Kauber FRAME Series User manual

PROJECTION SCREEN
INSTALLATION GUIDE
FRAME LED
ACTIVE

ww w . k a u b e r . e u
-2-

The FRAME series includes projection screens with a perfectly tight projection surface, stretched
over a stylish aluminium structure. This series is dedicated to demanding users with a special
purpose for home cinema.
IMPORTANT!!! INSTALLATION AND OPERATION NOTES
1. The screen should be installed in a location away from moisture and strong sunlight.
2. Use a soft, moistened cloth for cleaning. Do not use active cleaners. After cleaning, the screen should be
carefully wiped to remove any residual moisture.
3. A properly mounted screen must be absolutely levelled.
4. DIMENSIONAL TOLERANCE: Projection surface: ± 0.5% of the nominal size; components ±5mm
Package contents:
Quantity
Frame screen – frame elements
4 pcs
Mounting angle
8 pcs
M6x8 screw ("A" screw)
64 pcs
Washer 6.6
64 pcs
M6x12 set screw ("B" screw)
10 pcs
Magnet included with the screw
2 pcs
Surface fixing hooks
22 pcs
Wall mount bracket
2 pcs
Mounting pins for brackets (pin + screw)
4 pcs
Magnet holder
2 pcs
Holder mounting pins (pin + screw)
4 pcs
Projection surface
1 pc
Mounting wire
4 pcs
Frame profiles 2.5 cm wide
4 pcs
LED tape
2 pcs
DreamScreen device
1 pc
5V power supply
1 pc
HDMI cable
1 pc
ww w . k a u b e r . e u
-3-

SCREEN ASSEMBLY
1. Put all frame elements on a clean and level surface. Insert the steel angles into the frame profile as shown in
Fig. 2.
Fig.1 Fig.2
2. Insert the second frame to create a right angle, then fix the angle to the screen frame using the included "A"
screws (Fig. 3). Adjust the screen profiles to obtain a right angle and tighten the "A" screws (Fig. 4)
Fig.3 Fig. 4
ww w . k a u b e r . e u
-4-

3. If the frame profiles form a uniform surface, calibrate the profile using "B" screws, tightening the screws to
obtain a maximum level surface (Fig. 5), leaving space for the screws (Fig. 6), to which we will fix the black
frame profile in the next stage.
Fig.5 Fig. 6
4. After assembling the frame, unfold the projection surface so that the traces of surface sealing are visible at
the top. Straighten the surface (Fig. 7).
Fig.7
5. Slowly slide the steel rods attached to the set (Fig. 8) into the sealed pockets of the surface. Then place the
fixing hooks in the frame element (Fig. 9).
Fig.8 Fig.9
ww w . k a u b e r . e u
-5-

6. Tighten and fasten the surface to the frame according to (Fig. 10 to Fig. 13).
Fig.10 Fig.11
Fig.12 Fig.13
7. Put the black profile on the outside of the frame (Fig.14, Fig.15), then fasten with the "A" screw
Fig.14 Fig.15
ww w . k a u b e r . e u
-6-

8. Fix the attached magnet (Fig. 16) to the bottom profile of the frame (Fig. 17), at a maximum distance of
20cm from the edge of the frame.
Fig. 16 Fig.17
9. Degrease the space along the frame (Fig. 18) then, starting from one of the corners, stick the first stripe of
LED strip (Fig. 19). The second band of the LED strip should be stuck starting from the same corner of the
screen but in the opposite direction. (One LED strip should cover the two sides of our screen, (Fig. 20) the
excess strip should be cut off.) Write down the number of LEDs on each side (information will be necessary in
the configuration of active backlight).
Fig. 18 Fig. 19
Fig. 20
ww w . k a u b e r . e u
-7-

10. Attach the mount brackets (Fig. 21) to the wall, remembering that the hanging screen frame will be about 67
mm above the top edge of the bracket. Mounted brackets must be within 30 cm of the ends of the screen frame.
The screen profile after hanging is locked on the bracket, as shown in the illustration (Fig. 22).
After hanging on the brackets, it is possible to move the screen horizontally (to the left, to the right).
Fig. 21 Fig.22
11.The set includes two wall mount holders, designed to eliminate the distance from the bottom corners of the
screen to the wall (Fig. 22)
Advice! Pull the suspended frame of the screen at the bottom and fix the holder (Fig. 22) to the magnet with
(Fig. 16) Press the screen as much as possible to the wall. Then circle the shape of the holder on the wall, it will
serve as a pattern for attaching it (Fig. 23).
Fig.22 Fig.23
ww w . k a u b e r . e u
-8-

12. Diagram of connecting LED strips, voltage and HDMI cable to the DreamScreen device (Fig. 24)
Fig. 24
13. To set up active lighting, you will need the DreamScreen app, which you should download from the App
Store or Google Play
ww w . k a u b e r . e u
-9-

14. Connecting DreamScreen to a WiFi network
a) Android user
b) iOS user
The application will now connect to the DreamScreen device and add it to the WiFi network. This process may
take several minutes depending on the number of devices. During this process the LED on the device may flash
DreamScreen
ww w . k a u b e r . e u
-10-
Select your WiFi network
from the drop down menu
Add new device to the
WiFi network
Select your device, then go
forward by clicking
“Connue”
Enter the password to the
WiFi network
Select your WiFi network
from the drop down menu
Connect to the WiFi network of
the DreamScreen device
Add new device to the
WiFi network
Enter the password to the
WiFi network
Select your device, then go
forward by clicking
“Connue”

15. Description of the app's
operation.
ww w . k a u b e r . e u
-11-
Slide to the right / Press
the menu to display
groups and added
devices
Groups designed by the
user
Group tle
Devices in the group
Unlock to edit the name
and devices of the
group
Add new device
Edit the group name
LED light intensity
HDMI source
Audio Jack music source
Name of selected device
Sengs
Operaon mode
HDMI music source

ww w . k a u b e r . e u
-12-
Settings of active backlight dimensions
Select “Flex / DIY”mode
Number of LEDs horizontally
Number of LEDs vertically
Select the starting point for LED strips fixing
Unlock to edit
LED 1 or LED2 strips settings
Examples:
120 LEDs on one output,
starting at the top left
corner
Maximum 240 LEDs on two
LED strips starting at the
bottom left corner
Video settings
Adjusting RGB channel
Setting LED fading reaction
Setting RGB tone
Brighter colors will be more
distinctive. It can be switched off or
activated in three modes: Low,
Medium, High.
Detecting panoramic screen
Light intensity settings
regardless of the displayed
content

ww w . k a u b e r . e u
-13-
Audio settings
Audio visualization
Available in 4 modes to improve
your musical experience
Color adjustment
Adjustment of color intensity
Advanced settings
LEDs backlight active zones
Backlight intensity
CEC commands activation to change
active HDMI output
CEC commands activation between
the projector and selected source
Activation of automatic sleep mode after the
projector is switched off
Activation of automatic switching off the LED
strip by the projector
Delay of LED light in relation to the displayed image
(maximum 60 frames)

SPECIFICATIONS
Case dimension:
FRAME
A - width of the surface
B - height of the surface
Thank you for choosing the KAUBER screen.
We invite you to purchase other KAUBER products
ww w . k a u b e r . e u
-14-
C = A + 50mm
D = B + 50mm
