200ATI/BTI detector.
The power must be off when modifying transfer address code. Make sure it is
right, and power it on to see if the code is right, after modifying the code, it is valid
when powered on again.
Transmitter only can transmit alarm signal in arm state. So it must be armed in time
to make sure the reliability of system.
Remark:
D0
D1
D2
D3
3TH
TH
4
1TH
D0
D3
D2
D1
D0
D3
D2
D1
2
-
+
4TH
1TH
0TH
1
-
+
19
1 8
D 0 D 1 D 2 D 3
D 0 D 1 D 2 D 3
4TH
1T H
0TH
100-Zone Wireless Alarm System
-4-
between AC and DC, and it will indicate when battery power lower.
1.3 Wireless Emitter
KS-50AI Wireless Emitter adopts 8-bit single chip as processing core, and it
provides wired detectors with working power, and transmit on-off alarm signals of
wired detectors to the signal which can be recognized by KS-200B series alarm
host, and it can transmit and be armed/disarmed by remote controller. and it selects
rechargeable battery as backup power, and it can charge by itself, and also can
automatically exchange between AC and DC, and it will indicate when battery
power lower.
2. Definition
Transmit Wirelessly
The detector (emitter) can transmit signals of short-distance wireless detector
to the signals which can be recognized by KS-200B series alarm host. It has
advantages of emit wirelessly and save cost. For example, some building needs to
install 10 PIR detectors, in old way, you need install 10 KS-200ACT detectors, and
you need to consider the backup power and AC power of 10 detectors. If you adopt
transmit wirelessly, you can use one KS-200ATI detector, other 9 detectors can use
short-distance PIR detectors produced by our company (such as KS-200DCT and
so on). So it greatly save cost.
3. Operate Precautions
3.1 Please carefully read this User Manual and pay more attention to labels and
directions on main unit before operation. Check whether all wire connections are
correct and then turn it on to test so as to prevent occurring accidents.
3.2When alarm host is not equipped with backup power or clock module, the
time should be readjusted if power failure occurs.
3.3This alarm host can be equipped with 12V 1.2Ah sealed-acid storage cell.
standby time is longer than 24 hours, if power failure often occurs in some defense
area, batteries with larger capacity are recommended to serve as backup power.
3.4Please don’t disassemble alarm host at will so as not to cause accidents or
damage the apparatus.
3.5If failure occurs during operation, please carry with warranty card to contact
with Karassn client service department or Karassn agents. Remember not to
disassemble or repair it by yourself.
3.6Please periodically perform test so as to clear troubles in time to avoid

100-Zone Wireless Alarm System
-5-
omitting alarm signals.
4. Main Functions And Characteristics
KS-200B-A Function Introduction
4.1Detector (wireless emitter) can automatically learn codes with alarm host.
And dilatancy is easy and quick.
4.21-100 independent wireless defense area can be defined and the defense of
each defense area can be activated or deactivated independently. Common defense
area and emergent defense area can be defined at will.
4.3Alarm host has two groups of timer-open time and two groups of timer-close
time, and it indicates present time.
4.4Three kinds of alarm sound and four levels of alarm volume are optional.
4.5Ten pieces of up-to date alarm messages can scroll to display simultaneously.
4.6The 60 pieces of latest alarm message can be inquired.
4.7Build-in backup battery is optional. And it equips with floating charge device,
and it indicates when battery power lower.
4.8A set of normal open output, a set of normal close output and +12V DC output
are provided to control other devices (e.g. startup alarm siren, alarm light, alarm
linkage and etc.)
KS-200B-B Function Introduction
Based on KS-200B-A host, KS-200B-B host increases functions as following:
* It can automatically dial six groups of alarm telephone numbers and two
groups of pager numbers when alarming.
*The system dailer with distinguish function.
*It rushes to inform you the alarm message by cutting your speaking on the
telephone.
*Dailing pause function.
*Record 20 seconds alarm sound preset.
*Telephone short or cut report function can be opened/closed.
5. Name And Usage Of Main Parts
5.1 KS-200B-A/B Alarm Host
1、“ ” key: It is used to complete setup function together with “Function” key.
2 “Function” key: Press “Function” key to switch between setup functions.
<
、
100-Zone Wireless Alarm System
-20-
Precautions:
1.Please don’t press emergency button on remote controller to trigger the detector
when learning code.
2.For being transmit code of detector, the code signal alarm host receives should
be transmit by emitter (transmitter).
3.To avoid wrongly learning code, please trigger detector to test to see if the code
has been learned successfully.
For example:
Learning a detector in zone 2, set it to be emergency zone type.
Firstly, turn detector on, power alarm host off. Press “Function” Key, at the same
time, power alarm host, then release “Function” Key. It will show “01 : 0- 09”.
Press “< ” key to select the zone number 02, The screen will show “ 02 : 0- 09.
Press “> ” key, it will show 02 : 1- 09. Then press “Function” key and trigger the
detector to emit. It will make two indicative “beep, beep” sound, and “–” (middle
line) will change to “_” (under line), which means the setting is successful.
10. How To Set Transmit Function
KS-200ATI, BTI detector support wireless transmitting which can transmit 315
MHz detectors produced by our company (e.g., wireless door sensor, wireless
infrared detector, wireless smoke detector and so on)
Transmit Regulations
If the address code transmitted by transmitter is the same as that of 315MHz
detectors, transmitter will transmit VD5026 code signal to KS-200B alarm host.
Detector transmit signals according to the address code, so the address code of
transmitter should be the same as that of 315MHz detector. A transmitter can
transmit the alarm signal of several315MHz detectors, the quantity is unlimited in
theory.
Each KS-200ATI/BTI detector (transmitter) has 4 bits transmit address code. that
is D0,D1,D2,D3 and each address code has four states, that is “OTH, 1TH, 3TH,
4 TH” as picture 1
Picture 1
3TH
4TH
1TH
D0 D1 D2 D3
3TH
4TH
1TH

100-Zone Wireless Alarm System
-19-
will hang up automatically, and go on dialing other alarm telephone numbers.
Note:
1、 If you press“2#” ,it will stop alarming and stop dialing other alarm telephone
numbers.
2、If you don’t do any operations ,the alarm unit will hang down this telephone
and dial the next one. And it also will dial this telephone number in next dialing
circle.
9.How To Learn/Delete Code Of Detectors
KS-200B alarm system automatically learn code with detectors, the code of
detector should be learned to alarm host firstly, then the alarm host can receive
alarm signal. Each zone can be learned on detector code, and each zone can be set
to be common zone or emergency zone freely.
Common Zone: It can’t receive alarm signal when alarm host in disarm state, but it
still response to emergency button on remote controller.
Emergency Zone: It also refers to 24 hours zone. as long as alarm host is in working
state, It can receive alarm signal whatever alarm host is in arm or disarm state. It
also can use the emergency call to ask for emergency help.
How To Learn/Delete Code Of Detector
In power-off states, press “Function” Key, and power alarm host at the same time,
then release the “Function” key, the screen will show as following:
Function menu 9, learning code state, it is flashing
Learning display, “ ” (over line) it means the zone have been learned. “ ” (middle line)
it means the zone is empty or the code has been deleted.
Zone type: “0” is common zone. “1” is emergency zone.
Zone number display
Press “ <” key to choose zone number. Press “ >” key to change the zone type. After
choosing zone number, Then press “Function Key” to confirm, the alarm host will
make an indicative “beep” sound and display like 01:0- 09. and 09 stop flashing, It
means the zone is empty and enter learning code state to wait for receiving signals.
At this time, you can trigger the detector to emit signal. If alarm host receives the
signal, it will make two indicative “beep, beep” sound. And the “ “ (middle line)
will change to “- ” (under line) automatically, which means you have learned code
successful. Then you can press“< ” key to learn code in other zones, or you can
press “Reset” key to exit learning code state.
100-Zone Wireless Alarm System
-6-
There are eight functions altogether. Please refer to “ Operation Guide” chapter for
specific operations..
3 “ ” key: It is used to complete setup function together with “Function” key.
4 “Reset” key: When alarm occurs, press this key to stop alarming, and alarm
message will be automatically kept in record. When entering into setup state, press
this key to exit. KS-200B-B alarm host, when alarm occurs, press this key to stop
alarming, at the same time, it stops dialing other telephone numbers, and alarm
message will be automatically kept in record. When entering into setup state, press
this key to exit.
5 Time Display: Usually, it is used to show time, and the second light is flashing.
When alarm occurs, it is used to display alarm time and the second light is
completely on. When entering setup state, it is used to display setup contents and
the second light is completely on.
6 Orientation Display: Usually, it is used to display second. When there is an
alarm, it is used to indicate alarm location (defense area). When entering into
setup state, it is used to display function setup items.
7 Microphone: Only KS-200B-B have this function, please aim at microphone
when recording.
1 Interface Of Alarm Output: It provides with a group of normal open alarm
output, a group of normal close alarm output and a group of uncontrolled DC+12V
300mA output.
Interface Of Normal Open/Close Alarm Output: There is a label like
on the rear panel of main unit, the alarm output contact it can load is 1A 120VC or
3A 30VDC, it controls other equipments when alarming. When the power of
controlled equipments larger then the contact it can load, it is not allowed to
directly connect controlled equipments with this interface, it should adopt
middle relay to avoid damaging main unit.
、>
、
、
、
、
、
1
2
3
4
56
7
10 0-Z o ne Wir e les s A lar m Sys tem
TI ME OR IEN TATI O N

100-Zone Wireless Alarm System
-7-
Interface Of DC: V+and C end provide other devices with+12V-13.8V300mA
DC output. V+end is anode of DC, and C end is cathode of DC.
2 DC Input: Interface of +12V DC input, the polarity is .When it needs to
collocate with large capacity battery, it can be connected with backup power. This
interface has self-charge device and it can automatically between AC and DC. This
interface should not be short-circuit. If build-in backup battery is adopted, this
interface should not be connected with power.
3 Power Switch: When it is turned off, the main unit doesn’t work, but backup
battery still self charge with AC power.
4 Fuse: AC powr fuse, it is AC 220V1A tube fuse.
5 AC Power Input: It adopts AC 220V 50Hz.
6 Extension Socket: It connects with telephone set.
7 Outside Line Socket: It connects with outside line
5.2 KS-200AT Wireless PIR Detector
It sends alarm signal once when it is powered on.
1 Infrared Sensitivity Selection: If the jumper is inserted at “H” position, the
distance it can detect is 8 to 12 m. If the jumper is inserted at “L” position, the
distance it can detect is about 4 to 8 m. Lower sensitivity is
recommended under satisfaction.
2 Backup Power Input: There are floating charge devise,
if backup battery is not selected, it can be connected with
rechargeable battery or storage cell and allowable voltage
of input power is DC 12-13.8V.
3 AC Power Input.
4 Forced Emit Control: If it is short-circuit, the detector
will continuously send alarm signal till the jumper is
disconnected. Usually, it is used to test whether the emission circuit is normal.
5 Double PIR Sensor: The surface should be kept clear and it is not allowed to
touch the surface by hand. If the surface is dirty, clear it with a cotton ball dipped
、
、
、
、
、
、
、
、
、
、
、
123 4
PUSEPUSE
4
1234
PUSEPUSE
5
23
67
C V + V +
H
L
100-Zone Wireless Alarm System
-18-
Press 12# # to delete the 2nd group of informed telephone number.
Press 13# # to delete the 3rd group of informed telephone number.
Press 14# # to delete the 4th group of informed telephone number.
Press 15# # to delete the 5th group of informed telephone number.
Press 16# # to delete the 6th group of informed telephone number.
Press 17# # to delete the 7th group of informed pager number.
Press 18# # to delete the 8th group of informed pager number.
Press 19# # to delete all 8 groups informed telephone numbers.
(5) How To Record
Press 30 #, after hearing indicative “beep” sound, aim at the Microphone on the
front panel to speak what you like. The record time should not beyond 10 seconds,
Press # to finish. If the record is beyond 10 seconds or don’t press “#” key to stop
after 10 seconds, it will cause the un-completion or loss. You should record it again.
Each time enter this operation, the original voice will be lost. But the latest
record will be save permanently if no power failure.
(6) How To Play Record
Press 31# to play your record for 10 seconds at most. After 10 seconds, there is an
indicative “beep” sound, then you can go on other operations.
(7) How To Operate When Receiving Alarm Telephone Numbers
While receiving alarm, pick up telephone receiver, it will report in pure English to
tell you “which zone” occurs alarm. After an indicative “beep” sound,
press:2#------to stop alarming and stop dialing other inform telephone numbers.
5#-----re-play alarm record
If your command is effective, there should be an indicative “beep” sound, or you
have to press again.
E.g. There is alarm occurs in the 25th zone at No.3 building in XX garden. When
answering alarm telephone, you will hear the voice alert “Ding dong, attention
please!!!< No.3 building, XX garden in quanzhou city, fujian province> the 25th
zone occurs the anti-theft alarm, please do some effective operations quickly!!!”.
( <> is what you pre-record). After hearing the voice alert, you will hear an
indicative short “beep” sound, the system will wait for 20 seconds to receive
commands. Enter“5#”to replay if the alarm voice is not clear. After an indicative
short“ beep” sound, enter“2#”to stop alarming, and stop dialing other alarm
telephone numbers. If there are no operations within 20 seconds, the main unit

100-Zone Wireless Alarm System
-17-
Press 11# CCCCCC # to set the 1st group of informed telephone number.
Press 12 # CCCCCC # to set the 2nd group of informed telephone number.
Press 13 # CCCCCC # to set the 3rd group of informed telephone number.
Press 14 # CCCCCC # to set the 4th group of informed telephone number.
Press 15 # CCCCCC # to set the 5th group of informed telephone number.
Press 16 # CCCCCC # to set the 6th group of informed telephone number.
Press 17 # CCCCCC # to set the 7th group of informed pager number.
Press 18 # CCCCCC # to set the 8th group of informed pager number.
The above “CCCCCC” is the telephone (or mobile phone or pager) number.
Note:
1、During the course of entering telephone numbers (mobile phone, pager), Use a
“*” as a pause for two seconds. The number of * is subject to the type of telephone
exchanger, e.g.: mobile phone, group telephone. Semi-automatic pager station, etc.
2、Each group of number (including *) should not beyond 27 digits.
3、 It is unnecessary to enter superabundance phone numbers. If wrong numbers
has been entered, it can be directly cover with or be deleted.
4、When alarm host dials the pager. It will automatically add the signal code. But
it should be operated according to the local pager station formula.
E.g.: How To Set Pager In Middle Northern Of Quanzhou City
Press “95951 1234567”, there is indicative voice “hang up to answer the same
phone number, information code press 1 and press # to finished”. So the users shall
be enter into “1”, the pager formula as follows”
17#959511234567* * * * * * 1 * * #
The above * is a pause. Every * has 2 seconds pause time. The * number is subject
to time of the pager indicative voice.
E.g.: If the users want to set the first group telephone number to be “1234567”,The
second group to be “1234567” with the extension number is 801,the third group to
be 13900000012.
You can press as following:
11#1234567#
12#1234567**801#
13#13900000012#
(4) How To Delete Informed Telephone Numbers
Press 11# # to delete the 1st group of informed telephone number.
100-Zone Wireless Alarm System
-8-
in 90% alcohol.
6 Alarm Indicator: It lights when emitting alarm signal. Usually, to protect
wireless emission circuit, the alarm emission duration is controlled within 5
seconds, and the alarm interval is about 10 seconds. During the alarm interval
duration, the infrared detector doesn’t respond to alarm signals.
5.3 KS-200ACT Series Wireless PIR Detector
When KS-200ACT wireless PIR detector is powered on, it will be automatically
blocked for 20 seconds and won’t receive infrared signals. After 20 seconds, it will
automatically enter arm state.
1 Forced Emit Control: If it is short-circuit, the
detector will continuously send alarm signal till the
jumper is disconnected. Usually, it is used to test whether
the emission circuit is normal.
2 Infrared Sensitivity Selection: If the jumper is
inserted at “H” position, the distance it can detect is 8
to 12 m. If the jumper is inserted at “L” position, the
distance it can detect is about 4 to 8 m. Lower sensitivity
is recommended under satisfaction.
3 AC Power Input.
4 DC Input: There are floating charge devise, if backup battery is not selected,
it can be connected with rechargeable battery or storage cell and allowable voltage
of input power is DC 12-13.8V.
5 Double PIR Sensor
6 Transmit Address Code: It is used to change the address code of detector, and
only KS-200ATI,KS-200BTI have this function. They can transmit the signal of
KS-200DCT wireless PIR detector, KS-20BW wireless door sensor, smoke
detector to KS-200B-A/B series main unit.
7 Arm Indicator: It lights when it is in arm state, which means it enters defense
state, only KS-200ATI, KS-200BTI detectors have this function.
8 Alarm Indicator: It lights when it alarms.
5.4 KS-200ATI Wireless PIR Detector
Base on KS-200ACT, KS-200ATI wireless PIR detector increase functions to
arm/disarm/emergency alarm and transmit wirelessly. The detector is blocking by
itself for 20 seconds when powered on. And during the time, it doesn’t receive any
、
、
、
、
、
、
、
、
、
1
8
9
6
L H

100-Zone Wireless Alarm System
-9-
alarm signal. After which, it enters arm state automatically.
Functions: Infrared Detecting, Control By Remote Controller, Transmit Wirelessly.
5.5 KS-200BTI Wireless PIR Detector
Base on KS-200ATI, KS-200BTI increase functions to alarm on the spot, it sends
alarm signal for 5 seconds when triggered, at the same time, it make alarm sound on
the spot for 30 seconds.
Functions: Infrared Detecting, Alarm On The Spot, Control By Remote Controller,
Transmit Wirelessly.
6. Interfaces Instruction
Interfaces Instruction Of KS-200B Main Unit
V+ Terminal -------- Anode of DC 12V—13.8V output.
C Terminal -------- Cathode of DC 12V—13.8V output.
DC Input --------- If build-in backup battery has been selected, it is not need to
connect with outer power.
Alarm Horn --------- Active alarm horn is adopted, which will not affect the
operation of built-in speaker in alarm host. The horn is optional according to
specific requirements.
7. System Installation
7.1 Basic Requirements Of System Installation
(1)During installation, suitable types and models of detectors should be adopted
according to the user’s requirements on defense areas.
(2)The installation location, angle and height of detector are determined
3
PUSEPUSE
3
C V+ V +
12 V 1.2 Ah
100-Zone Wireless Alarm System
-16-
Well connect alarm host according to the charter of “ Interface Instruction”. Pick
up telephone receiver and operate as following:
Press # # # -------- It will make a short “beep” sound, which means system has
entered setup state. Press AAAAAA# ------ It means enter the password and
confirm it.
“AAAAAA” stands for password. The original password is “000000”. There will
be a short “beep” sound if the password is correct. Then you can go on the next
operations. Or it will exit the setup state. The password is modifiable. To modify
it, please refer to the “ password modification” charter.
Note
1、 After press # # #, the outside line will be cut off. The power of telephone is
provided by alarm host. There should be no dialing tone and other voice signals.
Or it shows the outside line still be connected, and should press again or change
the telephone set.
2、 After press # # #, if there are rapid “beep---beep---”sound. Usually, it is
because that the extension socket and line socket are wrongly connected. And
cause alarm because of line cut-off.
3、 If no any operations within 20 seconds in setup state, the system will
automatically exit.
Note: All the following operations should be done in setup state. And press 0 #
0 # to exit when finished.
(1)How To Set Alarm When Telephone Line Short Circuit Or Open Circuit
Press 6# to open the function to test line short circuit and open circuit.
Press 7# to close the function to test line short circuit and open circuit.
It is recommended to open this function, it will make urgently “Beep, Beep”
sound when it test telephone line short circuit or open circuit.
(2) Password Modification
Press 9 # AAAAAA # BBBBBB # BBBBBB #.
The “AAAAAA” is original password, the ex-factory state is “000000”. “BBBBBB”
is new password. After password is modified, the original password will be invalid.
If you want to program again you should enter the new password.
The users should take care of their password. If the password is lost, please contact
the agent to ask for help.
(3)How To Set Inform Telephone Number
