4. Product Use
4.1- EN 361:2002 Fall Arrest Harness
* Full Body Fall Arrest Harness
When full body fall arrest harness is used as fall arrester, all components
of the system should comply with the requirements of EN 363 (full fall
arrest systems). Remaining equipment which are anchoring points of har-
ness must comply with EN 795, Lanyards must comply with EN 354, Shock
absorbers must comply with EN 355, Carabiners must comply with EN 362.
* Back D Ring; ( Figure- 1 )
Use only back D rings of safety harness with other equipment described in
EN 363 ( Shock absorber, lanyard, fall arrest systems). These points were
marked with “A”in order to be recognized easily.)
4.2- EN 358:1999 Work Positioning Harness
Always use side D rings located on the back pad with a lanyard as shown in
Figure - 2Always make sure to place the lanyard at the same level of your
waist or above when positioning is performed.
4.3- EN 813:1997 Seat Harness
Figure - 3 seat harness is used when a lower point in rope access technique
or work positioning is needed. D ring in the seat harness can be used with
descenders, positioning lanyards and work area restriction lanyards.
4.4- Fall Clearance = A+B+C+D
Figure - 4 ; Fall Clearance ( Calculation of fallclearance distance)
Clearance distance should be calculated in the working area for a possible fall.
In case of fall from height, user should be able to adjust the clearence distance
in order not to hit any object or ground.
Fall Clearance
Fall clearance is the height at which a user must attach to an anchorage to
avoid contact with a lower level. In order to calculate required fallclearance
distance the following measurements must be kept in mind.
A :Length of Fall Arrest System (Lanyard)
B :Length of the Lanyard after afall
C :Height of Suspended User
D : Safety Factor
5. Product Control and Validation
5.1 Before Every Single Use
Working at height equipment must be used as personalized. These products
must be controled on a regular basis before and after each use and findings
must be recorded into product control form. Apply following controls on
an adequately lighted environment by lying the product down on a flat
surface;
• Webbings should be checked for cuts, abrasions, color change, broken stitches
and undue stretching.
• Buckles should be checked for signs of wear, cracks, deformation, corrosion
or other damages. They should function correctly and smoothly.
• D Rings and other metal parts should be checked for signs of wear,
cracks, deformation, corrosion or other damage.
• Connectors should be checked for sign of wear, cracks, deformation, corrosion,
dirt. The gate and the locking mechanisms should work easily and without
any problem. The gate should open and close completely.
• Labels should be secure and legible.
During the controls if at least one of these deviation is found, usage of the
equipment should be suspended or retired and immediately send back to
producer for detailed inspection. No repair is allowed by unauthorised person.
Only manufacturer directions should be applied.
5.2 During Each Use
When use product with a system , make sure that all pieces of equipment in
the system are correctly positioned and compatible with each other.
6. Supplementary Information Regarding Standard; EN 365
6.1 Rescue Plan
A worker who has been incapacitated by an injury or medical condition and
who is suspended by the full body harness must be rescued immediately.
So you must always have a rescue plan for such emergency situations. For
this adequately trained personnel and rescue equipment must be present.
6.2 Anchor Point
The anchor point of the system comprises this product should preferably
be located above the user or should at least at the waist level of the user.
An attachment point below this level will cause a serious injury or death.
The anchor point must conform to the requirements of the EN 795 standard
and the minimum strength of it must be12kN.
6.3 Various Situations
- A fall arrest harness is the only device allowed for supporting the body in
a fall arrest system.
- In a fall arrest system, it is essential to check the required clearance under
the user before each use, to avoid any collision with the ground or an obstacle
in case of a fall.
- Make sure that the anchor point is correctly positioned, in order to limit the
risk and the height of afall.
- When using multiple pieces of equipment together, a dangerous situation
may occur if the safety function of one piece of equipment is affected by the
safety function of another piece of equipment.
7. Kaya General Information
7.1 Life Span
Although the potential lifespan is 10 years from the date of production, it is
very difficult to define the exact service life as it varies according to the fre-
quency and intense of use, environmental conditions, correct maintenance
and storage. Recommended life expectancy of this Fall Arrest Harness is 5
years from date of first use.
If the product has one of the deviations below it should be withdrawn from
service immediately and should be destroyed to prevent further usage.
• It has suffered a heavy shock load or has had a load dropped onto it.
• There are discoloration, stiffness, cuts and tears, glazed or fused areas
on the webbing.
• There are cracks, deformation, corrosion or excessive wear on the metal
parts.
• It fails to pass inspection (before usage or detailed inspection).
• Labels (markings) are illegible or absent.
• It is extremely dirty and does not respond to normal washing.
• It has come into contact with chemicals and especially acids or is even
suspected.
• Its history is unknown.
• Its lifespan stated in the user’s manual has expired or even it has never
been used.
• There is a slightest doubt that the product is no more safe and reliable.
7.2 Storage
Product is sold with storage bag and user guide. Additionally model and
applied standards are provided with the product. During the storage keep
the product in it’s own bag. Storage area of the product should meet the
following requirements;
- Dry, away from direct sun light, room temperature.
- Do not store together with acids, solvents etc.
- Keep away from direct heat sources.
- If the product gets humid during the storage, dry the product in room
temperature before usage.
7.3 Maintenance
Personal protection equipment should be checked regularly to make sure
that the equipment will operate properly whenever it is used Harness can
be wiped with a wet sponge, for cleaning.
A mild soap and warm water not exceeding 30ºC can be used for difficult stains.
After cleaning, it should be thoroughly rinsed in clean cold water, hung out in a
dry, dark and cool place and kept away from the direct heat sources. Harnesses
should be hung out or placed loosely in a bag or another container in order to
protect it from harmful fumes, corrosive agent or light (artificial or sunlight).
Do not use acidic or solvent chemicals!
7.4 Changes and Repair
Changing a part, repair and addition to any component to product is strictly
forbidden without written authorization of KAYA. Any repair can be made only
by KAYA. Otherwise KAYA is not responsible for any possible consequences.
7.5 Transportation of Product
The product should be transported in a bag to protect it from damp,
chemicals and other objects.
7.6 Periodic Inspection of Product
Harness should be inspected by the user before each use and an additional
detailed inspection must be carried out by an authorized person in every
12 months.
During the inspection of product following information should be recorded;
Type of the product, model, contact information of manufacturer, serial
number, date of production, date of purchase, date of first usage, next
inspection date, problems, recommendations, name and surname of the
inspector. For further information visit www.kayasafety.com
7.7 Guarantee
This product has 3-year guarantee against all material or manufacturing
defects under proper usage and storage conditions. Guarantee will be void if;
product is misused; torn, cut, corroded; in case of unauthorized repair or
changes are made on the product or damaged by accidents.
8. Certification
This product is certified in accordance with 89/686/EEC directive by
TÜVSÜD ProductService CE0123 Notified Body after tests according to EN
358:1999, EN 361:2002, EN 813:2008
* KAYA SAFETY has CE0082 (APAVE SUDEUROPE SAS) notified bodynum-
ber 89/686/EEC 11 B Quality System certificate and commit to
produce each product same as tested sample.
APAVE SUDEUROPE SAS (n°0082)
13322 MARSEILLECEDEX 16 – France
T: +33 (0) 4 76 53 52 22 F: +33 (0) 4 76 53 32 40
Warning: Read user guide carefully before usage.
