Da-Lite Deluxe Insta-Theater User manual

INSTRUCTION BOOK FOR
Deluxe Insta-Theater

Introduction
Caution
Screen Care
1. Avoid touching the ilms during raising or lowering of unit.
2. Do not set up the screen on an unstable or uneven surface.
This may cause the screen to fall or tip over, resulting in
damage to the screen or personal injury. Be especially careful
when setting up at home where small children may be present.
3. When screen is not in use and retracted, use the built-in feet to
stabilize it on a lat surface. Standing the screen on one of its
ends creates the risk of falling over, and should be avoided.
4. Do not hang or attach items to the screen.
1. Do not leave the screen in areas subject to direct sunlight.
2. Keep the projection surface of the screen free from dirt and
dust, which can interfere with the quality of the projected
image. If the screen becomes dirty, lightly wipe it of with soft
cloth moistened in a weak, 20 to 1 solution of a mild neutral
detergent and water. Benzine, thinner, and other volatile agents
can cause permanent damage to the screen and should never
be used for cleaning.
3. Do not set up the screen in areas subjected to strong breeze.
This may cause the screen to move and interfere with the
quality of the projected image.
Thank you for purchasing this Da-Lite product. Before attempting
to use it, make sure to carefully read the contents of these
instructions.

Parts Identiication
1. Lifting Handle
2. Slat handle
3. Screen ilm
4. Skirt ilm
5. Left end cap
6. Rotating foot
7. Bottom case
8. Right end cap
9. Case cover (90" and 100"
only)
10. Case latch
11. Slat
12. Long arm
13. Upper arm hinge
14. Short arm
15. Lower arm hinge
16. Air shock
17. Case handle
18. Extending Handle
14
12
17
16
15
13
18
2
3
4
11
6
9
8
7
5
10
1

Setting Up the Screen
1. Rotate feet until they are perpendicular with the case (Figure 1).
2. Release the latches and open the case cover. On the 90"
and 100" models remove extending handle and extend it
as shown (Figure 1).
NOTE: Push lightly down on the center of the case to release
the latches.
3. Pull up the screen slowly at a certain height using the Lifting
Handle then grasp the Slat handle and raise the screen slowly
keeping the slat level as you raise the screen (Figure 3).
4. On 90" and 100" models only Place the end of the extending
handle under the slat handle as shown below and raise screen
to desired height. (Figure 4).
Figure 1
Figure 2
Figure 3
Figure 4

Storing the Screen
1. Grasp the Slat Handle and lower the screen slowly back into
the case. Make sure you hold onto the handle and keep the slat
level as you lower the screen back into the case (Figure 5).
2. On 90" and 100" models only Place the end of the extending
handle under the slat handle as shown below and lower the
screen until you can easily reach the slat handle (Figure 6).
3. On 90" and 100" models only Collapse the extending handle
by pressing on the button as shown and sliding the two halves
together. Store extending handle in case (Figure 7).
4. Close the case cover and latch it. It may be necessary to press
down on the case top to get the latches to engage properly
(Figure 8)..
NOTE: Before carrying the case, rotate the feet, so they are out
of the way (Figure 8).
WARNING: When storing the screen, be sure that you
protect it from falling. Leaning the case against a wall or
other surface creates the danger of falling over.
Figure 5
Figure 6
Figure 7 Figure 8

Speciications
55½"/71¼" / 87"
11¾"
4½"
4½"
60"
79¼"
73"
80¼"
80"
81½"
90"
88"
100"
96"
Screen Height Shipping dimensions Weight of unit (lbs.) Shipping weight (lbs.)
60" 6¼" x 7" x 61½" 14.0 17. 3
73" and 80" 6¼" x 7" x 77 ⅛" 16.4 20.4
90" and 100" 6¼" x 7" x 91¼" 19.8 23.8

83776
A Milestone AV Technologies Brand
3100 North Detroit Street
Warsaw, Indiana 46582
P: 574.267.8101 or 800.622.3737
F: 574.267.7804 or 877.325.4832
E: inf[email protected]
www.da-lite.com
DL–0277 01.14
© 2013 Milestone AV Technologies LLC. Printed in U.S.A.
