KATA Venus User manual

- 1 -

- 2 -
Contents
I. Safety and Precautions........................................................................................................................................ 3!
II. Venus S Outline .................................................................................................................................................... 7!
III. Preparations ......................................................................................................................................................... 8!
IV、Description of Cell Phone ............................................................................................................................ 15!
V. Basic operation of Venus S............................................................................................................................. 20!
VI. Operation menu function................................................................................................................................ 25!
Communication ....................................................................................................................................................... 25!
VII. Operating instructions of editor .................................................................................................................. 50!
VIII. Application of USB storage function ........................................................................................................ 51!
IX. Appendix 1.......................................................................................................................................................... 52!
X. Appendix 2........................................................................................................................................................... 55!

- 3 -
I. Safety and Precautions
To use your Venus S safely and effectively, please read the following information
before use:
Please turn off Venus S when you are near a chemical plant, a gas station, an oil
depot or other explosives.
Please keep Venus S out of the reach of children.
To ensure safety, please use earphone during driving; Otherwise, unless emergency,
you should make a call after parking your car by the roadside. Do NOT use the
phone during driving at high speed.
Do NOT use your Venus S while in a plane. Please check whether Auto Power On is
set or not before board.
Do NOT use your Venus S in a hospital to avoid interference with the normal
operation of medical equipment which may result in a medical accident. If the Venus
S is used near a pacemaker, audiphones and some medical electronic equipment,
you should pay special attention to that the Venus S may interfere with these
devices.
Auxiliaries and accessories NOT provided by us are excluded from the guarantee.

- 4 -
Do NOT dismantle your Venus S by yourself. In case of a failure, please contact the
service station specified by us.
Do NOT charge Venus S with no battery. Please turn off Venus S before removing
the battery; otherwise, the phone memory may be damaged.
The phone should be charged in the environment which is well-ventilated, and should
be kept away from the inflammables and explosives.
To avoid demagnetization, please keep Venus S away from magnetic substances,
such as magnetic disk, credit card, etc.
Please be sure the phone isn't exposed to any liquid. If this situation occurs, please
remove the battery and contact the service station specified by us.
Please use Venus S in the environment which is neither too hot nor too cold, and do
not expose Venus S to the strong sunlight or use in high-humidity environment.
Do NOT use liquid or wet cloth with strong detergent to clean Venus S.
Your Venus S has photo and record functions, so please use these functions
following the related laws and regulations. You may violate the law and regulation if
taking photo and record without authorization.
Do NOT throw, drop or hit the Venus S during use to avoid damage to the housing or

- 5 -
the elements inside the phone.
Do NOT dispose the worn battery as common domestic rubbish. Please dispose the
worn battery according to the specified instructions where the disposal of a worn
battery is clearly specified.
〈Note〉：1. Kata won't undertake any responsibility for any consequences caused by
failure to observe the above-mentioned suggestions or improper applications.
2. The provided cables are only applicable to this type of mobile phone
and the provided charge; you can also connect the phone to the PC by a USB cable
to charge the phone. Do not charge the phone by any other mode.
If any content described in this manual goes against that of your cell phone, please
subject to the real cell phone.
The original factory is entitled to modify the manual at any time without further notice.

- 6 -

- 7 -
II. Venus S Outline
The following is the view of the phone：

- 8 -
III. Preparations
Installation of your SIM card
You can apply for two different numbers offered by two network providers and get two
SIM cards (users identify cards).
With those two SIM cards, you can use various functions of this cell phone. Many
parameters required for communications are stored in the SIM cards. Personal data,
including the PIN (personal identification number), phonebook, SMS and other extra
system services can also be stored in the SIM cards.
Warning：Do NOT twist or scratch the SIM card and expose it to static electricity, dust
or water. If you lost your SIM card, please contact your network operator for help.
To install your SIM cards, please turn off your Venus S first, remove the back cover,
and insert the SIM cards into the SIM card slots at the back of the phone.
Please install the SIM cards as shown below：

- 9 -
Note：The SIM card is a small object, please keep the card out of the reach of the
child to avoid swallowing the card by accident! Do not touch the metal surface of the SIM
card and keep it away from electromagnetism to avoid loss and damage on the data. You
will not be able to connect to the network if the SIM card is damaged.
Installation of memory card
The phone supports T-FLASH card as to expand the memory space. Please install or
take out the memory card as per the following picture after shutting down the phone.
Note：The T-FLASH card is a small object, please keep the T-FLASH card out of the
reach of the child to avoid swallowing the card by accident!

- 10 -
Tip：The phone supports a memory card with capacity up to 8GB. It is recommended
that only the attached standard TF card and other TF cards of well-known brand like
SanDisk and Kingston are used. Other TF cards may be not compatible with the phone.
Installation of battery
Please use the original-packaging battery and accessories. Store the battery well if it is
not used.
Please install the battery at shut down status.
Note：Please follow the correct procedures as shown in the figure to prevent damage to

- 11 -
the battery contact points.
Charge the battery
The new battery must be fully charged and discharged for several times to reach its
best performance.
Charge as soon as possible when the power is used up as over-discharge will
damage your battery.
Disconnect the charger and the power supply and then disconnect the mobile phone
when the battery is fully charged.
Connect Venus S to the charger as per the drawing.

- 12 -
When charging, if the phone is switched on, the power quantity icon at the top right
corner of the screen will twinkle and will stop twinkling and fully display when the battery is
fully charged. If the phone is switch off, an icon will appear at the screen to show the
battery is in charging and icon will be static and OK will be display on the screen when the
battery is fully charged.
Note：A little heating while charging is normal.

- 13 -
Use of battery
The performance of the battery is affected by multiple factors including your wireless
loading network configuration, signal intensity and temperature when using the phone, the
function or settings you selected, the accessories adopted for Venus S and other applied
program modes.
To optimize the performance of the battery, please do as following regulations：
New battery or a battery is left unused for a long time should be charged for a long
time；
Keep the temperature at or near room temperature when charging；
The battery may require longer time to be full charged after being used for a long
time and this is normal. If the call time becomes too short, you may need to buy a
new battery produced by original factory or authorized by our company. Unqualified
battery or accessories may damage Venus S and even cause danger！
If the battery is left unused for a long time or the power is too low, it may require
longer time for the charging interface to appear, please wait patiently.
Note：1、For your safety and environment , please do not throw away the battery
everywhere.

- 14 -
2、When the capacity of battery is too low, the phone will alarm “capacity too
low”. Venus S should be charged in time.
Warning: Explosion, fire or personal injury may be caused by any type of battery
short-circuit！
PIN
PIN1 code: Personal identification code used to enter SIM card and to prevent others
to use the SIM card without your permission. If PIN1 code safeguard function of your
Venus S has already been started, the system will display “Enter SIM card 1/2 PIN” to
enter when switching on the phone. * will be displayed instead of the PIN1 you entered.
You can get PIN1 from your network provider together with the SIM card.
PIN2: The personal identification number use for special functions such as charging
function provided by the network.
PUK and PUK2 (8 digits）
A PUK is required to change the PIN. To change the PIN2, you need to use PUK2
(personal unlock code). If PUK is not provided together with the SIM card, please ask for it
from your network provider.

- 15 -
〈Warning〉：If the PIN code is entered continuously three times, the SIM card will be
locked in. Please consult the network supplier right away to look for deciphering.
Unauthorized deciphering may cause permanent failure to the SIM card.
IV、Description of Cell Phone
Dialing key
Make or answer calls.
Short pressing the dialing key can enter call log under standby status.
Hang-up key
Hang-up or reject a call.
On/off key
Long press the key to switch off the phone under standby status.
Long press the key to switch on the phone when the phone is switched off.
Slide key
Adjust the volume when you play MP3/MP4.

- 16 -
Icons on screen in standby status
SIM card 1 Antenna
SIM card 2 Antenna
Alarm clock activated
SIM card 1 SMS
SIM card 2 SMS
SIM card 1 MMS
SIM card 2 MMS
Battery
Vibration
Missed calls in SIM card 1
Missed calls in SIM card 2
SIM card 1 GPRS
SIM card 2 GPRS
Bluetooth
Call divert activated in SIM card 1

- 17 -
Call divert activated in SIM card 2
Languages & Input Methods
English input method is provided in Venus S. For details, please refer to chapters
related to language editing, where you can learn different input methods and how to
switch between them.
Incoming Call alert method
The built-in vibrating motor and buzzer in Venus S provides the following alerting
modes:
Only ringing
Only vibrating
Vibrating and ringing
Vibrating then ringing
Descriptions of nouns
Making a local call
The simplest way to make a domestic call is to input a phone number by
numeral keys and press the dialing key. If call by SIM card 1, the screen will display

- 18 -
“SIM Card 1 Dialing”, and if called by SIM card 2, the screen will display “SIM Card 2
Dialing”.
Call status will display on the screen when the call is answered.
Press the hang-up key to end the call.
Make domestic calls: zone number + phone number + dialing key.
The left soft key can be set the dialing key of SIM card 2. This function is
activated in the menu of “Call center/SIM card 2 call settings/SIM card 2 dialing
settings/Left soft key”.
Making an international call
To make an international call, long press or repeatedly short press the “*” key
until the symbol “+” is displayed on the screen. This allows you to make an
international call without knowing the prefix number of that country (e.g. China is
+86).
Then input the country code and the complete phone number. The country code
is subject to convention, e.g. Germany is 49, Britain is 44 and Sweden is 46, etc.
Make international calls: + country code + complete phone number + dialing

- 19 -
key.
Call extension of a fixed phone
Extensions of some fixed phones are not accessible directly, in such case, you
need to dial the host number and then the extension number. Simply insert the letter
“P” between the host number and the extension number and you can call the
extension. You can input a “P” by long pressing or repeatedly short pressing the *
key.
Call extension of a fixed phone: phone number + P + extension number +
dialing key.
Make emergency calls
In any country where digital GSM is used, you can make an emergency call if
Venus S is covered by the network (you can know about this by checking the signal
strength indicator bar at the upper corner of the display of the cell phone). If your
network operator does not provide roaming service in that area, the screen will
display "EMERGENCY CALLS ONLY", telling you that you can make this kind of call
only. If you are in the coverage of the network, you can make emergency calls even
if your SIM card is not inserted in.

- 20 -
* In some areas, the 112 (emergency call) service is provided by the network
operator. If there is anything abnormal, contact your network operator!
IMEI
International Mobile Equipment Identity. You can see the bar code label printed
with this number at the back of the Venus S after you have turned off the Venus S
and remove the battery. This number is also stored in the cell phone, and can be
displayed when you enter "*#06#" on the screen dial interface.
V. Basic operation of Venus S
Switch on
Press and hold on “ON/OFF” to start up the cell phone. If no password settings are
