Kauber INCEILING XL User manual

w w w . k a u b e r . e u
-1-
IN-CEILING PROJECTION SCREEN
INSTALLATION MANUAL
INCEILING XL

w w w . k a u b e r . e u
-2-
KAUBER InCeiling is a premium-class electrical projection screen designed for installation in
suspended ceilings. Its versatile aluminium housing has been designed to facilitate installation. In the
Tensioned version, the screen is additionally equipped with a special system improving flatness of the
projection surface. The InCeiling series was created for suspended ceiling installations in both conference
rooms and home-cinema applications.
IMPORTANT!!!
INSTALLATION AND APPLICATION GUIDELINES
1. One of the wooden blocks protecting the content of the package is a template for installation
holes –do not dispose of it before completion of the assembly and installation works.
2. The housing and lower beam of the screen are protected against mechanical damage with
polyurethane foam. Do not remove the main housing protection before step 9 and the lower beam
protection before step 11 of this assembly and installation manual.
3. The screen shall be installed away from humidity and direct source of strong sunlight.
4. Use a soft damp cloth to clean the screen. Do not use active cleaning chemicals. Protect the screen
assembly from penetration of water or other liquids inside the housing. Carefully wipe the screen
dry after cleaning, to remove any moisture.
Content of the set:
Qty.
Projection screen
1
Side panels
2
Mounting bracket
2
Wooden template for installation holes
1
Template for the screen slot
1
Hole marker
1
Threaded rods
4
M8 nut
12
Ø10 rawlplug
10
Screen limit position adjustment key
1
Box spanner No.13
1
Wall-mounted control switch panel (accessible for screens without built-in wireless
controller)
1
Protection gloves for installation works
2 pairs

w w w . k a u b e r . e u
-3-
INSTALLATION
1. Carefully unpack the contents of the box with particular attention for the wooden blodks
protecting the contents of the package. Remember that one of them is a template for drilling
installation holes –do not dispose of it before completion of the installation works!
2. In the location chosen for installation of the screen, apply the foil template for the main screen slot
and then draw around its perimeter with a pencil (Figure 1). Remove the foil template and
carefully cut the ceiling slot along the pencil line .
Figure 1
3. On each of the two sides of the slot, apply one of the wooden blocks protecting the contents of the
package in a way to aim the arrow (printed on the block) towards the outer edge of the slot
(Figure 2 , Figure 2a).
Figure 2
TEMPLATE

w w w . k a u b e r . e u
-4-
Figure 2a
4. Hold the template and then pass the marker through the holes in the block and mark the hole
drilling points on the fixed (primary) ceiling (Figure 3).
Figure 3
5. Using a ø10 drilling bit, drill rawlplug holes in the marked points. Holes shall be drilled in specific
sequence, starting from number 1 (as marked on the template block) (Figure 4). After drilling
whole number 1 move to drilling holes 2 and 3. Then drill holes number 4 and 5. Repeat the
sequence on the other side of the slot.

w w w . k a u b e r . e u
-5-
Figure 4
6. Using the rawlpugs and screws included in the package fix the mounting brackets to the primary
ceiling (Figure 5).
7. NOTE! The rawlplugs and screws supplied in the installation kit can only be used for structural
ceiling materials (concrete, Suporex or other similar materials). Shall the screen be mounted on
other types of material, choose appropriate plugs and screws.
Figure 5

w w w . k a u b e r . e u
-6-
8. Cut the threaded rods to the right length (calculated using the formula below):
Rod length =
Distance between the primary ceiling and
the bottom edge of the suspended ceiling
-10 cm
9. After cutting the adequate lengths of the rods, screw them into the sockets in the mounting
brackets and then counter-lock with the M8 nuts (Figure 6).
Figure 6
10. Fit an M8 nut on each of the rods (to a distance of approximately 5-6 cm from the bottom end of
the rod) and then match the screen housing. If needed, adjust the nut position in a way to rest the
screen housing mounting brackets on the nuts, with the bottom plate of the housing pushed all the
way against the suspended ceiling panel.
Figure 7

w w w . k a u b e r . e u
-7-
11. After connecting the power supply (see page 11), slide the screen housing on the rods and use the
box wrench to tighten each of the M8 nuts. Check for stability of the entire assembly (Figure 8).
A correctly installed screen shall be levelled in all planes. Adjust the position by turning the
installation nuts in or out on the adequate threaded rods.
Figure 8
A correctly installed screen is shown below (Figure 9). All the screw and nut fitments shall be
countered. Such an assembly ensures protection against vibration and potential resonance. Moving
nuts 1 and 2 allows accurate levelling of the screen, required to ensure its smooth and flawless
operation.
Figure 9
SUFIT –PRIMARY CEILING
Kontra –Counter washer
Szpilka –threaded rod (pin)
Nakrętka – nut
EKRAN - screen

w w w . k a u b e r . e u
-8-
12. Upon delivery, the screen is preset to limit positions specified in the order. Shall the screen
positions be too low or too high, the end positions can be adjusted using the special key provided
in the installation package.
NOTE! Only qualified persons may perform the end-position adjustments. All adjustments made
shall be the sole responsibility of the user. Non-qualified adjustment of the mechanical settings
may cause damage to the screen and shall void any guarantee claims.
Figure 10
13. After final inspection of the entire installation, mount the side blends (magnet fitment on both
sides of the housing) (Figure 11). In the case of side-tensioned screens, unwind the entire screen
surface. Need being, adjust the tensioning with the control screws on both sides of the lower bar)
using an Allen key.
Figure 11
Access to limit position adjustment

w w w . k a u b e r . e u
-9-
14. After installation of the screen, remove the scratch protection foil from the housing (Figure 12,
Figure 12a).
Figure 12
Figure 12a

w w w . k a u b e r . e u
-10-
ELECTRICALWIRING
NOTE!
Only certified electricians shall be allowed to make the electrical connections of the screen.
Before installing the main housing of the screen, route the power supply cable to the installation point and
then connect it to the screen following wiring diagram A (Figure 13A) or wiring diagram Bin case of
screens with built-in wireless control modules (Figure 13B).
. .
DIAGRAM A
Figure 13A
DIAGRAM B (built-in wireless controller)
Figure 13B
Faza –Hot wire
Zerowy –Neutral wire
Uziemienie –Grounding
Przełącznik klawiszowy – Switch panel
Czarny –black
Niebieski –Blue
Brązowy – Brown
Zółto zielony – Yellow/Green
Silnik ekranu –Screen motor

w w w . k a u b e r . e u
-11-
Wiring of the control switch panel (provided in the kit)
(Control switch panel provided in the screen installation kits without wireless
controller)

w w w . k a u b e r . e u
-12-
Wiring of the switch control panel to the screen
Pin Description Color
L Hot (L) Brown
N Neutral (N) Blue
X Earthing Yellow/Green
1 Black
2 Brown

w w w . k a u b e r . e u
-13-
TECHNICAL SPECIFICATIONS
Housing dimensions:
INCEILING XL
A- Screen width
B- Screen height
F = A + 162 mm
G = A + 19 2mm
J = A + 40 mm
K = 50 mm
INCEILING XL + BLACK FRAME
A- Active screen width
B- Active screen height
C = A + 100 mm
D = B + 100 mm
F = A + 262 mm
G = A + 292 mm
J = A + 140 mm
K = 50 mm
INCEILING XL + BLACK FRAME +
BLACK STRIPE
A- Active screen width
B- Active screen height
C = A + 100 mm
D = B + 50 mm + height of the black stripe
F = A + 262 mm
G = A + 292 mm
J = A + 140 mm
K = 50 mm

w w w . k a u b e r . e u
-14-
INCEILNG XL + TENSIONERS
A- Active screen width
B- Active screen height
C = A + 100 mm
D = B + 100 mm
F = A + 392 mm
G = A + 422 mm
J = A + 270 mm
K = 50 mm
INCEILNG XL + TENSIONERS + BLACK
STRIP
A- Active screen width
B- Active screen height
C = A + 100 mm
D = B + 50 mm + height of the black strip
F = A + 392 mm
G = A + 422 mm
J = A + 270 mm
K = 50 mm
Technical specification:
Supply: 230V, 50Hz
Power rating: 140 W –screen without wireless control system
160W –screen with built-in wireless control system

w w w . k a u b e r . e u
-15-
Thank you for choosing a KAUBER screen
Feel free to purchase other products of the KAUBER brand
