KaVo KaVoLUX 540 LED U User manual

Technician's instructions
KaVoLUX 540 LED U / T

Distributed by:
KaVo Dental GmbH
Bismarckring 39
D-88400 Biberach
Phone [phone]
Fax [phone]
Manufacturer:
Kaltenbach & Voigt GmbH
Bismarckring 39
D-88400 Biberach
www.kavo.com

Table of contents
1 User instructions............................................................................................................................................. 5
1.1 User guide ............................................................................................................................................. 5
1.1.1 Abbreviations ............................................................................................................................ 5
1.1.2 Symbols .................................................................................................................................... 5
1.1.3 Target group ............................................................................................................................ 5
1.2 Service................................................................................................................................................... 5
1.3 Terms and conditions of warranty.......................................................................................................... 6
1.4 Transportation and storage.................................................................................................................... 6
1.4.1 Currently valid packaging regulations ....................................................................................... 6
1.4.2 Damage in transit...................................................................................................................... 6
1.4.3 Information on the packaging: Storage and transportation ....................................................... 7
2 Safety ............................................................................................................................................................. 9
2.1 Description of safety instructions ........................................................................................................... 9
2.1.1 Warning symbol ........................................................................................................................ 9
2.1.2 Structure ................................................................................................................................... 9
2.1.3 Description of hazardous steps................................................................................................. 9
2.2 Purpose – Proper use ............................................................................................................................ 9
2.2.1 Information on electromagnetic compatibility............................................................................ 10
2.2.2 Disposal .................................................................................................................................... 11
2.2.3 Disposal of electronic and electrical devices ............................................................................ 11
2.3 Safety instructions ................................................................................................................................. 12
3 Function description ....................................................................................................................................... 14
3.1 Overview................................................................................................................................................ 14
3.2 KaVoLUX 540 LED U / T ....................................................................................................................... 14
3.2.1 Operating light KaVoLUX 540 LED U (Unit) ............................................................................. 14
3.2.2 Operating light KaVoLUX 540 LED T (touchpad) ..................................................................... 15
3.3 Description of function KaVoLUX 540 LED ........................................................................................... 15
3.4 Dimensions and swing range................................................................................................................. 16
3.5 Technical data and requirements .......................................................................................................... 18
4 Electrical controls ........................................................................................................................................... 19
4.1 Description of circuit board .................................................................................................................... 19
4.2 Wiring diagram....................................................................................................................................... 21
4.2.1 KaVoLUX 540 LED U / T .......................................................................................................... 21
4.2.2 Ceiling mounting set ................................................................................................................. 22
5 Assembling and disassembling the cladding.................................................................................................. 23
5.1 Disassembly of the glass cover ............................................................................................................. 24
6 Mechanical settings ........................................................................................................................................ 25
6.1 Adjusting the swinging arm brake.......................................................................................................... 25
6.2 Set the spring arm brake ....................................................................................................................... 25
6.3 Set the brakes on the operating light head ............................................................................................ 26
6.3.1 Setting the rotary motion und 3D joint movement..................................................................... 26
6.3.2 Adjusting the light head brake................................................................................................... 27
7 Firmware update............................................................................................................................................. 29
7.1 Firmware update KaVoLUX 540 LED U to E50 ..................................................................................... 29
Technician's instructions KaVoLUX 540 LED U / T
Table of contents
3 / 56

7.2 Firmware update KaVoLUX 540 LED U to E70/E80 and KaVoLUX 540 LED T.................................... 30
8 Service mode KaVoLUX 540 LED.................................................................................................................. 33
8.1 Service mode KaVoLUX 540 LED U (unit) ............................................................................................ 33
8.2 Service mode KaVoLUX 540 LED T (Touchpad) .................................................................................. 33
9 Cleaning and disinfection of the light and glass cover.................................................................................... 35
9.1 External cleaning ................................................................................................................................... 35
9.2 Internal cleaning .................................................................................................................................... 35
9.3 Sterilisation ............................................................................................................................................ 36
9.3.1 Sterilising the handles............................................................................................................... 36
10 Troubleshooting.............................................................................................................................................. 37
10.1 Replace the gas spring. ......................................................................................................................... 38
10.2 Install the luminaire insert from the operating light head ....................................................................... 39
10.3 Repair the luminaire insert..................................................................................................................... 40
10.3.1 Replace the strip line ................................................................................................................ 40
11 Safety checks - Test instructions.................................................................................................................... 42
11.1 Mounting the device............................................................................................................................... 42
11.2 Ceiling mounting .................................................................................................................................... 42
11.2.1 Introduction ............................................................................................................................... 42
11.2.2 Safety check instructions .......................................................................................................... 45
11.2.3 Safety Check [STK] Test Protocol ............................................................................................ 53
Technician's instructions KaVoLUX 540 LED U / T
Table of contents
4 / 56

Technician's instructions KaVoLUX 540 LED U / T
1 User instructions | 1.1 User guide
1 User instructions
1.1 User guide
Requirement
Read these instructions before the initial startup to prevent misuse and damage.
1.1.1 Abbreviations
Abbre-
viation
Explanation
IfU Instructions for use
CI Care instructions
AI Assembly instructions
TI Technician's instructions
SC Safety checks
IEC International Electrotechnical Commission
RI Repair instructions
EMC Electromagnetic compatibility
PI Processing instructions
1.1.2 Symbols
See the Safety/Warning Symbols section
Important information for users and technicians
CE mark (European Community). A product bearing this mark meets the re-
quirements of the applicable EU directive.
Action required
1.1.3 Target group
This document is for dentists, the dental office personnel, and the service technician.
1.2 Service
KaVo Customer Service:
[phone]
[email protected]
Please refer to the serial number of the product in all inquiries!
For further information, please visit: www.kavo.com
5 / 56

Technician's instructions KaVoLUX 540 LED U / T
1 User instructions | 1.3 Terms and conditions of warranty
6 / 56
1.3 Terms and conditions of warranty
KaVo provides the final customer with a warranty that the product cited in the han-
dover certificate will function properly and guarantees zero defects in the material or
processing for a period of 12 months from data of purchase, subject to the following
conditions:
Upon justified complaints of flaws or a short delivery, KaVo will make good its war-
ranty by replacing the product free of cost or repairing it according to the customer's
wishes. Other claims of any nature whatsoever, in particular with respect to compens-
ation, are excluded. In the event of default and gross negligence or intent, this shall
only apply in the absence of mandatory legal regulations to the contrary.
KaVo cannot be held liable for defects and their consequences due to natural wear,
improper cleaning or servicing, non-compliance with operating, servicing or connection
instructions, calcification or corrosion, contaminated air or water supplies or chemical
or electrical factors deemed abnormal or impermissible in accordance with factory
specifications.
The warranty does not usually cover bulbs, glassware, rubber parts and the colour-
fastness of plastics.
Defects or their consequences that can be attributed to interventions on or changes
made to the product by the customer or a third party are excluded from the warranty.
Claims from this warranty can only be asserted when the transfer form (copy) belong-
ing to the product has been sent to KaVo, and the original can be presented by the op-
erator or user.
1.4 Transportation and storage
1.4.1 Currently valid packaging regulations
Note
Only valid for the Federal Republic of Germany.
Dispose of and recycle the sales packaging appropriately in accordance with current
packaging regulations, employing waste management or recycling companies. Com-
ply with the comprehensive return system. KaVo has had its sales packaging licensed
for this purpose. Please comply with the regional public waste-disposal system.
1.4.2 Damage in transit
In Germany
If the packaging is visibly damaged on delivery, please proceed as follows:
1. The recipient of the package must record the loss or damage on the delivery re-
ceipt. The recipient and the representative of the shipping company must sign this
delivery receipt.
2. Leave the product and packaging in the condition in which you received it.
3. Do not use the product.
4. Report the damage to the shipping company.
5. Report the damage to KaVo.
6. Consult with KaVo first, before returning a damaged product.
7. Send the signed delivery receipt to KaVo.

Technician's instructions KaVoLUX 540 LED U / T
1 User instructions | 1.4 Transportation and storage
If the product is damaged but there was no discernable damage to the packaging on
delivery, proceed as follows:
1. Report the damage to the shipping company immediately and no later than 7 days
after delivery.
2. Report the damage to KaVo.
3. Leave the product and packaging in the condition in which you received it.
4. Do not use a damaged product.
Note
Failure on the part of the recipient to comply with any of the above-mentioned oblig-
ations will mean that the damage will be considered to have arisen following deliv-
ery (in accordance with the General German Freight Forwarders´ Terms and Condi-
tions, Art. 28).
Outside Germany
Note
KaVo shall not be held liable for damage arising from transportation.
The shipment must be checked on arrival.
If the packaging is visibly damaged on delivery, please proceed as follows:
1. The recipient of the package must record the loss or damage on the delivery re-
ceipt. The recipient and the representative of the shipping company must sign this
delivery receipt.
Without this evidence, the recipient will not be able to assert a claim for damages
against the shipping company.
2. Leave the product and packaging in the condition in which you received it.
3. Do not use the product.
If the product is damaged but there was no discernable damage to the packaging on
delivery, proceed as follows:
1. Report any damage to the shipping company either immediately or no later than 7
days after delivery.
2. Leave the product and packaging in the condition in which you received it.
3. Do not use a damaged product.
Note
If the recipient fails to comply with any of the above-mentioned obligations, the
damage will be considered to have arisen following delivery
(in accordance with CMR law, Chapter 5, Art. 30).
1.4.3 Information on the packaging: Storage and transportation
Note
Please keep the packaging in case you need to return the product for servicing or
repair.
The symbols printed on the outside are for transportation and storage, and have the
following meaning:
Transport upright with the arrows pointing upwards!
Fragile - protect against impact!
Protect from moisture!
7 / 56

Technician's instructions KaVoLUX 540 LED U / T
1 User instructions | 1.4 Transportation and storage
8 / 56
Permissible stacking load
Temperature range
Humidity
Air pressure

Technician's instructions KaVoLUX 540 LED U / T
2 Safety | 2.1 Description of safety instructions
2 Safety
2.1 Description of safety instructions
2.1.1 Warning symbol
Warning symbol
2.1.2 Structure
DANGER
The introduction describes the type and source of the hazard.
This section describes potential consequences of non-compliance.
▶ The optional step includes necessary measures for hazard prevention.
2.1.3 Description of hazardous steps
Safety instructions distinguishing between three hazard levels are used in this docu-
ment to prevent personal and property damage.
CAUTION
CAUTION
indicates a hazardous situation that can cause damage to property or mild to moder-
ate injuries.
WARNING
WARNING
indicates a hazardous situation that can lead to death or fatal injury.
DANGER
DANGER
indicates a maximal hazard due to a situation that can directly cause death or fatal in-
jury.
2.2 Purpose – Proper use
The dental operating lights KaVoLUX 540 LED U and T are designed for the illumina-
tion of the oral cavity of a patient during the dental treatment. The lights are mounted
to the dental treatment units, the use is restricted to medical specialist staff in rooms
used for medical purposes.
The type 540 LED T treatment light can also be mounted on the ceiling with an ad-
apter independent of a treatment unit.
The operation of the treatment light depends on the type of light used and is accom-
plished via:
▪ Type 540 LED U: control panel of an intended treatment unit and movement
sensor of the light
▪ Type 540 LED T: keypad on the light head and movement sensor of the light
9 / 56

Technician's instructions KaVoLUX 540 LED U / T
2 Safety | 2.2 Purpose – Proper use
10 / 56
The product complies with the requirements of DIN EN ISO 9680.
The KaVoLUX 540 LED U can be mounted to the following treatment units:
▪ ESTETICA E80 / E80 Vision
▪ ESTETICA E70 / E70 Vision
▪ ESTETICA E50 / E50 Life
The KaVoLUX 540 LED T can be mounted in the following positions/to the following
treatment centres:
▪ on the ceiling
▪ Primus 1058 / 1058 Life
▪ Status 1080
▪ Globus 1078
▪ ESTETICA Sensus 1066
▪ ESTETICA Comfort 1065
▪ ESTETICA Standard 1063
▪ ESTETICA E30
▪ DSEclinical
▪ CENTRO support system
Intended use also comprises the observation of all indications in the instructions for
used as well as adherence to prescribed inspections and maintenance.
Application of and compliance with the general guidelines and/or national laws, na-
tional regulations, and the rules of technology applicable to this product for start-up
and use of the KaVo product for the intended purpose are to be applied and complied
with.
The user must ensure that the device works safely and is in a satisfactory condition
before each use.
Note
The treatment light may no longer be operated if the functional safety and the fault-
less condition of the device cannot be guaranteed.
2.2.1 Information on electromagnetic compatibility
Note
Based on IEC 60601-1-2 (DIN EN 60601-1-2) concerning the electromagnetic com-
patibility of electrical medical devices, we must draw your attention to the following
points:
• Electrical medical devices are subject to special precautionary measures regard-
ing electromagnetic compatibility and must be operated in accordance with the
KaVo installation instructions.
• High-frequency communications devices can affect the operation of electrical
medical devices.
Further details of the technical EMC description are available on request.

Technician's instructions KaVoLUX 540 LED U / T
2 Safety | 2.2 Purpose – Proper use
Note
KaVo cannot guarantee the compliance of accessories, cables, and other compon-
ents not supplied by KaVo with the EMC requirements of IEC 60601-1-2 (DIN EN
60601-1-2).
2.2.2 Disposal
Note
Any waste which is generated must be recycled or disposed of in strict compliance
with all applicable national regulations in a manner which is safe both for people
and the environment.
If you have any questions regarding proper disposal of the KaVo product, please
contact the KaVo branch.
2.2.3 Disposal of electronic and electrical devices
Note
According to EC directive 2012/19 concerning used electrical and electronic
devices, this product is subject to the cited directive and must be disposed of ac-
cordingly within Europe.
For more information, please visit www.kavo.com or contact your specialised dental
supplier.
For final disposal:
In Germany
To return an electrical device, you need to proceed as follows:
1. On the homepage www.enretec.de of enretec GmbH, you can download a form for
a disposal order under the menu item eom. Download the disposal order or com-
plete it as an online order.
2. Enter the corresponding information to complete the order, and submit it as an on-
line order or by fax [phone] to enretec GmbH.
The following contact options are also available for questions and for initiating a
disposal order:
Phone: [phone]
Email: [email protected] and
Postal address: enretec GmbH, Geschäftsbereich eomRECYCLING®
Kanalstraße 17
D-16727 Velten
3. A unit that is not permanently installed will be picked up at the office.
A permanently installed unit will be picked up at the curb at your address on the
agreed date.
The owner or user of the device will have to bear the cost of disassembly, trans-
portation and packaging.
International
For country-specific information on disposal, contact your dental supplier.
11 / 56

Technician's instructions KaVoLUX 540 LED U / T
2 Safety | 2.3 Safety instructions
12 / 56
2.3 Safety instructions
DANGER
Explosion hazard.
Risk of fatal injury.
▶ Do not use KaVo product in areas subject an explosion hazard.
WARNING
Electrical power.
Death or injury from electric shock.
▶ Before servicing, pull the mains plug out of the socket or completely disconnect
the device from the power to de-energise it!
▶ After conversion, check the electrotechnical safety in accordance with IEC 62353
(DIN VDE 0751-1).
WARNING
Unintentional activation of the KaVo KEY Laser III and KEY Laser 3+.
Simultaneous application of the operating light KaVoLUX 540 LED and the KaVo KEY
Laser III or KEY Laser 3+ can lead to the unintentional activation of the KaVo KEY
Laser III and KEY Laser 3+.
▶ When using the KaVo KEY Laser III or the KEY Laser 3+, switch the operating
light to laser mode.
▶ Or switch off the operating light, do not use the KaVo KEY Laser III or KEY Laser
3+ and the KaVoLUX 540 LED operating light simultaneously.
CAUTION
Stroboscopic effect of the rotating instrument.
A stroboscopic effect could arise in instruments rotating at a certain speed during ap-
plication of the KaVoLUX 540 LED. This is an optical illusion that makes the hand-
piece appear to be standing still or rotating extremely slowly.
Risk of injury.
▶ If the stroboscopic effect is evident, change the speed slightly and continue work-
ing as usual.
CAUTION
Faulty measurement in connection with KaVo DIAGNOdent.
Simultaneous application of the operating light KaVoLUX 540 LED and the KaVo DIA-
GNOdent can lead to faulty measurements.
▶ Switch the operating light to laser mode when using the KaVo DIAGNOdent.
▶ Or switch off the operating light, do not use KaVo DIAGNOdent and operating
light KaVoLUX 540 LED simultaneously.
CAUTION
Damage from unsuitable accessories.
The use of accessories, other components, and cables other than those specified
(with the exception of components and cables sold by KaVo as spare parts for in-
ternal components) can increase emissions or reduce the electromagnetic immunity
of the product.
▶ Use accessories recommended by KaVo only!

Technician's instructions KaVoLUX 540 LED U / T
2 Safety | 2.3 Safety instructions
CAUTION
Electrostatic discharge.
Destroys electronic components.
▶ Before you touch the electronic circuit boards, always earth them by touching the
earthing conductor (PE).
▶ When working on an open unit, takes precautions against ESD.
▶ Always hold electronic boards on their edge only.
Note
Switch off the light during treatment intervals to increase the service life of the LED
light.
Compliance with the national statutory regulations is obligatory during the use of the
device, in particular in as far as it concerns:
▪ the applicable health and safety regulations
▪ the applicable accident prevention regulations
The user is responsible for:
▪ exclusive use of equipment that is operating correctly
▪ protecting him- or herself, the patient and third parties from danger
▪ preventing any contamination by means of the device
The following regulations must be observed for the ceiling assembly of the KaVoLUX
540 LED T:
▪ Guidelines of the regulatory and building authorities
▪ Only use fastening elements (heavy-duty dowels) that are approved by the build-
ing authorities
▪ The electrical installation may only be performed by a certified electrician
▪ The electrical installation must comply with the requirements and guidelines set
down in VDE 0100-710
The following regulations must be observed when the KaVoLUX 540 LED T is moun-
ted to a treatment center:
▪ The electrical installation must comply with the requirements and guidelines set
down in VDE 0100-710
The safety checks (SC) must be done at 24-month intervals.
See also:
211 Safety checks - Testing instructions, Page 42
13 / 56

Technician's instructions KaVoLUX 540 LED U / T
3 Function description | 3.1 Overview
14 / 56
3 Function description
3.1 Overview
① Swivel arm ② Spring arm with gas spring
③ 3D-joint (in KaVoLUX 540 LED T with
operating panel)
④ Operating light head
3.2 KaVoLUX 540 LED U / T
3.2.1 Operating light KaVoLUX 540 LED U (Unit)
The operating light control communicates with the treatment centre via CAN Bus.
The operating light is operated and adjusted via the dentist element or the assistant
element of the treatment centre or contact-free via the proximity sensor.
See also:
2GA treatment centre Chapter Operation
Note
For operation with the KaVoLUX 540 LED U, the treatment centre must be compat-
ible and the operating light type (KaVoLUX 540) must be set in service mode.

Technician's instructions KaVoLUX 540 LED U / T
3 Function description | 3.3 Description of function KaVoLUX 540 LED
3.2.2 Operating light KaVoLUX 540 LED T (touchpad)
The operating light operates self-sufficiently.
The operating light is operated and adjusted via the touchpad on the 3D swivel unit or
contact-free via the proximity sensor.
See also:
2GA treatment centre Chapter Operation
3.3 Description of function KaVoLUX 540 LED
① Top lighting unit 3 units ② Bottom lighting unit 2 units
The operating light KaVoLUX 540 LED U / T is equipped with five lighting units in the
light head. These are supplied with voltage via the PCBA control operating light, ac-
cording to the setting.
15 / 56

Technician's instructions KaVoLUX 540 LED U / T
3 Function description | 3.4 Dimensions and swing range
16 / 56
Presentation of treatment unit
Each lighting unit possesses four LEDs in different colours, which in the case of cer-
tain activation, mix and transmit different colour temperatures.
I.e.: If, for example, one of the four LEDs in a lighting unit fails, the affected operating
lighting unit will radiate another colour light.
BLEO
1
P
C
B
BLEO
2
BLEO
3
BLEU
4
BLEU
5
Diagram
All LEDs of one colour are connected in sequence via a ribbon cable. If one LED fails,
this will be automatically bridged by an LED protector.
3.4 Dimensions and swing range
CAUTION
Collision with persons or pieces of equipment.
Collisions could be caused by the required degrees of freedom and the large swivel
range
▶ Always move or swivel the operating light with great care.

Technician's instructions KaVoLUX 540 LED U / T
3 Function description | 3.4 Dimensions and swing range
843
659 120
240
300
Dimensions (in mm)
827 843
659
131°
131°
131°
131°
45°
320°
30°
30°
30° 30°
320°
118°
140°
140°
17°
17°
28°
45°
Swing ranges (in mm)
17 / 56

Technician's instructions KaVoLUX 540 LED U / T
3 Function description | 3.5 Technical data and requirements
18 / 56
3.5 Technical data and requirements
Input voltage 24 V AC
Frequency 50/60 Hertz
Power consumption max. 35 VA
Colour temperature normal light ca 4.000 to 6.000 Kelvin; preset 5.500
Kelvin (daylight quality)
Colour rendering index CRI >93 at 5,500 Kelvin Δc < 0.005
Photobiological safety (IEC 62471) Risk group 1 (low risk) The products are
safe under the majority of methods of ap-
plication, except for the case of prolonged
exposition with potentially direct eye ex-
posure.
Colour reproduction and illumination strength
Normal light approx. 20,00 to 40,000 Lux; preset
30,000 Lux in accordance
withISO 9680:2015
COMPOsave (compatible mode for light-
activatable restoration materials)
approx. 8,000 to 15,000 Lux in accord-
ance with ISO 9680:2015
Dimmed light approx. 8,000 to 15,000 Lux / approx.
4,000 K
Environmental conditions
Operating environment / temperature +10°C to +40°C
Relative humidity 30 % to 75 %
Air pressure 700 to 1060 hPa
Max. elevation for operation max. 3000 m
Transportation and storage conditions
Ambient temperature -20 oC to + 55 oC
Relative humidity 5% to 95% (non-condensating)
Air pressure: 700 to 1060 hPa

Technician's instructions KaVoLUX 540 LED U / T
4 Electrical controls | 4.1 Description of circuit board
4 Electrical controls
4.1 Description of circuit board
Mat. no. 10084486
Features of PCBA control operating lights:
▪ The PCBA control operating light receives its input voltage 24 V AC from the treat-
ment centre or from the ceiling mounting kit
▪ An operating voltage of 33 V DC is generated by the control operating light
▪ The control is equipped with its own controller
▪ The control runs with its own firmware (update via the programming adapter or
treatment centre and SD Card)
▪ The control is equipped with a temperature cutoff that is triggered in the case of
excessive temperature and is reset when the temperature returns to normal
LEDs
LED component Colour Action Step Description
V23 white on 33 V DC voltage display
V14 green KaVoLUX 540 LED U
(unit)
▪ 1 x flash pulse with
software version 1.1.4
▪ 10 x flash pulse with
software version 1.1.5
▪ Controller on PCBA
operating light is run-
ning
▪ CAN communication
with unit is in order
KaVoLUX 540 LED T
(touchpad)
▪ not possible with soft-
ware version 1.1.4
▪ 15 x flash pulse with
software version 1.1.5
▪ Controller on PCBA
operating light is run-
ning
▪ The operating light op-
erates independently
without connection to
the unit
permanently flashing Service mode activated
19 / 56

Technician's instructions KaVoLUX 540 LED U / T
4 Electrical controls | 4.1 Description of circuit board
20 / 56
Plug
Plug Description
X1 Supply voltage KaVoLUX 540 LED T / U
CAN connection only with KaVoLUX 540 LED U
X2 Slot for programming adapter
X5 Touchpad (only with KaVoLUX 540 LED T)
X6 Proximity sensor
X7 Flexible line connection to LED lighting units
